Telstra EasyCall 2 User manual

Telstra EasyCall® 2 Mobile Phone
User Guide
LEGAL INFORMATION
Copyright © 2010 ZTE CORPORATION.
Version 1.0 March 2011 All rights reserved.
No part of this publication may be excerpted, reproduced, translated or utilized in any form or
by any means, electronic or mechanical, including photocopying and microfilm, without the
prior written permission of ZTE Corporation.
The manual is published by ZTE Corporation. We reserve the right to make modifications on
print errors or update specifications without prior notice.
1

Index
1Introduction........................................................................................................4
1.1 General Precautions........................................................................................4
1.2 Precautions While Driving ................................................................................5
1.3 Aircraft Safety................................................................................................5
1.4 Precautions for Medical Devices and Facilities......................................................5
1.5 Precautions for Potentially Explosive Atmospheres...............................................6
1.6 Battery Safety ...............................................................................................6
1.7 Limitation of Liability ......................................................................................7
1.8 RF Safety (SAR) ..............................................................................................7
2Getting Started....................................................................................................8
2.1 Insert the SIM Card .........................................................................................8
2.2 Insert the battery ...........................................................................................9
2.3 Charging the battery.....................................................................................10
2.4 Battery level indicator ................................................................................... 11
2.5 Switch your phone On................................................................................... 11
3Get to know your phone .....................................................................................12
3.1 Your phone..................................................................................................12
3.2 Main Display ...............................................................................................13
3.3 Display Icons ...............................................................................................13
3.4 Key functions...............................................................................................14
3.5 Menu Map ..................................................................................................16
2

4Step by step guide..............................................................................................17
4.1 Switch Setting..............................................................................................17
4.2 Make and receive a call..................................................................................18
4.3 Add a Contact to your Phone Book ..................................................................19
4.4 Make a call from the Phone Book ....................................................................19
4.5 Messages ....................................................................................................20
4.6 Text Input methods ......................................................................................21
4.7 Phone Book .................................................................................................22
4.8 Speed Dial ...................................................................................................23
4.9 Call History..................................................................................................23
4.10 Settings > Audio Settings ...............................................................................24
4.11 Settings > Phone Settings...............................................................................25
4.12 Settings > Call Settings ..................................................................................26
4.13 Settings > Network Settings............................................................................27
4.14 Settings > Security Code ................................................................................27
4.15 Organiser > Alarms / Reminders.......................................................................27
4.16 Organiser > Calendar.....................................................................................29
4.17 Organiser > Calculator ...................................................................................29
4.18 Torch ..........................................................................................................29
4.19 Keylock Switch.............................................................................................29
4.20 FM Radio Switch...........................................................................................30
Technical Reference .....................................................................................................31
4.21 Technical Specifications.................................................................................31
4.22 Service Information ......................................................................................31
4.23 Warranty Information ...................................................................................32
4.24 Network Locked Device..................................................................................32
3

1Introduction
This section includes some important information on safety and efficient operation.
Please read this section before using the phone.
1.1 General Precautions
The antenna is located in the top portion of the handset, behind the display. When you
are using the handset try to avoid shielding the antenna area with your hand. Hold the
handset between your thumb and fingers towards the base of the handset. This will leave
the antenna area clear to transmit and receive signals. Touching the antenna area affects
call quality and may cause the phone to operate at a higher power level than needed.
Keep the phone out of the reach of small children. The phone may cause injury or be
damaged.
Protect the handset from liquids. Only use a soft dry cloth to clean the handset.
The handset will be damaged by liquid ingress. The handset contains a liquid detection
sticker which changes colour when exposed to liquids. Liquid ingress is not covered by
warranty under any circumstances.
Do not expose the handset to solvents, chemicals or abrasive cleaning products.
Do not expose the handset or battery to prolonged direct sunlight or temperatures
exceeding 50˚C. This may damage the battery and high temperatures can shorten the life
of electronic devices.
Please use original accessories only. Damage caused by non-genuine accessories may not
be covered by your warranty terms and conditions.
As your mobile phone can produce electromagnetic field, do not place it near magnetic
items such as computer disks or bank cards. Do not expose to metal filings which can stick
to the speaker area.
4

Using the phone near electrical appliances such as TV, telephone, radio and personal
computer may cause interference.
Do not drop or throw your handset.Rough handling can cause physical damage.
Do not attempt to disassemble the handset or battery.
1.2 Precautions While Driving
Obey all safety regulations and do not use your phone while driving.
Do not place your phone on an airbag or in the airbag deployment area. If a phone is in
the airbag deployment area it may be propelled with great force and cause injury to
occupants of the vehicle.
Please turn off your mobile phone at service stations as recommended.
1.3 Aircraft Safety
Please turn off your mobile phone before boarding as instructed by the airline personnel.
Disable your alarms to make sure that the phone does not turn on during the flight.
1.4 Precautions for Medical Devices and Facilities
If you use a pacemaker please keep the phone at least twenty centimetres from the
pacemaker when the phone is switched on. Do not carry the phone in your breast pocket.
Use the ear opposite the pacemaker to minimize the potential for interference. Switch off
the phone immediately if necessary.
Some phones may interfere with hearing aids. In the event of such interference consult
your hearing aid manufacturer to discuss alternatives.
If you use any other personal medical device, please consult the manufacturer of your
device to determine if it is adequately shielded from RF energy.
5

Obey the restrictions on the use of mobile phones at prescribed places such as hospitals,
airports, service stations,refineries, chemical works etc.Switch off your phone as required.
1.5 Precautions for Potentially Explosive Atmospheres
Switch off your phone prior to entering any area with potentially explosive atmospheres,
such as fuel or chemical transfer or storage facilities.
Do not remove, install, or charge batteries in such areas. Spark in a potentially explosive
atmosphere can cause explosion or fire.
To avoid possible interference with blasting operations switch off your phone when you
are near electrical blasting caps, in a blasting area, or in areas posted “Turn off electronic
devices.” Obey all signs and instructions.
Do not store the phone with flammable or explosive articles.
1.6 Battery Safety
Do not short-circuit the battery terminals. Do not carry the battery in your pocket in case
of accidental short circuits.
Do not store battery in hot areas or dispose of the battery in a fire.
Do not disassemble,pierce or modify the battery in any way.
Please store the battery in a cool dry place if you are not using it.
The battery is rechargeable but eventually it will wear out. When the operating time (talk
time and standby time) is reduced you should replace your battery.
Please stop using the charger and battery if they are damaged.
Return the worn-out battery to your service provider or dispose of it in accordance with
environmental regulations.Do not dispose of it in household rubbish.
6

1.7 Limitation of Liability
ZTE shall not be liable for any loss of profits or indirect, special, incidental or consequential
damages resulting from or arising out of or in connection with using this product, whether or
not ZTE had been advised, knew or should have known the possibility of such damages. The
user should refer to the enclosed warranty card for full warranty and service information.
1.8 RF Safety (SAR)
SAR tests have been completed as per the Radiocommunications Standard 2003 (Human
Exposure). The limit defined by this standard is 2.0W/Kg. The highest value SAR recorded for the
device is 1.13W/Kg at 850Mhz UMTS.
Notes
The pictures and icons shown in the manual are for reference only. The manufacturer
reserves the right to update the product at any time.
Your handset is locked to the Telstra network. If you wish to use your handset with
another service provider you need to contact Telstra to obtain the unlocking code. An
unlocking fee may apply for this service.
Warning:
If the battery is damaged do not recharge it. In the unlikely event of battery leakage
avoid contact with your skin and wash the affected area thoroughly in water.
7

2Getting Started
2.1 Insert the SIM Card
8
Remove the battery cover by pressing down on the back cover and sliding the cover
down. Insert the SIM card with the metal contacts facing down and the notch on the
bottom left corner as shown:

2.2 Insert the battery
1. Insert the battery carefully with the contacts located against the gold springs - the
battery will only fit one way.
9
2. Replace the battery cover. Make sure that the cover closes completely.

2.3 Charging the battery
The phone can be charged in the On or Off state. Make sure that the battery is
inserted before charging.
10
The charger lead is keyed and will only
fit one way. Insert the lead carefully
observing the correct alignment of the
plug and socket.

2.4 Battery level indicator
Charging Charged
The phone will give an audible alert when battery is low and display a low battery
message on screen. Please recharge the battery promptly to maintain service.
2.5 Switch your phone On
Press and hold the red key for 2 seconds to switch the phone on. Enter the PIN
code supplied with your SIM card. Press the green key (OK) to enter.
Warning: If you enter the wrong code three times your SIM card will be locked. The
phone will request you to enter the PUK code. Contact your service provider to obtain
the PUK code if required.
If your handset displays:
PIN: Enter the PIN supplied with your SIM card.
Limited Service Check the SIM card is inserted correctly.
Enter PUK code Contact your Service Provider.
11

3Get to know your phone
12
3.1 Your phone

3.2 Main Display
Information Bar
Network Provider
Time & Day
Date
3.3 Display Icons
Battery level Keypad locked
Network signal level Headset inserted
New SMS message Alarm enabled
SMS memory is full Silent Mode enabled
Missed call CTM Mode enabled (TTY)
Call Forwarding active Roaming
13

3.4 Key functions
Function Description
Call key
(Green Key)
Press to make a call. Press to answer an incoming call.
From the idle screen, press to enter the call history list.
Press to confirm the function you choose.
End key
(Red Key)
Long press to power on or off.
Press to go back to previous menu.
Clear text and numbers
Up key From the idle screen press to access the main menu.
Press to move cursor up.
Down key From the idle screen, press to enter Phone Book.
Press to move cursor down.
# key
Press to input ‘#’. Switch SMS text input mode – (Predictive)
Hold down to engage / disengage Silent mode.
14

Function Description
*key From the idle screen press to enter ‘*’,‘+’,‘W’, or ‘P’
Use + for the international dialling prefix.
‘W’ will wait until the next number is entered into the
dialling sequence.
‘P’ inserts a 3 second pause into the dialling sequence.
In SMS mode press to access common symbols.
Numeric keys Enter numbers 0-9 and characters A-Z.
Switch Activate your Switch Call and SMS (see Switch Setting).
Volume keys Adjust the volume up and down.
Torch switch Turn the torch on or off.
FM radio key Turn the FM radio on or off.
Keylock switch Lock and unlock keypad.
15

3.5 Menu Map
16

4Step by step guide
4.1 Switch Setting
The Switch on the back of the handset can be programmed to make a call and/or
send an SMS to friends or relatives simultaneously.
Press Down > Down > Down > Down to get to the Settings Menu
Go to Settings > Switch Setup > Switch to enable this feature. The switch is Off by
default.
Go to Settings > Switch Setup > Switch Number to program your phone numbers:
1. The first location will define the voice call number.
2. Location 2-5 defines the SMS numbers.
Go to Settings > Switch Setup > Switch SMS: To send an automated text message
you must enter a message in this field.
When enabled and programmed, pushing the Switch Key will send an SMS
message to numbers 2-5 and initiate a call to the first defined number.
The Alert tone (when enabled) will continue after the call until the Switch Key is
pushed back to the down position.
When the call is connected the handset automatically enables Handsfree
(speaker-phone) mode.
The alert tone volume can be adjusted to Off, Low, Medium or Loud
In any state, push the Switch key down to return the phone to standby mode.
Switch Dialling is still activated when the keypad is locked.
17

4.2 Make and receive a call
Enter the phone number using the number keys and press the Green key to dial. If
you enter a wrong digit use the Red Key to delete the mistake. Long press the Red
key to clear all the characters and return to the idle screen.
Press the * key twice to enter ‘+’for international dialling.
Press the * key three times for the Wait symbol ‘W’ which will hold dialling until
the next key is pressed.
Press the * key four times for the Pause symbol ‘P’ which adds a 3 second delay
into the dialled number.
Press the Green key to answer an incoming call, press Option > HF on to enable
speaker mode (Handsfree). Press the Red key to end or reject the call.
If you have set speed dial numbers long press the numeric keys (2, 4 to 9) to dial
the corresponding contact.
Press the Volume keys to adjust volume during the call.
Press and hold the 0 key to select the In Call volume level which you can
pre-define. Eg. If your normal ear-piece volume is 3, you can set the In Call volume
setting to 5 which you can use in noisy environments to give a quick volume
boost to the earpiece if required. See Audio Settings for more information.
Press the Red key to hang-up (End) the call.
18

4.3 Add a Contact to your Phone Book
Menu > Phone Book > Add New Contact > To Phone, To SIM > Name > Edit
Type in the Name using the keypad letter keys, (eg press the key once for the first
letter, twice for the second letter etc.), press OK when finished.
Press the # key to change text input modes (abc, ABC, 123) if required.
Menu > Phone Book > Add New Contact > To Phone, To SIM > Number > Edit
Enter the number using the number keys,press OK when finished
Press Done and then Yes to Save when prompted.
4.4 Make a call from the Phone Book
Press the Down Arrow Key to open the Phone Book Search view
Press the letter keys shown on the keypad to search for the name of your Phone
Book contact.
Eg. Press 5 to search for John.Press 5 twice to search for Karen.
Use the up and down arrows to scan your Phone Book contacts
When you have selected the required contact press Option > Dial to make a call to
that contact. Select the correct number where multiple numbers are stored.
19

4.5 Messages
The envelope icon indicates a new message.
Press the Green key to read the message. Press the Red key to exit.
The double envelope icon indicates the mail box is full. Please delete some
SMS messages.
From the idle screen press Up > Down to access Messages > Write message to
start a new message.Press the Green key for the option to save or send the SMS.
Press the # key to switch text input methods (eZiEng, abc, Abc, ABC, 123).
The Inbox shows all your received messages. Press OK to view the message. Press
Options to Reply, Delete, Forward, Delete All, Use Number, Move to (U)SIM,Copy
to (U)SIM.
The Outbox shows messages that failed to send. Sent shows sent messages.
Drafts shows all your saved messages which have not been sent.
Select Message Settings for Valid Time, SMS Centre Number, Delivery Report and
Cell ID Display options.
20
