Teltonika A13FMC User manual

FMC13A
ADVANCED LTE TERMINAL WITH
FLEXIBLE INPUTS CONFIGURATION
Quick Manual v1.9

Quick Manual v2.0 // FMC13A 2
Telematics
CONTENT
Content.................................................................................................................................................................................................................2
Know your device................................................................................................................................................................................................3
Pinout ...................................................................................................................................................................................................................4
Wiring scheme.....................................................................................................................................................................................................5
Set up your device ..............................................................................................................................................................................................6
PC Connection (Windows)..................................................................................................................................................................................7
How to install USB drivers (Windows) ..............................................................................................................................................................7
Conguration.......................................................................................................................................................................................................8
Quick SMS conguration................................................................................................................................................................................. 10
Mounting recommendations.......................................................................................................................................................................... 12
Basic characteristics ........................................................................................................................................................................................ 13
LED indications................................................................................................................................................................................................. 13
Electrical characteristics.................................................................................................................................................................................. 16
Safety information .......................................................................................................................................................................................... 18
Certication ...................................................................................................................................................................................................... 19
Warranty ........................................................................................................................................................................................................... 21
Warranty disclaimer ....................................................................................................................................................................................... 21

Quick Manual v2.0 // FMC13A 3
Telematics
KNOW YOUR DEVICE
STATUS
LED
NAVIGATE
LED
MICRO-SIM
SLOT
BATTERY
SOCKET
2x6
SOCKET
GNSS
ANTENA
TOP VIEW TOP VIEW
(WITHOUT COVER)
BOTTOM VIEW
(WITHOUT COVER)

Quick Manual v2.0 // FMC13A 4
Telematics
PINOUT
10
9
8
7
11
12
4
3
2
1
5
6
DOUT2
1WIRE POWER
1WIRE DATA
GND
DOUT1
INPUT 5
DIN3/AIN2
DIN 2-N / AIN 1
DIN1
DOUT3
+10...30 V DC
INPUT 6
FMC13A 2x6 socket pinout
PIN NUMBER PIN NAME DESCRIPTION
1 VCC (10-30) V DC (+) Power supply (10-30
V DC)
2 DOUT 3
Digital output, channel
3. Open collector output.
Max. 0,5 A DC
3 DIN 3 / AIN 2
Analog input, channel 2.
Input range: 0-30 V DC /
Digital input, channel 3
4 DIN 2-N / AIN 1
Digital input, channel 2,
Negative input (ground
sense), Analog input,
channel 1, Input range:
0-30 VDC
5 DIN 1 Digital input, channel 1
6 INPUT 6 TX EXT (LVCAN – TX)
7 GND (-) Ground pin. (10-30) V
DC (―)
8 DOUT 1
Digital output, channel
1. Open collector output.
Max. 0,5 A DC
9 DOUT 2
Digital output, channel
2. Open collector output.
Max. 0,5 A DC
10 1WIRE POWER +3,8 V output for 1–Wire
devices
11 1WIRE DATA Data for 1–Wire devices
12 INPUT 5V RX EXT (LVCAN - RX)

Quick Manual v2.0 // FMC13A 5
Telematics
WIRING SCHEME
BUZZER
30
8586
87a
87
IGNITION
DETECTION
FUEL GAUGE
STARTER
IBUTTON
POWER SUPPLY
10 - 30V DC
ANALOG
LLS SENSOR
CAN-CONTROL
ALARM BUTTON
DOOR SENSOR CENTRAL LOCK
DOUT2
1WIRE POWER
1WIRE DATA
GND
DOUT1
INPUT 5
DIN3/AIN2
DIN2-N/AIN1
DIN1
DOUT3
+10...30 V DC
INPUT 6
AIN2
DIN3
DIN2
DIN2-N
10
9
8
7
11
12
4
3
2
1
5
6

Quick Manual v2.0 // FMC13A 6
Telematics
SET UP YOUR DEVICE
HOW TO INSERT MICRO-SIM CARD AND CONNECT THE BATTERY
4
1COVER REMOVAL 3BATTERY CONNECTION 2MICRO-SIM CARD INSERT ATTACHING COVER BACK
You will receive your device
partly closed. Gently remove
top and bottom covers.
Insert SIM card as shown
with PIN request disabled
or read our Wiki1how to
enter it later in Teltonika
Congurator2. Make sure
that Micro-SIM card cut-o
corner is pointing outward
from slot. SIM slot 1 is closer
to PCB, SIM slot 2 is the top
one.
1 wiki.teltonika-gps.com/view/
FMC13A_Security_info
2 wiki.teltonika-gps.com/view/
Teltonika_Congurator
Connect battery as shown to
device. Position the battery
in place where it does not
obstruct other components.
After conguration, see
“PC Connection (Windows)”,
attach device top and
bottom cover back and
press them twice to the
full closure. Make sure that
product casing is closed
correctly.

Quick Manual v2.0 // FMC13A 7
Telematics
PC CONNECTION (WINDOWS)
HOW TO INSTALL USB DRIVERS (WINDOWS)
1. Power-up FMC13A with DC voltage (10 – 30 V) power supply using supplied power cable. LED’s should start blinking, see “LED
indications”.
2. Connect device to computer using Micro-USB cable or Bluetooth connection:
• Using Micro-USB cable
• You will need to install USB drivers, see “How to install USB drivers (Windows)”
• Using Bluetooth
• FMC13A Bluetooth is enabled by default. Turn on Bluetooth on your PC, then select Add Bluetooth or other device >
Bluetooth. Choose your device named – “FMC13A_last_7_imei_digits”, without LE in the end. Enter default password 5555,
press Connect and then select Done.
3. You are now ready to use the device on your computer.
1. Please download COM port drivers from here.
2. Extract and run TeltonikaCOMDriver.exe.
3. Click Next in driver installation window.
4. In the following window click Install button.
5. Setup will continue installing the driver and eventually the conrmation window will appear. Click Finish to complete the
setup.

Quick Manual v2.0 // FMC13A 8
Telematics
At rst FMC13A device will have default factory settings set. These settings should be changed according to the users needs. Main
conguration can be performed via Teltonika Congurator1software. Get the latest Congurator version from here2. Congurator
operates on Microsoft Windows OS and uses prerequisite MS .NET Framework. Make sure you have the correct version installed.
1 wiki.teltonika-gps.com/view/Teltonika_Congurator
2 wiki.teltonika-gps.com/view/Teltonika_Congurator_versions
CONFIGURATION
MS .NET REQUIREMENTS
Operating system MS .NET Framework version Version Links
Windows Vista
Windows 7
Windows 8.1
Windows 10
MS .NET Framework 4.6.2 32 and 64 bit www.microsoft.com1
1 https://dotnet.microsoft.com/en-us/download/dotnet-framework/net462

Quick Manual v2.0 // FMC13A 9
Telematics
Downloaded Congurator will be in compressed archive.
Extract it and launch Congurator.exe. After launch software
language can be changed by clicking 🌐in the right bottom
corner.
Conguration process begins by pressing on connected device.
FMC13A
Various Status window1 tabs display information about GNSS2,
GSM3, I/O4, Maintenance5and etc. FMC13A has one user
editable prole, which can be loaded and saved to the device.
After any modication of conguration the changes need to
be saved to device using Save to device button. Main buttons
oer following functionality:
 Load from device – loads conguration from device.
 Save to device – saves conguration to device.
 Load from le – loads conguration from le.
 Save to le – saves conguration to le.
 Update rmware – updates rmware on device.
 Read records – reads records from the device.
 Reboot device – restarts device.
 Reset conguration – sets device conguration to
default.
Most important congurator section is GPRS – where all
your server and GPRS settings6 can be congured and Data
Acquisition7– where data acquiring parameters can be
congured. More details about FMC13A conguration using
Congurator can be found in our Wiki8.
After connection to Congurator Status window will be
displayed.
FMC13A
1 wiki.teltonika-gps.com/view/FMC13A_Status_info
2 wiki.teltonika-gps.com/view/FMC13A_Status_info#GNSS_Info
3wiki.teltonika-gps.com/view/FMC13A_Status_info#GSM_Info
4wiki.teltonika-gps.com/view/FMC13A_Status_info#I.2FO_Info
5wiki.teltonika-gps.com/view/FMC13A_Status_info#Maintenance
6 wiki.teltonika-gps.com/view/FMC13A_GPRS_settings
7 wiki.teltonika-gps.com/view/FMC13A_Data_acquisition_settings
8 wiki.teltonika-gps.com/view/FMC13A_Congurationn

Quick Manual v2.0 // FMC13A 10
Telematics
QUICK SMS CONFIGURATION
Default conguration has optimal parameters present to ensure best performance of track quality and data usage.
Quickly set up your device by sending this SMS command to it:
Note: Before SMS text, two space symbols should be inserted.
GPRS SETTINGS:
 2001 – APN
 2002 – APN username (if there are no APN username,
empty eld should be left)
 2003 – APN password (if there are no APN password,
empty eld should be left)
SERVER SETTINGS:
 2004 – Domain
 2005 – Port
 2006 – Data sending protocol (0 – TCP, 1 – UDP)
« setparam 2001:APN;2002:APN_username;2003:APN_password;2004:Domain;2005:Port;2006:0»
1 2 3 4 5 6
1
2
3
4
5
6
