How to capture remote Tacho log from FM
device?
Main Page > Frequently Asked Questions - FAQ > How to capture remote Tacho log from FM device?
Contents
1 Supported devices
2 How does it work?
3 Steps to collect log file
4 How the received tacho log should look like
Supported devices
Solution applies for these devices:
FM6300/FMB630/FM6320
FMB640
FMC640
FMM640
FMB641
FMC650
FMM650
How does it work?
Fleet management devices Tacho log capturing is initiated using the command log2srv and by
setting the right configuration. The device establishes a GPRS connection and activates the link to
the computer, log starts to stream to the computer until the set time is elapsed. To stop streaming
log immediately log2srvstop is used.
Steps to collect log file
Here are steps on how to capture a Tacho online log from FM series devices:
Make sure you have external IP address with opened TCP port. This could be checked here.1.
Download "Hercules" program from www.hw-group.com and start it.2.
Go to (1) TCP Server → (2) Enter your
opened TCP port → (3) Press Listen then
click right mouse button over Received or
Sent data window → (4) Go to Special
Chars → (5) Set ASCII Names.
Click right mouse button over Received or
Sent data window → (1) Go to Log to File →
(2) Set file name and directory where
captured log will be saved → (3) Press Log
Enable.

Make sure that the FM device is turned on and the vehicle's ignition is turned on.3.
Send following SMS command to FM device:4.
If you have set SMS login and password: login pass log2srv
1,6,APN,APNusername,APNpassword,IP,port,1200,0
APN - Operator APN name of the SIM card, which is inserted into the device from which
the log will be captured.
APNusername - Operator APN username of the SIM card, which is inserted into the
device from which the log will be captured.
APNpassword - Operator APN password of the SIM card, which is inserted into the
device from which the log will be captured.
IP - External IP address of the computer to which the device will connect.
port - Opened TCP port (used in Hercules) of external ip address to which the device
will connect.
Command example: opa opa log2srv
1,6,banga,,,212.59.13.226,7056,1200,0
If SMS login and password are not set to leave two spaces before the command:
aalog2srv 1,6,APN,APNusername,APNpassword,IP,port,1200,0
If the command was sent correctly you should receive SMS Response:LOG2SRV OK=1,
6, IP, port, 1200, 0
Up to 5 minutes delay could appear if wrong log2srv commands settings will be
sent, during that time no SMS or GPRS command could be received. SMS will be
hanging, after timeout, hanging SMS’s will be proceeded.
After successful SMS response device will start streaming log to Hercules program. (1)5.
Logfile bytes will start increasing and (2) connected device will appear. Device log will be
captured for 20 minutes.
After the log will start coming send the following command, which will force the device6.
connection to the remote DDD download platform:
If you have set SMS login and password: login pass tacho_connect
If SMS login and password are not set to leave two spaces before the command:
aatacho_connect
Provide captured log to your Teltonika Sales Manager or Teltonika Support team for7.
further investigation.
If you want to stop log capturing immediately send following SMS command to FM device:
If you have set SMS login and password: login pass log2srvstop
If SMS login and password are not set to leave two spaces before the command:

aalog2srvstop
How the received tacho log should look like
TODO
