Teltonika FMB630 User manual

FMB630 User Manual
V1.8

2
Table of contents
1INTRODUCTION .................................................................................................................... 7
1.1 ATTENTION............................................................................................................................ 7
1.2 INSTRUCTIONS OF SAFETY ......................................................................................................... 8
1.3 LEGAL NOTICE........................................................................................................................ 8
1.4 ABOUT DOCUMENT ................................................................................................................. 8
2BASIC DESCRIPTION.............................................................................................................. 9
2.1 PACKAGE CONTENTS ................................................................................................................ 9
2.2 BASIC CHARACTERISTICS ........................................................................................................... 9
2.3 MECHANICAL FEATURES ......................................................................................................... 10
2.4 TECHNICAL INFORMATION ABOUT INTERNAL BATTERY! ................................................................. 11
2.4.1 Battery Disposal instructions:................................................................................. 12
2.5 ELECTRICAL CHARACTERISTICS.................................................................................................. 12
2.6 ABSOLUTE MAXIMUM RATINGS............................................................................................... 13
3CONNECTION AND PINOUT ................................................................................................ 14
3.1 SIM CARD INSERT SCHEME...................................................................................................... 14
3.2 INSTALLING FMB630 DRIVERS ................................................................................................ 16
3.3 NAVIGATE LED..................................................................................................................... 17
3.4 STATUS LED ........................................................................................................................ 17
3.5 SOCKET 210 PINOUT ........................................................................................................... 18
3.6 USB................................................................................................................................... 19
3.7 ACCESSORIES........................................................................................................................ 19
4FIRMWARE ......................................................................................................................... 26
4.1 UPDATING FIRMWARE USING USB CABLE .................................................................................. 26
5OPERATIONAL BASICS ........................................................................................................ 27
5.1 OPERATIONAL PRINCIPLES....................................................................................................... 27
5.2 OPERATIONAL MODES ........................................................................................................... 28
5.3 ACCELEROMETER .................................................................................................................. 28
5.4 VIRTUAL ODOMETER ............................................................................................................. 28
5.5 PROFILES............................................................................................................................. 28
5.6 FEATURES............................................................................................................................ 29
5.6.1 Scenarios ................................................................................................................ 29
5.6.1.1 ECO driving or Green driving Scenario. .............................................................................. 29
5.6.1.2 Over Speeding Scenario. .................................................................................................... 29
5.6.1.3 Authorized Driving and Immobilizer Scenario. ................................................................... 29
5.6.1.4 iButton notification. ........................................................................................................... 29
5.6.1.5 Excessive idling................................................................................................................... 30
5.6.1.6 Jamming detection............................................................................................................. 30
5.6.1.7 Crash detection. ................................................................................................................. 30
5.6.2 Trip.......................................................................................................................... 30
5.6.3 Geofencing.............................................................................................................. 30
5.6.4 Auto Geofencing ..................................................................................................... 30
5.6.5 Towing Detection.................................................................................................... 30
5.6.6 iButton list .............................................................................................................. 31
6CONFIGURATOR ................................................................................................................. 31
6.1 STARTUP........................................................................................................................... 31
6.2 CONFIGURATOR STRUCTURE.................................................................................................... 31
6.2.1 Buttons area ........................................................................................................... 32
6.2.2 Information area .................................................................................................... 33
6.2.3 Profiles/global parameters selection area ............................................................. 33
6.3 PARAMETERS CONFIGURATION ................................................................................................ 34

3
6.3.1 Global parameters Settings .................................................................................... 34
6.3.2 External Devices Settings....................................................................................... 35
6.3.3 Settings and configurable parameters menu ......................................................... 36
6.3.4 System Settings....................................................................................................... 36
6.3.5 GSM Settings .......................................................................................................... 37
6.3.5.1 GPRS................................................................................................................................... 37
6.3.5.2 Data limits functionality ..................................................................................................... 38
6.3.5.3 SMS Security....................................................................................................................... 38
6.3.5.4 SMS Data ............................................................................................................................ 39
6.3.5.5 SMS Events......................................................................................................................... 40
6.3.5.6 Operator List ...................................................................................................................... 41
6.3.5.7 Connection to device via Bluetooth ................................................................................... 42
6.3.6 Features.................................................................................................................. 43
6.3.6.1 sMode ................................................................................................................................ 43
6.3.6.2 Scenarios ............................................................................................................................ 43
6.3.6.3 Trip ..................................................................................................................................... 44
6.3.6.4 Geofencing ......................................................................................................................... 45
6.3.6.5 AutoGeofencing ................................................................................................................. 47
6.3.6.6 Towing Detection ............................................................................................................... 48
6.3.6.7 IButton List ......................................................................................................................... 49
6.3.7 CAN......................................................................................................................... 49
6.3.7.1 CAN Bus settings ................................................................................................................ 49
6.3.8 I/O........................................................................................................................... 52
6.3.8.1 FMB630 available I/O list ................................................................................................... 52
6.3.8.2 I/O configuring ................................................................................................................... 56
6.3.8.3 I/O properties..................................................................................................................... 57
6.3.8.4 SMS event configuration .................................................................................................... 59
6.3.8.5 LVCAN/ALL-CAN300 I/O elements...................................................................................... 60
6.3.8.6 K-Line parameters .............................................................................................................. 61
6.3.8.7 Configurable parameter values and Global parameter values........................................... 64
7PROFILE SWITCHING ........................................................................................................... 72
7.1 PROFILE SWITCHING DEPENDENCE ON GSM OPERATOR ............................................................... 72
7.2 PROFILE SWITCHING DEPENDENCE ON I/O EVENT ........................................................................ 74
7.2.1 Example #1 ............................................................................................................. 75
7.2.2 Example #2 ............................................................................................................. 75
8DUAL SIM FUNCTIONALITY ................................................................................................. 76
8.1.1 Home Network........................................................................................................ 77
8.1.2 SIM 1 Roaming ....................................................................................................... 77
8.1.3 SIM 2 Roaming ....................................................................................................... 78
8.1.4 Unknown Operator................................................................................................. 79
8.1.5 Dual SIM algorithm................................................................................................. 80
9DATA ACQUISITION ............................................................................................................ 81
9.1 GPS DATA ACQUISITION ......................................................................................................... 81
9.1.1 Min. Period ............................................................................................................. 81
9.1.2 Min. Distance.......................................................................................................... 82
9.1.3 Min. Angle .............................................................................................................. 82
9.1.4 Min. Speed.............................................................................................................. 82
9.2 I/O DATA ACQUISITION .......................................................................................................... 83
9.2.1 Configuration.......................................................................................................... 83
9.2.2 Event generation .................................................................................................... 83
10 SLEEP MODE ....................................................................................................................... 84
11 DEEP SLEEP MODE .............................................................................................................. 85
12 ONLINE DEEP SLEEP MODE ................................................................................................. 86
13 FEATURES AND SCENARIOS ................................................................................................ 86
13.1 ECO DRIVING OR GREEN DRIVING SCENARIOS............................................................................. 86

4
13.1.1 Mounting Requirements......................................................................................... 87
13.1.2 Configuration.......................................................................................................... 89
13.1.3 Data output ............................................................................................................ 89
13.2 OVERSPEEDING SCENARIO ...................................................................................................... 90
13.2.1 Mounting Requirements and Working Conditions ................................................. 90
13.2.2 Configuration.......................................................................................................... 90
13.3 IMMOBILIZER/AUTHORIZED DRIVING SCENARIO ......................................................................... 90
13.3.1 Configuration.......................................................................................................... 91
13.3.2 Configuration.......................................................................................................... 91
13.4 EXCESSIVE IDLING SCENARIO ................................................................................................... 91
13.5 JAMMING DETECTION SCENARIO.............................................................................................. 92
13.5.1 Configuration.......................................................................................................... 92
13.6 IBUTTON NOTIFICATION SCENARIO........................................................................................... 92
13.6.1 Configuraton........................................................................................................... 92
13.7 CRASH DETECTION SCENARIO.................................................................................................. 93
13.7.1 Configuration.......................................................................................................... 93
13.8 COM1 AND COM2 WORKING MODES .................................................................................... 93
13.8.1 Silent Mode............................................................................................................. 93
13.8.2 FM Log Mode.......................................................................................................... 93
13.8.3 LLS Mode ................................................................................................................ 93
13.8.3.1 LLS Mode Configuration ................................................................................................... 93
13.8.4 LCD Mode Configuration ........................................................................................ 93
13.8.5 RFID HID Mode Configuration ................................................................................ 94
13.8.6 RFID MF7 Mode Configuration ............................................................................... 94
13.8.7 Garmin Mode Configuration................................................................................... 94
13.8.7.1 Settings............................................................................................................................. 94
13.8.7.2 Firmware Configuration ................................................................................................... 94
13.8.8 TCP Link Mode ........................................................................................................ 95
13.8.9 TCP Link Mode (Binary)........................................................................................... 95
13.8.10 NMEA Log Mode..................................................................................................... 96
13.8.11 Records to LCD mode.............................................................................................. 96
13.9 BLUETOOTH FUNCTIONALITY ................................................................................................... 96
13.9.1 Bluetooth log .......................................................................................................... 96
13.9.2 Bluetooth Headset.................................................................................................. 97
14 SMS COMMAND LIST.......................................................................................................... 98
14.1 GETSTATUS .......................................................................................................................... 99
14.2 GETWEEKTIME ...................................................................................................................... 99
14.3 GETOPS ............................................................................................................................. 100
14.4 READOPS ........................................................................................................................... 100
14.5 GETNMEAINFO.................................................................................................................... 100
14.6 GETCFGTIME ...................................................................................................................... 100
14.7 GETGPS ............................................................................................................................. 100
14.8 LOADPROFILE# ................................................................................................................... 101
14.9 CPURESET .......................................................................................................................... 101
14.10 RESETALLPROF ............................................................................................................... 101
14.11 GETVER ........................................................................................................................ 101
14.12 GETIO........................................................................................................................... 101
14.13 GETINFO ....................................................................................................................... 101
14.14 DELETERECORDS............................................................................................................. 102
14.15 READIO #...................................................................................................................... 102
14.16 SETDIGOUT #### XYZW............................................................................................... 102
14.17 GETPARAM #### ........................................................................................................... 102
14.18 SETPARAM #### #......................................................................................................... 103
14.19 FLUSH #,#,#,#,#,#,#...................................................................................................... 103
14.20 GETGNSS ...................................................................................................................... 104
14.21 SN X............................................................................................................................. 104
14.22 BANLIST........................................................................................................................ 104

5
14.23 CRASHLOG .................................................................................................................... 104
14.24 BRAMINFO .................................................................................................................... 104
14.25 ODINFO ........................................................................................................................ 104
15 FMB630 WITH LV-CAN 200 AND ALL-CAN 300 CAN ADAPTER ........................................... 105
15.1 PURPOSE OF CAN ADAPTERS LV-CAN200 AND ALL-CAN300 ................................................... 105
15.2 LV-CAN200 AND ALL-CAN300 PROGRAM NUMBER SELECTION ................................................ 106
15.2.1 LV-CAN200 and ALL-CAN300 program number configuration via SMS command106
15.2.2 Selecting LV-CAN200 and ALL-CAN300 program number manually .................... 106
15.2.3 Program number logic change ............................................................................. 107
15.3 SIMPLE-CAN -CONTACTLESS CAN-BUS READER.................................................................... 109
15.4 CONNECTING FMB630 CAN ADAPTERS ALL-CAN300 AND LV-CAN200 .................................... 110
15.5 FMB630 CONFIGURATON ................................................................................................... 111
LVCAN mode (ID=903) ........................................................................................................... 113
Send data with 0, if ignition is off (ID=904) ........................................................................... 114
15.6 PARAMETERS ID ................................................................................................................. 114
16 CAN .................................................................................................................................. 120
16.1 GENERAL DESCRIPTION......................................................................................................... 121
16.2 CONFIGURATION................................................................................................................. 121
16.3 EXAMPLE........................................................................................................................... 122
16.4 FMB630 J1708 CONNECTION ............................................................................................. 125
16.5 SOFTWARE CONFIGURATION OF FMB630 WITHJ1708 .............................................................. 126
16.6 AUTOCAN DESCRIPTION ...................................................................................................... 127
16.6.1 Configuration........................................................................................................ 127
16.6.2 CAN monitoring .................................................................................................... 129
16.6.3 Offline configuration ............................................................................................ 129
16.6.4 AutoCAN ID list ..................................................................................................... 129
16.7 AUTOCAN CONFIGURATION OVER SMS ................................................................................. 144
16.7.1 SMS command format:......................................................................................... 144
16.7.2 AutoCAN element Id‘s........................................................................................... 144
17 USING TACHOGRAPH........................................................................................................ 145
17.1 CONNECTING TO TACHOGRAPH.............................................................................................. 145
17.2 WEB TACHO ..................................................................................................................... 147
17.3 TACHOCHECK SMS ......................................................................................................... 148
18 RS485 INTERFACE ............................................................................................................. 149
18.1 RS485 MODES................................................................................................................... 149
18.1.1 RS485 Receive - Silent Mode................................................................................ 150
18.1.2 RS485 Transmit - FM Log Mode ........................................................................... 150
18.1.3 RS485 Transmit - GPS Nmea Mode ...................................................................... 150
18.1.4 RS485 Receive - LLS Mode .................................................................................... 150
18.1.5 RS485 Receive -TCP Link Mode ............................................................................. 151
18.1.6 RS485 Receive - TCP Link Mode binary ................................................................ 151
18.2 RS485 INTERFACE .............................................................................................................. 152
19 RFID.................................................................................................................................. 152
20 GARMIN ........................................................................................................................... 153
20.1 SUPPORTED GARMIN FMI PROTOCOLS ................................................................................... 153
20.1.1 Standard protocols ............................................................................................... 154
20.1.2 Enhanced protocols .............................................................................................. 154
20.2 SUPPORTED FEATURES ON TAVL CLIENT APPLICATION ................................................................. 155
20.3 TEXT MESSAGING ................................................................................................................ 155
20.4 DESTINATION MESSAGE........................................................................................................ 155
20.5 ETA REQUEST MESSAGE ....................................................................................................... 155
20.6 CONNECTION AND PINOUT.................................................................................................... 156

6
21 LLS SENSOR....................................................................................................................... 157
21.1 SPECIFICATIONS .................................................................................................................. 157
21.2 HARDWARE ....................................................................................................................... 157
21.3 CONNECTING LLS TO FMB630 ............................................................................................. 157
22 MVC300 CAMERA ............................................................................................................. 159
22.1 INTRODUCTION................................................................................................................... 159
22.2 STARTUP AND CONFIGURATION ............................................................................................. 159
22.2.1 Camera parameters in FMB630: .......................................................................... 161
22.2.2 Camera parameters in MVC300: .......................................................................... 161
22.3 FMB630 AND MVC300 CONNECTION .................................................................................. 162
23 GPRS COMMANDS............................................................................................................ 162
24 DEBUG MODE................................................................................................................... 164
25 FMB630 REMOTE LOG ...................................................................................................... 165
MOUNTING RECOMMENDATIONS ............................................................................................ 169
25.1 CONNECTING WIRES............................................................................................................ 169
25.2 CONNECTING POWER SOURCE............................................................................................... 169
25.3 CONNECTING IGNITION WIRE ................................................................................................ 169
25.4 CONNECTING GROUND WIRE ................................................................................................ 169
25.5 CONNECTING ANTENNAS...................................................................................................... 170
25.6 MODULE INSTALLATION ....................................................................................................... 170
26 EC DECLARATION OF CONFORMITY .................................................................................. 171
27 WARRANTY POLICY .......................................................................................................... 173
28 CHANGE LOG .................................................................................................................... 173

7
1INTRODUCTION
1.1 Attention
Do not disassemble the device. If the device is
damaged, the power supply cables are not isolated or
the isolation is damaged, before unplugging the power
supply, do not touch the device.
All wireless data transferring devices produce
interference that may affect other devices which are
placed nearby.
The device must be connected only by qualified
personnel.
The device must be firmly fastened in the predefined
location.
The programming must be performed using a second
class PC (with autonomic power supply).
The device is susceptible to water and humidity.
Any installation and/or handling during a lightning
storm are prohibited.
FMB630 has USB interface;
Please use cables provided with FMB630 device.
Teltonika is not responsible for any harm caused by
using wrong cables for PC <-> FMB630 connection.
This sign on the packaging means that the electric and
electronic equipment to be utilized must be stored
separately.

8
1.2 Instructions of safety
This chapter contains information on how to operate FMB630 safely. By following these
requirements and recommendations, you will avoid dangerous situations. You must read these
instructions carefully and follow them strictly before operating the device!
To avoid mechanical damage, it is advised to transport the FMB630 device in an impact-
proof package. Before usage, the device should be placed so that its LED indicators are visible,
which show the status of operation the device is in.
The device uses SELV limited power source. The allowed range of voltage is 10V…30V DC.
When connecting the connection (2x10) cables to the vehicle, the appropriate jumpers of
the power supply of the vehicle should be disconnected.
Before dismounting the device from the vehicle, the 2x10 connection must be
disconnected.
The device is designed to be mounted in a zone of limited access, which is inaccessible for
the operator. All related devices must meet the requirements of standard EN 60950-1.
The device FMB630 is not designed as a navigational device for boats.
1.3 Legal Notice
Copyright © 2014 Teltonika. All rights reserved. Reproduction, transfer, distribution or
storage of part or all of the contents in this document in any form without the prior written
permission of Teltonika is prohibited.
Garmin and the Garmin logo are registered trademarks, all rights reserved.
Other products and company names mentioned here may be trademarks or trade names
of their respective owners.
1.4 About document
This document contains information about the architecture, possibilities, mechanical
characteristics, and configuration of the FMB630 device.
Acronyms and terms used in document:
PC –Personal Computer
GPRS –General Packet Radio Service
GPS –Global Positioning System
GSM –Global System for Mobile Communications
SMS –Short Message Service
AC/DC –Alternating Current/Direct Current
I/O –Input/Output.
Record –AVL data stored in FMB630 memory. AVL data contains GPS and I/O information
AVL packet - Data packet which is sent to server during data transmission.AVL packet can
contain 1 to 50 records.
Geofence –a virtual geographic area of interest that can be defined by a radius or polygon
for the location. In this document term “Geofence” is often used as functionality, which
generates an event when crossing a defined area.

9
2BASIC DESCRIPTION
FMB630 is a professional tracker with GPS and GSMconnectivity, which is able to
determine the object’s coordinates and transfer them via the GSM network. This device is
perfectly suitable for applications, which need location acquirement of remote objects. It is
important to mention that FMB630 has additional inputs and outputs, which let you control and
monitor other devices on remote objects. FMB630 also has a USB port for device status log
output and for saving configurations.
2.1 Package contents
1
Usually the FMB630 device sample is supplied to the customer in a cardboard box
containing all the equipment that is necessary for operation. The package contains:
FMB630 device
Input and output power supply cable with 2x10 connection pins
4 screws for assembling device
GPS/GLONASS antenna
GSM antenna
USB cable
Port 1/2 cable
Port 3 cable
2.2 Basic characteristics
GSM / GPRS / GNSS features:
Teltonika TM2500 quad band module (GSM 850 / 900 / 1800 / 1900 MHz);
GPRS class 12;
SMS (text, data);
Integrated GNSS receiver;
Up to -162 dBm GNSS receiver sensitivity;
GNSS TG3300 Module features:
Navigation Systems; GPS/GLONASS;
Protocol NMEA-0183: GGA, GGL, GSA, GSV, RMC, VTG;
Up to -162 dBm sensitivity;
Hardware features:
STM32 processor;
1 MB internal Flash memory;
External memory card slot;
Built-in accelerometer;
Built-in Bluetooth 3.0;
Internal backup battery included;
Interface features:
Power supply: 10 ÷ 30V;
USB port;
1
Package content depends on Order Code, and can be customized by customer needs.

10
4 digital inputs;
3 analog inputs;
4 open collector digital outputs;
4 1Wire® temperature sensor;
1Wire® iButton;
LEDs indicating device status;
K-Line interface for online Tachograph Vehicle Data transfer;
2xRS232 port;
RS485 port;
J1708 interface;
LVCAN interface;
CAN messages 2.0 A, B Active support. Speed up to 1 Mbit/s;
Roaming enabling/disabling;
Offline working mode;
Records importing using USB/microSD card;
Remote logs reading via SMS/GPRS;
Overvoltage protection:
Table 1 Overvoltage Protecton:
Description
Voltage
Duration
Normal operation
10-30V
Unlimited
Protection turns on, device turns off.
34V
Unlimited
Maximum voltage
<70V
Unlimited
Maximum voltage impulse
90V
5 miliseconds
2.3 Mechanical features
Table 2 FMB630 physical interfaces and operation environment
Part name
Physical specification
Operation environment
Navigation LED
LED
Power supply 10...30 V DC
2 W Max
Operation temperature:
-25⁰C … +55⁰C
Storage temperature:
-40⁰C … +70⁰C
Energy consumption1:
GPRS: 120 mA r.m.s Max.,
Nominal: average 65 mA r.m.s,
GPS Sleep: average 28 mA,
Deep Sleep: average less than 7 mA2
Storage relative humidity 5 … 95 % (non
condensating)
Modem LED
LED
GPS
GPS antenna connector SMA
jack(female outer shell, female inner
pin)
GSM
GSM antenna connector RP-SMA
jack(female outer shell, male inner
pin)
Socket 2x10
Tyco Micro MATE-N-LOK™
or similar
1Energy consumption has been tested at 12V voltage with no battery charging.
2When in Deep Sleep mode no data storing and sending is activated.

11
Part name
Physical specification
Operation environment
USB
Mini USB socket
Battery charge current:
average 100 mA,
Rated current: 250 mA,
Internal fuse: 3A, 125V
Port1
RS232 or RS485 port channel 1 (RJ45
socket)
Port2
RS232 port channel 1 (RJ45 socket)
J1708
J1708 port channel
Figure 1 FMB630 view & dimensions in mm (tolerance ±2mm)
2.4 Technical Information about internal battery!
Ni-MH Rechargeable battery, 8.4V, 550 mA.
FMB630 operating time with internal backup battery depends on temperature, data
sending frequency (SMS and GPRS), and accumulator age, number of charge/discharge cycles.
For example:
In sleep mode a new FMB630 device, operating time approximately 5 hours
In deep sleep mode –35 hours
Operating time for a new FMB630 device, working in normal mode (records are
being acquired every 10 sec. and sent in packets of 4 records every 60 sec.), is
approximately 2 h 10 min.
Charging temperature: 0 –40 °C
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

12
2.4.1 Battery Disposal instructions:
Battery should not be disposed of with general household waste.
Bring damaged or worn-out batteries to your local recycling center or dispose
them to battery recycle bin found in stores.
2.5 Electrical characteristics
Table 3 Electrical characteristics
VALUE
CHARACTERISTIC DESCRIPTION
Min.
Typ.
Max.
Unit
SUPPLY VOLTAGE
Supply Voltage (Recommended Operating Conditions)
10
-
30
V
Supply Voltage
(for internal rechargeable battery charging proper
functioning)
10
-
30
V
POWER SUPPLY CURRENT (HARDWARE VERSION WITH INTERNAL BATTERY)
Deep Sleep, average, Icc.ds
-
2.5
4
mA
Sleep, average, Icc.ds, Vcc=10V
-
45
-
mA
Sleep, average, Icc.ds, Vcc=30V
-
25
-
mA
Ucc=12.6V, all modules fully working, internal battery is
charging, Icc1
-
-
350
mA
Ucc=12.6V, all modules fully working, internal battery is
charged, Icc2
-
-
300
mA
Ucc=25.2V, all modules fully working, internal battery is
charging, Icc3
-
-
195
mA
Ucc=25.2V, all modules fully working, internal battery is
charged, Icc4
-
-
140
mA
DIGITAL OUTPUT (OPEN DRAIN GRADE)
Drain current (Digital Output OFF)
-
-
120
uA
Drain current (Digital Output ON, Recommended
Operating Conditions)
-
-
300
mA
Static Drain-Source resistance (Digital Output ON)
-
-
300
mOhm
DIGITAL INPUTS
Input resistance (DIN1, DIN2, DIN3)
15
-
-
kOhm
Input Voltage (Recommended Operating Conditions)
0
-
Supply
voltage
V
Input Voltage threshold (DIN1)
-
7,5
-
V
Input Voltage threshold (DIN2, DIN3, DIN4)
-
2,5
-
V

13
VALUE
CHARACTERISTIC DESCRIPTION
Min.
Typ.
Max.
Unit
ANALOG INPUTS
Input Voltage (Recommended Operating Conditions),
Range1
0
-
10
V
Input resistance, Range1
-
120
-
kOhm
Input Voltage (Recommended Operating Conditions)
Range2
0
-
30
V
Input resistance, Range2
-
147
-
kOhm
OUTPUT SUPPLY VOLTAGE 1-WIRE3
Supply Voltage
3,3
-
3,9
V
Output inner resistance
-
7
-
Ohm
Output current (Uout > 3.0V)
-
30
-
mA
Short circuit current (Uout = 0)
-
130
-
mA
CAN INTERFACE
Internal terminal resistors CAN bus
-
120
-
Ohm
Differential input resistance
19
30
52
kOhm
Recessive output voltage
2
2.5
3
V
Differential receiver threshold Voltage
0.5
0.7
0.9
V
Common mode input voltage
-30
-
30
V
When connecting a COM port to an active external device keep in mind that
the first power supply must be connected to FMB630, and then the external
device should be powered. Connecting external devices when FMB630 is
powered off is not recommended.
2.6 Absolute Maximum Ratings
Table 4 Absolute maximum ratings
VALUE
CHARACTERISTIC DESCRIPTION
Min.
Typ.
Max.
Unit
Supply Voltage (Absolute Maximum Ratings)
-32
32
V
Digital output clamp threshold voltage (Absolute
Maximum Ratings), (Idrain = 2mA)
36
V
Digital Input Voltage (Absolute Maximum Ratings)
-32
32
V
Analog Input Voltage (Absolute Maximum Ratings)
-32
32
V
Voltage on Supply Voltage 1-Wire (Absolute
Maximum Ratings)
0
10
V
Voltage on Data Input/Output 1-Wire (Absolute
Maximum Ratings)
0
10
V
3
-1-wire Supply voltage PIN is dedicated for 1-wire devices ONLY, do not use it for any other purpose.

14
Voltage on CANH, CANL (Absolute Maximum
Ratings)
-58
58
V
3CONNECTION AND PINOUT
3.1 SIM card insert scheme

Gently open FMB630 case using screwdrivers

15

Take off FMB630 case and insert SIM cards
as shown. SIM1 SLOT (default, recommended
for 1 SIM mode) is closer to PCB, SIM2 SLOT
is the upper one

Assemble device as shown and put screws
into the holes

Screw all 4 screws

Device is ready

16
3.2 Installing FMB630 drivers
Software requirements
•Operating system 32-bit and 64-bit: XP with SP3 or later, Windows Vista, Windows 7, 8
and 10.
• MS .NET Framework V3.5 or later (Microsoft)
Drivers
Please download Virtual COM Port drivers from Teltonika website: FMB630 VCP Driver
Installing drivers
Extract and run VCPDriver_V1.3.1_Setup.exe. This driver is used to detect FMB630 device
connected to the computer. Click 'Next' in driver installation window (figures below):
Figure 2 Driver installation window
This will launch the device driver installation wizard. In the following window click ‘Next’
button again:
Figure 3 Driver installation window
Setup will continue installing drivers and will display a window about successful process in
the end. Click 'Finish' to complete setup:

17
Figure 4 Driver installation window
You have now installed drivers for FMB630 device successfully.
3.3 Navigate LED
Table 5 Navigate LED operation
Behaviour
Meaning
Permanently switched on
GPS signal is not received
Blinking every second
Normal mode, GPS is working
Off
GPS is turned off because:
Deep sleep mode
Or
GPS antenna short circuited
3.4 Status LED
Table 6 Status LED Operation
Behaviour
Meaning
Blinking every second
Normal mode
Blinking every 2 seconds
Deep sleep mode
Blinking fast for a short time
Modem activity
Blinking fast constantly
Boot mode
Off
Device is not working
Or
Device firmware being flashed

18
3.5 Socket 210 pinout
AIN 3
10
20
K-Line
OUT 2
9
19
OUT 1
OUT 3
8
18
OUT 4
AIN 2
7
17
AIN 1
CAN2 L
6
16
CAN2_H
DIN 2
5
15
IGN (DIN1)
DIN 4
4
14
DIN 3
1W. PWR
3
13
1W. data
CAN1 L
2
12
CAN1 H
(-)GND
1
11
(+)VCC (1030)V DC
Figure 5 2x10 socket pinout
Table 7 2x10 SOCKET PINOUT DESCRIPTION
Pin
Nr.
Pin Name
Description
1
(-)GND
( - ) Ground pin. (10…30) V DC*
2
CAN1 L
SAE J1939 CAN interface Low channel 1
3
1W. PWR
Power supply pin for Dallas 1-Wire® devices
4
DIN 4
Digital input. Channel 4
5
DIN 2
Digital input. Channel 2
6
CAN2 L
SAE J1939 CAN interface Low channel 2
7
AIN 2
Analog input, channel 2. Input range: 0 - 30V/ 0 - 10V DC
8
OUT 3
Digital output. Channel 3. Open collector output
9
OUT 2
Digital output. Channel 2. Open collector output
10
AIN 3
Analog input, channel 3. Input range: 0 - 30V/ 0 - 10V DC
11
(+)VCC (10...30) V DC
Power supply pin
12
CAN1 H
SAE J1939 CAN interface High channel 1
13
1W. data
Data channel for Dallas 1-Wire® devices
14
DIN 3
Digital input, channel 3
15
DIN 1
Digital input, channel 1 (RESERVED FOR IGNITION LINE)
16
CAN2 H
SAE J1939 CAN interface High channel 2
17
AIN 1
Analog input, channel 1. Input range: 0 - 30V/ 0 - 10V DC
18
OUT 4
Digital output. Channel 4. Open collector output
19
OUT 1
Digital output. Channel 1. Open collector output
20
K-LINE
K-LINE interface for online Tachograph Vehicle Data transfer

19
3.6 USB
When FMB630 is connected to a PC it creates a STM Virtual COM Port, which can be used
as a system port (to flash firmware and configure the device).
Figure 6 COM-Ports
3.7 Accessories
Note: Teltonika does not provide any additional equipment like panic buttons,
door sensors etc, except 1 –wire devices: TTJ-101 thermo sensor, I-Button, 1-
wire RFID. These devices are not included in FMB630 package and can be
offered by special order only.
1 –Wire devices
One of the FMB630 features is realized 1-Wire data protocol, which enables connection of
up to three different type thermometers (DS1820, DS18S20 and DS18B20) and I-Button
DS1990A. Figure 7 and Figure 9 shows FMB630 and 1-wire devices connection schemes.

20
Figure 7 Temperature sensors connection scheme
Left row of pins
1
3
4
1
2
2
J1
J2
J3
U1
Right row of pins
1W. PWR
(FMB630 –pin3)
1
1W. Data
(FMB630 –pin13)
2
1
Vpp(+5
Volts DC) –
power
source for
external
digital
sensor
GND
(FMB630 –pin1)
3
2
Output
from
external
digital
sensor
Digital Input
4
Figure 8 Digital thermometer DS1820 and TTJ 100 connection scheme
