GH5200 First Start
Main Page > Autonomous Trackers > GH5200 > GH5200 First Start
GH5200 is an autonomous personal tracker for lone worker protection.
Contents
1 Know your device
2 Set up your device
2.1 How to insert Micro SIM card and connect the battery
2.2 PC Connection (Windows)
2.3 How to install USB drivers (Windows)
2.4 Configuration (Windows)
2.5 Quick SMS configuration
3 Safety information
3.1 Precautions
Know your device
Set up your device
How to insert Micro SIM card and connect the battery
Remove the cover.1.
Insert Micro-SIM card as shown with PIN request disabled. Make sure that Micro-SIM card2.
cut-off corner is pointing forward to slot.
Insert the battery as shown to device. Position the battery in place where it does not obstruct3.
other components.
Reattach the cover and tighten the screw.4.

Micro-SIM card insertion/removal must be performed when device is powered off and
battery is disconnected. Otherwise Micro-SIM card might be damaged or device will not
detect it.
PC Connection (Windows)
1. Turn on your device by holding the power button for around 7 seconds.
2. Connect device to computer using Micro-USB cable or Bluetooth connection:
Using Micro-USB cable
– You will need to install USB drivers, see “How to install USB drivers (Windows)” shown below.
Using Bluetooth
– GH5200 Bluetooth is enabled by default. Turn on Bluetooth on your PC, then select Add
Bluetooth or other device > Bluetooth. Choose your device named –
“GH5200_last_7_imei_digits”, without LE in the end. Enter default password 5555, press Connect
and then select Done.

3. You are now ready to use the device on your computer.
How to install USB drivers (Windows)
1. Please download COM port drivers from here.
2. Extract and run TeltonikaCOMDriver.exe.
3. Click Next in driver installation window.
4. In the following window click Install button. Setup will continue installing the driver and
eventually the confirmation window will appear. Click Finish to complete the setup.
Configuration (Windows)
At first GH5200 device will have default factory settings set. These settings should be changed
according to the user's needs.
Main configuration can be performed via Teltonika Configurator software. Configurator operates
on Microsoft Windows OS and uses prerequisite MS .NET Framework. Make sure you have the
correct version installed.
MS .NET requirements
Operating
system
MS .NET
Framework
version
Version Link
• Windows
Vista
• Windows
7
• Windows
8.1
• Windows
10
MS .NET
Framework
4.6.2
32 and
64 bit
www.microsoft.com
Downloaded Configurator will be in compressed archive. Extract it and launch Configurator.exe.
After launch software language can be changed by clicking in the right bottom corner:
Configuration process begins by pressing on connected device:

After connection to Configurator Status window will be displayed:
Various Status info tabs display information about GNSS, GSM, I/O, Maintenance and etc.
GH5200 has one user editable profile, which can be loaded and saved to the device. After any
modification of configuration the changes need to be saved to device using Save to device button.
Main buttons offer following functionality:
Load from device – loads configuration from device.1.
Save to device – saves configuration to device.2.
Load from file – loads configuration from file.3.
Save to file – saves configuration to file.4.
Update firmware – updates firmware on device.5.
Read records – read records from device.6.
Reboot device – restarts device.7.
Reset configuration – sets device configuration to default.8.
Most important configurator section is GPRS – where all your server and GPRS settings can be
configured and Data acquisition – where data acquiring parameters can be configured. More
details about GH5200 configuration using Configurator can be found here.

Quick SMS configuration
Default configuration has optimal parameters present to ensure best performance of track quality
and data usage.
Quickly set up your device by sending this SMS command to it:
" setparam
2001:APN;2002:APN_username;2003:APN_password;2004:Domain;2005:Port;2006:0"
GPRS settings:
2001 – APN
2002 – APN username (if there are no APN username, empty field should be left)
2003 – APN password (if there are no APN password, empty field should be left)
Server settings:
2004 – Domain
2005 – Port
2006 – Data sending protocol (0 – TCP, 1 – UDP)
Note: Before SMS text, two space symbols should be inserted.
Default configuration settings
Movement detection:
Device movement will be detected
by accelerometer
Device makes a record On Moving if one of these events happen:
300 seconds passes
Angle difference between
last coordinate and current
position is greater than 10°
degrees
Traveled distance is more than 100
meters
Speed difference between
last coordinate and current
position is greater than 10
km/h
Device makes a record On Stop if:
1 hour passes while device is
stationary
Records sending to server:
If device has made a record it is
sent to the server every 120
seconds
After successful SMS configuration, GH5200 device will synchronize time and update records to
configured server.

Safety information
This message contains information on how to operate GH5200 safely. By following these
requirements and recommendations, you will avoid dangerous situations. You must read these
instructions carefully and follow them strictly before operating the device!
Precautions
Operate the device in suitable conditions
Do not use the device where mobile connectivity is forbidden.
Road safety first
Comply with local traffic laws, always hold your hands on a steering wheel when using a device.
Your safety is of utmost importance when you drive.
Interference
All wireless devices are sensitive to electromagnetic interference, as a result wireless devices
affect the performance of each other.
Limit the use of device in hospitals
Please follow all restrictions. Turn off the device in the vicinity of medical devices when
required.
Limit the use of device in vehicles
Please follow all restrictions. Wireless devices can interfere with other electronic equipment in
vehicles.
Be cautious near flammable materials and liquids
Charging precautions
SELV LPS chargers, personal computers or laptops that device will be connected to must comply
with the requirements of IEC 60950:2005 standard.
Use only original batteries
Using uncertified manufacturer or different type batteries may cause an explosion.
Use batteries safely
Protect batteries from moisture. Place them in a cool and dry place when storing. Avoid
extensive operation at high temperatures. Do not attempt charging battery directly from the
electrical mains. All utilised batteries shall comply with IEC 62133.
Power supplies
Power supply circuits used to charge the device connection must have safeguards, which prevent
power leakage, short circuits or incorrect electrical grounding. Any used switches ought to be
installed in a readily accessible location. Power must be uninterrupted and the distance between
the contacts must be 3 mm or larger.
Remove device safely
Device must be disconnected from computer or charger by unplugging the magnetic USB cable
from the device.
Other
In order to prevent device from mechanical damage it is advisable to transport it in a
shock–resistant packaging. If device stopped working properly regardless of the settings only a
qualified specialist can help. It is recommended to contact your local seller or your UAB
Teltonika manager in such a case.
Use the right screwdriver
In order to prevent device's cover from mechanical damage it is recommended to use
screwdriver, which is included in the package. Do not use electrical screwdrivers.
