Teltonika FMB930 Installation guide

FMB930
Small and smart tracker
Quick Manual v1.3

Quick Manual v1.3 // FMB930 2
Telematics
CONTENT
Know your device................................................................................................................................................................................................3
Pinout ...................................................................................................................................................................................................................4
Wiring scheme.....................................................................................................................................................................................................5
Set up your device ..............................................................................................................................................................................................6
PC Connection (Windows)..................................................................................................................................................................................7
How to install USB drivers (Windows) ..............................................................................................................................................................7
Conguration.......................................................................................................................................................................................................8
Quick SMS conguration................................................................................................................................................................................. 10
Mounting recommendations.......................................................................................................................................................................... 12
Basic characteristics ........................................................................................................................................................................................ 13
LED indications................................................................................................................................................................................................. 13
Electrical characteristics.................................................................................................................................................................................. 16
Safety information .......................................................................................................................................................................................... 17
Certication and Approvals ............................................................................................................................................................................ 18
Warranty ........................................................................................................................................................................................................... 19
Warranty disclaimer ....................................................................................................................................................................................... 19

Quick Manual v1.3 // FMB930 3
Telematics
KNOW YOUR DEVICE
POWER
CABLE
MICRO-SIM
SLOT
BATTERY
SOCKET
STATUS
LED
MICRO-USB
NAVIGATE
LED
TOP VIEW BOTTOM VIEW (WITHOUT COVER)

Quick Manual v1.3 // FMB930 4
Telematics
PIN NUMBER PIN NAME DESCRIPTION
1VCC (10-90) V
DC (+)
(Red) Power supply
(+10-90 V DC)
2 GND (-) (Black) Ground
3 DIN1
(Yellow) Digital input,
channel 1. DEDICATED
FOR IGNITION INPUT
4DOUT2
(Grey) Digital output.
Open collector output.
Max. 0,5 A DC
5DOUT1
(White) Digital output.
Open collector output.
Max. 0,5 A DC
PINOUT
2
3
4
5
1
+10...90 V DC
GND
DIN1
DOUT2
DOUT1
FMB930 pinout

Quick Manual v1.3 // FMB930 5
Telematics
WIRING SCHEME
BUZZER
30
8586
87a
87
IGNITION
DETECTION
STARTER
ALARM BUTTON DOOR SENSOR
POWER SUPPLY
10 - 90V DC
2
3
4
5
1
+10...90 V DC
GND
DIN1
DOUT2
DOUT1

Quick Manual v1.3 // FMB930 6
Telematics
SET UP YOUR DEVICE
HOW TO INSERT MICRO-SIM CARD
4
1COVER REMOVAL 3BATTERY CONNECTION 2MICRO-SIM CARD INSERT ATTACHING COVER BACK
Gently remove FMB930
cover using plastic pry tool
from both sides.
Insert Micro-SIM card as
shown with PIN request
disabled or read our Wiki1
how to enter it later in
Teltonika Congurator2.
Make sure that Micro-
SIM card cut-o corner is
pointing forward to slot.
1 wiki.teltonika-gps.com/view/
FMB930_Security_info
2 wiki.teltonika-gps.com/view/
Teltonika_Congurator
Connect the battery as
shown on device. Position
the battery in place where
it does not obstruct other
components.
After conguration, see PC
Connection (Windows)3,
attach device cover back.
3 Page 7, "PC Connection
(Windows)"

Quick Manual v1.3 // FMB930 7
Telematics
PC CONNECTION (WINDOWS)
HOW TO INSTALL USB DRIVERS (WINDOWS)
1. Please download COM port drivers from here1.
2. Extract and run TeltonikaCOMDriver.exe.
3. Click Next in driver installation window.
4. In the following window click Install button.
5. Setup will continue installing the driver and eventually the conrmation window will appear. Click Finish to complete the
setup.
1 teltonika-gps.com/downloads/en/FMB930/TeltonikaCOMDriver.zip
1. Power-up FMB930 with DC voltage (10 – 90 V) power supply using power wires. LED’s should start blinking, see “LED
indications1”.
2. Connect device to computer using Micro-USB cable or Bluetooth connection:
• Using Micro-USB cable
• You will need to install USB drivers, see “How to install USB drivers (Windows)2”
• Using Bluetooth
• FMB930 Bluetooth is enabled by default. Turn on Bluetooth on your PC, then select Add Bluetooth or other device >
Bluetooth. Choose your device named – “FMB930_last_7_imei_digits”, without LE in the end.
• Enter default password 5555, press Connect and then select Done.
3. You are now ready to use the device on your computer.
1 Page 13, "LED indications"
2 Page 7, "How to install USB drivers (Windows)"

Quick Manual v1.3 // FMB930 8
Telematics
At rst FMB930 device will have default factory settings set. These settings should be changed according to the users needs. Main
conguration can be performed via Teltonika Congurator1software. Get the latest Congurator version from here2. Congurator
operates on Microsoft Windows OS and uses prerequisite MS .NET Framework. Make sure you have the correct version installed.
1 wiki.teltonika-gps.com/view/Teltonika_Congurator
2 wiki.teltonika-gps.com/view/Teltonika_Congurator_versions
CONFIGURATION
MS .Net requirements
Operating system MS .NET Framework version Version Links
Windows Vista
Windows 7
Windows 8.1
Windows 10
MS .NET 5.0 32 and 64 bit www.microsoft.com1
1 dotnet.microsoft.com/en-us/download/dotnet/5.0/runtime

Quick Manual v1.3 // FMB930 9
Telematics
Downloaded Congurator will be in compressed archive.
Extract it and launch Congurator.exe. After launch software
language can be changed by clicking 🌐in the right bottom
corner.
Conguration process begins by pressing on connected device.
FMB930
After connection to Congurator Status window will be
displayed.
FMB930
Various Status window1 tabs display information about GNSS2,
GSM3, I/O4, Maintenance5and etc. FMB930 has one user
editable prole, which can be loaded and saved to the device.
After any modication of conguration the changes need to
be saved to device using Save to device button. Main buttons
oer following functionality:
 Load from device – loads conguration from device.
 Save to device – saves conguration to device.
 Load from le – loads conguration from le.
 Save to le – saves conguration to le.
 Update rmware – updates rmware on device.
 Read records – reads records from the device.
 Reboot device – restarts device.
 Reset conguration – sets device conguration to
default.
Most important congurator section is GPRS – where all
your server and GPRS settings6 can be congured and Data
Acquisition7– where data acquiring parameters can be
congured. More details about FMB930 conguration using
Congurator can be found in our Wiki8.
1 wiki.teltonika-gps.com/view/FMB930_Status_info
2 wiki.teltonika-gps.com/view/FMB930_Status_info#GNSS_Info
3 wiki.teltonika-gps.com/view/FMB930_Status_info#GSM_Info
4 wiki.teltonika-gps.com/view/FMB930_Status_info#I.2FO_Info
5 wiki.teltonika-gps.com/view/FMB930_Status_info#Maintenance
6 wiki.teltonika-gps.com/view/FMB930_GPRS_settings
7 wiki.teltonika-gps.com/view/FMB930_Data_acquisition_settings
8 wiki.teltonika-gps.com/view/FMB930_Conguration

Quick Manual v1.3 // FMB930 10
Telematics
QUICK SMS CONFIGURATION
Default conguration has optimal parameters present to ensure best performance of track quality and data usage.
Quickly set up your device by sending this SMS command to it:
Note: Before SMS text, two space symbols should be inserted.
GPRS SETTINGS:
 2001 – APN
 2002 – APN username (if there are no APN username,
empty eld should be left)
 2003 – APN password (if there are no APN password,
empty eld should be left)
SERVER SETTINGS:
 2004 – Domain
 2005 – Port
 2006 – Data sending protocol (0 – TCP, 1 – UDP)
« setparam 2001:APN;2002:APN_username;2003:APN_password;2004:Domain;2005:Port;2006:0»
1 2 3 4 5 6
1
2
3
4
5
6

Quick Manual v1.3 // FMB930 11
Telematics
DEFAULT CONFIGURATION SETTINGS
DEVICE MAKES A RECORD ON MOVING IF ONE OF THESE EVENTS HAPPEN:
MOVEMENT AND IGNITION DETECTION:
VEHICLE MOVEMENT
will be detected by accelerometer
300
seconds passes
VEHICLE DRIVES
100 meters
IGNITION WILL BE DETECTED
by vehicle power voltage
between 13,2 – 30 V
VEHICLE TURNS
10 degrees
SPEED DIFFERENCE
between last coordinate and current
position is greater than 10 km/h
After successful SMS conguration, FMB930 device will synchronize time and update records to congured server. Time intervals
and default I/O elements can be changed by using Teltonika Congurator1or SMS parameters2.
1 wiki.teltonika-gps.com/view/Teltonika_Congurator
2 wiki.teltonika-gps.com/view/Template:FMB_Device_Family_Parameter_list
DEVICE MAKES A RECORD ON STOP IF: RECORDS SENDING TO SERVER:
1 HOUR PASSES
while vehicle is stationary and ignition
is o
IF DEVICE HAS MADE A RECORD
it is sent to the server every 120 seconds

Quick Manual v1.3 // FMB930 12
Telematics
MOUNTING RECOMMENDATIONS
CONNECTING WIRES
• Wires should be fastened to the other wires or non-moving parts. Try to avoid heat emitting and moving objects near the
wires.
• The connections should not be seen very clearly. If factory isolation was removed while connecting wires, it should be applied
again.
• If the wires are placed in the exterior or in places where they can be damaged or exposed to heat, humidity, dirt, etc., additional
isolation should be applied.
• Wires cannot be connected to the board computers or control units.
CONNECTING POWER SOURCE
• Be sure that after the car computer falls asleep, power is still available on chosen wire. Depending on car, this may happen in
5 to 30 minutes period.
• When module is connected, measure voltage again to make sure it did not decrease.
• It is recommended to connect to the main power cable in the fuse box.
• Use 3A, 125V external fuse.
CONNECTING IGNITION WIRE
• Be sure to check if it is a real ignition wire i. e. power does not disappear after starting the engine.
• Check if this is not an ACC wire (when key is in the rst position, most of the vehicle electronics are available).
• Check if power is still available when you turn o any of vehicles devices.
• Ignition is connected to the ignition relay output. As alternative, any other relay, which has power output when ignition is on,
may be chosen.
CONNECTING GROUND WIRE
• Ground wire is connected to the vehicle frame or metal parts that are xed to the frame.
• If the wire is xed with the bolt, the loop must be connected to the end of the wire.
• For better contact scrub paint from the spot where loop is going to be connected.

Quick Manual v1.3 // FMB930 13
Telematics
Behaviour Meaning
Permanently
switched on GNSS signal is not received
Blinking every
second Normal mode, GNSS is working
O
GNSS is turned o because:
Device is not working or Device is in
sleep mode
Blinking fast
constantly Device rmware is being ashed
Behaviour Meaning
Blinking every
second Normal mode
Blinking every two
seconds Sleep mode
Blinking fast for a
short time Modem activity
O Device is not working or Device is in
boot mode
LED INDICATIONS
NAVIGATION LED INDICATIONS
STATUS LED INDICATIONS
BASIC CHARACTERISTICS
Module
Name FMB930-TAIB0: Teltonika TM2500
Technology GSM/GPRS/GNSS/BLUETOOTH
GNSS
GNSS GPS, GLONASS, GALILEO, BEIDOU,
QZSS, AGPS
Receiver 33 channel
Tracking sensitivity -165 dBM
Accuracy < 3 m
Hot start < 1 s
Warm start < 25 s
Cold start < 35 s
Cellular
Technology GSM
2G bands Quad-band 850 / 900 / 1800 / 1900
MHz
Data transfer GPRS Multi-Slot Class 12 (up to 240
kbps), GPRS Mobile Station Class B
Data support SMS (text/data)

Quick Manual v1.3 // FMB930 14
Telematics
Power
Input voltage range 10-90 V DC
Back-up battery 170 mAh Li-Ion battery (0.63Wh)
Bluetooth
Specication 4.0 + LE
Supported
peripherals
Temperature and Humidity
sensor1, OBDII dongle2, Inateck
Barcode Scanner,Universal BLE
sensors support
INTERFACE
Digital Inputs 1
Digital Outputs 2
GNSS antenna Internal High Gain
Cellular antenna Internal High Gain
USB 2.0 Micro-USB
LED indication 2 status LED lights
SIM Micro-SIM
Memory 128MB internal ash memory
1 teltonika.lt/product/bluetooth-sensor
2 wiki.teltonika.lt/view/How_to_connect_OBD_II_Blue-tooth_Dongle_to_
FMB_device
Physical Specification
Dimensions 79 x 43 x 12 mm (L x W x H)
Weight 54 g
Operating Environment
Operating
temperature (with
battery)
-20 °C to +40 °C
Operating
temperature
(without battery)
-40 °C to +85 °C
Storage temperature
(without battery) -40 °C to +85 °C
Operating humidity 5% to 95% non-condensing
Ingress Protection
Rating IP54
Battery charge
temperature 0 °C to +45 °C
Battery discharge
temperature -20 °C to +60 °C
Battery storage
temperature
-20 °C to +35 °C for 1 month
-20 °C to +35 °C for 6 months
Features
Sensors Accelerometer

Quick Manual v1.3 // FMB930 15
Telematics
Scenarios
Green Driving, Over Speeding
detection, GNSS Fuel Counter,
DOUT Control Via Call, Excessive
Idling detection, Unplug detection,
Towing detection, Crash detection,
Auto Geofence, Manual Geofence,
Trip3
Sleep modes
GPS Sleep, Online Deep Sleep,
Deep Sleep, Ultra Deep Sleep4,
Power O Sleep5
Conguration and
rmware update
FOTA Web6, FOTA7, Teltonika
Congurator8(USB, Bluetooth),
FMBT mobile application9
(Conguration)
SMS Conguration, Events, DOUT
Control, Debug
3 wiki.teltonika-gps.com/view/FMB930_Features_settings
4 wiki.teltonika-gps.com/view/FMB930_Sleep_modes
5wiki.teltonika-gps.com/view/FMB930_Sleep_modes#Power_o_sleep_
mode
6 wiki.teltonika-gps.com/view/FOTA_WEB
7 wiki.teltonika-gps.com/view/FOTA
8 wiki.teltonika-gps.com/view/Teltonika_Congurator
9 wiki.teltonika-gps.com/view/FMBT_Mobile_application
GPRS commands Conguration, DOUT control, Debug
Time
Synchronization GPS, NITZ, NTP
Fuel monitoring OBDII dongle10
Ignition detection
Digital Input 1, Accelerometer,
External Power Voltage, Engine RPM
(OBDII dongle14)
10 wiki.teltonika-gps.com/view/How_to_connect_OBD_II_Bluetooth_
Dongle_to_FMB_device

Quick Manual v1.3 // FMB930 16
Telematics
ELECTRICAL
CHARACTERISTICS
Characteristic description Value
Supply voltage Min. Typ. Max. Unit
Supply Voltage
(Recommended
Operating Conditions)
+10 +90 V
Digital output (open drain grade)
Drain current (Digital
Output OFF) 120 µA
Drain current
(Digital Output ON,
Recommended
Operating Conditions)
0.5 A
Static Drain-Source
resistance (Digital
Output ON)
300 mΩ
Digital input
Input resistance (DIN1) 561 kOhm
Input voltage
(Recommended
Operating Conditions)
0 90 V
Input Voltage threshold 2.5 V

Quick Manual v1.3 // FMB930 17
Telematics
This message contains information on how to operate FMB930
safely. By following these requirements and recommendations,
you will avoid dangerous situations. You must read these
instructions carefully and follow them strictly before operating
the device!
• The device uses SELV limited power source. The nominal
voltage is +12 V DC. The allowed voltage range is +10...+90
V DC.
• To avoid mechanical damage, it is advised to transport
the device in an impact-proof package. Before usage,
the device should be placed so that its LED indicators are
visible. They show the status of device operation.
• When connecting the connection (1x5) cables to the
vehicle, the appropriate jumpers of the power supply of
the vehicle should be disconnected.
• Before dismounting the device from the vehicle, the 1x5
connection must be disconnected.
• The device is designed to be mounted in a zone of limited
access, which is inaccessible to the operator. All related
devices must meet the requirements of EN 62368-1
standard.
• The device FMB930 is not designed as a navigational
device for boats.
SAFETY INFORMATION Do not disassemble the device. If the device is
damaged, the power supply cables are not isolated
or the isolation is damaged, DO NOT touch the
device before unplugging the powe supply.
All wireless data transferring devices produce
interference that may aect other devices which are
placed nearby.
The device must be rmly fastened in a predened
location.
The programming must be performed using a PC
with autonomic power supply.
The device must be connected only by qualied
personnel.
Installation and/or handling during a lightning storm
is prohibited.
The device is susceptible to water and humidity.

Quick Manual v1.3 // FMB930 18
Telematics
CERTIFICATION AND APPROVALS
This sign on the package means that it is necessary
to read the User‘s Manual before your start using the
device. Full User‘s Manual version can be found in
our Wiki1.
1 wiki.teltonika-gps.com/view/FMB930
This sign on the package means that all used
electronic and electric equipment should not be
mixed with general household waste.
CHECK ALL CERTIFICATES
All newest certicates may be found in our Wiki2.
2 wiki.teltonika-gps.com/view/FMB930_Certication_%26_Approvals

Quick Manual v1.3 // FMB930 19
Telematics
TELTONIKA guarantees its products to be free of any manufacturing defects for a period of 24 months. With additional agreement
we can agree on a dierent warranty period, for more detailed information please contact our sales manager.
Contact us teltonika-gps.com/about-us/contacts
All batteries carry a reduced 6 month warranty period.
If a product should fail within this specic warranty time, the product can be:
• Repaired
• Replaced with a new product
• Replaced with an equivalent repaired product fullling the same functionality
• TELTONIKA can also repair products that are out of warranty at an agreed cost.
WARRANTY
WARRANTY DISCLAIMER
TELTONIKA PRODUCTS ARE INTENDED TO BE USED BY PERSONS WITH TRAINING AND EXPERIENCE. ANY OTHER USE RENDERS THE
LIMITED WARRANTIES EXPRESSED HEREIN AND ALL IMPLIED WARRANTIES NULL AND VOID AND SAME ARE HEREBY EXCLUDED.
ALSO EXCLUDED FROM THIS LIMITED WARRANTY ARE ANY AND ALL INCIDENTAL OR CONSEQUENTIAL DAMAGES INCLUDING BUT
NOT LIMITED TO, LOSS OF USE OR REVENUE, LOSS OF TIME, INCONVENIENCE OR ANY OTHER ECONOMIC LOSS.
More information can be found at teltonika-gps.com/warranty-repair
