GH5200 User interface
Main Page > Autonomous Trackers > GH5200 > GH5200 Configuration > GH5200 User interface
Contents
1 GSM Indications
2 GNSS Indications
3 Event Indications
4 Battery Indications
5 Keyboard Indications
6 Default Configuration LED indications
Indication is configurable in User Interface tab of configurator or via SMS/GPRS parameter ID.
Each 100 ms device checks if any indication is enabled in response to triggered scenarios. If two
scenarios need to indicate on the same indication source (LED or Vibration) then the active
indicating scenario needs to be finished first (with exception of Alarm and Device Off scenarios,
which can override the control of indication sources). Period setting is indicative of Periodic
scenarios and if Period is set to 0 the indication will take place immediately. When indication is
periodic and On parameter value is set to 0, the indication source will stay on until the scenario is
finished. Triggered scenarios will turn on LED and/or Vibration for a configured On duration and
then keep them off for a configured Off period of time. In case the configured Repeat value is higher
than 0 the device continues a periodic on/off cycle. Enable In Sleep parameter will let the
indication work while device is sleeping.
GSM Indications
Name Meaning
GSM Error SIM is not inserted, failed to connect to GSM operator or GSM signal is being jammed
GSM Signal Established Device successfully registered to GSM network
SMS Send/Receive SMS is received or sent
Incoming Call Device notices incoming call
Call Active Active voice call
Outgoing Call Device notices outgoing call
Remote Connection Device establishes connection with the server
GNSS Indications
Name Meaning
No GPS Fix Device searches for valid GPS fix
GPS Fix Device has valid GPS fix

Event Indications
Name Meaning
Event Eventual record is saved
Panic Event Panic record is saved
Device Off Device is turning off
Device On Device is turning on
Pre Alarm Indication when Man-down event functionality starts counting timeout till event
ManDown Man-down event indication
I Am Alive Periodical indication that device is on
Sleep Mode Device is in sleep mode
No Movement Pre Alarm Indication when No Movement event functionality starts counting timeout till event
Battery Indications
Name Meaning
Charging Device is charging
Fully Charged Device is fully charged
Charging Error An error occurred while charging
Battery Low Device battery is low
Keyboard Indications
Name Meaning
Alarm Key Pressed Alarm button is pressed and held down
Alarm Key Action
Activated
Configured functionality was activated by pressed Alarm button
Alarm Key Action
Deactivated
Configured functionality was deactivated by pressed Alarm button
Power Key Pressed Power button is pressed and held down
Power Key Action
Activated
Configured functionality was activated by pressed Power button
Power Key Action
Deactivated
Configured functionality was deactivated by pressed Power button
Key 1 Pressed Button 1 is pressed and held down
Key 1 Action Activated Configured functionality was activated by pressed button 1
Key 1 Action Deactivated Configured functionality was deactivated by pressed button 1
Key 2 Pressed Button 2 is pressed and held down
Key 2 Action Activated Configured functionality was activated by pressed button 2
Key 2 Action Deactivated Configured functionality was deactivated by pressed button 2
Key 3 Pressed Button 3 is pressed and held down
Key 3 Action Activated Configured functionality was activated by pressed button 3
Key 3 Action Deactivated Configured functionality was deactivated by pressed button 3

Default Configuration LED indications
Name LED, Color & Additional indication
GSM Error GSM
Incoming Call GSM, Vibration
Call Active GSM
Outgoing Call Battery
Remote Connection GSM
No GPS Fix GNSS
GPS Fix GNSS
Device Off Battery, Vibration, Audio
Device On Battery, Vibration, Audio
Man Down GSM
I Am Alive GNSS
Charging Battery
Fully Charged Battery
Charging Error Battery
Battery Low Battery
Alarm Key Pressed GNSS
Power Key Pressed GNSS
Key 1 Pressed GNSS
Key 2 Pressed GNSS
Key 3 Pressed GNSS
Note! Two LED colors are available - Green and Red. Indications are fully customizable depending
on the user needs.
