Teltonika TFT100 Installation guide

TFT100
2G tracker with high-voltage support
for e-mobility & heavy machinery
Quick Manual v1.0

Quick Manual v1.0 // TFT100 2
CONTENT
Know your device................................................................................................................................................................................................3
UART Pinout.........................................................................................................................................................................................................4
CAN Pinout...........................................................................................................................................................................................................5
RS232 Pinout .......................................................................................................................................................................................................6
RS485 Pinout .......................................................................................................................................................................................................7
Wiring scheme.....................................................................................................................................................................................................8
Set up your device ..............................................................................................................................................................................................9
PC Connection (Windows)............................................................................................................................................................................... 10
How to install USB drivers (Windows) ........................................................................................................................................................... 10
Conguration.................................................................................................................................................................................................... 11
Quick SMS conguration................................................................................................................................................................................. 13
Mounting recommendations.......................................................................................................................................................................... 15
Basic characteristics ........................................................................................................................................................................................ 16
LED indications................................................................................................................................................................................................. 16
Safety information .......................................................................................................................................................................................... 20
Certication and Approvals ............................................................................................................................................................................ 21
Warranty ........................................................................................................................................................................................................... 22
Warranty disclaimer ....................................................................................................................................................................................... 22

Quick Manual v1.0 // TFT100 3
TOP VIEW TOP VIEW (WITHOUT COVER)
POWER
CABLE
NAVIGATE LED
GNSS
ANTENNA
MICRO-SIM
SLOT
BATTERY
SOCKET
GSM
ANTENNA
MICRO-USB
STATUS LED
TFT100
KNOW YOUR DEVICE
TOP VIEW TOP VIEW (WITHOUT COVER)

Quick Manual v1.0 // TFT100 4
PIN COLOR PIN NAME DESCRIPTION
Red VCC (10-97) V DC (+) Power supply (+10...97 V
DC).
Black GND (-) Ground.
Yellow 1WIRE POWER Power supply pin for Dallas
1-Wire devices.
White/
Green UART-RX Input for data reception
through UART.
White UART-TX Output for data
transmission through UART.
Grey AIN 2 /
DIN 2
Analog input, channel 2 /
Digital input, channel 2.
White/
Orange
DOUT 1 /
DIN 3
Digital output, channel 1 /
Digital input, channel 3.
Violet DOUT 2 /
DIN 4
Digital output, channel 2 /
Digital input, channel 4.
Green AIN 1 /
DIN 1
Analog input, channel 1 /
Digital input, channel 1.
Blue 1WIRE DATA Data channel for 1–Wire
devices.
UART PINOUT
DOUT2/DIN4
1-WIRE DATA
AIN1/DIN1
GND
DOUT1/DIN3
UART-T X
UART-RX
1-WIRE POWER
AIN2/DIN2
+10...97 V DC
TFT100 UART PINOUT

Quick Manual v1.0 // TFT100 5
PIN COLOR PIN NAME DESCRIPTION
Red VCC (10-97) V DC (+) Power supply (+10...97 V
DC).
Black GND (-) Ground.
Yellow 1WIRE POWER Power supply pin for Dallas
1-Wire devices.
White/
Green CAN-H CAN interface High.
White CAN-L CAN interface Low.
Grey AIN 2 /
DIN 2
Analog input, channel 2 /
Digital input, channel 2.
White/
Orange
DOUT 1 /
DIN 3
Digital output, channel 1 /
Digital input, channel 3.
Violet DOUT 2 /
DIN 4
Digital output, channel 2 /
Digital input, channel 4.
Green AIN 1 /
DIN 1
Analog input, channel 1 /
Digital input, channel 1.
Blue 1WIRE DATA Data channel for 1–Wire
devices.
CAN PINOUT
DOUT2/DIN4
1-WIRE DATA
AIN1/DIN1
GND
DOUT1/DIN3
CAN-L
CAN-H
1-WIRE POWER
AIN2/DIN2
+10...97 V DC
TFT100 CAN PINOUT

Quick Manual v1.0 // TFT100 6
PIN COLOR PIN NAME DESCRIPTION
Red VCC (10-97) V DC (+) Power supply (+10...97 V
DC).
Black GND (-) Ground.
Yellow 1WIRE POWER Power supply pin for Dallas
1-Wire devices.
White/
Green RS232-IN Input wire for RS232.
White RS232-OUT Output wire for RS232.
Grey AIN 2 /
DIN 2
Analog input, channel 2 /
Digital input, channel 2.
White/
Orange
DOUT 1 /
DIN 3
Digital output, channel 1 /
Digital input, channel 3.
Violet DOUT 2 /
DIN 4
Digital output, channel 2 /
Digital input, channel 4.
Green AIN 1 /
DIN 1
Analog input, channel 1 /
Digital input, channel 1.
Blue 1WIRE DATA Data channel for 1–Wire
devices.
RS232 PINOUT
DOUT2/DIN4
1-WIRE DATA
AIN1/DIN1
GND
DOUT1/DIN3
RS232-OUT
RS232-IN
1-WIRE POWER
AIN2/DIN2
+10...97 V DC
TFT100 RS232 PINOUT

Quick Manual v1.0 // TFT100 7
PIN COLOR PIN NAME DESCRIPTION
Red VCC (10-97) V DC (+) Power supply (+10...97 V
DC).
Black GND (-) Ground.
Yellow 1WIRE POWER Power supply pin for Dallas
1-Wire devices.
White/
Green RS485-B Input for data reception
through UART.
White RS485-A Output for data
transmission through UART.
Grey AIN 2 /
DIN 2
Analog input, channel 2 /
Digital input, channel 2.
White/
Orange
DOUT 1 /
DIN 3
Digital output, channel 1 /
Digital input, channel 3.
Violet DOUT 2 /
DIN 4
Digital output, channel 2 /
Digital input, channel 4.
Green AIN 1 /
DIN 1
Analog input, channel 1 /
Digital input, channel 1.
Blue 1WIRE DATA Data channel for 1–Wire
devices.
RS485 PINOUT
DOUT2/DIN4
1-WIRE DATA
AIN1/DIN1
GND
DOUT1/DIN3
RS485-A
RS485-B
1-WIRE POWER
AIN2/DIN2
+10...97 V DC
TFT100 RS485 PINOUT

Quick Manual v1.0 // TFT100 8
WIRING SCHEME
BUZZER
IBUTTON
POWER SUPPLY
10 - 97 V DC
ALARM BUTTON
VEHICLE CAN
INTERFACE
USB
RS232RS485
BUFFERED
TRANSPARENT
MODE
BUFFERED
TRANSPARENT
MODE
CONFIGURATION
VIA PC
RFID
SUPER
SOCO
IF USING
DOUT1
IF USING
DOUT2
IF USING DIN2
IF USING DIN4
IF USING DIN3
IF USING DIN1

Quick Manual v1.0 // TFT100 9
SET UP YOUR DEVICE
HOW TO INSERT MICRO-SIM CARD
1
4
COVER REMOVAL
ATTACHING COVER BACK
3BATTERY CONNCETION 2
5
MICRO-SIM CARD INSERT
COMPLETELY CLOSED DEVICE
Remove the bottom cover.
After conguration, attach device
cover and put the screws back in.
Insert Micro-SIM card as shown
with PIN request disabled or read
Security info how to enter it later in
Congurator. Make sure that Micro-
SIM card cut-o corner is pointing
forward to slot.
Device is ready to be connected.
Connect the battery as shown to the
device.

Quick Manual v1.0 // TFT100 10
PC CONNECTION (WINDOWS)
HOW TO INSTALL USB DRIVERS (WINDOWS)
1. Please download COM port drivers from here1.
2. Extract and run TeltonikaCOMDriver.exe.
3. Click Next in driver installation window.
4. In the following window click Install button.
5. Setup will continue installing the driver and eventually the conrmation window will appear. Click Finish to complete the
setup.
1. Power-up TFT100 with DC voltage 10 - 97V power supply using supplied power cable. LED’s should start blinking, see “LED
behaviour description”.
2. Connect device to computer using Micro-USB cable or Bluetooth connection:
• Using Micro-USB cable
• You will need to install USB drivers, see "How to install USB drivers (Windows)"
• Using Bluetooth
• TFT100 Bluetooth is enabled by default. Turn on Bluetooth on your PC, then select Add Bluetooth or other device >
Bluetooth. Choose your device named – “TFT100_last_7_imei_digits”, without LE in the end. Enter default password 5555,
press Connect and then select Done.
3. You are now ready to use the device on your computer.
1 https://wiki.teltonika-gps.com/images/d/d0/TeltonikaCOMDriver.zip

Quick Manual v1.0 // TFT100 11
MS .NET REQUIREMENTS
Operating system MS .NET Framework version Version Links
Windows Vista
Windows 7
Windows 8.1
Windows 10
MS .NET Framework 4.6.2 32 and 64 bit www.microsoft.com1
1 dotnet.microsoft.com/en-us/download/dotnet-framework/net462
At rst TFT100 device will have default factory settings set. These settings should be changed according to the user’s needs. Main
conguration can be performed via Teltonika Congurator1software. Get the latest Congurator version from here2. Congurator
operates on Microsoft Windows OS and uses prerequisite MS .NET Framework. Make sure you have the correct version installed.
1 wiki.teltonika-gps.com/view/Teltonika_Congurator
2 wiki.teltonika-gps.com/view/Teltonika_Congurator_versions
CONFIGURATION

Quick Manual v1.0 // TFT100 12
Downloaded Congurator will be in compressed archive.
Extract it and launch Congurator.exe. After launch software
language can be changed by clicking 🌐in the right bottom
corner.
Conguration process begins by pressing on connected device.
TFT100
Various Status window1 tabs display information about GNSS2,
GSM3, I/O4,Maintenance5and etc. TFT100 has one user
editable prole, which can be loaded and saved to the device.
After any modication of conguration the changes need to
be saved to device using Save to device button. Main buttons
oer following functionality:
 Load from device – loads conguration from device.
 Save to device – saves conguration to device.
 Load from le – loads conguration from le.
 Save to le – saves conguration to le.
 Update rmware – updates rmware on device.
 Read records – reads records from the device.
 Reboot device – restarts device.
 Reset conguration – sets device conguration to
default.
Most important congurator section is GPRS – where all
your server and GPRS settings6 can be congured and Data
Acquisition7– where data acquiring parameters can be
congured. More details about TFT100 conguration using
Congurator can be found in our Wiki8.
After connection to Congurator Status window will be
displayed.
TFT100
1 wiki.teltonika-gps.com/view/TFT100_Status_info
2 wiki.teltonika-gps.com/view/TFT100_Status_info#GNSS_Info
3 wiki.teltonika-gps.com/view/TFT100_Status_info#GSM_Info
4 wiki.teltonika-gps.com/view/TFT100_Status_info#I.2FO_Info
5 wiki.teltonika-gps.com/view/TFT100_Status_info#Maintenance
6 wiki.teltonika-gps.com/index.php?title=TFT100_GPRS_settings
7 wiki.teltonika-gps.com/index.php?title=TFT100_Data_acquisition_set-
tings
8 wiki.teltonika-gps.com/index.php?title=TFT100_Conguration

Quick Manual v1.0 // TFT100 13
QUICK SMS CONFIGURATION
Default conguration has optimal parameters present to ensure best performance of track quality and data usage.
Quickly set up your device by sending this SMS command to it:
Note: Before SMS text, two space symbols should be inserted.
GPRS SETTINGS:
 2001 – APN
 2002 – APN username (if there are no APN username,
empty eld should be left)
 2003 – APN password (if there are no APN password,
empty eld should be left)
SERVER SETTINGS:
 2004 – Domain
 2005 – Port
 2006 – Data sending protocol (0 – TCP, 1 – UDP)
« setparam 2001:APN;2002:APN_username;2003:APN_password;2004:Domain;2005:Port;2006:0»
1 2 3 4 5 6
1
2
3
4
5
6

Quick Manual v1.0 // TFT100 14
DEFAULT CONFIGURATION SETTINGS
MOVEMENT AND IGNITION DETECTION: DEVICE MAKES A RECORD ON MOVING
IF ONE OF THESE EVENTS HAPPEN:
SPEED DIFFERENCE
between last coordinate
and current position is
greater than 10 km/h
VEHICLE DRIVES
100 meters
VEHICLE TURNS
10 degrees
PASSES
300 seconds
Time intervals and default I/O elements can be changed by using Teltonika Congurator1.
1 https://wiki.teltonika-gps.com/view/TFT100_Firmware_and_congurator
VEHICLE MOVEMENT
will be detected by
accelerometer
DEVICE MAKES A
RECORD ON STOP IF:
1 HOUR PASSES
while vehicle is
stationary
IGNITION
will be detected by
vehicle power voltage
between 12 – 30 V
RECORDS SENDING TO
SERVER:
EVERY 120 SECOND
it is sent to the server
If device has made a
record

Quick Manual v1.0 // TFT100 15
MOUNTING RECOMMENDATIONS
CONNECTING WIRES
• Wires should be connected while the module is not plugged in.
• Wires should be fastened to stable wires or other non-moving parts. Any heat emitting and/or moving objects should be
kept away from the wires.
• There should be no exposed wires. If factory isolation was removed while connecting wires, the isolation material should
be applied.
• If the wires are placed in the exterior or in places where they can be damaged or exposed to heat, humidity, dirt, etc.,
additional isolation should be applied and the wires should not be loose.
CONNECTING IGNITION WIRE
• Be sure to check if it is a real ignition wire i. e. power does not disappear after starting the engine.
• Check if this is not an ACC wire (when key is in the rst position, most of the vehicle electronics are available).
• Check if power is still available when you turn o any of vehicles devices.
• Ignition is connected to the ignition relay output. As alternative, any other relay, which has power output when ignition is
on, may be chosen.
CONNECTING GROUND WIRE
• Ground wire is connected to the vehicle frame or metal parts that are xed to the frame.
• If the wire is xed with the bolt, the loop must be connected to the end of the wire.
• For better contact scrub paint from the spot where loop is going to be connected.
PAY ATTENTION! Connecting the power supply must be carried out in a very low impedance point of on-board vehicle network.
These points in the car are the battery terminals. Therefore, we recommend connecting the power of TFT100 (GND and POWER wires)
directly to the battery terminals. Another valid option is to connect the wires to the main POWER cable inside the fuse box (if there is
none, then to the power supply where the fuses of vehicle’s computer are), GND wire must be connected in a special point, designed
to connect GND vehicle computer. Connecting the GND at an arbitrary point to the mass of the car is unacceptable, as static and
dynamic potentials on the line GND will be unpredictable, which can lead to unstable TFT100 operation and even its failure.

Quick Manual v1.0 // TFT100 16
BEHAVIOUR MEANING
Permanently
switched on GNSS signal is not received
Blinking every
second Normal mode, GNSS is working
O Device is not working or Device is in
sleep mode
Blinking fast
constantly Device rmware is being ashed
BEHAVIOUR MEANING
Blinking every
second Normal mode
Blinking every two
seconds Sleep mode
Blinking fast for a
short time Modem activity
O Device is not working or Device is in
boot mode
NAVIGATION LED INDICATIONS
STATUS LED INDICATIONS
BASIC CHARACTERISTICSLED INDICATIONS
PRODUCT
Model name
TFT100-TAIB0*,
TFT100-TAIBA**,
TFT100-TAIBB***,
TFT100-TAIBC****,
TFT100-TAIBD*****
MODULE
Name Teltonika TM2500
Technology 2G(GSM/GPRS)/GNSS/BLUETOOTH
GNSS
GNSS Teltonika TM2500
Receiver
L1: GPS, GLONASS, GALILEO,
BEIDOU, SBAS*, QZSS*, DGPS*,
AGPS*
Tracking sensitivity 33 tracking channel
99 acquisition channel
Position accuracy -165 dBM
Velocity accuracy < 0.1 m/s (within +/- 15% error)
*Standard CAN interface
**CAN with integrated 120 ohm resistor
***RS485 interface
****RS232 interface
*****UART interface

Quick Manual v1.0 // TFT100 17
Hot start < 1 s
Warm start < 25 s
Cold start < 35 s
CELLULAR
Technology GSM/GPRS
2G GSM: B2/B3/B5/B8
GPRS GPRS Mobile Station Class B
Data transfer GSM (GPRS): Max. 85.6 Kbps (DL) /
Max. 85.6 Kbps (UL)
Data support SMS (TEXT, PDU), Network protocols
(TCP,UDP,TLS,DTLS)
POWER
Input voltage range 10 - 97 V DC with overvoltage
protection
Back-up battery 1800 mAh Li-Ion battery 3.7 V (6.66
Wh)
Internal fuse 3.15 A, 125 V
POWER CONSUMPTION
At 12V (Ultra Deep
Sleep) < 8 mA
At 12V (Deep Sleep) < 12 mA
At 12V (Online Deep
Sleep) < 12 mA
At 12V (GPS Sleep) < 19.5 mA
At 12V (Nominal with
no load) < 34 mA
At 12V (With full
load/peak) < 2 A Max
PHYSICAL SPECIFICATION
Dimensions 72.5 x 73 x 27.3 mm (L x W x H)
Weight 169 g
OPERATING ENVIRONMENT
Operating
temperature
(without battery) -20 °C to +75 °C
Storage temperature
(without battery) -20 °C to +75 °C
Operating
temperature (with
battery)
-20 °C to +60 °C
*Optional GNSS modes available with custom rmware development,
for more information contact your sales manager.

Quick Manual v1.0 // TFT100 18
Storage temperature
(with battery) -20 °C to +45 °C
Operating humidity 5% to 95% non-condensing
Ingress protection
Rating IP67
Battery charge
temperature 0 °C to +45 °C
Battery discharge
temperature -20 °C to +70 °C
Battery storage
temperature -10 °C to +45 °C
INTERFACE
Digital input 4
Digital output 2
Analog input 2
1-Wire Data 1
1-Wire Power 1
Communication
interface CAN / RS485 / RS232 / UART*
GNSS antenna Internal High Gain
Cellular antenna Internal High Gain
USB 2.0 Micro-USB
LED indication 2 status LED lights
SIM Micro-SIM, eSIM**
Memory 128MB internal ash memory
*Depending on ordered TFT100 modication
**eSIM is available with separate PCB assembly, for more information
contact your sales manager
FEATURES
Sensors Accelerometer
Scenarios
Eco/Green Driving, Over Speeding,
Jamming, Excessive Idling, FallDown,
Towing detection, Crash detection,
Auto Geofence, Manual Geofence,
Trip/Odometer, Immobilizer,
iButton, DOUT control via call,
DOUT control via Ignition, Last
Known Position, Timestamp Backup,
Ignition ON Counter
CAN Modes*
Manual CAN, Manual CAN
commands, Manual J1939, Bosch,
Askoll, Default J1939, FLEX, Debug
RS485 Modes** Log Mode, NMEA, TCP Ascii, TCP
Binary, Super Soco
RS232 Modes*** Log Mode, NMEA, TCP Ascii, TCP
Binary
UART Modes*** Log Mode, NMEA, TCP Ascii, TCP
Binary
Sleep Modes GPS Sleep, Online Deep Sleep, Deep
Sleep, Ultra Deep Sleep

Quick Manual v1.0 // TFT100 19
Conguration and
rmware update
FOTA Web, Teltonika Congurator
(USB, Bluetooth)
SMS Conguration, Events, Debug
GPRS commands Conguration, Debug
Time
Synchronization GNSS, NITZ, NTP
Ignition detection Accelerometer, External Power
Voltage, DIN1, DIN3, DIN4, CAN*
*Available for TFT100-TAIB0 and TFT100-TAIBA
**Available for TFT100-TAIBB
***Available for TFT100-TAIBC and TFT100-TAIBD
CERTIFICATION &
APPROVALS
Regulatory CE (RED), EAC, E-Mark, Anatel, UKCA,
Ukrainian UCRF, RoHS, REACH, IP67

Quick Manual v1.0 // TFT100 20
This message contains information on how to operate
the device safely. By following these requirements and
recommendations, you will avoid dangerous situations. Please
read these instructions carefully and follow them strictly
before operating the device!
SAFETY INFORMATION
Do not disassemble the device. If the device is
damaged, the power supply cables are not isolated
or the isolation is damaged, DO NOT touch the
device before unplugging the power supply.
All wireless data transferring devices produce
interference that may aect other devices which are
placed nearby.
The programming must be performed using a PC
with autonomic power supply.
The device must be rmly fastened in a predened
location.
The device must be connected only by qualied
personnel.
Installation and/or handling during a lightning storm
is prohibited.
The device is susceptible to water and humidity.
Risk of explosion if battery is replaced by an
incorrect type. Dispose of used batteries according
to the instructions.
Battery should not be disposed of with general
household waste. Bring damaged or worn-out
batteries to your local recycling center or dispose
them to battery recycle bin found in stores.
