TAT100 First Start
From Wiki Knowledge Base | Teltonika Mobility
Main Page > Asset Trackers > TAT100 > TAT100 First Start
TAT100 is a device for asset tracking and additional protection against thefts of valuable goods, as well as it could be used in wide range of
applications from tools tracking to container tracking.
Contents
1 Know your device
2 Set up your device
2.1 How to insert Micro SIM card and start the device
2.2 PC Connection (Windows)
2.3 How to install USB drivers (Windows)
2.4 Conguration (Windows)
2.5 Important conguration notes
2.6 Tracking scenarios
2.7 Mounting recommendations

Saltoniškių g. 9B-1,
LT-08105 Vilnius
Tel. [phone]
Faks. [phone]
www.teltonika-iot-group.com
[email protected]
2.8 Quick SMS conguration
3 Safety information
3.1 Precautions
Know your device
Set up your device
How to insert Micro SIM card and start the device
1. Remove the cover.

Saltoniškių g. 9B-1,
LT-08105 Vilnius
Tel. [phone]
Faks. [phone]
www.teltonika-iot-group.com
[email protected]
2. Insert Micro-SIM card as shown with PIN request disabled or read Security info how to enter it later in Congurator. Make sure that Micro-
SIM card cut-o corner is pointing forward to slot and chip is facing USB port.
3. Flip the switch to ON.
4. Congure the device. When it is done, reattach the cover and push it in place.
Micro-SIM card insertion/removal must be performed when device is turned o. Otherwise Micro-SIM card might be damaged or
device will not detect it.
PC Connection (Windows)
1. Remove the cover.

Saltoniškių g. 9B-1,
LT-08105 Vilnius
Tel. [phone]
Faks. [phone]
www.teltonika-iot-group.com
[email protected]
2. Turn on your device by ipping the switch to ON.
3. Connect device to computer using Micro-USB cable. You will need to install USB drivers, see “How to install USB drivers (Windows)” shown
below.
4. You are now ready to use the device on your computer.
How to install USB drivers (Windows)
1. Please download COM port drivers from here (https://teltonika-gps.com/downloads/en/fmb120/TeltonikaCOMDriver.zip).
2. Extract and run TeltonikaCOMDriver.exe.
3. Click Next in driver installation window.
4. In the following window click Install button. Setup will continue installing the driver and eventually the conrmation window will appear. Click
Finish to complete the setup.
Conguration (Windows)
At rst the device will have default factory settings unless you order pre-congured device. These settings should be changed according to the
user's needs.
Main conguration can be performed via Teltonika Congurator software. Congurator operates on Microsoft Windows OS and uses
prerequisite MS .NET Framework. Make sure you have the correct version installed.

Saltoniškių g. 9B-1,
LT-08105 Vilnius
Tel. [phone]
Faks. [phone]
www.teltonika-iot-group.com
[email protected]
MS .NET requirements
Operating system MS .NET Framework
version Version Link
Windows
Vista
Windows 7
Windows
8.1
Windows 10
MS .NET Framework 4.6.2 32 and 64
bit
www.microsoft.com
(https://dotnet.micro
soft.com/en-us/down
load/dotnet-framewo
rk)
Downloaded Congurator will be in compressed archive. Extract it and launch Congurator.exe. After launch software language can be changed
by clicking in the right bottom corner:
Conguration process begins by pressing on connected device:
After connection to Congurator Status window will be displayed:

Saltoniškių g. 9B-1,
LT-08105 Vilnius
Tel. [phone]
Faks. [phone]
www.teltonika-iot-group.com
[email protected]

Saltoniškių g. 9B-1,
LT-08105 Vilnius
Tel. [phone]
Faks. [phone]
www.teltonika-iot-group.com
[email protected]
Various Status info tabs display information about GNSS, GSM, I/O, Maintenance and etc. TAT100 has one user editable prole, which can be
loaded and saved to the device. After any modication of conguration the changes need to be saved to device using Save to device button.
Main buttons oer following functionality:
1. Load from device – loads conguration from device.
2. Save to device – saves conguration to device.
3. Load from le – loads conguration from le.
4. Save to le – saves conguration to le.
5. Update rmware – updates rmware on device.
6. Read records – read records from device.
7. Reboot device – restarts device.
8. Reset conguration – sets device conguration to default.
Most important congurator sections are GPRS – where all your server and GPRS settings can be congured and Tracking – where data
acquiring parameters can be congured. More details about TAT100 conguration using Congurator can be found here.
Important conguration notes
We strongly recommend testing the network connection from device to the server before adjusting
TAT100 conguration to your needs.
Use the following steps to perform this test:
Congure these parameters: APN, server Domain and server Port
Save conguration to the device by clicking on a Save to device button;
Initiate connection by pressing the Test Connection button
At this point, TAT100 device will create one high-priority record and initiates connection to the server immediately. If connection was not
initiated, it can mean any of the following:
Improperly inserted SIM Card

Saltoniškių g. 9B-1,
LT-08105 Vilnius
Tel. [phone]
Faks. [phone]
www.teltonika-iot-group.com
[email protected]
Incorrect values are set to these elds: APN, Domain or Port
GPRS functionality disabled by GSM provider
No GSM coverage
Server cannot be reached
Try solving this problem before proceeding with further device conguration.
Please note:
Why TAT100 is not sending data: Instructions
Common conguration issues: Instructions
CAUTION! Device usage with USB cable.
In order to prevent device battery from running out of power, make sure USB cable is not
connected, while testing the device.
Continuous use of device, while connected to the USB cable will result in faster battery drain.
Tracking scenarios
Periodic: This mode is used to get positioning data at xed intervals. Conguration range is from 360 to 259200 (in seconds).

Saltoniškių g. 9B-1,
LT-08105 Vilnius
Tel. [phone]
Faks. [phone]
www.teltonika-iot-group.com
[email protected]
Please note:
Default tracking period (On Move/On stop) is set to 28800 seconds (8 hours)
Frequent tracking period will reduce battery lifetime!
For more information refer to: Tracking settings
Scheduler: This mode is used to get positioning data at xed schedule. Device can send positioning data up to 6 times on set days.
Time Zone: Set tracking scenario time zone. Time zone can be set in range of -12h to +14h.
Main rules of Schedule setting:

Saltoniškių g. 9B-1,
LT-08105 Vilnius
Tel. [phone]
Faks. [phone]
www.teltonika-iot-group.com
[email protected]
Intervals between time must be at least 6 minutes.
Days of the week must be selected and highlighted for the device to send records according to set schedule.
Please note:
Device has up to 3 min. hardcoded time to get xed position while it's awake from a Sleep
Mode.
If GNSS signal is poor - device will need more time to get xed position. Battery usage is higher
while device is looking for GNSS positions than it stays in Sleep Mode.
Mounting recommendations

Saltoniškių g. 9B-1,
LT-08105 Vilnius
Tel. [phone]
Faks. [phone]
www.teltonika-iot-group.com
[email protected]
We recommend placing the device in such a way, that the GNSS antenna is facing upwards to the sky.
We recommend to install the device in a place where the TAT100 line of sight to the sky is not obstructed.
Quick SMS conguration
Please note:
SMS message cannot be delivered until the device has woken up from Sleep Mode to
deliver location data to the server.
During the period, when device is in Sleep Mode, SMS carrier holds SMS message
delivery.
We cannot control mobile provider's SMS deliveries or assure that your SMS message
will be received until next device wake up cycle, therefore we recommend to congure
the device using the congurator.

Saltoniškių g. 9B-1,
LT-08105 Vilnius
Tel. [phone]
Faks. [phone]
www.teltonika-iot-group.com
[email protected]
Default conguration has optimal parameters present to ensure best performance of track quality and data usage.
Quickly set up your device by sending this SMS command to it:
" setparam 2001:APN;2002:APN_username;2003:APN_password;2004:Domain;2005:Port;2006:0"
Note: Before SMS command, two space symbols must be inserted.
GPRS settings:
2001 – APN
2002 – APN username (if there are no APN username, empty eld
should be left)
2003 – APN password (if there are no APN password, empty eld
should be left)
Server settings:
2004 – Domain
2005 – Port
2006 – Data sending protocol (0 – TCP, 1 – UDP)

Saltoniškių g. 9B-1,
LT-08105 Vilnius
Tel. [phone]
Faks. [phone]
www.teltonika-iot-group.com
[email protected]
After successful SMS conguration, TAT100 device will synchronize time and update records to congured server.
Safety information

Saltoniškių g. 9B-1,
LT-08105 Vilnius
Tel. [phone]
Faks. [phone]
www.teltonika-iot-group.com
[email protected]
This message contains information on how to operate TAT100 safely. By following these requirements and recommendations, you will avoid
dangerous situations. You must read these instructions carefully and follow them strictly before operating the device!
Precautions

Saltoniškių g. 9B-1,
LT-08105 Vilnius
Tel. [phone]
Faks. [phone]
www.teltonika-iot-group.com
[email protected]
Operate the device in suitable conditions
Do not use the device where mobile connectivity is forbidden.
Road safety rst
Comply with local trac laws, always hold your hands on a steering wheel when using a device. Your safety is of utmost importance when you drive.
Interference
All wireless devices are sensitive to electromagnetic interference, as a result wireless devices aect the performance of each other.
Limit the use of device in hospitals
Please follow all restrictions. Turn o the device in the vicinity of medical devices when required.
Limit the use of device in vehicles
Please follow all restrictions. Wireless devices can interfere with other electronic equipment in vehicles.
Be cautious near ammable materials and liquids
Use only original batteries
Using uncertied manufacturer or dierent type batteries may cause an explosion.
Use batteries safely
Protect batteries from moisture. Avoid extensive operation at high temperatures. Batteries are integrated, do not attempt to change or charge the batteries.
Remove device safely
Device must be disconnected from computer by unplugging the micro USB cable from the device.

Saltoniškių g. 9B-1,
LT-08105 Vilnius
Tel. [phone]
Faks. [phone]
www.teltonika-iot-group.com
[email protected]
Other
In order to prevent device from mechanical damage it is advisable to transport it in a shock–resistant packaging. If device stopped working properly regardless of the
settings only a qualied specialist can help. It is recommended to contact your local seller or your UAB Teltonika manager in such a case.
