Teltonika MVC200 User manual

4
STEP 5 Main interface
1
Locate and run DVS Client Software file from CD directory.
2
Install and run DVC software application.
NOTE: Default password for login is blank (leave this field empty).
3
Click icon for the video server to be available in the local LAN device list.
NOTE: PC and Video Server must be in the same network for proper connection.
After successful connection and
login you will be able to monitor
and record video stream in the
main operational window.
You will be able to work with up
to 30 cameras at the same time.
For more detailed information on
a usage of this software please
refer to it User Manual.
Troubleshooting
In case if your LAN (Local Area Network) device list is empty, check these steps:
*
Check and insure your 3G Camera is powered.
*
Check and insure your 3G Camera and PC are connected with LAN cable.
NOTE: LAN port green LED will blink or stay bright indicating successful
connection.
*
Check and insure Firewall is switched off.
If you still facing problems, please contact you local dealer.
LEGAL NOICE
Copyright © 2010 TELTONIKA Ltd. All rights reserved. Reproduction, transfer, distribution or
storage of part or all of the contents in this document in any form without the prior written permission of
TELTONIKA Ltd is prohibited.
Other product and company names mentioned herein and above may be trademarks or trade names of their
respective owners.
QUICK START GUIDE
v.1.0
3G MOBILE CAMERA
MVC200
PACKAGE CONTENTS CHECKLIST
MVC200 3G Camera
External GSM antenna
AC/DC Power adapter
Leaflet “Quick Start Guide”
CD with software and manual
Screw driver
LAN Ethernet cable
3G MOBILE CAMERA
MVC200
3G MOBILE CAMERA
MVC200

2 3
Back panel
Figure 1. 3G Camera back panel view.
1. Power supply adapter socket.
2. Reset Button.
3. LAN Ethernet Port (RJ45).
4. Ain –Audio Input.
5. Aout –Audio Output.
6. SD Card –SD Card slot.
7. ANT - GSM antenna connector.
8. ALM in –Alarm Input.
9. ALM out –Alarm Output.
STEP 1 Insert SIM card
NOTE: Insure that SIM card is not PIN protected before installation.
1
Unscrew four screws of the front panel and pull out gently until SIM holder will be visible.
NOTE: Do not pull out front panel more, than it shown on the picture below!
2
Take out mounting frame and insert SIM card with a contacts face down and “cut-off” corner on the
top.
NOTE: Front and back panels are connected with GSM antenna cable!
3
Attach mounting frame and front panel to it previous position.
STEP 2 Attach antenna
Screw in the antenna in a clockwise direction. Position
the antenna upwards at its connecting joint. This will
ensure optimal GSM signal reception.
STEP 3 Camera Configuration
1
Locate and run “IPCAM Network Setup”
file from CD directory.
2
Select available camera in bottom field of
a left column “Information about this
computer”
NOTE: In case if your camera is not in
the list, try to connect it directly to you
PC with the same subnet.
3
Configure IP settings and generate
Administrator password in a right
column. Save your settings by pressing
“Save Settings” button.
NOTE: Camera’s default IP address is
http://192.168.0.233
STEP 4 Log in to the 3G Camera
1
Run Internet Explorer and enter your
camera IPaddress in address field.
NOTE: OCX plug-in is must for proper
use. Click the link on Login page bottom
and follow onscreen instructions.
Remember to close the browser before
installation.
2
Enter User and Password in proper fields
and press “Login“ button.
NOTE: Default Login settings are:
User –admin
Password –admin
NOTE: For detailed information on camera configuration, please refer to Users Manual.
