Axis P3905-RE User manual

AXISP3905-RENetworkCamera
UserManual

AboutthisDocument
Thismanualisintendedforadministratorsandusersof
AXISP3905–RENetworkCameraandisapplicabletormware6.50
andlater.Itincludesinstructionsforusingandmanagingtheproduct
onyournetwork.Previousexperienceofnetworkingwillbeofusewhen
usingthisproduct.SomeknowledgeofUNIXorLinux-basedsystems
mayalsobeusefulwhendevelopingshellscriptsandapplications.Later
versionsofthisdocumentwillbepostedatwww.axis.com.Seealsothe
product’sonlinehelpavailablethroughtheweb-basedinterface.
Lealconsiderations
Videosurveillancecanberegulatedbylawsthatvaryfromcountryto
country.Checkthelawsinyourlocalregionbeforeusingthisproduct
forsurveillancepurposes.
Thisproductincludesthefollowinglicences:
•one(1)H.264decoderlicense
Topurchasefurtherlicensescontactyourreseller.
Liability
Everycarehasbeentakeninthepreparationofthisdocument.Please
informyourlocalAxisofceofanyinaccuraciesoromissions.Axis
CommunicationsABcannotbeheldresponsibleforanytechnicalor
typographicalerrorsandreservestherighttomakechangestothe
productandmanualswithoutpriornotice.AxisCommunicationsAB
makesnowarrantyofanykindwithregardtothematerialcontained
withinthisdocumentincludingbutnotlimitedtotheimplied
warrantiesofmerchantabilityandtnessforaparticularpurpose.Axis
CommunicationsABshallnotbeliablenorresponsibleforincidentalor
consequentialdamagesinconnectionwiththefurnishingperformance
oruseofthismaterial.Thisproductisonlytobeusedforitsintended
purpose.
Intellectualpropertyrihts
AxisABhasintellectualpropertyrightsrelatingtotechnologyembodied
intheproductdescribedinthisdocument.Inparticularandwithout
limitationtheseintellectualpropertyrightsmayincludeoneormore
ofthepatentslistedatwww.axis.com/patent.htmandoneormore
additionalpatentsorpendingpatentapplicationsintheUSandother
countries.
Thisproductcontainslicensedthird-partysoftware.Seethemenuitem
“About”intheproduct’suserinterfaceformoreinformation.
ThisproductcontainssourcecodecopyrightAppleComputer
Inc.underthetermsofApplePublicSourceLicense2.0(see
www.opensource.apple.com/apsl).Thesourcecodeisavailablefrom
https://developer.apple.com/bonjour/
Equipmentmodications
Thisequipmentmustbeinstalledandusedinstrictaccordancewiththe
instructionsgivenintheuserdocumentation.Thisequipmentcontains
nouser-serviceablecomponents.Unauthorizedequipmentchangesor
modicationswillinvalidateallapplicableregulatorycertications
andapprovals.
Trademarkacknowledments
AXISCOMMUNICATIONSAXISandVAPIXareregisteredtrademarksor
trademarkapplicationsofAxisABinvariousjurisdictions.Allother
companynamesandproductsaretrademarksorregisteredtrademarks
oftheirrespectivecompanies.
AppleBoaApacheBonjourEthernetInternetExplorerLinux
MicrosoftMozillaRealSMPTEQuickTimeUNIXWindowsWindows
VistaandWWWareregisteredtrademarksoftherespectiveholders.
JavaandallJava-basedtrademarksandlogosaretrademarksor
registeredtrademarksofOracleand/oritsafliates.UPnPTMisa
certicationmarkoftheUPnPTMImplementersCorporation.
SDSDHCandSDXCaretrademarksorregisteredtrademarksofSD-3C
LLCintheUnitedStatesothercountriesorboth.AlsominiSDmicroSD
miniSDHCmicroSDHCmicroSDXCarealltrademarksorregistered
trademarksofSD-3CLLCintheUnitedStatesothercountriesorboth.
Reulatoryinformation
Europe
ThisproductcomplieswiththeapplicableCEmarkingdirectives
andharmonizedstandards:
•ElectromagneticCompatibility(EMC)Directive2014/30/EU.See
Electromagneticcompatibility(EMC)onpage2.
•LowVoltage(LVD)Directive2014/35/EU.Seeafetyonpage3.
•RestrictionsofHazardousSubstances(RoHS)Directive2011/65/EU.
SeeDisposalandrecyclingonpage3.
Acopyoftheoriginaldeclarationofconformitymaybeobtainedfrom
AxisCommunicationsAB.SeeContactinformationonpage3.
Electromaneticcompatibility(EMC)
Thisequipmenthasbeendesignedandtestedtofulllapplicable
standardsfor:
•Radiofrequencyemissionwheninstalledaccordingtothe
instructionsandusedinitsintendedenvironment.
•Immunitytoelectricalandelectromagneticphenomenawhen
installedaccordingtotheinstructionsandusedinitsintended
environment.
USA
Usinganunshieldednetworkcable(UTP)–Thisequipmenthas
beentestedusinganunshieldednetworkcable(UTP)andfoundto
complywiththelimitsforaClassAdigitaldevicepursuanttopart
15oftheFCCRules.Theselimitsaredesignedtoprovidereasonable
protectionagainstharmfulinterferencewhentheequipmentis
operatedinacommercialenvironment.Thisequipmentgenerates
usesandcanradiateradiofrequencyenergyandifnotinstalledand
usedinaccordancewiththeinstructionmanualmaycauseharmful
interferencetoradiocommunications.Operationofthisequipmentina
residentialareaislikelytocauseharmfulinterferenceinwhichcase
theuserwillberequiredtocorrecttheinterferenceathisownexpense.
Usingashieldednetworkcable(STP)–Thisequipmenthasalso
beentestedusingashieldednetworkcable(STP)andfoundtocomply
withthelimitsforaClassBdigitaldevicepursuanttopart15ofthe
FCCRules.Theselimitsaredesignedtoprovidereasonableprotection
againstharmfulinterferenceinaresidentialinstallation.This
equipmentgeneratesusesandcanradiateradiofrequencyenergyand
ifnotinstalledandusedinaccordancewiththeinstructionsmaycause
harmfulinterferencetoradiocommunications.Howeverthereisno
guaranteethatinterferencewillnotoccurinaparticularinstallation.If
thisequipmentdoescauseharmfulinterferencetoradioortelevision
receptionwhichcanbedeterminedbyturningtheequipmentoffand
ontheuserisencouragedtotrytocorrecttheinterferencebyoneor
moreofthefollowingmeasures:
•Reorientorrelocatethereceivingantenna.
•Increasetheseparationbetweentheequipmentandreceiver.
•Connecttheequipmentintoanoutletonacircuitdifferentfrom
thattowhichthereceiverisconnected.
•Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
Tobeusedinaresidentialareaorademandingelectricalenvironment
theproductshallbeconnectedusingashieldednetworkcable(STP)
thatisproperlygrounded.
Canada
ThisdigitalapparatuscomplieswithCANICES-3(ClassB).Theproduct
shallbeconnectedusingashieldednetworkcable(STP)thatis
properlygrounded.Cetappareilnumériqueestconformeàlanorme
CANNMB-3(classeB).Leproduitdoitêtreconnectéàl'aided'uncâble
réseaublindé(STP)quiestcorrectementmisàlaterre.
Europe
ThisdigitalequipmentfulllstherequirementsforRFemission
accordingtotheClassBlimitofEN55022.Theproductshallbe
connectedusingashieldednetworkcable(STP)thatisproperly
grounded.
Australia/NewZealand
ThisdigitalequipmentfulllstherequirementsforRFemission
accordingtotheClassBlimitofAS/NZSCISPR22.Theproductshall
beconnectedusingashieldednetworkcable(STP)thatisproperly
grounded.
apan
この装置は、クラスB情報技術装置です。この装置は、家
庭環境で使⽤することを⽬的としていますが、この装置が
ラジオやテレビジョン受信機に近接して使⽤されると、受
信障害を引き起こすことがあります。取扱説明書に従って
正しい取り扱いをして下さい。本製品は、シールドネット
ワークケーブル(STP)を使⽤して接続してください。また
適切に接地してください。
Korea

이기기는가정용(B급)전자파적합기기로서주로가정에
서사용하는것을목적으로하며,모든지역에서사용할수
있습니다.적절히접지된STP(shieldedtwistedpair)케이
블을사용하여제품을연결하십시오.
Safety
ThisproductcomplieswithIEC/EN/UL60950-1and
IEC/EN/UL60950-22SafetyofInformationTechnology
Equipment.Theproductshallbegroundedeitherthroughashielded
networkcable(STP)orotherappropriatemethod.
Disposalandrecyclin
Whenthisproducthasreachedtheendofitsusefullifedisposeof
itaccordingtolocallawsandregulations.Forinformationabout
yournearestdesignatedcollectionpointcontactyourlocalauthority
responsibleforwastedisposal.Inaccordancewithlocallegislation
penaltiesmaybeapplicableforincorrectdisposalofthiswaste.
Europe
Thissymbolmeansthattheproductshallnotbedisposedof
togetherwithhouseholdorcommercialwaste.Directive2012/19/EU
onwasteelectricalandelectronicequipment(WEEE)isapplicablein
theEuropeanUnionmemberstates.Topreventpotentialharmto
humanhealthandtheenvironmenttheproductmustbedisposed
ofinanapprovedandenvironmentallysaferecyclingprocess.For
informationaboutyournearestdesignatedcollectionpointcontact
yourlocalauthorityresponsibleforwastedisposal.Businessesshould
contacttheproductsupplierforinformationabouthowtodispose
ofthisproductcorrectly.
ThisproductcomplieswiththerequirementsofDirective201 1/65/EUon
therestrictionoftheuseofcertainhazardoussubstancesinelectrical
andelectronicequipment(RoHS).
China
ThisproductcomplieswiththerequirementsofSJ/T11364-2014
Markingfortherestrictionofhazardoussubstancesinelectricaland
electronicproducts.
有毒有害物质或元素
部
件
名
称
铅
(Pb)汞
(Hg)镉
(Cd)六价
铬
(Cr(VI)
)
多溴
联苯
(PBB)
多溴
二苯
醚
(PBDE)
电
气
实
装
部
分
X00000
0:表示该有毒有害物质在该部件所有均质材料中的含量均在
GB/T26572标准规定的限量要求以下。
X:表示该有毒有害物质至少在该部件的某一均质材料中的含
量超出GB/T26572标准规定的限量要求。
Contactinformation
AxisCommunicationsAB
Emdalavägen14
22369Lund
Sweden
Tel:[phone]
Fax:[phone]
www.axis.com
Support
ShouldyourequireanytechnicalassistancepleasecontactyourAxis
reseller.Ifyourquestionscannotbeansweredimmediatelyyour
resellerwillforwardyourqueriesthroughtheappropriatechannelsto
ensurearapidresponse.IfyouareconnectedtotheInternetyoucan:
•downloaduserdocumentationandsoftwareupdates
•ndanswerstoresolvedproblemsintheFAQdatabase.Search
byproductcategoryorphrase
•reportproblemstoAxissupportstaffbyloggingintoyourprivate
supportarea
•chatwithAxissupportstaff
•visitAxisSupportatwww.axis.com/support
Warrantyinformation
ForinformationaboutAxis’productwarrantyandtheretorelated
informationgotowww.axis.com/warranty/
Learnmore!
VisitAxislearningcenterwww.axis.com/academy/forusefultrainings
webinarstutorialsandguides.

AXISP3905-RENetworkCamera
TableofContents
Safetyinformation..........................................6
Hazardlevels...................................................6
Othermessagelevels.............................................6
Hardwareoverview..........................................7
Howtoaccesstheproduct....................................8
Howtoaccesstheproductfromabrowser...........................8
HowtoaccesstheproductfromtheInternet.........................8
Howtosettherootpassword.....................................9
Abouttheliveviewwindow.......................................9
Aboutmediastreams........................................12
AboutH.264format.............................................12
AboutMJPEGformat............................................12
AboutAXISMediaControl(AMC)...................................12
Alternativemethodsofaccessingthevideostream....................13
Howtosetuptheproduct....................................15
Howtoperformabasicsetup.....................................15
Aboutvideosettings........................................16
Howtosetupvideostreams......................................16
Aboutstreamproles............................................18
AboutONVIFmediaproles.......................................18
Aboutcamerasettings...........................................18
ViewArea.....................................................20
Aboutoverlays..................................................21
Aboutprivacymasks.............................................23
Howtoconguretheliveviewwindow.........................24
AboutPTZ(PanTiltZoom)....................................26
Aboutpresetpositions...........................................26
Aboutguardtours...............................................27
Advanced......................................................27
Aboutthecontrolqueue..........................................28
Aboutdetectors............................................29
Aboutcameratampering.........................................29
Aboutapplications..........................................30
Aboutapplicationlicenses........................................30
Howtouploadandstartanapplication.............................30
ApplicationConsiderations........................................30
Aboutevents...............................................31
Howtosetupactionrules........................................31
Howtoaddrecipients............................................33
Howtocreateschedules..........................................34
Howtosetuprecurrences........................................35
Aboutrecordings...........................................36
Howtondrecordings...........................................36
Howtoplayrecordings...........................................36
Howtoexportavideoclip........................................37
Aboutcontinuousrecording.......................................37
Aboutlanguages............................................38
Aboutsystemoptions........................................39
Security.......................................................39
Date&Time....................................................41
Network.......................................................41
Storage.......................................................46
Maintenance...................................................49
Support.......................................................49
Advanced......................................................50
Howtoresettofactorydefaultsettings.............................50
Troubleshooting............................................52
Howtocheckthecurrentrmware.................................52
Howtoupgradethermware.....................................52
Symptomspossiblecausesandremedialactions......................53
Technicalspecications......................................56
4

AXISP3905-RENetworkCamera
TableofContents
LEDIndicators..................................................56
SDcardslot....................................................56
Buttons.......................................................56
Connectors....................................................57
Performanceconsiderations.......................................57
5

AXISP3905-RENetworkCamera
Safetinformation
Safetinformation
Hazardlevels
DANGER
Indicatesahazardoussituationwhichifnotavoidedwillresultindeathorseriousinjury.
WARNING
Indicatesahazardoussituationwhichifnotavoidedcouldresultindeathorseriousinjury.
CAUTION
Indicatesahazardoussituationwhichifnotavoidedcouldresultinminorormoderateinjury.
NO NO
NOTICE TICE TICE
Indicatesasituationwhichifnotavoidedcouldresultindamagetoproperty.
Othermessaelevels
Important
Indicatessignicantinformationwhichisessentialfortheproducttofunctioncorrectly.
Note
Indicatesusefulinformationwhichhelpsingettingthemostoutoftheproduct.
6

AXISP3905-RENetworkCamera
Hardwareoverview
Hardwareoverview
ForspecicationsofthehardwarecomponentsseeTechnicalspecicationsonpage56.
1Opticassembly
2Lenstool
3Partnumber(P/N)&erialnumber(/N)
4LEDindicators
5Dcardslot(microD)
6Controlbutton
7NetworkconnectorM12/RJ45
8Topcover
7

AXISP3905-RENetworkCamera
Howtoaccesstheproduct
Howtoaccesstheproduct
ToinstalltheAxisproductseetheInstallationGuidesuppliedwiththeproduct.
Theproductcanbeusedwithmostoperatingsystemsandbrowsers.Werecommendthefollowingbrowsers:
•InternetExplorer®withWindows®
•Safari®withOSX®
•ChromeTMorFirefox®withotheroperatingsystems.
ToviewstreamingvideoinInternetExplorerallowinstallationofAXISMediaControl(AMC)whenprompted.
TheAxisproductincludesone(1)H.264decoderlicenseforviewingvideostreams.ThelicenseisautomaticallyinstalledwithAMC.
Theadministratorcandisabletheinstallationofthedecoderstopreventinstallationofunlicensedcopies.
Note
•QuickTimeTMisalsosupportedforviewingH.264streams.
Howtoaccesstheproductfromabrowser
1.Startawebbrowser.
2.EntertheIPaddressorhostnameoftheAxisproductinthebrowser’saddresseld.
ToaccesstheproductfromaMaccomputer(OSX)gotoSafariclickonBonjourandselecttheproductfromthe
drop-downlist.
IfyoudonotknowtheIPaddressuseAXISIPUtilitytolocatetheproductonthenetwork.Forinformationabout
howtodiscoverandassignanIPaddressseethedocumentAssignanIPAddressandAccesstheVideotreamonAxis
Supportwebatwww.axis.com/support
Note
ToshowBonjourasabrowserbookmarkgotoSafari>Preferences.
3.Enteryourusernameandpassword.Ifthisisthersttimetheproductisaccessedtherootpasswordmustrstbe
congured.
4.Theproduct’sliveviewpageopensinyourbrowser.
Note
Thecontrolsandlayoutoftheliveviewpagemayhavebeencustomizedtomeetspecicinstallationrequirementsand
userpreferences.Consequentlysomeoftheexamplesandfunctionsfeaturedheremaydifferfromthosedisplayedin
yourownliveviewpage.
HowtoaccesstheproductfromtheInternet
OnceconnectedtheAxisproductisaccessibleonyourlocalnetwork(LAN).ToaccesstheproductfromtheInternetyoumust
congureyournetworkroutertoallowincomingdatatrafctotheproduct.TodothisenabletheNAT-traversalfeaturewhich
willattempttoautomaticallyconguretheroutertoallowaccesstotheproduct.ThisisenabledfromSetup>SystemOptions>
Network>TCP/IPAdvanced.
FormoreinformationseeNATtraversal(portmapping)forIPv4onpage44.SeealsoAXISInternetDynamicDNSServiceat
www.axiscam.net
ForTechnicalnotesonthisandothertopicsvisittheAxisSupportwebatwww.axis.com/support
8

AXISP3905-RENetworkCamera
Howtoaccesstheproduct
Howtosettherootpassword
ToaccesstheAxisproductyoumustsetthepasswordforthedefaultadministratoruserroot.ThisisdoneintheCongureRoot
Passworddialogwhichopenswhentheproductisaccessedforthersttime.
TopreventnetworkeavesdroppingtherootpasswordcanbesetviaanencryptedHTTPSconnectionwhichrequiresanHTTPS
certicate.HTTPS(HypertextTransferProtocoloverSSL)isaprotocolusedtoencrypttrafcbetweenwebbrowsersandservers.The
HTTPScerticateensuresencryptedexchangeofinformation.SeeHTTPonpage40.
Thedefaultadministratorusernamerootispermanentandcannotbedeleted.Ifthepasswordforrootislosttheproductmustbe
resettothefactorydefaultsettings.SeeHowtoresettofactorydefaultsettingsonpage50.
TosetthepasswordviaastandardHTTPconnectionenteritdirectlyinthedialog.
TosetthepasswordviaanencryptedHTTPSconnectionfollowthesesteps:
1.ClickUseHTTPS.
Atemporarycerticate(validforoneyear)iscreatedenablingencryptionofalltrafctoandfromtheproductandthe
passwordcannowbesetsecurely.
2.Enterapasswordandthenre-enterittoconrmthespelling.
3.ClickOK.Thepasswordhasnowbeencongured.
SetPowerLineFrequency
PowerlinefrequencyissetthersttimetheAxisproductisaccessedandcanonlybechangedfromPlainCong(seepage50)
orbyresettingtheproducttofactorydefault.
Selectthepowerlinefrequency(50Hzor60Hz)usedatthelocationoftheAxisproduct.Selectingthewrongfrequencymaycause
imageickeriftheproductisusedinuorescentlightenvironments.
Whenusing50Hzthemaximumframerateislimitedto25fps.
Note
Powerlinefrequencyvariesdependingongeographicregion.TheAmericasusuallyuse60Hzwhereasmostotherpartsof
theworlduse50Hz.Localvariationscouldapply.Alwayscheckwiththelocalauthorities.
Abouttheliveviewwindow
Thecontrolsandlayoutoftheliveviewwindowmayhavebeencustomizedtomeetspecicinstallationrequirementsanduser
preferences.Consequentlysomeoftheexamplesandfunctionsfeaturedheremaydifferfromthosedisplayedinyourownliveview
window.Thefollowingprovidesanoverviewofeachavailablecontrol.
Aboutthecontrolsintheliveviewwindow
ClicktheViewsizebuttonstoshowtheimageinfullsize(rightbutton)ortoscaledowntheimageto
tthebrowserwindow(leftbutton).
SelectastreamprolefortheliveviewwindowfromtheStreamProledrop-downlist.Forinformation
abouthowtocongurestreamprolesseepage18.
9

AXISP3905-RENetworkCamera
Howtoaccesstheproduct
UsetheManualTriggerbuttontotriggeranactionrulefromtheliveviewwindow.Forinformation
abouthowtocongureandenablethebuttonseeAboutthemanualtriggeronpage10.
ClickSnapshottosaveasnapshotofthevideoimage.Thisbuttonisprimarilyintendedforusewhen
theAXISMediaControlviewertoolbarisnotavailable.EnablethisbuttonfromLiveViewCong>
ActionButtons.
Aboutthemanualtrier
TheManualTriggerisusedtotriggeranactionrulefromtheLiveViewpage.Themanualtriggercanforexamplebeusedto
validateactionsduringproductinstallationandconguration.
Tocongurethemanualtrigger:
1.GotoSetup>Events.
2.ClickAddtoaddanewactionrule.
3.FromtheTriggerdrop-downlistselectInputSignal.
4.Fromtheseconddrop-downlistselectManualTrigger.
5.Selectthedesiredactionandconguretheothersettingsasrequired.
FormoreinformationaboutactionrulesseeAbouteventsonpage31.
ToshowthemanualtriggerbuttonsintheLiveViewpage:
1.GotoSetup>LiveViewCong.
2.UnderActionButtonsselectShowmanualtriggerbutton.
AbouttheAXISMediaControlviewertoolbar
TheAXISMediaControlviewertoolbarisavailableinInternetExploreronly.SeeAboutAXIMediaControl(AMC)onpage12for
moreinformation.Thetoolbardisplaysthefollowingbuttons:
ThePlaybuttonconnectstotheAxisproductandstartsplayingamediastream.
TheStopbuttonstopsthemediastream.
TheSnapshotbuttontakesasnapshotofthevideoimage.
ClicktheViewFullScreenbuttonandthevideoimagewilllltheentirescreen.PressESC(Escape)onthecomputer
keyboardtocancelfullscreenview.
TheRecordbuttonisusedtorecordthecurrentvideostreamonyourcomputer.Thelocationwheretherecordingissaved
canbespeciedintheAMCControlPanel.EnablethisbuttonfromLiveViewCong>ViewerSettings.
PTZControls
Note
ThesecontrolsareavailableifdigitalPTZisenabledintheselectedviewareaseeViewAreaonpage20.
10

AXISP3905-RENetworkCamera
Howtoaccesstheproduct
WiththePTZControlQueueenabledthetimeeachuserisincontrolofthePTZsettingsislimited.Clickthebuttonstorequestor
releasecontrolofthePTZcontrols.ThePTZControlQueueissetupunderPTZ>ControlQueue.
ClicktheEmulatejoystickmodebuttonandclickintheimagetomovethecameraviewinthedirectionofthe
mousepointer.
ClicktheCentermodebuttonandclickintheimagetocenterthecameraviewonthatposition.
Thecentermodebuttoncouldalsobeusedtozoominonaspecicarea.Clickintheimageanddragtodrawa
rectanglesurroundingtheareatobemagnied.Tozoomoutrotatethemousewheel.
ToviewaspecicviewareaorpresetpositionselectitfromtheSourcelist.
PanandTiltbars–Usethearrowstopanandtiltthecameravieworclickonapositiononthebartosteerthecameraviewto
thatposition.
Zoombar–Usethearrowstozoominandoutorclickonapositiononthebartozoomtothatposition.
ThePTZcontrolscanbedisabledunderPTZ>Advanced>ControlsseeAboutadvancedPTZsettingsonpage27.
11

AXISP3905-RENetworkCamera
Aboutmediastreams
Aboutmediastreams
TheAxisproductprovidesseveralvideostreamformats.Yourrequirementsandthepropertiesofyournetworkwilldeterminethe
typeyouuse.
TheliveviewwindowintheproductprovidesaccesstoH.264andMotionJPEGvideostreamsandtothelistofavailablestream
proles.Otherapplicationsandclientscanaccessvideostreamsdirectlywithoutgoingviatheliveviewwindow.
AboutH.264format
H.264canwithoutcompromisingimagequalityreducethesizeofadigitalvideolebymorethan80%comparedwiththeMotion
JPEGformatandasmuchas50%morethantheMPEG-4standard.Thismeansthatmuchlessnetworkbandwidthandstoragespace
arerequiredforavideole.Orseenanotherwaymuchhighervideoqualitycanbeachievedforagivenbitrate.
Decidingwhichcombinationofprotocolsandmethodstousedependsonyourviewingrequirementsandonthepropertiesof
yournetwork.TheavailableoptionsinAXISMediaControlare:
UnicastRTPThisunicastmethod(RTPoverUDP)isused
forliveunicastvideoespeciallywhenitis
importanttohaveanup-to-datevideostream
evenifsomeframesaredropped.
RTPoverRTSPThisunicastmethod(RTPtunneledoverRTSP)
isusefulasitisrelativelysimpletocongure
rewallstoallowRTSPtrafc.
RTPoverRTSPoverHTTPThisunicastmethodcanbeusedtotraverse
rewalls.Firewallsarecommonlyconguredto
allowtheHTTPprotocolthusallowingRTPto
betunneled.
Unicastingisusedforvideo-on-demand
transmissionsothatthereisnovideotrafc
onthenetworkuntilaclientconnectsand
requeststhestream.
Notethatthereareamaximumof20
simultaneousunicastconnections.
MulticastRTPThismethod(RTPoverUDP)shouldbeusedforlivemulticastvideo.Thevideostreamisalways
up-to-dateevenifsomeframesaredropped.
Multicastingprovidesthemostefcientusageofbandwidthwhentherearelargenumbersof
clientsviewingsimultaneously.Amulticastcannothoweverpassanetworkrouterunlessthe
routerisconguredtoallowthis.ItisnotpossibletomulticastovertheInternetforexample.
Notealsothatallmulticastviewerscountasoneunicastviewerinthemaximumtotalof20
simultaneousconnections.
AXISMediaControlnegotiateswiththeAxisproducttodeterminethetransportprotocoltouse.Theorderofprioritylistedinthe
AMCControlPanelcanbechangedandtheoptionsdisabledtosuitspecicrequirements.
Note
H.264islicensedtechnology.TheAxisproductincludesoneH.264viewingclientlicense.Installingadditionalunlicensed
copiesoftheclientisprohibited.TopurchaseadditionallicensescontactyourAxisreseller.
AboutMJPEGformat
ThisformatusesstandardJPEGstillimagesforthevideostream.Theseimagesarethendisplayedandupdatedataratesufcient
tocreateastreamthatshowsconstantlyupdatedmotion.
TheMotionJPEGstreamusesconsiderableamountsofbandwidthbutprovidesexcellentimagequalityandaccesstoeveryimage
containedinthestream.TherecommendedmethodofaccessingMotionJPEGlivevideofromtheAxisproductistousetheAXIS
MediaControlinInternetExplorerinWindows.
AboutAXISMediaControl(AMC)
AXISMediaControl(AMC)inInternetExplorerinWindowsistherecommendedmethodofaccessinglivevideofromtheAxisproduct.
12

AXISP3905-RENetworkCamera
Aboutmediastreams
TheAMCControlPanelcanbeusedtocongurevariousvideosettings.PleaseseetheAXISMediaControlUser’sManualformore
information.
TheAMCControlPanelisautomaticallyinstalledonrstuseafterwhichitcanbecongured.OpentheAMCControlPanelfrom:
•WindowsControlPanel(fromtheStartscreenorStartmenu)
•Alternativelyright-clickthevideoimageinInternetExplorerandclickSettings.
Alternativemethodsofaccessinthevideostream
YoucanalsoaccessvideoandimagesfromtheAxisproductinthefollowingways:
•MotionPEGserverpush(ifsupportedbytheclientChromeorFirefoxforexample).ThisoptionmaintainsanopenHTTP
connectiontothebrowserandsendsdataasandwhenrequiredforaslongasrequired.
•StillPEGimagesinabrowser.Enterthepathhttp://<ip>/axis-cgi/jpg/image.cgi
•WindowsMediaPlayer.ThisrequiresAXISMediaControlandtheH.264decodertobeinstalled.Thefollowingpaths
canbeused:
-UnicastviaRTP:axrtpu://<ip>/axis-media/media.amp
-UnicastviaRTSP:axrtsp://<ip>/axis-media/media.amp
-UnicastviaRTSPtunneledviaHTTP:axrtsphttp://<ip>/axis-media/media.amp
-Multicast:axrtpm://<ip>/axis-media/media.amp
•QuickTimeTM.Thefollowingpathscanbeused:
-rtsp://<ip>/axis-media/media.amp
-rtsp://<ip>/axis-media/media.3gp
13

AXISP3905-RENetworkCamera
Aboutmediastreams
Note
•<ip>=IPaddress
•TheAxisproductsupportsQuickTime6.5.1andlater.
•QuickTimemayaddlatencytothevideostream.
•ItmaybepossibletouseotherplayerstoviewtheH.264streamusingthepathsabovealthoughAxisdoesnotguarantee
this.
14

AXISP3905-RENetworkCamera
Howtosetuptheproduct
Howtosetuptheproduct
TheAxisproductcanbeconguredbyuserswithadministratororoperatorrights.Toopentheproduct’ssetuppagesclickSetupin
thetopright-handcorneroftheliveviewwindow.
•Administratorshaveunrestrictedaccesstoallsettings.
•OperatorshaverestrictedaccesstosettingsseeUsersonpage39
Seealsotheonlinehelp.
Howtoperformabasicsetup
BasicSetupprovidesshortcutstothesettingsthatshouldbemadebeforeusingtheAxisproduct:
1.Users.Seepage39.
2.TCP/IP.Seepage41.
3.Date&Time.Seepage41.
4.VideoStream.Seepage16.
TheBasicSetupmenucanbedisabledfromSystemOptions>Security>Users.
15

AXISP3905-RENetworkCamera
Aboutvideosettings
Aboutvideosettings
ItispossibletocongurethefollowingvideofeaturesinyourAxisproduct:
•Videostream.Seepage16.
•Streamproles.Seepage18.
•ONVIFMediaProles.Seepage18.
•Camerasettings.Seepage18.
•Viewareas.Seepage20.
•Overlayimage.Seepage21.
•Privacymask.Seepage23.
Howtosetupvideostreams
Tosetuptheproduct’svideostreamsgotoVideo>VideoStream.
Thevideostreamsettingsaredividedintothefollowingtabs:
•Image.Seepage16.
•H.264.Seepage17.
•MJPEG.Seepage18.
Aboutthepixelcounter
Thepixelcountershowsthenumberofpixelsinanareaoftheimage.Thepixelcounterisusefulinsituationswherethereis
aspecicsizerequirementforexampleinfacerecognition.
Thepixelcountercanbeused:
•WhensettingupavideostreamseeHowtosetupvideostreamsonpage16.UnderPreviewclickOpenandselectthe
Showpixelcounteroptiontoenabletherectangleintheimage.Usethemousetomoveandresizetherectangleorenter
thenumberofpixelsintheWidthandHeighteldsandclickApply.
•WhenaccessingtheLiveViewpageinInternetExplorerwithAXISMediaControl(AMC)inWindows.Right-clickinthe
imageandselectPixelcounter.Usethemousetomoveandresizetherectangle.
Imae
ThedefaultimagesettingscanbeconguredunderVideo>VideoStream.SelecttheImagetab.
Thefollowingsettingsareavailable:
•Resolution.Selectthedefaultresolution.
•Compression.Thecompressionlevelaffectstheimagequalitybandwidthandlesizeofsavedimages;thelowerthe
compressionthehighertheimagequalitywithhigherbandwidthrequirementsandlargerlesizes.
•Mirrorimage.Ifrequiredtheimagecanbemirrored.
•Rotateimage.Ifrequiredtheimagecanberotated.
16

AXISP3905-RENetworkCamera
Aboutvideosettings
•Maximumframerate.ToavoidbandwidthproblemstheframerateallowedtoeachviewercanbeLimitedtoaxed
amount.AlternativelytheframeratecanbesetasUnlimitedwhichmeanstheAxisproductalwaysdeliversthehighest
frameratepossibleunderthecurrentconditions.
•Overlaysettings.SeeAboutoverlaytextonpage21.
ClickSavetoapplythenewsettings.
AboutH.264
H.264alsoknownasMPEG-4Part10/AVCisavideocompressionstandardthatprovideshighqualityvideostreamsatlowbitrates.
AnH.264videostreamconsistsofdifferenttypesofframessuchasI-framesandP-frames.AnI-frameisacompleteimagewhereas
P-framesonlycontainthedifferencesfrompreviousframes.
AboutGOPlenth
AGroupofPictures(GOP)containsoneI-framefollowedbyanumberofP-frames.TheGOPlengthisthenumberofframes
betweentwoI-frames.
EqualvaluesforGOPlengthandframerateresultinoneGOPpersecond.AhigherGOPlengthvalueresultsinmoresmall-sized
P-framesandlessbig-sizedI-frameswhilekeepingthesameframerate.InotherwordsahighGOP-lengthvaluesavesbandwidth
butthevideoqualitymaydecrease.AlowGOP-lengthvalueincreasesthevideoqualitybutrequiresmorebandwidth.
AboutH.264proles
TheAxisproductsupportsthefollowingH.264prole(s):
•Baseline:UsetheBaselineproleiftheclientdoesnotsupportCABACentropycoding.
•Main:TheMainproleusesCABACandprovidesabettercompressionwithmaintainedvideoquality.Itrequiresalarger
amountofprocessingpowertodecodethantheBaselineprole.
Aboutbitratecontrol
Bitratecontrolisusefultomakesurethevideostreamingdoesnottakeuptoomuchbandwidth.
Aboutvariablebitrate
Variablebitrate(VBR)adjuststhebitrateaccordingtotheimagecomplexity.WhentheactivityinthesceneincreasesVBRadjusts
thebitrateaccordingtothecomplexityusingupmorebandwidthforincreasedactivityinthesceneandlessforlowersceneactivity.
Variablebitrateissuitableifthereisasurplusinbandwidthwheretheincreasedbitratemaynotbeanissue.
Aboutmaximumbitrate
IfyouhavelimitedbandwidthwerecommendMaximumbitrate(MBR).MBRallowsyoutosetatargetbitratetocontrolthe
bandwidthconsumption.Thetargetvaluelimitsthebitratebutitmaintainsaexibilitytobeabletoprioritizeacontinuousvideo
stream.Consequentlytheframeratemightneedtogodownandtheimagequalitymightdecrease.Topartlycompensateforthis
youcanselectwhichvariableshallbeprioritized.Notsettingaprioritymeansthatframerateandimagequalityareequallyaffected.
HowtosetanH.264prole
1.TochangethesettingsforallH.264streamsthatdonotuseastreamprolegotoVideo>VideoStream>H.264.
2.ToincreaseordecreasethenumberofframesperGOPsettheGOPlength.
3.SelectoneoftheH.264proles.
4.Selectoneofthefollowing:
-Variablebitrate
17

AXISP3905-RENetworkCamera
Aboutvideosettings
-Maximumbitrate
5.IfyouselectMaximumbitrateselectwhichvariabletoprioritizeinthePrioritydrop-downlist.
6.ClickSave.
Howtoincludecurrentbitrateinatextoverlay
1.GotoVideo>VideoStream>OverlaySettings.
2.IntheIncludetexteldenter#b.
3.ClickSave.
AboutMJPEGsettins
Sometimestheimagesizeislargeduetolowlightorcomplexscenery.Adjustingthemaximumframesizehelpstocontrolthe
bandwidthandstorageusedbytheMotionJPEGvideostreaminthesesituations.SettingtheframesizetotheDefaultsetting
providesconsistentlygoodimagequalityattheexpenseofincreasedbandwidthandstorageusageinlowlight.Limitingtheframe
sizeoptimizesbandwidthandstorageusagebutmayresultinpoorimagequality.
Aboutstreamproles
Astreamproleisasetofpredenedstreamsettingsincludingresolutioncompressionframerateandoverlaysettings.Stream
prolescanbeused:
•Whensettinguprecordingusingactionrules.SeeAbouteventsonpage31.
•Whensettingupcontinuousrecording.SeeAboutcontinuousrecordingonpage37.
•IntheLiveViewpage–selectthestreamprolefromtheStreamproledrop-downlist.
TocreateanewproleormodifyanexistingprolegotoSetup>Video>StreamProles.
ToselectadefaultstreamprolefortheLiveViewpagegotoSetup>LiveViewCong.
AboutONVIFmediaproles
AnONVIFmediaproleconsistsofasetofcongurationsthatcanbeusedtochangemediastreamsettings.ONVIFmediaproles
canbeusedbyaclienttoconguremediastreamproperties.
TheONVIFMediaProlespagelistsallpreconguredproles.Theseprolesareincludedintheproductforquicksetup.Youcan
addmodifyorremoveONVIFmediaprolesfromthispage.
Aboutcamerasettins
TheVideo>CameraSettingspageprovidesaccesstoadvancedimagesettingsfortheAxisproduct.
Aboutimaeappearance
TochangeImageAppearancegotothemenusunderSetup>Video>CameraSettings.
IncreasingtheColorlevelincreasesthecolorsaturation.Thevalue100producesmaximumcolorsaturationandthevalue0
resultsinablackandwhiteimage.
TheimageBrightnesscanbeadjustedintherange0–100whereahighervalueproducesabrighterimage.
IncreasingtheSharpnesscanincreasebandwidthusage.Asharperimagemightincreaseimagenoiseespeciallyinlowlight
conditions.Alowersettingreducesimagenoisebutthewholeimagewillappearlesssharp.
18

AXISP3905-RENetworkCamera
Aboutvideosettings
TheContrastchangestherelativedifferencebetweenlightanddark.Itcanbeadjustedusingtheslidebar.
Aboutwhitebalance
TochangethissettinggotoSetup>Video>CameraSettings
Whitebalanceisusedtomakecolorsintheimageappearthesameregardlessofthecolortemperatureofthelightsource.TheAxis
productcanbesettoautomaticallyidentifythelightsourceandcompensateforitscolor.Alternativelyselectthetypeoflight
sourcefromthedrop-downlist.Foradescriptionofeachavailablesettingseetheonlinehelp.
ThewhitebalancewindowisenabledfortheAutomaticandAutomaticoutdooroptionsthatappearintheWhitebalancedrop-down
list.Selectoneoftheoptionsfromthedrop-downlisttosetthewhitebalancewindowproperties.SelectAutomatictousethe
defaultsettingsfortheAutomaticandAutomaticoutdooroptions(intheWhitebalancedrop-downlist).SelectCustomtomanually
setareferencewindowforwhitebalanceintheviewarea.
WideDynamicRane
Widedynamicrange(DynamicContrast)canimprovetheexposurewhenthereisaconsiderablecontrastbetweenlightanddark
areasintheimage.EnableWDRinintensebacklightconditions.DisableWDRinlowlightconditionsforoptimalexposure.
Note
Thissettingisonlypossiblewhenusingautomaticexposurecontrol.
TrafcLihtmode
Thismodewilldecreasetheexposuresothattrafclightsandotherbrightlightsourceswillnotsaturatewheninviewatnight.
Inthismodeitispossibletodistinguishthecolorofthetrafclightsatanysurroundinglightlevel.Thismodeisalsofavorable
forlicenseplaterecognition.
Note
Thedecreaseinexposurewillmakethewholeimagedarkerduringconditionsabove.
ThissettingwilldisabletheExposureSettingsforbestresults.
ExposureSettins
Exposureistheamountoflightthecamera’ssensorcapturesforascene.Toomuchlightresultsinawashedoutimageandtoo
littlelightresultsinadarkimage.
Exposurevalue-UsetheExposurevalueslidertoadjusttheoverallbrightnessoftheimage.
Exposurecontrol-Selectasuitableoptiontocontrolexposure.
FormostscenestheAutomaticoptionwillprovidethebestresults.Theshutterspeedisautomaticallysettoproduceoptimum
imagequality.Fluorescentlampsorotherlightsourcescansometimescauseickeringintheimage.Toreduceickerintheimage
selecttheFlickeroptionthatmatchesthepowerlinefrequency.
TheHoldcurrentoptionlocksthecurrentexposuresettings.
Maxexposuretime-Shutterspeedalsocalled‘exposuretime’standsforthelengthoftimethecamerashutterisopenthereby
exposingthecamerasensortolight.Ifshutterspeedisfastitcanfreezeactioneffectively.Ifshutterspeedisslowitcancause
movingobjectstoappearblurred.Decreasingtheexposuretimewillreducemotionblur.
EnableBacklightcompensation-Enablethisoptionifabrightspotoflightsuchasalightbulbcausesotherareasintheimage
toappeartoodark.
Exposurezones-Thissettingdetermineswhichpartoftheimageisusedtocalculatetheexposure.FormostsituationstheAuto
settingcanbeused.
YoucanselectapredenedareabydeningIncludeandExcludewindowswithintheimage.Excludewindowsexcludeareasthatare
toobrightordarkandIncludewindowsincludeareasinthescenethathavebetterlightingwhichwillcontributetotheexposuredata.
TheremustbeatleastoneIncludewindow.TherecanbeatotaloftenIncludeandExcludewindowstotailortheexposurezone.
NotethatanExcludewindowiseffectiveonlywhenplacedinsideanincludewindow.
19

AXISP3905-RENetworkCamera
Aboutvideosettings
Tip:IfanareaisextremelybrightdrawanIncludewindowtocoverthewholeareaanddeneExcludewindowswithinitto
blockoutthebrightareas.
Shutter&Gain
Theshutterandgainsettingsaffecttheamountofmotionblurandnoiseintheimage.Toadapttodifferentlightingavailable
storagespaceandbandwidthitisoftennecessarytoprioritizeeitherlowmotionblurorlownoise.TheAxisproductallowsdifferent
prioritizationinnormallightandinlowlight.
Shutterspeedisrelatedtotheamountoftimetheshutterisopenedandismeasuredinseconds(s).Aslowshutterspeedallows
morelighttoreachthesensorandcanhelpproduceabrighterimageinlowlightsituations.Ontheotherhandaslowshutter
speedcancausemovingobjectstoappearblurry.
SetShutterto:
•Autotosettheshutterspeedautomatically.IfrequireduseMaxshuttertolimittheshutterspeedtopreventtheframe
ratefrombeingreduced.
Forexampletoget30fpssetMaxshutterto1/30.
•Fixedtouseaxedshutterspeed.
Gainmeasuredindecibel(dB)istheamountofamplicationappliedtotheimage.Ahighgainmayprovideabetterimageinlow
lightsituationsbutwillincreasetheamountofimagenoise.
SetGainto:
•Autotosetthegainautomatically.IfrequireduseMaxgaintolimittheappliedgain.
•Fixedtouseaxedgain.
Example
Ifstoragespaceorbandwidthislimitedtryusingalowergain.Thiswillreduceimagenoiseandproducesmallerimageles.
ViewArea
Aviewareaisacroppedpartofthefullview.EachviewareaistreatedasavideosourceinLiveViewandhasitsownvideo
streamandPTZsettings.
Whensettingupaviewareaitisrecommendedthatthevideostreamresolutionisthesamesizeasorsmallerthantheviewarea
size.Settingthevideostreamresolutionlargerthantheviewareasizeimpliesdigitallyscaledupvideoaftersensorcapture
requiringmorebandwidthwithoutaddingimageinformation.
ToenablegotoVideo>CameraSettingsandselectEnableViewAreas.
Toaddanewviewarea:
1.GotoVideo>ViewArea.
2.ClickAdd.
3.ThenewviewareaappearsunderSelectedviewarea.EnteradescriptivenameintheNameeld.
4.SelectanAspectratioandaVideostreamresolution.
5.Anewviewareacoversthewholeimage.Usethemousetomoveandresizetheviewarea.
6.SelectEnablePTZtoenabledigitalPTZfortheviewarea.
7.ClickSavetosavethesettings.
Tomodifyaviewareaselecttheviewareainthelistandmodifythesettingsasrequired.ClickSave.
20
