Tema Telecomunicazioni AD615/SIP User manual

AD615/SIP
Analog/Digital Encoder for Multicast
Audio Streaming with VoIP SIP protocols integrated
Audio Over IP Network
PRODUCT MANUAL
Version HW 1.0 - Version SW 1.10
Revision
Date
Revision reason
Pr
epared
Checked
/Approv
ed
0 07/01/2021 First edition MM, DP DP, FL
TEMA TELECOMUNICAZIONI
“IP COMMUNICATION AND SECURITY COMPANY”
WWW.TEMATLC.IT
Products for VoIP SIP LAN networking Communications, Paging Amplifiers Systems and
Audio Applications. Zone Announcements, Night Ringer, Multicast general call,
Background music, Standard SIP call or Emergency call, SD memory with pre-recorded
messages, Relays for LAN drives.

TEMA TELECOMUNICAZIONI IP PoE Multicast Encoder AD615/SIP
MAS-AD615SIP-REV00EN Page 2 of 28
We, TEMA TELECOMUNICAZIONI SRL Via C. Girardengo, 1/4 - 20161 MILANO
declare under our sole responsibility that the product:
Product name Encoder Multicast IP PoE
Trade name TEMA TELECOMUNICAZIONI Srl
Type or model AD615/SIP
and accessories --
to which this declaration relates is in conformity with the essential requirements and other
relevant requirements of the R&TTE Directive ( 1999/5/EC, 2006/95/EC, 2004/108/EC ).
The product is in conformity with the followings standards and/or other normative documents:
HEALT & SAFETY EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2011
EMC EN 55022:2010, EN 55024:2010, EN 61000-3-2:2006
EN 61000-3-3 :2008
MILANO, 07 January 2021 TEMA TELECOMUNICAZIONI SRL
D. Pontillo
I. IMPORTANT INFORMATIONS REGARDING THE RECOVERY AND RECYCLING OF THIS
ELECTRONIC DEVICE
DICHIARAZIONE DI CONFORMITÀ CE
DECLARATION OF CONFORMITY CE
UNI EN ISO 9001:2015
TEMA TELECOMUNICAZIONI
isa certified company
The crossed
-
out wheeled bin symbol below indicates that this electronic equipment is
intended to be disposed in a separate collection and not in an unsorted municipal
waste, in order to provide for the treatment of WEEE (Waste Electrical and Electronic
Equipment) using best available recovery and recycling techniques. Specific treatment
for WEEE is indispensable in order to avoid the dispersion of pollutants and other
hazardous substances into the waste stream, while recycling leads to reduction of
disposal of waste and the negative impacts on environment and human health. That is,
priority is given to reuse of WEEE in its components, subassemblies and
consumables. As the final holder, the user has an important role in contributing to
reuse, recycling and other forms of recovery of WEEE and is responsible to return this
waste in the collection facilities set up by EC Member States and to fulfill other duties
in compliance with Directive 2002/96/EC and local laws.

TEMA TELECOMUNICAZIONI IP PoE Multicast Encoder AD615/SIP
MAS-AD615SIP-REV00EN Page 3 of 28
RECOMMENDATIONS
1. It is recommended to read this entire manual before proceeding to the installation of the device.
2. The installation and commissioning of the device can only be performed by specialized technicians.
3. The device is accurately manufactured and tested. In any case, the product is not recommended for use
where an error of operations can cause property damage and/or injury to persons.
4. It is expressly not recommended maintenance inside the device which must be carried out by Tema
Telecomunicazioni, the removal of the closures will invalidate the warranty and makes accessible internal
parts with risk of electric shock.
5. Tema Telecomunicazioni accepts no responsibility for damage to property and/or persons resulting from
incorrect use of the equipment or by procedures that do not comply with the instructions in this manual.
Tema Telecomunicazioni reserves the right to make modification to the technical and functional
specifications at any time and without any notice.
6. Products powered via PoE (Power over Ethernet) may only be connected with cables coming from the
internal network company (inside the building), are not allowed connections LAN cables coming from outside
the building.
7. Use for this device only and exclusively original spare parts and consumables supplied by Tema
Telecomunicazioni. The company is not responsible for damage caused by the use of materials not supplied
by the same.
8. Do not expose the unit to direct sunlight, protect from heat, dust, humidity and chemicals.
9. Tema Telecomunicazioni reserves the right to vary the product characteristics for improvement without prior
notice. Check the WWW.TEMATLC.IT website for any updates to the latest firmware, manuals, and
technical documentation.
10. This document is property of Tema Telecomunicazioni, It is forbidden any duplication and reproduction, even
partial, as well as storage on any medium without written permission of Tema Telecomunicazioni.
This symbol in the descriptions indicates a general warning or a damage danger
to equipment or people.
This symbol in the descriptions indicates useful information or a suggestion for
the optimization of the device functionality.

TEMA TELECOMUNICAZIONI IP PoE Multicast Encoder AD615/SIP
MAS-AD615SIP-REV00EN Page 4 of 28
1. PRESENTATION ........................................................................................................................................ 5
2. FEATURES.................................................................................................................................................. 7
3. PACKING LIST ........................................................................................................................................... 8
4. TECHNICAL SPECIFICATIONS ............................................................................................................... 8
5. OPERATION................................................................................................................................................ 9
5.1. S IMPLE APPLICATION WITH AD615/SIP E NCODER .................................................................................................9
5.2. A PPLICATION OF THE E NCODER AD615/S WITH IP-PBX........................................................................................9
5.3. E XTENDED AD615/SIP E NCODER A PPLICATION .................................................................................................10
6. OPERATING MODES............................................................................................................................... 11
6.1. M ULTICAST A UDIO S TREAMING .........................................................................................................................11
7. INSTALLATION ........................................................................................................................................ 12
7.1. M OUNTING AND S YSTEM POSITIONING ...............................................................................................................12
7.2. C ONNECTION ..................................................................................................................................................12
8. PROGRAMMING ...................................................................................................................................... 14
8.1. P REPARATION FOR THE SYSTEM PARAMETERS PROGRAMMING ..............................................................................14
8.2. A CCESS TO PROGRAMMING ...............................................................................................................................16
8.3. N ETWORK PARAMETERS ...................................................................................................................................17
8.4. SIP P ARAMETERS ...........................................................................................................................................18
8.5. A UDIO CHANNELS ............................................................................................................................................19
8.6. M ESSAGES .....................................................................................................................................................20
8.7. A UTOMATIC ANNOUNCEMENTS ..........................................................................................................................20
9. MAINTENANCE........................................................................................................................................ 22
9.1. S YSTEM ..........................................................................................................................................................22
9.2. L OGIN CREDENTIALS ........................................................................................................................................23
9.3. D IAGNOSTIC LOGS ...........................................................................................................................................23
10. APPENDIXES............................................................................................................................................ 24
10.1. A PPENDX 1: U SE OF THE VLC M EDIA P LAYER SOFTWARE AS AN AUDIO FILES PLAYER ........................................24
10.2. A PPENDIX 2: U SE OF THE AUDACITY SOFTWARE FOR AUDIO FILES RECORDING ...............................................25
10.3. A PPENDIX 3: S IGNALS OF RJ45 MICROPHONE INPUT ......................................................................................26
10.4. A PPENDIX 3: C ABLING OF A RJ45 NETWORK CABLE ACCORDING TO THE STANDARD EIA568B ............................27
INDICE PAGINA

TEMA TELECOMUNICAZIONI IP PoE Multicast Encoder AD615/SIP
MAS-AD615SIP-REV00EN Page 5 of 28
1. PRESENTATION
AD615/SIP Digital IP Encoder with Integrated PoE power supply converts an analog audio signal from any external
source into a digital audio streaming in Multicast channels for audio signal distribution via LAN. AD615/SIP is ideal
for background music streaming on the LAN in any environment (offices, factories, public places and outdoors) with
the ability to make announcements in the same environments.
To the 3.5mm jack port of the device it is possible to connect FM radio tuners, CD-DVD players, MP3 players,
Smartphones, iPods, Tablets, PC Sound Blaster sound card outputs etc. to convert analog audio to a digital audio
streaming.
AD615/SIP also has an RJ45 socket with proprietary connections for an external microphone or a microphone base
(only TEMA models) with which it is possible to launch Multicast general call on all AD600 series amplifiers and IP
speakers connected to the network.
Differences with the basic model AD615/S
The audio to be streamed can also be sent via telephone (the user makes a phone call to the device and chooses
which multicast channel to send his message to). In fact, the difference between the basic model lies in the
possibility of AD615/SIP to be able to register on an IP-PBX or SIP Server and manage the VoIP telephone
communication protocol. Once registered on an IPPBX with its own account, the AD615/SIP answers the calls and
allows the caller to launch an announcement by selecting one of the 16 available Multicast channels, to
individual IP speakers, to groups, or to all in general call. This gives the advantage of registering only one third-
party account on the PBX without the need to register all the IP speakers installed on the network. Another
advantage: it is possible to launch announcements from any telephone on the internal network and of any
technology, including analog telephones, IP telephones, Cordless Dect, Softphones, etc.
Audio Streaming Codec
AD615/SIP offers the possibility to choose the most appropriate codec according to the audio quality and the
required LAN bandwidth. The following codecs are available: G711 (a/μ-law), G722, 16kHz/24kHz/32kHz
Proprietary Linear for the highest audio quality. In the case of phone stream, the G711 codec is always used.
Multicast Streaming Audio for music and announcements
AD615/SIP can route the analog audio to its input to 2 multicast channels selectable by the front lever .
In the case of stream via telephone, however, the user has 16 audio channels to choose from (or you can force the
use of a particular channel for telephone calls in the configuration).
Programming
Programming is done remotely thanks to the integrated web server with security password. Total remote
management for programming, configuring, replacing the firmware release, configuration backup and restore,
system reboot.
Power Supply
AD615/SIP can be powered directly on the network LAN cable from a standard 803.af PoE injector. If the PoE
power is unavailable, it is posssible to power AD615/SIP with a 230Vac/12Vdc-1,0A power adapter (for example
the TEMA model AA-39DL plug-in, the model AA-39D1A for DIN rail, the model AA-39P4 Injector PoE). The
external power supply is NOT included.

TEMA TELECOMUNICAZIONI IP PoE Multicast Encoder AD615/SIP
MAS-AD615SIP-REV00EN Page 6 of 28
VoIP SIP Amplifiers-Speakers Products and Accessories of the AD600 “SipComStage” series
AD610
2X2W PoE IP-
SIP Amplifier Module,
External Amplifier Adapter with Sound Isolation
Transformer. Directly pilot external power
amplifiers or 8 Ohm external passive speakers.
AD611
IP-
SIP PoE 10W Amplifier Module
(2X5W). Directly pilot 8 Ohm external passive
speakers.
AD633
IP-SIP speaker 12W PoE
open-to-ceiling version.
AD635
IP-
SIP PoE 12W speaker for wall
mounting with the
possibility of integrating a PoE
injector adapter.
AD333/12XTP
Passive 8 Ohm 12W
speaker with anti-
flame cover (AD333/12TP
without cover), internal transformer for 100V
audio line. Ideal for connecting to AD610-611-
612
or as 2nd speaker to the AD63x series IP-
SIP
speakers.
AD335/06TP
Passive 8 Ohm 6W speaker
with 100V audio line transformer. Ideal for
connecting to AD610-611-
612 or as 2nd speaker
to the AD63x series IP-SIP speakers.
AD330/25T
Passive horn speaker 25W 8
ohm with transformer for 100V audio line. Ideal
for connecting to the AD610-611-
612 modules or
as 2nd speaker for AD63x IP-SIP speakers.
AD330/
xx
Are available Speakers of
different pow
er, Horns and Loudspeakers
for flush and ceiling mount.
AA
-
39DL
Plug Power Supply 220Vac/12Vdc-1,0A.
AA
-
39D1A
DIN Power Supply 220Vac/15Vdc-1,0A.
A
A
-
39P4
PoE injector 230Vac/48Vdc 0,5A.
AA
-
39E3 /
-
E6V
DIN Power Supplies 220Vac/24Vdc-1,5A
220Vac/24Vdc-2,5A.
AA
-
36
Protected Power Relay
Actuator 250Vac/16A/4KVA, command in
AC/DC 12V/24V, 1 contact, Led, contacts
protected by electric arcs.
Ideal for
driving loads up to 4.000W.
AD612
IP-SIP PoE 40W
(2x20W) Amplifier
Module when powered with an external power
supply.
Directly pilot 8 Ohm external passive
speakers.
AA
-
699
xxx
Flash lights with Xeon
l
amp or high brightness LEDs. Ideal to be
controlled by the relay of the IP-
SIP
speakers of the AD630 series or by the
IP-
SIP amplifier AD610, AD611, AD612
modules, with a call in progress add a
light signal to the acoustic signal.
AD320/30
PA 100V audio line
transformer 30W, constant voltage, high
efficiency toroidal type
with low magnetic
flux leakage.
AD32
Isolation transformer, balanced,
mixer, attenuator, audio signal filter, low
impedance ou
tput. Ideal for decoupling
devices of audio sources to other
amplifiers to eliminate noises.
AD615/S
Audio Encoder Module from
analog to digital on LAN Network in
Multicast/Broadcast Channels.
AD301R
30W analog amplifier,
2 channels, Volume-High-Low +/-
12dB
controls
AD630
IP-
SIP PoE 25W Horn Speaker
with 40W internal amplifier (2x20W) IP65
protection.
AD634
IP-
SIP 20W PoE Sound Projector
Speaker metal version
AD696BM
Desktop microphone
base with 7 selectable Din-don
AD696B
Simple Desktop microphone
base (NO Din-don)
*** PRODUCT LIST MAY BE INC
OMPLETE PLEASE REFER TO TEMA WEB SITE FOR NEWS ***

TEMA TELECOMUNICAZIONI IP PoE Multicast Encoder AD615/SIP
MAS-AD615SIP-REV00EN Page 7 of 28
2. FEATURES
• Analog/Digital Converter Encoder Function for 2 Channel Multicast Audio Streaming (Alternative)
• Audio stream function from VoIP phone call to 1 of 16 Multicast channels available
• Music channel input from external analog player with 3,5mm jack
• Microphone/microphone base input, RJ45 plug with proprietary connections
• Microphone volume adjustment
• 3-position switch lever to enable/disable LAN sending of digitized signal
• Selectable codecs: G711, G722, Linear 16kHz, 24kHz, 32kHz
• Power supply via PoE (Power over Ethernet) or external power supply, at the same time
• Programming via the Web Interface with password protection
• Possibility of software / firmware update via LAN
• Integration with the local LAN, 100BaseT Ethernet LAN port with RJ45 connector
• Integrated 802.af PoE, a single UTP cable for connection
• Extremely compact dimensions 74x58x25 mm
• Wall mounting, table/shelf and DIN rail
• Possibility of sending RTP streaming audio in MULTICAST, for paging audio announcements and music
• Audio streaming with high quality codecs
AD615/SIP - views and dimensions

TEMA TELECOMUNICAZIONI IP PoE Multicast Encoder AD615/SIP
MAS-AD615SIP-REV00EN Page 8 of 28
3. PACKING LIST
The systems are supplied with the parts included in the following list:
• One AD615/SIP device
• System documentation manual (this one)
• A CD-ROM with complete documentation
• UTP Patch Cord LAN cable 1.5 meters
• DIN rail kit (plastic adapter, 2 screws and 2 washers for fixing the unit, DIN bracket, 2 dowels and screws)
• 4 self-adhesive foots for table or shelf resting
• 1 cable for audio stereo input audio jack 3,5mm / 2 RCA male
• 1 cable for audio stereo input audio jack 3,5mm / stereo jack 3,5mm
4. TECHNICAL SPECIFICATIONS
LAN
TCP/IP Network 10/100BaseTx
Connection
SIP Server (IP
-
PBX) o
r
P2P (Peer To Peer)
Protocols
SIP 2.0,
RFC 3261
A
udio communication
Monodirectional
, from
AD615/S to receiver devices
Bandwidth
80Hz
–
20k
Hz
RTP Multicast audio Streaming
G711µ, G711a, G722, L16 from 16 to 44 kHz
External audio input
Stereo 3.5 mm stereo jack connector. Isolation via inte
rnal
system transformer, maximum signal level/impedance of
2Vpp/600 Ohm.
Microphone input
Proprietary connector, RJ45. Electret microphone with power
supplied from AD615/SIP
Power Supply
PoE, PoE Injector and/or
external
Ac/Dc
power supply
PoE
802.3af class
0 12,95W
External Power Supply
(Op
t
.)
230Vac/12
-
24Vdc
-
1A
T
echnology
IMX25 400MHz
microprocessor
Memory
256MB Ram, Micro
-
SD Flash 2GB
Program
ming
practical Web interface and password
Installation
wall, table, standard DIN rail
Storage temperature
from
-
20°
to
+65°C
Operating temperature
from
-
20° to
+55°C
Relative humidity
95%
non
-
condensing
Dimensions
74x58x25mm
Weight
200gr
W
arrant
y
2
years, possibility of extension (
O
ption)
Compatibility
CE, ROHS

TEMA TELECOMUNICAZIONI IP PoE Multicast Encoder AD615/SIP
MAS-AD615SIP-REV00EN Page 9 of 28
5. OPERATION
The device allows the sound broadcast in "streaming" Multicast. RTP audio to be sent over the network is taken
from the analog inputs of the system (Jack 3.5mm and proprietary microphone RJ45 socket) and sent to the LAN.
There is therefore a dedicated input for ambient music streaming and an input for a microphone.
In the Multicast mode, multiple remote devices connected to the same LAN where AD615/SIP is connected can
communicate simultaneously the same transmitted audio content, useful for launch pre-recorded announcements
or background music. Once programmed, in stand-by, the system waits for drives.
AD615/SIP will send the analog audio present at its inputs to the two multicast channels selectable from the front
lever. With the lever in the center position, the device does not send anything. By activating the lever in the stable
position, the audio provided on its input jack (typically ambient music) will be transmitted, continuous transmission.
By moving the lever to the momentary position, however, the audio received directly from the microphone
connected to the system on the proprietary RJ45 connector (eg, short operator announcements) will be transmitted.
With the optional microphone base, the operator who has to launch warning messages will operate directly on the
table microphone base and no longer by the AD615/SIP system lever. The microphone output volume is easily
adjustable with a trimmer located on the left side of the AD615/SIP (to better suit the various types of electret
microphones).
It is also possible to call the device via a telephone. Upon answering, the device emits 2 short tones followed
by the number of the multicast channel to be used (from 01 to 16). If desired, during the configuration phase you
can set which channel number to associate with the phone call (the invitation tones to select will not be emitted).
5.1. Simple application with AD615/SIP Encoder
5.2. Application of the Encoder AD615/S with IP-PBX
LAN
NETWORK
Microphone
Encoder
Multicast
AD615/S
IP
Audio source
Radio, Compact Disk,
iPod, PC, etc…
Microphone base
AD696/BM
AD635
IP-SIP Speaker bidirectional
terminal 2 6W
Other
AD600 series
SipComStage
terminals
SIP Phone wi
th Multicast function keys for
uni
directional or bidirectional P2P Peer to Peer
calls (eg GXP2130/2140)
LAN
NETWORK
Microphone base
IP PBX
AD61
1
IP-SIP Amplifier terminal
unidirectional 2 6W with
passive loudspeakers
AD635
IP-SIP Speaker bidirectional
terminal 2 6W
Mic
rophone
Audio source
Radio, Compact Disk,
iPod, PC, etc…
Other
AD600 series
SipComStage
terminals
SIP Phone with Multicast function keys for
uni
directional or bidirectional P2P Peer to
Peer calls (eg GXP2130/2140)
Encoder
Multicast
AD615/S

TEMA TELECOMUNICAZIONI IP PoE Multicast Encoder AD615/SIP
MAS-AD615SIP-REV00EN Page 10 of 28
5.3. Extended AD615/SIP Encoder Application
The picture below shows a more complete scenario of possible realization of a plant.
Starting from a musical sound source like a CD player or other, the analog signal enters the audio input jack of the
AD615/SIP (the one used for the ambient music broadcast). The signal must be of "line" level like a typical output
of a non-amplified stereo player. The volume is adjusted in the external music source.
WARNING: do not connect to this input outputs from amplifier equipment or devices that directly pilot a speaker,
the levels would not be adequate for the correct operation of the system and you may get poor quality audio quality
or you can damage the device.
By moving the system lever from the center (no transmission) to the top position, AD615/SIP begins to encode the
audio from the jack input and transmit it to one of the selected channels for LAN broadcast.
At the RJ45 proprietary input (the one used to connect a microphone base), is taken instead the audio of an
electret microphone, to be used for the transmission of announcements by an operator. The microphone is
powered directly from AD615/SIP (note that it is not a Phantom power, suitable for commercially available
microphones, then it is necessary to have the accessories provided by Tema for generating announcements
messages).
To broadcast the message (which AD615/SIP will send on the second address/channel that has priority over
music) it is necessary to move the system lever down and keep it in this position for the duration of the
announcement. With the microphone base, instead, use the suitable control buttons.
The various AD600 systems connected to the network and set to receive the streaming audio encoded by
AD615/SIP will reproduce the sound from the sources on the various loudspeakers set up in the room to be
sonorized.
LAN
NETWORK
3 positions lever for
enabling audio sources
and microphone with
signaling LED
12Vdc/ac Power Supply
(not necessary if the
connected Switch is PoE)
AD615/S
IP
Network
Encoder
A
nal
o
g
audio signal
FM radio tuner
Compact Disk Player
M
p3 player
or iPOD for
playlist and
Web Radio
PC with Sound Blaster card audio
output. It can be used with VLC as
second encoder on a different
Multicast channel
LAN
LAN PoE
AD611
IP Amplifier
2 x 6W
AD633C
IP Speaker 10W
AD635
IP Speaker 10W
AD630
IP Horn 25W
SIP phone for zone
announcements or
general call on a priority
Multicast channel
AD612
IP Amplifier
2 x 20W
Audio
AD610
Audio Decoder
IP Interface
2 x 2W
E isting PA
Amplifier
AD696/
BM
Microphone Base
LED MIC ON LED AUDIO ON
(red) (green)

TEMA TELECOMUNICAZIONI IP PoE Multicast Encoder AD615/SIP
MAS-AD615SIP-REV00EN Page 11 of 28
6. OPERATING MODES
6.1. Multicast Audio Streaming
In a LAN network, the Multicast term indicates the possibility to distribute an information like data, audio or video, to
a group of IP terminals of the Ethernet network. For Multicast are used class D IP addresses and they range from
224.x.x.x to 239.x.x.x. In our case AD615/SIP is able to transmit multicast audio starting from its analog inputs.
The audio can be generated from a PC software application (for example VLC) or directly from a CD or tape player.
It is possible to program up to 16 audio receive addresses in the network terminals (AD6xx), each with its own
priority and its playback volume, so that the same terminal, if it is already playing audio (eg music) can be
interrupted by a higher priority stream (for example an announcement) and with a different volume (typically an
announcement must be played at a higher volume than background music). The audio supported by this mode is in
the G.711 format (aLaw or μLaw), G722 or linear high quality 16 bit (proprietary format, diffused through the AD615
device or an Intercom AA-540).
L’audio diffuso in streaming è utile per la generazione di messaggi vocali di annuncio, modalità detta anche
“Paging”. Ovviamente lo streaming è monodirezionale, nel senso che il flusso audio viene inviato dalla sorgente
alla destinazione ma non viceversa. L’audio in streaming può essere ricevuto da più terminali AD600
contemporaneamente (programmati con lo stesso indirizzo di Multicast in ricezione). With AD615/SIP it is
possible to program up to 16 multicast transmission streaming addresses (identifiable as distinct audio
channels). The first two are linked to the analog input and the position of the lever, while all 16 (including also the
first 2) can be addressed via a normal SIP VoIP call (the user chooses in post-selection which audio channel to
use).
On receiving devices, the fact that it is possible to assign a priority level to each address (channel), give the
opportunity to create a background music service on the less priority channel and overlapping announcements
directly by an operator from its microphone base or its SIP phone connected to the PBX to another priority channel
over the music channel.
Example
In a plant there are the systems showed in the diagram, connected to the same network switch.
AD615/SIP can make an announcement via Multicast to the address 239.255.12.42 or normally broadcast ambient
music at 239.255.12.43:
Many more devices than those shown in the example may be connected, there are no limits. The receivers are
programmed to receive only the announcement, the music plus the announcement or the only music that
AD615/SIP makes available on the LAN streaming.
System number 1 in the example figure will only play the announcement message, the system number 2 will
broadcast the music that will be interrupted due to the broadcast of a priority announcement, the system number 3
will always and only broadcast the music without ever listening to messages (the music will be interrupted anyway
for the duration of the message being sent to other devices).
To get a continuous service of ambient music you will need to have a second AD615/SIP in order to dedicate a
system for the transmission of music and the other to the transmission of the announcement messages, because
with just one system the music channel will be interrupted when a microphone announcement is being
broadcasted.
AD615/S
IP
For multicast
announcers
AD611 n. 1
Multicast
Address
239.255.12.42 (announcements)
LAN Switch
Fonia
AD611 n. 2
Multicast
Address
239.255.12.42 (annuncements)
239.255.12.43 (music)
Fonia
AD611 n. 3
Multicast
Address
239.255.12.43 (music)
Fonia
1
2
3

TEMA TELECOMUNICAZIONI IP PoE Multicast Encoder AD615/SIP
MAS-AD615SIP-REV00EN Page 12 of 28
7. INSTALLATION
Position, connect and operate AD615/SIP is very simple.
7.1. Mounting and System positioning
Simply place AD615/SIP on a table or shelf after applying the rubber anti-slip adhesive feet. Alternatively, if
desired, it is possible to screw to the bottom of the system the practical accessory adapter for DIN rail using only
the 2.5MA cross-head screws and washers supplied. Otherwise fix to the wall using the side fins with fastening
eyelets and screw anchors with screws provided. Warning: the side flaps can be opened only once to avoid their
weakening.
7.2. Connection
The connection must be carried out by qualified technical personnel, operate without power, strictly follow the
specifications of voltage and current levels indicated in the figure.
4-pin removable terminal block
+Vout Terminal block from which it is possible to withdraw unregulated power supply, POSITIVE
GND Terminal block from which it is possible to withdraw unregulated power supply, NEGATIVE
A Terminal block to power the system, irrelevant polarity
C Terminal block to power the system, irrelevant polarity
RJ45 LAN Port
AD615/SIP requires a LAN cable to connect to the network. If the port cable has also PoE, it will not be necessary
to supply the module with other power sources (Recommended solution).
At the "+Vout" output there is a + 12Vdc voltage when the device is powered via PoE, otherwise, at
this output the voltage will be the same as at the terminals A-C. The use of "+Vout" is permitted as
long as it is not exceeded a maximum 200mA current consumption and the load has a protection on
the input current. Improper use of this output will permanently damage the unit.
Devices powered via PoE (Power over Ethernet) may only be connected with cables coming from
inside the building, they are not allowed connections to LAN cables coming from outside the
building.
AD615/SIP

TEMA TELECOMUNICAZIONI IP PoE Multicast Encoder AD615/SIP
MAS-AD615SIP-REV00EN Page 13 of 28
Jack 3,5mm audio input
This is the input for a stereo cable ending with a 3.5mm stereo jack. The input is expected to be connected to a
"line" output coming from a common non-amplified audio playback device such as audio CD players, FM tuners,
MP3 players.
RJ45 microphone base
At the RJ45 proprietary input can be connected an optional microphone base from which the audio of an electret
microphone is picked up. The microphone is powered directly by AD615/SIP.
Audio selector lever and current audio indicator LED
Is the three-position lever that controls the transmission of audio signals over the LAN network, encoded by
AD615/SIP and sent in the selected protocol by the system parameters. A LED is located above each input jack.
Red for the microphone and green for the audio input from the cable. Turns on when audio transmission is selected
from either of the two ports.
Wall installation with dowels
Use the anchors provided and before fixing to the wall fold the flaps with eyelet not used towards the side walls of the
device.
Installation on standard DIN rail
Secure the plastic DIN accessory on the back of the device using the 2 flat washers + 2 countersink 2.5x6mm
screws supplied and clip onto a standard DIN rail, fold all the flaps with eyelet towards the side walls of the device.
Installation support on table or shelf into Rack cabinet
Apply the non-slip rubber feet provided on the bottom surface of the device, fold all flaps with eyelet towards the side walls
of the device.
D
o not connect to this input outputs from amplifier equipment or devices that directly pilot a speaker,
the levels would not be adequate for the correct operation of the system and you may get poor
quality audio quality or you can damage AD615/SIP.
Please note that
this
is not a
P
hantom power, suitable for commercially available microphones, then
it is necessary to have the accessories provided by Tema for generating announcements messages

TEMA TELECOMUNICAZIONI IP PoE Multicast Encoder AD615/SIP
MAS-AD615SIP-REV00EN Page 14 of 28
8. PROGRAMMING
8.1. Preparation for the system parameters programming
Programming is done via the WEB interface. To gain access, simply connect an Ethernet cable from a PC or from a
switch to the LAN port of AD615/SIP.
The default IP address of AD615/SIP is "192.168.0.10".
Remember that in order to successfully connect to the web interface of AD615/S, it is necessary that, in the IP
addresses configuration of your PC, is present the subnet 192.168.0.x, where "x" is any number between 1 and
254 and different from 10. See below how to configure your PC to reach the correct subnet. The shown procedure
applies to Windows® operating systems.
Open the Windows Control Panel and set the field "View by": "Category" "Large Icons" or "Small Icons".
Choose "Network and Sharing Center" as shown in the first figure, detect your LAN connection, choosing the one
referring to the network card that you are using to connect with AD615/SIP.

TEMA TELECOMUNICAZIONI IP PoE Multicast Encoder AD615/SIP
MAS-AD615SIP-REV00EN Page 15 of 28
Once the correct connection is identified, click on it and it will appear the window where it is necessary to click on
the "Properties" button. It will then open the window where must be selected "Internet Protocol Version 4
(TCP/IPv4)" and then click the Properties button again. See the following figures:
If the PC is already on subnet 192.168.0.x with a mask 255.255.255.0, ignore the following steps. Otherwise,
proceed as follows. (The address of the PC configuration should not be 192.168.0.10).
Remember the current TCP/IP configuration of your computer for any subsequent restore of the correct
parameters.
Click "Use the following IP address" and type in the appropriate field the following IP address: 192.168.0.11
(instead of "11" used in the example it is possible to enter any number between 1 and 254, but excluding the 10
which is the default address of the system to be programmed). In the "Subnet Mask" enter the netmask
255.255.255.0. Click OK to confirm the changes. The PC is now ready to configure the door phone. Remember at
the end of programming to restore the network configuration of the PC to its original state if necessary.
Once the IP address of your PC is successfully configured, it is possible to reach the Web interface to configure
AD615/SIP at the address 192.168.0.10 .

TEMA TELECOMUNICAZIONI IP PoE Multicast Encoder AD615/SIP
MAS-AD615SIP-REV00EN Page 16 of 28
8.2. Access to programming
To program the device, it is sufficient to use a standard browser such as Explorer, Firefox, Chrome or others.
The default address of the device is 192.168.0.10 with a mask of 255.255.255.0, and the user/password with which
to connect are master/master.
Make sure to have access to this network segment from your computer. Once logged in, it is possbile to change the
administrative password for the maximum safety of your device, see par.Errore. L'origine riferimento non è stata
trovata.
The use is very simple and intuitive, it is always visible on the left the menu for selecting the functions to be
programmed, while on the right is shown the configuration window that is currently active.
Any change will be confirmed by pressing the "Apply" or "Save" buttons.
Closing the browser or changing the page without selecting those buttons will make lost any change . Any changes
do not require restarting the device (except the change of IP address, and the software update).

TEMA TELECOMUNICAZIONI IP PoE Multicast Encoder AD615/SIP
MAS-AD615SIP-REV00EN Page 17 of 28
8.3. Network parameters
On this page it is possible to set the network parameters, such as IP address, netmask, etc.:
The default IP address of the device is 192.168.0.10 . Gateway and DNS are only needed if you want the device to
have the ability to access the Internet (for example to get the current date / time, in the example from the site
ntp1.inrim.it).
The changes to the network settings are taken over by the device until the next reboot. Once you have completed
the configuration steps so be sure to reboot the system and if necessary, change the network segment of your
computer so that it can connect to the new address.
•IP address: specify the IP address you want to assign to AD615/SIP.
•Subnet mask: indicate the subnet mask to be assigned to AD615/SIP.
•Default gateway: indicate the gateway that can enable AD615/SIP to access to internet.
•Primary and secondary DNS server: indicate the addresses of two DNS servers you want to use to resolve
IP addresses.
•Time server: indicate the address of the server you want to use for time synchronization device.
•Test address (ping): if inserted, this address is used by the system to verify the correct operation of the
network connection.
•Device description: optional, is the description that appears on the net with the search tool Tema “ADAM
Audio Domain & Access Management” a very useful software for the centralizad management of all
devices IP Audio series AD600 and IP Intercom series AA-500/600.

TEMA TELECOMUNICAZIONI IP PoE Multicast Encoder AD615/SIP
MAS-AD615SIP-REV00EN Page 18 of 28
8.4. SIP Parameters
The SIP parameter settings allow the device to register with the PBX with its own account. In this way it
can also be reached by a normal telephone call to activate the audio stream on any of its 16 multicast
channels:
•SIP server address: specify the IP address of the PBX to which AD611/612 must connect.
•Port: is the port number of the SIP PBX with which the AD611/612 must operate. Generally it is the 5060
but some stations use a different port.
•Domain: enter the domain to which register the system.
•Outbound proxy: some PBXs require that the extension number to call is followed by the proxy address. In
most cases this field can be left empty.
•Local SIP port: generally the 5060 port is used, but it is possible to specify a different number (i.e. for
particular routing tables).
•User/password: credentials for the registration of the extension (which obviously must have been already
created on the PBX).
•Expiration: indicates how many seconds the device should check the correct registration of the client.
•Audio channel: indicates the number of the audio channel on which to send the incoming stream via
telephone. If you set 0, the system will emit two short beeps upon answering and get ready to receive the
number of the channel to be used (from 01 to 16), otherwise it will use the channel number indicated for the
stream without requesting it from the caller.
•Duration of communication: maximum duration of communication in seconds (0 = no limit).

TEMA TELECOMUNICAZIONI IP PoE Multicast Encoder AD615/SIP
MAS-AD615SIP-REV00EN Page 19 of 28
8.5. Audio channels
This section contains the basic programming, where to configure the destination addresses of multicast traffic and
the audio codec to use:
The stream addresses must be preceded by the "#" character (but the software will add it anyway). Channel 1
represents the stream destination associated with the high position of the lever (generally the music) while channel
2 is the destination of the audio associated with the lower position of the lever (announcements from the
microphone). The two streams addresses can also coincide.
All channels (from 1 to 16) can be addressed manually when the system is reached by telephone.
The stream codec parameter indicates which codec to use when digitizing the incoming audio signal. It is not
necessary to program the type of codec set up in AD615/SIP of the receiving devices as the detection will be
automatic. It is possible to choose between the G711 quality (the lowest) and the L16 quality at 32 kHz (the
highest). Obviously a best quality matches a greater bandwidth.
The selected codec in AD615/SIP in the above window will be the same for the background music stream as well
as for the stream output of a voice announcement from the microphone.

TEMA TELECOMUNICAZIONI IP PoE Multicast Encoder AD615/SIP
MAS-AD615SIP-REV00EN Page 20 of 28
8.6. Messages
In this window it is possible to change/listen to the Announcement messages. The memory contains a default
message for each position, the user can change any of them and the messages format must be WAV PCM 8 kHz,
16 bit, mono. Max duration is 16s upgradable to over 8 minutes each with licence. These messages will be used for
the function described in “Automatic announcements”.
8.7. Automatic announcements
It is possible to program the diffusion of announcements at pre-set times, which can be streamed to other devices
Daily activation:
it is possible to automate the diffusion of a daily announcement (which will take place at the set time) for each day.
It will be reproduced for the number of repetitions, with separation between a message and the other given by the
number of seconds set. It is also possible to manually activate the message (with the "Activate now" button) or stop
