Templari KITA AIR User manual

INSTALLATION INSTRUCTION
AIR TO AIR
THE HEAT PUMP

Summary
1 Introducon ........................................................................................................... 4
1.1 General Notes......................................................................................................... 4
1.2 Suggested tools ...................................................................................................... 4
1.3 Seriesdescripon ................................................................................................... 4
2 Read Carefully before use ....................................................................................... 5
2.1 Importantinformaon............................................................................................ 5
2.2 Proper use.............................................................................................................. 5
2.3 Regulatory.............................................................................................................. 5
2.4 Energecsaving...................................................................................................... 5
3 Expected use of the heat pump .............................................................................. 5
3.1 Operangareaesafedevices ................................................................................. 5
3.2 Heat pump structure .............................................................................................. 5
3.3 Operaonmode ..................................................................................................... 6
4 Equipment supplied................................................................................................ 6
4.1 Main unit................................................................................................................ 6
4.2 Name and serial number ........................................................................................ 6
4.3 KITA AIR Templari® internal unit dimension ........................................................... 7
5 Transport................................................................................................................ 8
6 Mounngandinstallaon....................................................................................... 8
6.1 Equipment check .................................................................................................... 8
6.2 External unit measurements................................................................................... 8
6.3 Free spaces for the assembly .................................................................................. 8
6.4 Choiceofinstallaonplace ..................................................................................... 9
6.5 Externalunitmounng........................................................................................... 9
6.6
Condensatedischargepreparaon................................................................................ 9
6.7 Correct alignment................................................................................................. 10
6.8 Probeinstallaon ................................................................................................. 10
7 Montaggio e installazione dell’unità interna ......................................................... 11
7.1 Internal unit sizes and components ...................................................................... 11
7.2 Generaliesandchoiceoftheinstallaonplace ................................................... 11
7.3 AssemblyinternalunitandcorrectposioningofB2probe .................................. 11
8 Refrigerantcircuitonnecon................................................................................ 11
8.1 Installaonrequirements ..................................................................................... 11
8.2 Preparaonforinstallaonandrefrigerantpipelinesinstallaon.......................... 11
8.3 Vacuum procedure ............................................................................................... 12
9 Maintenance and cleaning.................................................................................... 13
9.1 Finned coil cleaning .............................................................................................. 13
9.2 Condensate discharge cleaning............................................................................. 13
9.3 Refrigerant circuit maintenance............................................................................ 13
10 Electricconnecon ............................................................................................... 14

10.1 Generalinformaon ............................................................................................. 14
10.2 Operaonsoflaying ............................................................................................. 14
10.3 Externalunitconnecon....................................................................................... 14
10.4 Internalunitconnecon ....................................................................................... 14
10.5 Probes and remote controller ............................................................................... 14
11 Terminal box wiring .............................................................................................. 16
11.1 Internal terminal box wiring ................................................................................. 16
11.2 External unit internal terminal box wiring KITA - AIR............................................. 16
11.3 pLANwebwiring-“mul-KITA” ............................................................................ 18
12 Electronics (UPC) .................................................................................................. 18
12.1 Digital outputs...................................................................................................... 18
12.2 Digital inputs ........................................................................................................ 18
12.3 Analogical outputs................................................................................................ 18
12.4 Analogical inputs .................................................................................................. 18
12.5 Electric diagram KITA AIR...................................................................................... 19
12.6 Internalwiringconnecondiagram ...................................................................... 20
13 Commissioning ..................................................................................................... 21
13.1 Preliminary controls ............................................................................................. 21
13.2 Commissioning ..................................................................................................... 21
14 Control unit .......................................................................................................... 22
14.1 Control panel measurement ................................................................................. 22
14.2 Control panel structure......................................................................................... 22
14.3 Control panel display............................................................................................ 22
14.4 Main menu........................................................................................................... 23
14.5 ON-OFF menu....................................................................................................... 23
14.6 SETPOINT menu.................................................................................................... 23
14.7 Clock/metablemenu .......................................................................................... 24
14.8 Input/Output menu.............................................................................................. 25
14.9 Alarms history menu ............................................................................................ 25
14.10Boardchangemenu.............................................................................................. 25
14.11 Assistance menu................................................................................................... 25
14.12Menuoverview .................................................................................................... 29
15 Alarms.................................................................................................................. 30
15.1 Alarmsresoluon ................................................................................................. 32
15.2 Nocaons......................................................................................................... 32
16 Performances ....................................................................................................... 33
17 Declaraonofconformity..................................................................................... 34
17.1 DeclaraonofconformityKITAAIR....................................................................... 34

4
www.templari.com
1 Introducon
This manual aims to give all the necessary informaon installaon
and proper operaon of KITA - AIR Templari® heat pump, from
its start-up and for all its life cycle. The document is divided
into chapters , each of which contains general informaon and
procedures to be performed.
1.1 General Notes
• The selecon and the use of the unit that serves the plant
shall be carried out by competent sta in accordance with
regulaons in place, so as to fully sasfy the demands of
the system.
• Installaon, commissioning and maintenance must be
performed by competent sta that must be able to assess
risk factors or malfunconing of the machine.
• The unit is directly supplied by the manufacturer with all
the opons and funconalies . Tampering with any part of
the refrigerator circuit or the soware are not allowed. Any
tampering will invalidate the manufacturer responsibilies.
• Regular inspecons and proper maintenance of the heat
pump KITA - AIR Templari® can prevent damages and any
costs for repairs.
• The warranty is void for an installaon that doesn’t meet
the specicaons.
• Keep this manual with the necessary diagrams in an easily
accessible place.
• In case of malfunconing, check the error code on the
control panel, if necessary contact the installer. If necessary,
please request for original parts.
• You can nd all informaons on the KITA Templari® label,
in accordance with the regulaon on labeling,in parcular
you can nd:
• Voltage and frequency of Power supply of the machine;
• Thermal power in heang and cooling;
• Maximum power consumpon;
• Sound power level;
• The refrigerant ulized.
1.2 Suggested tools
• Set of screwdrivers;
• Cuer;
• Scissors;
• Set of wrenches or pipe wrenches;
• Ladder;
• Pumber material to seal the threads;
• Electrical equipments for connecons;
• Protecve gloves;
• Testers and current clamp;
1.3 Seriesdescripon
KITA - AIR Templari® heat pump series presents air to air
machines which are composed by an external and internal
unit (aerothermal unit) for heang and cooling in big spaces
applicaons.
KITA - AIR Templari® is full-inverter with high performance and
generously sized component to reach high energy eciencies.
Another feature is the EVI technology (Enhanced Vapour Injecon)
that enlarges the operang zone and the thermal power of the
machine. The R410A refrigerant allows the achievement of high
performances and low environmental impact. Full reliability
and opmal funconality are ensured by two electronic valves,
a 4-ways valve, pressure transducers, temperature probes,
controlled by the electronics onboard. The user can control the
whole machine funconalies by a remote panel controller: by
this control it is possible to change the setpoint and the working
mode (summer/winter) and to monitoring the operaons.
External unit
Internal unit

5
www.templari.com
2 Read Carefully before use
2.1 Importantinformaon
ATTENTION!!
The use and the maintenance of the KITA - AIR Templari®
heat pump, are subjected to the juridical ordinances of the
desnaon country. Depending on the amount of refrigerant you
need to check and note the ghtness of the heat pump at regular
intervals referring to qualied personnel.
• During transport it’s possible lt the external unit not over
45° (in any direcon).
• Transport protecon must be removed before to
commissioning.
• Don’t cover or reduce the sucon area.
• Comply with the building regulaons specic to individual
countries.
• If the heat pump is installed near the wall, be careful to the
inuence of building physics factors. Make sure that there
aren’t windows in the fan discharge area.
• If the heat pump is installed near a wall, there is a higher
risk of deposit of impuries. Besides, external air moved
by the heat pump must escape in order to not increase the
building thermal losses.
• It Is not allowed the installaon of the external unit or of
the monoblock in niches or in interior courtyards, because
the cooled air accumulates on the ground and in the case
of prolonged funconing would aspirated again by the heat
pump.
• The frozing limit can change depending on climate region.
Respect the regulaons of the countries concerned.
• Observe correct rotaonal direcon: in case of incorrect
wiring the start of the heat pump is hindered. The unit
presents a phase monitoring that indicates the correct
connecon.
• The heat pump could stop operaons in case of too low
external temperature. In case of long me power cut,
please see the commissioning procedure explained
forward.
• Before opening the device, make sure to switch o all the
electronics.
• Only qualied sta of the customer service can operate on
the device.
2.2 Proper use
KITA - AIR Templari® heat pump is homologated only for the
expected use, and it must be used as described by this manual.
A dierent ulizaon mode is considered non-compliant. Any
modicaon of the device is forbidden.
2.3 Regulatory
This device, in accordance to the 1st arcle of the 2006/42/ CE
Direcve, must be use only in residenal environment, and hence
is subjected to the 2006/95/CE Direcve (Low voltage supply).
For design and realizaon of the heat pump all the CE direcves
and all the DIN and VDE have been observed.
The electric connecon of the heat pump must be made in
accordance with the VDE, EN and DIN specicaons. Besides, the
specicaons for the electrical connecons xed by the supplier
must be observed.
People, in parcular children, that due to physical or mental
diseases or lack of experience can’t use the device in safe,
mustn’t use the device without an expert guide. Make sure that
children don’t play with the heat pump.
2.4 Energecsaving
KITA Templari® contributes to environmental saving. To properly
ulize the thermal energy contained in the air, make sure of a
correct disposion of energy sources and plant. In order to
obtain an high energy eciency is necessary to reduce as much
as possible the temperature dierence between the external
air and internal air. For this reason a correct sizing and design
of the plant is recommended. Foratemperaturedierenceof
1°Chigher,itmeansanincreaseinconsumponof2,5%. Avoid
to place the internal unit inside dusty ambients. The dust may
accumulate on the heat exchanger decreasing its eciency. The
same in the case of corrosive volale substances.
3 Expected use of the heat
pump
3.1 Operangareaesafedevices
• KITA AIR Templari® heat pump has to be used with external
air temperature between -30°C and 46°C.
Internal air temperature range:
• Heang: min. temperature 15°C, max. temperature 35°C
• Cooling: min. temperature 20°C, max. temperature 28°C
• KITA AIR Templari® heat pump is equipped by a pressure
switch that stops the machine operaons when a pressure
of 4,5 MPa is reached.
ATTENTION!
Make sure to switch o the device and to disconnect it from the
electric connecon before performing maintenance.
• KITA AIR Templari® heat pump is equipped by a
discharge temperature probe that controls the discharge
temperature.
NOTE!
The device is not suitable for use with an external inverter. If the
machine is powered o (disconnected from the net) for long
periods, do not interrupt the procedure of the oil warming that
starts when the machine is powered once again. This procedure
prevents the compressor breakdown.
3.2 Heat pump structure
The heat pump system includes the following components:
• The KITA AIR Templari® external unit contains the refrigerant
circuit;
• KITA AIR Templari® internal unit (aerothermal) for the diusion
of the air inside ambient;
• Remote control panel.

6
www.templari.com
4 Equipment supplied
4.1 Main unit
The KITA AIR Templari® heat pump is provided in 2 units and it’s
consists of components which are indicated at page 4.
4.2 Name and serial number
The name of the model and the serial number are indicated on
the plate (1). Figure 1 and 2.
gure 1
1
3.3 Operaonmode
The heat pump can operate in two modes, aconable trough the
switching of the 4 way valve: as shown below, this modes are
heang and cooling.
Heangmode
1 Evaporator
2 4-W valve
3 Fan
4 Compressor
5 Electronic expansion
valve
6 Internal unit
exchanger
Cooling mode
1 Evaporator
2 4-W valve
3 Fan
4 Compressor
5 Electronic expansion
valve
6 Internal unit
exchanger
gure 2

7
www.templari.com
4.3 KITA AIR Templari® internal unit dimension
1 Deector
2 Fan
3 Case
4 Baery exchanger
5 Electric box
6 Side cover (remove to access to electric box)
7 Probe cable B2 prewired to unroll
The image is intended only to indicate the main internal components. The actual product may looks dierent.

8
www.templari.com
5 Transport
WARNINGS!
Regardless of the type of transport, must never be inclined more
than 45°. Contrary you can have anomalies in the refrigerant
circuit in the next operaon. In severe cases this may have as a
consequence a failure inside.
The transport to the nal place of installaon should be done on
a pallelt. The heat pump KITA AIR Templari® can be transported
using a forkli.
KITA AIR Kg. 260 - 130
• Protect the sidewalls of the product coming into contact
with the forkli to prevent scratches and damages.
• Li the product only from the back and from the side of the
ngs.
• The liing of excessive weights can cause spinal injuries, for
example.
• Consider the weight of the product riported in the technical
data.
• In the transport of heavy loads, comply with the instrucons
and the provisions in force.
• It is recommended to pay aenon do not to overexeron
when liing the internal unit. It is advisable to be at least in
two persons.
6 Mounngandinstallaon
6.1 Equipment check
• cable for remote control panel connecon
• sensor probe
oponal
• An-vibraon mounngs for ground xing;
• wall support for internal unit.
6.2 External unit measurements
C: IN
D: cable passages
A: condensate drain
B: OUT
1516
325 1133 325
259 1257
1791
121
122
89
292
352
233 170 231
641
231 170 233
A
B
C
D
6.3 Free spaces for the assembly
Distance Measures in millimeters
A>300
B >2500
C >500
D>3000
E >1000
Respect the minimum distances menoned above to ensure a
sucient air ow and facilitate maintenance works.
• If the product is installed in areas prone to heavy snowfalls,
verify the snow doesn’t accumulate around the product
and the minimum distances menoned above are
respected. If these condions can’t be sased, install then
an addional heat generator in the heang circuit.

9
www.templari.com
6.4 Choiceofinstallaonplace
• Observe all the rules in force.
• Install the product outside the building.
• Don’t install the product:
- near a heat source,
- near ammable substances,
- near venlaon opening of conguous buildings,
- Below deciduous trees.
• For the installaon of the product observe:
- prevailing winds,
- noise of the fan and the compressor,
- opcal impression on the environment
• Avoid place where on the air outlet of the product there is
the eect of strong winds.
• Don’t orient the fan towards the near windows.
• If necessary, install noise-protecon system.
• Install the product on one of the following supports:
- Concrete pavement,
- T steal beem
- Concrete block.
• Don’t expose the product to dusty and corrosive air (e.g.
near rough roads).
• Don’t install the product near wells of air discharge.
• Prepare the laying of electrical cables.
• In places where there are snowfalls, install the heat pump
at least 25 cm from the ground to avoid clogging at the
inlet and drain zone.
6.5 Externalunitmounng
1. Before installing the device, please see the safety warnings
in this manual.
2. Install the product on T beam steel, Concrete Block or with
a wall support.
3. Make sure that water doesn’t accumulate under the
device.
4. To avoid ice formaon, make sure that the ground in front
of the device can absorb condensed water.
6.6 Condensatedischargepreparaon
The condensate is discharged behind the heat pump by a unique
way. Prepare the condensate discharge with a discharge pipe
or with a gravel bed.
WARNINGS!
Frozen condensate on the path can cause falls. Make sure that
the condensate doesn’t ow on the path and that it doesn’t
freeze.
• Preparaon of the base for condensate drain
• Example 3 condensate drain (it is recommended to bury the
drain pipe to prevent the formaon of ice in the event that
you do not purchases oponally the heang resistor for
discharge condensate)
Frost proof
depth
min 200mm
Frost
proof
depth
Frost proof
depth
min 200mm
Frost
proof
depth
Frost proof
depth
min 200mm
Frost
proof
depth
Frost proof
depth
min 200mm
Frost
proof
depth

10
www.templari.com
Frost proof
depth
min 200mm
Frost
proof
depth
• Example 2 condensate drain
• Example 3 condensate drain with condensate drain element
The condensaon water accumulated during the operaon must
be carried away without it can freeze. To ensure the correct
oulow the heat pump must be in a horizontal posion. The
condensaon water pipe must have a minimum diametre of
18mm and must ow in the drain channel without it can freeze.
Don’t discharge the condensate directly into puricaon basins
and moats. The aggressive fumes and the condensaon pipe, if
it isn’t protected against frost, can cause irreparable damages to
the evaporator.
In places where there are snowfalls, install the heat pump at least 25
cm from the oor to avoid clogging in the sucon and condensate
drain area.
6.7 Correct alignment
Put horizontally the heat pump KITA AIR Templari® so that
the condensate can ow. The product must be installed with
amorzed feet, purchased separately. The amorzed feet
increase the height of the product, facilitang the ow of
condensate and reducing vibraons.
6.8 Probeinstallaon
All probe used for the operaon of the plant must be installed
properly in the appropriate wells using a suitable thermal paste.
WARNINGS!
Installing the probes not in a proper way will voids the warranty.
7 Montaggio e installazione
dell’unità interna
7.1 Internal unit sizes and components

11
www.templari.com
7.2 Generaliesandchoiceofthe
installaonplace
WARNING!
• Install the unit in an internal environment.
• The unit must not to be install near heat or steam sources.
• Install the internal unit respecng the minimal distances
from walls and obstacles for facilitate the assembly and
maintenance operaons.
• Secure a proper air circulaon.
• Install the unit in a vercal posion, as shown in gure at
paragraph 7.1.
7.3 Assembly internal unit and correct
posioningofB2probe
The unit has to be xed to the wall using dowels and L supports.
Li the unit and hang it on the wall. Cauon, it is advisable to
be at least in two persons or more, as the excessive weight can
cause serious injuries.
Probe cable B2
The B2 probe cable must be posioned
sideways respecng a distance of 2 m from
the internal unit, it must alight at man height
paying aenon it cannot be in direct contact
with the wall because it is primary that the
cable of this probe be at least 3cm away from
the wall.
2 m
Probe cable B2
8 Refrigerantcircuitonnecon
The refrigerant pipes connecons have to be made up by
qualied and licensed personnel. The connecons requires the
use of a weld tool.
8.1 Installaonrequirements
• The connecng tubes between internal and external units
have to respect the below indicated dimensions.
• Non respecng of indicated measurements can lead to
signicant decrease of the machine performance.
• If the internal unit is installed at a higher level than the
external unit, it is necessary to provide some specic
siphons each 5 meters high on the refrigerant conduit
return to facilitate the oil return eventually remained in the
circuit
Nominal
lenght
Maximum
lenght
of the piping
(m of equivalent
length)
Maximum
height
dierence
(m of equivalent
length)
Addional
refrigerant
charge
recommended *
(g/m of equivalent
length)
All models 1 30 30 45
* sub-cooling must be in a range between 3°C and 4°C with heat pump in steady state.
NOTE: the parameter equivalent lenght has to consider the
curves too. Each 90° curve in the circuit has to be counted as
a 1 m straight poron. Each 180° curve in the circuit has to be
counted as a 2 m straight poron. Each oil trap in the circuit has
to be counted as a 4 m straight poron.
8.2 Preparaonforinstallaonand
refrigerantpipelinesinstallaon
The coolant pipes connecons must be sealed to prevent
leakage of the coolant and the consequent malfunconing of the
heang pump. The connecon pipes must be insulated and have
diameters specied in the following table.
Gas (mm) Liquid (mm)
KITA AIR Ø 28 Ø 16
For the preparaon of the pipes for installaon, proceed as
follows:
• Measure the distance between internal and external units,
and perform all necessary installaon curves..
• The laying of the pipes must include the minimum number
of bends, because each curve increases the pressure drop
of the circuit and reduce the machine performance.
• Cut the pipes to a length slightly greater than that
measured.
• Completely remove smudging from the cut secon, holding
the pipe downward and blowing air into the pipe.
• Respect the safety measures that are indicated into the
table, or add the request quanty of refrigerant.
• Weld the provided manufacturer’s anchors at the end of
the connecon pipe. Weld the inner side female anchors
and the outer side male anchors. Where is possible,
perform welding in nitrogen atmosphere. Otherwise at the
end of welding operaon blow the nitrogen braise points..
• Insulate carefully the refrigerant anchors and connecons.

12
www.templari.com
8.3 Vacuum procedure
• We recommend to run a leak test with nitrogen to 40 bar
pressure to check the quality of the welding connecons
• For the vacuum perform, connect the pump charging
vacuum connecon procedure (1/4) inside the external
unit.
• Perform the vacuum unl reaching 0.4mbr pressure
(duraon of procedure for about 1 h for 15m total length
connecon. If the length increases as result will increase
duraon of the vacuum perform).
• At the end of the procedure remove the pump and open
the valve to pour out the refrigerant liquid.

13
www.templari.com
9 Maintenance and cleaning
A regularly maintenance is necessary in parcular for correct
and ecient heat pump operaons, so as to reduce damages
and usury of the components. The user decides the maintenance
frequency. It depends in parcular on two factors:
• The ulizaon mode: if the operang mode during the year
is single (heat pump or chiller), an annual maintenance is
suggested; if the operang mode is double (heat pump
and chiller) during the year, the maintenance shall be
halfyearly.
• The installaon place: if the installaon is located in heavy
polluted places or in the presence of dust that could
obstruct the nned coil, it is suggested to frequently check
the nned coil condions and, if necessary, to supply a
more frequent maintenance.
WARNING!
Disconnect the device from the electric supply before every
operaon to avoid injuries due to the acvaon of some
parcular operang logics.
9.1 Finned coil cleaning
During the machine funconing it’s possible that the nned
baery will parally obstructed because presence of leaves or
incrustaons of various kinds, also provoking a malfunconing of
the heat pump. It is possible then clean the baery with a under
pressure jet of air in a parallel direcon of the ns, you should
also remove any deposits in the baery compartment keeping
an adequate distance so as not to risk to fold or damage them.
• Clean the frontal surface;
• Remove the panel on top as shown by the gure.
• clean also the internal unit nned baery, especially if it is
placed in dusty ambient
WARNING!
Don’t touch the ns to avoid to be cued. Don’t fold the ns, this
could reduce the performances. In case of folded ns, contact a
service center.
9.2 Condensate discharge cleaning
Please make sure that the condensate discharge pipe is in the
correct posion e without any obstrucon to ensure a proper
condensate ow from the nned coil ns.
9.3 Refrigerant circuit maintenance
The machine is equipped with a safety valve which ensure
the reducon of internal refrigerant circuit pressure in case of
external generaon of heat (e.g. in case of re).
To ensure proper operaon of the valve, contact the manufacturer
and make sure to replace it each 4 years.
WARNING!
The direct contact between the skin and coolant out of the safety
valve cause serious injury. Do not stand near the valve.

14
www.templari.com
10 Electricconnecon
10.1 Generalinformaon
• Before starng any operaon please adopt any safety
device and make sure that the unit is in stable equilibrium
and that there isn’t any element connected to the electric
supply.
• The electric supply line must adopt safety devices suitable
for the machine characteriscs that can interrupt the
hortcircuit current.
• Refer to the electric diagram of the unit.
• At rst please connect the grounding connecon.
• Before switching the unit on, all protecons must be acve.
10.2 Operaonsoflaying
• Please install cables far from lines with dierent voltage or
from devices that can create electromagnec interferences.
• Avoid parallel laying with other cables, the arrangement is
only permied at 90 °
• Pass the power cables and the net control cable of the
machine only trough proper holes.
10.3 Externalunitconnecon
• Connect the power supply to the external unit electric
terminal by the following table named “power supply
cables indicaon“. Cables passage takes place through the
apposite holes.
• See 12.1 for the connecon of drain pan’s electric heater.
10.4 Internalunitconnecon
• For electric connecon see the following table named
“power supply cables indicaon“. See the chapter 11 the
terminal picture where to connect RS485 fan contacts (2 core
cable) and the sensor probe (2 core cable). The cable carries
low voltage control signals: nd a route far from sources of
interference, do not joints along the way, possibly using a 3
core cable + shield secon 1.50 sq mm (shield connected to
GND to indoor unit side).
• Connect the internal unit 230V fan power supply ( phase,
neutral, ground) to the terminal board of the external unit
through the tripolar cable (minimum secon 1,5 mmq).
• Pay special aenon on ground connecon: the GND
must be the same for the 2 units. ABSOLUTELY AVOID THE
CONTACT BETWEEN THE SIGNAL GND AND THE THE GND OF
POWER SUPPLY!
WARNING!
The secon of the supply cables is to be considered indicave
and relave to the last part of the line towards the machine, that
should be as shorter as possible. The external protecons, the
posion and cable secon of the previous supply line should be
sized and realized by an authorized person and according to the
technical standards of the naonal authories.
10.5 Probes and remote controller
Temperature probe B2 of internal ambient temperature must
be connected with a mulpolar cable (2x1,5 shielded) along
the shortest route and away from the power cables. Parcular
aenon should be paid to the juncons because of parasic
resistance inuence which may compromise the Control Board
value readings.
Connect the remote panel with a telephone cable to the external
unit. The remote panel and the probes cable can be laid together
with the same precauons.
WARNING!
We recommend to use a ferrite Toroid to protect the remote
panel from any external disturbance.

15
www.templari.com
Powersupplycablesindicaon
• KITA AIR
External unit
Supply 400 Vac - 50 Hz
Cable 5x6 mmq
Secondarylineprotecon230
µPCprotecon24Vdc
3 fuses - 5x20-4A
1 fuse - 5x20-4A
Internal unit
Supply 230 Vac - 50 Hz
Cable 3x1,5 mmq

16
www.templari.com
11 Terminal box wiring
11.1 Internal terminal box wiring
11.2 External unit internal
terminal box wiring KITA - AIR
D
R S T N PE
S
F4
F1 F2 F3
N
A
B
PE
D
R S T N PE
S
F4
F1 F2 F3
N
A
B
PE
1 3 5 7 9 11
2 4 6 8 10 12
B2 -
1
3
5
7
9
11
2
4
6
8
10
12
B2
Gnd
B4
GND
B5
+VDC
B3
GND
Y3
GND
B7
GND
C
230V auxiliary power supply
internal fan
A Auxiliary fuses 4 A
B Power: Phase, Neutal and
Ground for internal split
C Sensor terminal block
(the simbol - indicates GND, the
simbol + indicates +VDC)
D Supply: Power wiring terminal
GND
B2
S
N
PE
RX- / TX-
RX+ / TX+
L
N
PE
1
2
3
4
L
N
PE
B2
GND
RSB
RSA

17
www.templari.com
µPC Connector
descripon:
B1 Subcooling
B2 internal ambient probe
B3
B4
B5
B6
Head compressor probe
B7
B8 outside t. probe
B9 drain probe
B10 sucon probe
B11 transducer high
B11 +5V
B11 GND
B12 transducer low
B12 +5V
B12 GND
DI1 summer-winter
DI2 thermal sensor
DI3 press. switch high
DI6 solar boost SGR bit0
DI8 remote on-o
DI9 P-Lan protocol
DI10 ow switch (present on
old models)
F4
Elektrische Sicherung -
5x20 250 mA
Y2
Y3 PWM Circulator
GND
+5VR
C4
NO8
NO9
NO10
NO11
NO12
Rx+ / Tx+
Rx- / Tx-
RX-/TX-
RX+/TX+
C1
NO1
NO2
NO3
C2
NO4
NO5
NO6
NO7
C3
NC7
G
G0
B1
B2
B3
B4
B5
B6
B7
GND
+Vdc
+Vdc
GND
+5 Vref
GND
Y1
Y2
Y3
Y4
DI1
DI2
DI3
DI4
DI5
DI6
DI7
DIC1
B8
B9
B10
B11
B12
GND
DI8
DI9
DI10
DIC2
Connect the Modbus RS485 port on the uPC
using the proper cable (image on the side)

18
www.templari.com
11.3 pLANwebwiring-“mul-KITA”
If the air condioning system has more units which interact with
each other in a pLAN logical “master-slave”, you need to connect
the machines via the bipolar cable screened according to the
following scheme:
Scheda 1
(master)
Tx+ Tx+ Tx+ Tx+tx- tx- tx- tx- GND GND GND GND
Scheda 2 Scheda 3 Scheda 4
The wiring should be done in the port dedicated to the “P-2 LAN”
tab (see point 11 on the scheme in chapter 12).
12 Electronics (UPC)
1 Power 24 Vdc
2 Sensor power
3 Analog inputs from B1 to B7
4 Port BMS
5 Digital inputs from DI1 to DI7
6 Analog outputs from Y1 to Y4
7 Analog inputs from B8 to B12
8 Injecon valve
9 Digital inputs from DI8 to DI12
10 P-Lan 1 Operator panel
11 P-Lan 2
12 Port RS485 Modbus
13 Expansion valve
14 Block outputs C1 NO1 - NO3
15 Block outputs C2 NO4 - NO6
16 Block outputs C3 No7 - Nc7
17 Block outputs C4 NO8 - NO12
18 Bar hooks Din 35
6
12 3
4
59
7
8
17
10
11 12
13
14 15 16
18
18 18
12.1 Digital outputs
KITA AIR
NO1 /
NO2 /
NO3 /
NO4 /
NO5 Condensate discharge heater
NO6 alternave power source
NO7 /
NO8 /
NO9 /
NO10 4 way valve for cycle inversion
NO11 Compressor carter heater
NO12 /
12.2 Digital inputs
KITA AIR
ID1 Winter/Summer commutaon
ID9 Thermic compressor discharge
ID3 Pressure switch for high pressure
ID4 /
ID5 /
ID6 /
ID7 /
ID8 Remote on-o
ID10 Flow switch
12.3 Analogical outputs
KITA AIR
Y1 (0-10V) /
Y2 (0-10V) /
Y3 (0-10V/PWM)) /
Y4 (0-10V) /
12.4 Analogical inputs
KITA AIR
B1 (NTC HS)
B2 (NTC) Internal ambient temperature
B3 (NTC)
B4 (NTC)
B5 (NTC)
B6 (0-5V) Injecon pressure transducer
B7 (NTC)
B8 (NTC) External temperature
B9 (NTC HT) Compressor discharge temperature
B10 (NTC HS) Compressor sucon temperature
B11 (0-5V) High pressure transducer
B12 (0-5V) Low pressure transducer

19
www.templari.com
12.5 Electric diagram KITA AIR
RSTN
400 Vac 50 Hz
J7
RX+/TX-
GND
J9
Vout
J11
C1
N01
N02
N03
C2
N04
N05
N06
N07
C3
NC7
C4
N08
N09
N010
N011
N012
RX+/TX+
RX+/TX-
RX+/TX+
GND
J17
G
G0
+Vdc
GND
+5vr
B1
B2
B3
B4
B5
B6
B7
GND
VDC
J6
ID1
ID2
ID3
ID4
ID5
ID6
ID7
IDC1
GND
Y1
Y2
Y3
Y4
B8
B9
B10
B11
B12
GND
ID8
ID9
ID10
IDC2
J8 J10 J12 J13 J14 J15
J1 5J4J3J2J J18 J16
R
S
T
N
R
S
T
N
N
EVV EVV
M
OUT
+5vrf
M
OUT
+
5vrf
R S T
Heater condensate drain
Injection valve
4
4
CH
3
RS485
M
3 ~
M
3 ~
RS485
Bridge to the terminal block
6-7 5-8
COMPRESSOR
t
t
t
t
t
t
t
t
t
REMOTE ON/OFF
PLAN / BMS
HP
0-45 Bar
LP
0-17 Bar
10k
10k
HT
10k
10k
10k
10k
10k
10k
10k
HS
uPC
HP 40.5
PDC CHR
Term Comp.
DC CHOKE
HS
F
1
F2
F3
F4
N
L-V
-V
+V
+V
PWR
24 VDC
RST
R S T
M
3 ~
RST
S
R S T
PE
INTERNAL UNIT FAN
EXTERNAL UNIT FAN
Expansion valve
Auxiliary
boiler
4-way valve

20
www.templari.com
12.6 Wiringconnecondiagraminternalunit
PE Yellow/Green
NBlue
NO4
3
2
1
N-Lok 3
Brown
SBrown
RBrown
PE
6
5
4
3
2
1
N-Lok 6
Yellow/Green
NBlue
TBrown
NBlue
NBlue
NO11
6
5
4
3
2
1
N-Lok 9
Brown
PE Yellow/Green
No10 Brown
8
7
9
20
19
B6
B1
14
13
12
11
10
9
Molex Mini Fit Jr 20
White
+5V Red
Gnd Black
B11
B10 White
White
Red
Black
Black
Black
Black
Black
Black
Black
B9 White
B8 White
White
D13
D12 White
B12 White
White 16
15
17
18
8
7
2
1
4
3
5
6
