tempmate S1 User manual

•tempmate.com V1.0
Product Overview
This document describes the correct handling process for tempmate.®-S1 data loggers, for the purpose to ensure the
proper operation and provide a reliable temperature and time record during transportation and storage.
Waterproof Cover
Serial Number Label
LED Indicators Start/Stop + Status/Mark Button
USB Interface
Product Configuration
Information
Front
Start/Stop Instructions
Glue Spot
Back
Status Request
Mark Instructions
Expiry Date
Recording Options Single-Use
Temperature Range –30°C to 70°C
Temperature Accuracy ±0.2°C (0°C/+60°C); ±0.5°C (others)
Temperature Resolution 0.1 °C
Data Storage Capacity 31.200 readings
Shelf Life / Battery 2 years1/ CR2450 button cell
Recording Interval 10 minutes (standard)
Recording Duration 200 days
Startup Mode Button or preprogrammed scheduled start
Stop Mode Button or preprogrammed scheduled start
Protection Class IP67 / NEMA 6
Weight 15.2 g
Dimensions 88 mm × 47 mm × 8 mm (L × W × H)
Certifications According to EN 12830,according to FCC and
CE, RoHS
Validation Certificate PDF file in memory and online database
Software
PDF or CSV program
Optional: Cloud Ready with the
tempmate.®-Cloud
Report Generation Automatic PDF & CSV report
Connection Interface USB 2.0, A-Type
Alarm Configuration Optional, up to 6 points
1Depending on optimal storage conditions (+15°C to +23°C / 45% to 75% rH)
• Technical Specifications
Single-Use USB Data Logger
-S1
Manual –

•tempmate.com V1.0
Operation Instructions
Status Action LED confirmation
Start Logger Push button for 5 sec GREEN LED flashes 10 times
Set Mark double-click button RED LED +GREEN LED flashes 5 times simultaneously
Mark limit full double-click button RED LED +GREEN LED flashes 5 times alternating
Stop Logger Push button for 5 sec RED LED flashes 10 times
Start / Stop
Status Action LED confirmation
Not Started push button once RED LED +GREEN LED flashes 1 time
Recording – OK push button once GREEN LED flashes 1 time
Recording – Alarm push button once RED LED flashes 1 time
Stopped – OK push button once GREEN LED flashes 2 times
Stopped – Alarm push button once RED LED flashes 2 times
Low Battery push button once RED LED flashes 3 times
Scheduled Start push button once RED LED +GREEN LED flashes 2 times alternately
Status Request by pushing Button once
01 Press and hold for at least 5 seconds to start recording.
If the GREEN LED flashes 10 times, the start was
successful.
Note: If the GREEN LED does not flash 10 times to
indicate a correct start or RED LED flashes 3 times, DO
NOT use this logger.
02 Press button once at any time to check current
status of the logger. Double-click button to
set a mark in the report. See details of these
optional features in tables below.
03 Keep button pressed for minimum 5 seconds to
stop recording. Then RED LED flashes
10 times, which indicates a successful stopping.
Note: For safety issues the logger is not stoppable in the
first 30min. after the start.
04 After stopping record, tear o the transparent
plastic cover and connect the logger to a USB
port of the computer. The PDF ans CSV report
will be generated automatically and can be
found in the device‘s „tempmate“ folder.
Press button
Press button Tear o
Status Request or Set Mark (optional)
Single-Use USB Data Logger
-S1
Manual –

•tempmate.com V1.0
Notes
˦When tempmate.®-S1 logger is stopped and connected to the computer the first time, both LEDs are
flashing to indicate the PDF report is in process of generation. At this time, please do not unplug the
logger until both LEDs are on, which indicates the finished PDF generation.
˦A stopped tempmate.®-S1 logger cannot be started again.
˦Do not place tempmate.®-S1 logger into corrosive liquid.
˦The battery of tempmate.®-S1 loggers is a non-exchangeable CR2450 lithium battery. Please do not
expose to direct heat. Do not place in microwave.
˦Store tempmate.®-S1 loggers under room temperature conditions and do not use it after the expiry
date printed on the logger..
˦Please recycle or dispose tempmate.®-S1 loggers in accordance with local laws and regulations.
˦Hold the logger against the back of your phone to access the validation certificate of your
tempmate.®-S1 and all associated documents via the NFC function.
Single-Use USB Data Logger
-S1
Manual –
Certificate of Validation
˦Hold the tempmate.®-S1 logger to the back of
your phone
˦The NFC function opens the tempmate.®
certificate database
˦You automatically get access to the
validation certificate of your tempmate.®-S1
logger and all related documents
˦Open your browser and go to the following
page:
˦https://www.tempmate.com/database/
˦Alternatively you can scan this QR-Code to get
to the mentioned page.
˦Enter the serial number of your tempmate.®-S1
in the search bar and press the ENTER button
˦You automatically get access to the validation
certificate of your tempmate.® logger
The certificate of validation is available online for each logger. Follow the steps below to access your
logger‘s certificate and retrieve all related documents.
