Tenda W322U User manual

300MbpsWireless USBAdapterUserGuide

300MbpsWireless USBAdapterUserGuide
CopyrightStatement
istheregisteredtrademarkof
ShenzhenTendaTechnologyCo.,Ltd.All theproducts
andproductnamesmentionedhereinarethe
trademarksorregisteredtrademarksoftheir
respectiveholders. Copyright ofthewholeproductas
integration,includingitsaccessoriesandsoftware,
belongsto ShenzhenTendaTechnologyCo.,Ltd.
Without thepermission ofShenzhenTendaTechnology
Co.,Ltd,anyindividualorpartyisnot allowedto copy,
plagiarize,imitateortranslateitinto otherlanguages.
All thephotosandproductspecificationsmentioned in
thisguideareforreferencesonly.Astheupgradeof
softwareandhardware,therewill be changes. Andif
therearechanges,Tendaisnotresponsiblefor
informinginadvance.Ifyou want toknowmoreabout
ourproductinformation,pleasevisitourwebsiteat
www.tenda.cn.

300MbpsWireless USBAdapterUserGuide
Tableof Content
Chapter1Introduction..................................................1
1.1ProductFeature....................................2
1.2ProductDeployment..............................3
1.3IndicatorDescription.............................4
1.4Package Contents.................................4
Chapter2InstallationGuide.......................................5
Chapter3ClientUtilityInterface............................10
3.1Station Mode............................................10
3.1.1Station ModeTopology......................11
3.1.2Status............................................12
3.1.3SiteSurvey.....................................13
3.1.4ProfileManagement..........................15
3.1.5Statistics........................................17
3.1.6WPSSetting....................................17
3.2APMode..................................................19
3.2.1APMode Topology............................19
3.2.2BasicSetting...................................20
3.2.3SecuritySetting...............................21
3.2.4AccessControl.................................22
3.2.5About.............................................24
AppendixOne:AcronymsandTerms....................25
AppendixTwo:Product Specification...................28
AppendixThree: Howtoconnect with PSP........29
AppendixFour:HowtoSetWPS...........................34

300MbpsWireless USBAdapterUserGuide
1
Chapter1Introduction
W322UisaWireless USB Adapterwith upto300Mbps
transmittingrate.It adoptstheverylatestwireless
standard—IEEE802.11n,whichperfectlycomplies
downwardwith IEEE802.11g/bstandards, efficiently
reducesthe“deadspots”inwireless areaandwidely
multipliesthewireless coverage area.
W322Uissuitablebothfordesktopandnotebook
computers. Itstransmittingratecanreachupto
300MbpsanditstransmittingtimeinLANwillbegreatly
shortened whenconnected toTendaW306R11N
WirelessRouter.It respondsimmediatelyandkeeps
smooth whenyou aresearchingwebpages,
downloading,gamingandwatchingvideoonline.
All inall,W322Uisacost-effective300MbpsWireless
USB Adapterwith robustsignal,farthertransmitting
distanceandstableperformance.

300MbpsWireless USBAdapterUserGuide
2
1.1 ProductFeature
•Supports300Mbpswireless receivingand
transmittingrate
•Complieswith thelatest802.11nand
802.11b/gstandards
•ProvidesUSB2.0port
•Supports20MHz/40MHzfrequencywidth
•Detectswirelessnetworkandchanges
transmittingrateautomatically
•Providestwoworkingmodes:Infrastructure
andAd-Hoc
•Supports64/128-bitWEPand
WPA/WPA2/802.1xencryption methods
•SupportsWPS(Wi-Fi Protected Setup)
encryption to securewireless networkstrongly
•Complieswith Windows2000/XP/Vista, Linux,
MACOS,etc.
•SupportsWMMtosmooth youraudioandvideo

300MbpsWireless USBAdapterUserGuide
3
1.2 ProductDeployment
W322UWireless USBAdapteroffersfast,
reliableandcost-effectivesolutionforwireless
access. Deployment as follows;
•Forstaff who requireshighermobilityinthe
office,theywant to haveaccess to traditional
wired orwirelessnetworkinanyplaceofthe
company;
•Enterpriseorindividualwho requiresoften
changesinlayout of networkcables;
•Companiesorplaceswhicharenot suitablefor
LANcablelayingout becauseofbudgetor
objectivebuilding,includingplacesofgreat
interests, rent placesorplacesforshort-term
usage;
•Companyorindividualwho avoidsusing
expensivecables, rentingcablesorrenting
rightsforaccess.

300MbpsWireless USBAdapterUserGuide
4
1.3 IndicatorDescription
In thefront panel of W322U,thereisaLED indicator
blinkingwhendatacommunication isgoingon.
1.4 PackageContents
Unpackthepackets, andpleasefindthefollowing
items:
ØOneW322U300MbpsWirelessUSB Adapter
ØOneCD-ROM

300MbpsWireless USBAdapterUserGuide
5
Chapter2Installation Guide
Thischapteristoassistyouhowtousetheincluded
CD-ROMwhichcomprisestheSetupWizardandthe
Client UtilityInterface.
ThefollowingstepsonSetupWizardaretakenthe
WindowsXPasexample.
1.PleaseinserttheWireless USB Adapterintothe
USB portof yourcomputer.
2.“FoundNewHardware”systemdialogueappears,
andselects“Cancel” to usetheincludedSetup
Wizardforfastinstallation;ofcourse,you alsocan
select“Next” to install bymanual.

300MbpsWireless USBAdapterUserGuide
6
3. InerttheincludedCD-ROMintotheCD-ROMdrive
ofyourcomputer,andtheWelcomescreen
appears.(Ifnot appear,doubleclickthe
“W322U.exe” icon.)

300MbpsWireless USBAdapterUserGuide
7
4.Click“Enter”.
5. Click“Next” to startinstalling.

300MbpsWireless USBAdapterUserGuide
8
6. Click“Change…”toselectthedirectorypath,or
click“Next”.
7. Select“OK” and“Next” inthefollowingwindow.
8.Duringtheinstallation,thefollowingdialoguemaybe

300MbpsWireless USBAdapterUserGuide
9
appears.Clickthe“ContinueAnyway” to continue.
Thereisno securitythreatto yourcomputer.
9.Click“Finish” to completetheinstallation.

300MbpsWireless USBAdapterUserGuide
10
Chapter3ClientUtilityInterface
ThissoftwareisfortheW322UWireless USB Adapter
management.Ifitdoesnotappear,select“Start”—“All
Programs”—“Tenda”—“W322U”,orclicktheshortcut
on yourPC’sdesktop.
Note:
In theWindowsXP,you canselecttheincluded
W322UClient UtilityInterfaceortheWindowsXP
internalwirelessapplicationto configurethedevice.
Therearetwoclient utilityapplicationsinW322U:
Stationmode andAPmode.
Note:
In thisutilityinterface,Station Mode(Client Mode)
isthedefaultaccessway.
3.1 Station Mode

300MbpsWireless USBAdapterUserGuide
11
3.1.1Station ModeTopology
Inthismode,W322Uservesasaclienttoreceive
thewirelesssignalstoaccesstheInternet.

300MbpsWireless USBAdapterUserGuide
12
3.1.2Status
IntheNetworkStatuswindow,itdisplayssomethingon
wirelessadapterandwirelessnetworkstatus,including
SSID,Authenticationtype,Encryption Type,IPaddress,
subnetmaskandgatewayandsoon.

300MbpsWireless USBAdapterUserGuide
13
3.1.3SiteSurvey
TheSiteSurveyisusedto scantheavailablewireless
networkaround,showingthewireless network’ssignal
strengthandotherinformationwhichprovidesbasisfor
you to accesswhichwireless network.
Connect: selectoneentryinthewireless network
listandclickthebuttonto connectthedevicewith
theselected network.
Refresh: rescanthewireless networkaround.

300MbpsWireless USBAdapterUserGuide
14

300MbpsWireless USBAdapterUserGuide
15
3.1.4ProfileManagement
Thiswindowsavesthegeneralwireless parametersfor
different profiles, whichisusedto fastconnectthe
wireless networkyou need.
UP/DOWN: Tochangetheprofile’ssequenceinthe
list.
Connect: Toactivateoneprofile.
New: Tocreateanewprofileandconfigurethesite
statusandsecuritysetting.
Modify: Tomodifyoneexistingprofile.
Delete: Todeleteoneexistingprofile.

300MbpsWireless USBAdapterUserGuide
16
(SiteStatus)
(SecuritySetting)

300MbpsWireless USBAdapterUserGuide
17
3.1.5Statistics
StatisticsisusedtosummarizeRxandTxdatapackets,
includingthesuccessanderrorpacketamount.
Clear: clickthisbuttonto renewthestatistics.
3.1.6WPS Setting
WPSsettingisenabledonlyonWPS-compliantdevices.
