POWER
 
 

Է И
Л
Й
К М
PoE HD Video Security Kit
Quick Installation Guide

Ԯ
ԯ
԰
Ա
Բ
Գ
Դ
Ե
- 1 -
Wall mounting hole
English
Package contents
Appearance
Զ
Է
И
Й
К
Л
М
Network Video Recorder x 1 Screwdriver×1
HDMI cable×1
1m Ethernet cable×1
18m Ethernet cable×2
30m Ethernet cable×2
Surveillance sticker×1
Quick installation guide
PoE Camera×4
Power adapter x 1
NVR installation package x 1
Camera installation package x 4
Camera mounting template×4
Mouse x 1
HDD×1
Only equipped in some kits
Screw: Thread diameter: 3.5 mm; Length: 5 mm; Head diameter: 6.5 mm
−Plastic anchor: Outer diameter: 6.6 mm; Inner diameter: 2.4 mm; Length
26.4 mm
−Screw: Thread diameter: 3 mm; Length: 25 mm; Head diameter: 6.0 mm
POWER LED indicator
Hard disk drive
(HDD) screw hole
Power port
AUDIO OUT port USB2.0 port
HDMI port
10/100 Mbps PoE power supply and
data transmission multiplexing port
Grounding terminal
10/100 Mbps LAN port
AUDIO IN port
VGA port
POWERPOWER PoE PORTS LAN AUDIO HDMI
OUT
1 3
2 4
VGA USB1 USB2
IN
Solid blue: Initializing.
Solid green: NVR recording.
NVR (The N6P-4H is taken as an example here.)
Camera
When the arrow is at 12 o'clock position, the monitoring direction is the positive
direction.
Microphone
Ethernet port, 10/100 Mbps auto-negotiation
The camera supports the IEEE 802.3af standard, this port can be connected to
the PoE port of a PoE power sourcing equipment for power supply.
Blinking green: NVR working properly but not recording.
Solid red: NVR faulty (LAN port disconnected, or HDD faulty).
The K4P-4CR Kit is taken as an example here. The actual product prevails.

-2-
Grounding terminal.
Connect the grounding terminal of the NVR to the earth or the ground terminal of the building
with a grounding cable to prevent static electricity or lightning from damaging the NVR.
Power port.
Use the included power adapter to power on the NVR.
POWER
PoE
PORTS
LAN
AUDIO
IN
AUDIO
OUT
HDMI
VGA
USB
Fast Ethernet LAN port.
Used to connect to such devices as the router and switch.
Audio input port.
Used to connect to the audio input devices , such as pickups.
Audio output port.
Used to connect to audio output devices, such as active speakers.
HDMI port.
Connect your monitor or TV to this port using an HDMI cable for audio and video output.
VGA port.
Connect your monitor to this port using a VGA cable for video output.
USB 2.0 port.
Used to connect to such devices as a mouse and a USB storage device.
DescriptionPort
Tips
- Recommended Ethernet cable: CAT 5 or better.
- Power supply distance:
• Normal Mode (default): Up to 100m
• Long-range Mode: Up to 250m
Fast Ethernet port, which supports IEEE 802.3af/at PoE power supply. Used to connect to
cameras.
Tips
When installing or replacing the HDD, please cut off the power supply of the NVR, otherwise the HDD may not be
detected or even be damaged.
I Install the HDD
If the kit does not include any HDD, please prepare it by yourself. You are recommended to use the HDD
dedicated for surveillance.
ԮUse a screwdriver to unfasten the screws, then remove the cover of the NVR. Reserve the screws for
later use.
POWER
POWER PoE PORTS LAN AUDIO HDMI
OUT
1 3
2 4
VGA USB1 USB2
IN
Flip
Remove the cover
Wall-mounting holes
Wall-mounting materials are self-prepared. Recommended specifications of the plastic
screws and anchors:
Screw: thread diameter: 3 mm, length: 14 mm; head diameter: 5.2 mm
Plastic anchor: inner diameter: 6.0 mm; length: 26.4 mm

- 3 -
ԯTake out 2 screws from the NVR installation package, and screw them into the two screw holes
closest to the SATA connector. Reserve about 2 mm between the screws head and the HDD for
subsequent installation.
԰Align the SATA connector of the HDD with the SATA slot on the motherboard of the NVR, and then
insert the HDD into the slot until it is tightly fixed.
ԱTake out the remaining screws from the NVR installation package, and screw them into the HDD
screw holes to fix the HDD.
ԲMount the cover with the previously removed screws.
SATA connector
HDD
HDD
HDD
POWER
POWER PoE PORTS LAN AUDIO HDMI
OUT
1 3
2 4
VGA USB1 USB2
IN

- 4 -
II Install the camera
Tips
Please make sure the wall or the ceiling is strong enough to withstand three times the weight of the camera.
You may need to prepare a hammer drill, a drill bit, a rubber hammer, a screwdriver, and a ladder for the installation.
−
−
Remove the base
Rotate the body of the camera, align the housing slot with any base notch, and then use a screwdriver to
pry the housing at the slot to remove the base.
Fix the camera
The camera supports ceiling and wall mounting. The ceiling mounting is taken as an example here.
Base notch
Housing slot
Anchor
Mounting template
A Run the cable through the side
B Run the cable through the bottom
Base
Screw
Base
Screw
Mounting template
 


Adjust the monitoring direction

- 5 -
IV Basic configuration
Quick setup

After connecting the mouse and monitor to the NVR, you can perform quick setup.
Select the language displayed on the GUI and the time zone in which the NVR locates, and then click
OK.
Startup
Local management
Connect the included power adapter to the power port of the NVR, and plug the power adapter into the
power socket to start up the NVR.
Use the included power adapter to power on the NVR. The NVR may fail to work normally or even be damaged due to abnormal power supply.
Shutdown
Note
Note
Do not directly cut off the power supply of the NVR to force a shutdown; otherwise, the HDD may be damaged, videos may be lost, or even the
NVR may be damaged.
Initial Setup
(UTC+8:00) Beijing, Chongqing, H
2022 - 01 - 14
11 : 26 ：51
Language
Time Zone
Date
Time
OK
Engilsh
Shutdown
After connecting the mouse and monitor to the NVR, perform the following settings on the NVR's web UI
(exit the Full Screen interface): Click in the upper right corner, click Shutdown , and then click OK.
When The Device is Shut Down. Please Cut Off the Power appears on the screen, unplug the power
adapter of the NVR.
III Connect the device
Computer
OUT
POWERPOWER PoE PORTS LAN AUDIO HDMI
1 3
2 4
VGA USB1 USB2
IN
Router
LAN
LAN
PoE NVR
WAN
LAN
Internet
Monitor
PoE
Ethernet cable
HDMI cable
or VGA cable
The K4P-4CR kit is taken as an example here.
PoE Camera PoE Camera PoE Camera PoE Camera

- 6 -
Set Password, enter your Email Address, and then click Activate.
Device Activation
8 to 32 characters
Re-enter the login password
Only for resetting the password
User Name
Password
Confirm Password
Email Address
Activate
admin
Shutdown
Unlock Pattern Network Cloud
Draw an Unlock Pattern
Redraw
Do Not Use Unlock Pattern
If you want to use a pattern to unlock the web UI, draw an unlock pattern. Otherwise, click Do Not Use
Unlock Pattern and skip to step  .
ConnectedConnection Status
IP Address
Subnet Mask
Default Gateway
Unlock Pattern Network Cloud
Previous Next
DHCP

Tips
Ensure that the connection status is Connected, then click Next.
Ensure that the LAN port connection of the NVR is normal.
Ensure that the DHCP server function of the router to which the NVR is connected is enabled.
−
−
If the connection status is Disconnected, try the following solutions:

- 7 -

Tips
Ensure that the cloud status is Online and click OK.
−
−
If the cloud status is Offline, please ensure that the router to which the NVR is connected can access the internet and the filter function is
disabled.
You can also manage the NVR through the TDSEE App. Please refer to App management in this guide for details.
OnlineCloud Status
Previous OK
Unlock Pattern Network Cloud
Scan the QR Code to Download TDSEE App Scan the QR code with the TDSEE App to add the device
If you want to add the NVR to TDSEE App, please operate within 30 minutes
after the device is connected to the cloud; Otherwise, please reboot the
device and try again.
Settings completed. You can perform such operations as previewing real-time video, playing back the
recording and managing monitoring devices.
Run the TDSEE App and follow the instructions to complete user registration. Enter the homepage, then
tap Add a device or in the upper right corner of the homepage.
App management
Tips
After the cloud service of the NVR is enabled and the cloud status is Online, you can add and manage
the NVR through the TDSEE App.



To ensure that the login password of the NVR can be reset through the TDSEE App, please register using the email address you used to activate
the NVR.
Scan the QR code on the label at the bottom of the NVR or scan the QR code on the Cloud
Service page, then follow the instructions in the App.
After adding the NVR, you can remotely preview real-time video, play back the recordings and check
alarm messages through the TDSEE App.
23$PEF
0S
Download the TDSEE App.
After the smartphone is connected to the internet successfully, download and install the TDSEE App
onto your mobile phone by scanning the QR code or by searching for TDSEE in Google Play or App
Store.
Ensure that the NVR is powered on and working properly.

- 8 -
If the NVR is not activated, you can activate it through the web UI. When the activation is completed, you
need to log in again.
Activate


Connect the computer to the switch or router that is connected to the NVR.
Set the IP address of the computer to an unused one belonging to the same network segment as the IP
address of the NVR but different from the IP address of the NVR.
The default login IP address of the NVR is 192.168.1.254, please set the IP address of the computer to
192.168.1.X (X indicates 2 to 253, and is unused by other devices).
Web management
These series of NVRs can be managed on the web UI.
192 . 168 . 1 . 10
General
Log in to web UI
Tips
The NVR supports HTTPS login. When you access its management page, the browser may prompt that the web address is not secure, just
ignore it and continue.
Device Activation
8 to 32 characters
Re-enter the login password
Only for resetting the password
User Name
Password
Confirm Password
Email Address
Activate
admin
English
Launch a browser and enter the default IP address 192.168.1.254 of the NVR in the address bar. Set
Password, enter your Email Address, and click Activate.
Done. You can re-enter the web UI of the NVR to preview real-time videos or configure the NVR as
required.
The DHCP function of the NVR is enabled. If there is a DHCP server in the network, the IP address of the
NVR may be changed. Please refer to the actual IP address assigned to the NVR by the DHCP server.
Refer to step  to  in Activate to operate.

- 9 -
FAQ
Q1. What should I do if the NVR cannot find the camera?
A1. Try the following solutions:
− The camera needs a period to start. Please wait about 120s after the camera is connected to the PoE port of the
NVR through the Ethernet cable.
− Ensure the camera is connected to the PoE port of the NVR properly.
Navigate to Configuration > Network Configuration > PoE Configuration to check the port status of the NVR. If the
icon of the port status is gray and the output power is 0.0W, it indicates that the camera connection is abnormal or
no power is supplied to the camera. Please re-plug or replace the Ethernet cable.
−If the problem persists, please contact Tenda technical support.
Q2. What should I do if the GUI preview is normal, but no recordings during playback?
A2. Enter the Live View page to view whether a recording icon is displayed in the upper right corner of the channel.
If no recording icon is displayed in the upper right corner of the channel, try the following solutions:
− If the HDD is not installed inside the NVR, please install it first.
− Navigate to Configuration > Storage > HDD to check whether the HDD is normal. If the status of the HDD is
abnormal, please shut down the NVR first, then remove the cover and unplug and re-plug the HDD. If the problem
persists, please format or replace the HDD.
− Navigate to Configuration > Storage > Schedule to check that the recording function is enabled, and the
recording mode and time are set correctly.
If a recording icon is displayed in the upper right corner of the channel, please try the following solutions:
− Navigate to Configuration > System > Time to ensure that the system time of the NVR is accurate.
− Navigate to Configuration > Storage > HDD to check whether the HDD space is full. By default, the Overwrite
function is enabled. If the HDD space is full, the oldest recording files will be overwritten.
Q3. What should I do if the TDSEE App fails to add the NVR?
A3. Try the following solutions:
Navigate to Configuration > Network > Cloud Service of the NVR to ensure that the cloud service function is
enabled.
− If Cloud Status is Online, please ensure that the mobile phone (with the App installed) is connected to the internet.
− If Cloud Status is Offline, try the following solutions:
• Navigate to Configuration > Network > Internet to ensure that the internet parameters configuration is correct.
• Ensure that the LAN port of the NVR is correctly connected to the peer side (switch or router).
• Ensure that the router in the network is connected to the internet and the filter function is enabled (such as MAC
filter and blacklist).
• Ensure that the DHCP server function of the router in the network is enabled.

- 10 -
Dansk
Pakkens indhold
Udseende
Ԯ
ԯ
԰
Ա
Բ
Գ
Դ
Ե
Զ
Է
И
Й
К
Л
М
Netværksvideooptager x 1 1m Ethernet kabel x 1
HDMI kabel x 1
1m Ethernet kabel x 1
18m Ethernet kabel x 1
30m Ethernet kabel x 1
Klistermærke til overvågning x 1
Hurtig installationsvejledning
PoE Kamera x 4
Strømadapter x 1
NVR-installationspakke x 1
Installationspakke til kamera x 4
Skabelon til kameramontering x 4
Mus x 1
HDD × 1 (kun udstyret i nogle sæt)
Skrue: Gevinddiameter: 3,5 mm; Længde: 5 mm; Hoveddiameter: 6,5 mm
−Plastanker: Udvendig diameter: 6,6 mm; Indvendig diameter: 2,4 mm;
Længde 26,4 mm
−Skrue: Gevinddiameter: 3 mm; Længde: 25 mm; Hoveddiameter: 6,0 mm
POWER LED indikator
HDD skrue hul
Vægmonteringshuller
Strømport
Hurtig Ethernet-port USB 2.0 porte
HDMI port
10/100 Mbps PoE power supply and
data transmission multiplexing port
Jordforbindelse terminal
Hurtig Ethernet LAN port
AUDIO IN port
VGA port
POWERPOWER PoE PORTS LAN AUDIO HDMI
OUT
1 3
2 4
VGA USB1 USB2
IN
Solid blå: Initialiserer.
Fast grøn: NVR-optagelse.
NVR (N6P-4H er taget som et eksempel her.)
Digitalkamera
Når pilen er ved 12-tiden, er overvågningsretningen den positive retning.
Mikrofon
Ethernet-port, 10/100 Mbps auto-forhandling
Kameraet understøtter IEEE 802.3af-standarden, denne port kan tilsluttes
PoE-porten på et PoE-strømforsyningsudstyr til strømforsyning.
Blinker grønt: NVR fungerer korrekt, men optager ikke.
Konstant rødt: NVR defekt (LAN-port afbrudt, eller HDD defekt).
K4P-4CR-sættet er taget som et eksempel her. Det faktiske produkt har forrang.

-11-
Jordforbindelse terminal
Tilslut NVR ' ens jordforbindelse til jorden eller bygningens jordforbindelse med et
jordforbindelse for at forhindre statisk elektricitet eller lyn i at beskadige NVR.
Strømport.
Brug den medfølgende strømadapter til at tænde NVR.
Fast Ethernet port, som understøtter IEEE 802.3 af / at PoE strømforsyning. Bruges til at oprette
forbindelse til kameraer.
POWER
PoE
PORTS
LAN
AUDIO
IN
AUDIO
OUT
HDMI
VGA
USB
Hurtig Ethernet LAN port.
Bruges til at oprette forbindelse til sådanne enheder som routeren og kontakten.
Lydindgangsport.
Bruges til at oprette forbindelse til lyd indgangs enheder, såsom pickupper.
Lyd udgangs port.
Bruges til at oprette forbindelse til lyd udgangs enheder, såsom aktive højttalere.
HDMI port.
Tilslut din skærm eller dit TV til denne port ved hjælp af et HDMI kabel til lyd- og video udgang.
VGA port.
Tilslut din skærm til denne port ved hjælp af et VGA kabel til videoudgang.
USB 2.0 porte.
Bruges til at oprette forbindelse til sådanne enheder som en mus og en USB lagerenhed.
Vægmonteringshuller
BeskrivelsePort
Tip
- Anbefalet Ethernet-kabel: Kat 5 eller bedre.
- Strømforsyning afstand:
• Normal tilstand (standard): Op til 100m
• Langtrækkende tilstand: Op til 250m
Vægmonterings materialer er selvforberedte. Anbefalede specifikationer af plast
skruer og ankre:
Skrue: gevinddiameter: 3 mm, længde: 14 mm; hoveddiameter: 5.2 mm
Plastanker: indre diameter: 6,0 mm; længde: 26,4 mm
Tip
Når du installerer eller udskifter harddisken, skal du afbryde strømforsyningen til NVR, ellers kan harddisken muligvis ikke
registreres eller endda blive beskadiget.
I Installer harddisken
Hvis sættet ikke indeholder nogen HDD, bedes du forberede det selv. Det anbefales at bruge den
dedikerede HDD til overvågning.
ԮBrug en skruetrækker til at løsne skruerne, og fjern derefter dækslet på NVR. Reserver skruerne til
senere brug.
POWER
POWER PoE PORTS LAN AUDIO HDMI
OUT
1 3
2 4
VGA USB1 USB2
IN
Vend
Fjern dækslet

- 12 -
ԯTag 2 skruer ud af NVR-installationspakken, og skru dem ind i de to skruehuller tættest på SATA
stikket. 2 mm mellem skruehovedet og harddisken til efterfølgende installation.
԰Juster SATA stikket på harddisken med SATA slot på bundkortet på NVR, og indsæt derefter
harddisken i åbningen, indtil den er tæt fastgjort.
ԱTag de resterende skruer ud af NVR installationspakken, og skru dem ind i HDD skruehullerne for at
fastgøre harddisken.
ԲMonter dækslet med de tidligere fjernede skruer.
SATA stikket
HDD
HDD
HDD
POWER
POWER PoE PORTS LAN AUDIO HDMI
OUT
1 3
2 4
VGA USB1 USB2
IN

- 13 -
II Installer kameraet
Tips
Sørg for, at loftet er stærkt nok til at modstå tre gange kameraets vægt.
Det kan være nødvendigt at forberede en borehammer, en borekrone, en gummihammer, en skruetrækker og en stige til installationen.
−
−
Fjern basen
Drej kamerahuset, juster husets åbning med et hvilket som helst basishak, og brug derefter en
skruetrækker til at lirke huset ved åbningen for at fjerne bunden.
Fastgør kameraet
Kameraet understøtter loft- og vægmontering. Loftmonteringen tages som eksempel her.
Grundhak
Husslids
Anker
Monteringsskabelon
A Før kablet gennem siden
B Før kablet gennem bunden
Grundlag
Skrue
Grundlag
Skrue
Monteringsskabelon
 


 Juster overvågningsretningen

Når du har tilsluttet musen og skærmen til NVR, skal du udføre følgende indstillinger på NVR ' s GUI
(Afslut fuldskærm grænsefladen):
Klik på i øverste højre hjørne, Klik på Shutdown (Lukning) , og klik derefter på OK. Når The Device
is Shut Down (Enheden er lukket ned). Please Cut Off the Power (Afbryd strømmen) vises på
skærmen, tag stikket ud af NVR ' ens strømadapter.
- 14 -
IV Grundlæggende konfiguration
Quick setup

Når du har tilsluttet musen og skærmen til NVR, kan du udføre hurtig opsætning.
Vælg det sprog, der vises på GUI'en, og den tidszone, NVR'en befinder sig i, og klik derefter på OK.
Start
Lokal ledelse
Tilslut den medfølgende strømadapter til strømporten på NVR, og sæt strømadapteren i stikkontakten for at
starte NVR.
Brug den medfølgende strømadapter til at tænde NVR. NVR kan ikke fungere normalt eller endda blive beskadiget på grund af unormal
strømforsyning.
Lukning
Note
Note
Afbryd ikke strømforsyningen til NVR direkte for at tvinge en nedlukning; ellers kan harddisken blive beskadiget, videoer kan gå tabt, eller endda
NVR kan blive beskadiget.
Initial Setup
(UTC+8:00) Beijing, Chongqing, H
Language
Time Zone
Date
Time
OK
Engilsh
Shutdown
III Tilslut enheden
Computer
OUT
POWERPOWER PoE PORTS LAN AUDIO HDMI
1 3
2 4
VGA USB1 USB2
IN
Router
LAN
LAN
PoE NVR
WAN
LAN
Internettet
Overvågning
PoE
Ethernet-kabel
HDMI eller
VGA kabel
K4P-4CR-sættet er taget som et eksempel her.
PoE kamera PoE kamera PoE kamera PoE kamera
2022 - 01 - 14
11 : 26 ：51

- 15 -
Indstille Password (Adgangskode), indtast din Email Address (mailadresse), klik derefter på Activate
(Aktivere).
Device Activation
8 to 32 characters
Re-enter the login password
Only for resetting the password
User Name
Password
Confirm Password
Email Address
Activate
admin
Shutdown
Unlock Pattern Network Cloud
Draw an Unlock Pattern
Redraw
Do Not Use Unlock Pattern
Hvis du vil bruge et mønster til at låse internet-brugergrænsefladen op, skal du tegne et oplåsning-
smønster. Ellers skal du klikke på Do Not Use Unlock Pattern (Brug Ikke Oplåsningsmønster) og spring
til trin .
ConnectedConnection Status
IP Address
Subnet Mask
Default Gateway
Unlock Pattern Network Cloud
Previous Next
DHCP

Tips
Sørg for, at forbindelsesstatus er Connected (Forbundet), og klik derefter på Next (Næste).
Sørg for, at LAN-porten på NVR er tilsluttet korrekt.
Sørg for, at DHCP-serverfunktionen på den router, som NVR er tilsluttet, er aktiveret.
−
−
Hvis forbindelsesstatus er Disconnected (Afbryde), prøv følgende løsninger:

- 16 -

Tips
Sørg for, at cloud-status er Online og klik OK.
−Hvis cloud status er Offline, sørg for, at den router, som NVR er tilsluttet, kan få adgang til internettet, og Filterfunktionen er deaktiveret.
Du kan også administrere NVR via TDSEE appen. Se App management i denne vejledning for detaljer.
OnlineCloud Status
Previous OK
Unlock Pattern Network Cloud
Scan the QR Code to Download TDSEE App Scan the QR code with the TDSEE App to add the device
If you want to add the NVR to TDSEE App, please operate within 30 minutes
after the device is connected to the cloud; Otherwise, please reboot the
device and try again.
Du kan forhåndsvise videoer i realtid, afspille optagelserne og administrere overvågningsenheder.
Kør Tdsee-appen, og følg instruktionerne for at fuldføre brugerregistreringen. Gå ind på startsiden, og
tryk derefter på Tilføj en enhed eller i øverste højre hjørne af startsiden.
App management
Tips
Når cloud-tjenesten i NVR er aktiveret, og cloud-status er online, kan du tilføje og administrere NVR via
Tdsee-appen.



For at sikre, at login-adgangskoden til NVR kan nulstilles via Tdsee-appen, skal du registrere dig ved hjælp af den e-mail-adresse, du brugte til
at aktivere NVR.
Scan QR-koden på etiketten nederst på NVR ' en, eller scan kr-koden på Cloud Service (Sky
Service) følg derefter instruktionerne i appen.
Når du har tilføjet NVR, kan du eksternt forhåndsvise videoer i realtid, afspille optagelserne og kontrollere
alarmmeddelelser via Tdsee-appen.
23LPEF
FMMFS
Hent TDSEE App.
Når smartphone er tilsluttet internettet med succes, hente og installere TDSEE App på din mobiltelefon
ved at scanne QR koden eller ved at søge efter TDSEE i Google Play eller App Store.
Sørg for, at NVR er tændt og fungerer korrekt.
Fuldføre.

- 17 -
Hvis NVR ikke er aktiveret, kan du aktivere den via internet-brugergrænsefladen. Når aktiveringen er
afsluttet, skal du logge ind igen.
Aktivere


Tilslut computeren til kontakten eller routeren, der er tilsluttet NVR.
Indstil computerens IP-adresse til en ubrugt, der tilhører det samme netværkssegment som standard
IP-adressen på NVR, men forskellig fra IP-adressen på NVR.
NVR ' ens standard login-IP-adresse er 192.168.1.254. Indstil IP-adressen på computeren til
192.168.1.X (X angiver 2 til 253 og bruges ikke af andre enheder).
Web management (Internet management)
Disse serier af NVR'er kan administreres på web-UI.
192 . 168 . 1 . 10
General
Log ind på Internet UI
Tips
NVR understøtter HTTPS login. Når du får adgang til dets INTERNETGRÆNSEFLADE, kan Bro.seren bede om, at internetadressen ikke er
sikker, bare ignorere den og fortsætte.
Device Activation
8 to 32 characters
Re-enter the login password
Only for resetting the password
User Name
Password
Confirm Password
Email Address
Activate
admin
English
Start en bro. ser og indtast standard IP-adressen 192.168.1.254 af NVR i adresselinjen. Indstille
Password (Adgangskode), indtast din Email Address (Mailadresse), og klik på Activate (Aktivere).
Gjort. Du kan genindtaste NVR ' ens INTERNETGRÆNSEFLADE for at få vist videoer i realtid eller
konfigurere NVR efter behov.
DHCP-funktionen af NVR er aktiveret. Hvis der er en DHCP-server i netværket, kan IP-adressen på NVR
ændres. Se den faktiske IP-adresse, der er tildelt NVR af DHCP-serveren.
Se trin  at  i Aktivere for at betjene.
