Teqball SMART Series User manual

indoor / outdoor
OWNER’S MANUAL

2
Dear Customer,
Thank you for choosing our product. To make the most of your Teqball Smart table, we
would like to give you some hints and safety instructions in this manual.
The Teqball Smart table is a specially-designed piece of sports equipment which has been
empirically tested and scientifically developed. Applying the laws of mathematics and
physics the ball bounces off the Teqball Smart table so the players can control and
handle the ball in all cases. The net is made of transparent PMMA plate, which means
the ball will bounce consistently.
Teqball Smart table is a durable and safe product which can be used indoor and outdoor.
The steel undercarriage is coated with corrosion-resitant paint and the tabletop consists
of an exterior HPL sheet.
The Teqball Smart table is under international patent, trademark and copyright protection.
Find out more about Teqball at
www.teqball.com

3
SPECIFICATIONS
The size specification of the Teqball Smart table in the unfolded position is:
The size specification of the Teqball Smart table in the folded position is:
The curvature of the playing surface is determined by the distance of the highest and
lowest points of the surface and by the horizontal distance from the lowest (farthest)
point of the surface to the height of the net.
The highest point of the playing surface – measured from the ground – is 760 mm, while
the lowest point is 565 mm. The horizontal distance between the lowest part of the
surface and the net is 1490 mm.
The Teqball Smart table consists of the following materials:
Fasteners and additional components:
The weight of the Teqball Smart table is 156 kg (excluding the packaging).
Length: 3 000 mm
Width: 1 700 mm (including the net)
Height: 900 mm (top of the net)
Length: 760 mm
Width: 1 700 mm (including the net)
Height: 1 800 mm
CDP and powder-coated S235 structural steel
Exterior HPL laminate
PUR adhesive
Transparent PMMA plate (acrilyc glass)
Coated stainless steel screws
Stainless steel washers and nuts
Gas springs
Wheels and castors
Additional polymer components

4
CLEANING
Please start the cleaning procedure of the Teqball Smart table for unknown stains with
basic cleaning. For the last step of the cleaning process you have to perform a final
cleaning procedure to prevent streaking. In case there is any type of stain which is not
listed below and you cannot clean the table by following the listed cleaning processes
please contact us at [email protected].
Basic cleaning
To clean dust, coffee, tea, fingerprints, fruit juice or grease/fat please use both the
following cleaning process and the final cleaning process:
Final cleaning
Detergents must be removed with water completely to avoid streaking. Finally, clean
with warm water and wipe off the surface with an absorbent cloth or paper towel.
Clean the surface with warm water and use a mop (DO NOT use any abrasive
sponges).
Clean the surface with warm water and use a mop (DO NOT use any abrasive
sponges). Add household cleaners without abrasives to the warm water.

5
MAINTENANCE
Depending on the frequency of use, at least twice a month check all screws, bolts
etc. to ensure that they function properly. The fasteners are coated with adhesive
which is inactive until the coated fasteners are used. During assembly the adhesive
is activated. The adhesive can prevent the self-loosening of fasteners, but the effect
of the adhesive decreases with every assembly. Please do not remove the adhesive
from the fasteners.
Damaged or worn components may endanger your safety or shorten the lifespan of
the Teqball Smart table. Stop using the Teqball Smart table immediately and contact
us at [email protected].
Regular maintenance is essential to keep the Teqball Smart table safe and reliable. Lack of
maintenance or inadequate maintenance can lead to dangerous situations, accidents and
health problems.

6
WARNINGS
To safely enjoy playing TeqSports, please read and understand all the enclosed
instructions and information before using this product. Use the Teqball Smart table at
your own risk.
Each person who uses the Teqball Smart table must be informed about the following
safety instructions and about the proper use of the Teqball Smart table. Teqball Smart
table is a specially-designed piece of sports equipment and it is not suitable for any other
purposes. Never leave children unattended or uncontrolled in the vicinity of the Teqball
Smart table. Non-observance may cause damage or even accidents which the company
is not responsible for. Adult supervision applies to setting up and storing as well as
playing on the Teqball Smart table.
The Teqball Smart table must be set up properly and must only be
moved in the folded position. This is not only for a better
gameplay experience but for your safety as well. Please follow
these instructions:
Do not use the Teqball Smart table in extreme weather conditions.
Do not touch the Teqball Smart table in hot weather conditions, as it may heat up
and cause burn.
Avoid any damage of the playing surface and the supporting framework, otherwise
the lifetime of the Teqball Smart table shortens quickly.
Set up only on level floor surfaces. If the surface is not even,
the connecting parts may not fit together properly.
If one or more legs do not rest on the ground set the
adjustable feet or safely wedge the legs.
Moving or storing the Teqball Smart table on a sloping surface
may cause it to tip over, damage, or more seriously, lead to
injury. Take the necessary precautions.
Wind may cause the Teqball Smart table to tip over, damage,
or more seriously, cause personal injury. Take the necessary
precautions.

7
Teqball Smart table is a heavy product and improper use can cause injuries. Please be
aware of the following instructions:
It is strictly forbidden to sit, jump, or stand on the Teqball Smart table or any part of
it either when folded or unfolded.
Do not hit or kick the Teqball Smart table, specifically the edges, as it can cause
injuries.
Do not stay underneath or next to the Teqball Smart table and be careful of trapping
fingers while the tabletop is being lowered.
Do not lean or put your weight on the Teqball Smart table because of the risk of
collapse.
Damaged or worn components may endanger your safety. In this case, stop using
the Teqball Smart table immediately.
Do not replace defective parts yourself, and do not alter the construction (removal
of original parts, addition of other components etc.) because the Teqball Smart table
may become unstable and collapse, causing damage or injuries.
The failure of the safety lock may cause damage or injuries. In this case, leave the
Teqball Smart table in the game position and stop using it immediately.
Do not leave children unattended around the Teqball Smart table.
DO NOT LEAN OR PUT
YOUR WEIGHT ON THE TABLE
DO NOT STAY UNDERNEATH/NEXT TO THE TABLE DO NOT STAND OR SIT ON THE TABLE
DO NOT LEAVE CHILDREN
UNATTENDED AROUND THE TABLE

8
HANDLING
The Teqball Smart table must be set up properly. This is not only for better gameplay
experience but also for your safety. Please follow these instructions:
Lowering the tabletops
Lock the wheels. This prevents the unexpected movement of the Teqball Smart table.
Unlock the safety lock located on the back of the tabletop.
For singles games, lower the tabletop on one side to the game position. Make sure
you control the lowering and do not let the tabletop fall down or lift suddenly, as
this might cause injury or damage to your Teqball Smart table. If you do not feel
confident about lowering the tabletop, ask for help.
For doubles games, repeat the 2nd and 3rd steps on the other side.
1.
2.
3.
4.

9
GENTLY LOWER THE TABLETOP PUT IT GENTLY TO THE GROUND
3.
LOCK THE WHEELS
1.
UNLOCK THE SAFETY LOCK
2.
4.

10
Lifting the tabletops
Make sure that the wheels are locked. If they are not locked, lock both.
Lift the tabletop to the vertical position. Make sure you control the lifting and do not
let the tabletop fall down or lift suddenly, as this might cause injury or damage to
your Teqball Smart table. If you do not feel confident about lifting the tabletop, ask
for help.
Check that the safety lock is working properly. To check, try to move the tabletop
carefully without unlocking the safety lock. Do not leave the Teqball Smart table
until the safety locks are locked in place.
Before moving the Teqball Smart table repeat the 2nd and 3rd steps on both sides and
unlock the wheels. Do not leave the Teqball Smart table unattended with unlocked
wheels.
1.
2.
3.
4.

11
LIFT THE TABLETOP
CHECK THE SAFETY LOCK
LOCK THE WHEELS
1. 2.
3.
UNLOCK THE WHEELS TO MOVE
THEN LOCK AGAIN
4.

12
This warranty gives the Purchaser specific legal rights, and the Purchaser may have other
rights which vary from state to state.
Warranty period: 2 years’ warranty on tabletop (which includes 2 pieces of tabletops), 2
years’ warranty on net (which includes 1 piece of transparent PMMA plate), 2 years’
warranty on undercarriage (which includes 2 pieces of swivel wheels, 2 pieces of fixed
wheels, 2 pieces of gas springs,1 piece of left and right side console, 2 pieces of side wall
console, 2 pieces of side walls, 1 piece of mid console, 2 pieces of net fixing elements, 4
pieces of leg-connectors, 2 pieces of external legs, 2 pieces of safety lock elements I, 4
pieces of safety lock elements II, 2 pieces of connector elements, 4 pieces of sheet metal
elements I, 4 pieces of sheet metal elements II and 4 pieces of sheet metal elements III).
LIMITED 2 YEARS WARRANTY
Teqball International Limited (hereinafter: Company) warrants to the original retail
purchaser (hereinafter: Purchaser) that this product will be free from defects in material
and workmanship for a period of two (2) years from the date of purchase. Should this
product become defective due to material or workmanship within the warranty period,
contact our Customer Service Department for repair or replacement, which will be
provided free of charge at our discretion, www.teqball.com/warranty or at
[email protected].
This warranty is not transferable and does not cover normal wear and tear or damage
caused by improper handling, installation or use of this product. This warranty is void if
the product is
In any way abused, damaged, or modified from its original state, or if used for other
than residential use.
Damaged through improper usage, negligence, misuse, transportation damage,
acts of nature or accident (including failure to follow the instructions supplied with
the product).
Used in commercial applications or rentals.
Modified or repaired by anyone not authorized by the Company.

13
WHAT THE COMPANY WILL PAY FOR
If during the warranty period, any part or component of the product is found by the
Company to be defective, the Company will either repair the product, replace the
product with a new product (either the same or an equivalent or an upgraded model),
replace the defective part(s) or make the original retailer of the product exchange the
product with a new product (either the same or an equivalent or an upgraded model) or
refund the original purchase price of the product, without charge for labour or parts.
The Company’s obligation to repair, replace or exchange the product or part(s), however,
shall be limited to the amount of the original purchase price of the product.
The warranty is limited to defective parts acknowledged as faulty by the Company. The
warranty does not apply to damage caused by assembly not conforming to these
instructions, not complying with the instructions for use and safety, normal wear of
parts, lack of maintenance, use of aggressive products for maintenance, wind causing
the table to fall in the storage position and, more generally, a cause detrimental to the
quality of the table (impact, falls, etc.), damage to paintwork caused by climatic,
thermal, chemical or industrial pollution.
Any claim must indicate the type of table, the serial number that is to be found on the
underside of the tabletop and the part(s) in question, and it must be accompanied by a
proof of purchase showing the original date of purchase.

14
SPECIFIC WARRANTY CONDITIONS
Before using the Teqball Smart table in environments with constant extreme weather
conditions (extreme cold weather, extreme hot weather, corrosive environment near the
sea, etc.) please contact us at [email protected]. In this case a specific proposal is
given in order to safely enjoy the Teqball Smart table.
The defect must be reported as soon as it is discovered to [email protected].
This must be within the warranty period.
The defect must not be due to external influences such as damage, climatic, thermal,
chemical or industrial pollution, insufficient care or maintenance.
The defect must be reported as soon as it is discovered to [email protected].
This must be within the warranty period.
The defect must not have been caused originally by damage, neglect, insufficient care
or maintenance or by external corrosion (rusting).
The company must be advised about any rusting as soon as it is found at
[email protected].
Paint warranty
The Teqball Smart table is provided with a warranty for a period of 2 years from the date
of purchase against any manufacturing defects with the paintwork.
The only preconditions are:
Frame protection warranty
Teqball Smart table is provided with a warranty for a period of 2 years from the date of
purchase against corrosion.
The only preconditions are:

15
ENJOY TEQSPORTS!

Further information
www.teqball.com
[email protected]
