Philips HF3650 User manual

HF3650, HF3651,
HF3653, HF3654

2
1
11
10
1
9
7543 6
8

English 6
Кыргызча 23
Русский 41
Қазақша 59
Հայերեն 76

English
6English
Contents
Introduction ______________________________________________________________________________ 6
General description_________________________________________________________________________ 6
Intended use ______________________________________________________________________________ 7
The effects of the Sleep & Wake-Up Light______________________________________________________ 7
Important safety information ________________________________________________________________ 7
Safety and compliance ______________________________________________________________________ 9
Electromagnetic fields (EMF)_________________________________________________________________ 9
Interactive menu icons ______________________________________________________________________ 10
Navigating the menu _______________________________________________________________________ 11
Setting wake-up profiles ____________________________________________________________________ 11
Time + alarm back-up _______________________________________________________________________ 12
Snoozing__________________________________________________________________________________ 12
Dismissing the alarm________________________________________________________________________ 12
Using the Sleep & Wake-Up Light as a bedside lamp ____________________________________________ 13
Midnight Light _____________________________________________________________________________ 13
Settings ___________________________________________________________________________________ 13
Music _____________________________________________________________________________________ 15
Wind-down programs ______________________________________________________________________ 16
Charging your mobile phone ________________________________________________________________ 17
Cleaning and storage _______________________________________________________________________ 17
Recycling__________________________________________________________________________________ 18
Warranty and support ______________________________________________________________________ 18
Troubleshooting ___________________________________________________________________________ 18
Open-source and third-party software ________________________________________________________ 20
Specifications ______________________________________________________________________________ 20
Introduction
Congratulations on your purchase and welcome to Philips! To fully benefit from
the support that Philips offers, register your product at
www.philips.com/welcome.
The Philips Sleep & Wake-Up Light helps you wake up more pleasantly. If the
Sunrise Simulation is active, the light intensity of the lamp gradually increases to
the set level and the light color changes from deep morning red to bright
daylight. The light gently prepares your body for waking up at the set time. To
make waking up an even more pleasant experience, you can use natural wake-
up sounds or the FM radio* to wake up to.
*HF3653 does not feature a radio.
General description
1 Lamp housing
2 Display
3 USB charging port
4 Reset button
5 Radio antenna*
6 Adapter DC socket

7
English
7 Auxiliary (AUX) input
8 Speaker
9 Snooze/Midnight Light button
10 Adapter
11 Small plug
*HF3653 does not feature a radio.
Intended use
The Philips Sleep & Wake-Up Light is intended to give you a more natural and
refreshed wake up and a relaxed feeling before falling asleep.
This is not a general illumination product.
The effects of the Sleep & Wake-Up Light
The Philips Sleep & Wake-Up Light gently prepares your body for waking up
during the last 30 minutes of sleep. In the early morning hours our eyes are more
sensitive to light than when we are awake. During that period the relatively low
light levels of a simulated natural sunrise prepare our body for waking up and
getting alert.
People who use the Sleep & Wake-Up Light wake up more easily, have a better
overall mood in the morning and feel more energetic. Because the sensitivity to
light differs per person, you can set the light intensity of your Sleep & Wake-Up
Light to a level that matches your light sensitivity for an optimal start of the day.
To fully experience the effects of the Sleep & Wake-Up Light, place the appliance
at approximately 16in. –20in. / 40cm –50cm from your head, on a flat stable
surface of your bedside table.
For more information about the Sleep & Wake-Up Light, see www.philips.com.
Important safety information
Read this important information carefully before you use the appliance and save
it for future reference.
Danger
-Water and electricity are a dangerous combination. Do not use this appliance
in wet surroundings (e.g. in the bathroom or near a shower or swimming
pool).
-Keep the adapter dry.
-Do not let water run into the appliance or spill water onto the appliance.
-Do not immerse the appliance in water or rinse under the tap.
-Do not place anything close to the appliance that could cause water or any
other liquid to drip or splash onto the appliance.
-This appliance is for indoor use only.
-The adapter contains a transformer, which converts an unsafe
100V–240VAC mains voltage to a safe 24VDC low voltage. Do not cut off
the adapter to replace it with another plug, as this causes a hazardous
situation.

8English
Warning
-Never use the appliance if the lamp housing is damaged, broken or missing.
-If the adapter, cord or appliance has been damaged in any way, liquid has
spilled or objects have fallen into and/or onto the appliance, the appliance
has been exposed to rain or moisture, does not operate normally or has been
dropped or damaged, it should not be operated.
-If you feel uncomfortable at any point while using RelaxBreathe in the
breathing exercise, just go back to breathing normally.
-Only use the appliance in combination with the adapter supplied.
-If the adapter is damaged, always have it replaced with one of the original
type in order to avoid a hazard.
-This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
-Consult your doctor before you start using the appliance if you have suffered
from or are suffering from depression.
-Do not use this appliance as a means to reduce your hours of sleep. The
purpose of this appliance is to help you wake up more easily. It does not
diminish your need for sleep.
Caution
-Check if the voltage indicated on the appliance corresponds to the local
voltage before you connect the appliance.
-Protect the power cord from being walked on or pinched, particularly at
plugs, wall sockets and points where it exits from the lamp.
-Do not use the adapter in or near wall sockets that contain an electric air
freshener to prevent irreparable damage to the adapter.
-Do not drop the appliance on the floor, hit it hard or expose it to other heavy
shocks.
-Place the appliance on a stable, level and non-slippery surface.
-Do not impair the cooling of the appliance by covering the appliance with
items such as blankets, curtains, clothes, papers, etc.
-Do not use the appliance at room temperatures lower than 5°C or higher
than 35°C.
-The appliance has no on/off switch. To disconnect the appliance, remove the
adapter from the socket-outlet. The adapter and socket-outlet shall remain
easily accessible at all times.
-This appliance is only intended for household use, including similar use for
instance in hotels.
-No naked flame sources, such as lighted candles, should be placed on the
appliance.
-The LEDs inside this Wake-Up Light are not replaceable, when they reach
their end of life the whole Wake-Up Light shall be replaced.
General
-If you often wake up too early or with a headache, reduce the set light
intensity level and/or the set sunrise simulation time.

9
English
-If you often wake up by the alarm sound, increase the set light intensity level
or the set sunrise simulation time.
-If you share a bedroom with someone else, this person may unintentionally
wake up from the light of the appliance, even though this person is further
removed from the appliance. This phenomenon is the result of differences in
light sensitivity between people.
-The power consumption of the appliance is lowest if no device is connected
to the USB port and the lamp, radio and display are turned off.
Safety and compliance
This appliance meets the safety requirements in the EU for:
-IEC 60598: Luminaires.
-IEC 62368: Audio/video, information and communication technology
equipment.
-IEC 62471: Photobiological safety of lamps and lamp systems.
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable standards and regulations
regarding exposure to electromagnetic fields.

10 English

Interactive menu icons
Wake-up profile/Alarm Light intensity and light
on/off
Enable shortcuts
Settings Sounds Confirm and save
setting
Wind-down program AUX inlet Clock time
Select natural sound Select radio preset Change alarm settings
Display settings Display brightness Keep light on
Enable display timeout Disable display timeout Keep light off
Enable audio feedback Disable audio feedback Alarm toggle on/off
Sunset simulation Duration of the wake-up
profile
Dismiss alarm
Light or sound guidance RelaxBreathe Edit wake-up profile
RelaxBreathe pace Duration of relaxation
program
Deactivate alarm
Return to a higher level in the
menu

11
English

Navigating the menu
On the display you can select and set the wake-up profile, bedside light, settings,
sound (source) or the unwind program.
Note: All your personalized settings and profiles will be permanently stored in
the memory, they will not be erased by removing the adapter from the electrical
outlet. You can change all settings at any time, the last setting will be stored.
Note: If the display is blank, move your hand towards the lower part of the Sleep
& Wake-Up Light to show the display menu. You will see the menu buttons.
Setting wake-up profiles
Press the Wake-up/Alarm icon to start setting a wake-up profile.
Note: Press and hold the alarm button for 1 second to deactivate all set alarms at
once.
You can set two different wake-up profiles. For each profile you can set the
alarm time, the light intensity, the wake-up curve duration, and the type of
wake-up sound and its volume.
Note: The set alarm will automatically go off at the same time every day until you
deactivate the alarm by first pressing the alarm toggle icon and then the
deactivate alarm icon to deactivate the alarm.
Light intensity of the wake-up profile
The lamp of the appliance simulates a sunrise. Like a sunrise, the brightness of
the lamp increases gradually. During this wake-up curve, the color of the light
changes from soft red to warm orange to bright yellow.
Press icon on the display to choose one of the 25 light intensity levels.
Note: The main display of the appliance shows if the alarm has been set.
Duration of the wake-up profile
Press this icon to open the menu.

12 English
The default duration of the wake-up curve (brightness increase to the set
maximum light intensity) is 30 minutes. Press icon to change the duration of
the wake-up profile to your preference.
Press + or - to increase or decrease the brightness of the light in the wake-up
curve.
Type of sound
Press this icon to open the sounds menu to set the sound of the wake-up profile.
1Press the toggle icon to choose one of the three sounds options: a natural
sound, radio* or no sound.
2Press the natural sound icon to select one of the natural sounds or press
the radio icon to select one of the radio presets.
3You can set the volume with the loudspeaker icon .
*HF3653 does not feature a radio.
Time + alarm back-up
In the event of a power failure, all functions of the appliance, including the
display, do not work. However, the internal clock and a back-up alarm remain
active for at least 8 more hours.
If during the power failure the set alarm time is due, a back-up alarm goes off
generating a beeping sound for approximately 30 seconds.
Snoozing
When the wake-up curve has ended (when the set maximum light intensity has
been reached) and the alarm sound is playing, you can tap the top of the
appliance to snooze.
The lamp stays on, but the sound is muted. After 9 minutes, the alarm sound
starts playing again.
Note: The light and sound automatically turn off 60 minutes after the alarm has
gone off or 60 minutes after the last snooze action.
Dismissing the alarm
When the wake-up curve is active or the alarm goes off, you can dismiss it by
pressing this icon on the appliance. If you dismiss the alarm, the alarm profile is
deactivated for that day.

13
English
Using the Sleep & Wake-Up Light as a bedside
lamp
You can use the Sleep & Wake-Up Light as a bedside lamp.
Press this icon on the display to switch on the bedside lamp.
Note: Long-press the lamp icon to switch off the bedside lamp.
You can increase and decrease the brightness of the light. You can select a
brightness level between 1 (low) and 25 (high). The default brightness level is 20.
Note: To switch off the bedside lamp, press the cross button in the menu.
Tip: When the light is on, you can also turn off the light with a single tap on top
of the Sleep & Wake-Up Light. All active programs will stop. Set alarms are still
active.
Midnight Light
If you wake up during the night, you can tap the top of the appliance to activate
a dim light. This dim, subtle orange light provides you with just enough light to
find your way in the dark. Switch off the Midnight Light by tapping the top of
the appliance again.
Note: The Midnight Light cannot be activated directly when the main light is
already on. In that case, first tap the top of the appliance to deactivate the main
light. Then tap again to activate the Midnight Light.
Settings
Press the settings icon to open the settings menu.
In the settings menu, you can adjust the clock time, the display settings and the
alarm settings.

14 English
Time
Press this icon to open the time menu.
In this menu you can change the time by pressing + or -.
Press the time notation icon to toggle between the 12-hour clock and 24-hour
clock.
Display settings
Press the display settings button in the settings menu to set the display settings.
In the display settings menu, you can deactivate and reactivate the audio
feedback, adjust the display brightness, switch the display on or off and select
shortcuts.
Audio feedback
If you do not want to hear clicks when you press an icon, press the audio
feedback icon to turn off the audio feedback. You hear one click as a
confirmation.
To reactivate the audio feedback, press this icon .
Display brightness
You can adjust the display brightness from level 1 to level 6. Choose a level that
is optimal for you to see the display at night. The appliance automatically adjusts
the display brightness when the light in your bedroom changes.
Display timeout
If you do not want the appliance to produce any light, not even from the time
indication, press the display timeout icon.
Normally, if you do not touch the display for some time in any menu, the display
reverts to time and status indication only. When the display timeout is activated,
no time indication is shown.
Press the the display timeout icon to turn on the display again.
Tip: If you want to check the time or select a function while the display timeout is
activated, just place your hand near the display to turn it on for a few seconds.

15
English
Shortcuts
Press the shortcuts icon to get quick access to five key functions right from the
main screen, so you can immediately turn on the light, have access to alarm and
sound menus as well as the wind-down programs.
Alarm settings
The light switches off when you dismiss the alarm.
If you do not want this, press this icon in the alarm settings menu and save the
setting to ensure that the light stays on after you dismiss the alarm.
Music
Tip: When the radio or music is on, you can turn off the sound with a single tap
on top of the Sleep & Wake-Up Light. All active programs will stop. Set alarms
are still active.
Listening to radio*
You can listen to the FM radio with the Sleep & Wake-Up Light. If you selected
the radio function in the sounds menu, it shows the selected radio station. You
can manually change the radio station by selecting the FM frequency of another
radio station.
Tip: Make sure to unwind the antenna fully and move it around until you receive
the best reception.
You can preset 5 radio stations. First, select a radio station by setting the FM
frequency. Press and hold the double arrow button to automatically search for
the next radio station.
After setting a radio station, you can easily add another preset radio station by
selecting the toggle button. With this process, you can preset 5 radio stations.
Set the preferred volume with the loudspeaker button.
Note: To save your settings, select the check mark button
*HF3653 does not feature a radio.

16 English
Music via Auxiliary (AUX) inlet
You can use the Sleep & Wake-Up Light as a speaker for music by connecting a
music playing device (for instance your mobile phone) to the AUX inlet.
Note: You cannot wake up to music from a device connected to the AUX inlet.
If the sound is not loud enough when you have set the Sleep & Wake-Up Light to
maximum volume, increase the volume of your music playing device.
If the sound is too loud or distorted when you have set the Sleep & Wake-Up
Light to a low volume setting, decrease the volume of your music playing device.
Note: Press and hold the music note icon to activate/deactivate the sound via
the menu. You can also deactivate the sound by tapping the top of the
appliance.
Note: You need an AUX cable to connect the Sleep & Wake-Up Light to a music
playing device.
Wind-down programs
The appliance features two wind-down programs to help you relax before you
fall asleep.
Note: You can deactivate the active wind-down program by tapping the top of
the appliance.
Sunset Simulation
During the Sunset Simulation, the brightness of the light decreases gradually
with colors changing from bright yellow to warm orange to soft red. You can set
the duration of the sunset simulation and the initial light intensity of the sunset
simulation.
You can also select a sound that fades away during the sunset simulation. You
can set the sound source and the initial volume. You can either choose a natural
sound, radio* or no sound. You can also play your own music by connecting a
music playing device to the AUX socket.
*HF3653 does not feature a radio.
RelaxBreathe
RelaxBreathe uses the belly breathing technique as a basis for the breathing
program. You can choose one of the breathing programs, guided by light or
sound. The combination of the belly breathing exercise and the guidance of the
Sleep & Wake-Up Light helps you slow down and feel relaxed.
You can select one of seven relaxation programs with preset breathing pace.
Each relaxation program has a different breathing pace. The '4 breaths' program
is preset to 4 breaths per minute. The '5 breaths' program is preset to 5 breaths
per minute. Each next program has one additional breath per minute. The last
program (10 breaths) is preset to 10 breaths per minute.

17
English
You can select light or sound to guide you during the selected relaxation
program. Follow the light or sound when you inhale and exhale.
-For guidance with light, inhale when the light intensity increases. In between
the two subtle light flashes, hold your breath. Exhale slowly when the light
intensity decreases.
-For guidance with sound, inhale when the intensity of the sound of the waves
increases. When the intensity of the sound pauses, hold your breath. Slowly
exhale when the intensity of the sound of the waves decreases.
Follow your preferred pace with the help of light or sound for a more relaxed
feeling. You can even do this with your eyes closed.
Press this icon to set the duration of the relaxation program. You can select a
duration of 5, 10 or 15 minutes.
Belly breathing for relaxation
Belly breathing is the most recognized breathing exercise technique to help
people relax. When you breathe from your belly, your diaphragm pulls down
automatically. This pulls down your lungs and allows you to inhale fully and
deeply.
Caution: If you feel uncomfortable at any point during this breathing
exercise, just go back to breathing normally.
How to do belly breathing
1Lie down comfortably on your back.
2Inhale through your nose, exhale through your nose or mouth.
3Place one hand on your stomach and your other hand on your chest.
You should see your hand on your stomach move up with each inhale and
move down with each exhale. The hand on your chest should only move
slightly.
4Your breath should only come from your belly. Try to make your exhale
longer than your inhale as this will quickly make you feel more relaxed.
Note: The RelaxBreathe function of the appliance can guide you during belly
breathing.
Charging your mobile phone
You can use the USB port (see 'General description') to charge your mobile
phone (max 1A).
Cleaning and storage
-Clean the appliance with a soft cloth.
-Do not use abrasive cleaning agents, pads or cleaning solvents like alcohol,
acetone, etc., as this may damage the surface of the appliance.

18 English
-If you are not going to use the appliance for an extended period of time,
remove the adapter from the wall socket and store the appliance in a safe,
dry location where it will not be crushed, banged, or subjected to damage.
-Do not wrap the power cord around the appliance when storing it.
Recycling
-This symbol means that this product shall not be disposed of with normal
household waste (2012/19/EU).
-Follow your country's rules for the separate collection of electrical and
electronic products. Correct disposal helps prevent negative consequences for
the environment and human health.
Warranty and support
If you need information or support, please visit www.philips.com/support or
go to your Philips dealer. You can also contact the philips Consumer Care Center
in your country (see the international warranty leaflet for contact details).
Troubleshooting
This chapter summarizes the most common problems you could encounter with
the appliance. If you are unable to solve the problem with the information
below, visit www.philips.com/support for a list of frequently asked questions
or contact the Consumer Care Center in your country.
Problem Solution
The appliance does not
work at all.
Perhaps the adapter is not inserted properly in the wall socket. Insert the
adapter properly in the wall socket.
Perhaps the plug is not inserted properly in the appliance. Insert the plug
properly in the appliance.
Perhaps there is a power failure. Check if the power supply works by connecting
another appliance.
The appliance functions
properly, but the lamp
does not work anymore.
The appliance uses durable LED technology. The lamp should last a long time.
However, if the lamp stops working, go to www.philips.com/support or
contact the Consumer Care Center.
The appliance does not
respond when I try to set
different functions.
If you want to go back to factory settings, press the reset button on the back of
the appliance (see 'General description'). If you press the reset button, the setup
wizard needs to be set again.
The lamp does not go on
when the alarm goes off.
Perhaps you set a light intensity level that is too low. Increase the light intensity
level in your wake-up profile.
Perhaps you turned off the alarm function. The alarm icon is visible on the
display when the alarm function is active.

19
English
Problem Solution
The lamp does not go on
right away when I switch
it on.
It may take between 1 to 5 seconds for the lamp to switch on, depending on the
set light intensity level.
I do not hear the alarm
sound when the alarm
goes off.
Perhaps you set a sound level that is too low. To set a higher sound level,
increase the volume level of the wake-up sound in your wake-up profile.
When you have set an alarm, you will first see the light of the wake up curve.
The alarm sound only starts playing when the set alarm time is reached. You can
change the duration of the wake up light curve.
Perhaps you turned off the alarm function. The alarm icon is visible on the
display when the alarm function is active.
If you selected the FM radio* as the alarm sound, turn on the FM radio* after
you turn off the alarm to check if the FM radio* works.
Check if your FM radio* is correctly tuned to a radio station. If necessary, adjust
the frequency. If it does not work, contact the Consumer Care Center in your
country.
The FM radio* does not
work.
Perhaps you set the volume too low. Increase the volume level.
Check if your FM radio* is correctly tuned to a radio station. If necessary, adjust
the frequency.
Change the position of the antenna by moving it around. Make sure you have
unwound the antenna completely.
Contact the Consumer Care Center in your country.
The FM radio* produces a
crackling sound.
Perhaps the broadcast signal is weak. Adjust the frequency and/or change the
position of the antenna by moving it around. Make sure you have unwound the
antenna completely.
The alarm went off
yesterday, but it did not
go off today.
Perhaps you turned off the alarm function. The alarm icon is visible on the
display when the alarm function is active.
Perhaps you set a volume level and/or light intensity level that is too low. Set a
higher volume and/or light intensity level in your wake-up profile.
When there has been a power failure, the clock time will keep on running up to
8 hours. Perhaps the power failure lasted longer. In this case, you have to set the
clock time again.
I wanted to snooze, but
the alarm did not go off
again after 9 minutes.
Tap on the top of the Sleep & Wake-Up Light to snooze. If you press the button
to dismiss the alarm, the alarm profile is deactivated for that day.
The light wakes me too
early.
Perhaps the light intensity level you have set is not appropriate for you. Try a
lower light intensity level if you wake up too early. You can also change the
duration of the wake-up curve. If light intensity 1 is not low enough, move the
appliance further away from the bed.

20 English
Problem Solution
The light wakes me too
late.
Perhaps the light intensity you have set is too low. Select a higher light intensity.
Perhaps the appliance is positioned at a lower level than your head. Make sure
the appliance is located at a height at which the light is not blocked by your bed,
comforter, blanket or pillow. Also make sure the appliance is not placed too far
away.
I am unable to turn the
Midnight Light function
on/off.
Make sure you tap on the correct position (top/back) of the appliance.
I am unable to stream
music via USB.
The USB connection is only for charging your mobile phone. You are not able to
stream music to the Sleep & Wake-Up Light.
The AUX inlet doesn't
work properly.
Try to set the volume on your mobile phone either higher or lower. If necessary,
adjust the volume level on the appliance as well.
Suddenly the device
makes a beeping sound.
The backup alarm went off. The internal clock and the back-up alarm remain
active for at least 8 hours. If an alarm is due during this back-up period, it will go
off. The alarm sound stops automatically after approximately 30 seconds. You
also can stop the alarm sound immediately by connecting the appliance to the
power briefly.
To prevent the back-up alarm from going off when the power is disconnected
(e.g. during storage), disable the alarms before you disconnect the appliance
from the power.
*HF3653 does not feature a radio.
Open-source and third-party software
A copy of the open-source software and third-party commercial software license
agreement can be found on the website www.philips.com/support
Search for the device number HF3670 / HF3671 / HF3672 / HF3650 / HF3651 /
HF3652 / HF3653 / HF3654 on the technical documentation page of the
product.
Specifications
Adapter
Manufacturer PHILIPS
Type number HF20
Rated input voltage 100 V– 240V AC
Rated input frequency 50 / 60Hz
Rated output voltage 24.0V DC
Rated output current 0.75A
Rated output power 18.0W

21
English
No-load power < 0.1W
Efficiency class VI
Safety classification Class II power supply
Dimensions
(height x width x depth)
35 x 78 x 66 mm (1.38 x 3.07 x 2.6 in.) for EU version
50 x 78 x 56 mm (1.97 x 3.07 x 2.2 in.) for UK version
Weight Approx. 0.12kg (4.2oz.) for EU version
Approx. 0.13 kg (4.6 oz.) for UK version
Cord length Approx. 150cm (4.9ft)
Main unit
Manufacturer PHILIPS
Type number HF3650, HF3651, HF3653, HF3654
Rated input voltage 24V DC
Rated input current 0.75A
Rated input power 18W
Standby power appliance
(main unit + adapter)
Conditions: night (12 h / 0 lux), day (12 h / 500 lux), all functions
suspended
< 0.5W (display at maximum brightness)
< 0.25W (display off)
Safety classification Class III luminaire
Dimensions
(height x width x depth)
Approx. 225 x 220 x 120mm (8.86 x 8.66 x 4.72in.)
Weight Approx. 0.79kg (27.9oz.)
Ports
USB charging 5V DC, 1A
AUX sensitivity 280 mV
Light
Light output (level 1 – 25) Approx. 1 lux – 350*lux at 45cm (approx. 1 lux – 350*lux
at 17.7in.)
*depending on model
Light color (level 1 – 25) Approx. 1500 K – 2800K
FM

22 English
FM-radio frequency band
(HF3653 does not have a radio)
87.5MHz – 108.0MHz
Operating conditions
Temperature 5 °C to 35 °C (41 °F to 95 °F)
Relative humidity 20 % to 90 % (no condensation)
Atmospheric pressure 86 kPa to 106 kPa
Storage conditions
Temperature -20 °C to 50 °C (-4 °F to 122 °F)
Relative humidity 20 % to 90 % (no condensation)
Atmospheric pressure 86 kPa to 106 kPa
