Terminix AllClear 2000 EDITION User manual

2000 EDITION
OPERATOR’S MANUAL
1-888-9NO-BITE
www.terminixallclear.com
Covered by one or more of U.S. Patent
6,951,073 and patents pending

READ AND SAVE THESE INSTRUCTIONS
QUESTIONS OR COMMENTS
Please contact Universal Pest Solutions if you have
any questions about your TERMINIX®ALLCLEAR®
Cordless Mosquito Mister at:
1-888-9NO-BITE or www.terminixallclear.com
Universal Pest Solutions, LP
5950 Berkshire Lane, Suite 400
Dallas, TX 75225

3
TABLE OF CONTENTS
Safety Information and Instructions .................................4
Product Registration..........................................................4
Repair and Service ............................................................4
Mister Description.............................................................5
Mister Set-Up ....................................................................6
Charging & Recharging the Battery.......................6
Filling the Tank.......................................................7
Operation...........................................................................8
Positioning the Mister ...........................................8
Activating Mist Cycle......................................9 & 10
Storage and Winterization ................................................10
Troubleshooting.................................................................11
Frequently Asked Questions..............................................12
Warranty............................................................................13
INTRODUCTION
Congratulations on your purchase of the TERMINIX®ALLCLEAR®
Mosquito Mister, the only portable mosquito control device
that when used with ALLCLEAR Mosquito Mister Concentrates
delivers immediate and reliable control of mosquitoes and other
small biting insects* in your yard. The TERMINIX ALLCLEAR
Mosquito Mister’s patented misting technology delivers a
3-minute, ultra-fine mist that creates a barrier of biting insect
protection of up to 2,000 sq. ft. for as long as 6 hours.**
Together, the TERMINIX ALLCLEAR Mosquito Mister and
ALLCLEAR Concentrates quickly kill and repel mosquitoes and
other biting insects, giving you and your family the freedom
and confidence to enjoy hours of outdoor activities without the
annoyance of biting insects.
Incorporate the TERMINIX ALLCLEAR products into your complete
mosquito management program. Enjoy and use responsibly.
* Other insects include: ticks, gnats, horse flies, stable flies, deer flies, face flies and others.
** When used with ALLCLEAR PLUS Concentrate. Results may vary based on environmental factors such as rain, wind, sunlight, temperature, and humidity.

4
PLEASE READ ENTIRE OPERATOR’S MANUAL AND ALLCLEAR CONCENTRATE
LABEL BEFORE PLACING AND OPERATING YOUR TERMINIX ALLCLEAR
MOSQUITO MISTER.
GENERAL
• TERMINIX ALLCLEAR Mosquito Mister is designed for use ONLY with
ALLCLEAR Mosquito Mister Concentrates. (Not Included. Sold Separately.)
• Important: read and follow ALLCLEAR Mosquito Mister Concentrate label
completely before use.
• For outdoor use only.
OPERATIONAL
• Operate Mister when needed and when mosquitoes are most active –
typically dawn and dusk.
• For optimal results, avoid using the Mister during high winds (>10 mph),
heavy rainfall, fog, or when outside air temperatures fall below 50 degrees
Fahrenheit.
• Charge battery indoors, in a dry location, and away from outdoor elements.
• Be a good neighbor — some individuals may have sensitivities to pesticides
or object to them drifting onto their property.
Universal Pest Solutions is committed to excellent quality and
service. If you have any questions about your TERMINIX ALLCLEAR
Mosquito Mister or require replacement parts, please contact us at:
1-888-9NO-BITE or 1-888-966-2483 or visit our Web site at:
www.terminxallclear.com
Please have serial number ready when calling customer service.
Serial number is located on the bottom of the battery pack.
Record Serial Number here: _____________________________
Go online and register your TERMINIX ALLCLEAR
Mosquito Mister today!
Why Register?
• Activate Mister warranty
• Provide valuable product feedback
• Choose to review special offers and tips
• Chance to win free product!
To register go to www.terminixallclear.com.

5
R
R
2000 EDITION
OPERATOR’SMANUAL
1-888-9NO-BITE
www.terminixa llclear.com
CoveredbyoneormoreofU.S.Patent
6,951,073andpatentspending
Tank Cap
Battery Pack
Power/Mister Button
Naturals™
Concentrate
Synergized PLUS
Concentrate
Mister designed for use ONLY with ALLCLEAR
Concentrates. For more information about
concentrates or where to purchase, visit:
www.terminixallclear.com

6
IMPORTANT TIPS
• Before first use and at the start of
each season, charge Battery Pack
for 4 hours. Allow approximately
2 to 4 hours for later battery
charges.
• Recharge battery when Recharge
Battery light on Battery Pack is lit.
• Fully charged, Mister battery will
operate for approximately 15 mist
applications before needing to be
recharged.
• User can charge Mister Battery
Pack for 10 minutes to get one
mist application before recharging
fully.
• Battery may be recharged at any
time without harming the battery.
• Charge battery fully before storing
for the winter.
CHARGING & RECHARGING THE BATTERY
Charge the Battery Pack for 4 hours or until light on Charging Adapter is Green. Fully charged, battery will operate
for approximately 15 mist applications before needing to be recharged. To charge Mister battery:
1. Locate Battery Pack at rear base of Mister.
2. Place hand under Battery Pack, squeeze latch, and pull Pack outward to remove.
3. Insert Battery Charging Adapter cord into Battery Pack Charge Port.
4. Charge Battery Pack for 4 hours or until light on Charging Adapter is Green.
5. Unplug Adapter from Battery Pack and reinsert Pack into base of Mister. Battery Pack is fully inserted if
power light illuminates when green Power/Mist button is pressed.
NOTE: When light on Charging Adapter is Green, battery is fully charged and Mister is ready for use. If light on
Adapter is Red, charge battery for at least 4 hours or until the light is Green. If Recharge Battery light is on,
charge battery as directed above.
Battery Pack Charge Port
Recharge Battery Light

7
IMPORTANT TIPS
• The TERMINIX ALLCLEAR Mosquito
Mister is designed for use ONLY
with ALLCLEAR Mosquito Mister
Concentrates. Not Included.
Sold Separately.
• Refill Mister only when Tank is
completely empty and/or when
solution level is below Refill indicator
on front of tank. This prevents
incorrect solution mix which could
affect operation.
TRANSPORTING MISTER IN A
VEHICLE
The Mister can be transported in a car
or other vehicle. When possible, empty
Tank. To transport:
1. Securely fasten Tank Cap.
2. Position Mister upright in vehicle
to prevent leaking of solution from
Tank Cap if tank is not empty.
3. Secure Mister to prevent
movement when vehicle is in
motion.
FILLING THE TANK*
1. Remove Tank Cap from the top of the unit by pushing down and turning Cap
counterclockwise.
NOTE: Beneath Tank Cap is a Filter. Leave in place when filling Tank. As needed, remove filter and
rinse clean with water. After rinsing, replace filter in tank opening.
2. Slowly fill Tank with water to the ‘1/2’ full indicator (see Mister front panel). For
best results use a garden hose or watering can.
3. Slowly add one entire bottle of ALLCLEAR Concentrate. (Before adding
Concentrate, read Concentrate instructions carefully.)
4. Slowly finish filling Tank with water until solution level reaches bottom of filter.
Be sure to fill Tank slowly to avoid foaming of solution.
5. Replace Tank Cap.
*NOTE: When filling for the first time, users may want to test with water only. Be sure
to fill Mister all the way.

8
POSITIONING THE MISTER
Proper placement of the Mister is
important for optimal insect control.
In certain situations, users may
need to mist more than once and/or
move the Mister to another location
to achieve optimal results (see
Important Tips).
1. Determine area to be protected.
2. Pull up on Mister Handle and
roll into desired coverage area.
3. Establish direction of prevailing
wind and position Mister
according to wind conditions
(see illustrations).
EXAMPLE:
Treating a patio area. Determine
prevailing wind. Depending on
wind direction, place Mister on
either side of, in the center of, or
a few feet beyond center of patio
so that prevailing winds will carry
mist solution directly over patio and
surrounding areas.
IMPORTANT TIPS
• Mister performs best if positioned
and activated inside of or near
desired coverage area.
• For optimal control, users may
need to mist an area more than
once and/or move the Mister to
another part of the treatment area
in the following situations:
• Areas of very heavy
mosquito populations
• Areas planned for large
gatherings (more people
bring increased mosquito
activity)
• Areas where wind is idle
since solution may not
be carried as far into
treatment area
• Operate Mister daily for optimal
results.
Position Mister at edge
of desired coverage
area with Mister nozzles
facing mist area so that
prevailing wind will carry
mist solution over target
area.
Position Mister in the
center of desired coverage
area so that the wind will
carry mist solution equally
throughout desired
coverage area.
Position Mister in
the center of desired
coverage area or a few
feet beyond center of
coverage area.
SINGLE DIRECTIONAL WIND
YOUR DESIRED
COVERAGE AREA
MULTI-DIRECTIONAL WIND
YOUR DESIRED COVERAGE AREA
IDLE WIND
YOUR DESIRED COVERAGE AREA

9
IMPORTANT TIPS
• Operate Mister daily for optimal
results.
• Mister will automatically power
OFF after 10 minutes of inactivity
• Users will experience immediate
relief from biting insects. Best
results are realized 10-15 minutes
after misting.
• In areas of high mosquito
populations or in situations where
many people are inside coverage
area, additional mist applications
may be necessary.
• Avoid using Mister during
high winds (>10 mph), heavy
rainfall, fog, or when outside
air temperatures fall below 50
degrees Fahrenheit or other times
when insects are typically not
active.
ACTIVATING MIST CYCLE
WHEN TO ACTIVATE:
The TERMINIX ALLCLEAR Mosquito Mister can be used any time of day to provide immediate and reliable control
of mosquitoes, gnats, ticks, and other biting insects for up to 6 hours in an area of up to 2,000 sq. ft.* It is
recommended that users activate Mist Cycle 10 to 15 minutes before spending time outdoors to allow for mist
solution to take maximum effect (especially when mosquitoes are most active). See ALLCLEAR Concentrate label
and/or go to www.terminixallclear.com for additional application instructions.
WHAT TO EXPECT:
The TERMINIX ALLCLEAR Mosquito Mister mists an ultra-fine solution of water and ALLCLEAR Mosquito Mister
Concentrate. The mist solution is atomized out from Mister and carried by the wind into desired coverage area.
During the 3-minute Mist Cycle, the mist appears like a light fog and is visible for the first 5-10 feet from the
machine. Even when no longer visible, mist continues to move throughout the coverage area creating an invisible
barrier of protection from biting insects for hours. Users will experience immediate relief from biting insects. Best
results are realized 10-15 minutes after misting. In areas of high mosquito populations or when there is a large
gathering, such as a party, additional mist applications may be necessary.
Depending on weather and wind conditions, mist may swirl high and low around Mister and/or it may move
directly out from unit or drift behind Mister during Mist Cycle. This is normal operation. If mist moves toward an
undesired area, stop Mist Cycle with Remote Control, allow mist to dissipate, and reposition Mister so mist is
carried by wind into desired area. (See page 8 for ‘Positioning the Mister’ instructions.)
* When used with ALLCLEAR PLUS Concentrate.
Other insects include: ticks, gnats, horse flies,
stable flies, deer flies, face flies and others.
ACTIVATING WITH REMOTE CONTROL
1. Press green Power/Mist Button on back of Mister once to turn unit ON. System Power light on
Battery Pack will flash indicating unit is ON.
NOTE: Mister will automatically power OFF after 10 minutes of inactivity.
2. Press and HOLD for one second Remote Control ON button.
3. Mister begins a 12 second audible countdown before 3-minute Mist Cycle begins.
4. Watch mist movement to ensure mist moves toward desired area.
NOTE: If mist moves toward an undesired area, stop Mist Cycle by pressing OFF button once on Remote Control device.
5. Mist Cycle automatically ends after 3 minutes.
6. If needed, move or reposition Mister (see page 8).
CAUTION: Store Remote Control device in an area inaccessible to children.

10
During months when outdoor temperatures fall below 40°F, store Mister in a sheltered location away from
outdoor elements and in an area with temperatures above freezing (32°F, 0°C). When storing Mister for
extended periods of time, store with an empty Tank.
1. To empty Tank, use all misting solution as per recommended operating instructions.
2. Charge battery fully before storing for the winter and/or long periods of non-use.
3. Roll and store Mister in a sheltered location with temperatures above freezing (32°F, 0°C).
4. While in storage, charge Mister battery every two months for optimal battery life.
ACTIVATING DIRECTLY FROM MISTER
1. Press green Power/Mist Button on back of Mister once to turn unit ON. System Power
light on Battery Pack will flash indicating unit is ON.
NOTE: Mister will automatically power OFF after 10 minutes of inactivity.
2. Press and HOLD green Power/Mist Button for 3 seconds until Mister begins to beep.
NOTE: 3 second ‘Press and HOLD’ feature is intended to prevent accidental activation from
unauthorized users.
3. Follow Steps 4 through 6 on page 9.
TO STOP MIST CYCLE
Option 1: Use Remote Control device to stop unit before or during Mist Cycle by pushing the OFF button once on the Remote Control device.
Option 2: Before misting begins push green Power/Mist Button on Mister once to stop Mist Cycle.
NOTE: If Mister is stopped, it will reset to original settings. The next time Mister is activated it will begin a new 3-minute Mist Cycle with a
12 second delay and audible warning beep.

11
PROBLEM
Mister is not misting after
pushing green Power/Mist
button
1. Not pressing and holding the green Power/Mist button for 3 seconds
2. Mister Battery is low
3. Mister Tank empty
4. None of the above
1. Press and Hold Power/Mist button for 3 seconds
2. Remove Battery Pack and charge battery (page 6)
3. Check solution level on front of Tank. Fill Tank if empty.
4. Contact Customer Service at 1-888-9NO-BITE
Remote Control device will
not operate Mister
1. Mister is not powered ON
2. Not pressing Remote's ON button for at least ONE second
3. Remote Control batteries are low
4. 'Possible Causes' 2 & 3 in above section
5. Remote Control is not functioning
6. None of the above
1. Press Power/Mist button once to power ON
2. Press and hold Remote ON button for one full second
3. Replace Remote Control batteries (CR2032 or equivalent)
4. Try steps 2 & 3 in above section
5. Try activating Mister directly from the unit
6. Contact Customer Service at 1-888-9NO-BITE
Mister will not Power ON after
pushing green Power/Mist button
1. Mister Battery is low
2. Battery Pack is not pushed in far enough
3. None of the above
1. Remove Battery Pack and charge battery (page 6)
2. Push Battery Pack until it “clicks” into place
3. Contact Customer Service at 1-888-9NO-BITE
Mister is not controlling
mosquitoes/other biting insects
1. Mister is not positioned properly
2. Tank is empty/solution low
3. Mister solution needs to be agitated
4. Concentrate and water dilution is incorrect
5. None of the above
1. See page 8 for 'Positioning the Mister'
2. Check solution level on front of Tank. Fill if empty.
3. Gently rock Mister back and forth for 10 seconds
4. See page 7 for proper filling instructions
5. Contact Customer Service at 1-888-9NO-BITE
Only 1 or 2 nozzels are misting 1. Nozzels may be loose
2. Clogged nozzels
1. Hand-tighten nozzles
2. Contact Customer Service at 1-888-9NO-BITE
POSSIBLE CAUSE SOLUTION

12
What is the TERMINIX ALLCLEAR Mosquito Mister 2000?
The TERMINIX ALLCLEAR Mosquito Mister 2000 is the fastest way to clear a
yard of mosquitoes and other biting insects. In just 3 minutes ALLCLEAR reduces
mosquitoes by more than 90% for as long as six hours.*
How large of an area will the Mister protect?
TERMINIX ALLCLEAR 2000 has been proven to protect up to 2,000 sq. ft. for as
long as six hours*. The Mister can be easily repositioned or moved to another area
of the yard for additional mosquito control. The number of people in the area and
other environmental factors such as wind can affect the level of protection. It
may be necessary to mist more often or reposition the Mister according to outdoor
conditions.
How does the TERMINIX ALLCLEAR Mister work?
It works by atomizing an ultra-fine mist solution of water and ALLCLEAR Mosquito
Mister Concentrate. The mist controls mosquitoes immediately and then creates and
invisible barrier of protection that repels biting insects for hours.
What kind of insecticide does the TERMINIX ALLCLEAR Mosquito Mister 2000
use?
There are two concentrates customers can choose from to best meet their insect
control needs.
•100% NATURALS: 100% plant-based formula that protects with the
power of the lemongrass plant. It is SAFE to use around kids, pets, food.
Environmentally friendly, biodegradable.
•Synergized PLUS: synthetic formula based on botanical extract from the
Chrysanthemum flower. EPA registered, low in toxicity, effective for up to 6
hours.
Are the concentrates OK to use in yards with children and animals?
Yes. Our 100% NATURALS formula is safe to use around kids, pets, and food. It
contains a botanical extract of the lemongrass plant. Our EPA-registered PLUS
formula is a highly effective solution that is considered low toxicity and is intended
for use in yards with children and pets.
Can I use my Mister to protect the area around my pool?
Yes. The Mister is very effective at treating areas where you and your family spend
time outdoors, including the area around your pool.
What kinds of insects does the Mosquito Mister 2000 eliminate?
The TERMINIX ALLCLEAR Mister and Concentrates kill and repel mosquitoes, gnats,
stable flies, horse flies, face flies, and deer flies.
Will it kill insects like bees and butterflies?
It’s important to mist when mosquitoes are most active – dusk and dawn – typically
the time when beneficial insects are NOT active. The mist has been carefully
calibrated to control small biting insects, but can be harmful to larger insects if
they come in direct contact with the mist application. Try to mist away from flower
gardens and other areas that are known to attract beneficial insects.
Where should I place my TERMINIX ALLCLEAR Mosquito Mister 2000?
Simply place the Mister in the outdoor living area you want to protect and activate.
Winds carry the mist throughout the desired coverage area (up to 2,000 sq. ft.),
killing mosquitoes on contact and repelling others for up to 6 hours.* The Mister
can be easily repositioned or moved to treat other areas of the yard.
* When used with ALLCLEAR PLUS Concentrate. Other insects include:
ticks, gnats, horse flies, stable flies, deer flies, face flies and others.

13
UNIVERSAL PEST SOLUTIONS, LP
LIMITED WARRANTY: TERMINIX®ALLCLEAR® Mosquito Mister
What Is Covered:
With respect to the TERMINIX ALLCLEAR Mosquito Mister, this warranty covers any defects in parts, materials, or workmanship,
subject to the exclusions set forth below.
How Long Coverage Lasts:
The warranty period is 18 months or 1.5 years from the date of the first consumer purchase of the TERMINIX ALLCLEAR Mosquito
Mister.
Condition of Coverage:
This warranty applies only when the TERMINIX ALLCLEAR Mosquito Mister is used for personal, family, or household purposes.
What is not Covered:
This warranty does not cover the following: (a) damage caused by use with unauthorized or non-Universal Pest Solutions parts;
(b) damage caused by accident, misuse, abuse, flood, fire, or external causes; (c) damage caused by use in a manner inconsistent
with the permitted or intended uses described in the Operator’s Manual; (d) damage caused by service performed by anyone
other than a representative of Universal Pest Solutions, LP; (e) an TERMINIX ALLCLEAR Mosquito Mister that is modified to
significantly alter its functionality or capability, without the prior written consent of Universal Pest Solutions; (f) consumable
parts, including batteries used in the remote control but excluding the battery used in the main unit of the TERMINIX ALLCLEAR
Mosquito Mister, unless damage to a consumable part occurs due to a defect in TERMINIX ALLCLEAR Mosquito Mister parts,
materials, or workmanship; (g) an TERMINIX ALLCLEAR Mosquito Mister that is rented, leased, or used for any other commercial
purpose; and (h) an TERMINIX ALLCLEAR Mosquito Mister whose Universal Pest Solutions serial number is removed or defaced.
NO PERSON, AGENT, DEALER, OR DISTRIBUTOR IS AUTHORIZED OR EMPOWERED TO GIVE ANY OTHER WARRANTY OR TO
ASSUME ANY OTHER LIABILITY ON BEHALF OF UNIVERSAL PEST SOLUTIONS.
UNIVERSAL PEST SOLUTIONS, LP SHALL NOT BE LIABLE FOR CONSEQUENTIAL DAMAGES RESULTING FROM ANY BREACH OF
WARRANTY OR CONDITION. BECAUSE SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATIONS OF CONSEQUENTIAL
DAMAGES, THE FOREGOING LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
What Universal Pest Solutions Will Do:
During the warranty period, Universal Pest Solutions, LP will have the option to repair, replace, or refund in full the original
purchase price of any TERMINIX ALLCLEAR Mosquito Mister that is defective in parts, materials, or workmanship. When
appropriate, repair may include or consist of replacing defective parts.
How to Get Service:
If you believe that your TERMINIX ALLCLEAR Mosquito Mister contains a defect in parts, materials, or workmanship, please do
the following:
• Telephone Universal Pest Solutions at 1-888-9NO-BITE (1-888-966-2483). Please state the nature of
your problem and have your proof of purchase (e.g., sales receipt) on hand. Also have your Serial
Number ready which is located on the bottom of unit Battery Pack.
Universal Pest Solutions, LP is committed to excellent quality and service. If you have any questions or comments about your
TERMINIX ALLCLEAR Mosquito Mister, please contact Universal Pest Solutions, LP at the following address:
Universal Pest Solutions, LP
5950 Berkshire Lane, Suite 400
Dallas, Texas 75225
1-888-9NO-BITE (1-888-966-2483)
www.terminixallclear.com
This warranty gives you specific legal rights, and you may have additional legal rights that vary from State to State.
This product has been tested and complies with the specifications for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used according to the instructions,
may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which is found by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna
•Increase the separation between the equipment or devices
•Connect the equipment to an outlet other than the receiver’s
•Consult a dealer or an experienced radio/TV technician for
assistance
FCC ID: W3CACM2000
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment

14

15

1-888-9NO-BITE or www.terminixallclear.com
Universal Pest Solutions, LP
5950 Berkshire Lane, Suite 400
Dallas, TX 75225
ACM3100
v3: 11-11
