Grading Scrapers
Specifications & Capacities
Designs, specifications, features and information are subject to change without notice.
GS15 Series
Description GS1548 GS1560 GS1572
Working Width 48" 60" 72"
Overall Width 54 1/4" 66 1/4" 78 1/4"
Number of Scarifier Shanks 445
Tractor HP Requirement 20-50 hp 25-50 hp 25-50 hp
Unit Weight with Shanks 437 lbs. 511 lbs. 594 lbs.
Overall Length 50"
Overall Height 32"
Side Panel Height 14"
Side Panel Length 44"
Side Panel Thickness Tractor 3/16" Thick with 2 3/4" formed edges.
Front Main Beam & Scarifier Support. 4"x 4" x 5/16" Reinforced heavy wall tubing.
Rear Beam Construction 2"x 2"x 3/16" Heavy wall tubing.
Skid Shoe Dimensions 3/8" Thick x 2 3/4" wide x 44" long.
Scarifier Shank Construction - Optional Heat treated 4-position shank with dimpled-on hardened tips.
Cutting Edges Two 1/2" x 6" high carbon heat treated blades
that are reversible and replaceable.
Cutting Edge Placement Two parallel grading blades positioned at a 5 degree grading angle
with 17 1/2" fore and aft spacing in between leading edges.
Cutting Edge Adjustment Infinite vertical adjustment from level grade to 1 1/2" below grade.
Shank Adjustments 3 1/2" and 1 1/2" below grade level.
1/2" and 2 1/2" above grade level.
Lower Draft Link Attachment Clevis type
Hitch Type Category 1 and Category 1 Quick Hitch
Color Selections Land Pride beige or orange
