TerraTec SINE DI 8 User manual

TERRATEC PRODUCER/SINE DI 4 / SINE DI 8
English Manual
Version 1.0, last revised: November 2003

CE Declaration
We:
TerraTec Electronic GmbH, Herrenpfad 38, D-41334 Nettetal, Germany
hereby declare that the products:
TerraTec Producer SINE DI 4 and SINE DI 8,
to which this declaration refers are in compliance with the following standards or stan-
dardizing documents:
1. EN 55013
2. EN 55020
The following are the stipulated operating and environmental conditions for said compli-
ance:
residential, business and commercial environments and small-company environments.
This declaration is based on:
Test report(s) of the EMC testing laboratory
The information in this document is subject to change without notice and shall not be deemed as a
warranty by the seller. No warranties, express or implied, are made with regard to the quality, suit-
ability or accuracy of this document. The manufacturer reserves the right to change the contents of
this document and/or the associated products at any time without the provision of prior notice to
specific persons or organizations. The manufacturer shall not be held liable for damages of any
kind arising from the use, or the inability to use this product or its documentation, even if the possi-
bility of such damage is known. The information in this document is subject to copyright. All rights
are reserved. No part of this manual may be reproduced or transmitted in any form or for any pur-
pose without the express written permission of the copyright holders. Product and brand names
contained in this document are used for identification purposes only. All registered trademarks,
product designations or brand names used in this document are the registered property of their
respective owners.
©TerraTec®Electronic GmbH, 1994-2003. All rights reserved (12.11.03).
2 SINE DI 4 / SINE DI 8 (English)

Contents
Important safety information........................................................................................ 4
Welcome! ....................................................................................................................... 5
Scope of delivery........................................................................................................... 5
SINE DI 4 ........................................................................................................................ 6
Connections and controls ............................................................................................ 6
The front panel:........................................................................................................ 6
The rear panel:......................................................................................................... 6
Function....................................................................................................................... 7
Technical data ............................................................................................................. 7
SINE DI 8 ........................................................................................................................ 8
Connections and controls ............................................................................................ 8
The front panel:........................................................................................................ 8
The rear panel:......................................................................................................... 8
Function....................................................................................................................... 9
Technical data ............................................................................................................. 9
Service at TerraTec Producer..................................................................................... 10
Internet, Hotline ......................................................................................................... 10
SINE DI 4 / SINE DI 8 (English) 3

Important safety information
n
n
n
n
n
n
n
n
n
n
n
Please read all instructions before using this device.
Never use the device near water, i.e. next to a bathtub, sink, or drain, in a damp
basement or near a swimming pool.
Used in combination with an amplifier and headphones or speakers, this device can
cause sound levels that may result in lasting hearing damage. Avoid long exposure to
excessive or unpleasantly high volume levels. Consult an ear specialist immediately if
you detect a loss of hearing or a ringing in your ears.
Ensure adequate ventilation for the device when setting it up.
Do not install it near sources of heat such as radiators, ovens or similar devices.
Ensure that the device is connected only to a standard AC outlet.
Position it in such a manner that no dust, liquids or foreign objects can enter the hous-
ing.
Unplug the external power supply from the AC outlet if you do not intend to use the
device for an extended period.
The device must be serviced by trained personnel if:
o the external power supply is damaged,
o objects or liquids have entered the device,
o the device was left in the rain,
o the device was damaged by dropping,
o the device is malfunctioning.
Do not attempt to repair the device yourself. Please consult a trained technician.
Please ensure that all analog devices are turned off before plugging them in. This will
protect you from any possible—albeit weak—electrical shocks, as well as protecting
your speakers and your hearing from sudden peaks. For digital devices, be sure to at
least lower the volume on your playback equipment.
4 SINE DI 4 / SINE DI 8 (English)

Welcome!
We are pleased that you have chosen a TerraTec Producer rack system and would like to
congratulate you on your decision. You've purchased a sophisticated product represent-
ing the state of the art of studio technology, and we're convinced that our product will
prove extremely useful to you in the coming years and provide you with a great deal of
entertainment.
This manual describes the SINE DI 4/DI 8 DI boxes. It contains everything you need to
know about the correct use of the systems, as well as a number of practical tips that will
get you started right away.
We hope you enjoy your DI box and would like to suggest that you browse this hopefully
entertaining manual when you get the chance. In addition to the important information
about its technology, we have outlined a number of typical applications as well as tips and
tricks wherever appropriate. We're convinced that even experienced users will profit from
this guide.
Thanks for your attention—and here's to your creativity.
Sincerely, Your TerraTec Producer Team
Scope of delivery
Start by making sure that the contents of the package are complete. The SINE DI 4/DI 8
Rack DI System package should contain at least the following:
n
n
n
n
n
n
SINE DI 4 or DI 8 19" rack module
12V AC power supply only DI 4
Customer service card
Registration card with the serial number
BeSonic Premium Account registration card
This manual
Please return the enclosed registration card to us at the earliest possible opportunity or
register online at http://www.terratec.com/register.htm. This is important for support
and hotline services.
SINE DI 4 / SINE DI 8 (English) 5

SINE DI 4
Connections and controls
The front panel:
1. INPUT: Input socket (1/4" mono jack)
2. LINK-OUT: Output for direct signal feed-through
3. -20 dB attenuation
4. -40 dB attenuation (only in conjunction with –20 dB attenuation)
5. GROUND-LIFT: Ground isolation of the signal
6. 12 V AC: AC power
The rear panel:
7. POWER: Power switch
8. 12 V AC: AC power
9. OUTPUT: Balanced output, XLR
10. INPUT: Input socket (1/4" mono jack)
6 SINE DI 4 / SINE DI 8 (English)

Function
The SINE DI 4 rack system is an active direct injection box that converts unbalanced line
signals to balanced signals. Apply an unbalanced line signal to the input on the front or
rear panel to get a balanced signal at the XLR output. The signal is also fed through un-
changed to the Link-Out socket.
You can also attenuate the signal by –20 dB or –40 dB.
And if you're being annoyed by hum pickup, use the ground lift switch to fully isolate the
input and output signals from one another.
Note: do not connect two sources (front and back) to the same input channel. This
may damage the device.
Technical data
Audio inputs: 4 x 1/4" unbalanced jacks, front panel
4 x 1/4" unbalanced jacks, rear panel (parallel to front panel)
Input impedance: 470 ohm
Audio outputs: 4 x XLR, balanced, rear panel
4 x Link-Out, unbalanced, front panel
Output impedance: 1 kohm
Frequency response: 25 Hz – 20 kHz
AC power: 12V AC, 700 mA
Dimensions: 482.6 x 87 x 44 mm (19”, 1U)
SINE DI 4 / SINE DI 8 (English) 7

SINE DI 8
Connections and controls
The front panel:
1. INPUT: Input socket (1/4" mono jack)
2. -20 dB attenuation
3. GROUND-LIFT: Ground isolation of the signal
The rear panel:
4. OUTPUT: Balanced output, XLR
5. INPUT: Input socket (1/4" mono jack)
8 SINE DI 4 / SINE DI 8 (English)

Function
The SINE DI 8 rack system is a passive direct injection box which does not require a
dedicated power supply. The primary application of the SINE DI 8 is the isolation of input
and output signals (synthesizers, mixers, etc.). This is partly realized by interrupting the
ground connection of the signal that frequently causes hum pickup. For example, to iso-
late the connection between a synthesizer and mixer, connect the synthesizer to one of
the 8 inputs of the DI 8. Next, connect the associated output of the DI 8 to the mixer input.
You can also attenuate the signal by -20 dB.
Note: do not connect two sources (front and back) to the same input channel. This
may damage the device.
Technical data
Audio inputs: 8 x 1/4" unbalanced jacks, front panel
8 x 1/4" unbalanced jacks, rear panel (parallel to front panel)
Input impedance: 1 kohm
Audio outputs: 8 x XLR, balanced
Output impedance: 1 kohm
Frequency response: 25 Hz – 20 kHz
Dimensions: 482.6 x 87 x 44 mm (19”, 1U)
SINE DI 4 / SINE DI 8 (English) 9

10 SINE DI 4 / SINE DI 8 (English)
Service at TerraTec Producer
Sometimes, no matter how good the weather is, things do not always work as they
should. Problems can arise in the best studio systems. If this happens to you, the Ter-
raTec Producer team is happy to offer its service and support.
Internet, Hotline
If you have a tough problem—where you cannot solve the problem yourself, the support
in this manual doesn't resolve the problem, and your dealer can't fix it either—please con-
tact us directly.
If possible, try our Internet support system first: under http://www.terratec.com/ you will
always find current answers to frequently asked questions (FAQ).
If these options do not provide the necessary help, please contact our phone hotline. You
can also reach us online.
To do so, visit us at http://supporten.terratec.net/.
In either case, please have the following information handy:
n
n
your registration number
this documentation.
In addition, it would be helpful to our technicians if you are at your device during the
phone call to directly carry out tips and tricks. Please do not forget to write down the
name of the respective support technician if you contact our Support Team. You will need
this name if a defect is present and your device needs to be mailed to us.
