Tesla 32S307WH User manual

LED TV
OPERATING
INSTRUCTION
ENG AL BiH CG HR MK SLO SRB
SERIES 332S307WH

OPERATING INSTRUCTION
Please read these instructions before operating
your set and retain them for future reference.
UDHËZIM PËR PËR
Ju lutemi lexonie këtë udhëzim para përdorimit të
pajisjë suaj dhe ruajeni për nevoja plotësuese eventuale.
UPUTSTVO ZA UPOTREBU
Prije upotrebe uređaja pročitati ova uputstva
i zadržati ih radi kasnijih referenci.
UPUTE ZA KORIŠTENJE
Prije korištenja uređaja pažljivo pročitati
upute i sačuvati ih za buduću upotrebu.
NAVODILA ZA UPORABO
Pred uporabo pozorno preberite navodila
in jih shranite za morebitno uporabo v prihodnosti.
UPUTSTVO ZA UPOTREBU
Pre upotrebe uređaja pročitati ova uputstva
i zadržati ih radi kasnijih referenci.
УПАТСТВО ЗА КОРИСТЕЊЕ
Ве молиме прочитајте го ова упатство пред да го
инсталирате и употребувате вашиот уред.
AL
ENG
BiH/CG
HR
MK
SLO
SRB

3
ENG
Note
1. The graphics and data in this manual are only for reference.
2. You TV’s OSD may be slightly different with that shown in this manual.
3. The information in this document is subject to change without notice. The manufacturer
accepts no liability for damage resulting directly or indirectly from faults, incompleteness
or discrepancies between the user manual and the product described.
4. In dry environment due to static electricity, the product may restart and return to the main
OSD interface, USB player interface or the previous source mode. It is normal and please
continue to operate the TV as your will.
Contents
WARNINGS AND PRECAUTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
PANEL BUTTONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
TERMINALS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
REMOTE CONTROL FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
RECORDER (REC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
ELECTRONIC PROGRAM GUIDE (EPG) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
MENU SETTINGS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Menu Operation (DTV Mode) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Channel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Option. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
USB CONTROL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
USB Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Play Movie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Play Music. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Browse Photo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
TROUBLESHOOTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
LICENSE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

4
ENG
WARNINGS AND PRECAUTIONS
Read all of the instruction before operating the set. Keep the instruction for later use.
• Read these instructions – All the safety and operating instructions should be read before this
product is operated.
• Keep these instructions – The safety and operating instructions should be retained for future
reference.
• Read all warnings – All warnings on the appliance and in the operating instructions should
be adhered to.
• Follow all instructions – All operating and use instructions should be followed.
• Do not use this apparatus near water – The appliance should not be used near water or
moisture – for example, in a wet basement or near a swimming pool, and the like.
• Clean only with dry cloth.
• Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
• Do not defeat the safety purpose of the polarized or grounding plug. A polarized plug
has two blades with one wider than the other. A grounding plug has two blades and a
third grounding prong. The wide blade or the third prong is provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
• Protect the power cord from being walked on or pinched particularly at the plugs,
convenience receptacles, and at the point where they exit from the apparatus.
• Only use attachments/accessories specified by the manufacturer.
• Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,
or sold with the apparatus. When a cart or rack is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
• Unplug the apparatus during lightning storms or when unused for long periods of time.
• Refer all servicing to qualified personnel. Servicing is required when the apparatus has
been damaged in any way, such as power supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
• CAUTION: These servicing instructions are for use by qualified service personnel only.
To reduce the risk of electric shock, do not perform any servicing that contained in the
operating instructions unless you are qualified to do so.
• Do not install this equipment in a confined or building-in space such as a book case or
similar unit, and remain a well ventilation conditions at open site. The ventilation should not
be impeded by covering the ventilation openings with items such as newspaper, table-
cloths, curtains etc.
• Caution – To prevent electric shock hazard, replace grille.
• Please refer the information on exterior bottom enclosure for electrical and safety
information before installing or operating the apparatus.
• To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
• The apparatus shall not be exposed to dripping or splashing and that no objects filled with
liquids, such as vases, shall be placed on the apparatus.
Important Safety Instructions

5
ENG
• For the terminals marked with symbol of “ ” may be of sufficient magnitude to constitute a
risk of electric shock. The external wiring connected to the terminals requires installation by
an instructed person or the used of ready-made leads or cords.
• To prevent injury, this apparatus must be securely attached to the floor/wall in accordance
with the installation instructions.
• Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type.
• The battery (battery or batteries or battery pack) shall not be exposed to excessive heat such
as sunshine, fire or the like.
• LExcessive sound pressure from earphones and headphones can cause hearing loss.
Listening to music at high volume levels and for extended durations can damage one’s
hearing. In order to reduce the risk of damage to hearing, one should lower the volume to
a safe, comfortable level, and reduce the amount of time listening at high levels. (Only for
German).
• The mains plug/appliance coupler/direct plug-in adapter is used as disconnect device, the
disconnect device shall remain readily operable.
• When not in use and during movement, please take care of the power cordset, e.g. tie up
the power cordset with cable tie or something like that. It shall be free from sharp edges
and the like that can cause abrasion of the power cordset. When put into use again, please
make sure the power cordset being not damaged, If any damages found, please look for
the service person to replace the power cordset specified by the manufacturer or have the
same characteristics as the original one.
• Attention should be drawn to environmental aspects of battery disposal.
• No naked flame sources, such as lighted candles, should be placed on the apparatus. To
prevent the spread of fire, keep candles or other open flames away from the apparatus at all
times.
• The mains plug/appliance coupler/direct plug-in adapter is used as disconnect device, the
disconnect device shall remain readily operable.Using cabinets or stands recommended by
the manufacturer of the television.
• When not in use and during movement, please take care of the power cordset, e.g. tie up
the power cordset with cable tie or something like that. It shall be free from sharp edges
and the like that can cause abrasion of the power cordset. When put into use again, please
make sure the power cordset being not damaged, If any damages found, please look for
the service person to replace the power cordset specified by the manufacturer or have the
same characteristics as the original one.
• Attention should be drawn to environmental aspects of battery disposal.
• No naked flame sources, such as lighted candles, should be placed on the apparatus. To
prevent the spread of fire, keep candles or other open flames away from the apparatus at all
times.
• If the apparatus have the symbol in its rating label and the power cord has two pins, it
means that the equipment is a Class II or double insulated electrical appliance. It has been
designed in such a way that it does not require a safety connection to electrical earth.

6
ENG
WARNING
Do not ingest the battery, Chemical Burn Hazard
(The remote control supplied with) This product contains a coin/button cell battery. If the
coin/button cell battery is swallowed, it can cause severe Internal burns in just 2 hours and
can lead to death.
Keep new and used batteries away from children. If the battery compartment does not
close securely, stop using the product and keep it away from children.
If you think batteries might have been swallowed or placed inside any part of the body,
seek immediate medical attention.
Warning for Apparatus containing COIN / BUTTON CELL BATTERIES
(Below instruction only used for the apparatus containing a user-replaceable coin/button cell
battery)
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
• This lightning flash with arrowhead symbol within an equilateral triangle is intended to
alert the user to the presence of non-insulated “dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude to constitute a risk of electric shock.
• To reduce the risk of electric shock. Do not remove cover (or back). No user serviceable
parts inside. Refer to qualified service personnel.
• The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operating and maintenance instructions in the literature
accompanying the appliance
• The following information are recommended to be included as far as applicable where
applicable:
Refers to alternating current (AC)
Refers to direct current (DC)
Refers to ClassII equipment
Refers to stand-by
Refers to pow er ON.
Refers to dangerous voltage

7
ENG
• Install Display on solid horizontal surface such as a table or desk. For ventilation, leave a
space of at least 10cm free all around the set. To prevent any fault and unsafe situations,
please do not place any objects on top of the set. This apparatus can be used in tropical
and/or moderate climates.
• Never place a television set in an unstable location. A television set may fall, causing serious
personal injury or death. Many injuries, particularly to children, can be avoided by taking
simple precautions such as:
• Using cabinets or stands recommended by the manufacture of the television.
• Only using furniture that can safely support the television.
• Ensuring the television is not overhanging the edge of the supporting furniture.
• Not placing the television on tall furniture (for example, cupboards or bookcases) without
anchoring both the furniture and the television set to a suitable support.
• Not placing the television set on cloth or other materials that may be located between the
television set and supporting furniture.
• Educating children about the dangers of climbing on furniture to reach the television or
its controls.
If your existing television set is being retained and relocated, the same considerations as
above should be applied (Only for the TV with mass exceed 7 kg)
Correct Disposal of this product. This marking indicates that this product should not
be disposed with other household wastes throughout the EU. To prevent possible harm to
the environment or human health from uncontrolled waste disposal, recycle it responsibly to
promote the sustainable reuse of material resources. To return your used device, please use
the return and collection systems or contact the retailer where the product was purchased.
They can take this product for environmental safe recycling.
WEEE Directive
Positioning of the TV Set
Note: The pictures are for reference only.

8
ENG
An optional wall mount can be used with your television. Consult with your local dealer for a
wall mount that supports the VESA standard used by your TV model. Carefully attach the wall
mount bracket at the rear of the TV. Install the wall mount bracket on a solid wall perpendicular
to the floor. If you are attaching the TV to other building materials, please contact qualified
personnel to install the wall mount. Detailed instructions will be included with the wall mount.
Please use a wall mount bracket where the device is adequately secured to the wall with
enough space to allow connectivity to external devices.
• Disconnect the power before moving or installing the TV. Otherwise electric shock may
occur.
• Remove the stand before installing the TV on a wall mount by performing the stand
attachment in reverse.
• If you install the TV on a ceiling or slanted wall, it may fall and result in severe injury. Use an
authorized wall mount and contact the local dealer or qualified personnel. Otherwise it is
not covered by the warranty.
• Do not over tighten the screws as this may cause damage to the TV and void your warranty.
• To prevent injury, this apparatus must be securely attached to the floor/wall in accordance
with the installation instructions.
• Use th e screws and wall mounts that meet the following specifications. Any damages or
injuries by misuse or using an improper accessory are not covered by the warranty.
Note:
1) The pictures are for reference only.
2) For the TV sets with terminals towards the wall, in order to leave enough space to use the
terminals, a rubber cushion is needed together with the screw to fix the wall mount. It is a
small hollow pillar whose internal diameter is 8mm, external diameter is 18mm and height
is 30mm.
Mounting on a Wall
CAUTION
Model Size: 32" Top Down
Screw
Diameter (mm) "E" M4 M4
Depth (mm)
“D”
Max 9 9
Min 6 6
Quantity 2 2
VESA (AxBxC) 100x100x100

9
ENG
• Do not install this equipment in a confined space such as a bookcase or similar unit.
• Do not use the set near damp, and cold areas, protect the set from overheating.
• Keep away from direct sunlight.
• Do not use the set near dust place.
• Do not attach candle to accessible opening area, to avoid flammable foreign material from
entering the TV.
• Use the remote control by pointing it towards the remote sensor. The items between the
remote control and the remote sensor will interfere the normal operation.
• Do not make remote control vibrate violently. Also, do not splash liquid on the remote
control, also do not put the remote control in high humidity place.
• Do not place remote control under direct sunlight which will cause deformation of the unit
by heat.
• When the remote sensor is under direct sunlight or strong lighting, the remote control will
do not work. If so please change the lighting or TV’s position, or operate the remote control
closer to the remote sensor.
Improper using of the battery will cause leakage. So please do as the following methods and
use carefully.
1. Please note the batteries’ polarity, to avoid short circuit.
2. When the battery’s voltage is insufficient which affect the use range, you should replace new
battery. Remove the batteries from the remote control unit if you do not intend to use it for a
long time.
3. Do not use different types of batteries( for example, Manganese and Alkaline batteries)
together.
4. Do not put the battery into fire, and charge or decompose the battery.
5. Please dispose batteries abide by relevant environmental protection regulation.
6. WARNING: The batteries (battery pack or batteries installed) shall not be exposed to
excessive heat such as sunshine, fire or the like.
Place two AAA size batteries in the remote controls battery compartment, making sure to
match the polarity markings inside the compartment.
Operating Environment
Precautions For Using Remote Control
Precautions For Using Battery
Install Remote Control Battery

10
ENG
PANEL BUTTONS
Note: The images are intended for reference only.
Rocker Button
Bottom view
TERMINALS
Note: Please select the terminals according to your actual TV set.
Press middle button:
1. In standby mode, press it to turn on the TV;
2. Without OSD, short press it to access source menu; long press to turn the TV to standby;
3. With OSD, short press it to confirm a selection; long press it to return or exit.
Push left: decrease volume or go to left.
Push right: increase volume or go to right.
Push forward: channel up or go to above.
Push backward: channel down or go to below.
Rocker Button
1Video & Audio L/R Connect audio and video signal from signal source
such as DVD.
2HDMI1/MHL &HDMI2 Connect HDMI input signal from signal source
such as DVD. HDMI1 supports MHL function.
3DIGITAL AUDIO Use a SPDIF cable to output the TV audio signal to
a compatible audio receiver.
4EARPHONE Audio output, speakers will be muted when
earphone is plugged.
5USB USB port
6LNB/AIR/CABLE Connect a coaxial cable to receive signal from the
antenna, cable or satellite.
7SERVICE Debugging interface only for professional
technician.
8CI CI card port.

11
ENG
REMOTE CONTROL FUNCTIONS
Remote Control
1. POWER ( ) Press to turn the TV on or to put it
in standby.
2. MUTE ( ) Press to mute or restore the
volume.
3. PICTURE Change picture mode.
4. SOUND Change sound mode.
5. Zoom Change aspect ratio.
6. Numeric buttons Choose channel directly.
7. CHN LIST Press to enter the channel list.
8. RETURN (BACK) Press to go back to a
previously viewed channel.
9. MENU Open the menu options.
10. SOURCE Select the input source mode.
11. Up/Down/Left/Right (///)
Navigate through the menu.
12. ENTER Confirm the selection.
13. TV/RADIO Switch between TV and radio.
14. EXIT Exit the current menu.
15. HOME Enter the home desktop. If your TV don’t
have HOME function, this button will not work.
16. Volume Up/Down (VOL+/VOL-)
Adjust the volume level.
17. Program Up/Down (PR+/PR-)
Change programs up or down.
18. SLEEP Select the sleep time, such as 10min,
20min etc.

12
ENG
19. EPG Press to display the current EPG
information in DTV mode.
20. SUBTITLE Enable/disable subtitles in DTV/USB
mode.
21. FAV. (Favorite Channel)
Press to view your assigned favourite channels.
Press Up/Down buttons to move through your
assigned favourite channels. Press ENTER to
confirm.
22. Record (REC) Press to record the current
programme (available in DTV mode only).
23. INFO Display information about current source.
24. USB Play Control Buttons
Play & Pause ( )
Press to pause playback, then press again to
continue playback.
Stop ( )
Press to stop playback.
Fast Backward Button ( )
Press to fast reverse.
Fast Forward ( )
Press to fast forward.
Previous ( )
Press to play the previous file.
Next ( )
Press to play the next file.
25. Color buttons Press to execute the prompt
function in TV or DTV mode.
26. NICAM Press to select desired sound output
depending on the broadcasting channel.
27. FREEZE (HOLD) Freeze the picture on the
screen (Not available in USB mode).
28. REC LIST Display the recording file list.
29. QUICK No function.
30. 3D No function.
31. AD (Audio Description) Press to turn on audio
description, a narrator will describe what is
happening on the screen for blind or visually
impaired viewers. press again will turn it off
(Only available in DTV mode).

13
ENG
TELETEXT BUTTONS
32. TEXT Press to enter or exit the teletext menu.
33. HOLD
Press to hold the teletext page on screen
without update and changes. Press again to
release the hold state.
34. Other Buttons
SIZE Enlarge the teletext display: Press this
button once to enlarge upper half of the screen.
Press this button again to enlarge lower half of
the screen. Press this button again to resume to
normal screen size.
REVEAL Press this button to display concealed
information, such as solutions to riddles or
puzzles. Press again to remove the information
from the display.
MIX
Press this button to superimpose the teletext
over the TV program. Press again to return to
normal teletext mode.
SUB-PAGE
Press this button to enter or exit subpage mode
(if subpage is available). Press Red / Green
buttons to select the desired subpage.
INDEX Press this button to display index page.
CANCEL
Press this button to return to TV program
temporarily while searching for a Teletext page.
When the search is done, the page number will
be displayed on the upper left of the screen.
Press again to return to the Teletext page.

14
ENG
RECORDER (REC)
Instant one-touch recording and playback
Timer recording
IMPORTANT NOTES:
1. For any type of recording with this television, you must have connected an external device
to the appropriate USB port at the back of the television to record on.
2. The USB device must be FAT32 format.
3. For the first time using the USB device to record on the this TV, suggest to format the USB
device on the TV before you start the recording.
4. Make sure you are watching DTV program.
5. Use high-quality mobile device to record HD programs, otherwise the videos will be
jammed during the playback.
6. Back up all of the data in the USB storage device in case data was lost due to an
unexpected accident. We do not assume any liability for the losses by misuse or
malfunction. Data backup is consumer’s responsibility.
1. Please insert the an external high-speed storage device, and make sure the device has
enough free space.
2. Select the TV program and channel you wish to record.
3. Press REC button to enter into REC mode and start recording. REC control bar on the
screen shows as below, you can select the appropriate settings as your desire.
4. If the REC function can not be realized, try to format your USB device.
5. If you wish to stop the recording, press [ ] button and the recording will stop.
There are two ways to set the timer to record a television program.
If you know the programming details:
1. Go to the channel that will broadcast the program you want to record.
2. Press the EPG button on your remote control to bring up the EPG interface. The channel
you are watching will be highlighted on the screen that appears.
3. Press the RED button on the remote control, then enter into the program details on the
recorder menu by pressing / to select an item and / to change the setting. For
example, if the program starts at 8:30pm on the same day, enter: 30 in the space for
MINUTES, 20 in the space for HOURS (a 24 hour clock applies), and then the relevant date.
Use the same method for entering the finish time.
Note: (A) During the record mode, you cannot change channels or select another function.
(B) If the signal is interrupted or removed while in record, the recording will stop until
the signal is established. This may cause you to lose program content.

15
ENG
ELECTRONIC PROGRAM GUIDE (EPG)
EPG stands for Digital Electronic Program Guide. It is supplied by the program providers and
offers information about the programs to be broadcast. You can access it in digital mode by
pressing the EPG button on the remote control.
1. Press the EPG button to bring up the EPG interface. The second bar from the top will
display the current date and time. On the list below, the channel you are currently watching
will be highlighted.
2. Before you can view any EPG information, you have to ‘activate’ every channel for which
you want to view program information. To do this, use the / buttons to select a channel,
then press ENTER to confirm.
3. To check programs to be broadcast on a future date, scroll up with the button to the
date field. Use the button to select the date you want to check.
4. Press the Index ( ) button to scroll up to the top bar in the display, then press the
button to select the channel List. The second bar will then display one of your available
channels.
5. Go to the channel and use the / buttons to select the channel for which you want to
view information. After a brief moment, the program information will appear.
6. Use the / buttons to scroll through the time slots.
7. Press MENU button to exit the EPG menu.
Recorder
Press the RED button to display the recorder menu (right).
See detailed information about the different ways of
recording with the television onto a USB device.
Info
Press the GREEN button to show information about the
selected program.
Schedule
Press the YELLOW button to display the Schedule List.
Press / to select an event, press the RED button to
delete an Event.
Remind
Press the BLUE button to display a reminder menu.
Press / to select an item and / to change the
setting.
Press ENTER to add the reminder event to the schedule
list. An updated schedule list will be shown.
4. Choose the appropriate recording mode: once, every day or weekly.
5. Press ENTER to confirm your selection. A schedule of all your recordings (the schedule list)
will appear. See EPG function for more on the schedule.
If you are browsing the EPG, Follow the steps on EPG function page.

16
ENG
MENU SETTINGS
Menu Operation (DTV Mode)
Press "MENU" key to enter the main menu .
Press the [ ] / [ ] guide key to select desired item.
Press "ENTER" key to enter the item.
Press [ ] / [ ] and ENTER buttons to select the submenus.
Press "MENU" key to exit the item.
Note: Some options may be not available under some sources.
Picture Mode: Select the automatic picture control mode. Choices are Dynamic,
Standard, Mild and User.
Color Temperature: Select the overall color tone of the picture. Choices are Cool,
Medium, Warm and User.
Aspect Ratio: Select the aspect ratio (display proportions) according to your video signal
type or preference. Choices are 16: 9/4: 3/Just Scan /Zoom1/ Zoom2.
Noise Reduction: Eliminates noise in the picture. Choices are Off/Low/Middle/High.
MPEG NR: Eliminates noise generated while creating digital picture signals. Choices are
Off/Low/Middle/High.
Sound
Sound Mode: Select your favorite sound mode for each input. Choices are Standard/
Music/Movie/Sports/User.
Bass: Adjusts the lower frequency of the sound.
Treble: Adjusts the higher frequency of the sound.
Balance: Control the sound balance between the right and left loudspeaker.
Auto Volume: Adjust the volume corresponding to the input audio level. Contain On
and Off.
Surround Sound: Helps to create rich and wider sound from stereo sound sources.
AD Switch (Only available in DTV mode): Turn on the Audio description, you can
activate the setting of AD volume. When turn on the audio description, a narrator will
describe what is happening on the screen for blind or visually impaired viewers.
SPDIF Mode (May not be available): Select the SPDIF mode: Auto or PCM.
Channel
Auto Tuning
Select DVB-T or DVB-C and press ENTER button to go to the next step. Select country or scan
type and then search and store programmes automatically. If you want to stop the auto search,
press MENU button or EXIT button and exit dialog box will pop out.
• Press to confirm exit.
• Press to continue searching.
Advanced Tuning
Access the satellite settings essential for programme searching through DVB-S source.

17
ENG
Satellite Dish Settings (Step 1-3, refer to Fig. 1)
A set of satellite dish settings must be configured for each wanted satellite before
performing a channel scan.
Satellite - Select the satellite for this TV.
LNB Type - Make sure the LNB type is appropriate for your dish.
LNB Power - Enable or disable power supply for the LNB.
22KHz - Select the 22KHz to set 22K switch to ON/OFF. Use auto mode to switch 22KHz
on or off depending on the LNB type.
DiSEqC1.0/1.1 - Select the DiSEqC mode for the selected LNB.
Fig. 1
Step 2
Step 1
Step 3
Step 1: Highlight Satellite and press ENTER to access the satellite list and select the desired
one.
Step 2: Highlight LNB Type and press ENTER to select the LNB type.
Step 3: Make sure that 22KHz, DiSEqC1.0/1.1 switch corresponds to the selected satellite.
After completing the above steps, press the blue button to search for the channels.
DTV Manual Tuning
Search and store programmes manually.
Channel DTV Manual Tuning
Select the source type (DVB-T or DVB-C) and search digital programmes manually. In the
Channel menu, select DTV Manual Tuning and press ENTER button to access.
1. Press or to select channel number and then press ENTER to start the search.
2. The search stops when programme is found and this program will be stored in the current
channel position. If you want to stop the search, press the MENU button.
ATV Manual Tuning
First select the source type of ATV. Then select ATV Manual Tuning in the Channel menu and
press ENTER button to access.
1. Highlight and press or tto select Storage To 1 (or any other number), Sound System
or Channel number. Then select Search and press ENTER to start the search.

18
ENG
• Press for the unit to search towards higher frequency;
• Press for the unit to search towards lower frequency;
2. The search stops when programme is found. This programme will be stored in the current
channel position. If you want to stop the search, press the MENU button.
Fine-Tune
Use it to make small adjustments to tuning of each individual channel. Fine-tune is not
necessary under normal conditions. However, in area with poor broadcast conditions,
where adjustments are necessary to improve picture and sound, use the fine-tune option.
1. Select the channel that you want to fine tune.
2. In Channel menu, select ATV Manual Tuning and press to highlight Fine-Tune.
3. Press or to fine-tune until the best possible picture and sound are obtained.
Program Edit
Edit the programmes. You can press colour buttons on the remote control to skip programmes,
rename and delete programmes or move programmes, and add programmes to the favourite
list by pressing FAV button.
Signal Information
Display of the current DTV channel information.
CI Information
Allowing the user to select from the CAM-provided menu. Select the CI menu according to the
menu PC Card.
5V Antenna Power
This option is only available with DVB-T source. Select On to supply power to the TV antenna.
Select Off to turn off this function.
Software Update (OAD) (only for some regions)
Select On to allow the TV to update the system software over the air. Choosing Off will turn off
this function.
OAD Tuning (only for some regions)
When software update (OAD) is off, this option is disabled. Choosing OAD scan involves
scanning channels to find the OAD update information.
LCN ON/OFF (Only for some regions)
When tuning programs, select ON, the channel list is sorted according to LCN; select OFF, the
channel list is sorted according to the default order.
Option
OSD Language
Select the OSD language.
Audio Languages / Subtitle Languages (Note 1)
Select the desired language.

19
ENG
TTX Language
Select TTX language for different regions.
Time
Can setup Auto Sync, Clock, Time Zone, Summer Time, Sleep Timer and Auto Sleep.
HDMI CEC
Press to enter submenus.
HDMI CEC – Turn on or off the HDMI CEC function.
Auto Standby – Turn the TV to standby automatically.
Device List – When HDMI CEC is on, check the list of devices connected to the TV.
REC File System (Note1)
If you want to use this function, you must have received a digital program and connected
a USB disk.
EWS Local Postal Codes(Only for some regions)
The Emergency Warning System defined by DVB provides the necessary mecha
Restore Default
Restore user setting to default.
Software Update (USB)
Connect USB device storing the software that has to be upgraded to upgrade the TV system.
Note:
1. Audio Languages/ Subtitle languages /REC File System only works under DVB-S /DVB-C /
DVB-T mode.
2. User data on this TV will lose completely after operating the feature of Restore Deafault.
3. Do not power off the TV during the software upgrading process, otherwise the TV may not
work, and the customer should be responsible.
Lock
Lock System
Input the initial password (0000) to access this feature. Choose “on” and the features
“Set password”, “Block programme” and “Parental guidance” will be activated. Choose “off”
and the above mentioned three features will become inactive. If you forget the password, you
can also input the super password (8899) to enter into the lock system.
Set Password
Reset the password.
Block Programme
Block the desired programmes.
Parental Guidance
Choose the programmes appropriate for children to watch.
Hotel Mode (Only for some regions)
Only for hotel use.

20
ENG
USB CONTROL
USB Menu
Press Source menu and select USB button. You can play movie, music and photo files from
your USB storage devices.
1. Connect USB storage device to USB input terminal and select the types of media on the
home page: MOVIE, MUSIC and PHOTO.
2. Press [ENTER] button, the screen will show the connected USB device. Press [ENTER]
button again to view the file folders and files.
3. Press [] / [] or [] / [] to select folder. Press [ENTER] to open folders and select files,
then press [ENTER] to tick them. Highlight the one you want to play first, press [/]
tostart playing. To start playing directly, select a file and press [/].
4. Press [ ] to stop playing and return to upper lever folder.
5. Continuously press [RETURN] to go back to upper lever folder.
6. Use the above steps to select and play another media type.
Reminder When Using the USB Player
1. Some USB storage devices may not be compatible to operate smoothly with this TV.
2. Back up all of the data in the USB storage device in case data was lost due to an
unexpected accident. We do not assume any liability for the losses by misuse or
malfunction. Data backup is consumer's responsibility.
3. For large file sizes, the loading speed may be slightly longer.
4. The recognition speed of a USB storage device may depend on each device.
5. When connecting or disconnecting the USB storage device, make sure the TV is not in USB
mode otherwise the USB storage device or the files stored in it may be damaged.
6. Please use only a USB storage device which is formatted in FAT16, FAT32, NTFS file system
provided with the Windows operating system. In case of a storage device formatted as a
different utility program which is not supported by Windows, it may not be recognized.
7. When using a USB Hard Disk Drive which requires electric power source, ensure its power
does not exceed 500mA. If the power of the USB hard Disk exceed 500mA, the TV system
will be changed into standby mode, you must pull out the USB hand Disk and restart the
TV system.
8. An "Unsupported File" message will be displayed if the file format is unsupported or the
file is corrupted.
9. FHD big picture needs longer time to process, which is not caused by the TV. Please be
patient to wait.
10. This TV may not support some multimedia files changed and upgraded as the change of
encoding format or other technical advances.
