Tesla TSL-SWI-WIFI1 User manual

QUICK START GUIDE
TESLA SMART SWITCH/DUAL
(With Neutral Required)
EN
SK
SL
HR
DE
PL
UA
RU
CZ
HU
TSL-SWI-WIFI1/ TSL-SWI-WIFI2

- Voice/APP Control
- Smart Home Automation with Multi devices
- Silent switch with LED Indication
Product Indtoruction
Smart switch products are suitable for electrical equipment such as light-
ning, fans, curtains, etc., through the network, voice and APP remote control
functions, with various sensors to easily achieve home automation.
Specification
Input Power: 100~240V AC 50/60Hz
Resistive load: Incandescent: 1500W MAX
CFL: 600W MAX
LED: 600W MAX
Communication: WiFi 2.4G
Standby Power: ≤0.5W
Working Temperature: -10°C ~ 45°C
Working Humidity: <90%
Life Cycle: 50k times
Dimension: 86x86x37.5mm
2

Product outline
Indicator Light Status
Indicator LED
On/Off button
Light Color Green Light Status Switch Status:
White OFF The switch turn off
ON The switch turn on
Flicker The switch is in quick
configure mode
Green ON The switch turn off
OFF The switch turn on
3

Contents Supplied
Tools You‘ll Need
Switch
Screws
Flat-head Screwdriver
Screwdriver
Pliers
Voltage tester Approximately
30 minutes of your time
to install and setup
the Switch
4

Installation
Turn Off The Breaker
Turn off the circuit break and use the electrical
tester to test the power.
WARNING: RISK OF ELECTRIC SHOCK
This product installation requires handling 100-240 volt wiring.
Follow each step carefully. If any concerns handling wiring, hire
a qualified electrician. Ensure all work meets applicable local and
national codes.
1
5

L2 LN
N
N L
L
Connection Diagram
1 GANG
2 GANG
2
6

3 GANG
N
L
L2L3 LN
N
NL N L
L
L
Remove The Panel
3
Remove the switch panel
cover of the switch.
7

1
2
Mount The Switch
Attach The Wallplate
4
5
Use the screws provided.
Attach the adapter to the switch
using the screws provided and snap
on the wallplate.
8

Turn On The power
APP Operation
6
Turn the power back on at the circuit breaker
1 Preparation for use
•Tesla Smart is available for both iOS and Android OS. Search the name
‚Tesla Smart‘ in App Store or Android Market, or scan the QR-Code to
download the App and register or login your account.
• Make sure that the smartphone is connected to the 2.4Ghz network.
9

2 Connect the device
• Open Tesla Smart app and click “+” sign to Add new device
• Select Switches - Tesla Smart Switch
• Please follow the instructions to add the Tesla Smart Switch step by step
3 Control Switch
• Control switch with APP
10
