Teufel
Technical description and user guide
iTeufel®Dock
The docking station for Apple iPod media players*
* Player not included! A complete and up to date list of compatible iPod
models can be found on our Website.
iPod is a trademark of Apple Inc. registered in the USA and other countries.

2 · iTeufel®Dock
For your information
The information in this document may be
changed without advance notification and
does not represent any obligation on behalf
of Lautsprecher Teufel GmbH. Lautsprecher
Teufel GmbH accepts no responsibility for
any errors in this manual.
No part of these instructions for use may
be copied in any way, whether electronically,
mechanically, using photocopies or recordings,
or transferred without the prior written
agreement of Lautsprecher Teufel GmbH.
© Lautsprecher Teufel GmbH
Version 1.4
June 2009
Trademark
® All trademarks are the property of their
respective owners.
Warranty terms
There is a two-year warranty starting from
the date of purchase on equipment and work
time, with the exception of damage
caused by incorrect use or electrical or
mechanical overload. An original copy of
our invoice is required as the warranty
document. This warranty is exclusively valid
for iTeufel® Docks that have been
purchased from Teufel by end users for
their own private use. The warranty is not
valid for iTeufel® products that the end user
has purchased from a different distributor.
If the Teufel product is sold on privately,
the warranty may be transferred to the
purchaser, providing that the original proof
of purchase is also transferred.
Returns policy
For all products purchased directly from
Teufel and from www.teufel.de, Teufel pro-
vides an eight-week right of return with a
money-back guarantee. You will not have to
pay any additional shipping costs for retur-
ning Teufel goods. Teufel covers the freight
for transporting the goods back to the
factory, and we will promptly refund the
purchase price to your account once we
have verified the condition of the goods.
You may only return individual components
from a set if Teufel offers these compon-
ents for sale separately. If you return one
or more individual components from a set,
this voids the discount that Teufel provides
on the sale of components as a set. This
means that for individually returned com-
ponents from a set, you will be refunded
the difference between the set price and
the sum purchase price of the individual
components you decide to keep, i.e., we
will deduct the discount that applies to set
purchases.
If you decide to return any or all of the
purchased goods, please always contact us
first.
Note that we can only process and accept
returned goods if you have telephoned us in
advance and discussed the required returns
procedure.
Please contact our service department if
you have any questions, suggestions or if
there is anything you think we could do
better.
Lautsprecher Teufel GmbH
Gewerbehof Bülowbogen - Aufgang D1
Bülowstr. 66
D-10783 Berlin(Germany)
Tel.: +49(30) - 30 09 300
Fax:+49(30) - 30 09 30 30
www.teufel.eu

3
· iTeufel®Dock
Contents
Table of contents.......................................................................Page 3
Introduction to iTeufel® Dock ..........................................................Page 3
Safety information .....................................................................Page 4
Unpacking · Contents · Connection........................................................Page 5
Connection ............................................................................Page 6
Remote control · Use....................................................................Page 7
Manual Version 1.4
Introduction to iTeufel® Dock
Dear Lautsprecher Teufel customer,
many thanks for buying a product from
iTeufel® of Lautsprecher Teufel.
With the iTeufel® Dock you have purchased
a high-performance docking station that
allows you to connect your iPod for example
to an amplifier, an active speaker or a TV.
In order to avoid complications, please read
the instructions fully before using the
appliance and keep them in a safe place for
future reference. If you have any further
questions please contact our engineers on
+ 49(30) 300 9 300 or send an e-mail using
the contact form on our website www.
teufel.eu. Please have your invoice number
ready so that we can deal with
your query as well and as
quickly as possible.
Please refer to our safety
information on Page 4 of
these instructions for use
and only use the Teufel
product once you have read
the safety information.

4 · iTeufel®Dock
Please note the
following safety infor-
mation.
Risk of suffocation -
keep packaging materials
(e.g. the plastic lm) out
of the reach and sight of
children.
Risk of electrocution -
do not leave children
unsupervised with
electrical appliances!
In case of emergency:
If any of the following oc-
cur disconnect the appli-
ance from the mains and
consult our technicians:
4If the plug or cable
are damaged
4If foreign bodies or li-
quid have entered the
appliance
4If the appliance has
been in direct contact
with rain or other wa-
ter
4If the appliance does
not play, even if you
have followed the in-
structions for use
4If the appliance has
been dropped or da-
maged in some other
way.
We cannot accept any re-
sponsibility for incidences
that occur because safety
information has not been
adhered to.
As a matter of principle, please read these instructions for
use very carefully! It is essential that you take note of all of the
safety information and instructions for use before starting the
appliance. Please keep this user guide in a safe place for future
reference.
Important: Please read the user guide. You should also follow all
instructions for start-up and ongoing use.
Information on cleaning: Please do not attempt to clean the
appliance using household chemicals because this could dama-
ge the surface. Simply use a dry cloth. Disconnect the appliance
from the mains before cleaning.
Caution - moisture and sunlight: Ensure that the appliance
does not come into contact with moisture! You should also pro-
tect the device against excessively high air humidity by not using
it in damp areas, e.g. in damp cellars; also avoid any use near wet
areas such as bathtubs, showers, washbasins, drains or swimming
pools etc. Direct sunlight should also be avoided! Do not expose
device to dripping or splashing water. Do not place objects filled
with liquids, such as vases on the device.
Information on location: Do not use the appliance unsecured
in vehicles, in unstable places, on wobbly tripods or furniture or
supports that are too small. The speakers could fall and cause
damage to people, including yourself. Speakers, particularly if
positioned on stands or on the TV/monitor, may fall and cause
damage due to their weight, even if they have been positioned
securely and basically protected against falling, as a result of
external influences(pulling on the cable, tripping over the cable,
unintentional physical contact). This also applies to wall supports
that have been attached inappropriately or incorrectly to walls
that may not be capable of supporting their weight. Only use sui-
table wall supports for mounting. Make sure that you know how
much weight the walls can bear. The appliance must not be placed
near sources of heat. This includes radiators and heaters, ovens
and other appliances that emit heat (e.g. amplifiers). No sources
of heat may be placed on the speakers such as fan heaters or
candles.
For ventilation: Slits and openings in the case have been pro-
vided for ventilation. Their purpose is to guarantee reliable
operation and to prevent the appliance from overheating. These
openings must not be blocked or covered, including by placing
the appliance on a bed, sofa, carpet or other soft surface. Do not
place any newspapers or table cloths etc. on the appliance. The
cooling plate of the amplifier electronics must not be covered
or exposed to direct sunlight. Additional active cooling of the
appliance is generally not permitted.
Electrical supply: The dock must only be supplied from a po-
wer source with the correct voltage as specified on the identi-
fication label. If you are unsure about the electricity supply in
your home, please contact us or your electricity supplier for
more information. The appliance does not need to be earthed.
Please only use the appropriate mains cable for connecting to
the mains socket. This mains cable must not be modified under
any circumstances. Regulations on polarity and earth connection
must be adhered to.
Information on wiring: Please place the supply cable flat and
flush to the wall and floor. Cables that are laid loosely represent a
risk of tripping. This could also result in interference and cause
the sound to be disrupted. The electricity supply cable should be
laid so that it is not likely to be stepped on or squashed from
the sides or above by heavy objects. Damaged cables must be
replaced. Pay particular attention to the cable/ plug connection,
the mains socket and the cable output from the dock. The power
supply cable and the cables that connect the dock should be che-
cked regularly for insulation faults or breaks. If a fault is discove-
red, the appliance and the cabling must be disconnected from the
mains immediately and the defective cable must be replaced.
During periods without use: Remove the dock’s power supply
cable from the socket for longer periods of absence or non-use.
During thunderstorms: In order to avoid damage caused by
lightening strikes, the appliance should be switched off and also
detached from the mains socket as soon as a thunderstorm is
expected.
Risk of overload: You should not overload wall sockets, extension
cables or integrated appliance sockets, because this could poten-
tially lead to short circuits and even fires. You should also avoid
turning up the volume very high(= approx. three quarters of the
control range) on the relevant amplifier, especially if you have in-
creased the bass using the bass control, the loudness button or
one of the deep bass boost switches.
Foreign bodies and liquids: Foreign bodies and liquids must not
get into the appliance via its openings under any circumstances,
because they could come into contact with parts carrying high
voltages,which could then cause short circuits and fires.Therefo-
re do not spill any liquids of any kind on the appliance.
Troubleshooting: Do not attempt to repair the appliance your-
self.Contact our service department first for authorisation if you
think that you can repair the fault yourself. Otherwise the appli-
ance must be sent to our service department’s address.
Information on spare parts: Lautsprecher Teufel will provide
you with spare parts during the warranty period. Your warranty
will not be invalidated if you replace the parts yourself on-site
using Lautsprecher Teufel spare parts.
Unusual sounds: If any unusual sounds occur during use or the
sound becomes distorted, the speaker output must be reduced
immediately so that the system plays an undistorted sound.
Connecting and changing the fuse: Disconnect the mains plug.
A faulty fuse may only be changed for one of the same type.
Information on volume: Loud noises can damage hearing.
In addition to physical damage, please be aware of possible
psychological consequences. Children and pets require
particular care. If necessary, set the volume control of your
signal source appliance to the lowest level. When the volume
is high always keep a certain distance from the appliance and
never have your ears right next to the speaker.
Safety information

5
· iTeufel®Dock
Contents
The iTeufel® Dock is supplied as a complete
system:
41 x iTeufel® Dock
41 x iTeufel® Dock remote control
41 x battery
iTeufel® Dock front
Remote control receiver
ON indicator
Electrical connection to the iPod
iPod socket
41 x iTeufel® Dock supply unit
45 x iPod inserts in different shapes
(1 insert is placed in the dock)
iTeufel® Dock back
Mains plug connection jack
Stereo audio output
Video output*
S-video output*
Before use please
check if the system is
complete.
Please note:
Empty boxes are not
available!
Completely remove the
items from the packaging
materials and place all of
the parts in front of you
to check them.
Do not use any sharp or
pointed objects to remove
the packaging materials.
These objects could
damage the surfaces and
cables of the products
supplied.
Please keep the boxes for
the eight-week return pe-
riod because we can only
repay the full purchase
price if the products are
returned in the ORIGINAL
PACKAGING in which they
were supplied.
Warning:
Explosion hazard with
inappropriate replace-
ment of the battery.
Replacement only by the
same or an equivalent
type. Not expose batteries
to excessively warms as
sunshine, re or like.
Attention:
The separating equipment
of this equipment is
the mains plug, this
separating equipment
must be usable without
difculties.
* Due to changes to the
operating software on the
part of the manufacturer
apple your iPod may not
work properly witch the
video outputs.
For detailed and up to
date information please
visit our website.
Unpacking .Contents .Connection

6 · iTeufel®Dock
Connection
1. Using the correct docking adaptor.
Select the docking adaptor that fits your
iPod from the five docking adaptors
supplied (Fig. A) and place it in the dock’s
support shell as shown in Fig. B.
Fig. A
2. Connecting the iPod and the dock.
Place your iPod in the dock socket and
carefully allow it to snap gently into the
embedded connection jack as shown in
Figure C.
Fig. B Fig. C
Information
Fully active subwoofers,
e.g. A 200/3 SW(Motiv 2),
have a stereo input pair
with cinch jacks just like
a conventional stereo
amplifier. The iTeufel®
Dock connects to these.
3. Connecting the dock and the amplifier/television
Connect the cable as shown in the diagram.

7
· iTeufel®Dock
Remote control • Use
Information
Do not drop the remote
control or step on it. This
could result in damage
that could cause the
remote control to stop
working.
If the remote control is
going to be out of use for
a longer period, please
remove the batteries to
prevent leakage.
Do not expose the
remote control to
unnecessary extra light.
Do not use the iTeufel®
Dock remote control at
the same time as other
remote controls.
Technical data
You can find the technical
data on our website.
You can comfortably control the functions
of your iPod using the remote control
supplied. The drive functions are related to
those of an iPod.
1. ON/Standby
2. Menu scroll up
3. Menu
4. Previous track
5. Enter
6. Play/pause
7. Treble control
8. Bass control
9. Reset
10. Menu scroll down
11. Next track
12. Volume
Changing the batteries
When inserting batteries, ensure that the “+”
and “-” poles exactly match the “+” and “-”
positions of the battery compartment.
1. Start
Switch on the appliance using
the standby button on the
remote control. A LED will first
flash then light up continuously.
The iPod is only charged when
the Start button has been pressed once.
Pressing the button again starts playback
mode.
2. iPod control
Using the remote control
corresponds to the normal
iPod control.
3. Volume
The “+” and “-” buttons
increase and decrease the
volume. During the change
the LED will flash. If the
maximum or minimum level
is reached the LED will light up
continuously.
4. Treble control
The “+” and “-” buttons
increase or reduce the
amount of treble. During
the change the LED will
flash. If the maximum or
minimum value is reached the LED will light
up continuously.
5. Bass control
The “+” and “-” buttons
increase or reduce the
amount of bass. During the
change the LED will flash. If
the maximum or minimum
value is reached the LED will light up
continuously.
6. Reset
This button returns the
appliance to its original
state.

Lautsprecher Teufel GmbH
Gewerbehof Bülowbogen - Aufgang D1
Bülowstr. 66
D-10783 Berlin(Germany)
Tel.: +49(30) - 30 09 300
Fax:+49(30) - 30 09 30 30
www.teufel.eu
Teufel
