INTRODUCTION
This is a 2 in 1 product. The Universal Serial Bus (USB) Hub is a three port device to connect
USB devices to your desktop computer or notebook. The USB Hub complies with USB 2.0
specification, and offers you the flexibility of two transfer rates. The 480Mbps rate is for devices
that require increasing bandwidth and 1.5Mbps is for low-speed devices like game pads and
joysticks. The high speed USB 2.0 all in one card reader can support all kinds of cards, with 4
different slots and Plug-and-play setup.
GENERAL INFORMATION AND SAFETY INSTRUCTIONS
Fully compliant with the Hi-Speed USB 2.0 specification.
Hi-Speed data transfer rates up to 480Mb/s.
Self-powered or bus powered (power adaptor included).
LED indicates card insertion and data transfer.
Memory Card Standard.
Supports the most popular Memory Cards.
Always read the safety instructions carefully.
Keep this User Manual for future reference.
Keep this equipment away from humidity.
Lay this equipment on a flat stable surface before setting it up.
If any of the following situations arise, get the equipment checked by our service centre:
The plug is damaged
The equipment has been exposed to moisture
The equipment has been dropped and damaged
If the equipment has obvious signs of breakage
The equipment is not working well or you cannot get it to work according to this User
Manual
Ensure that the mains supply is compatible with the adaptor configuration before
connecting to the power supply
ASSEMBLY AND PARTS LIST
Pack Contents
Please make sure that this package includes the following items:
USB Hub & Card Reader Combo
AC/DC power adapter 5V (2A)
USB Extension cable
User Manual

Helpline No.: UK/N. Ireland: 08 458 684 540 Rep. of Ireland: 076 60 600 29 5
Web Support: www.unisupport.net P50630
GETTING STARTED
Hardware installation
(Figure 1) A typical Hub architectural configuration.
AC/CD Adapter USB Hub Power Jack
Computer (cable A type male). Upstream (mini B type male) USB Hub Downstream
(device A type male cable) Devices (printer, keyboard, mouse, modem, digital camera, PDA,
joystick, etc).
(Figure 2)
U1~U3: USB 2.0 Hub A type connector (female).
Mini B: The interface connects to the USB port of the computer, USB B type connector
(female).
Power: DC Adaptor
LED: DC Jack/USB Host Power LED
LED

Helpline No.: UK/N. Ireland: 08 458 684 540 Rep. of Ireland: 076 60 600 29 6
Web Support: www.unisupport.net P50630
(Figure 3)
U1~U3: USB 2.0 Hub A type connector (female).
(Figure 4)
Power: DC Adaptor
Mini B: The interface connects to the USB port of the computer, USB B type connector
(female).
FEATURES
USB Hub






Three USB ports up to 100mA per port or up to 500mA (with power
adaptor - included).
Over current protection.
Supports both High-Speed (480 Mb/sec. with USB 2.0) and Full-Speed (12
Mb/sec. with USB 1.1) transfer rates.
Plug & Play.
Chains up to 127 USB devices.
USB and ACPI compliant.
Card Reader



Reader and Writer Support: Compact Flash / Micro Drive / Smart Media /
Multimedia / Secure Digital Card / Memory Stick / Memory Stick Pro /
XD-picture.
Reads high speed over 4.3 Mb/sec., writes high speed over 1.3Mb/sec..
Icons besides card slots are easy to distinguish.
OS

Windows XP, Windows 2000, Windows Vista.
Power

AC/DC power adapter DC 5V (2A).
Power Adaptor

Helpline No.: UK/N. Ireland: 08 458 684 540 Rep. of Ireland: 076 60 600 29 7
Web Support: www.unisupport.net P50630
INSTRUCTIONS
Installation
Installation of the USB Hub is easy. There are two different methods to connect the Hardware-
Bus, bus-powered and self-powered. You can choose either one of them to install your USB
Hub.
A bus-powered hub is a hub that draws all its power from the host computer's USB interface. It
does not need a separate power connection. However, many devices require more power than
this method can provide, and will not work in this type of hub.
A self-powered hub is one that takes its power from an external power supply unit and can
therefore provide full power to every port. The USB power is allocated in units of 100mA up to a
maximum total of 500mA per port.
Plug the DC plug into the DC (power) jack on the side panel of the Hub and (L2) LED will
activate.
FAQ
Q: How to check if the hub is installed and working correctly?
A: After complete installation of the USB 3Port Hub, go to My Computer and right click to
select Properties. Click the Hardware tab, and then click the Device Manager tab. Select
Universal Serial Bus Controllers, find the General Purpose USB Hub. Highlight that,
then go to the Property icon and check the Device Status, make sure it reads, “This
device is working properly.”
The Card Reader part of this device will install automatically and adds 4 extra device letters to
your system.
You will only be able to access these, when you have some type of flash card inserted in a slot.
OTHER USEFUL INFORMATION
Specifications
Interface

Universal Serial Bus (USB) 2.0.
Connector

Three A type (female) connectors and one B type (female) connector.
Cable

One USB cable.
Transfer
rate

High-Speed 480 Mb/sec. (USB 2.0), Full-Speed at 12 Mb/sec. (USB 1.1)
and Low-Speed at 1.5 Mb/sec. (game pads and joysticks).
LED

Power LED for USB cable plug in detection.
Power

AC/DC power adapter DC 5V (2A).
Enclosure

Plastic.
EMC

CE.
Adaptor

Input: 100-240V. Output power: 5V 2A.

Helpline No.: UK/N. Ireland: 08 458 684 540 Rep. of Ireland: 076 60 600 29 8
Web Support: www.unisupport.net P50630
Requirements

IBM PC/AT Compatible, Apple iMAC.

USB 2.0 Host card or USB 2.0 Hub device.

Windows 2000, Windows XP or Windows Vista operating system.
