Welcome
You have made an excellent choice with the purchase of this quality Tevion® brand product.
By doing so you now have the assurance and peace of mind which comes from purchasing
a product that has been manufactured to the highest standards of performance and safety,
supported by the high quality standards of Aldi.
We want you to be completely satised with your purchase so this (brand) product is
backed by a comprehensive manufacturer’s 3 year warranty and an outstanding after sales
service through our dedicated Helpline.
We hope you will enjoy using your purchase for many years to come.
If you require technical support or in the unlikely event that made your purchase is faulty
please telephone our Helpline for immediate assistance. Faulty product claims made within
the 3 year warranty period will be repaired or replaced free of charge provided that you
have satisfactory proof of purchase (keep your till receipt safe!) This does not aect your
statutory rights. However, be aware that the warranty will become null and void if the prod-
uct is found to have been deliberately damaged, misused or disassembled.
1

YEARS
WARRANTY
AFTER SALES SUPPORT
www.unisupport.com
076 60 600 29
IRE
08 458 684 540
GB
1 X Transmitter
1 X Receiver
2 x Power Adaptors
2 x A/V Connection Cables
2 x RCA-SCART Adaptors
1 X IR Remote Signal Extension Wire
1 X User Manual
1 X Warranty Documentation
MODEL: 48659
A. Product Description
Congratulations on purchasing this 2.4G series Wireless AV Transmitter & Receiver with Wire-
less IR Remote Extender. The advanced 2.4GHz wireless transmission has the advantages
of a long transmission range, strong anti-interference and high mobility. It can transmit AV
signals from DVD, DVR, CCD camera, IPTV, Satellite STB, Digital STB and other similar devices,
and wireless transmit the AV signal into your second TV set. Moreover, the IR remote control
extender can be used at the receiving end to control the device from the second TV set.
1. Functions and features
Uses 2.4GHz ISM frequency band, supporting 4 groups of channels. You can select•
these channels to avoid interference from signals from a wireless router, etc.
Wireless transmission range: 150 meters (depending on surrounding environment)•
The Transmitter and the Receiver use the same channel, pair then by setting then on•
the same channel.
Compatible with DVD, DVR, CCD camera, IPTV, Satellite STB, Digital STB, and any other•
AV devices.
433MHz Wireless IR Remote Extender is fully compatible with remote control signals of•
DVD, DVR, CCD camera, IPTV, satellite STB, digital TV STB and any other AV devices.
The product is equipped with a super strong IR signal transmitter.•
Images are received by using radio waves, the picture and sound is therefore very•
clear.
Supports video transmission of PAL/NTSC and stereo audio transmission.•
Plug and Play. There is no need to install software, easy and convenient.•
Dimensions: 10cm (L) ×8.5cm (W) ×3.0cm (H).•
2.4GHz module is FCC CLASS B certicated. Wireless application is safe and reliable.•
2. Applications
The AV Transmitter transmits the signal by using radio waves and can be used for wire-•
less sharing of AV signals from DVD, DVR, CCD camera, IPTV, Satellite STB, Digital STB
and any other AV devices.
Wireless AV transmission solutions are suitable for video conference or multimedia•
class rooms.
It can also be used in AV transmission applications where the AV cabling is dicult or•
expensive.
2

YEARS
WARRANTY
AFTER SALES SUPPORT
www.unisupport.com
076 60 600 29
IRE
08 458 684 540
GB
1 X Transmitter
1 X Receiver
2 x Power Adaptors
2 x A/V Connection Cables
2 x RCA-SCART Adaptors
1 X IR Remote Signal Extension Wire
1 X User Manual
1 X Warranty Documentation
MODEL: 48659
3. Content
1 x Transmitter
1 x Receiver
2 x Power adapter
2 x RCA cable
2 x Scart adapter
1 x IR extension
1 x User Manual
1 x Warranty Documentation
4. Specications
Power input: DC 5V = 1000mA
Video input: 1Vp-p(PAL/NTSC)
Audio input: 1.5Vp-p (Dual channel)
Video output: 1Vp-p(PAL/NTSC)
Audio output: 1.5Vp-p (Dual channel)
3

YEARS
WARRANTY
AFTER SALES SUPPORT
www.unisupport.com
076 60 600 29
IRE
08 458 684 540
GB
1 X Transmitter
1 X Receiver
2 x Power Adaptors
2 x A/V Connection Cables
2 x RCA-SCART Adaptors
1 X IR Remote Signal Extension Wire
1 X User Manual
1 X Warranty Documentation
MODEL: 48659
B. Hardware and Installation Instructions
1. Location
2. Transmitter panel description
(Vertically allocated) (Horizontally allocated) (Wall/hung)
4
antenna

YEARS
WARRANTY
AFTER SALES SUPPORT
www.unisupport.com
076 60 600 29
IRE
08 458 684 540
GB
1 X Transmitter
1 X Receiver
2 x Power Adaptors
2 x A/V Connection Cables
2 x RCA-SCART Adaptors
1 X IR Remote Signal Extension Wire
1 X User Manual
1 X Warranty Documentation
MODEL: 48659
3. Receiver panel description
4. Transmitter installation
Put the“Transmitter” near the STB/AV device and connect the AV wires with corre-•
sponding colors (Red, White, Yellow – OUTPUT from AV device).
In order to ensure the remote function using the Wireless IR Remote Extender, please•
arrange the IR eye close to the IR area on the STB/AV device.
Or you can try putting the transmitter above the STB/AV device so that the IR transmit-•
ting window is sticking out by 1 or 2cm and vertically aims at the receiving window of
the IR signal of the STB /AV device.
Please note
The receiving window for the IR signal of the STB/AV device is generally marked with “IR”.
Please vertically aim the IR signal transmitting window of the transmitter at it.
5
antenna

YEARS
WARRANTY
AFTER SALES SUPPORT
www.unisupport.com
076 60 600 29
IRE
08 458 684 540
GB
1 X Transmitter
1 X Receiver
2 x Power Adaptors
2 x A/V Connection Cables
2 x RCA-SCART Adaptors
1 X IR Remote Signal Extension Wire
1 X User Manual
1 X Warranty Documentation
MODEL: 48659
5. Receiver installation
6. Location of the antenna
Please pay attention to the location of the antenna. Make sure there is no obstacle around
the antenna, especially metal obstacles which may have serious impact on the wireless
transmission.
Please pay attention to the location of the antenna. Make sure there is no obstacle around
the antenna, especially metal obstacles which may have serious impact on the wireless
transmission.
6

YEARS
WARRANTY
AFTER SALES SUPPORT
www.unisupport.com
076 60 600 29
IRE
08 458 684 540
GB
1 X Transmitter
1 X Receiver
2 x Power Adaptors
2 x A/V Connection Cables
2 x RCA-SCART Adaptors
1 X IR Remote Signal Extension Wire
1 X User Manual
1 X Warranty Documentation
MODEL: 48659
C. Operation
1. Power Switch
Press the power switch to turn ON the Transmitter and Receiver.
Please note
To avoid damage to the product, please ensure that the power is disconnected when con-
necting the cables. The power can only be switched on after the connection is completed.
After the power is switched on, do not disconnect. If the product is not used for an ex-
tended period, please switch o the power.
2. Channel selection
Move the Channel switches to select which transmission channel you wish to use. The AV
signal can only be transmitted when the Transmitter and the Receiver are on the same chan-
nel.
Channel selection (move the switch down)
Please note
Please select the transmission channel from 1 to 4 that performs best in the actual environ-
ment. If there is interference from a router in the environment, please select another trans-
mission channel to avoid the interference source.
7

YEARS
WARRANTY
AFTER SALES SUPPORT
www.unisupport.com
076 60 600 29
IRE
08 458 684 540
GB
1 X Transmitter
1 X Receiver
2 x Power Adaptors
2 x A/V Connection Cables
2 x RCA-SCART Adaptors
1 X IR Remote Signal Extension Wire
1 X User Manual
1 X Warranty Documentation
MODEL: 48659
3. Wireless IR Remote Extender
If the connected STB/AV device is equipped with a remote control, you can use it to control
the second TV set through this product.
Transmitting RF
1. Transmission frequency: 433.92MHz±200KHz Superheterodyne
2. Carrier frequency: 38KHz
3. IR signal Receiving: ≤10m
Receiving RF
1. Transmission frequency: 433.92MHz±500KHz Superheterodyne
2. Carrier frequency: 38KHz
3. IR signal Transmitting:≤5m
Please note
If the Wireless IR Remote Extender is not sensitive enough, you may be able to adjust the
locations of the Transmitter and the Receiver. Keep them away from the AV connection wires
or other metal objects to ensure barrier-free signal transmission.
8

YEARS
WARRANTY
AFTER SALES SUPPORT
www.unisupport.com
076 60 600 29
IRE
08 458 684 540
GB
1 X Transmitter
1 X Receiver
2 x Power Adaptors
2 x A/V Connection Cables
2 x RCA-SCART Adaptors
1 X IR Remote Signal Extension Wire
1 X User Manual
1 X Warranty Documentation
MODEL: 48659
D. Commom problems and Troubleshooting
If the indicator does not light up and there is no image•
1. Check if the power to the Transmitter and Receiver is correctly connected and if
the power switch is on.
2. Change the transmission channel of the Transmitter and Receiver
(see: Channel selection).
3. Check if the AV connection wires of the Transmitter and Receiver are correctly
connected. (See: Hardware and installation instructions)
If the Wireless IR Remote Extender function fails•
1. Check if the IR signal extension wire is properly connected.
2. Adjust the locations of the Transmitter and the Receiver.
3. Disconnect the power to the Transmitter and the Receiver and restart after a few
minutes.
If the image has interference•
1. Change the transmission channel of the Transmitter and Receiver
(See: Channel selection).
2. Adjust the angle of the antenna on both the Transmitter and Receiver.
3. Place the Transmitter and Receiver on higher location if possible.
9

YEARS
WARRANTY
AFTER SALES SUPPORT
www.unisupport.com
076 60 600 29
IRE
08 458 684 540
GB
1 X Transmitter
1 X Receiver
2 x Power Adaptors
2 x A/V Connection Cables
2 x RCA-SCART Adaptors
1 X IR Remote Signal Extension Wire
1 X User Manual
1 X Warranty Documentation
MODEL: 48659
E. Warranty Details
Should your item become defective during the warranty period, in the first instance, please
call our customer service centre using the service number shown below.
We will at our discretion, either repair or exchange the device in accordance with warranty
legislation.
Please note the following terms under which guarantee claims can be made:
Our guarantee covers only problems caused by material or manufacturing defects, and it
is restricted to the rectification of these defects or the replacement of the equipment. It
does not cover replacement work for transport damage, damage caused by failure to follow
the assembly and operating instructions, damage through misuse or incorrect applica-
tions, damage caused by failure to follow the maintenance and safety instructions, damage
resulting from the use of force and external effects, or the normal wear and tear which arises
during the proper use of the product.
The guarantee is rendered null and void if any attempt is made to tamper with the equip-
ment.
No guarantee claims will be accepted after the end of the guarantee period.
The guarantee is valid for a period of three years starting from the purchase date. Please
keep your sales receipt in a safe place, as it is your proof of purchase and will be needed
when making a guarantee claim.
Your statutory rights are not affected by this guarantee.
During the guarantee period you can report defective equipment by phone or via the
website shown below.
After the guarantee period has elapsed you can still send a defective item to the address be-
low for repair. When the guarantee period has ended, you must pay the costs of all repairs.
This does not affect your statutory rights.
10

YEARS
WARRANTY
AFTER SALES SUPPORT
www.unisupport.com
076 60 600 29
IRE
08 458 684 540
GB
1 X Transmitter
1 X Receiver
2 x Power Adaptors
2 x A/V Connection Cables
2 x RCA-SCART Adaptors
1 X IR Remote Signal Extension Wire
1 X User Manual
1 X Warranty Documentation
MODEL: 48659 11
F. Disposal

YEARS
WARRANTY
AFTER SALES SUPPORT
www.unisupport.com
076 60 600 29
IRE
08 458 684 540
GB
1 X Transmitter
1 X Receiver
2 x Power Adaptors
2 x A/V Connection Cables
2 x RCA-SCART Adaptors
1 X IR Remote Signal Extension Wire
1 X User Manual
1 X Warranty Documentation
MODEL: 48659
Warranty Card
Wireless Video/Audio Sender
Please keep your purchase receipt together with your warranty card
Name
Address
Date of purchase
Location of purchase
Detailed description of malfunction:
12
