Tele Radio T9-02 User manual

safe smart strong
T 9
T 1 1
T9-02, T9-12 T11-04, T11-14
ENDUSER
INSTRUCTIONS
Transmitters:
ED-TG2-TX102-EN-v02
Language: English (original)

©Tele Radio AB
Datavägen 21
SE-436 32 Askim
Sweden
Phone: [phone]

Enduser instructions│T9/T11│
CHAPTER 1: INTRODUCTION 5
1.1About this document 7
1.2About Tiger TG2 systems 8
CHAPTER 2: SAFETY 9
2.1Warnings & restrictions 9
2.2Safety features 11
CHAPTER 3: TECHNICAL DATA 12
3.1Transmitter specifications 12
3.2Radio frequency band 13
CHAPTER 4: PRODUCT GENERAL DESCRIPTION 15
4.1Transmitter front 15
4.2Transmitter back 16
4.3Display and top LED 17
CHAPTER 5: STATUS AND ERROR INDICATIONS 18
5.1Top LED status indication 18
5.2Errorindications and messages 18
CHAPTER 6: OPERATION 19
6.1General information 19
6.2General navigation 19
6.3User permissions 20
6.4Functionality test 21
6.5Start a session (no PIN code) 22
6.6Start a session (PIN code required) 24
6.7Log the transmitter out from a receiver 26
6.8Switch the transmitter off 26
CHAPTER 7: BATTERY 27
7.1Battery precautions 27
7.2Battery information 29
CHAPTER 8: FOILS 33
8.1Affix a foil to the transmitter 33
CHAPTER 9: WARRANTY, SERVICE, REPAIRS, AND MAINTENANCE 34
CHAPTER 10: REGULATORY INFORMATION 35
10.1Europe 35
10.2North America 36
ED-TG2-TX102-EN-v02 3

Enduser instructions│T9/T11│
10.3AEC 39
ANNEX A: INDEX 40
4 ED-TG2-TX102-EN-v02

Enduser instructions│T9/T11│Chapter 1: Introduction
CHAPTER 1: INTRODUCTION
Thank you for using a Tele Radio AB product
READ ALL INSTRUCTIONS AND WARNINGS CAREFULLY BEFORE OPERATING
THE PRODUCTS.
These Enduser instructions have been published by Tele Radio AB and are not
subject to any warranty. The Enduser instructions may be withdrawn or revised by
Tele Radio AB at any time and without further notice. Corrections and updates will
be added to the latest version of the manual. Always download the Enduser
instructions from our website, www.tele-radio.com, for the latest available version.
Keep the safety instructions for future reference.
IMPORTANT! These instructions are intended for end users. The instructions can be
printed and handed to end user.
Tele Radio AB remote controls are often built into wider applications. This
documentation is not intended to replace the determination of suitability or
reliability of the product for specific user applications and should not be used for
this purpose. It is the responsibility of any such users or integrators to perform the
appropriate and complete risk analysis, evaluation and testing of the products with
respect to the relevant specific application or use. Tele Radio AB shall not be
responsible or liable for misuse of the information contained herein.
Always refer to the applicable local regulations for installation and safety
requirements relating to cranes, hoists, material handling applications, lifting
equipment, industrial machinery, and/or mobile hydraulic applications using Tele
Radio AB products, e.g.:
lapplicable local and industrial standards and requirements,
lapplicable occupational health and safety regulations,
lapplicable safety rules and procedures for the factory where the equipment is
being used,
luser and safety manuals or instructions of the manufacturer of the
equipment where Tele Radio AB remote control systems are installed.
Tele Radio AB Enduser instructions do not include or address the specific
instructions and safety warnings of the end product manufacturer.
For battery precautions, see "7.1 Battery precautions".
ED-TG2-TX102-EN-v02 5

Enduser instructions│T9/T11│Chapter 1: Introduction
Tele Radio AB products are covered by a warranty against material, construction, or
manufacturing faults. See "Chapter 9: Warranty, service, repairs, and maintenance".
6 ED-TG2-TX102-EN-v02

Enduser instructions│T9/T11│Chapter 1: Introduction
1.1About this document
Before installing or operating the product, read the corresponding documentation
carefully.
Tele Radio AB's product range is composed of transmitters, receivers, and
accessories intended for use together as a system.
These End user instructions cover general safety issues, main technical
specifications, standard operating instructions and battery information. Images
shown in this document are for illustrative purposes only.
Please report any error or omission in this document, as well as any improvement
or amendment suggestion to [e-mail].
1.1.1COPYRI GHT
Information in this document is subject to change without notice. No part of this
publication may be reproduced, stored in a retrieval system, or transmitted in any
form or by any means, electronic, photographic, mechanical (including
photocopying), recording or otherwise for any purpose other than the purchaser's
personal use without the written permission of Tele Radio AB.
1.1.2TERM AND SYMBOL DEFINITIONS
The capitalized terms and symbol used herein shall have the following meaning:
lWARNING: indicates a hazardous situation which, if not avoided, could result
in death or serious injury.
lCAUTION: indicates a hazardous situation which, if not avoided, will result in
minor or moderate injury.
lIMPORTANT: is used for information that requires special consideration.
lNOTE: is used to address practices not related to physical injury.
This symbol is used to call attention to safety messages that would be
assigned the signal words "WARNING"or "CAUTION".
ED-TG2-TX102-EN-v02 7

Enduser instructions│T9/T11│Chapter 1: Introduction
1.2About Tiger TG2 systems
The Tiger TG2 product range is composed of transmitters and receivers intended for
use together as a system in complex lifting applications such as cranes, OHT cranes
and electric hoists or mobile applications.
1.2.1ABOUT T9/T11 TRANSMITTERS
T9/T11 transmitters have simplex communication with support for duplex.
T9/T11 transmitters are compatible with all R4, R9 andR10 receivers within the
same frequency range.
Overview of the available models
Model
Step buttons transmitters
Number of buttons Display Available frequencies
6 8 10 12 433 MHz 915 MHz
T9-02 ● ● ●
T9-12 ● ● ●
T11-04 ● ● ●
T11-14 ● ● ●
●Standard
8 ED-TG2-TX102-EN-v02

Enduser instructions│T9/T11│Chapter 2: Safety
CHAPTER 2: SAFETY
2.1Warnings & restrictions
Carefully read through the following safety instructions before
proceeding with the installation, configuration, operation, or
maintenance of the product. Failure to follow these warnings could
result in death or serious injury.
This product must not be operated without having read and understood the
Enduser instructions and having received the appropriate training. The purchaser
of this product has been instructed how to handle the system safely. The following
information is intended for use as a complement to applicable local regulations
and standards.
IMPORTANT! Tele Radio AB remote controls are often built into wider
applications. These systems should be equipped with:
• a wired emergency stop where necessary
• a brake
• an audible or visual warning signal
2.1.1OPERATION
This radio system must not be used in areas where there is a risk of
explosion.
Only qualified personnel should be permitted to access the transmitter
and operate the equipment.
ED-TG2-TX102-EN-v02 9

Enduser instructions│T9/T11│Chapter 2: Safety
lAlways follow operating and maintenance instructions as well as all
applicable safety procedures and requirements.
lDo not open the receiver encapsulation unless you are qualified.
lYou must satisfy the age requirements in your country for operating
the equipment.
lIt is strictly prohibited to operate the equipment under the influence
of drugs, alcohol and/or medications.
lAlways test the transmitter stop button before operating it. Press the
stop button then twist and pull it out. This test should be done on
each shift, without a load.
lNever use a transmitter if the stop button is mechanically
damaged.Contact your supervisor or representative for service
immediately.
lNever leave the transmitter unattended.
lAlways switch the transmitter off when not in use. Store in a safe
place.
lKeep a clear view of the work area at all times.
2.1.2MAINTENANCE
Before maintenance intervention on any remote controlled equipments:
• always remove all electrical power from the equipment.
• always follow lockout procedures.
lKeep the safety information for future reference. Always download the
Enduser instructions from our website, www.tele-radio.com, for the latest
available version.
lIf error messages are shown, it is very important to find out what caused
them. Contact your representative for help.
lThe functionality of the stop button should be tested at least after every 200
hours’ use (see "2.2.1 Stop button").
lIf the stop button is mechanically damaged, do not use the transmitter.
Contact your supervisor or representative for service immediately.
lKeep the product in a clean, dry place.
lDo not try to open the encapsulation.
10 ED-TG2-TX102-EN-v02
