Texas Instruments TPA3123D2 User manual

User's GuideSLOU208 – August 2007
TPA3123D2 Audio Power Amplifier EVM
Contents1 Introduction ................................................................................................................... 22 Operation ..................................................................................................................... 43 TPA3123D2 EVM Schematic............................................................................................... 54 TPA3123D2 EVM PCB Layers ............................................................................................. 65 TPA3123D2 Evaluation Module Parts List ............................................................................... 8
List of Figures
1 TPA3123D2 Audio Power Amplifier EVM (Top View) ................................................................... 22 TPA3123D2 Audio Power Amplifier EVM (Bottom View) ............................................................... 33 TPA3123D2 EVM Schematic............................................................................................... 54 Top Side Layout.............................................................................................................. 65 Bottom Side Layout .......................................................................................................... 7
List of Tables
1 TPA3123D2 EVM Specifications .......................................................................................... 22 Gain Settings ................................................................................................................. 43 TPA3123D2 EVM Bill of Materials ......................................................................................... 8
SLOU208 – August 2007 TPA3123D2 Audio Power Amplifier EVM 1Submit Documentation Feedback

www.ti.com
1 Introduction
Introduction
The TPA3123D2 evaluation module consists of a single 25-W, class-D, stereo audio power amplifiercomplete with a small number of external components mounted on a circuit board that are used to directlydrive speakers with an external analog audio source as the input.
Table 1. TPA3123D2 EVM Specifications
VALUE UNIT
V
CC
Supply voltage range 10 to 30 VI
CC
Supply current, maximum 2 AP
O
Continuous output power, P
O
: 4 Ω, V
CC
= 27 V, THD+N = 10% 24 WZ
L
Minimum load impedance 3.2 Ω
Figure 1. TPA3123D2 Audio Power Amplifier EVM (Top View)
2TPA3123D2 Audio Power Amplifier EVM SLOU208 – August 2007Submit Documentation Feedback

www.ti.com
Introduction
Figure 2. TPA3123D2 Audio Power Amplifier EVM (Bottom View)
SLOU208 – August 2007 TPA3123D2 Audio Power Amplifier EVM 3Submit Documentation Feedback

www.ti.com
2 Operation
2.1 Quick Start List for Stand-Alone Operation
2.1.1 Power Supply
2.1.2 Evaluation Module Preparations
Operation
Follow these steps to use the TPA3123D2EVM stand-alone or when connecting it into existing circuits orequipment. Connections to the EVM module can be made by inserting stripped wire, or using bananaplugs for the power supply and output connections. The inputs accept standard RCA plugs.
1. Ensure that all external power sources are set to OFF.2. Connect an external regulated power supply adjusted from 10 V to 30 V to the module VCC (J7) andGND (J8) banana jacks taking care to observe marked polarity.
Inputs and Outputs:1. Connect an audio source to the input jacks, J9 and J10.2. Connect a speaker across GND (J5) and +ROUT (J6). Connect another speaker across LOUT (J3)and GND (J4)3. Install both gain jumpers GAIN0 (J1) and GAIN1 (J2). This sets the gain of the amplifier to the lowestlevel, 20 dB.
Control Inputs:1. SHUTDOWN: This terminal is active LOW. A LOW on the device terminal (<0.8 V) shuts down theamplifier; a HIGH (>2 V) on the device terminal places the amplifier in the active state. Holding downswitch SW1 places the amplifier in the SHUTDOWN state. Releasing SW1 returns the amplifier to theactive state. This terminal is V
CC
compliant.2. MUTE: This terminal is active HIGH. A HIGH (>2 V) on this terminal will immediately terminate audioplayback through the speakers; a LOW (<0.8 V) enables the device. The outputs remain switching withfifty percent duty cycle. SW2 on the EVM controls the state of the MUTE terminal. Holding down switchSW2 places the amplifier in the MUTE state. Releasing SW2 returns the amplifier to the active state.This terminal is V
CC
compliant.3. GAIN0/GAIN1: Together, these terminals determine the gain of the amplifier. See Table 2 . Installing ajumper in J1 or J2 sets the respective terminal to GND. Removing the jumper sets the respectiveterminals to VCC. Removing jumpers increases the gain while installing jumpers decreases the gain.Logic levels are TTL compatible. These terminals are V
CC
compliant.4. Power-off Depop Circuit: Additional circuitry to quiet power-off pop is provided on the EVM. Thiscircuit consists of shunt regulator D1, bipolar transistor Q4, and the surrounding components. Thiscircuit is activated by installing the jumper J11 which connects V
CC
to the network. The depop circuithas two different modes of operation. When R13 is installed, this circuit slowly pulls down the voltageon the Bypass pin when power is removed resulting in a controlled reduction of the Class D outputduty cycle. If R17 is installed, the network reduces the pop by pulling down the shutdown pin atpower-off. This approach can be used if the power supply operates in such a way that there is asignificant time delay between removal of power and the point where V
CC
falls below the chip UVLOlevel, which is approximately 8 volts.
Table 2. Gain Settings
GAIN0 (J1) GAIN1 (J2) Amplifier Gain (dB)
ON ON 20ON OFF 26OFF ON 32OFF OFF 36
TPA3123D2 Audio Power Amplifier EVM4 SLOU208 – August 2007Submit Documentation Feedback

www.ti.com
2.1.3 Power Up
3 TPA3123D2 EVM Schematic
RIGHT_OUT
LEFT_IN
RIGHT_IN
LEFT_OUT
VCC
VCC
VCC
VCC
VCC
VCC
C9 open
C16 open
Circuit inside dotted line is
for power down de-pop
improvement.
R3
10K
R3
10K
J4
-LOUT
J4
-LOUT
TP4TP4
SW1
SHUTDOWN
SW1
SHUTDOWN
U1U1
TPA3123
PVCCL
1
SD
2
PVCCL
3
MUTE
4
LIN
5
RIN
6
BYPASS
7
AGND
8
AGND
9
PVCCR
10
VCLAMP
11
PVCCR
12 PGNDR 13
PGNDR 14
ROUT 15
BSR 16
GAIN1 17
GAIN0 18
AVCC 19
AVCC 20
BSL 21
LOUT 22
PGNDL 23
PGNDL 24
THERMAL
25
C14
0.1uF C14 0.1uF
TP5TP5
R6
4.75K
R6
4.75K
L2
22uH
L2
22uH
J7
VCC
J7
VCC
R12
10K
R12
10K
C6
1.0uF C6 1.0uF
R9
0
R9
0
D2
Dl4148
R4
10K
R4
10K
C18
0.01uF
C18
0.01uF
R17 open
10
R17 open
10
TP12
RGND
TP12
RGND
SW2
MUTE
SW2
MUTE
TP3TP3
C12 0.22uFC12 0.22uF C9
1.0uF
C9
1.0uF
R16
20K
R16
20K
R7
4.75K
R7
4.75K
+
C8
470uF
+
C8
470uF
1
2
J8
GND
J8
GND
TP2TP2
J10
RIN
J10
RIN
2
3
1
R8
4.75K
R8
4.75K
J9
LIN
J9
LIN
2
3
1
R18 10K R18 10K
+
C10
470uF
+
C10
470uF
1 2
J11J11
1
2
TP10
GND
TP10
GND
C16
1.0uF
C16
1.0uF
R1
10K
R1
10K
C15 0.22uFC15 0.22uF
R13
150K
R13
150K
TP7
RIGHT_OUT
TP7
RIGHT_OUT
J5
-ROUT
J5
-ROUT
J1
GAIN0
J1
GAIN0
1
2
+
C17
470uF
+
C17
470uF
1 2
C3
1.0uF
C3
1.0uF
R15 open
1M
R15 open
1M
J3
+LOUT
J3
+LOUT
TP11
LGND
TP11
LGND
TP1
LEFT_IN
TP1
LEFT_IN
C19
0.68uF
C19
0.68uF
R2
10K
R2
10K
C
E
B
Q4
MMBT3904
C
E
B
Q4
MMBT3904
1
23
+
C2
470uF
+
C2
470uF
1
2
J6
+ROUT
J6
+ROUT
R10
0
R10
0
C11 open
10pF
C11 open
10pF
10pF
C21 open
10pF
C13
10uF C13 10uF
C4
1.0uF
C4
1.0uF
J2
GAIN1
J2
GAIN1
1
2
C7 0.1uFC7 0.1uF
C20
0.68uF
C20
0.68uF
TP6
LEFT_OUT
TP6
LEFT_OUT
R11
2.49K
R11
2.49K
10K
R19
10K
D1
TLV431ACDBZR
D1
TLV431ACDBZR
32
1
C1 0.1uFC1 0.1uF
TP9
INPUT_GND
TP9
INPUT_GND
TP8
RIGHT_IN
TP8
RIGHT_IN
L1
22uH
L1
22uH
C5
1.0uF C5 1.0uF
TPA3123D2 EVM Schematic
1. Verify correct voltage and input polarity, and turn the external power supplies ON.
The EVM should begin operation.1. Adjust the input signal.2. Adjust the control inputs to the desired settings.3. Adjust the amplifier gain by installing/removing the gain jumpers, J1 and J2.
Figure 3. TPA3123D2 EVM Schematic
SLOU208 – August 2007 TPA3123D2 Audio Power Amplifier EVM 5Submit Documentation Feedback

www.ti.com
4 TPA3123D2 EVM PCB Layers
3
TPA3123D2 EVM PCB Layers
The following illustrations depict the TPA3123D2 EVM PCB layers.
Figure 4. Top Side Layout
6TPA3123D2 Audio Power Amplifier EVM SLOU208 – August 2007Submit Documentation Feedback

www.ti.com
3
TPA3123D2 EVM PCB Layers
Figure 5. Bottom Side Layout
SLOU208 – August 2007 TPA3123D2 Audio Power Amplifier EVM 7Submit Documentation Feedback

www.ti.com
5 TPA3123D2 Evaluation Module Parts List
TPA3123D2 Evaluation Module Parts List
Table 3. TPA3123D2 EVM Bill of MaterialsRef. Description Size Qty Status Manufacturer Part Number
C1, C7, C14 Capacitor, ceramic, 0.1 μF, ±10%, X7R, 50V 0603 3 TDK C1608X7R1H104KT
C2, C8, C10,
Capacitor, Electrolytic, 470 μF, 35 V Radial 4 Nichicon UHE1V471MH06C17
C3–C6 Capacitor, ceramic, 1.0 μF, ±10%, X7R, 16V 0603 4 Taiyo Yuden EMK107BJ105KA-TR
C9, C16 Capacitor, ceramic, 1.0 μF, ±10%, X7R, 50V 0805 2 open TDK C3216X7R1H105K
Capacitor, ceramic, 0.22 μF, ±10%, X7R,C12, C15 0603 2 TDK C1608X7R1C224KT16V
Capacitor, ceramic, 10 μF, +80%/–20%,C13 1210 1 Murata GRM32DF51H106ZA01LY5V, 50V
C19, C20 Capacitor, metal poly, 0.68 μF, 63V Radial 2 EPCOS, Inc. B32529C684J
Inductor, 22 μH, radial lead, ferrite material,L1-L2 Radial 2 Toko A7503AY-220Mshielded
R1-R4 Resistor, chip, 10 k Ω, 1/16 W, 5% 0603 4 Panasonic ERA-V15J103V
R6, R7 Resistor, chip, 4.7 k Ω, 1/10 W, 5% 0603 2 Panasonic ERJ-3GEYJ472V
R9, R10 Resistor, chip, 0 Ω, 1/10 W, 5% 0603 2 Panasonic ERJ-3GEY0R00V
J1-J2 Phono Jack, PC mount, switched 2 Switchcraft PJRAN1X1U03
Banana Jack w/knurled Thumbnut (nickelJ3-J8 6 Johnson 111-2223-001plate)
J9-J10 Header, 2 position, Male 2mm 2 Norcomp 2163-36-01-P2
JP9-JP10
SHUNT, 2MM 2mm 2 Specialty 2JM-G(shunts)
SW1, SW2 Switch, momentary, SMD, Low profile 2 Panasonic EVQ-PPBA25
Standoffs, 5/8" length, 4-40 thread 4 Keystone 1808
Screws, 4-40, .375 4
U1 TPA3123D2PWP 24 pin TSSOP 1 TI TPA3123D2PWP
The following parts comprise the power-off depop circuit which is enabled by installing J11.
Capacitor, ceramic, 10 pF, ±10%, C0G,C11, C21 0603 2 open Murata GRM1885C2A100RA01D100V
Capacitor, ceramic, 0.01 μF, ±10%, X7R,C18 0603 1 TDK C1608X7R1H103K50V
D1 Shunt Regulator, Adjustable SOT-23-3 1 Texas Instruments TLV431ACDBZR
D2 Rectifier, Silicon, 0.15 A, 75V mini MELF 1 Micro Commercial DL4148-TP
Q4 Transistor, NPN, AMP SOT-23 1 Fairchild Semiconductor MMBT3904
R8 Resistor, chip, 4.7 k Ω, 1/10 W, 5% 0603 1 Panasonic ERJ-3GEYJ472V
R11 Resistor, chip, 2.49 k Ω, 1/10 W, 1% 0603 1 Vishay CRCW06032K49FKEA
R12, R18, R19 Resistor, chip, 10 k Ω, 1/16 W, 5% 0603 3 Panasonic ERA-V15J103V
R13 Resistor, chip, 150 k Ω, 1/10 W, 1% 0603 1 Vishay CRCW0603150KJNEA
R15 Resistor, chip, 1 M Ω, 1/10 W, 1% 0603 1 open Vishay CRCW06031M00FKEA
R16 Resistor, chip, 20 k Ω, 1/10 W, 1% 0603 1 Vishay CRCW060320K0FKEA
R17 Resistor, chip, 10 Ω, 1/16 W, 1% 0603 1 open Vishay CRCW060310R0FKEA
J11 Header, 2 position, Male 2mm 1 open Norcomp 2163-36-01-P2
