bq50002A Wireless Power TX EVM
bqTESLA is a trademark of Texas Instruments.
Avid is a registered trademark of Avid Technology, Inc..
User's Guide
SLUUBJ2–October 2016
bq50002A Wireless Power TX EVM
The bqTESLA™ wireless power transmitter evaluation module from Texas Instruments is a high-
performance, easy-to-use development module for the design of wireless power solutions. The bq50002A
evaluation module (EVM) provides all the basic functions of a Qi-compliant, wireless charger pad. The 5-V
input, single coil transmitter enables designers to speed the development of their end-applications. The
EVM supports both the Qi WPC 1.0, WPC 1.1, and WPC 1.2 receivers and will support output power up to
5 W.
Contents
1 Applications................................................................................................................... 2
2 bq50002AEVM-607 Electrical Performance Specifications ............................................................ 2
3 Modifications.................................................................................................................. 3
4 Connector and Test Point Descriptions................................................................................... 3
4.1 Input/Output Connections.......................................................................................... 3
4.2 Test Point Descriptions ............................................................................................ 4
5 Schematic and Bill of Materials ............................................................................................ 8
6 Test Setup................................................................................................................... 11
6.1 Equipment.......................................................................................................... 11
6.2 Equipment Setup.................................................................................................. 12
6.3 EVM Procedure.................................................................................................... 12
7 I2C Interface and bqStudio ................................................................................................ 16
7.1 EV2400 Set Up.................................................................................................... 16
7.2 bqStudio ............................................................................................................ 17
8 bq50002AEVM-607 Assembly Drawings and Layout ................................................................. 18
9 Reference ................................................................................................................... 20
List of Figures
1 bq50002AEVM-607 Schematic ............................................................................................ 8
2 Efficiency vs Power, bq50002AEVM-607 TX and bq51013BEVM-764 Receiver.................................. 14
3 Start Up...................................................................................................................... 14
4 Thermal Performance...................................................................................................... 15
5 Connections of the EV2400 kit ........................................................................................... 16
6 bqStudio Window........................................................................................................... 17
7 Assembly Top............................................................................................................... 18
8 Inner Layer 1................................................................................................................ 19
9 Inner Layer 2................................................................................................................ 19
10 Bottom Layer................................................................................................................ 20
List of Tables
1 bq50002AEVM-607 Electrical Performance Specifications ............................................................ 2
2 Bill of Materials............................................................................................................... 9

Applications www.ti.com
2SLUUBJ2–October 2016
Submit Documentation Feedback
Copyright © 2016, Texas Instruments Incorporated
bq50002A Wireless Power TX EVM
1 Applications
The bq50002AEVM-607 evaluation module demonstrates the transmitter portion of the bqTESLA™
wireless power system. This transmitter EVM is a complete transmitter-side solution that powers a
bqTESLA receiver. The EVM requires a single 5-V power supply capable of up to 2.0 A to operate and
combines the transmitter electronics, input power circuit, LED indicators, and the transmitting coil on the
single printed-circuit board (PCB). The open design allows easy access to key points of the electrical
schematic.
This EVM has the following features:
• Qi-Certified WPC 1.2 solution for 5-W operation
• 5-V input and fixed operation voltage
• Enhanced Foreign Object Detection (FOD)
• WPC 1.2 FOD
• Transmitter-coil mounting pad providing the correct receiver interface
• Highly-integrated analog front end including LDO, FETs, drivers, current sense amplifier, and de-
modulation circuit
• Standard WPC A11-type transmitter coil with no magnet
• LED and audio indication of power transfer
2 bq50002AEVM-607 Electrical Performance Specifications
Table 1 provides a summary of the EVM performance specifications. All specifications are given for an
ambient temperature of 25°C.
Table 1. bq50002AEVM-607 Electrical Performance Specifications
Parameter Notes and Conditions Min Typ Max Unit
Input Characteristics
VIN Input voltage 4.5 5 5.5 V
IIN Input current VIN = Nom, IOUT = 1 A at 5 V 1.4 A
Input no-load current VIN = Nom, IOUT = 0 A 165 mA
Input stand-by current VIN = Nom 4 mA
Output Characteristics – Receiver bq51013BEVM-764
VOUT Output voltage VIN = Nom, IOUT = 1 A , VOUT = 5 V 4.95 5.00 5.04 V
Output ripple VIN = Nom, IOUT = 1.0 A, VOUT = 5 V 200 mVPP
IOUT VIN = Min to Max VIN = Min to Max, VOUT = 5 V 0 1.5 A
Systems Characteristics
FSSwitching frequency During power transfer 110 205 kHz
ηpk Peak efficiency VIN = Nom, P Out RX = 3 W 74 %
ηFull-load efficiency VIN = Nom, IOUT = Max 71 %

www.ti.com Modifications
3
SLUUBJ2–October 2016
Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated
bq50002A Wireless Power TX EVM
3 Modifications
See the datasheet for bq50002A (SLUSBW1) or bq500511A (SLUSCN3) when changing components.
FOD – R27 threshold and R26 FOD_Cal (see Section 6.3.8)
4 Connector and Test Point Descriptions
4.1 Input/Output Connections
The connection points are described in Section 4.1.1 through Section 4.1.4.
4.1.1 J1 – VIN
Input power 5 V ±500 mV, return at J3.
4.1.2 J2 – USB Input
USB input connection.
4.1.3 J3 –GND
Return for input power, input at J1.
4.1.4 J4 – Serial Interface
I2C interface connection to communicate with the IC. Used with bqStudio tool to monitor behavior

Connector and Test Point Descriptions www.ti.com
4SLUUBJ2–October 2016
Submit Documentation Feedback
Copyright © 2016, Texas Instruments Incorporated
bq50002A Wireless Power TX EVM
4.2 Test Point Descriptions
The test points are described in Section 4.2.1 through Section 4.2.56.
4.2.1 TP1 – CS+
Current sense amplifier positive input.
4.2.2 TP2 – CS–
Current sense amplifier negative input.
4.2.3 TP3 – VIN
Input power, 5 V ±500 mV.
4.2.4 TP4 – GND
Return for input power.
4.2.5 TP5 –DMIN1
Modulation signal input from coil for DEMOD Channel 1.
4.2.6 TP6 –SW1
Switch node of the half bridge MOSFETs.
4.2.7 TP7 – GND
Low-noise ground test point (TP).
4.2.8 TP8 –Low-Noise Analog Ground
Low-noise ground TP.
4.2.9 TP9 – GND
Low-noise ground TP.
4.2.10 TP10 – GND
Low-noise ground TP.
4.2.11 TP11 – PGND
Return for SW1.
4.2.12 TP12 – DMIN2
Modulation signal input from coil for DEMOD Channel 2.
4.2.13 TP13 – PEAK
Peak detection.
4.2.14 TP14 – SW2
Switch node of the half-bridge MOSFETs.

www.ti.com Connector and Test Point Descriptions
5
SLUUBJ2–October 2016
Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated
bq50002A Wireless Power TX EVM
4.2.15 TP15 – BP3
Output of 3-V LDO.
4.2.16 TP16 – TANK
Coil signal at junction between transmitter coil and resonant capacitors.
4.2.17 TP17 – PGND
Return for SW2.
4.2.18 TP18 – PWM1/CLK
Input to control half-bridge MOSFETs connected to SW1 when PWM_CTRL is high. The operating
frequency/pulse width changes up or down depending on every rising edge of this periodic signal when
PWM_CTRL is low.
4.2.19 TP19 – PWM2/UPDN
Input to control half-bridge MOSFETs connected to SW2 when PWM_CTRL is high. Increase or decrease
power transfer when PWM_CTRL is low.
4.2.20 TP20 – CSO
Output of the current sense amplifier.
4.2.21 TP21 – DMOUT1
Demodulated 2-kHz bit stream from demodulation channel 1.
4.2.22 TP22 – DMOUT2
Demodulated 2-kHz bit stream from demodulation channel 2.
4.2.23 TP23 – BUZZ
DC output when power transfer is started. Can be used to drive a DC style buzzer or LED. See data sheet
for more information.
4.2.24 TP24 – LED_B
Status indication, typically RED.
4.2.25 TP25 – LED_A
Status indication, typically GREEN.
4.2.26 TP26 – LED_C
Status indication, typically ORANGE.
4.2.27 TP27 – LED_MODE
LED mode selection.
4.2.28 TP28 – T_SENSE
Temperature sensing for safety shutdown.

Connector and Test Point Descriptions www.ti.com
6SLUUBJ2–October 2016
Submit Documentation Feedback
Copyright © 2016, Texas Instruments Incorporated
bq50002A Wireless Power TX EVM
4.2.29 TP29 – FOD_CAL
FOD calibration.
4.2.30 TP30 – FOD_THR
FOD threshold.
4.2.31 TP31 – V_SENSE
Input voltage sense.
4.2.32 TP32 – FLIM
Leave floating to conform to WPC specification 205-kHz maximum operating frequency.
4.2.33 TP33 – ILIM
ILIM can be used to restrict the input current in order to operate with a limited input voltage source. Leave
this pin open if no fixed current limit should be used.
4.2.34 TP34 – Reserved IC Pin 5
Unused.
4.2.35 TP35 – Unused IC Pin 7
Leave this pin open.
4.2.36 TP36 – Unused IC Pin 25
Leave this pin open.
4.2.37 TP37 – Unused IC Pin 27
Leave this pin open.
4.2.38 TP38 - Unused IC Pin 17
Leave this pin open.
4.2.39 TP39 - Unused IC Pin 6
Leave this pin open.
4.2.40 TP40 - Unused IC Pin 24
Leave this pin open.
4.2.41 TP41 - Unused IC Pin 26
Leave this pin open.
4.2.42 TP42 - Unused IC Pin 18
Leave this pin open.
4.2.43 TP43 – CLK_IN
CLK_OUT signal from the internal oscillator of the bq50002A.

www.ti.com Connector and Test Point Descriptions
7
SLUUBJ2–October 2016
Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated
bq50002A Wireless Power TX EVM
4.2.44 TP44 – MODE
Control of frequency/pulse width of the internal generated oscillator signal.
4.2.45 TP45 – SDA
I2C data.
4.2.46 TP46 – SCL
I2C clock.
4.2.47 TP47 – 3-V Rail Resistor Divider
4.2.48 TP49 – Floating Test Point
4.2.49 TP50 – Floating Test Point
4.2.50 TP51 – GND
4.2.51 TP52 - Floating Test Point
4.2.52 TP53 - Floating Test Point
4.2.53 TP54 – GND
4.2.54 TP55 – Floating Test Point
4.2.55 TP56 – Floating Test Point
4.2.56 TP57 – GND
