Texas Instruments DAC7716EVM User manual

User's Guide
SBAU159–October 2009
DAC7716EVM
DAC7716EVM
This user's guide describes the characteristics, operation, and use of the DAC7716EVM. The evaluation
module (EVM) is an evaluation board that allows for quick and easy evaluation of the DAC7716. The
DAC7716 is a quad, high-accuracy, 12-bit R-2-R digital-to-analog converter (DAC). The device features
low-power operation, good linearity, and the ability to use different reference voltages for the output
channels. This EVM allows evaluation of all aspects of the DAC7716. Complete circuit descriptions,
schematic diagrams, and bill of material are included in this document.
The following related documents are available through the Texas Instruments web site at
http://www.ti.com.
EVM-Compatible Device Data Sheets
Device Literature Number
DAC7716 SBAS463
REF5025 SBOS410
REF5050 SBOS410
OPA211 SBOS377
TL750L08 SLVS017
All trademarks are the property of their respective owners.
1
SBAU159–October 2009 DAC7716EVM
Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated

EVM Overview www.ti.com
Contents
1 EVM Overview ............................................................................................................... 2
2 Analog Interface ............................................................................................................. 3
3 Digital Interface .............................................................................................................. 3
4 Power Supplies .............................................................................................................. 5
5 Reference Voltage .......................................................................................................... 5
6 EVM Operation .............................................................................................................. 6
7 Schematics and Layout .................................................................................................... 8
List of Figures
1 Reference Test Points...................................................................................................... 6
2 DAC7716EVM Default Jumper Locations ............................................................................... 7
3 Default Settings for Switch S1 (LDAC Low) ............................................................................ 8
4 Default Settings for Switch S2 and S3 ................................................................................... 8
List of Tables
1 J1: Analog Interface Pinout................................................................................................ 3
2 J2: Serial Interface Pins ................................................................................................... 4
3 J3 Configuration: Power-Supply Input.................................................................................... 5
4 DAC7716EVM Bill of Materials ........................................................................................... 9
1 EVM Overview
1.1 Features
DAC7716EVM:
• Contains all support circuitry needed for the DAC7716
• Voltage reference options: Either 5V or 2.5V onboard, or external
• Jumpers on output pins for gain adjustment
• Compatible with the TI Modular EVM System
This manual covers the operation of the DAC7716EVM. Throughout this document, the abbreviation EVM
and the term evaluation module are synonymous with the DAC7716EVM.
1.2 Introduction
The DAC7716 uses a high-speed SPI interface (up to 50MHz) to communicate with a DSP or a
microprocessor using a compatible serial interface. The DAC features four individual outputs whose gain
is controlled by the addition of a feedback resistor. An additional VMON pin can relay any of the four output
channels from the DAC or the signal from the AIN pin.
The DAC7716EVM is designed to run in either bipolar (default mode) or unipolar modes of operation. This
flexible design allows for a wide range of supply voltages. The operating mode can be controlled using an
onboard switch or digitally, through the digital header.
The DAC7716EVM is an evaluation module built to the TI Modular EVM System specification. It can be
connected to any modular EVM system interface card. The EVM ships in the TQFP-48 pin package
option.
Note that the DAC7716EVM has no microprocessor and cannot run software. To connect it to a computer,
some type of interface is required.
The device shown in the front-page figure is the DAC8734, the 16-bit version of the DAC7716. The
DAC7716 is installed in place of the DAC8734 on the DAC7716 evaluation module.
2DAC7716EVM SBAU159–October 2009
Submit Documentation Feedback
Copyright © 2009, Texas Instruments Incorporated

www.ti.com Analog Interface
2 Analog Interface
For maximum flexibility, the DAC7716EVM can interface to multiple analog sources. Samtec part numbers
SSW-110-22-F-D-VS-K and TSM-110-01-T-DV-P provide a 10-pin, dual-row, header at J1. This header
provides access to the analog input and output pins of the DAC. Consult Samtec at
http://www.samtec.com or call 1-800-SAMTEC-9 for a variety of mating connector options.
Table 1 summarizes the pinouts for analog interface J1.
Table 1. J1: Analog Interface Pinout
Pin Number Signal Description
J1.1 SGND-0 Signal GND DAC output 0
J1.2 VOUT-0 Analog output 0
J1.3 SGND-1 Signal GND DAC output 1
J1.4 VOUT-1 Analog output 1
J1.5 SGND-2 Signal GND DAC output 2
J1.6 VOUT-2 Analog output 2
J1.7 SGND-3 Signal GND DAC output 3
J1.8 VOUT-3 Analog output 3
J1.9-13 (odd) AGND Analog ground connections
J1.10 AIN Auxiliary analog input
J1.14 VMON_BUF Monitor output after buffer
J1.15 Unused —
J1.17-19 (odd) AGND Analog ground connections
J1.18 RefGND Reference ground pins on the
DAC7716 (see below)
J1.20 EXTREF+ External reference source input (+
side of reference input)
J1.12 Unused —
J1.16 Unused —
The analog interface is populated on the top of the evaluation model. This configuration makes it possible
to stack multiple EVMs to run them in daisy-chain mode. J4 can be installed with a 90-degree connector to
allow access to the analog outputs if multiple EVMs are stacked. The J1B connector can be installed if the
part is used as a standalone board.
The DAC7716 can be configured with an output gain of 2 or 4. By default, the analog outputs of the
DAC7716EVM are configured with a gain of 4. If a gain of 2 is desired, the proper jumper must be
installed (JP2-JP5, depending on the output channel), and the command register must be set accordingly.
The SGND pins of the DAC7716 are connected to the ground of the evaluation board.
The Auxiliary Analog Input pin can be further protected from over-voltage and over-driving conditions. A
Schottky diode (D1) can be installed to protect the DAC7716 from an input over-voltage condition. An op
amp buffer is placed on the VMON output to limit the current that passes through the pin.
The DAC7716EVM has an external reference voltage option. If an external reference voltage is used,
switches S2 and S3 must be properly configured. Use the EXTREF+ (J1.20) to apply an external
reference voltage.
The DAC7716 is designed to have the REFGND-A and REFGND-B pins within 0.3V of the AGND.
Therefore, we recommend not using the RefGND pin when connecting an external reference. Connect the
ground source of the reference voltage to the ground of the board (J1.19). See the Reference Voltage
section for more information.
3 Digital Interface
The DAC7716EVM is a serial input data converter. The evaluation module is designed for interfacing to
multiple control platforms.
3
SBAU159–October 2009 DAC7716EVM
Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated

Digital Interface www.ti.com
3.1 Serial Data Interface
Samtec part numbers SSW-110-22-F-D-VS-K and TSM-110-01-T-DV-P provide a 10-pin, dual-row,
header/socket combination at J2. This header/socket provides access to the digital control and serial data
pins from both J2A (top side) and J2B (bottom side) of the connector. Consult Samtec at
http://www.samtec.com or call 1-800-SAMTEC-9 for a variety of mating connector options.
Table 2 describes the serial interface pins.
Table 2. J2: Serial Interface Pins(1)
Pin No. Signal Name I/O Type Pullup Function
J2.1 Unused — —
J2.2 GPIO-0 In/Out High GPIO-0
J2.3 J2.5 SCLK In None DAC7716 SPI
clock; pins are
shorted together
J2.4 DGND In/Out None Digital ground
J2.6 GPIO-1 In/Out High GPIO-1
J2.7 J2.9 CS In None SPI bus chip select;
pins are shorted
together
J2.8 Uni/Bip A In High Output mode select
of Group A
J2.10 DGND In/Out None Digital ground
J2.11 SDO/SDI In/Out None DAC7716 SPI data
in/out
J2.12 Uni/Bip B In High Output mode select
of Group B
J2.13 Unused — —
J2.14 RST In High Input register reset
J2.15 LDAC In High GPIO signal to
control LDAC for
DAC output latch
update
J2.16 Unused — —
J2.17 LDAC In High Alternate GPIO
signal to control
LDAC for DAC
output latch update
J2.18 DGND In/Out None Digital ground
J2.19 Unused — —
J2.20 Unused — —
(1) Group A contains VOUT-0 and VOUT-1. Group B contains VOUT-2 and VOUT-3.
The SCLK signal and the CS signal can each be controlled by two different pins on J2. Pins J2.3 and J2.5
have been shorted together, as well as pins J2.7 and J2.9.
Pins J2.8, J2.12, J2.14, J2.15, and J2.17 have weak pull-up/pulldown resistors. These resistors provide
default settings for many of the control pins. J2.3, J2.5, J2.7, J2.9, J2.11 correspond directly to DAC7716
pins. See the DAC7716 product data sheet for complete details on these pins.
Control signals to and from the DAC7716 can be accessed through the digital interface, or switches and
jumpers found directly on the EVM. The /LDAC, Uni/Bip A, Uni/Bip B, and RST signals are initially pulled
high through 10kΩresistors and can be controlled by switch S1 or through J2.
The load DAC (LDAC) pin is connected via jumper JP1 to either the J2.15 or J2.17 pin. Updating the DAC
registers can be completed in two different ways. LDAC can either be tied to ground, in which case the
input registers are immediately updated, or LDAC can be pulled high. Therefore, the DAC registers update
when LDAC is taken low. Switch S1.1 can be closed to hold the LDAC low. See the DAC7716 data sheet
for more information on updating the DAC.
4DAC7716EVM SBAU159–October 2009
Submit Documentation Feedback
Copyright © 2009, Texas Instruments Incorporated

www.ti.com Power Supplies
4 Power Supplies
Samtec part numbers SSW-105-22-F-D-VS-K and TSM-105-01-T-DV-P provide a 5-pin, dual-row,
header/socket combination at J3. Table 3 lists the configuration details for J3. The voltage inputs to the
DAC can be applied directly to the device. The DAC7716 requires multiple power supplies to operate.
AVDD, AVSS, DVDD, and IOVDD are required to properly power the DAC.
Table 3. J3 Configuration: Power-Supply Input
Pin No. Pin Name Function Required
J3.1 +VA +4.75V to +24V analog supply Yes
J3.2 –VA –18V to –4.75V analog supply Yes
J3.3 +5VA +5V analog supply No
J3.4 –5VA –5V analog supply No
J3.5 DGND Digital ground input Yes
J3.6 AGND Analog ground input Yes
J3.7 +1.8VD 1.8V digital supply Optional
J3.8 +3.3VD 3.3V digital supply Optional
J3.9 VD1 Not used No
J3.10 +5VD +5V Yes
The Digital and Analog ground inputs are short-circuited internally through a ground plane.
The dc logic voltage for the DAC7716 (IOVDD) is selectable between +3.3VD, +1.8VD, or +5VD via the
JP8 jumper. These power-supply voltages are referenced to digital ground.
The DAC7716EVM is designed to work in either unipolar and bipolar mode. Each mode requires different
power-supply connections. Consult the DAC7716 data sheet for the restrictions on the power supplies for
the two operating modes.
5 Reference Voltage
The DAC7716EVM has the ability to use two different reference sources simultaneously for different
output channels. REFA and REFB control the reference voltages for the DAC. Output channels VOUT-0 and
VOUT-1 use REFA as a reference. REFB is used as a reference for output channels VOUT-2 and VOUT-3.
The evaluation module has three options for supplying reference voltages to the DAC7716. Switch S3
(REFA) and S2 (REFB) can select the reference voltage from the REF5050 (U5), REF5025 (U4) or use an
external reference. The REF5050 supplies 5.0V to the reference. The REF5025 supplies 2.5V to the
reference. These reference voltages are additionally filtered through an RC filter before connecting to the
DAC7716. The TL751L08 is used to voltage regulate +VA to properly power the REF5025 and REF5050.
When using an external reference, make sure that the ground terminal (from the external source) is
connected to the ground of the EVM board. There is a built-in diode in the DAC7716 that does not allow
the RefGND-A/RefGND-B to have more than a 0.3V difference from the board AGND on the DAC. A
jumper across pins 2 and 3 on JP6 and JP7 connects the RefGND-A and RefGND-B to the ground of the
board.
5
SBAU159–October 2009 DAC7716EVM
Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated

EVM Operation www.ti.com
Note that if an external reference voltage is input to J1.20, it will be filtered through a first-order, low-pass
RC filter. To input your own reference signal without this filter, connect the reference signal directly to TP1
or TP2. Figure 1 shows the reference test points on the EVM.
Figure 1. Reference Test Points
6 EVM Operation
This section provides information on the analog input, digital control, and general operating conditions of
the DAC7716EVM.
6.1 Analog Output
The DAC7716 has four analog outputs that are available through the J1 header or the J4 header. The J4
header is designed to use 90-degree Samtec pins (not installed) when multiple EVMs are stacked to be
used in daisy-chain mode.
Jumpers J5-J8 control the gain of the individual output channels by connecting additional feedback
resistors to the internal op amp buffer. See the DAC7716 data sheet for more information on setting the
gain. Each analog output is able to swing ±16V in bipolar mode and 0 to 20V in unipolar mode.
The signal ground, SGND-N (for the output signals), are connected to header J1 and are short-circuited to
the board ground. All of the output signals are referenced to the ground of the board.
VMON is the channel monitor output. It can relay any of the four analog output signals or the AIN signal. The
VMON signal is buffered and current-limited through the OPA227 (U2). By default, the VMON pin is in 3-state
mode, causing the op amp to saturate. In order to avoid the op amp saturating to a rail, a 200kΩresistor is
put in place. The resistor serves as a load for the op amp when the VMON pin is in 3-state mode. However,
as a result, there is an error of ~1% on the VMON_BUF signal when relaying a signal.
6.2 Digital Control
The digital control signals can be applied directly to J1 (top or bottom side). The modular DAC7716EVM
can also be connected directly to a DSP or microcontroller interface board.
No specific evaluation software is provided with this EVM; however, various code examples are available
that show how to use EVMs with a variety of digital signal processors from Texas Instruments. Check the
respective product folders or send an e-mail to [email protected] for a listing of available code
examples. The EVM Gerber files are also available on request.
6DAC7716EVM SBAU159–October 2009
Submit Documentation Feedback
Copyright © 2009, Texas Instruments Incorporated

www.ti.com EVM Operation
6.3 Default Jumper Settings and Switch Positions
Figure 2 shows the jumpers found on the EVM and the respective factory default conditions for each.
Figure 2. DAC7716EVM Default Jumper Locations
Jumper JP1 controls whether the LDAC signal is controlled by J2.15 or J2.17. By default, the LDAC signal
is controlled by J2.17 but can be changed using JP1.
Jumpers JP2, JP3, JP4, and JP5 are used to control the gain of the individual DAC channels. By default,
the jumpers are removed, resulting in each DAC channel having a gain of 4. The gain of the output
channel is 2 when the corresponding jumper is in place.
JP6 and JP7 control the signals applied to REFGND-A and REFGND-B on the DAC7716. By default, a
jumper is placed across JP6.2 and JP6.3 as well as JP7.2 and JP7.3. This jumper connects REFGND-A
and REFGND-B to the ground of the board when an onboard reference is used. When an external
reference source is used, it is recommended that this jumper stay in place and configure the external
reference source to share a common ground with the EVM. See the Reference Voltage section for more
information.
Jumper JP8 is used to control the digital voltage for IOVDD. By default, a jumper is in place to short-circuit
pins JP8.1 and JP8.2 to use a 3.3V digital supply. If pins JP8.3 and JP8.4 are connected, a 1.8V digital
supply will be used. If pins JP8.5 and JP8.6 are connected, a 5V digital supply will be used for IOVDD.
Jumper JP9 is not installed. If the user desires to disconnect RFB1 from VOUT1, the trace between JP9
must be cut. JP9 can then be installed.
7
SBAU159–October 2009 DAC7716EVM
Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated

Schematics and Layout www.ti.com
Switch S1 allows the user to pull down four control signals to ground. LDAC, Uni/Bip B, RST, and Uni/Bip
A can be pulled low using the switch. By default, switch position S1.1 is open, causing LDAC to be
connected to ground. Switches S1.2 and S1.4 are open to short-circuit Uni/Bip A and Uni/Bip B to ground.
This configuration sets the DAC7716 to bipolar mode (default). Figure 3 shows the default settings for
switch S1.
Figure 3. Default Settings for Switch S1 (LDAC Low)
Switch S2 controls the reference voltage selection for Ref B. When the switch is furthest left (position 1),
the onboard 5V reference is used from the REF5050. When the switch is in the middle position (position
2), the onboard 2.5V reference is used from the REF5025. If the switch is moved to the right (position 3),
Ref B is set up to use an external reference. Pins J1.18 (Ref–) and J1.20 (Ref+) are used to apply an
external reference voltage.
Switch S3 controls the reference voltage selection for Ref A. The switch has the same functionality as
switch S2. By default, switch S2 and switch S3 are set to use the 5V onboard reference, as Figure 4
shows.
Figure 4. Default Settings for Switch S2 and S3
7 Schematics and Layout
Schematics for the DAC7716EVM are appended to this user's guide. The bill of materials is provided in
Table 4.
7.1 Bill of Materials
NOTE: All components should be compliant with the European Union Restriction on Use of
Hazardous Substances (RoHS) Directive. Some part numbers may be either leaded or
RoHS. Verify that purchased components are RoHS-compliant. (For more information about
TI's position on RoHS compliance, see the TI web site.)
8DAC7716EVM SBAU159–October 2009
Submit Documentation Feedback
Copyright © 2009, Texas Instruments Incorporated

www.ti.com Schematics and Layout
space
Table 4. DAC7716EVM Bill of Materials(1)
Item No. Qty Ref Des Description Manufacturer Mfr Part Number
1 1 N/A Printed wiring board Texas Instruments 6508538
2 6 C1, C6, C10, Capacitor, ceramic 1.0µF 16V X5R TDK C1608X5R1C105K
C11, C14, C15 10% 0603
3 7 C2, C3, C4, Capacitor, ceramic 10µF 25V X5R MuRata GRM31CR61E106KA12L
C5, C7, C8, 1206 10%
C9
4 4 C12, C13, Capacitor, ceramic 10µF 10V 0603 Panasonic ECJ-1VB1A106M
C16, C 17 X5R 20%
5 0 D1 Not installed N/A N/A
6 3 JP1, JP6, JP7 Header strip, 3-pin (1x3) Samtec TSW-103-07-L-S
7 5 JP2, JP3, JP4, Header strip, 2-pin (1x2) Samtec TSW-102-07-L-S
JP5, JP9
8 1 JP8 Header strip, 6-pin (2x3) Samtec TSW-103-07-L-D
9 2 J1A, J2A 10-Pin, Dual Row, SM Header (20 Samtec TSM-110-01-T-DV-P
(Top Side) Pos.)
10 0 J1B Not installed N/A N/A
(Bottom Side)
11 1 J2B 10-Pin, Dual Row, SM Header (20 Samtec SSW-110-22-F-D-VS-K
(Bottom Side) Pos.)
12 1 J3A 5-Pin, Dual Row, SM Header (10 Pos.) Samtec TSM-105-01-T-DV-P
(Top Side)
13 1 J3B(2) 5-Pin, Dual Row, SM Header (10 Pos.) Samtec SSW-105-22-F-D-VS-K
(Bottom Side)
14 0 J4 Not installed N/A N/A
15 5 R1, R2, R3, Resistor 33 Ω1/10W 5% 0603 SMD Panasonic ERJ-3GEYJ330V
R4, R5
16 6 R6, R7, R8, Resistor 10 kΩ1/10W 5% 0603 SMD Yageo RC0603JR-0710KL
R9, R10, R11
17 2 R12, R13 Resistor 1.0 kΩ1/10W 5% 0603 SMD Panasonic ERJ-3GEYJ102V
18 2 R14, R15 Resistor 1.0 Ω1/10W 5% 0603 Panasonic ERJ-3GEYJ1R0V
19 1 R16 Resistor 200 kΩ1/10W 1% 0603 SMD Panasonic ERJ-3EKF2003V
20 1 S1 Switch Dip Tape 4 pos C&K TDA04H0SB1R
21 2 S2, S3 SW SLIDE ULTRA MINI SP3T TOP NKK SS14MDP2
ACT
22 3 TP1, TP2 ,TP3 Test Point - Single .025 Pin, Red Keystone 5000
23 2 TP4, TP5 Test Point - Single .025 Pin, Black Keystone 5001
24 1 U1 Quad, 12-bit, High Accuracy DAC, Texas Instruments DAC7716SPFB
TQFP Package
25 1 U2 OPA227, Differential Operational Texas Instruments OPA227UA
Amplifier
26 1 U3 Single output, 8V voltage regulator Texas Instruments TL750L08CD
27 1 U4 Precision Voltage reference 2.5V Texas Instruments REF5025AID
28 1 U5 Precision Voltage reference 5.0V Texas Instruments REF5050AID
29 8 N/A 0.100 Shunt - Black Samtec SNT-100-BK-T
(1) Manufacturer and part number for items may be substituted with electrically equivalent items.
(2) J3B parts are not shown in the schematic diagram. J3B is installed on the bottom side of the PWB opposite to J3A.
9
SBAU159–October 2009 DAC7716EVM
Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated

1 2 3 4 5 6
A
B
C
D
654321
D
C
B
A
ti
5411 EAST WILLIAMS BOULEVARD, TUCSON, AZ 85711 USA
TITLE
SHEET OF FILE
SIZE DATE REV
DRAWN BY
ENGINEER
REVISION HISTORY
REV ENGINEERING CHANGE NUMBER A ROVED
B
PRECISION ANALOG PRODUCTS
HIGH- ERFORMANCE ANALOG DIVISION
SEMICONDUCTOR GROU
DOCUMENT CONTROL NO.
Vmon 34
Vout-0 15
RFB1-0 17
RFB2-0 16
SGND-0 18
Vout-1 23
RFB1-1 21
RFB2-1 22
SGND-1 20
RFB1-2 44
Vout-2 46
RFB2-2 45
SGND-2 43
Vout-3 38
RFB1-3 40
RFB2-3 39
SGND-3 41
REFGND-A 29
REF-A 30
DVDD 14
AVSS 33 AVSS 28
AVDD 35 AVDD 26
IOVDD 13
CS
2
SCLK
3
SDI
4
SDO
5
LDAC
6
Ain
47
Uni/Bip A
10
Uni/Bip B
48
NC
36
NC
37
NC
1
NC
25
NC
24
NC
19
NC
12
NC
42
RST
7
DGND
11
AGND
27
G IO-1
9G IO-0 8
REF-B
31
REFGND-B
32
U1
DAC7716
-VA 2
-5VA 4
AGND 6
VD1 8
+5VD 10
+VA
1
+5VA
3
DGND
5
+1.8VD
7
+3.3VD
9
J3
DAUGHTER-POWER
VIN
2VOUT 6
TRIM 5 GND
4TEM
3
U5
REF5050
+VA -VA -5VA+1.8VD +5VD+3.3VD
+VA
+VA -VA
IOVDD
IOVDD
R8
10k
R9
10k
R10
10k
R11
10k
VIN
2VOUT 6
TRIM 5 GND
4TEM
3
U4
REF5025
2
4
6
1
3
5
7 8
9 10
11 12
13 14
15 16
17 18
19 20
J2B
Seri l He der Bottom
+5VD
1 8 2 7 3 6 4 5
S1
DIPSWITCH-4
-VA
+VA
-VA
JP6 nd JP7 control the RefGND
2
4
6
1
3
5
7 8
9 10
11 12
13 14
15 16
17 18
19 20
J2A
Seri l He der Top
CS
SCLK
SDI
SDO
LDAC
Uni/Bip A
Uni/Bip B
GPIO-0
GPIO-1
SCLK
LDAC
SDO
CS
GPIO-0
GPIO-1
Uni/Bip A
Uni/Bip B
RST
RST
GPIO-0
GPIO-1
Uni/Bip A
Uni/Bip B
RST
SDI
CS
SCLK
R1 33
R2 33
R3 33
R4 33
Vout-0
Vout-1
Vout-2
Vout-3
Ain
Vmon_buf
ExtREF-
ExtREF+
T. C l bri
T. C l bri
DAC8734EVM
+5VA
R7
10k
R6
10k
Output 1
Com 2
Com 3
Com 6
Com
7
Input
8
NC
5
NC
4
U3
TL750L08
2
3
6
74
U2
OPA227
An log to only be popul ted t top of bo rd
R12
1k
R13
1k
ExtREF+
R5 33
S3
NKK_SS14MDP2
CC
1
12
23
3
S2
NKK_SS14MDP2
A1
1K1 3
D1A
A2
3K2 2
D1B
6508538
C2
10uF
C3
10uF
C4
10uF
C5
10uF
C7
10uF
C8
10uF
C9
10uF
C1
1uF
C6
1uF
C10
1uF
C11
1uF
C15
1uF C13
10uF
C12
10uF
C14
1uF
C16
10uF
C17
10uF
JP2
JP3
JP4
JP5
JP1
3POS_JUMPER
JP7
3POS_JUMPER
JP6
3POS_JUMPER
1 2 3 4 5 6
JP8
JPR-2X3
TP1
TP2
A0(+) 2
A1(+) 4
A2(+) 6
A3(+) 8
A4 10
A5 12
A6 14
A7 16
REF- 18
REF+ 20
A0(-)
1
A1(-)
3
A2(-)
5
A3(-)
7
AGND
9
AGND
11
AGND
13
VCOM
15
AGND
17
AGND
19
J1A
DAUGHTER-ANALOG
1
2
3
4
5
6
7
8
J4
HEADER-8
R15
1
R14
1
TP4
TP3
TP5
R16
200k
2
4
6
1
3
5
7 8
9 10
11 12
13 14
15 16
17 18
19 20
J1B
DAUGHTER ANALOG BOTTOM
JP9
A
