Texas Instruments LMX2582EVM User manual

LMX2582EVM High Performance, Wideband
PLLatinum™ RF Synthesizer Evaluation Board
Operating Instructions
User's Guide
Literature Number: SNAU194
December 2015

Contents
1 Evaluation Board Setup ........................................................................................................ 3
2 EVM Software Startup Instructions......................................................................................... 5
3 EVM Software Navigation...................................................................................................... 6
4 Schematic........................................................................................................................... 8
5 BOM................................................................................................................................... 9
6 Layout............................................................................................................................... 11
2Contents SNAU194–December 2015
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated

3.3 V 1
3
2
OSCin
Vcc
100 MHz
@ +6 dBm
USB Cable
Phase Noise
Analyzer
Power
Supply
Sig Gen
4
RFout
USB2ANY 10 pin ribbon
cable
Laptop or PC
Chapter 1
SNAU194–December 2015
Evaluation Board Setup
Figure 1-1. Setup Diagram
1. Power:
(a) Set power supply to 3.3 V with 500-mA current limit.
(b) Connect VCC with SMA cable or clip to test point VCC_TP.
2. Input Signal
(a) Option 1 (default): The on-board Oscillator is powered on and outputs 100-MHz signal to OSCinP
(pin 8) of the device input.
(b) Option 2: MUST switch R14p to R14, which routes the input signal from the OSCinP SMA
connector instead of on-board Oscillator. Set a low phase noise signal generator to 100 MHz with
6-dBm power level. Connect to OSCinP or OSCinM if you have a single-ended signal. Connect to
both if you have a differential signal.
NOTE: Phase noise of input signal should be below –150 dBc/Hz at 10-kHz offset for 100-MHz
signal, otherwise the input reference noise will dominate the in-band phase noise at RF
output. The On-board Oscillator is only at –134 dBc/Hz.
3
SNAU194–December 2015 Evaluation Board Setup
Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated

www.ti.com
3. Output
(a) Connect RFoutAM or RFoutAP to a phase noise analyzer. Connect a 50-Ωtermination on the
unused output if you are using only single-end. Use a balan if you are using differential-ended.
4. Programming Interface
(a) Connect your laptop to the EVM as shown with included USB2ANY module.
4Evaluation Board Setup SNAU194–December 2015
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated

Chapter 2
SNAU194–December 2015
EVM Software Startup Instructions
1. Download TICS software from TI.com: http://www.ti.com/tool/TICSPRO-SW
2. To start the EVM software, open TICS.exe from installed directory.
5
SNAU194–December 2015 EVM Software Startup Instructions
Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated

LMX2582
Chapter 3
SNAU194–December 2015
EVM Software Navigation
1. The software should be opened as shown in Figure 3-1:
Figure 3-1. Software Screenshot
2. Top Menu
• File: Allows you to load or save a setting, export or import the registers in HEX values.
• USB Communications: Check your connection with the USB2ANY module. (If there is new
software follow the on-screen instructions to upgrade.) Load the device (the keyboard shortcut is
CTRL+L), which programs all the registers into the device.
• Default configuration: Load a pre-set setting file given to start from a known state.
• To select the LMX2582: Click Select Device on top menu. Click PLL + VCO and select LMX2582.
3. Left Panel
• User Controls: Here you can configure registers, organized by function. Hover your mouse over
the register and its information will appear in the Context tab on the left panel.
• Raw Registers: See the entire register map. Enter a HEX value in to the Data cell then click Write
Register to program that value. To read registers you must have MUXout pin (pin 20) connected to
the USB2ANY (by default it is connected to the LED, switch R40 to R39 for readback). Also set
MUXOUT_SEL=0 for readback. You can also read a register by the name of the register in
Register/Field Name section.
4. PLL
• Fosc: Enter the input signal frequency between 5 to 1400MHz
6EVM Software Navigation SNAU194–December 2015
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated

www.ti.com
• Doubler: Can double input signal frequency (input must be 50% duty cycle to use this)
• Pre-R divider: Divides frequencies up to 1400 MHz
• Multiplier: Multiplies frequencies between 40 to 70 MHz and outputs between 180 to 250 MHz
• R divider: Used for dividing frequencies below 5 MHz for very low PFD
• Charge Pump Gain: This tab will auto-update both UP and DN to be equal. Go to bits/pins section
if you want to force different values.
• Gain multiplier: Multiplies Charge Pump Gain by a factor
• State: Changes the charge pump output state
• FCAL_EN: Every time you change the output frequency, toggle this off or on to calibrate the device
to the frequency.
• Fvco: Set the VCO frequency between 3550 to 7100 MHz.
• Divider MUX: This determines which of the 3 segments is included for a total division between 2 to
192.
• Output MUX: Selects the signal from the VCO output or the Divider.
• Power Settings: Changes the output power (increase 0 to 31, then additional boost with 49 to 63).
5. Burst Mode
• Enter a register in Load Register or delay in seconds.
• You can run and stop the commands in a single burst or continuous loop.
7
SNAU194–December 2015 EVM Software Navigation
Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated

A
SV601260
A
PCB Number:
PCB Rev:
VCC 4 E/D
1
GND
2OUT 3
100MHz
Y1
CWX813-100.0M
1µF
C7
18
R20
68
R17
18
R14
18
R16
68
R19
18
R14p
1
2 3 4 5
OSCinM
142-0701-851
1
2 3 4 5
OSCinP
142-0701-851
18
R18
1
2 3 4 5
RFoutAM
142-0701-851
1 2
3 4
5 6
7 8
9 10
uWire
52601-S10- 8LF
Green
1 2
D1
330
R40
0.1µF
C6
10µF
C5
On Board Oscilla tor Option
SDI_TP
12k
R7
12k
R9
12k
R8
10
R15
CSB_TP
MUXout
0
R2
1
2 3 4 5
Vcc
142-0701- 851
10µF
C4
0
R10
0
R13
100pF
C17
1
2 3 4 5
RFoutBP
142-0701-851
1
2 3 4 5
RFoutBM
142- 0701- 851
100pF
C15
100pF
C14
100pF
C13
VccR F
12k
R4
Vcc
12k
R3 L1
LQG15HS18NJ02D
68
R25
68
R28
18
R24
18
R27
18
R26
18
R29
0.1µF
C3
MUXout_TP
L2
LQG15HS18NJ02D
Vcc
Vcc_TP
49.9
R32
49.9
R31
150
R2_LF
0.047µF
C2_LF
560pF
C1_LF
12
R3_LF
300pF
C3_LF
0
R4_LF
Vtune_TP
6800pF
C4_LF
680
R36
0.1µF
C11
0
R21
0.1µF
C12
0
R23
0.1µF
C20
0
R35
0
R37
0.1µF
C25
0
R39
MUXout
10µF
C21
10
µF
C23
10
µF
C22
10
µF
C27
10
µF
C24
1
µF
C26
1µF
C10
0.1µF
C8
0.1µ
F
C9
External Input Frequency Option
Pin5_TP
Pin28_TP
Pin32_TP
1
2 3 4 5
RFoutAP
142-0701-851
49.9
R33
100pF
C18
VccRF
0.1µF
C30
10µF
C29
10µF
C2
0
R1
0.1µF
C1
0.1µF
C16
VccRF
0
R30
0
R38
0.1µF
C28
CE
1
GND 2
VBIASVCO
3GND 4
NC 5
GND 6
VCCDIG
7
OSCINP
8
OSCINM
9
VREGIN
10
VCCCP
11
CPOUT 12
GND 13
GND 14
VCCMASH
15
SCK
16 SDI
17
RFOUTBP 18
RFOUTBM 19
MUXOUT 2 0
VCCBUF
21
RFOUTAM 22
RFOUTAP 23
CSB
24
GND 25
VCCVCO2
26
VBIASVCO2
27
NC 28
VREFVCO2
29
REXT 30
GND 31
NC 32
VBIASVARAC
33
GND 34
VTUNE 35
VREFVCO
36
VCCVCO
37
VREGVCO
38
GND 39
GND 40
GND 41
U1
LMX2582RHAR
0
R22
12k
R6
SCK_TP
12k
R11
12k
R5
GND_TP
12k
R12
Vcc
100pF
C19
49.9
R34
Chapter 4
SNAU194–December 2015
Schematic
Figure 4-1. Schematic
8Schematic SNAU194–December 2015
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated

Chapter 5
SNAU194–December 2015
BOM
DESIGNATOR DESCRIPTION MANUFACTURER PART NUMBER QUANTITY
!PCB Printed Circuit Board Any SV601260 1
C1, C3, C6, C8, C9, CAP, CERM, 0.1 µF, 16 V,
C11, C12, C16, C20, AVX 0603YC104JAT2A 12
±5%, X7R, 0603
C25, C28, C30 CAP, CERM, 560 pF, 50 V,
C1_LF Kemet C0603C561K5RACTU 1
±10%, X7R, 0603
CAP, CERM, 10 µF, 10 V,
C2, C4, C5, C29 Kemet C0805C106K8PACTU 4
±10%, X5R, 0805
CAP, CERM, 0.047 µF, 50 V,
C2_LF MuRata GRM188R71H473KA61D 1
±10%, X7R, 0603
CAP, CERM, 6800 pF, 50 V,
C4_LF MuRata GRM188R71H682KA01D 1
±10%, X7R, 0603
CAP, CERM, 1 µF, 16 V,
C7, C10 TDK C1608X7R1C105K 2
±10%, X7R, 0603
C13, C14, C15, C17, CAP, CERM, 100 pF, 50 V, MuRata GRM1535C1H101JDD5D 6
C18, C19 ±5%, C0G/NP0, 0402
C21, C22, C23, C24, CAP, CERM, 10 µF, 10 V, TDK C1608X5R1A106M 5
C27 ±10%, C0G/NP0, 0603
CAP, CERM, 1 µF, 6.3 V,
C26 TDK C1608X5R0J105K 1
±10%, X5R, 0603
CSB_TP, GND_TP,
MUXout_TP, Test Point, Compact, White, Keystone 5007 7
SCK_TP, SDI_TP, TH
Vcc_TP, Vtune_TP
D1 LED, Green, SMD Lite-On LTST-C190GKT 1
Inductor, Multilayer, Air Core,
L1, L2 MuRata LQG15HS18NJ02D 2
18 nH, 0.3 A, 0.36 Ω, SMD
OSCinM, OSCinP,
RFoutAM, RFoutAP, Connector, SMT, End launch Emerson Network Power 142-0701-851 7
RFoutBM, RFoutBP, SMA 50 ohm Connectivity
VCC
R1, R2, R4_LF, R10,
R13, R21, R22, R23, RES, 0 Ω, 5%, 0.1W, 0603 Vishay-Dale CRCW06030000Z0EA 12
R30, R35, R37, R38
R2_LF RES, 150, 5%, 0.1 W, 0603 Vishay-Dale CRCW0603150RJNEA 1
R3_LF RES, 12, 5%, 0.1 W, 0603 Vishay-Dale CRCW060312R0JNEA 1
R5, R6, R8, R11 RES, 12k Ω, 5%, 0.1 W, 0603 Vishay-Dale CRCW060312K0JNEA 4
R14p, R16, R18, R20 RES, 18 Ω, 5%, 0.1 W, 0603 Vishay-Dale CRCW060318R0JNEA 4
R15 RES, 10 Ω, 5%, 0.1 W, 0603 Vishay-Dale CRCW060310R0JNEA 1
R17, R19 RES, 68 Ω, 5%, 0.1 W, 0603 Vishay-Dale CRCW060368R0JNEA 2
R24, R26, R27, R29 RES, 18, 5%, 0.063 W, 0402 Vishay-Dale CRCW040218R0JNED 4
R25, R28 RES, 68, 5%, 0.063 W, 0402 Vishay-Dale CRCW040268R0JNED 2
R31, R33 RES, 49.9, 1%, 0.063 W, 0402 Vishay-Dale CRCW040249R9FKED 2
R36 RES, 680, 1%, 0.1 W, 0603 Yageo America RC0603FR-07680RL 1
R40 RES, 330 Ω, 5%, 0.1 W, 0603 Yageo America RC0603JR-07330RL 1
9
SNAU194–December 2015 BOM
Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated

www.ti.com
DESIGNATOR DESCRIPTION MANUFACTURER PART NUMBER QUANTITY
High Performance, Wideband
U1 PLLatinum RF Synthesizer, Texas Instruments LMX2582RHAR 1
RHA0040C
Header (shrouded), 100mil,
uWire FCI 52601-S10-8LF 1
5x2, Gold plated, SMD
OSC 100.0000 MHZ 3.3 V ±25
Y1 Connor-Winfield CWX813-100.0M 1
PPM SMD
10 BOM SNAU194–December 2015
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated

Chapter 6
SNAU194–December 2015
Layout
Figure 6-1. Top Overlay
Figure 6-2. Top Solder
11
SNAU194–December 2015 Layout
Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated

www.ti.com
Figure 6-3. Top Layer
Figure 6-4. Ground Layer
Figure 6-5. Power Layer
12 Layout SNAU194–December 2015
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated

www.ti.com
Figure 6-6. Bottom Layer
Figure 6-7. Bottom Solder
Figure 6-8. Bottom Overlay
13
SNAU194–December 2015 Layout
Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated

www.ti.com
Figure 6-9. Drill Drawing
Figure 6-10. Board Dimensions
14 Layout SNAU194–December 2015
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated

STANDARD TERMS AND CONDITIONS FOR EVALUATION MODULES
1. Delivery: TI delivers TI evaluation boards, kits, or modules, including any accompanying demonstration software, components, or
documentation (collectively, an “EVM” or “EVMs”) to the User (“User”) in accordance with the terms and conditions set forth herein.
Acceptance of the EVM is expressly subject to the following terms and conditions.
1.1 EVMs are intended solely for product or software developers for use in a research and development setting to facilitate feasibility
evaluation, experimentation, or scientific analysis of TI semiconductors products. EVMs have no direct function and are not
finished products. EVMs shall not be directly or indirectly assembled as a part or subassembly in any finished product. For
clarification, any software or software tools provided with the EVM (“Software”) shall not be subject to the terms and conditions
set forth herein but rather shall be subject to the applicable terms and conditions that accompany such Software
1.2 EVMs are not intended for consumer or household use. EVMs may not be sold, sublicensed, leased, rented, loaned, assigned,
or otherwise distributed for commercial purposes by Users, in whole or in part, or used in any finished product or production
system.
2Limited Warranty and Related Remedies/Disclaimers:
2.1 These terms and conditions do not apply to Software. The warranty, if any, for Software is covered in the applicable Software
License Agreement.
2.2 TI warrants that the TI EVM will conform to TI's published specifications for ninety (90) days after the date TI delivers such EVM
to User. Notwithstanding the foregoing, TI shall not be liable for any defects that are caused by neglect, misuse or mistreatment
by an entity other than TI, including improper installation or testing, or for any EVMs that have been altered or modified in any
way by an entity other than TI. Moreover, TI shall not be liable for any defects that result from User's design, specifications or
instructions for such EVMs. Testing and other quality control techniques are used to the extent TI deems necessary or as
mandated by government requirements. TI does not test all parameters of each EVM.
2.3 If any EVM fails to conform to the warranty set forth above, TI's sole liability shall be at its option to repair or replace such EVM,
or credit User's account for such EVM. TI's liability under this warranty shall be limited to EVMs that are returned during the
warranty period to the address designated by TI and that are determined by TI not to conform to such warranty. If TI elects to
repair or replace such EVM, TI shall have a reasonable time to repair such EVM or provide replacements. Repaired EVMs shall
be warranted for the remainder of the original warranty period. Replaced EVMs shall be warranted for a new full ninety (90) day
warranty period.
3Regulatory Notices:
3.1 United States
3.1.1 Notice applicable to EVMs not FCC-Approved:
This kit is designed to allow product developers to evaluate electronic components, circuitry, or software associated with the kit
to determine whether to incorporate such items in a finished product and software developers to write software applications for
use with the end product. This kit is not a finished product and when assembled may not be resold or otherwise marketed unless
all required FCC equipment authorizations are first obtained. Operation is subject to the condition that this product not cause
harmful interference to licensed radio stations and that this product accept harmful interference. Unless the assembled kit is
designed to operate under part 15, part 18 or part 95 of this chapter, the operator of the kit must operate under the authority of
an FCC license holder or must secure an experimental authorization under part 5 of this chapter.
3.1.2 For EVMs annotated as FCC – FEDERAL COMMUNICATIONS COMMISSION Part 15 Compliant:
CAUTION
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
FCC Interference Statement for Class A EVM devices
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
SPACER
SPACER
SPACER
SPACER
SPACER
SPACER
SPACER
SPACER

FCC Interference Statement for Class B EVM devices
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
3.2 Canada
3.2.1 For EVMs issued with an Industry Canada Certificate of Conformance to RSS-210
Concerning EVMs Including Radio Transmitters:
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may
cause undesired operation of the device.
Concernant les EVMs avec appareils radio:
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
Concerning EVMs Including Detachable Antennas:
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser)
gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type
and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for
successful communication. This radio transmitter has been approved by Industry Canada to operate with the antenna types
listed in the user guide with the maximum permissible gain and required antenna impedance for each antenna type indicated.
Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited
for use with this device.
Concernant les EVMs avec antennes détachables
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et
d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage
radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope
rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante. Le
présent émetteur radio a été approuvé par Industrie Canada pour fonctionner avec les types d'antenne énumérés dans le
manuel d’usage et ayant un gain admissible maximal et l'impédance requise pour chaque type d'antenne. Les types d'antenne
non inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de
l'émetteur
3.3 Japan
3.3.1 Notice for EVMs delivered in Japan: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_01.page 日本国内に
輸入される評価用キット、ボードについては、次のところをご覧ください。
http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_01.page
3.3.2 Notice for Users of EVMs Considered “Radio Frequency Products” in Japan: EVMs entering Japan may not be certified
by TI as conforming to Technical Regulations of Radio Law of Japan.
If User uses EVMs in Japan, not certified to Technical Regulations of Radio Law of Japan, User is required by Radio Law of
Japan to follow the instructions below with respect to EVMs:
1. Use EVMs in a shielded room or any other test facility as defined in the notification #173 issued by Ministry of Internal
Affairs and Communications on March 28, 2006, based on Sub-section 1.1 of Article 6 of the Ministry’s Rule for
Enforcement of Radio Law of Japan,
2. Use EVMs only after User obtains the license of Test Radio Station as provided in Radio Law of Japan with respect to
EVMs, or
3. Use of EVMs only after User obtains the Technical Regulations Conformity Certification as provided in Radio Law of Japan
with respect to EVMs. Also, do not transfer EVMs, unless User gives the same notice above to the transferee. Please note
that if User does not follow the instructions above, User will be subject to penalties of Radio Law of Japan.
SPACER
SPACER
SPACER
SPACER
SPACER

【無線電波を送信する製品の開発キットをお使いになる際の注意事項】 開発キットの中には技術基準適合証明を受けて
いないものがあります。 技術適合証明を受けていないもののご使用に際しては、電波法遵守のため、以下のいずれかの
措置を取っていただく必要がありますのでご注意ください。
1. 電波法施行規則第6条第1項第1号に基づく平成18年3月28日総務省告示第173号で定められた電波暗室等の試験設備でご使用
いただく。
2. 実験局の免許を取得後ご使用いただく。
3. 技術基準適合証明を取得後ご使用いただく。
なお、本製品は、上記の「ご使用にあたっての注意」を譲渡先、移転先に通知しない限り、譲渡、移転できないものとします。
上記を遵守頂けない場合は、電波法の罰則が適用される可能性があることをご留意ください。 日本テキサス・イ
ンスツルメンツ株式会社
東京都新宿区西新宿６丁目２４番１号
西新宿三井ビル
3.3.3 Notice for EVMs for Power Line Communication: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page
電力線搬送波通信についての開発キットをお使いになる際の注意事項については、次のところをご覧くださ
い。http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page
SPACER
4EVM Use Restrictions and Warnings:
4.1 EVMS ARE NOT FOR USE IN FUNCTIONAL SAFETY AND/OR SAFETY CRITICAL EVALUATIONS, INCLUDING BUT NOT
LIMITED TO EVALUATIONS OF LIFE SUPPORT APPLICATIONS.
4.2 User must read and apply the user guide and other available documentation provided by TI regarding the EVM prior to handling
or using the EVM, including without limitation any warning or restriction notices. The notices contain important safety information
related to, for example, temperatures and voltages.
4.3 Safety-Related Warnings and Restrictions:
4.3.1 User shall operate the EVM within TI’s recommended specifications and environmental considerations stated in the user
guide, other available documentation provided by TI, and any other applicable requirements and employ reasonable and
customary safeguards. Exceeding the specified performance ratings and specifications (including but not limited to input
and output voltage, current, power, and environmental ranges) for the EVM may cause personal injury or death, or
property damage. If there are questions concerning performance ratings and specifications, User should contact a TI
field representative prior to connecting interface electronics including input power and intended loads. Any loads applied
outside of the specified output range may also result in unintended and/or inaccurate operation and/or possible
permanent damage to the EVM and/or interface electronics. Please consult the EVM user guide prior to connecting any
load to the EVM output. If there is uncertainty as to the load specification, please contact a TI field representative.
During normal operation, even with the inputs and outputs kept within the specified allowable ranges, some circuit
components may have elevated case temperatures. These components include but are not limited to linear regulators,
switching transistors, pass transistors, current sense resistors, and heat sinks, which can be identified using the
information in the associated documentation. When working with the EVM, please be aware that the EVM may become
very warm.
4.3.2 EVMs are intended solely for use by technically qualified, professional electronics experts who are familiar with the
dangers and application risks associated with handling electrical mechanical components, systems, and subsystems.
User assumes all responsibility and liability for proper and safe handling and use of the EVM by User or its employees,
affiliates, contractors or designees. User assumes all responsibility and liability to ensure that any interfaces (electronic
and/or mechanical) between the EVM and any human body are designed with suitable isolation and means to safely
limit accessible leakage currents to minimize the risk of electrical shock hazard. User assumes all responsibility and
liability for any improper or unsafe handling or use of the EVM by User or its employees, affiliates, contractors or
designees.
4.4 User assumes all responsibility and liability to determine whether the EVM is subject to any applicable international, federal,
state, or local laws and regulations related to User’s handling and use of the EVM and, if applicable, User assumes all
responsibility and liability for compliance in all respects with such laws and regulations. User assumes all responsibility and
liability for proper disposal and recycling of the EVM consistent with all applicable international, federal, state, and local
requirements.
5. Accuracy of Information: To the extent TI provides information on the availability and function of EVMs, TI attempts to be as accurate
as possible. However, TI does not warrant the accuracy of EVM descriptions, EVM availability or other information on its websites as
accurate, complete, reliable, current, or error-free.
SPACER
SPACER
SPACER
SPACER
SPACER
SPACER

SPACER
6. Disclaimers:
6.1 EXCEPT AS SET FORTH ABOVE, EVMS AND ANY WRITTEN DESIGN MATERIALS PROVIDED WITH THE EVM (AND THE
DESIGN OF THE EVM ITSELF) ARE PROVIDED "AS IS" AND "WITH ALL FAULTS." TI DISCLAIMS ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, REGARDING SUCH ITEMS, INCLUDING BUT NOT LIMITED TO ANY IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT OF ANY
THIRD PARTY PATENTS, COPYRIGHTS, TRADE SECRETS OR OTHER INTELLECTUAL PROPERTY RIGHTS.
6.2 EXCEPT FOR THE LIMITED RIGHT TO USE THE EVM SET FORTH HEREIN, NOTHING IN THESE TERMS AND
CONDITIONS SHALL BE CONSTRUED AS GRANTING OR CONFERRING ANY RIGHTS BY LICENSE, PATENT, OR ANY
OTHER INDUSTRIAL OR INTELLECTUAL PROPERTY RIGHT OF TI, ITS SUPPLIERS/LICENSORS OR ANY OTHER THIRD
PARTY, TO USE THE EVM IN ANY FINISHED END-USER OR READY-TO-USE FINAL PRODUCT, OR FOR ANY
INVENTION, DISCOVERY OR IMPROVEMENT MADE, CONCEIVED OR ACQUIRED PRIOR TO OR AFTER DELIVERY OF
THE EVM.
7. USER'S INDEMNITY OBLIGATIONS AND REPRESENTATIONS. USER WILL DEFEND, INDEMNIFY AND HOLD TI, ITS
LICENSORS AND THEIR REPRESENTATIVES HARMLESS FROM AND AGAINST ANY AND ALL CLAIMS, DAMAGES, LOSSES,
EXPENSES, COSTS AND LIABILITIES (COLLECTIVELY, "CLAIMS") ARISING OUT OF OR IN CONNECTION WITH ANY
HANDLING OR USE OF THE EVM THAT IS NOT IN ACCORDANCE WITH THESE TERMS AND CONDITIONS. THIS OBLIGATION
SHALL APPLY WHETHER CLAIMS ARISE UNDER STATUTE, REGULATION, OR THE LAW OF TORT, CONTRACT OR ANY
OTHER LEGAL THEORY, AND EVEN IF THE EVM FAILS TO PERFORM AS DESCRIBED OR EXPECTED.
8. Limitations on Damages and Liability:
8.1 General Limitations. IN NO EVENT SHALL TI BE LIABLE FOR ANY SPECIAL, COLLATERAL, INDIRECT, PUNITIVE,
INCIDENTAL, CONSEQUENTIAL, OR EXEMPLARY DAMAGES IN CONNECTION WITH OR ARISING OUT OF THESE
TERMS ANDCONDITIONS OR THE USE OF THE EVMS PROVIDED HEREUNDER, REGARDLESS OF WHETHER TI HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. EXCLUDED DAMAGES INCLUDE, BUT ARE NOT LIMITED
TO, COST OF REMOVAL OR REINSTALLATION, ANCILLARY COSTS TO THE PROCUREMENT OF SUBSTITUTE GOODS
OR SERVICES, RETESTING, OUTSIDE COMPUTER TIME, LABOR COSTS, LOSS OF GOODWILL, LOSS OF PROFITS,
LOSS OF SAVINGS, LOSS OF USE, LOSS OF DATA, OR BUSINESS INTERRUPTION. NO CLAIM, SUIT OR ACTION SHALL
BE BROUGHT AGAINST TI MORE THAN ONE YEAR AFTER THE RELATED CAUSE OF ACTION HAS OCCURRED.
8.2 Specific Limitations. IN NO EVENT SHALL TI'S AGGREGATE LIABILITY FROM ANY WARRANTY OR OTHER OBLIGATION
ARISING OUT OF OR IN CONNECTION WITH THESE TERMS AND CONDITIONS, OR ANY USE OF ANY TI EVM
PROVIDED HEREUNDER, EXCEED THE TOTAL AMOUNT PAID TO TI FOR THE PARTICULAR UNITS SOLD UNDER
THESE TERMS AND CONDITIONS WITH RESPECT TO WHICH LOSSES OR DAMAGES ARE CLAIMED. THE EXISTENCE
OF MORE THAN ONE CLAIM AGAINST THE PARTICULAR UNITS SOLD TO USER UNDER THESE TERMS AND
CONDITIONS SHALL NOT ENLARGE OR EXTEND THIS LIMIT.
9. Return Policy. Except as otherwise provided, TI does not offer any refunds, returns, or exchanges. Furthermore, no return of EVM(s)
will be accepted if the package has been opened and no return of the EVM(s) will be accepted if they are damaged or otherwise not in
a resalable condition. If User feels it has been incorrectly charged for the EVM(s) it ordered or that delivery violates the applicable
order, User should contact TI. All refunds will be made in full within thirty (30) working days from the return of the components(s),
excluding any postage or packaging costs.
10. Governing Law: These terms and conditions shall be governed by and interpreted in accordance with the laws of the State of Texas,
without reference to conflict-of-laws principles. User agrees that non-exclusive jurisdiction for any dispute arising out of or relating to
these terms and conditions lies within courts located in the State of Texas and consents to venue in Dallas County, Texas.
Notwithstanding the foregoing, any judgment may be enforced in any United States or foreign court, and TI may seek injunctive relief
in any United States or foreign court.
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265
Copyright © 2015, Texas Instruments Incorporated
spacer

IMPORTANT NOTICE
Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, enhancements, improvements and other
changes to its semiconductor products and services per JESD46, latest issue, and to discontinue any product or service per JESD48, latest
issue. Buyers should obtain the latest relevant information before placing orders and should verify that such information is current and
complete. All semiconductor products (also referred to herein as “components”) are sold subject to TI’s terms and conditions of sale
supplied at the time of order acknowledgment.
TI warrants performance of its components to the specifications applicable at the time of sale, in accordance with the warranty in TI’s terms
and conditions of sale of semiconductor products. Testing and other quality control techniques are used to the extent TI deems necessary
to support this warranty. Except where mandated by applicable law, testing of all parameters of each component is not necessarily
performed.
TI assumes no liability for applications assistance or the design of Buyers’ products. Buyers are responsible for their products and
applications using TI components. To minimize the risks associated with Buyers’ products and applications, Buyers should provide
adequate design and operating safeguards.
TI does not warrant or represent that any license, either express or implied, is granted under any patent right, copyright, mask work right, or
other intellectual property right relating to any combination, machine, or process in which TI components or services are used. Information
published by TI regarding third-party products or services does not constitute a license to use such products or services or a warranty or
endorsement thereof. Use of such information may require a license from a third party under the patents or other intellectual property of the
third party, or a license from TI under the patents or other intellectual property of TI.
Reproduction of significant portions of TI information in TI data books or data sheets is permissible only if reproduction is without alteration
and is accompanied by all associated warranties, conditions, limitations, and notices. TI is not responsible or liable for such altered
documentation. Information of third parties may be subject to additional restrictions.
Resale of TI components or services with statements different from or beyond the parameters stated by TI for that component or service
voids all express and any implied warranties for the associated TI component or service and is an unfair and deceptive business practice.
TI is not responsible or liable for any such statements.
Buyer acknowledges and agrees that it is solely responsible for compliance with all legal, regulatory and safety-related requirements
concerning its products, and any use of TI components in its applications, notwithstanding any applications-related information or support
that may be provided by TI. Buyer represents and agrees that it has all the necessary expertise to create and implement safeguards which
anticipate dangerous consequences of failures, monitor failures and their consequences, lessen the likelihood of failures that might cause
harm and take appropriate remedial actions. Buyer will fully indemnify TI and its representatives against any damages arising out of the use
of any TI components in safety-critical applications.
In some cases, TI components may be promoted specifically to facilitate safety-related applications. With such components, TI’s goal is to
help enable customers to design and create their own end-product solutions that meet applicable functional safety standards and
requirements. Nonetheless, such components are subject to these terms.
No TI components are authorized for use in FDA Class III (or similar life-critical medical equipment) unless authorized officers of the parties
have executed a special agreement specifically governing such use.
Only those TI components which TI has specifically designated as military grade or “enhanced plastic” are designed and intended for use in
military/aerospace applications or environments. Buyer acknowledges and agrees that any military or aerospace use of TI components
which have not been so designated is solely at the Buyer's risk, and that Buyer is solely responsible for compliance with all legal and
regulatory requirements in connection with such use.
TI has specifically designated certain components as meeting ISO/TS16949 requirements, mainly for automotive use. In any case of use of
non-designated products, TI will not be responsible for any failure to meet ISO/TS16949.
Products Applications
Audio www.ti.com/audio Automotive and Transportation www.ti.com/automotive
Amplifiers amplifier.ti.com Communications and Telecom www.ti.com/communications
Data Converters dataconverter.ti.com Computers and Peripherals www.ti.com/computers
DLP® Products www.dlp.com Consumer Electronics www.ti.com/consumer-apps
DSP dsp.ti.com Energy and Lighting www.ti.com/energy
Clocks and Timers www.ti.com/clocks Industrial www.ti.com/industrial
Interface interface.ti.com Medical www.ti.com/medical
Logic logic.ti.com Security www.ti.com/security
Power Mgmt power.ti.com Space, Avionics and Defense www.ti.com/space-avionics-defense
Microcontrollers microcontroller.ti.com Video and Imaging www.ti.com/video
RFID www.ti-rfid.com
OMAP Applications Processors www.ti.com/omap TI E2E Community e2e.ti.com
Wireless Connectivity www.ti.com/wirelessconnectivity
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265
Copyright © 2015, Texas Instruments Incorporated
