This user's guide describes the characteristics, operation, and use of theTLV320AIC33EVM, both by itself and as part of the TLV320AIC33EVM-PDK. Thisevaluation module (EVM) is a complete stereo audio codec with several inputs andoutputs, extensive audio routing, mixing and effects capabilities. A complete circuitdescription, schematic diagram and bill of materials are also included.
The following related documents are available through the Texas Instruments web siteat www.ti.com .
EVM-Compatible Device Data Sheets
Device Literature Number
TLV320AIC33 SLAS480TAS1020B SLES025REG1117-3.3 SBVS001TPS767D318 SLVS209SN74LVC125A SCAS290SN74LVC1G125 SCES223SN74LVC1G07 SCES296
Contents1 EVM Overview ............................................................................................................... 22 Analog Interface .............................................................................................................. 33 Digital Interface .............................................................................................................. 44 Power Supplies .............................................................................................................. 55 EVM Operation ............................................................................................................... 66 Kit Operation ................................................................................................................. 77 EVM Bill of Materials ....................................................................................................... 41Appendix A TLV320AIC33EVM Schematic .................................................................................. 45Appendix B USB-MODEVM Schematic ...................................................................................... 46
List of Figures
1 TLV320AIC33EVM-PDK Block Diagram ................................................................................. 82 Default Software Screen .................................................................................................. 103 Interface Selection Window .............................................................................................. 114 I
2
C Address Selection Window .......................................................................................... 115 Audio Generator Screen .................................................................................................. 136 Audio Analyzer Screen ................................................................................................... 147 Audio Input Tab ............................................................................................................ 158 Audio Interface Tab ....................................................................................................... 179 Clocks Tab ................................................................................................................. 18
I
2
S, I
2
C are trademarks of Koninklijke Philips Electronics N.V.Windows is a trademark of Microsoft Corporation.SPI is a trademark of Motorola, Inc.LabView is a trademark of National Instruments.All trademarks are the property of their respective owners.
SBAU114 – November 2005 TLV320AIC33EVM and TLV320AIC33EVM-PDK User's Guide 1

www.ti.com
1 EVM Overview
1.1 Features
1.2 Introduction
EVM Overview
10 GPIO Tab ................................................................................................................... 2011 AGC Tab .................................................................................................................... 2112 Filters Tab .................................................................................................................. 2213 ADC Highpass Filter Settings ............................................................................................ 2314 Enabling Filters ............................................................................................................ 2315 Shelf Filters ................................................................................................................. 2416 EQ Filters ................................................................................................................... 2417 Analog Simulation Filters ................................................................................................. 2518 Preset Filters ............................................................................................................... 2619 De-emphasis Filters ....................................................................................................... 2720 User Filters ................................................................................................................. 2821 3D Effect Settings ......................................................................................................... 2922 DAC/Line Outputs Tab .................................................................................................... 3023 Output Stage Configuration Tab ......................................................................................... 3224 High Power Outputs Tab ................................................................................................. 3325 Command Line Interface Tab ............................................................................................ 3426 File Menu ................................................................................................................... 35
List of Tables
1 Analog Interface Pin Out .................................................................................................... 32 Alternate Analog Connectors ............................................................................................... 43 Digital Interface Pin Out ..................................................................................................... 44 Power Supply Pin Out ....................................................................................................... 55 List of Jumpers ............................................................................................................... 76 USB-MODEVM SW2 Settings ............................................................................................. 97 USB Control Endpoint HIDSETREPORT Request .................................................................... 368 Data Packet Configuration ................................................................................................ 369 GPIO Pin Assignments .................................................................................................... 3910 TLV320AIC33EVM Bill of Materials ...................................................................................... 4211 USB-MODEVM Bill of Materials .......................................................................................... 43
•Full-featured evaluation board for the TLV320AIC33 stereo audio codec.•Modular design for use with a variety of digital signal processor (DSP) and microcontroller interfaceboards.
The TLV320AIC33EVM-PDK is a complete evaluation kit, which includes a universal serial bus(USB)-based motherboard and evaluation software for use with a personal computer running the MicrosoftWindows™ operating system (Win2000 or XP).
The TLV320AIC33EVM is in Texas Instruments' modular EVM form factor, which allows direct evaluationof the device performance and operating characteristics, and eases software development and systemprototyping. This EVM is compatible with the 5-6K Interface Evaluation Module (SLAU104 ) and theHPA-MCUINTERFACE (SLAU106 ) from Texas Instruments and additional third-party boards whichsupport TI's Modular EVM format.
The TLV320AIC33EVM-PDK is a complete evaluation/demonstration kit, which includes a USB-basedmotherboard called the USB-MODEVM Interface board and evaluation software for use with a personalcomputer running the Microsoft Windows operating systems.
2TLV320AIC33EVM and TLV320AIC33EVM-PDK User's Guide SBAU114 – November 2005

www.ti.com
2 Analog Interface
Analog Interface
For maximum flexibility, the TLV320AIC33EVM is designed for easy interfacing to multiple analog sources.Samtec part numbers SSW-110-22-F-D-VS-K and TSM-110-01-T-DV-P provide a convenient 10-pin dualrow header/socket combination at J13 and J14. These headers/sockets provide access to the analog inputand output pins of the device. Consult Samtec at www.samtec.com or call 1-800-SAMTEC-9 for a varietyof mating connector options. Table 1 summarizes the analog interface pinout for the TLV320AIC33EVM..
Table 1. Analog Interface Pin OutPIN NUMBER SIGNAL DESCRIPTION
J13.1 HPLCOM High Power Output Driver (Left Minus or Multifunctional)
J13.2 HPLOUT High Power Output Driver (Left Plus)
J13.3 HPRCOM High Power Output Driver (Right Minus or Multifunctional)
J13.4 HPROUT High Power Output Driver (Right Plus)
J13.5 LINE1LM MIC1 or LINE1 Analog Input (Left Minus or Multifunctional)
J13.6 LINE1LP MIC1 or LINE1 Analog Input (Left Plus or Multifunctional)
J13.7 LINE1RM MIC1 or LINE1 Analog Input (Right Minus or Multifunctional)
J13.8 LINE1RP MIC1 or LINE1 Analog Input (Right Plus or Multifunctional)
J13.9 AGND Analog Ground
J13.10 MIC3L MIC3 Input (Left or Multifunctional)
J13.11 AGND Analog Ground
J13.12 MIC3R MIC3 Input (Right or Multifunctional)
J13.13 AGND Analog Ground
J13.14 MICBIAS Microphone Bias Voltage Output
J13.15 NC Not Connected
J13.16 MICDET Microphone Detect
J13.17 AGND Analog Ground
J13.18 NC Not Connected
J13.19 AGND Analog Ground
J13.20 NC Not Connected
J14.1 LINE2RM MIC2 or LINE2 Analog Input (Right Minus or Multifunctional)
J14.2 LINE2RP MIC2 or LINE2 Analog Input (Right Plus or Multifunctional)
J14.3 LINE2LM MIC2 or LINE2 Analog Input (Left Minus or Multifunctional)
J14.4 LINE2RP MIC2 or LINE2 Analog Input (Left Plus or Multifunctional)
J14.5 MONO_LOP Mono Line Output (Plus)
J14.6 MONO_LOM Mono Line Output (Minus)
J14.7 LEFT_LOP Left Line Output (Plus)
J14.8 LEFT_LOM Left Line Output (Minus)
J14.9 AGND Analog Ground
J14.10 RIGHT_LOP Right Line Output (Plus)
J14.11 AGND Analog Ground
J14.12 RIGHT_LOM Right Line Output (Minus)
J14.13 AGND Analog Ground
J14.14 NC Not Connected
J14.15 NC Not Connected
J14.16 NC Not Connected
J14.17 AGND Analog Ground
J14.18 NC Not Connected
J14.19 AGND Analog Ground
J14.20 NC Not Connected
SBAU114 – November 2005 TLV320AIC33EVM and TLV320AIC33EVM-PDK User's Guide 3

www.ti.com
3 Digital Interface
Digital Interface
In addition to the analog headers, the analog inputs and outputs may also be accessed through alternateconnectors, either screw terminals or audio jacks. The stereo microphone input is also tied to J6 and thestereo headphone output (the HP set of outputs) is available at J7.
Table 2 summarizes the screw terminals available on the TLV320AIC33EVM.
Table 2. Alternate Analog Connectors
DESIGNATOR PIN 1 PIN 2 PIN3
J1 LINE1LP LINE1LMJ2 LINE1RP LINE1RMJ3 LINE2LP LINE2LMJ4 LINE2RP LINE2RMJ5 MIC3 IN LEFT MIC3 IN RIGHT AGNDJ11 (+) HPLOUT (-) HPLCOMJ12 (+) HPROUT (-) HPRCOM
The TLV320AIC33EVM is designed to easily interface with multiple control platforms. Samtec partnumbers SSW-110-22-F-D-VS-K and TSM-110-01-T-DV-P provide a convenient 10-pin dual rowheader/socket combination at J16 and J17. These headers/sockets provide access to the digital controland serial data pins of the device. Consult Samtec at www.samtec.com or call 1-800- SAMTEC-9 for avariety of mating connector options. Table 3 summarizes the digital interface pinout for theTLV320AIC33EVM.
Table 3. Digital Interface Pin Out
PIN NUMBER SIGNAL DESCRIPTION
J16.1 NC Not ConnectedJ16.2 GPIO1 General Purpose Input/Output #1J16.3 SCLK SPI Serial ClockJ16.4 DGND Digital GroundJ16.5 NC Not ConnectedJ16.6 GPIO2 General Purpose Input/Output #2J16.7 /SS SPI Chip SelectJ16.8 RESET INPUT Reset signal input to AIC33EVMJ16.9 NC Not ConnectedJ16.10 DGND Digital GroundJ16.11 MOSI SPI MOSI Slave Serial Data InputJ16.12 SPI SELECT Select Pin (SPI vs I
2
C Control Mode)J16.13 MISO SPI MISO Slave Serial Data OutputJ16.14 AIC33 RESET ResetJ16.15 NC Not ConnectedJ16.16 SCL I
2
C Serial ClockJ16.17 NC Not ConnectedJ16.18 DGND Digital GroundJ16.19 NC Not ConnectedJ16.20 SDA I
2
C Serial Data Input/OutputJ17.1 NC Not ConnectedJ17.2 NC Not ConnectedJ17.3 BCLK Audio Serial Data Bus Bit Clock (Input/Output)J17.4 DGND Digital Ground
TLV320AIC33EVM and TLV320AIC33EVM-PDK User's Guide4 SBAU114 – November 2005

www.ti.com
4 Power Supplies
4.1 Stand-Alone Operation
Power Supplies
Table 3. Digital Interface Pin Out (continued)
PIN NUMBER SIGNAL DESCRIPTION
J17.5 NC Not ConnectedJ17.6 NC Not ConnectedJ17.7 WCLK Audio Serial Data Bus Word Clock (Input/Output)J17.8 NC Not ConnectedJ17.9 NC Not ConnectedJ17.10 DGND Digital GroundJ17.11 DIN Audio Serial Data Bus Data Input (Input)J17.12 NC Not ConnectedJ17.13 DOUT Audio Serial Data Bus Data Output (Output)J17.14 NC Not ConnectedJ17.15 NC Not ConnectedJ17.16 SCL I
2
C Serial ClockJ17.17 MCLK Master Clock InputJ17.18 DGND Digital GroundJ17.19 NC Not ConnectedJ17.20 SDA I
2
C Serial Data Input/Output
Note that J17 comprises the signals needed for an I
2
S™ serial digital audio interface; the control interface( I
2
C™ and RESET) signals are routed to J16. I
2
C is actually routed to both connectors; however, thedevice is connected only to J16.
J15 provides connection to the common power bus for the TLV320AIC33EVM. Power is supplied on thepins listed in Table 4 .
Table 4. Power Supply Pin Out
SIGNAL PIN NUMBER SIGNAL
NC J15.1 J15.2 NC+5VA J15.3 J15.4 NCDGND J15.5 J15.6 AGNDDVDD (1.8V) J15.7 J15.8 NCIOVDD (3.3V) J15.9 J15.10 NC
The TLV320AIC33EVM-PDK motherboard (the USB-MODEVM Interface board) supplies power to J15 ofthe TLV320AIC33EVM. Power for the motherboard is supplied either through its USB connection or viaterminal blocks on that board.
When used as a stand-alone EVM, power can be applied to J15 directly, making sure to reference thesupplies to the appropriate grounds on that connector.
CAUTIONVerify that all power supplies are within the safe operating limits shown onthe TLV320AIC33 data sheet before applying power to the EVM.
SBAU114 – November 2005 TLV320AIC33EVM and TLV320AIC33EVM-PDK User's Guide 5

www.ti.com
4.2 USB-MODEVM Interface Power
5 EVM Operation
5.1 Analog Input
5.2 Analog Output
5.3 Digital Control
EVM Operation
The USB-MODEVM Interface board can be powered from several different sources:•USB
•6VDC-10VDC AC/DC external wall supply (not included)•Lab power supply
When powered from the USB connection, JMP6 should have a shunt from pins 1–2 (this is the defaultfactory configuration). When powered from 6V-10VDC, either through the J8 terminal block or J9 barreljack, JMP6 should have a shunt installed on pins 2–3. If power is applied in any of these ways, onboardregulators generate the required supply voltages and no further power supplies are necessary.
If lab supplies are used to provide the individual voltages required by the USB-MODEVM Interface, JMP6should have no shunt installed. Voltages are then applied to J2 (+5VA), J3 (+5VD), J4 (+1.8VD), and J5(+3.3VD). The +1.8VD and +3.3VD can also be generated on the board by the onboard regulators fromthe +5VD supply; to enable this configuration, the switches on SW1 need to be set to enable theregulators by placing them in the ON position (lower position, looking at the board with text readingright-side up). If +1.8VD and +3.3VD are supplied externally, disable the onboard regulators by placingSW1 switches in the OFF position.
Each power supply voltage has an LED (D1-D7) that lights when the power supplies are active.
This section provides information on the analog input and output, digital control, and general operatingconditions of the TLV320AIC33EVM.
The analog input sources can be applied directly to J13 (top or bottom side) or through signal conditioningmodules available for the modular EVM system.
The analog inputs may also be accessed through J6 and and screw terminals J1, J2, and J3.
The analog outputs from the TLV320AIC33 are available on J13 and J14 (top or bottom). They also maybe accessed through J4, J5, J7, J11,and J12.
The digital control signals can be applied directly to J16 and J17 (top or bottom side). The modularTLV320AIC33EVM can also be connected directly to a DSP interface board, such as the5-6KINTERFACE or HPA-MCUINTERFACE, or to the USB-MODEVM Interface board if purchased as partof the TLV320AIC33EVM-PDK. See the product folder for this EVM or the TLV320AIC33 for a current listof compatible interface and/or accessory boards.
6TLV320AIC33EVM and TLV320AIC33EVM-PDK User's Guide SBAU114 – November 2005

www.ti.com
5.4 Default Jumper Locations
6 Kit Operation
6.1 TLV320AIC33EVM-PDK Block Diagram
Kit Operation
Table 5 provides a list of jumpers found on the EVM and their factory default conditions.
Table 5. List of Jumpers
DEFAULTJUMPER POSITION JUMPER DESCRIPTION
JMP1 2-3 When connecting 2-3, mic bias comes from the MICBIAS pin on the device; whenconnecting 1-2, mic bias is supplied from the power supply through a resistor, whichthe user must install.JMP2 Installed Connects on-board Mic to Left Microphone Input.JMP3 Installed Connects on-board Mic to Right Microphone Input.JMP4 Installed Provides a means of measuring IOVDD current.JMP5 Installed Provides a means of measuring AVDD_ADC current.JMP6 Installed Provides a means of measuring DVDD current.JMP7 Installed Provides a means of measuring DRVDD current.JMP8 Installed Provides a means of measuring AVDD_DAC current.JMP9 Installed Connects Analog and Digital Grounds.JMP10 3-5 When connecting 3 to 5, I
2
C is selected as control mode; when connecting 1 to 3, SPIis selected as control mode. When connecting 3 to 4, mode selection can be made bya logic level at J16.12JMP11 3-5 In I
2
C control mode, this jumper sets the state of A0. When connecting 3 to 5, A0 = 0;when connecting 1 to 3, A0 = 1. In SPI control mode, connecting 3 to 4, SPI /SS isprovided from J16.2JMP12 3-5 In I
2
C control mode, this jumper sets the state of A1. When connecting 3 to 5, A1 = 0;when connecting 1 to 3, A1 = 1. In SPI control mode, connecting 3 to 4, SPI SCLK isprovided from J16.3JMP13 Installed When installed, shorts across the output capacitor on HPLOUT; remove this jumper ifusing AC-coupled output driveJMP14 Installed When installed, shorts across the output capacitor on HPLCOM; remove this jumper ifusing AC-coupled output driveJMP15 Installed When installed, shorts across the output capacitor on HPROUT; remove this jumper ifusing AC-coupled output driveJMP16 Installed When installed, shorts HPLCOM and HPRCOM. Use only if these signals are set toconstant VCM.JMP17 Installed When installed, shorts across the output capacitor on HPRCOM; remove this jumper ifusing AC-coupled output driveJMP18 Open Selects on-board EEPROM as Firmware Source.JMP19 Open When installed, allows the USB-MODEVM to hardware reset the device under usercontrol
The following section provides information on using the TLV320AIC33EVM-PDK, including set up,program installation, and program usage.
A block diagram of the TLV320AIC33EVM-PDK is shown in Figure 1 . The evaluation kit consists of twocircuit boards connected together. The motherboard is designated as the USB-MODEVM Interface board,while the daughtercard is the TLV320AIC33EVM described previously in this manual.
SBAU114 – November 2005 TLV320AIC33EVM and TLV320AIC33EVM-PDK User's Guide 7

www.ti.com
EVM Position 2
EVM Position 1
TLV320AIC33EVM
Control Interface
TLV320AIC33
TAS1020B
USB 8051
Microcontroller
USB
SPI, I C
2
I S, AC97
2
Audio Interface
Kit Operation
Figure 1. TLV320AIC33EVM-PDK Block Diagram
The USB-MODEVM Interface board is intended to be used in USB mode, where control of the installedEVM is accomplished using the onboard USB controller device. Provision is made, however, for driving allthe data buses (I
2
C, SPI™, I
2
S/AC97) externally. The source of these signals is controlled by SW2 on theUSB-MODEVM. Refer to Table 6 for details on the switch settings.
8TLV320AIC33EVM and TLV320AIC33EVM-PDK User's Guide SBAU114 – November 2005

www.ti.com
6.2 Installation
Kit Operation
Table 6. USB-MODEVM SW2 Settings
SW-2 SWITCH
NUMBER LABEL SWITCH DESCRIPTION
1 A0 USB-MODEVM EEPROM I
2
C Address A0ON: A0 = 0OFF: A0 = 12 A1 USB-MODEVM EEPROM I
2
C Address A1ON: A1 = 0OFF: A1 = 13 A2 USB-MODEVM EEPROM I
2
C Address A2ON: A2 = 0OFF: A2 = 14 USB I
2
S I
2
S Bus Source SelectionON: I
2
S Bus connects to TAS1020OFF: I
2
S Bus connects to USB-MODEVM J145 USB MCK I
2
S Bus MCLK Source SelectionON: MCLK connects to TAS1020OFF: MCLK connects to USB-MODEVM J146 USB SPI SPI Bus Source SelectionON: SPI Bus connects to TAS1020OFF: SPI Bus connects to USB-MODEVM J157 USB RST RST Source SelectionON: EVM Reset Signal comes from TAS1020OFF: EVM Reset Signal comes from USB-MODEVM J158 EXT MCK External MCLK SelectionON: MCLK Signal is provided from USB-MODEVM J10OFF: MCLK Signal comes from either selection of SW2-5
For use with the TLV320AIC33EVM, SW-2 positions 1 through 7 should be set to ON, while SW-2.8should be set to OFF.
Ensure that the TLV320AIC33EVM is installed on the USB-MODEVM Interface board, aligning J13, J14,J15, J16, J17 with the corresponding connectors on the USB-MODEVM.
Place the CD-ROM into your PC CD-ROM drive. Locate the Setup program on the disk, and run it. TheSetup program will install the TLV320AIC33 Evaluation software on your PC.
After the main program is installed, the NI-VISA Runtime installer will automatically run. This softwareallows the program to communicate with USB.
When the installation completes, click Finish on the TLV320AIC33EVM installer window. You may beprompted to restart your computer.
When installation is complete, attach a USB cable from your PC to the USB-MODEVM Interface board. Asconfigured at the factory, the board will be powered from the USB interface, so the power indicator LEDson the USB-MODEVM should light. Once this connection is established, launch the TLV320AIC33Evaluation software on your PC.
SBAU114 – November 2005 TLV320AIC33EVM and TLV320AIC33EVM-PDK User's Guide 9

www.ti.com
6.3 USB-MODEVM Interface Board
Kit Operation
The software should automatically find the TLV320AIC33EVM, and a screen similar to the one in Figure 2should appear.
Figure 2. Default Software Screen
The simple diagram shown in Figure 1 shows only the basic features of the USB-MODEVM Interfaceboard. The board is built around a TAS1020B streaming audio USB controller with an 8051-based core.The board features two positions for modular EVMs, or one double-wide serial modular EVM may beinstalled.
Since the TLV320AIC33EVM is a double-wide modular EVM, it is installed with connections to both EVMpositions, which connects the TLV320AIC33 digital control interface to the I
2
C port realized using theTAS1020B, as well as the TAS1020B digital audio interface..
In the factory configuration, the board is ready to use with the TLV320AIC33EVM. To view all the functionsand configuration options available on the USB-MODEVM board, see the USB-MODEVM Interface Boardschematic in Appendix B .
10 TLV320AIC33EVM and TLV320AIC33EVM-PDK User's Guide SBAU114 – November 2005

www.ti.com
6.4 Program Description
6.5 Interface Selection
6.6 Indicators and Main Screen Controls
Kit Operation
After the TLV320AIC33EVM-PDK software installation (described in Section 6.2 ) is complete, evaluationand development with the TLV320AIC33 can begin.
When the program first starts up, a small window (Figure 3 ) appears that gives two choices for the controlinterface: I
2
C or SPI. Click on the interface that will be used by the EVM, as selected by the jumpersettings detailed in Table 5 .
Figure 3. Interface Selection Window
If the I
2
C interface is selected, a second window then appears which allows for selecting the address ofthe TLV320AIC33. This window (see Figure 4 ) has two checkboxes for setting the state of A0 and A1.Note that this address should correspond to the jumper settings selected as described in Table 5 .
Figure 4. I
2
C Address Selection Window
Figure 2 illustrates the indicators and controls near the top of the screen, and a large tabbed interfacebelow. This section will discuss the controls above this tabbed section.
At the top left of the screen is an Interface indicator. This indicator shows which interface is selected forcontrolling the TLV320AIC33 , either I
2
C or SPI; it is lit after the program begins.
To the right of the Interface indicator is a group box called Firmware. This box indicates where thefirmware being used is operating from—in this release, the firmware is on the USB-MODEVM, so youshould see USB-MODEVM in the box labeled Located On:. The version of the firmware appears in theVersion box below this.
SBAU114 – November 2005 TLV320AIC33EVM and TLV320AIC33EVM-PDK User's Guide 11

www.ti.com
Kit Operation
To the right, the next group box contains controls for resetting the TLV320AIC33. A software reset can bedone by writing to a register in the TLV320AIC33, and this is accomplished by pushing the button labeledSoftware Reset. The TLV320AIC33 also may be reset by toggling a pin on the TLV320AIC33, which isdone by pushing the Hardware Reset button.
CAUTIONIn order to perform a hardware reset, the RESET jumper (JMP19) must beinstalled and SW2-7 on the USB-MODEVM must be turned OFF. Failure todo either of these steps results in not generating a hardware reset orcausing unstable operation of the EVM, which may require cycling powerto the USB-MODEVM.
The ADC Overflow and DAC Overflow indicators light when the overflow flags are set in theTLV320AIC33. These indicators, as well as the other indicators on this panel, are updated only when thesoftware's front panel is inactive, once every 20ms. Below these indicators are other indicators that showwhen the AGC noise threshold is exceeded. To the far right on this screen, the short-circuit indicatorsshow when a short-circuit condition is detected, if this feature has been enabled. Below the short-circuitindicators is a bar graph that shows the amount of gain which has been applied by the AGC, andindicators that light when the AGC is saturated.
6.6.1 Audio Analyzer
Near the left side of the screen is a button labeled Audio Analyzer, and this button can be set to ON orOFF. Pressing the button to turn it ON opens another window (see Figure 5 ). This feature provides theability to generate signals to send to the TLV320AIC33 DACs as well as viewing and analyzing signalsread by the TLV320AIC33 ADCs. This ability to view and process the real-time streaming USB audio is ademanding task. Use of the Audio Analyzer feature requires a computer with at least 512MB of memoryand reasonable processor speed (> 1GHz); computers with inadequate resources could still use the AudioAnalyzer to generate signals for the DACs, but will be unable to process signals from the ADCs becausethe FFT, distortion analysis, and signal-to-noise ratio analysis will not be able to keep up with the dataprocessing requirements.
The Audio Analyzer features two tabs. The front tab, shown in Figure 5 and titled Generator, createsdigital waveforms to send to the DACs. When first started, the function will be set to SNR (Output Zeros)which feeds only zero codes to the DAC. This is commonly done to test for the noise floor of the DAC.
The second function available is THD (-1dB sinewave). This function sends a sinewave at a coherentfrequency to the 44.1kHz sample rate to the DACs; this is commonly used for testing THD+N.
These first two functions do not require any further settings; therefore, the frequency and amplitude knobsbelow the function selector are not used. Selecting a function of Function Generator allows the choice ofwaveform shape by using the pull-down menu next to the function selector, and the frequency andamplitude of that signal can be varied using the knobs below.
The output waveforms for both left and right channels are displayed in the graph at the bottom of thisscreen.
TLV320AIC33EVM and TLV320AIC33EVM-PDK User's Guide12 SBAU114 – November 2005

www.ti.com
Kit Operation
Figure 5. Audio Generator Screen
SBAU114 – November 2005 TLV320AIC33EVM and TLV320AIC33EVM-PDK User's Guide 13

www.ti.com
Kit Operation
The second tab, titled Analyzer (Figure 6 ), handles the display and analysis of data from the ADCs.
Figure 6. Audio Analyzer Screen
The analyzer screen features a graph of the input signals, both left and right channels, in a time domaindisplay at the top of the screen, and in the frequency domain (FFT) at the bottom of the screen.
TLV320AIC33EVM and TLV320AIC33EVM-PDK User's Guide14 SBAU114 – November 2005

www.ti.com
6.7 Audio Input/ADC Tab
Kit Operation
Next to the time domain plots, calculated values of SINAD, SNR, and THD are shown. These values areall expressed in dB relative to the full-scale of the TLV320AIC33. Note that the SNR number shown isA-weighted.
In Figure 6 , a sine wave generated by the TLV320AIC33 DACs is fed through the high power drivers andback into the ADC and the resulting FFTs can be seen. Note that this is a full analog loopback test case,so the measured numbers show the combined performance of the DAC, drivers, and ADC. There is alsono post-DAC filtering; as noted in the data sheet, this may degrade measurements even though there isno audible noise.
The Audio Input/ADC Tab is laid out like an audio mixing console. Each input channel has a vertical stripthat corresponds to that channel. LINE1L and LINE1R input strips have controls to route that input toeither the left or right ADC input; by default, all inputs are muted when the TLV320AIC33 is powered up.To route an input to the ADC, first click on the MUTE button in the input channel strip which correspondsto the ADC input channel you want that input to go to—the caption on the button will change to ACTIVE.The level of the input channel routed to that particular ADC channel can then be adjusted using the Levelknob below the MUTE/ACTIVE button. See Figure 7 .
Figure 7. Audio Input Tab
Similarly, the LINE2L and LINE2R inputs can be routed to the ADC. However, note that these inputs donot have the choice to route to either ADC channel; they can only be configured to connect to thecorresponding ADC input.
SBAU114 – November 2005 TLV320AIC33EVM and TLV320AIC33EVM-PDK User's Guide 15

www.ti.com
6.8 Audio Interface Tab
Kit Operation
The MIC3L and MIC3R inputs are similar to the LINE1L and LINE1R inputs in that they can be routed toeither ADC input channel. Control of the mic bias is accomplished by using the pull-down menu at the topof these channel strips. The mic bias can either be powered down or set to 2.0V, 2.5V, or the powersupply voltage of the ADC (AVDD_ADC).
To use the on-board microphone, JMP2 and JMP3 must be installed and nothing should be plugged intoJ6. In order for the mic bias settings in the software to take effect, JMP1 should be set to connectpositions 2 and 3, so that mic bias is controlled by the TLV320AIC33.
In the upper right of this tab are controls for Weak Common Mode Bias. Enabling these controls willresult in unselected inputs to the ADC channels to be weakly biased to the ADC common mode voltage.
Below these controls are the controls for the ADC PGA—the master volume controls for the ADC inputs.Each channel of the ADC can be powered up or down as needed using the Powered Up buttons. PGAsoft-stepping for each channel is selected using the control below this. The large knobs set the actualADC PGA Gain; at the extreme counterclockwise rotation, the channel is muted. Rotating the knobclockwise increases the PGA gain.
The Audio Interface tab (Figure 8 ) sets up the audio data interface to the TLV320AIC33. For use with thePC software and the USB-MODEVM, the default settings should be used. If using an external I
2
S source,or other data source, the interface mode may be selected using the Transfer Mode control—selectingeither I
2
S mode, DSP mode, or Right- or Left-Justified modes. Word length can be selected using theWord Length control, and the bit clock rate can also be selected using the Bit Clock rate control. TheData Word Offset, used in TDM mode (see the product datasheet ) can also be selected on this tab.
TLV320AIC33EVM and TLV320AIC33EVM-PDK User's Guide16 SBAU114 – November 2005

www.ti.com
Kit Operation
Figure 8. Audio Interface Tab
Along the bottom of this tab are controls for choosing the BLCK and WCLK as being either inputs oroutputs, as well as options for tristating the DOUT line when there is not valid data and transmitting BLCKand WCLK when the codec is powered down.
Re-sync of the audio bus is enabled using the controls in the lower right corner of this screen. Re-sync isdone if the group delay changes by more than ±FS/4 for the ADC or DAC sample rates (see theTLV320AIC33 datasheet). The channels can be soft muted when doing the re-sync if the Soft Mute buttonis enabled.
In the upper right corner of this tab is the Digital Mic Functionality control. The TLV320AIC33 can accepta data stream from a digital microphone, which would have its clock pin connected to the TLV320AIC33GPIO1 pin, and the mic data connected to the GPIO2 pin. Refer to section Section 6.10 for a discussion ofsetting the GPIO pin options. The TLV320AIC33 can provide a modulator clock to the digital microphonewith oversampling ratios (OSR) of 128, 64, or 32. For a detailed discussion of how to connect a digitalmicrophone on this platform, refer to the application note Using the Digital Microphone Function onTLV320AIC33 with AIC33EVM/USB-MODEVM System (literature number SLAA275 ), available fordownload at www.ti.com .
SBAU114 – November 2005 TLV320AIC33EVM and TLV320AIC33EVM-PDK User's Guide 17

www.ti.com
6.9 Clocks Tab
Kit Operation
The TLV320AIC33 has a very flexible scheme for generating the clock sources for ADC and DAC samplerates. The Clocks tab allows access to set the different options for setting up these clocks. Refer to theAudio Clock Generation Processing figure in the TLV320AIC33 datasheet.
For use with the PC software and the USB-MODEVM, the clock settings must be set a certain way. Thesesettings are not the default settings of the TLV320AIC33. The EVM-required settings can be loadedautomatically by pushing the Load EVM Clock Settings button at the bottom of this tab. Note thatchanging any of the clock settings from the values loaded when this button is pushed may result in theEVM not working properly with the PC software or USB interface. If an external audio bus is used (audionot driven over the USB bus), then settings may be changed to any valid combination. See Figure 9 .
Figure 9. Clocks Tab
The codec clock source is chosen by by the CODEC_CLK Source control. When this control is set toCLKDIV_OUT, the PLL is not used; when set to PLLDIV_OUT, the PLL is used to generate the clocks.
6.9.1 Use Without PLL
Setting up the TLV320AIC33 for clocking without using the PLL is straightforward. The CLKDIV_IN sourcecan be selected as either MCLK or BCLK, the default is MCLK. The CLKDIV_IN frequency is then enteredinto the CLKDIV_IN box, in megahertz (MHz). The default value shown, 11.2896MHz, is the frequencyused on the USB-MODEVM board. This value is then divided by the value of Q, which can be set from 2to 17; the resulting CLKDIV_OUT frequency is shown in the indicator next to the Qcontrol.
TLV320AIC33EVM and TLV320AIC33EVM-PDK User's Guide18 SBAU114 – November 2005

www.ti.com
6.10 GPIO Tab
Kit Operation
This frequency will then be used to calculate the actual Fsref frequency, and the ADC and DAC samplerates, after the NADC and NDAC factors are applied to the Fsref. If dual rate mode is desired, this optioncan be enabled for either the ADC or DAC by pressing the corresponding Dual Rate Mode button.
6.9.2 Use With The PLL
When PLLDIV_OUT is selected as the codec clock source, the PLL will be used. The PLL clock source ischosen using the PLLCLK_IN control, and may be set to either MCLK or BCLK. The PLLCLK_INfrequency is then entered into the PLLCLK_IN Source box.
The PLL_OUT and PLLDIV_OUT indicators show the resulting PLL output frequencies with the values setfor the P, K, and R parameters of the PLL. Refer to the the TLV320AIC33 datasheet for an explanation ofthese parameters. The parameters can be set by clicking on the up/down arrows of the P,K, and Rcombo boxes, or they can be typed into these boxes. The values can also be calculated by the PCsoftware.
To use the PC software to find the ideal values of P, K, and R for a given PLL input frequency and desiredFsref, the desired Fsref must be set using the switch on this tab; it can be set to either 44.1kHz or 48kHz.Once the desired Fsref and PLLCLK_IN values are correctly set, pushing the Search for Ideal Settingsbutton starts the software searching for ideal combinations of P, K, and R which achieve the desired Fsref.The possible settings for these parameters are displayed in the spreadsheet-like table labeled PossibleSettings. Clicking on a row in this table sets the P, K, and R values in the software and updates thePLL_OUT and PLLDIV_OUT readings, as well as the Actual Fsref and Error displays. This process doesnot actually load the values into the TLV320AIC33, however; it only updates the displays in the software.This allows for different possible solutions to be selected and the error evaluated before loading into thedevice.
When a suitable combination of P,K, and R have been chosen, pressing the Load Settings into Device?button will download these values into the appropriate registers on the TLV320AIC33.
The GPIO tab (see Figure 10 ) selects options for the general-purpose inputs and outputs (GPIO) of theTLV320AIC33. Many pins on the TLV320AIC33 are denoted as multifunction pins, meaning they may beused for many different purposes.
SBAU114 – November 2005 TLV320AIC33EVM and TLV320AIC33EVM-PDK User's Guide 19

www.ti.com
Kit Operation
Figure 10. GPIO Tab
The GPIO1 groupbox contains controls for setting options for the GPIO1 pin. The Function control selectsthe function that GPIO1 will be used for—it can be used as the ADC Word Clock, as an output clock, asinterrupt pins to signal Short Circuit or AGC Noise Threshold detection, or Button Press or Headsetdetection. It may also be used for the alternate I
2
S Word Clock or provide a modulator clock for use with adigital microphone (see Section 6.8 and the TLV320AIC33 datasheet). In addition, it can also be used as ageneral-purpose I/O pin.
If selected as a General Purpose Input, the state of the GPIO1 pin is reflected by the Input Levelindicator. If selected as a General Purpose Output, the state of the GPIO1 pin can be set by using theOutput Level button.
For use as an interrupt output, the behavior of the interrupt can be selected using the Interrupt Durationcontrol. A Single, 2ms pulse can be delivered when the selected interrupt occurs, or Continuous Pulsescan be generated signaling the interrupt.
In similar fashion, the GPIO2 pin can also be used for an alternate I
2
S bus, provide interrupt outputs, or beused with a digital microphone. These options are selected using the Function control in the GPIO2groupbox. The other controls in this groupbox work the same as the corresponding controls for GPIO1.
When the control interface for the TLV320AIC33 is selected to be I
2
C, the SDA and SCL groupboxes andcontrols within them are disabled. If SPI mode is selected, however, the SDA and SCL pins can be usedas GPIO, and selected as either inputs or outputs using the SDA Function and SCL Function controls.The Output Level and Input Level controls function for these pins in the same way that they do forGPIO1 or GPIO2.
TLV320AIC33EVM and TLV320AIC33EVM-PDK User's Guide20 SBAU114 – November 2005
