TPS563231EVM-032 3-A, Synchronous Step-down Converter Evaluation
Module
User's Guide
SLUUBT7A–July 2018–Revised December 2018
TPS563231EVM-032 3-A, Synchronous Step-down
Converter Evaluation Module
This user's guide contains information for the TPS563231 as well as support documentation for the
TPS563231EVM-032 evaluation module. Included are the performance specifications, schematic, and the
bill of materials of the TPS563231EVM-032.
Contents
1 Introduction ................................................................................................................... 2
2 Performance Specification Summary ..................................................................................... 2
3 Modifications.................................................................................................................. 3
3.1 Output Voltage Setpoint............................................................................................ 3
4 Test Setup and Results..................................................................................................... 4
4.1 Input/Output Connections.......................................................................................... 4
4.2 Start-Up Procedure................................................................................................. 4
4.3 Efficiency............................................................................................................. 5
4.4 Load Regulation..................................................................................................... 6
4.5 Line Regulation ..................................................................................................... 7
4.6 Load Transient Response ......................................................................................... 7
4.7 Output Voltage Ripple.............................................................................................. 8
4.8 Input Voltage Ripple................................................................................................ 9
4.9 Start-Up............................................................................................................. 10
4.10 Shut-Down ......................................................................................................... 11
5 Board Layout................................................................................................................ 12
5.1 Layout............................................................................................................... 12
6 Schematic, Bill of Materials, and Reference............................................................................ 14
6.1 Schematic .......................................................................................................... 14
6.2 List of Materials.................................................................................................... 15
6.3 Reference .......................................................................................................... 15
List of Figures
1 TPS563231EVM-032 Efficiency ........................................................................................... 5
2 TPS563231EVM-032 Light Load Efficiency.............................................................................. 5
3 TPS563231EVM-032 Load Regulation ................................................................................... 6
4 TPS563231EVM-032 Line Regulation.................................................................................... 7
5 TPS563231EVM-032 Load Transient Response, 25% to 75% Load Step .......................................... 7
6 TPS563231EVM-032 Output Voltage Ripple, IOUT = 3 A................................................................ 8
7 TPS563231EVM-032 Output Voltage Ripple, IOUT = 300 mA .......................................................... 8
8 TPS563231EVM-032 Output Voltage Ripple, IOUT = 0 mA ............................................................. 9
9 TPS563231EVM-032 Input Voltage Ripple, IOUT = 3 A.................................................................. 9
10 TPS563231EVM-032 Start-Up Relative to VIN.......................................................................... 10
11 TPS563231EVM-032 Start-Up Relative to EN ......................................................................... 10
12 TPS563231EVM-032 Shut-Down Relative to VIN ...................................................................... 11
13 TPS563231EVM-032 Shut-Down Relative to EN...................................................................... 11
14 Top Assembly............................................................................................................... 12
15 Top Layer ................................................................................................................... 13

Introduction www.ti.com
2SLUUBT7A–July 2018–Revised December 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
TPS563231EVM-032 3-A, Synchronous Step-down Converter Evaluation
Module
16 Bottom Layer................................................................................................................ 13
17 TPS563231EVM-032 Schematic Diagram.............................................................................. 14
List of Tables
1 Input Voltage and Output Current Summary............................................................................. 2
2 TPS563231EVM-032 Performance Specifications Summary.......................................................... 2
3 Output Voltages.............................................................................................................. 3
4 Connection and Test Points................................................................................................ 4
5 List of Materials............................................................................................................. 15
1 Introduction
The TPS563231 is a single, adaptive on-time, D-CAP3™ mode, synchronous buck converter requiring a
very low external component count. The D-CAP3 control circuit is optimized for low-ESR output capacitors
such as POSCAP, SP-CAP, or ceramic types and features fast transient response with no external
compensation. The switching frequency is internally set at a nominal 600 kHz and enters Advanced Eco-
mode in light load conditions. The high-side and low-side switching MOSFETs are incorporated inside the
TPS563231 package along with the gate-drive circuitry. The low drain-to-source on resistance of the
MOSFETs allows the TPS563231 to achieve high efficiencies and helps keep the junction temperature low
at high output currents. The TPS563231 dc/dc synchronous converter is designed to provide up to a 3-A
output from an input voltage source of 4.5 V to 17 V. The output voltage range is from 0.6 V to 7 V. Rated
input voltage and output current ranges for the evaluation module are given in Table 1.
The TPS563231EVM-032 evaluation module (EVM) is a single, synchronous buck converter providing 3.3
V at 3 A from 4.5-V to 17-V input. This user’s guide describes the TPS563231EVM-032 performance.
Table 1. Input Voltage and Output Current Summary
EVM INPUT VOLTAGE RANGE OUTPUT CURRENT RANGE
TPS563231EVM-032 VIN = 4.5 V to 17 V 0 A to 3 A
2 Performance Specification Summary
A summary of the TPS563231EVM-032 performance specifications is provided in Table 2. Specifications
are given for an input voltage of VIN = 12 V and an output voltage of 3.3 V, unless otherwise noted. The
ambient temperature is 25°C for all measurement, unless otherwise noted.
Table 2. TPS563231EVM-032 Performance Specifications Summary
SPECIFICATIONS TEST CONDITIONS MIN TYP MAX UNIT
Input voltage range (VIN) 4.5 12 17 V
CH1
Output voltage 3.3 V
Operating frequency VIN = 12 V, IO= 3 A 600 kHz
Output current range 0 3 A
Over current limit VIN = 12 V, LO= 3.3 µH A
Output ripple voltage VIN = 12 V, IO= 3 A 15 mVPP

www.ti.com Modifications
3
SLUUBT7A–July 2018–Revised December 2018
Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated
TPS563231EVM-032 3-A, Synchronous Step-down Converter Evaluation
Module
3 Modifications
These evaluation modules are designed to provide access to the features of the TPS563231. Some
modifications can be made to this module.
3.1 Output Voltage Setpoint
To change the output voltage of the EVMs, it is necessary to change the value of resistor R5. Changing
the value of R5 can change the output voltage above 0.6 V. The value of R5 for a specific output voltage
can be calculated using Equation 1.
(1)
Table 3 lists the R5 values for some common output voltages. Note that the values given in Table 3 are
standard values and not the exact value calculated using Table 3.
Table 3. Output Voltages
OUTPUT VOLTAGE
(V) R5 (kΩ)R6 (kΩ)
L1
(µH) C5 + C6 +C7
(µF)
Min Typ Max
1.0 6.65 10.0 1 1.5 4.7 20 - 68
1.05 7.5 10.0 1 1.5 4.7 20 - 68
1.2 10 10.0 1 1.5 4.7 20 - 68
1.5 15 10.0 1.5 2.2 4.7 20 - 68
1.8 20 10.0 1.5 2.2 4.7 20 - 68
2.5 31.6 10.0 2.2 3.3 4.7 20 - 68
3.3 45.3 10.0 2.2 3.3 4.7 20 - 68
5.0 73.2 10.0 3.3 4.7 4.7 20 - 68
6.5 98.3 10.0 3.3 4.7 4.7 20 - 68

Test Setup and Results www.ti.com
4SLUUBT7A–July 2018–Revised December 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
TPS563231EVM-032 3-A, Synchronous Step-down Converter Evaluation
Module
4 Test Setup and Results
This section describes how to properly connect, set up, and use the TPS563231EVM-032. The section
also includes test results typical for the evaluation modules and efficiency, output load regulation, output
line regulation, load transient response, output voltage ripple, input voltage ripple, start-up, and switching
frequency.
4.1 Input/Output Connections
The TPS563231EVM-032 is provided with input/output connectors and test points as shown in Table 4. A
power supply capable of supplying 3 A must be connected to J1 through a pair of 20-AWG wires. The load
must be connected to J2 through a pair of 20-AWG wires. The maximum load current capability is 3 A.
Wire lengths must be minimized to reduce losses in the wires. Test point TP3 provides a place to monitor
the VIN input voltages with TP4 providing a convenient ground reference. TP9 is used to monitor the output
voltage with TP5 as the ground reference.
Table 4. Connection and Test Points
REFERENCE DESIGNATOR FUNCTION
J1 VIN (see Table 1 for VIN range)
J2 VOUT, 3.3 V at 3-A maximum
JP1 EN control. Shunt EN to GND to disable
TP1 VIN positive power point
TP2,TP11 GND power point
TP3 VIN positive monitor point
TP4,TP5,TP12,TP13 GND monitor test point
TP6 EN test point
TP7 Switch node test point
TP8 Test point for loop response measurements
TP9 VOUT positive monitor point
TP10 VOUT positive power point
4.2 Start-Up Procedure
1. Ensure that the jumper at JP1 (Enable control) pins 1 and 2 are covered to shunt EN to GND, disabling
the output.
2. Apply appropriate VIN voltage to VI (J1-2) and GND (J1-1).
3. Move the jumper at JP1 (Enable control) pins 1 and 2 (EN and GND) to enable the output.

Output Current - A
Efficiency - %
0.001 0.01 0.1 1 3
20
30
40
50
60
70
80
90
100
D02_
VIN = 5V
VIN = 12V
VIN = 17V
Output Current - A
Efficiency - %
0 0.5 1 1.5 2 2.5 3
20
30
40
50
60
70
80
90
100
D01_
VIN = 5V
VIN = 12V
VIN = 17V
www.ti.com Test Setup and Results
5
SLUUBT7A–July 2018–Revised December 2018
Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated
TPS563231EVM-032 3-A, Synchronous Step-down Converter Evaluation
Module
4.3 Efficiency
Figure 1 shows the efficiency for the TPS563231EVM-032 at an ambient temperature of 25°C.
Figure 1. TPS563231EVM-032 Efficiency
Figure 2 shows the efficiency at light loads for the TPS563231EVM-032 at an ambient temperature of
25°C.
Figure 2. TPS563231EVM-032 Light Load Efficiency

Output Current - A
Output Voltage Deviation - %
0 0.5 1 1.5 2 2.5 3
-2
-1.5
-1
-0.5
0
0.5
1
D03_
VIN = 5V
VIN = 12V
VIN = 17V
Test Setup and Results www.ti.com
6SLUUBT7A–July 2018–Revised December 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
TPS563231EVM-032 3-A, Synchronous Step-down Converter Evaluation
Module
4.4 Load Regulation
The load regulation for the TPS563231EVM-032 is shown in Figure 3.
Figure 3. TPS563231EVM-032 Load Regulation

VOUT = 100 mV / div (AC coupled)
IL = 1 A / div
Load Step = 0.75 A t2.25 A , Slew Rate = 500 mA / s
200 s / div
Input Voltage - V
Output Voltage Deviation - %
5 6 7 8 9 10 11 12 13 14 15 16 17
-0.5
-0.4
-0.3
-0.2
-0.1
0
0.1
0.2
0.3
0.4
0.5
D04_
ILOAD = 0 A
ILOAD = 1.5 A
ILOAD = 3 A
www.ti.com Test Setup and Results
7
SLUUBT7A–July 2018–Revised December 2018
Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated
TPS563231EVM-032 3-A, Synchronous Step-down Converter Evaluation
Module
4.5 Line Regulation
The line regulation for the TPS563231EVM-032 is shown in Figure 4.
Figure 4. TPS563231EVM-032 Line Regulation
4.6 Load Transient Response
The TPS563231EVM-032 response to load transient is shown in Figure 5. The current steps and slew
rates are indicated in the figures. Total peak-to-peak voltage variation is as shown.
Figure 5. TPS563231EVM-032 Load Transient Response, 25% to 75% Load Step

Vout = 20 mV / div (AC coupled)
SW = 5 V / div
1 s / div
Vout = 20 mV / div (AC coupled)
SW = 5 V / div
1 s / div
Test Setup and Results www.ti.com
8SLUUBT7A–July 2018–Revised December 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
TPS563231EVM-032 3-A, Synchronous Step-down Converter Evaluation
Module
4.7 Output Voltage Ripple
The TPS563231EVM-032 output voltage ripple is shown in Figure 6,Figure 7, and Figure 8. The output
currents are as indicated.
Figure 6. TPS563231EVM-032 Output Voltage Ripple, IOUT =3A
Figure 7. TPS563231EVM-032 Output Voltage Ripple, IOUT = 300 mA

Vin = 50 mV / div (AC coupled)
SW = 5 V / div
1 s / div
Vout = 20 mV / div (AC coupled)
SW = 5 V / div
1 s / div
www.ti.com Test Setup and Results
9
SLUUBT7A–July 2018–Revised December 2018
Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated
TPS563231EVM-032 3-A, Synchronous Step-down Converter Evaluation
Module
Figure 8. TPS563231EVM-032 Output Voltage Ripple, IOUT = 0 mA
4.8 Input Voltage Ripple
The TPS563231EVM-032 input voltage ripple is shown in Figure 9. The output current is as indicated.
Figure 9. TPS563231EVM-032 Input Voltage Ripple, IOUT =3A

Vin = 5 V / div
Vout = 1 V / div
EN = 3 V / div
1 ms / div
Vin = 5 V / div
Vout = 1 V / div
EN = 3 V / div
2 ms / div
Test Setup and Results www.ti.com
10 SLUUBT7A–July 2018–Revised December 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
TPS563231EVM-032 3-A, Synchronous Step-down Converter Evaluation
Module
4.9 Start-Up
The TPS563231EVM-032 start-up waveform relative to VIN is shown in Figure 10.Load=2Ωresistive.
Figure 10. TPS563231EVM-032 Start-Up Relative to VIN
The TPS563231EVM-032 start-up waveform relative to enable (EN) is shown in Figure 11.Load=2Ω
resistive.
Figure 11. TPS563231EVM-032 Start-Up Relative to EN

Vin = 5 V / div
Vout = 1 V / div
EN = 3 V / div
1 ms / div
Vin = 5 V / div
Vout = 1 V / div
EN = 5 V / div
2 ms / div
www.ti.com Test Setup and Results
11
SLUUBT7A–July 2018–Revised December 2018
Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated
TPS563231EVM-032 3-A, Synchronous Step-down Converter Evaluation
Module
4.10 Shut-Down
The TPS563231EVM-032 shut-down waveform relative to VIN is shown in Figure 12.Load=2Ωresistive.
Figure 12. TPS563231EVM-032 Shut-Down Relative to VIN
The TPS563231EVM-032 shut-down waveform relative to EN is shown in Figure 13.Load=2Ωresistive.
Figure 13. TPS563231EVM-032 Shut-Down Relative to EN

Board Layout www.ti.com
12 SLUUBT7A–July 2018–Revised December 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
TPS563231EVM-032 3-A, Synchronous Step-down Converter Evaluation
Module
5 Board Layout
This section provides a description of the TPS563231EVM-032, board layout, and layer illustrations.
5.1 Layout
The board layout for the TPS563231EVM-032 is shown in Figure 14,Figure 15 and Figure 16. The top
layer contains the main power traces for VIN, VOUT, and ground. Also on the top layer are connections
for the pins of the TPS563231 and a large area filled with ground. Most of the signal traces are also
located on the top side. The input decoupling capacitors, C1, C2, and C3 are located as close to the IC as
possible. The input and output connectors, test points, and all of the components are located on the top
side. The bottom layer is a ground plane along with the switching node copper fill, signal ground copper fill
and the feed back trace from the point of regulation to the top of the resistor divider network.
Figure 14. Top Assembly

www.ti.com Board Layout
13
SLUUBT7A–July 2018–Revised December 2018
Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated
TPS563231EVM-032 3-A, Synchronous Step-down Converter Evaluation
Module
Figure 15. Top Layer
Figure 16. Bottom Layer

Schematic, Bill of Materials, and Reference www.ti.com
14 SLUUBT7A–July 2018–Revised December 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
TPS563231EVM-032 3-A, Synchronous Step-down Converter Evaluation
Module
6 Schematic, Bill of Materials, and Reference
6.1 Schematic
Figure 17 is the schematic for the TPS563231EVM-032.
Figure 17. TPS563231EVM-032 Schematic Diagram

www.ti.com Schematic, Bill of Materials, and Reference
15
SLUUBT7A–July 2018–Revised December 2018
Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated
TPS563231EVM-032 3-A, Synchronous Step-down Converter Evaluation
Module
6.2 List of Materials
Table 5. List of Materials
DES QTY DESCRIPTION PART NUMBER MANUFACTURER
!PCB1 1 Printed Circuit Board BSR032 Any
C1, C4,C7 3 Capacitor, ceramic, 0.1 µF, 25V, ±10%, X7R, 0603 GRM188R71E10
4KA01D MuRata
C2, C3 2 Capacitor, ceramic, 10 µF, 25V, ±10%, X7R, 1210 GRM32DR71E106KA
12L MuRata
C5 1 Capacitor, ceramic, 22 µF, 10V, ±10%, X7R, 1210 GRM32ER71A22
6ME20L MuRata
C6 1 Capacitor, ceramic, 10 µF, 10 V, ±10%, X7R, 1210 GRM32DR71A10
6KA01L MuRata
C10 1 Capacitor, aluminum, 100 µF, 25 V, ±20%, 0.13 ohm,
TH UBT1E101MPD1 TD Nichicon
J1, J2 2 Terminal block, 5.08 mm, 2 x 1, Brass, TH ED120/2DS On-Shore Technology
JP1 1 Header, 100 mil, 2 x 1, tin, TH PEC02SAAN Sullins Connector
Solutions
L1 1 Inductor, shielded drum core, powdered iron, 3.3 µH, 6
A, 0.019 Ω, SMD 74437349033 Wurth Elektronik
LBL1 1 Thermal transfer printable labels, 0.650" W x 0.200" H -
10,000 per roll THT-14-423-10 Brady
R1 1 Resistor, 20 kΩ, 5%, 0.1 W, 0603 CRCW060320K0
JNEA Vishay-Dale
R3 1 Resistor, 51 Ω, 5%, 0.1 W, 0603 CRCW060351R0
JNEA Vishay-Dale
R5 1 Resistor, 45.3 kΩ, 1%, 0.1 W, 0603 CRCW060345K3
FKEA Vishay-Dale
R6 1 Resistor, 10.0 kΩ, 1%, 0.1 W, 0603 CRCW060310K0
FKEA Vishay-Dale
SH-JP1 1 Shunt, 100 mil, gold plated, black SNT-100-BK-G Samtec
TP1, TP2,
TP10, TP11 4 Terminal, turret, TH, double 1502-2 Keystone
TP3, TP6,
TP7, TP8,
TP9 5 Test point, miniature, red, TH 5000 Keystone
TP4, TP5,
TP12, TP13 4 Test point, miniature, black, TH 5001 Keystone
U1 1 4.5-V to 17-V, 3-A 600 kHz PFM Synchronous Step-
Down Converter, DRL0006A (SOT-OTHER-6) TPS563231DRLR Texas Instruments
C8 0 Capacitor, ceramic, 100 pF, 50 V, ±5%, C0G/NP0, 0603 GRM1885C1H10
1JA01D MuRata
C9 0 Capacitor, ceramic, 0.01 µF, 50 V, ±10%, X7R, 0603 GRM188R71H10
3KA01D MuRata
R2 0 Resistor, 10 kΩ, 5%, 0.1 W, 0603 CRCW060310K0
JNEA Vishay-Dale
R4 0 Resistor, 0 Ω, 5%, 0.1W, 0603 ERJ-3GEY0R00V Panasonic
6.3 Reference
1. TPS56323x 4.5 V to 17 V Input, 3-A Synchronous Step-Down Voltage Regulator in SOT563 data sheet
(SLUSD65)
7 Trademarks
D-CAP3 is a trademark of Texas Instruments.

Revision History www.ti.com
16 SLUUBT7A–July 2018–Revised December 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Revision History
Revision History
NOTE: Page numbers for previous revisions may differ from page numbers in the current version.
Changes from July 1, 2018 to December 5, 2018 ............................................................................................................ Page
• Changed Figure 1 TPS563231EVM-032 Efficiency .................................................................................. 5
• Changed Figure 2 TPS563231EVM-032 Light Load Efficiency..................................................................... 5
• Changed Figure 3 TPS563231EVM-032 Load Regulation .......................................................................... 6
• Changed Figure 4 TPS563231EVM-032 Line Regulation ........................................................................... 7

STANDARD TERMS FOR EVALUATION MODULES
1. Delivery: TI delivers TI evaluation boards, kits, or modules, including any accompanying demonstration software, components, and/or
documentation which may be provided together or separately (collectively, an “EVM” or “EVMs”) to the User (“User”) in accordance
with the terms set forth herein. User's acceptance of the EVM is expressly subject to the following terms.
1.1 EVMs are intended solely for product or software developers for use in a research and development setting to facilitate feasibility
evaluation, experimentation, or scientific analysis of TI semiconductors products. EVMs have no direct function and are not
finished products. EVMs shall not be directly or indirectly assembled as a part or subassembly in any finished product. For
clarification, any software or software tools provided with the EVM (“Software”) shall not be subject to the terms and conditions
set forth herein but rather shall be subject to the applicable terms that accompany such Software
1.2 EVMs are not intended for consumer or household use. EVMs may not be sold, sublicensed, leased, rented, loaned, assigned,
or otherwise distributed for commercial purposes by Users, in whole or in part, or used in any finished product or production
system.
2Limited Warranty and Related Remedies/Disclaimers:
2.1 These terms do not apply to Software. The warranty, if any, for Software is covered in the applicable Software License
Agreement.
2.2 TI warrants that the TI EVM will conform to TI's published specifications for ninety (90) days after the date TI delivers such EVM
to User. Notwithstanding the foregoing, TI shall not be liable for a nonconforming EVM if (a) the nonconformity was caused by
neglect, misuse or mistreatment by an entity other than TI, including improper installation or testing, or for any EVMs that have
been altered or modified in any way by an entity other than TI, (b) the nonconformity resulted from User's design, specifications
or instructions for such EVMs or improper system design, or (c) User has not paid on time. Testing and other quality control
techniques are used to the extent TI deems necessary. TI does not test all parameters of each EVM.
User's claims against TI under this Section 2 are void if User fails to notify TI of any apparent defects in the EVMs within ten (10)
business days after delivery, or of any hidden defects with ten (10) business days after the defect has been detected.
2.3 TI's sole liability shall be at its option to repair or replace EVMs that fail to conform to the warranty set forth above, or credit
User's account for such EVM. TI's liability under this warranty shall be limited to EVMs that are returned during the warranty
period to the address designated by TI and that are determined by TI not to conform to such warranty. If TI elects to repair or
replace such EVM, TI shall have a reasonable time to repair such EVM or provide replacements. Repaired EVMs shall be
warranted for the remainder of the original warranty period. Replaced EVMs shall be warranted for a new full ninety (90) day
warranty period.
3Regulatory Notices:
3.1 United States
3.1.1 Notice applicable to EVMs not FCC-Approved:
FCC NOTICE: This kit is designed to allow product developers to evaluate electronic components, circuitry, or software
associated with the kit to determine whether to incorporate such items in a finished product and software developers to write
software applications for use with the end product. This kit is not a finished product and when assembled may not be resold or
otherwise marketed unless all required FCC equipment authorizations are first obtained. Operation is subject to the condition
that this product not cause harmful interference to licensed radio stations and that this product accept harmful interference.
Unless the assembled kit is designed to operate under part 15, part 18 or part 95 of this chapter, the operator of the kit must
operate under the authority of an FCC license holder or must secure an experimental authorization under part 5 of this chapter.
3.1.2 For EVMs annotated as FCC – FEDERAL COMMUNICATIONS COMMISSION Part 15 Compliant:
CAUTION
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
FCC Interference Statement for Class A EVM devices
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.

FCC Interference Statement for Class B EVM devices
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
3.2 Canada
3.2.1 For EVMs issued with an Industry Canada Certificate of Conformance to RSS-210 or RSS-247
Concerning EVMs Including Radio Transmitters:
This device complies with Industry Canada license-exempt RSSs. Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may
cause undesired operation of the device.
Concernant les EVMs avec appareils radio:
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
Concerning EVMs Including Detachable Antennas:
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser)
gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type
and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for
successful communication. This radio transmitter has been approved by Industry Canada to operate with the antenna types
listed in the user guide with the maximum permissible gain and required antenna impedance for each antenna type indicated.
Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited
for use with this device.
Concernant les EVMs avec antennes détachables
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et
d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage
radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope
rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante. Le
présent émetteur radio a été approuvé par Industrie Canada pour fonctionner avec les types d'antenne énumérés dans le
manuel d’usage et ayant un gain admissible maximal et l'impédance requise pour chaque type d'antenne. Les types d'antenne
non inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de
l'émetteur
3.3 Japan
3.3.1 Notice for EVMs delivered in Japan: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_01.page 日本国内に
輸入される評価用キット、ボードについては、次のところをご覧ください。
http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_01.page
3.3.2 Notice for Users of EVMs Considered “Radio Frequency Products” in Japan: EVMs entering Japan may not be certified
by TI as conforming to Technical Regulations of Radio Law of Japan.
If User uses EVMs in Japan, not certified to Technical Regulations of Radio Law of Japan, User is required to follow the
instructions set forth by Radio Law of Japan, which includes, but is not limited to, the instructions below with respect to EVMs
(which for the avoidance of doubt are stated strictly for convenience and should be verified by User):
1. Use EVMs in a shielded room or any other test facility as defined in the notification #173 issued by Ministry of Internal
Affairs and Communications on March 28, 2006, based on Sub-section 1.1 of Article 6 of the Ministry’s Rule for
Enforcement of Radio Law of Japan,
2. Use EVMs only after User obtains the license of Test Radio Station as provided in Radio Law of Japan with respect to
EVMs, or
3. Use of EVMs only after User obtains the Technical Regulations Conformity Certification as provided in Radio Law of Japan
with respect to EVMs. Also, do not transfer EVMs, unless User gives the same notice above to the transferee. Please note
that if User does not follow the instructions above, User will be subject to penalties of Radio Law of Japan.

【無線電波を送信する製品の開発キットをお使いになる際の注意事項】 開発キットの中には技術基準適合証明を受けて
いないものがあります。 技術適合証明を受けていないもののご使用に際しては、電波法遵守のため、以下のいずれかの
措置を取っていただく必要がありますのでご注意ください。
1. 電波法施行規則第6条第1項第1号に基づく平成18年3月28日総務省告示第173号で定められた電波暗室等の試験設備でご使用
いただく。
2. 実験局の免許を取得後ご使用いただく。
3. 技術基準適合証明を取得後ご使用いただく。
なお、本製品は、上記の「ご使用にあたっての注意」を譲渡先、移転先に通知しない限り、譲渡、移転できないものとします。
上記を遵守頂けない場合は、電波法の罰則が適用される可能性があることをご留意ください。 日本テキサス・イ
ンスツルメンツ株式会社
東京都新宿区西新宿６丁目２４番１号
西新宿三井ビル
3.3.3 Notice for EVMs for Power Line Communication: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page
電力線搬送波通信についての開発キットをお使いになる際の注意事項については、次のところをご覧ください。http:/
/www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page
3.4 European Union
3.4.1 For EVMs subject to EU Directive 2014/30/EU (Electromagnetic Compatibility Directive):
This is a class A product intended for use in environments other than domestic environments that are connected to a
low-voltage power-supply network that supplies buildings used for domestic purposes. In a domestic environment this
product may cause radio interference in which case the user may be required to take adequate measures.
4EVM Use Restrictions and Warnings:
4.1 EVMS ARE NOT FOR USE IN FUNCTIONAL SAFETY AND/OR SAFETY CRITICAL EVALUATIONS, INCLUDING BUT NOT
LIMITED TO EVALUATIONS OF LIFE SUPPORT APPLICATIONS.
4.2 User must read and apply the user guide and other available documentation provided by TI regarding the EVM prior to handling
or using the EVM, including without limitation any warning or restriction notices. The notices contain important safety information
related to, for example, temperatures and voltages.
4.3 Safety-Related Warnings and Restrictions:
4.3.1 User shall operate the EVM within TI’s recommended specifications and environmental considerations stated in the user
guide, other available documentation provided by TI, and any other applicable requirements and employ reasonable and
customary safeguards. Exceeding the specified performance ratings and specifications (including but not limited to input
and output voltage, current, power, and environmental ranges) for the EVM may cause personal injury or death, or
property damage. If there are questions concerning performance ratings and specifications, User should contact a TI
field representative prior to connecting interface electronics including input power and intended loads. Any loads applied
outside of the specified output range may also result in unintended and/or inaccurate operation and/or possible
permanent damage to the EVM and/or interface electronics. Please consult the EVM user guide prior to connecting any
load to the EVM output. If there is uncertainty as to the load specification, please contact a TI field representative.
During normal operation, even with the inputs and outputs kept within the specified allowable ranges, some circuit
components may have elevated case temperatures. These components include but are not limited to linear regulators,
switching transistors, pass transistors, current sense resistors, and heat sinks, which can be identified using the
information in the associated documentation. When working with the EVM, please be aware that the EVM may become
very warm.
4.3.2 EVMs are intended solely for use by technically qualified, professional electronics experts who are familiar with the
dangers and application risks associated with handling electrical mechanical components, systems, and subsystems.
User assumes all responsibility and liability for proper and safe handling and use of the EVM by User or its employees,
affiliates, contractors or designees. User assumes all responsibility and liability to ensure that any interfaces (electronic
and/or mechanical) between the EVM and any human body are designed with suitable isolation and means to safely
limit accessible leakage currents to minimize the risk of electrical shock hazard. User assumes all responsibility and
liability for any improper or unsafe handling or use of the EVM by User or its employees, affiliates, contractors or
designees.
4.4 User assumes all responsibility and liability to determine whether the EVM is subject to any applicable international, federal,
state, or local laws and regulations related to User’s handling and use of the EVM and, if applicable, User assumes all
responsibility and liability for compliance in all respects with such laws and regulations. User assumes all responsibility and
liability for proper disposal and recycling of the EVM consistent with all applicable international, federal, state, and local
requirements.
5. Accuracy of Information: To the extent TI provides information on the availability and function of EVMs, TI attempts to be as accurate
as possible. However, TI does not warrant the accuracy of EVM descriptions, EVM availability or other information on its websites as
accurate, complete, reliable, current, or error-free.

6. Disclaimers:
6.1 EXCEPT AS SET FORTH ABOVE, EVMS AND ANY MATERIALS PROVIDED WITH THE EVM (INCLUDING, BUT NOT
LIMITED TO, REFERENCE DESIGNS AND THE DESIGN OF THE EVM ITSELF) ARE PROVIDED "AS IS" AND "WITH ALL
FAULTS." TI DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, REGARDING SUCH ITEMS, INCLUDING BUT
NOT LIMITED TO ANY EPIDEMIC FAILURE WARRANTY OR IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT OF ANY THIRD PARTY PATENTS, COPYRIGHTS, TRADE
SECRETS OR OTHER INTELLECTUAL PROPERTY RIGHTS.
6.2 EXCEPT FOR THE LIMITED RIGHT TO USE THE EVM SET FORTH HEREIN, NOTHING IN THESE TERMS SHALL BE
CONSTRUED AS GRANTING OR CONFERRING ANY RIGHTS BY LICENSE, PATENT, OR ANY OTHER INDUSTRIAL OR
INTELLECTUAL PROPERTY RIGHT OF TI, ITS SUPPLIERS/LICENSORS OR ANY OTHER THIRD PARTY, TO USE THE
EVM IN ANY FINISHED END-USER OR READY-TO-USE FINAL PRODUCT, OR FOR ANY INVENTION, DISCOVERY OR
IMPROVEMENT, REGARDLESS OF WHEN MADE, CONCEIVED OR ACQUIRED.
7. USER'S INDEMNITY OBLIGATIONS AND REPRESENTATIONS. USER WILL DEFEND, INDEMNIFY AND HOLD TI, ITS
LICENSORS AND THEIR REPRESENTATIVES HARMLESS FROM AND AGAINST ANY AND ALL CLAIMS, DAMAGES, LOSSES,
EXPENSES, COSTS AND LIABILITIES (COLLECTIVELY, "CLAIMS") ARISING OUT OF OR IN CONNECTION WITH ANY
HANDLING OR USE OF THE EVM THAT IS NOT IN ACCORDANCE WITH THESE TERMS. THIS OBLIGATION SHALL APPLY
WHETHER CLAIMS ARISE UNDER STATUTE, REGULATION, OR THE LAW OF TORT, CONTRACT OR ANY OTHER LEGAL
THEORY, AND EVEN IF THE EVM FAILS TO PERFORM AS DESCRIBED OR EXPECTED.
8. Limitations on Damages and Liability:
8.1 General Limitations. IN NO EVENT SHALL TI BE LIABLE FOR ANY SPECIAL, COLLATERAL, INDIRECT, PUNITIVE,
INCIDENTAL, CONSEQUENTIAL, OR EXEMPLARY DAMAGES IN CONNECTION WITH OR ARISING OUT OF THESE
TERMS OR THE USE OF THE EVMS , REGARDLESS OF WHETHER TI HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. EXCLUDED DAMAGES INCLUDE, BUT ARE NOT LIMITED TO, COST OF REMOVAL OR
REINSTALLATION, ANCILLARY COSTS TO THE PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES, RETESTING,
OUTSIDE COMPUTER TIME, LABOR COSTS, LOSS OF GOODWILL, LOSS OF PROFITS, LOSS OF SAVINGS, LOSS OF
USE, LOSS OF DATA, OR BUSINESS INTERRUPTION. NO CLAIM, SUIT OR ACTION SHALL BE BROUGHT AGAINST TI
MORE THAN TWELVE (12) MONTHS AFTER THE EVENT THAT GAVE RISE TO THE CAUSE OF ACTION HAS
OCCURRED.
8.2 Specific Limitations. IN NO EVENT SHALL TI'S AGGREGATE LIABILITY FROM ANY USE OF AN EVM PROVIDED
HEREUNDER, INCLUDING FROM ANY WARRANTY, INDEMITY OR OTHER OBLIGATION ARISING OUT OF OR IN
CONNECTION WITH THESE TERMS, , EXCEED THE TOTAL AMOUNT PAID TO TI BY USER FOR THE PARTICULAR
EVM(S) AT ISSUE DURING THE PRIOR TWELVE (12) MONTHS WITH RESPECT TO WHICH LOSSES OR DAMAGES ARE
CLAIMED. THE EXISTENCE OF MORE THAN ONE CLAIM SHALL NOT ENLARGE OR EXTEND THIS LIMIT.
9. Return Policy. Except as otherwise provided, TI does not offer any refunds, returns, or exchanges. Furthermore, no return of EVM(s)
will be accepted if the package has been opened and no return of the EVM(s) will be accepted if they are damaged or otherwise not in
a resalable condition. If User feels it has been incorrectly charged for the EVM(s) it ordered or that delivery violates the applicable
order, User should contact TI. All refunds will be made in full within thirty (30) working days from the return of the components(s),
excluding any postage or packaging costs.
10. Governing Law: These terms and conditions shall be governed by and interpreted in accordance with the laws of the State of Texas,
without reference to conflict-of-laws principles. User agrees that non-exclusive jurisdiction for any dispute arising out of or relating to
these terms and conditions lies within courts located in the State of Texas and consents to venue in Dallas County, Texas.
Notwithstanding the foregoing, any judgment may be enforced in any United States or foreign court, and TI may seek injunctive relief
in any United States or foreign court.
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265
Copyright © 2018, Texas Instruments Incorporated
