1 Description
The TPS51120 is a highly sophisticated dual current mode synchronous step-down controller. It is a full-featured
controller designed to run directly off three to four-cell Li-ion battery and provide high power and 5-V, 3.3-V, or
both, standby regulation for all the downstream circuitry in a notebook computer system. High current, 100-mA,
5-V, or 3.3-V on-board linear regulators have glitch-free switch over function to SMPS and can be kept alive
independently during standby state. The pseudo-constant frequency adaptive on-time control scheme supports
full range of current mode operation including simplified loop compensation, ceramic output capacitors, and
seamless transition to reduced frequency operation at light-load condition. Optional D-CAP™ mode operation
optimized for SP-CAP or POSCAP output capacitors allows further reduction of external compensation parts.
The TPS51120EVM-001 evaluation module is a high efficiency, dual synchronous buck converter providing 5 V
at 6 A and 3.3 V at 6 A from 8-V to 25-V input. This user’s guide describes the TPS51120EVM-001 performance
in D-CAP mode and RDS(on) current sensing.
2 Electrical Performance
Table 2-1. Electrical Performance
Specifications Test Conditions MIN TYP MAX Unit
Input voltage range (VBAT) 8 12 25 V
CH1
Output voltage 5 V
Operating frequency TONSEL: VREF2, VBAT = 12 V, IOUT1 = 6 A 280 kHz
Output current VBAT = 8 V to 25 V 6 A
Overcurrent limit VBAT = 12 V 10 A
Output ripple voltage VBAT = 12 V, IOUT1 = 6 A 40 mVp-p
CH2
Output voltage 3.3 V
Operating frequency TONSEL: VREF2, VBAT = 12 V, IOUT2 = 6 A 430 kHz
Output current VBAT = 8 V to 25 V 6 A
Overcurrent limit VBAT = 12 V 10 A
Output ripple voltage VBAT = 12 V, IOUT2 = 6 A 45 mVp-p
Description www.ti.com
2TPS51120 Buck Controller Evaluation Module User's Guide SLUU240B – JANUARY 2006 – REVISED MARCH 2022
Submit Document Feedback
Copyright © 2022 Texas Instruments Incorporated

3 Schematic
Figure 3-1. TPS51120 EVM Schematic Diagram
www.ti.com Schematic
SLUU240B – JANUARY 2006 – REVISED MARCH 2022
Submit Document Feedback
TPS51120 Buck Controller Evaluation Module User's Guide 3
Copyright © 2022 Texas Instruments Incorporated

4 Test Setup and Results
4.1 Test Setup
Connect the test equipment and TPS51120EVM-001 board as shown in Figure 4-1.
4. Test Setup and Results
4.1. Test setup
Connect test equipment and TPS51120EVM-001 board as shown in Figure 2.
HPA153
TPS51120EVM
+
-Electronic
Load2
Oscilloscope
CH2
Electronic
Load1
+
-
Oscilloscope
CH1
V O 1
V O 1_G N D
V O 2
V O 2_G N D
12V/10A
Power supply
V B AT_G N D
V B A T
DMM4
+
-
+
-
DMM3
+
-
DMM2
+
-
DMM1
+
-
V R EG 5
V R EG 3
DMM6
+
-
DMM5
+
-
V R EF2
C N 1
C N 2
Figure 4-1. Equipment Setup for TPS51120EVM-001 Board
4.2 Test Procedure
1. Make sure the switches SW1 (EN1), SW2 (EN2), SW3 (EN5), and SW4 (EN3) are in the “OFF” position.
2. Make sure the shunt jumper for JP1 is set 5-pin to 6-pin (Med2), and shunt jumper for JP2 is set 1-pin to 2-
pin (auto-skip).
3. Apply appropriate VBAT voltage to VBAT1 and VBAT_GND1 terminals.
4. Turn on SW3 (EN5) and VREG5 (5V-LDO) starts up.
5. Turn on SW4 (EN3) and VREG3 (3.3V-LDO) starts up.
6. When SW3 and SW4 stay on, VREF2 (2V-REF) enables.
7. When SW3 and SW4 stay on and turn on SW1 (EN1), CH1-output will start up.
8. When SW3 and SW4 stay on and turn on SW2 (EN2), CH2-output will start up.
Test Setup and Results www.ti.com
4TPS51120 Buck Controller Evaluation Module User's Guide SLUU240B – JANUARY 2006 – REVISED MARCH 2022
Submit Document Feedback
Copyright © 2022 Texas Instruments Incorporated

4.3 Start-Up Performance
Figure 4-2. 5-V Start-Up Waveforms Figure 4-3. 3.3-V Start-Up Waveforms
4.4 Transient Performance
Figure 4-4. 5-V Load Transient Response Figure 4-5. 3.3-V Load Transient Response
www.ti.com Test Setup and Results
SLUU240B – JANUARY 2006 – REVISED MARCH 2022
Submit Document Feedback
TPS51120 Buck Controller Evaluation Module User's Guide 5
Copyright © 2022 Texas Instruments Incorporated

5 Configuration
This EVM could be set to the user’s desirable configurations. Please refer to the following specific configuration
setting sections.
5.1 Switching Frequency Selection
The switching frequency can be set by the TONSEL pin using JP1 on the EVM. The default setting is Medium2.
Table 5-1. Switching Frequency Selection
Jumper (JP1) Set to Frequency(1)
TYP CH1 CH2
Top (1-2 pin shorted) Slow 180 kHz 270 kHz
2nd (3-4 pin shorted) Medium1 220 kHz 330 kHz
3rd (5-6 pin shorted) Medium2 280 kHz 430 kHz
Bottom (7-8 pin shorted) Fast 380 kHz 580 kHz
(1) Frequencies are approximate.
5.2 Skip Mode and Faults Disable Selection
Skip mode can be set by the SKIPSEL pin using JP2 on the EVM. In addition, faults disable mode can be
selected for debugging purpose. The default setting is auto-skip and fault enable.
Table 5-2. Skip Mode Selection
Jumper (JP2) set to Skip Faults
Top (1-2 pin shorted) Auto-skip Enable
2nd (3-4 pin shorted) Auto-skip Disable
Bottom (5-6 pin shorted) PWM Enable
5.3 Output Voltage Setting Selection
Output voltage can be set by the VFBx pin using some resistors on the EVM. The default setting is adjustable
output.
Table 5-3. Output Voltage Setting Selection (CH1)
R3 R4 R9
Adjustable output 7.5 kW 30 kW Open
Fixed output; 5 V Open Open 0 W
Table 5-4. Output Voltage Setting Selection (CH2)
R28 R29 R25
Adjustable output 7.5 kW 17.2 kW Open
Fixed output; 3.3 V Open Open 0 W
5.4 Control Scheme Selection
The control scheme can be set by the COMPx pin using some resistors and capacitors on the EVM. The default
setting is D-CAP mode.
Table 5-5. Control Scheme Selection (CH1)
R12 C9 C11 R14
D-CAP mode Shorted Open Open Open
Current mode(1) Open Put on Put on Put on
(1) When current mode is selected, please add appropriate parts on C9, C11, and R14 and cut the trace between the pads of R12.
Table 5-6. Control Scheme Selection (CH2)
R24 C15 C14 R20
D-CAP mode Shorted Open Open Open
Configuration www.ti.com
6TPS51120 Buck Controller Evaluation Module User's Guide SLUU240B – JANUARY 2006 – REVISED MARCH 2022
Submit Document Feedback
Copyright © 2022 Texas Instruments Incorporated

Table 5-6. Control Scheme Selection (CH2) (continued)
R24 C15 C14 R20
Current mode(1) Open Put on Put on Put on
(1) When current mode is selected, please add appropriate parts on C15, C14, and R20 and cut the trace between the pads of R24.
www.ti.com Configuration
SLUU240B – JANUARY 2006 – REVISED MARCH 2022
Submit Document Feedback
TPS51120 Buck Controller Evaluation Module User's Guide 7
Copyright © 2022 Texas Instruments Incorporated

6 EVM Assembly Drawing and PCB Layout
Figure 6-1. Top Assembly
Figure 6-2. Bottom Assembly
EVM Assembly Drawing and PCB Layout www.ti.com
8TPS51120 Buck Controller Evaluation Module User's Guide SLUU240B – JANUARY 2006 – REVISED MARCH 2022
Submit Document Feedback
Copyright © 2022 Texas Instruments Incorporated

Figure 6-3. Top Layer
Figure 6-4. Inner Layer 1
www.ti.com EVM Assembly Drawing and PCB Layout
SLUU240B – JANUARY 2006 – REVISED MARCH 2022
Submit Document Feedback
TPS51120 Buck Controller Evaluation Module User's Guide 9
Copyright © 2022 Texas Instruments Incorporated

Figure 6-5. Inner Layer 2
Figure 6-6. Bottom Layer
EVM Assembly Drawing and PCB Layout www.ti.com
10 TPS51120 Buck Controller Evaluation Module User's Guide SLUU240B – JANUARY 2006 – REVISED MARCH 2022
Submit Document Feedback
Copyright © 2022 Texas Instruments Incorporated

7 List of Materials
Reference Designator QTY Description Size Mfr Part Number
— 2 Shunt,100 mil, Black 0.100 3M 929950-00
C1, C24 0 Capacitor,Ceramic 1210 Any Any
C13 1 Capacitor,Ceramic, 1 mF,6.3 V, BJ, 20% 0805 TDK C2012X5R0J105K
C16, C17 2 Capacitor,Ceramic, 10 mF,6.3 V, BJ, 20% 0805 TDK C2012X5R0J106K
C2, C3, C25, C26 4 Capacitor,Ceramic, 10 mF,25 V, BJ , 20% 1210 Taiyo Yuden TMK325BJ106MM
C4, C7, C9, C11, C12, C14,
C15, C19,C27
0 Capacitor,Ceramic 0805 Any Any
C5, C18, C22 3 Capacitor,Ceramic, 1 nF, 50 V, BJ, 20% 0805 Std Std
C6, C23 2 Capacitor,Ceramic, 0.1 mF,50 V, BJ, 20% 0805 Std Std
C8, C10, C20, C21 4 Capacitor,POSCAP, 150 mF, 6.3 V, 55 mW, 20% 7343 SANYO 6TPB150ML
CN1, CN2 2 Adaptor, 3.5-mm probe clip (or 131-5031-00) 0.2 Tektronix 131-4244-00
D1, D4 0 Diode,Schottky, 0.5 A, 30 V SOD-123 Any Any
D2, D3 0 Diode,Schottky, 1 A, 30 V SMA Any Any
JP1 1 Header, 2 × 4 pin,100-mil spacing (36-pin strip) 0.20 × 0.40 inch Sullins PTC36DAAN
JP2 1 Header, 2 × 3 pin, 100-mil spacing (36-pin strip) 0.20 × 0.30 inch Sullins PTC36DAAN
L1 1 Inductor,4.7 μH, 12.8 A, 8.8 mW 0.496 × 0.532 inch Toko FDA1254-4R7M
L2 1 Inductor,2.2 μH, 17.8 A, 4.5 mW 0.496 × 0.532 inch Toko FDA1254-2R2M
Q1, Q4 2 MOSFET, N-ch, 30 V, 11 A, 9.1 mW SO8 IR IRF7821
Q2, Q3 2 MOSFET, N-ch, 30 V, 16 A, 4.0 mW SO8 IR IRF7832
R1, R2, R5, R8, R9, R11–
R15, R20–R22, R24, R25,
R27, R31, R32
0 Resistor,Chip 0805 Any Any
R10, R26 2 Resistor,Chip, 100 kW,1/10W, 1% 0805 Std Std
R16, R23 0 Resistor,Metal Strip, 1 W, 1% 2512 Std Std
R17 1 Resistor,Chip, 3.6 kW,1/10W, 1% 0805 Std Std
R19 1 Resistor,Chip, 3.3 kW,1/10W, 1% 0805 Std Std
R29 1 Resistor,Chip, 17.2 kW,1/10W, 1% 0805 Std Std
R3, R6, R28 3 Resistor,Chip, 7.5 kW,1/10W, 1% 0805 Std Std
R4 1 Resistor,Chip, 30 kW,1/10W, 1% 0805 Std Std
R7, R18, R30 3 Resistor,Chip, 5.1 W,1/10W, 1% 0805 Std Std
SW1, SW2, SW3, SW4 4 Switch,ON-ON Mini Toggle 0.28 × 0.18 inch Nikkai G12AP
TP1–TP5 5 Pin,Probe monitor 0.12(D) × 0.4 inch MillMax or MAC8 LC-2-S
U1 1 IC, Dual Current Mode, Sync. Step-down Controller QFN32 TI TPS51120RHB
VO1, VO2,VO1_GND1,
VO2_GND1,
VBAT_GND1,VBAT1
6 Pin, Wiring Terminal 0.12(D) × 0.4 inch MillMax or MAC8 3183-2-00-15-00-00-080 or
WT-3-1
8 References
Texas Instruments, TPS51120 Dual Current Mode, Synchronous Step-Down Controller data sheet
9 Revision History
NOTE: Page numbers for previous revisions may differ from page numbers in the current version.
Changes from Revision A (February 2006) to Revision B (March 2022) Page
• Updated the numbering format for tables, figures, and cross-references throughout the document. ................2
• Updated the user's guide title............................................................................................................................. 2
www.ti.com List of Materials
SLUU240B – JANUARY 2006 – REVISED MARCH 2022
Submit Document Feedback
TPS51120 Buck Controller Evaluation Module User's Guide 11
Copyright © 2022 Texas Instruments Incorporated

STANDARD TERMS FOR EVALUATION MODULES
1. Delivery: TI delivers TI evaluation boards, kits, or modules, including any accompanying demonstration software, components, and/or
documentation which may be provided together or separately (collectively, an “EVM” or “EVMs”) to the User (“User”) in accordance
with the terms set forth herein. User's acceptance of the EVM is expressly subject to the following terms.
1.1 EVMs are intended solely for product or software developers for use in a research and development setting to facilitate feasibility
evaluation, experimentation, or scientific analysis of TI semiconductors products. EVMs have no direct function and are not
finished products. EVMs shall not be directly or indirectly assembled as a part or subassembly in any finished product. For
clarification, any software or software tools provided with the EVM (“Software”) shall not be subject to the terms and conditions
set forth herein but rather shall be subject to the applicable terms that accompany such Software
1.2 EVMs are not intended for consumer or household use. EVMs may not be sold, sublicensed, leased, rented, loaned, assigned,
or otherwise distributed for commercial purposes by Users, in whole or in part, or used in any finished product or production
system.
2Limited Warranty and Related Remedies/Disclaimers:
2.1 These terms do not apply to Software. The warranty, if any, for Software is covered in the applicable Software License
Agreement.
2.2 TI warrants that the TI EVM will conform to TI's published specifications for ninety (90) days after the date TI delivers such EVM
to User. Notwithstanding the foregoing, TI shall not be liable for a nonconforming EVM if (a) the nonconformity was caused by
neglect, misuse or mistreatment by an entity other than TI, including improper installation or testing, or for any EVMs that have
been altered or modified in any way by an entity other than TI, (b) the nonconformity resulted from User's design, specifications
or instructions for such EVMs or improper system design, or (c) User has not paid on time. Testing and other quality control
techniques are used to the extent TI deems necessary. TI does not test all parameters of each EVM.
User's claims against TI under this Section 2 are void if User fails to notify TI of any apparent defects in the EVMs within ten (10)
business days after delivery, or of any hidden defects with ten (10) business days after the defect has been detected.
2.3 TI's sole liability shall be at its option to repair or replace EVMs that fail to conform to the warranty set forth above, or credit
User's account for such EVM. TI's liability under this warranty shall be limited to EVMs that are returned during the warranty
period to the address designated by TI and that are determined by TI not to conform to such warranty. If TI elects to repair or
replace such EVM, TI shall have a reasonable time to repair such EVM or provide replacements. Repaired EVMs shall be
warranted for the remainder of the original warranty period. Replaced EVMs shall be warranted for a new full ninety (90) day
warranty period.
WARNING
Evaluation Kits are intended solely for use by technically qualified,
professional electronics experts who are familiar with the dangers
and application risks associated with handling electrical mechanical
components, systems, and subsystems.
User shall operate the Evaluation Kit within TI’s recommended
guidelines and any applicable legal or environmental requirements
as well as reasonable and customary safeguards. Failure to set up
and/or operate the Evaluation Kit within TI’s recommended
guidelines may result in personal injury or death or property
damage. Proper set up entails following TI’s instructions for
electrical ratings of interface circuits such as input, output and
electrical loads.
NOTE:
EXPOSURE TO ELECTROSTATIC DISCHARGE (ESD) MAY CAUSE DEGREDATION OR FAILURE OF THE EVALUATION
KIT; TI RECOMMENDS STORAGE OF THE EVALUATION KIT IN A PROTECTIVE ESD BAG.

www.ti.com
2
3Regulatory Notices:
3.1 United States
3.1.1 Notice applicable to EVMs not FCC-Approved:
FCC NOTICE: This kit is designed to allow product developers to evaluate electronic components, circuitry, or software
associated with the kit to determine whether to incorporate such items in a finished product and software developers to write
software applications for use with the end product. This kit is not a finished product and when assembled may not be resold or
otherwise marketed unless all required FCC equipment authorizations are first obtained. Operation is subject to the condition
that this product not cause harmful interference to licensed radio stations and that this product accept harmful interference.
Unless the assembled kit is designed to operate under part 15, part 18 or part 95 of this chapter, the operator of the kit must
operate under the authority of an FCC license holder or must secure an experimental authorization under part 5 of this chapter.
3.1.2 For EVMs annotated as FCC – FEDERAL COMMUNICATIONS COMMISSION Part 15 Compliant:
CAUTION
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
FCC Interference Statement for Class A EVM devices
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
FCC Interference Statement for Class B EVM devices
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
3.2 Canada
3.2.1 For EVMs issued with an Industry Canada Certificate of Conformance to RSS-210 or RSS-247
Concerning EVMs Including Radio Transmitters:
This device complies with Industry Canada license-exempt RSSs. Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may
cause undesired operation of the device.
Concernant les EVMs avec appareils radio:
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
Concerning EVMs Including Detachable Antennas:
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser)
gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type
and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for
successful communication. This radio transmitter has been approved by Industry Canada to operate with the antenna types
listed in the user guide with the maximum permissible gain and required antenna impedance for each antenna type indicated.
Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited
for use with this device.

www.ti.com
3
Concernant les EVMs avec antennes détachables
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et
d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage
radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope
rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante. Le
présent émetteur radio a été approuvé par Industrie Canada pour fonctionner avec les types d'antenne énumérés dans le
manuel d’usage et ayant un gain admissible maximal et l'impédance requise pour chaque type d'antenne. Les types d'antenne
non inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de
l'émetteur
3.3 Japan
3.3.1 Notice for EVMs delivered in Japan: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_01.page 日本国内に
輸入される評価用キット、ボードについては、次のところをご覧ください。
http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_01.page
3.3.2 Notice for Users of EVMs Considered “Radio Frequency Products” in Japan: EVMs entering Japan may not be certified
by TI as conforming to Technical Regulations of Radio Law of Japan.
If User uses EVMs in Japan, not certified to Technical Regulations of Radio Law of Japan, User is required to follow the
instructions set forth by Radio Law of Japan, which includes, but is not limited to, the instructions below with respect to EVMs
(which for the avoidance of doubt are stated strictly for convenience and should be verified by User):
1. Use EVMs in a shielded room or any other test facility as defined in the notification #173 issued by Ministry of Internal
Affairs and Communications on March 28, 2006, based on Sub-section 1.1 of Article 6 of the Ministry’s Rule for
Enforcement of Radio Law of Japan,
2. Use EVMs only after User obtains the license of Test Radio Station as provided in Radio Law of Japan with respect to
EVMs, or
3. Use of EVMs only after User obtains the Technical Regulations Conformity Certification as provided in Radio Law of Japan
with respect to EVMs. Also, do not transfer EVMs, unless User gives the same notice above to the transferee. Please note
that if User does not follow the instructions above, User will be subject to penalties of Radio Law of Japan.
【無線電波を送信する製品の開発キットをお使いになる際の注意事項】 開発キットの中には技術基準適合証明を受けて
いないものがあります。 技術適合証明を受けていないもののご使用に際しては、電波法遵守のため、以下のいずれかの
措置を取っていただく必要がありますのでご注意ください。
1. 電波法施行規則第6条第1項第1号に基づく平成18年3月28日総務省告示第173号で定められた電波暗室等の試験設備でご使用
いただく。
2. 実験局の免許を取得後ご使用いただく。
3. 技術基準適合証明を取得後ご使用いただく。
なお、本製品は、上記の「ご使用にあたっての注意」を譲渡先、移転先に通知しない限り、譲渡、移転できないものとします。
上記を遵守頂けない場合は、電波法の罰則が適用される可能性があることをご留意ください。 日本テキサス・イ
ンスツルメンツ株式会社
東京都新宿区西新宿６丁目２４番１号
西新宿三井ビル
3.3.3 Notice for EVMs for Power Line Communication: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page
電力線搬送波通信についての開発キットをお使いになる際の注意事項については、次のところをご覧ください。http:/
/www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page
3.4 European Union
3.4.1 For EVMs subject to EU Directive 2014/30/EU (Electromagnetic Compatibility Directive):
This is a class A product intended for use in environments other than domestic environments that are connected to a
low-voltage power-supply network that supplies buildings used for domestic purposes. In a domestic environment this
product may cause radio interference in which case the user may be required to take adequate measures.

www.ti.com
4
4EVM Use Restrictions and Warnings:
4.1 EVMS ARE NOT FOR USE IN FUNCTIONAL SAFETY AND/OR SAFETY CRITICAL EVALUATIONS, INCLUDING BUT NOT
LIMITED TO EVALUATIONS OF LIFE SUPPORT APPLICATIONS.
4.2 User must read and apply the user guide and other available documentation provided by TI regarding the EVM prior to handling
or using the EVM, including without limitation any warning or restriction notices. The notices contain important safety information
related to, for example, temperatures and voltages.
4.3 Safety-Related Warnings and Restrictions:
4.3.1 User shall operate the EVM within TI’s recommended specifications and environmental considerations stated in the user
guide, other available documentation provided by TI, and any other applicable requirements and employ reasonable and
customary safeguards. Exceeding the specified performance ratings and specifications (including but not limited to input
and output voltage, current, power, and environmental ranges) for the EVM may cause personal injury or death, or
property damage. If there are questions concerning performance ratings and specifications, User should contact a TI
field representative prior to connecting interface electronics including input power and intended loads. Any loads applied
outside of the specified output range may also result in unintended and/or inaccurate operation and/or possible
permanent damage to the EVM and/or interface electronics. Please consult the EVM user guide prior to connecting any
load to the EVM output. If there is uncertainty as to the load specification, please contact a TI field representative.
During normal operation, even with the inputs and outputs kept within the specified allowable ranges, some circuit
components may have elevated case temperatures. These components include but are not limited to linear regulators,
switching transistors, pass transistors, current sense resistors, and heat sinks, which can be identified using the
information in the associated documentation. When working with the EVM, please be aware that the EVM may become
very warm.
4.3.2 EVMs are intended solely for use by technically qualified, professional electronics experts who are familiar with the
dangers and application risks associated with handling electrical mechanical components, systems, and subsystems.
User assumes all responsibility and liability for proper and safe handling and use of the EVM by User or its employees,
affiliates, contractors or designees. User assumes all responsibility and liability to ensure that any interfaces (electronic
and/or mechanical) between the EVM and any human body are designed with suitable isolation and means to safely
limit accessible leakage currents to minimize the risk of electrical shock hazard. User assumes all responsibility and
liability for any improper or unsafe handling or use of the EVM by User or its employees, affiliates, contractors or
designees.
4.4 User assumes all responsibility and liability to determine whether the EVM is subject to any applicable international, federal,
state, or local laws and regulations related to User’s handling and use of the EVM and, if applicable, User assumes all
responsibility and liability for compliance in all respects with such laws and regulations. User assumes all responsibility and
liability for proper disposal and recycling of the EVM consistent with all applicable international, federal, state, and local
requirements.
5. Accuracy of Information: To the extent TI provides information on the availability and function of EVMs, TI attempts to be as accurate
as possible. However, TI does not warrant the accuracy of EVM descriptions, EVM availability or other information on its websites as
accurate, complete, reliable, current, or error-free.
6. Disclaimers:
6.1 EXCEPT AS SET FORTH ABOVE, EVMS AND ANY MATERIALS PROVIDED WITH THE EVM (INCLUDING, BUT NOT
LIMITED TO, REFERENCE DESIGNS AND THE DESIGN OF THE EVM ITSELF) ARE PROVIDED "AS IS" AND "WITH ALL
FAULTS." TI DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, REGARDING SUCH ITEMS, INCLUDING BUT
NOT LIMITED TO ANY EPIDEMIC FAILURE WARRANTY OR IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT OF ANY THIRD PARTY PATENTS, COPYRIGHTS, TRADE
SECRETS OR OTHER INTELLECTUAL PROPERTY RIGHTS.
6.2 EXCEPT FOR THE LIMITED RIGHT TO USE THE EVM SET FORTH HEREIN, NOTHING IN THESE TERMS SHALL BE
CONSTRUED AS GRANTING OR CONFERRING ANY RIGHTS BY LICENSE, PATENT, OR ANY OTHER INDUSTRIAL OR
INTELLECTUAL PROPERTY RIGHT OF TI, ITS SUPPLIERS/LICENSORS OR ANY OTHER THIRD PARTY, TO USE THE
EVM IN ANY FINISHED END-USER OR READY-TO-USE FINAL PRODUCT, OR FOR ANY INVENTION, DISCOVERY OR
IMPROVEMENT, REGARDLESS OF WHEN MADE, CONCEIVED OR ACQUIRED.
7. USER'S INDEMNITY OBLIGATIONS AND REPRESENTATIONS. USER WILL DEFEND, INDEMNIFY AND HOLD TI, ITS
LICENSORS AND THEIR REPRESENTATIVES HARMLESS FROM AND AGAINST ANY AND ALL CLAIMS, DAMAGES, LOSSES,
EXPENSES, COSTS AND LIABILITIES (COLLECTIVELY, "CLAIMS") ARISING OUT OF OR IN CONNECTION WITH ANY
HANDLING OR USE OF THE EVM THAT IS NOT IN ACCORDANCE WITH THESE TERMS. THIS OBLIGATION SHALL APPLY
WHETHER CLAIMS ARISE UNDER STATUTE, REGULATION, OR THE LAW OF TORT, CONTRACT OR ANY OTHER LEGAL
THEORY, AND EVEN IF THE EVM FAILS TO PERFORM AS DESCRIBED OR EXPECTED.

www.ti.com
5
8. Limitations on Damages and Liability:
8.1 General Limitations. IN NO EVENT SHALL TI BE LIABLE FOR ANY SPECIAL, COLLATERAL, INDIRECT, PUNITIVE,
INCIDENTAL, CONSEQUENTIAL, OR EXEMPLARY DAMAGES IN CONNECTION WITH OR ARISING OUT OF THESE
TERMS OR THE USE OF THE EVMS , REGARDLESS OF WHETHER TI HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. EXCLUDED DAMAGES INCLUDE, BUT ARE NOT LIMITED TO, COST OF REMOVAL OR
REINSTALLATION, ANCILLARY COSTS TO THE PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES, RETESTING,
OUTSIDE COMPUTER TIME, LABOR COSTS, LOSS OF GOODWILL, LOSS OF PROFITS, LOSS OF SAVINGS, LOSS OF
USE, LOSS OF DATA, OR BUSINESS INTERRUPTION. NO CLAIM, SUIT OR ACTION SHALL BE BROUGHT AGAINST TI
MORE THAN TWELVE (12) MONTHS AFTER THE EVENT THAT GAVE RISE TO THE CAUSE OF ACTION HAS
OCCURRED.
8.2 Specific Limitations. IN NO EVENT SHALL TI'S AGGREGATE LIABILITY FROM ANY USE OF AN EVM PROVIDED
HEREUNDER, INCLUDING FROM ANY WARRANTY, INDEMITY OR OTHER OBLIGATION ARISING OUT OF OR IN
CONNECTION WITH THESE TERMS, , EXCEED THE TOTAL AMOUNT PAID TO TI BY USER FOR THE PARTICULAR
EVM(S) AT ISSUE DURING THE PRIOR TWELVE (12) MONTHS WITH RESPECT TO WHICH LOSSES OR DAMAGES ARE
CLAIMED. THE EXISTENCE OF MORE THAN ONE CLAIM SHALL NOT ENLARGE OR EXTEND THIS LIMIT.
9. Return Policy. Except as otherwise provided, TI does not offer any refunds, returns, or exchanges. Furthermore, no return of EVM(s)
will be accepted if the package has been opened and no return of the EVM(s) will be accepted if they are damaged or otherwise not in
a resalable condition. If User feels it has been incorrectly charged for the EVM(s) it ordered or that delivery violates the applicable
order, User should contact TI. All refunds will be made in full within thirty (30) working days from the return of the components(s),
excluding any postage or packaging costs.
10. Governing Law: These terms and conditions shall be governed by and interpreted in accordance with the laws of the State of Texas,
without reference to conflict-of-laws principles. User agrees that non-exclusive jurisdiction for any dispute arising out of or relating to
these terms and conditions lies within courts located in the State of Texas and consents to venue in Dallas County, Texas.
Notwithstanding the foregoing, any judgment may be enforced in any United States or foreign court, and TI may seek injunctive relief
in any United States or foreign court.
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265
Copyright © 2019, Texas Instruments Incorporated

IMPORTANT NOTICE AND DISCLAIMER
TI PROVIDES TECHNICAL AND RELIABILITY DATA (INCLUDING DATA SHEETS), DESIGN RESOURCES (INCLUDING REFERENCE
DESIGNS), APPLICATION OR OTHER DESIGN ADVICE, WEB TOOLS, SAFETY INFORMATION, AND OTHER RESOURCES “AS IS”
AND WITH ALL FAULTS, AND DISCLAIMS ALL WARRANTIES, EXPRESS AND IMPLIED, INCLUDING WITHOUT LIMITATION ANY
IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT OF THIRD
PARTY INTELLECTUAL PROPERTY RIGHTS.
These resources are intended for skilled developers designing with TI products. You are solely responsible for (1) selecting the appropriate
TI products for your application, (2) designing, validating and testing your application, and (3) ensuring your application meets applicable
standards, and any other safety, security, regulatory or other requirements.
These resources are subject to change without notice. TI grants you permission to use these resources only for development of an
application that uses the TI products described in the resource. Other reproduction and display of these resources is prohibited. No license
is granted to any other TI intellectual property right or to any third party intellectual property right. TI disclaims responsibility for, and you
will fully indemnify TI and its representatives against, any claims, damages, costs, losses, and liabilities arising out of your use of these
resources.
TI’s products are provided subject to TI’s Terms of Sale or other applicable terms available either on ti.com or provided in conjunction with
such TI products. TI’s provision of these resources does not expand or otherwise alter TI’s applicable warranties or warranty disclaimers for
TI products.
TI objects to and rejects any additional or different terms you may have proposed. IMPORTANT NOTICE
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265
Copyright © 2022, Texas Instruments Incorporated
