TL-QUAD-LOOP & TL-DUAL-LOOP Transmitter Manual (d0108)
Input Range:��������������Jumper selectable DC current (4-20mA)
and DC voltage (0-5V, 1-5V, 0-10V)�
Accuracy:������������������±0�02% of reading�
Warm up time:�����������Up to 10 minutes depending on input�
Transducer Excitation : 24 Vdc output, 90 mA max�
Isolation:��������������������5000Vrms isolation between input and
output signals, power supply isolation
between input and output�
Power Indicator:�������Red or Green power LED
Power Supply:�����������AC/DC Auto sensing wide range supply
PS1 (std) ����������������
85-265 VAC 50-400Hz / 95-300 VDC 3.5W max.
PS2 ������������������������� 15-48 VAC 50-400Hz / 10-72 VDC 3�5W
max�
Environmental-
Operating Temperature.: 0 to 50 ˚C (32 ˚F to 122 ˚F).
Storage Temperature: -20 ˚C to 70 ˚C (-4 ˚F to 158 ˚F).
Relative Humidity:����95% (non condensing) at 40 ˚C (104
˚F).
Mechanical-
Mounting:������������������DIN Rail Mount
Case Dimensions:����22�5mm x 102�4mm x 128�7mm
0�89" (W)x 4�03" (H) x 5�07" (D)
Plus 11�8 mm (0�47”) for Right-angled
connectors�
Weight:�����������������������6�4 oz�, 8�0 oz when packed
0�16 kg�, 0�22 kg when packed
• The TL-QUAD-LOOP is a universal process input, 4-channel
4-20mA output retransmitter� Selectable inputs include
4-20mA, 0-5V, 1-5V and 0-10V, and isolated 24VDC
excitation is conveniently supplied at the input� Each output
channel includes a 10ohm test resistance and adjustment
potentiometers for zero (typically 4mA) and span (20mA)
calibration� In addition, each output has a signal amplitude
LED indicator (dim at 4mA, bright at 20mA)�
• The TL-DUAL-LOOP is a universal process input, 2-channel
4-20mA output retransmitter� Selectable inputs include
4-20mA, 0-5V, 1-5V and 0-10V, and isolated 24VDC
excitation is conveniently supplied at the input� Each output
channel includes a 10ohm test resistance and adjustment
potentiometers for zero (typically 4mA) and span (20mA)
calibration� In addition, each output has a signal amplitude
LED indicator (dim at 4mA, bright at 20mA)�
• PWR LED showing unit is powered up.
• “Z” (ZERO) and “S” (SPAN) potentiometers for each
channel�
• Output LED showing relative signal strength for each
channel (marked L1 for Channel 1, L2 for Channel 2, etc�)�
• Input range selection jumpers (voltage or current; voltage
range) (NOTE: the jumpers are located inside of the case)
Product Description Specifications
User Interface
LEOPARD FAMILY
TL-QUAD-LOOP TL-DUAL-LOOP
Universal Analog to Dual or Quad 4-20mA
Transmitter / Retransmitter
Designed and
Manufactured
by

Texmate, Inc. www.texmate.comPage 2 TL-QUAD-LOOP & TL-DUAL-LOOP Transmitter Manual (d0108)
Pinout Diagram
The TL Series Transmitter uses plug-in type screw terminal con-
nectors for all input and output connections. The power supply
connections have a unique plug and socket outline to prevent cross
connection�
!
WARNING: AC and DC input signals and power supply
voltages can be hazardous. Do Not connect live wires to
screw terminal plugs, and do not insert, remove or handle
screw terminal plugs with live wires connected.
Connector PinoutsConnector Pinouts
Connector PinoutsInput Select
Installation Guidelines
Installation
1� Install and wire transmitter per local applicable codes
regulations, the particular application, and good instal-
lation practices�
2� Install transmitter in a location that does not exceed the
maximum operating temperature and that provides good air
circulation�
3� Separate input/output leads from power lines to protect
the transmitter from external noise� Input/output leads
should be routed as far away as possible from contactors,
control relays, transformers and other noisy components�
Shielding cables for input/output leads is recommended
with shield connection to earth ground near the meter pre-
ferred�
!
4� A circuit breaker or disconnect switch is required to dis-
connect power to the meter. The breaker/switch should be
in close proximity to the meter and marked as the discon-
necting device for the meter or meter circuit. The circuit
breaker or wall switch must be rated for the applied voltage
(e�g�, 120VAC or 240VAC) and current appropriate for the
electrical application (e�g�, 15A or 20A)�
5� See Connector Pinouts section for wiring�
6� Use 28-12 AWG wiring, minimum 90˚C (HH) temperature
rating� Strip wire approximately 0�3 in� (7-8 mm)�
7� Re c ommended torque on all terminal plug screws is 4�5
lb-in (0�51 N-m)�
POWERINPUT
Neutral
(–)
Line
(+)
!
4-20mA
0-5V
1-5V
0-10V
Test
+
–
Test
+
–
Test
+
–
Test
+
–
Zero
Span
CH1 out CH2 out CH3 out CH4 out
CH1
Zero
Span
CH2
Zero
Span
CH3
Zero
Span
CH4
Signal +
24V Exc.
Signal Grd
85 to 265 VAC 2W nom.
50-400 Hz
95 to 300 VDC 2W nom.
15 to 48 VAC 2W nom.
50-400 Hz
10 to 72 VDC 2W nom.
Input range is normally set by the factor per your
order, but you may change that by following these
directions.
1� WARNING: Disconnect the power from the meter
and disconnect any equipment attached to the outputs before
attempting this procedure� Dangerous voltages may be present�
2� Remove the four screws from the top panel (label side), nuts
are in the bottom panel. Open the case.
3. To select 4-20mA input, move the Voltage/Current jumper to
CURRENT, move the range selection jumper to 4-20mA.
4. To select a voltage input, move the Voltage/Current jumper to
VOLTAGE, move the range selection jumper to the desired volt-
age range (0-5V, 1-5V, 0-10V)�
5� Reassemble the case�
6� It is best to place a small label at the input connector indicating
the required input signal�
NOTE: Input signal calibration is not required in the
TL-DUAL-LOOP and TL-QUAD-LOOP meters.
!

Page 3
Texmate, Inc. www.texmate.com
TL-QUAD-LOOP & TL-DUAL-LOOP Transmitter Manual (d0108)
Case Dimensions
22.5mm
(0.89”) 128.7mm
(5”)
102.4mm
(4”)
99.7mm
(3.9”)
SIDE
22.5 mm
(0.89”) TOP
WARRANTY
Texmate warrants that its products are free from defects in material and workmanship under
normal use and service for a period of one year from date of shipment. Texmate’s obligations
under this warranty are limited to replacement or repair, at its option, at its factory, of any of
the products which shall, within the applicable period after shipment, be returned to Texmate’s
facility, transportation charges pre-paid, and which are, after examination, disclosed to the sat-
isfaction of Texmate to be thus defective. The warranty shall not apply to any equipment which
shall have been repaired or altered, except by Texmate, or which shall have been subjected
to misuse, negligence, or accident. In no case shall Texmate’s liability exceed the original pur-
chase price. The aforementioned provisions do not extend the original warranty period of any
product which has been either repaired or replaced by Texmate.
USER’S RESPONSIBILITY
We are pleased to offer suggestions on the use of our various products either by way of printed
matter or through direct contact with our sales/application engineering staff� However, since
we have no control over the use of our products once they are shipped, NO WARRANTY
WHETHER OF MERCHANTABILITY, FITNESS FOR PURPOSE, OR OTHERWISE is made
beyond the repair, replacement, or refund of purchase price at the sole discretion of Texmate.
Users shall determine the suitability of the product for the intended application before using,
and the users assume all risk and liability whatsoever in connection therewith, regardless
of any of our suggestions or statements as to application or construction� In no event shall
Texmate’s liability, in law or otherwise, be in excess of the purchase price of the product.
Texmate cannot assume responsibility for any circuitry described. No circuit patent or software
licenses are implied. Texmate reserves the right to change circuitry, operating software, speci-
fications, and prices without notice at any time�
Output Signal Calibration
Copyright © 202-2021 Texmate Inc. All Right Reserved.
1934 Kellogg Ave� Carlsbad, CA 92008
Tel: [phone] • USA 1-800-839-6283 • That’s 1-800-TEXMATE
• Email: [email protected] • [email protected]
• Web: www.texmate.com
TL-dual-LOOP and TL-QUAD-LOOP Technical Manual Copyright © 2020-
2021 Texmate Inc. All rights reserved. Published by: Texmate Inc. USA.
Inormation in this Technical Manual is subject to change without notice due
to correction or enhancement. The information described in this manual is
proprietary to Texmate, Inc. and may not be copied, reproduced or transmit-
ted, in whole or in part, in connection with the design, manufacture, or sale
of apparatus, device or private label product without the express written
consent of Texmate, Inc.
Each output channel is normally calibrated by the factory.
You may recalibrate the output channels by following these direc-
tions. Each output channel is calibrated using the “Z” (ZERO)
and “S” (SPAN) potentiometers located on the front panel, L1 for
Channel 1, L2 for Channel 2, etc�
1� A calibrated input signal source is strongly recommended�
2� A calibrated 4-20mA measurement meter is strongly recom-
mended for the output�
3� Make sure the input signal type (current or voltage) and
range are correctly set. See INPUT SELECT above.
4� Make sure power is applied to the meter and the PWR LED
is lit�
5. The calibration process takes several iterations, so it is not
necessary to get to 4�00mA or 20�00mA on the first pass�
Rather, set the output progressively more accurately with
each iteration�
6� Apply the low value of the input signal range to the input
connector�
7. Adjust the ZERO potentiometer until a reading of 4.0mA is
observed at the output�
8� Set the input to the high value of the input signal range�
9. Adjust the “S” (SPAN) potentiometer until a reading 20.0mA is
observed at the output�
10� Repeat steps 6 through 9, targeting 4�00mA and 20�00mA,
until stable outputs are achieved. This typically takes 3-4 iter-
ations�
NOTE: Normally, the output is 4-20mA, but the
TL-LOOP-QUAD output can be adjusted to 0mA on the
low end of the range�
NOTE: The 4-20mA output is easily converted into a
voltage by adding a suitable resistor across the output
pins, e�g�, a 0�5% 1/4W 250 ohm metal film resistor,
although accuracy of the resulting voltage will be affect-
ed by the precision and tolerance of the resistor�
