INSTRUCTION MANUAL
Read and understand all of the instructions and
safety information in this manual before operating
or servicing this tool.
Register this product at www.greenlee.com
52059181 REV 6 © 2011 Greenlee Textron Inc. 7/11
GATOR®GRIP
Crimp-on Cable Pulling Grips
4455 Boeing Drive • Rockford, IL 61109-2988 • USA • 815-397-7070
An ISO 9001 Company • Greenlee Textron Inc. is a subsidiary of Textron Inc.
USA
Tel: [phone]
Fax: [phone]
Canada
Tel: [phone]
Fax: [phone]
International
Tel: [phone]
Fax: [phone]
www.greenlee.com
Operation
Where to strip wire jacket and where to crimp:
Crimp #1 Crimp #2 Strip
Strip Length
Step 1. Line up the wire to be crimped
with the strip line and the open end of
the wire grip. This is the length of the
wire jacket you want to remove.
Step 2. Insert the stripped wire into the
grip up to the strip line.
Step 3. Crimp on the rst crimp line
using a Greenlee EK12IDL or HK12ID
dieless crimping tool.
Step 4. Rotate the crimping tool 180° to
the other side of the wire grip and crimp
on the second crimp line.
Step 5. Attach the eye on the grip
harness to a pulling swivel or rope clevis.
Note: There may be some cracking of the grip
when it is crimped. This is a normal, inherent
property of the material when crimped and
will not affect the strength of the pull.

Description
Greenlee’s Crimp-on Cable Pulling Grips
are intended to pull wire sizes 1 AWG
through 1000 kcmil through conduit.
These grips are designed to be used
only with the following Greenlee 12-ton
dieless crimping tools:
• EK12IDL
• HK12ID
Refer to the instruction manuals for these
crimping tools for safety instructions and
proper use.
Safety
Safety is essential in the use and mainte-
nance of Greenlee tools and equipment.
This instruction manual and any mark-
ings on the tool provide information for
avoiding hazards and unsafe practices
related to the use of this tool. Observe all
of the safety information provided.
Purpose of this Manual
This manual is intended to familiarize
all personnel with the safe operation
and maintenance procedures for the
Greenlee Crimp-on Cable Pulling Grips.
Keep this manual available to all
personnel.
Replacement manuals are available
upon request at no charge at
www.greenlee.com.
All specications are nominal and may
change as design improvements occur.
Greenlee Textron Inc. shall not be liable for
damages resulting from misapplication or
misuse of its products.
GATOR is a registered trademark of
GreenleeTextron Inc.
Specifications
The grips are available in ve different lengths. Each size grip is engineered to pull
specic sizes of wire.
Refer to the table below for size ranges for each grip, load ratings, and the minimum
conduit sizes recommended for use with each grip.
KEEP THIS MANUAL
Grip
Cat. No.
Grip Wire
Range
Wire
Size
REGULAR AND COMPACT STRANDED COPPER CABLE REGULAR AND COMPACT STRANDED ALUMINUM CABLE Minimum
Conduit Size
(in)
Rated Pulling
Load Per Cable
(lb)
Rated Pulling
Load for 3Cables
(lb)
Rated Pulling
Load for 4Cables
(lb)
Rated Pulling
Load for 5Cables
(lb)
Rated Pulling
Load Per Cable
(lb)
Rated Pulling
Load for 3Cables
(lb)
Rated Pulling
Load for 4Cables
(lb)
Rated Pulling
Load for 5Cables
(lb)
GG1-1/0 1 to 1/0 1 1200 3600 4800 6000 500 1500 2000 2500 1-1/4
1/0 2000 6000 8000 10000 650 1950 2600 3250 1-1/4
GG2/0-4/0 2/0 to 4/0
2/0 2000 6000 8000 10000 800 2400 3200 4000 1-1/2
3/0 2000 6000 8000 10000 900 2700 3600 4500 2
4/0 2000 6000 8000 10000 1000 3000 4000 5000 2
GG250-350 250 to 350
250 1600 4800 6400 8000 1600 4800 6400 8000 2
300 2000 6000 8000 10000 1700 5100 6800 8500 2-1/2
350 2500 7500 10000 12500 2200 6600 8800 11000 2-1/2
GG400-500 400 to 500 400 2500 7500 10000 12500 1900 5700 7600 9500 2-1/2
500 2500 7500 10000 12500 2500 7500 10000 12500 3
GG600-750 600 to 750 600 1800 5400 7200 9000 1500 4500 6000 7500 3
750 3000 9000 12000 15000 2300 6900 9200 11500 3-1/2
GG1000 1000 1000 3000 9000 12000 15000 3500 10500 14000 17500 3-1/2
Read and understand all
of the instructions and
safety information in this
manual before operating
or servicing this tool.
Also read the instruc-
tion manuals and safety
information for the puller
and crimping tool being
used.
Failure to observe this
warning could result in
severe injury or death.
Wear eye protection
when operating this tool.
Failure to wear eye
protection could result in
serious eye injury from
ying debris.
Each grip is engineered to pull spe-
cic sized wires. Read this instruc-
tion manual or refer to the markings
on the grip for specic wire to be
used with your grip.
Failure to observe this precau-
tion may result in injury or property
damage.
Important Safety Information
Note: Greenlee GATOR®Grip pulling grips are intended for use with compact, compressed, and
regular stranded copper conductors with Class “B” and Class “C” stranding as defined by ASTM
specification B8, and for use with compact, compressed, and regular stranded aluminum conductors
with Class “B” and Class “C” stranding as defined by ASTM specification B231. This includes most
type THHN/THWN, XHHW, and RHH/RHW building wire.
Not for use with fine-stranded wire.
