Textron JACOBSEN 73-70680 TERRA RAKE RK260 Setup guide

WARNING: If incorrectly used this machine can cause severe injury. Those who use
and maintain this machine should be trained in its proper use, warned of its dangers
and should read the entire manual before attempting to set up, operate, adjust or
service the machine.
OWNER/OPERATOR’S MANUAL
& ILLUSTRATED PARTS LIST
09-284 REV A
MODEL:
73-70680 TERRA RAKE RK260

CALIFORNIA
Proposition 65 Warning
Diesel engine exhaust and some of
its constituents are known to the State
of California to cause cancer, birth
defects and other reproductive harm.
Californie Proposition 65
Avertissement
Les échappements des moteurs diesel
et certains de leurs composés sont
reconnus par l’Etat de Californie pour
être cancérigènes, provoquer des
défauts congénitaux et d’autres dangers
en matière de reproduction.
ADVERTENCIA
AVERTISSEMENT
WARNING
The engine exhaust from this product
contains chemicals known to the State
of California to cause cancer, birth
defects or other reproductive harm.
California Advertencia
de la Proposicion 65
El estado de California hace saber que
los gases de escape de los motores
diesel y algunos de sus componentes
producen cáncer, defectos de
nacimiento y otros daños en el
proceso de reproducción humana.
L’ é mission du moteur de ce mat é riel
contient des produits chimiques que
l’Etat de Californie consid è re ê tre
canc é rig è nes, provoquer des d é fauts
cong é nitaux et d’autres dangers en
mati è re de reproduction.
El estado de California hace saber
que los gases de escape de este
producto contienen productos
quÍmicos que producen cáncer,
defectos de nacimiento y otros daños
en el proceso de reproducción
humana.
© 2003, TEXTRON INC

1
TERRA
RAKE
IMPORTANTMESSAGE
Thank you for purchasing this Jacobsen product. You have purchased a world class product, one of the best
designed and built anywhere.
This product comes with an Owner/Operator's Manual. The useful life and good service you receive from this
product depends to a large extent on how well you read and understand this manual. Treat this product properly
and adjust it as instructed, and it will give you many years of reliable service.
See a Jacobsen dealer for any service or parts needed. Jacobsen service ensures that you continue to receive
the best results possible from Jacobsen products. You can trust Jacobsen replacement parts because they are
manufactured with the same high precision and quality as the original parts.
Jacobsen designs and builds its equipment to serve many years in a safe and productive manner. For longest
life, use this product only as directed in the manual, keep it in good repair and follow safety warnings and
instructions. You'll always be glad you did.
Jacobsen, a Textron Company
One Bob Cat Lane
Johnson Creek, WI 53038-0469
6-2004
TABLE OF CONTENTS FIGURES PAGE
INTRODUCTION / SPECIFICATIONS........................................................................................................... 2
SAFETY ..................................................................................................................................................... 3, 4
ASSEMBLY INSTRUCTIONS ........................................................................................................................ 5
INSTALLATION / FEATURES ........................................................................................................................ 6
OPERATION .................................................................................................................................................. 7
SERVICE ....................................................................................................................................................... 8
PARTS SECTION .......................................................................................................................................... 9
HITCH PARTS ................................................... FIGURE 1 ..................................................................10, 11
RAKE PARTS..................................................... FIGURE 2 ................................................................. 12, 13
CASTER WHEELS ............................................ FIGURE 3 ................................................................. 14, 15

2
TERRA
RAKE
INTRODUCTION / SPECIFICATIONS
SPECIFICATIONS
Overall Length with wheels front ................................................. 67"
Overall Length with wheels rear .................................................. 49"
Overall Width ............................................................................... 67"
Maximum Working Width ............................................................ 66"
Minimum Working Width (angled)............................................... 61"
Working Positions........................................................................ Hydraulically controlled
Self-leveling Device ..................................................................... Spring-loaded
Number of Teeth.......................................................................... 38
Size of Teeth................................................................................ 5/16 X 1 X 27
Space between Teeth.................................................................. 3/4"
Caster Gauge Wheel Height Adjustment .................................... 2" in 1/2" increments
Tire Size....................................................................................... 13 X 5.00 - 6
Ground Clearance ....................................................................... 5" on Model 420 / 430
Weight.......................................................................................... 270 lbs.
DESCRIPTION
The RK260 Terra Rake attaches to the Steiner power units’ front quick hitch in a minute or less. Power
angle and adjustable casters allow fine tuning for spreading topsoil, crushed stone, gravel or cinders.
Landscape operations include:
•Removing stones, roots and debris prior to seeding.
•Grading and leveling athletic fields, beaches, parking lots, drives and trails.
•Grooming cinder tracks, bridle paths, parks and playgrounds.

3
TERRA
RAKE SAFETY
NOTICE !!!
Unauthorized modifications may present extreme
safety hazards to operators and bystanders and
could also result in product damage.
Jacobsen, a Textron Company strongly warns
against, rejects and disclaims any modifications,
add-on accessories or product alterations that are
not designed, developed, tested and approved by
Jacobsen Engineering Department. Any Jacobsen
product that is altered, modified or changed in any
manner not specifically authorized after original
manufacture–includingtheadditionof“after-market”
accessories or component parts not specifically
approved by Jacobsen–will result in the Jacobsen
Warranty being voided.
Anyandallliabilityforpersonalinjuryand/orproperty
damagecausedbyanyunauthorizedmodifications,
add-on accessories or products not approved by
Jacobsen will be considered the responsibility of
the individual(s) or company designing and/or
making such changes. Jacobsen will vigorously
pursuefull indemnificationand costsfrom any party
responsibleforsuchunauthorizedpost-manufacture
modifications and/or accessories should personal
injury and/or property damage result.
This symbol means:
ATTENTION!
BECOME ALERT!
Your safety and the safety of others is involved.
Signal word definitions:
The signal words below are used to identify levels
of hazard seriousness. These words appear in this
manual and on the safety labels attached to
Jacobsenmachines.Foryour safetyand thesafety
ofothers,readandfollowtheinformationgivenwith
thesesignalwordsand/orthesymbolshownabove.
DANGER indicates an imminently hazardous
situationwhich, ifnot avoided,WILL result indeath
or serious injury.
WARNING indicates a potentially hazardous
situation which, if not avoided, COULD result in
death or serious injury.
CAUTION indicates a potentially hazardous
situation which, if not avoided, MAY result in minor
or moderate injury. It may also be used to alert
against unsafe practices or property damage.
CAUTION used without the safety alert symbol
indicates a potentially hazardous situation which, if
not avoided, MAY result in property damage
MODEL NUMBER: This number appears on
sales literature, technical manuals and price
lists.
SERIAL NUMBER: This number appears only
on your mower. It contains the model number
followed consecutively by the serial number.
Use this number when ordering parts or seeking
warranty information.

4
TERRA
RAKE
1. Read and understand the Owner’s Manual before attempting to operate this machine.
2. Operate all controls from the operator’s seat. NO RIDERS.
3. Keep all shields in place and safety switches adjusted properly.
4. Do not leave equipment unattended. STOP the engine and remove the key.
5. Do not allow minors or the inexperienced to operate this machine.
6. Keep people and pets a safe distance away from machine using power driven attachments. Injury
could result from flying debris.
GENERALSAFETY
OPERATINGSAFETY
1. DO NOT attempt to work on power unit or any
attachments with the engine running. STOP
ENGINE!
3. Before leaving the tractor seat:
•Lower Rake.
• Set PARKING brake.
• Stop engine.
SAFETY

5
TERRA
RAKE ASSEMBLY INSTRUCTIONS
ASSEMBLY
1. Remove rake and attaching parts from shipping crate.
2. See Page 12 and 14, Figures 1 & 2 for parts identification and location. Attach the hitch to the rake
frame with 1 X 3-1/2 bolt and nylon locknut as shown on Page 8, Photo 5.
3. Attach the top link to the rake frame with a 5/8 X 6 bolt, long spacer, lockwasher and nut.
4. Attach the rod end of the cylinder to the rake frame with a 5/8 X 2-1/2 bolt, lockwasher and nut.
5. Attach the rake to the tractor.
6. Leveling adjustment:
A. Place tractor with rake installed on a level floor.
B. Place the rake in straight position.
C. With caster wheels in the rear position, add or remove spacers until the rake and wheels will
contact the floor. Typical setting is one spacer at the bottom and the remaining 3 spacers at
the top.
D. Angle rake to the extreme right position. Adjust top link to obtain equal rake surface contact in
this position. Angle to the extreme left postion and check again. The ideal setting is to have
the rake touch the floor equally in all postions. This is the setting you would likely use for
spreading topsoil or gravel.
E. For more or less working depth, minor adjustment of the top link may be needed.
7. Check and tighten all bolts. Grease the center pivot ball and caster wheels.

6
TERRA
RAKE
INSTALLATION / FEATURES
INSTALLATION
1. Attach Terra Rake to the “quick hitch” front lift in the usual manner.
2. Connect the hoses to the auxiliary quick couplers.
NOTE: To reverse the auxiliary hydraulic lever action, switch the hoses at the quick couplers.
FEATURES
1. Self leveling ...........independent of tractor.
2. Front mounted .......excellent visibility.
3. Gauge wheels .......front or rear position.
4. Power angle ..........straight or angle right and left.
5. Top link..................provide fine depth adjustment.
Spring loaded (factory set) for self leveling... independent of tractor angle.

7
TERRA
RAKE OPERATION
1. The power angle allows the operator many choices of rake position. The rake may be power angled
straight ahead, to the right or left , or any position in between.
2. Gauge wheels are adjustable by moving 1/2" spacers to obtain correct working depth for various
surface conditions. The wheels may be mounted to the front or to the rear as the task requires.
3. After making the initial setting for the working depth by moving the spacers, fine tune the setting by
adjusting the top link. This is important when using the rake to spread topsoil and/or gravel.
4. Operate only with front lift in the “FLOAT” position. Do not use down pressure.
5. Always rake in forward direction. Raise the rake when backing.
6. Use the Model BD260 power angle blade where large amounts of material need to be leveled.
Remove large rocks before raking. Do not use this Terra Rake as a bulldozer. It is designed for light
duty soil finishing and conditioning.
CAUTIO
N
Operate only with front lift in the “FLOAT” position.
Always rake in forward direction.
Lift rake before backing.
Serious damage (breaking or bending) of the tines may occur.

8
TERRA
RAKE
SERVICE
1. Check tines periodically for bent or misaligned tines. Straighten or replace if necessary.
2. Check tire pressures every 100 hours. Adjust to 16 lbs. maximum.
3. Grease pivot ball every 100 hours.
4. Keep it clean!
Top Link...provides fine tuning for depth adjustment

9
TERRA
RAKE PARTS SECTION
PARTS SECTION

10
TERRA
RAKE
HITCH PARTS
FIGURE 1

11
TERRA
RAKE
ITEM PART NO. DESCRIPTION QTY ITEM PART NO. DESCRIPTION QTY
HITCH PARTS
FIGURE 1
1-1 47-009 TOP LINK 1
1-2 29-010 S/B GREASE FITTING 1
1-3 64-759.7 CHANNEL-SPRING TENSION2
1-4 41-034 SPRING,COMP 0.968 X 2.0 4
1-5 64163-67 WASHER-.516X1X12GA 4
1-6 90-0848 BOLT,1/2-13 X 6 2
1-7 90-1020 BOLT,5/8-11 X 2-1/2 3
1-8 64006-04 LOCKWSHR-HELICAL 5/8 3
1-9 64025-21 NUT-HEX 5/8-11 3
1-10 23-053 STEERING CYLINDER 1
1-11 25-2103-4-6 90-M/M 9/16 JIC x 1/8 2
1-12 20-047 HOSE, 1/4 X 58 1
1-13 25-0103-4-6 FTG-9/16 JIC x 1/4 2
1-14 23-004 MALE QUICK COUPLER 2
1-15 20-021 HOSE-1/4 X 52 1
1-16 64-762.7 FRAME, RAKE HITCH 1
1-17 64123-80 BLT-HEX 1/4-20X1-1/4 1
1-18 64-635.7 CLAMP, HOSE RETAINER 1
1-19 64229-01 LOCKNUT-NYLON 1/4-20 1
1-20 64229-05 LOCKNUT, 1/2-13 NYLON 2
* 4128372 LABEL-STEINER 1
* 4124072 LABEL-JACOBSEN 1
* NOT ILLUSTRATED

12
TERRA
RAKE
RAKE PARTS
FIGURE 2

13
TERRA
RAKE
ITEM PART NO. DESCRIPTION QTY ITEM PART NO. DESCRIPTION QTY
RAKE PARTS
FIGURE 2
2-1 62-772.7 MOUNT-RAKE TINES RK260 1
2-2 62-773.7 HOLDER-RAKE TINES RK260 1
2-3 64123-75 BOLT-3/8-16X3 HEX 6
2-4 64139-24 BOLT-3/8-16X1 36
2-5 64141-4 NUT-WLF 3/8-16 47
2-6 79-072 TINE, TERRA-RAKE 5/16 x 1 38
2-7 64025-21 NUT-HEX 5/8-11 2
2-8 64006-04 LOCKWSHR-HELICAL 5/8 2
2-9 90-1020 BOLT-5/8-11 X 2-1/2 1
2-10 91-1628 BOLT-1 X 3-1/2 1
2-11 99-E04 LOCKNUT 1
2-12 64-758 SPACER, SPRING TENSION 1
2-13 90-1048 BOLT-5/8-11 X 6 1
2-14 64-761.7 FRAME, RAKE TINE MOUNT 1
2-15 64123-88 BOLT-3/8-16X2-3/4 3
2-16 64139-18 BOLT-3/8-16 X 1-1/4 2
* 00-158 DECAL-TERRA-RAKE MODEL 1
* NOT ILLUSTRATED

14
TERRA
RAKE
CASTER WHEELS
FIGURE 3

15
TERRA
RAKE
ITEM PART NO. DESCRIPTION QTY ITEM PART NO. DESCRIPTION QTY
CASTER WHEELS
FIGURE 3
3-1 03-017 CLIP, 5/16" 2
3-2 64163-22 SPACER-CSTR HEIGHT ADJ 8
3-3 85-B34 BUSHING, FLANGED 4
3-4 29-010 S/B GREASE FITTING 2
3-5 62-771.7 FRAME, CASTER SWIVEL 2
3-6 50-082.7 FRAME-CASTER YOKE 2
3-7 64139-21 BLT-WLF 3/8-16X3/4 4
3-8 64163-06 WASHER-3/4 ID 18 4
3-9 53-093 WHEEL,W/13X500X6 2
3-10 50-063 AXLE, CASTER WHEEL 2
3-11 64123-75 BOLT, 3/8-16X3 HEX 6
3-12 64141-4 NUT-WLF 3/8-16 6
3-13 64-760.7 FRAME, WHEEL SUPPORT 2
3-14 03-0820 CLEVIS PIN, 1/2 X 2-1/2 2
3-15 02-PP0313 PIN, 3/16 x 1.5/8 2

BOB-CAT BROUWER BUNTON CUSHMAN RYAN STEINER
Equipment from Jacobsen, a Textron company,
is built to exacting standards ensured by
ISO 9001 and ISO 14001 registration at all our
manufacturing locations.
A worldwide dealer network and factory-trained
technicians backed by Textron Parts Xpress
provide reliable, high-quality product support.
