Textron Jacobsen LS340 Setup guide

WARNING: If incorrectly used this machine can cause severe injury. Those who use
and maintain this machine should be trained in its proper use, warned of its dangers
and should read the entire manual before attempting to set up, operate, adjust or
service the machine.
OWNER/OPERATOR’S MANUAL
& ILLUSTRATED PARTS LIST
09-164 REV B
MODEL:
73-70632 LAWN SWEEPER LS340

CALIFORNIA
Proposition 65 Warning
Diesel engine exhaust and some of
its constituents are known to the State
of California to cause cancer, birth
defects and other reproductive harm.
Californie Proposition 65
Avertissement
Les échappements des moteurs diesel
et certains de leurs composés sont
reconnus par l’Etat de Californie pour
être cancérigènes, provoquer des
défauts congénitaux et d’autres dangers
en matière de reproduction.
ADVERTENCIA
AVERTISSEMENT
WARNING
The engine exhaust from this product
contains chemicals known to the State
of California to cause cancer, birth
defects or other reproductive harm.
California Advertencia
de la Proposicion 65
El estado de California hace saber que
los gases de escape de los motores
diesel y algunos de sus componentes
producen cáncer, defectos de
nacimiento y otros daños en el
proceso de reproducción humana.
L’ é mission du moteur de ce mat é riel
contient des produits chimiques que
l’Etat de Californie consid è re ê tre
canc é rig è nes, provoquer des d é fauts
cong é nitaux et d’autres dangers en
mati è re de reproduction.
El estado de California hace saber
que los gases de escape de este
producto contienen productos
quÍmicos que producen cáncer,
defectos de nacimiento y otros daños
en el proceso de reproducción
humana.
© 2003, TEXTRON INC

1
LAWN
SWEEPER
IMPORTANT MESSAGE
Thank you for purchasing this Jacobsen product. You have purchased a world class product, one of the best
designed and built anywhere.
This product comes with an Owner/Operator's Manual. The useful life and good service you receive from this
product depends to a large extent on how well you read and understand this manual. Treat this product properly
and adjust it as instructed, and it will give you many years of reliable service.
See a Jacobsen dealer for any service or parts needed. Jacobsen service ensures that you continue to receive
the best results possible from Jacobsen products. You can trust Jacobsen replacement parts because they are
manufactured with the same high precision and quality as the original parts.
Jacobsen designs and builds its equipment to serve many years in a safe and productive manner. For longest
life, use this product only as directed in the manual, keep it in good repair and follow safety warnings and
instructions. You'll always be glad you did.
Jacobsen, a Textron Company
One Bob Cat Lane
Johnson Creek, WI 53038-0469
2-2005
TABLE OF CONTENTS FIGURES PAGE
INTRODUCTION / SPECIFICATIONS ........................................................................................................... 2
SAFETY ..................................................................................................................................................... 3, 4
OPERATION / SERVICE ................................................................................................................................ 5
MAIN PARTS...................................................... FIGURE 1 ..................................................................... 6, 7
BRUSH PARTS .................................................. FIGURE 2 ..................................................................... 8, 9

2
LAWN
SWEEPER
INTRODUCTION / SPECIFICATIONS
SPECIFICATIONS
Overall Width ............................................................................... 62"
Overall Height .............................................................................. 52"
Overall Length to Hitch ................................................................ 66"
Width of Pick Up .......................................................................... 40"
Brush............................................................................................ 3 paddle, staggered
Depth Wheels .............................................................................. Semi-pneumatic
Hitch ............................................................................................. Right, left or center pull adjustment
Carrying Capacity ........................................................................ 24 cu. ft.
Weight .......................................................................................... 530 lbs.
DESCRIPTION
The Lawn Sweeper is designed to give a “clean sweep” in your lawn sweeping operations. The unit is
ground-driven so it can be pulled by any lawn and garden tractor. It can be used to trail behind with offset
hitch while mowing, or regular hitch to clean-up after you’ve finished mowing. The packing action allows
you to put much more material into the unit before it is necessary to unload.
There is a transport position for the sweeper and clutch levers on each wheel to disengage the wheel
clutches.

3
LAWN
SWEEPER
SAFETY
NOTICE !!!
Unauthorized modifications may present extreme
safety hazards to operators and bystanders and
could also result in product damage.
Jacobsen, a Textron Company strongly warns
against, rejects and disclaims any modifications,
add-on accessories or product alterations that are
not designed, developed, tested and approved by
Jacobsen Engineering Department. Any Jacobsen
product that is altered, modified or changed in any
manner not specifically authorized after original
manufacture–including the addition of “after-market”
accessories or component parts not specifically
approved by Jacobsen–will result in the Jacobsen
Warranty being voided.
Any and all liability for personal injury and/or property
damage caused by any unauthorized modifications,
add-on accessories or products not approved by
Jacobsen will be considered the responsibility of
the individual(s) or company designing and/or
making such changes. Jacobsen will vigorously
pursue full indemnification and costs from any party
responsible for such unauthorized post-manufacture
modifications and/or accessories should personal
injury and/or property damage result.
This symbol means:
ATTENTION!
BECOME ALERT!
Your safety and the safety of others is involved.
Signal word definitions:
The signal words below are used to identify levels
of hazard seriousness. These words appear in this
manual and on the safety labels attached to
Jacobsen machines. For your safety and the safety
of others, read and follow the information given with
these signal words and/or the symbol shown above.
DANGER indicates an imminently hazardous
situation which, if not avoided, WILL result in death
or serious injury.
WARNING indicates a potentially hazardous
situation which, if not avoided, COULD result in
death or serious injury.
CAUTION indicates a potentially hazardous
situation which, if not avoided, MAY result in minor
or moderate injury. It may also be used to alert
against unsafe practices or property damage.
CAUTION used without the safety alert symbol
indicates a potentially hazardous situation which, if
not avoided, MAY result in property damage
MODEL NUMBER: This number appears on
sales literature, technical manuals and price
lists.
SERIAL NUMBER: This number appears only
on your mower. It contains the model number
followed consecutively by the serial number.
Use this number when ordering parts or seeking
warranty information.

4
LAWN
SWEEPER
SAFETY
GENERAL SAFETY
• Read and understand the owner’s manual,
before attempting to operate this machine.
• Operate all controls from the operator’s
seat, (if so equipped). NO RIDERS.
• Keep all shields in place and safety
switches adjusted properly.
• Do not leave equipment unattended. STOP
the engine and remove the key (if so
equipped).
• Do not allow minors or the inexperienced to
operate this machine.
• Never allow anyone to operate or service
this machine while under the influence of
alcohol or drugs.
• Keep people and pets a safe distance away
from machines using power driven
attachments. Injury could result from flying
debris.
• Wear all the necessary protective clothing
and personal safety devices to protect your
head, eyes, ears, hands, and feet.
• Operate the machine only in daylight or in
good artificial light.
OPERATING SAFETY
1. Remove large objects or debris from the path of
the lawn sweeper.
2. Before leaving the tractor seat to clear
blockage, service or make adjustments:
1. Set PARKING brake.
2. Stop Engine.
3. Disengage clutches and raise broom to
transport position before transporting at high
speed.

5
LAWN
SWEEPER
OPERATION / SERVICE
OPERATING INSTRUCTIONS
1. Determine hitch position for offset or straight pull position.
2. Transport to clean-up site with the clutches disengaged and sweeper in transport position.
3. Lower the sweeper housing and adjust sweeper height on right side of sweeper housing by choosing
the pin location to regulate gauge wheel height.
NOTE: Operation is best when the sweeper is approximately 1/2" below the tips of the grass, but does
not “scrub” the lawn.
4. Adjust the float springs allowing the sweeper to “float” over rough areas or high spots in the lawn.
5. Engage clutches on both wheels by rotating the lever approximately 180 degrees.
6. When sweeping leaves - the best results are obtained by sweeping several times during the leaf fall
rather than waiting until there is a large accumulation. A large accumulation will require several passes
to make a clean sweep. MAXIMUM SPEED IS 10 M.P.H.
7. Open rear door to unload.
8. To transport: Always disengage wheel clutches and raise sweeper housing. DO NOT TRAVEL AT
HIGH SPEEDS WITH CLUTCHES ENGAGED! MAXIMUM SPEED IS 10 M.P.H.
NOTE: To disengage both wheels rotate each lever approximately 180 deg. You can feel a high spot
when it is disengaged.
Do not travel at high speeds with clutches
engaged. MAXIMUM SPEED IS 10 M.P.H.
Disengage clutches for transport. MAXIMUM
SPEED IS 10 M.P.H.
MAINTENANCE
Daily
Visually check chain drive - it should not run “dry”.
Lube with chain lube or 30W oil
Weekly or 50 Hours
Grease all bearings and wheels.
Check tire pressure (12 lbs.)

6
LAWN
SWEEPER
MAIN PARTS
FIGURE 1
36

7
LAWN
SWEEPER
ITEM PART NO. DESCRIPTION QTY ITEM PART NO. DESCRIPTION QTY
MAIN PARTS
FIGURE 1
1-1 62-602.7 MAIN FRAME, LS340 1
1-2 60-187.7 DOOR 1
1-3 42-205.7 HINGE ROD 1
1-4 64140-1 COTTER PIN-1/8X1 2
1-5 41-010 SPRING 2
1-6 40-114.7 LATCH-RIGHT 1
40-115.7 LATCH-LEFT 1
1-7 83-407016 SPROCKET 1
1-8 41-013 SPRING 2
1-9 86-020.7 CLUTCH PAWL-RIGHT 1
86-021.7 CLUTCH PAWL-LEFT 1
1-10 64164-10 1/4X1/4X1-1/4 MACH KEY 3
1-11 86-043.7 CLUTCH 2
1-12 50-030 WHL & TIRE ASSY 2
53-089 TIRE-16X7.50X8 1
50-101 RIM 1
55-IB-1 BEARING 1
* 29-053 GREASE FITTING, 1/4-28 2
1-13 64163-84 WASHER-1.015 X 1.75 X.125 7
1-14 02-CP0612 COTTER PIN, 3/16 X 1-1/2 2
1-15 64025-02 NUT-HEX 5/16-18 12
1-16 64123-66 BLT-HEX 5/16-18X3-1/2 6
1-17 64025-05 NUT-3/8-16 HEX 8
1-18 55-FB22016 BEARING 2
1-19 64123-16 BLT-HEX 3/8-16X1-1/4 8
1-20 60-188.7 BOTTOM PAN 1
1-21 80-124.7 PACKER ROTOR 1
1-22 64123-39 BOLT-HEX 1/2-13X1-1/4 4
1-23 62-357.7 HITCH 1
1-24 64025-09 HEX, NUT 1/2-13 4
1-25 86-044 HUB-CLUTCH DRIVE 2
1-26 64123-50 BOLT-HEX 3/8-16X1 2
1-27 64006-05 LOCKWSHR-HELICAL 1/2 4
1-28 64163-61 WSHR .81X.406X16GA 12
1-29 64006-03 LOCKWASHER-3/8 HEL 8
1-30 64006-02 LOCKWASHER-5/16 HEL 6
1-31 85-SC06 SET COLLAR-3/8 4
(AFTER SN 1097)
1-32 99-K02 BOLT, FLANGE 5/16-18 X 1 4
(AFTER SN 1097)
1-33 64141-6 NUT, 5/16-18 4
(AFTER SN 1097)
1-34 64-535 STOP-ADJUSTABLE LATCH 2
(AFTER SN 1097)
1-35 64229-03 LOCKNUT-NYLON 3/8-16 2
1-36 M0005 GREASE FITTING 2

8
LAWN
SWEEPER
BRUSH PARTS
FIGURE 2

9
LAWN
SWEEPER
ITEM PART NO. DESCRIPTION QTY ITEM PART NO. DESCRIPTION QTY
BRUSH PARTS
FIGURE 2
2-1 62-385.7 HOUSING, BROOM LS340 1
2-2 64025-09 HEX, NUT 1/2-13 3
2-3 64025-05 NUT-3/8-16 HEX 8
2-4 PL7640 EYEBOLT 2
2-5 41-010 SPRING 3
2-6 64163-16 WASHER-41/64 X 1, 3/8 X 12 12
2-7 53-104 WHL-10.25X3.25 CASTER 2
(SN 1001 - 1559)
55-G527 BALL BEARING 2
55-107 BEARING-5/8IDX1-3/8OD 2
(OPTIONAL HEAVY DUTY)
53-186 WHL-10.25X3.25 CASTER 2
(SN 1559 - )
55-112 BRG-ROLLER 5/8IDX1-3/8 1
53-187 RETAINER-FLANGED 2
2-8 64123-93 BLT-HEX 3/8-16X5 2
2-9 64163-61 WSHR .81X.406X16GA 2
2-10 40-227.7 IDLER ARM 1
2-11 56-RC40-59 CHAIN-DRIVE #40 59" LNG 1
81-056 CONNECTOR LINK-#40 CHN 1
81-076 HALF LINK-#40 CHN 1
2-12 64164-10 1/4X1/4X1-1/4 MACH KEY 1
2-13 64123-24 BLT-HEX 1/2-13X2 1
2-14 83-H401216 SPROCKET 1
2-15 83-4017E08 IDLER SPROCKET 1
2-16 55-FB23016 FLANGE BRG-2 BOLT, 1" 2
2-17 79-017 BRUSH 6
2-18 80-125.7 ROTOR 1
2-19 64229-01 LOCKNUT-NYLON 1/4-20 1
2-20 64123-07 BOLT, 1/4-20X1-1/2 HEX 1
2-21 02-PP0420 PRESTO PIN, 1/8 X 2-9/16 1
2-22 42-207.7 HANDLE, LIFT 1
2-23 42-206.7 HEIGHT ADJUSTER 1
2-24 02-PP0318 PIN, 3/32 x 2.5/16 1
2-25 85-SC16 SET COLLAR 2
2-26 64163-67 WASHER-.516X1X12GA 6
2-27 64123-72 BLT-HEX 1/2-13X2-1/2 1
2-28 64006-05 LOCKWSHR-HELICAL 1/2 2
2-29 64123-39 BOLT-HEX 1/2-13X1-1/4 1
2-30 64229-05 LOCKNUT, 1/2-13 NYLON 2
2-31 50-062 SHAFT-WHEEL 2
2-32 64123-16 BOLT-3/8 X 1-1/4 4
2-33 64141-4 NUT-WLF 3/8-16 2
2-34 64006-03 LOCKWASHER-3/8 HEL 4
2-35 64123-117 BOLT-HEX 1/2-13X1-1/2 1

BOB-CAT BROUWER BUNTON CUSHMAN RYAN STEINER
Equipment from Jacobsen, a Textron company,
is built to exacting standards ensured by
ISO 9001 and ISO 14001 registration at all our
manufacturing locations.
A worldwide dealer network and factory-trained
technicians backed by Textron Parts Xpress
provide reliable, high-quality product support.
