TFT Flip Tip Only No Shutoff User manual

©Copyright Task Force Tips LLC 2012-2019 LIN-060 April 29, 2019 Rev01
MANUAL: FLIP TIPTM NOZZLE
PATENT 9,138,754
INSTRUCTIONS FOR INSTALLATION, SAFE OPERATION AND MAINTENANCE
WARNING Understand manual before use. Operation of this device without understanding the manual and
receiving proper training is a misuse of this equipment. Obtain safety information at tft.com/
serial-number
This instruction manual is intended to familiarize fi refi ghters and maintenance personnel with the operation, servicing and safety
procedures associated with the Flip Tip fi re fi ghting nozzles.
This manual should be kept available to all operating and maintenance personnel.
TASK FORCE TIPS LLC
MADE IN USA • tft.com
3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 • 219-462-6161 • Fax [phone]
Flip Tip Only
No Shutoff
Flip Tip
Valve Shutoff
Flip Tip
Valve Shutoff w/Pistol Grip
G-Force Flip Tip
Valve Shutoff w/Pistol Grip
G-Force Flip Tip
Valve Shutoff

©Copyright Task Force Tips LLC 2012-2019 LIN-060 April 29, 2019 Rev01
2
DANGER
PERSONAL RESPONSIBILITY CODE
The member companies of FEMSA that provide emergency response
equipment and services want responders to know and understand the
following:
1. Firefi ghting and Emergency Response are inherently dangerous activities
requiring proper training in their hazards and the use of extreme caution
at all times.
2. It is your responsibility to read and understand any user’s instructions,
including purpose and limitations, provided with any piece of equipment
you may be called upon to use.
3. It is your responsibility to know that you have been properly trained in
Firefi ghting and /or Emergency Response and in the use, precautions, and
care of any equipment you may be called upon to use.
4. It is your responsibility to be in proper physical condition and to maintain
the personal skill level required to operate any equipment you may be
called upon to use.
5. It is your responsibility to know that your equipment is in operable
condition and has been maintained in accordance with the manufacturer’s
instructions.
6. Failure to follow these guidelines may result in death, burns or other
severe injury.
FEMSA
Fire and Emergency Manufacturers and Service Association
P.O. Box 147, Lynnfi eld, MA 01940 • www.FEMSA.org

©Copyright Task Force Tips LLC 2012-2019 LIN-060 April 29, 2019 Rev01
3
Table Of Contents
1.0 MEANING OF SAFETY SIGNAL WORDS................................................................. 4
2.0 SAFETY ..................................................................................................................... 4
3.0 GENERAL INFORMATION......................................................................................... 4
3.1 VARIOUS MODELS AND TERMS.......................................................................... 5
3.2 SPECIFICATIONS.................................................................................................. 5
3.3 NOZZLE COUPLINGS ........................................................................................... 5
3.4 USE WITH SALTWATER........................................................................................ 5
4.0 FLOW CHARACTERISTICS AND CHARTS.............................................................. 6
5.0 NOZZLE CONTROLS ................................................................................................ 7
5.1 REMOVABLE STREAM STRAIGHTENER ............................................................ 7
5.2 FLIP TIP LOCK.......................................................................................................7
5.3 REAR SMOOTH BORE INSERTS......................................................................... 8
5.4 FRONT SMOOTH BORE NOZZLE........................................................................ 8
5.5 FRONT G-FORCE FOG NOZZLE.......................................................................... 8
6.0 USE OF NOZZLES..................................................................................................... 9
7.0 APPROVALS .............................................................................................................. 9
8.0 COLOR CODED VALVE HANDLE AND PISTOL GRIP ............................................. 9
9.0 EXPLODED VIEWS AND PARTS LISTS ................................................................. 10
9.1 TIP ONLY FLIP TIP............................................................................................... 10
9.2 FLIP TIP WITH INTEGRATED VALVE ................................................................. 12
10.0 WARRANTY ............................................................................................................ 14
11.0 MAINTENANCE....................................................................................................... 14
11.1 FIELD INSPECTION............................................................................................ 14
11.2 REPAIR................................................................................................................ 14
11.3 FIELD LUBRICATION.......................................................................................... 15
11.4 SERVICE TESTING............................................................................................. 15
11.4.1 HYDROSTATIC TESTING ............................................................................. 15
11.4.2 FLOW TESTING............................................................................................ 15
11.4.3 RECORDS..................................................................................................... 15
12.0 OPERATION AND INSPECTION CHECKLIST ...................................................... 16
13.0 ANSWERS TO YOUR QUESTIONS ....................................................................... 16

©Copyright Task Force Tips LLC 2012-2019 LIN-060 April 29, 2019 Rev01
4
1.0 MEANING OF SAFETY SIGNAL WORDS
A safety related message is identifi ed by a safety alert symbol and a signal word to indicate the level of risk involved with a particular
hazard. Per ANSI standard Z535.6-2006, the defi nitions of the four signal words are as follows:
DANGER DANGER indicates a hazardous situation which, if not avoided, will result in death or serious
injury.
WARNING WARNING indicates a hazardous situation which, if not avoided, could result in death or serious
injury.
CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor
or moderate injury.
NOTICE NOTICE is used to address practices not related to personal injury.
3.0 GENERAL INFORMATION
The Task Force Tips Flip Tip nozzles are designed to provide excellent performance under most fi re fi ghting conditions. Their rugged
construction is compatible with the use of fresh water as well as fi re fi ghting foam solutions. Other important operating features
include:
• Changeable smooth bore tips
• Stream straightener removable through back of standard 1.5” coupling. If a 2.5” coupling is required, contact TFT for details.
• TFT’s fi ve-year warranty and unsurpassed customer service
2.0 SAFETY
DANGER An inadequate supply of nozzle pressure and/or fl ow will cause an ineff ective stream and can
result in injury, death, or loss of property. See fl ow graphs or call 800-348-2686 for assistance.
WARNING The nozzle may be damaged if frozen while containing signifi cant amounts of water. Such damage
may be diffi cult to detect visually and can lead to possible injury or death. Any time the nozzle is
subject to possible damage due to freezing, it must be tested by qualifi ed personnel before being
considered safe for use.
WARNING This equipment is intended for use by trained personnel for fi refi ghting. Their use for other
purposes may involve hazards not addressed by this manual. Seek appropriate guidance and
training to reduce risk of injury.
WARNING Failure to restrain nozzle reaction can cause fi refi ghter injury from loss of footing and/or stream
protection. Nozzle reaction will vary as supply conditions change: such as opening or closing
other nozzles, hose line kinks, changes in pump settings, etc. Changes in spray pattern or
fl ushing will also aff ect nozzle reaction. The nozzle operator must always be prepared in the
event of these changes.
WARNING If nozzle gets out of control or away from operator, retreat from nozzle immediately. Do not attempt
to regain control of nozzle while fl owing water. Injury from whipping can occur.
WARNING Water is a conductor of electricity. Application of water on high voltage equipment can cause
injury or death by electrocution. The amount of current that may be carried back to the nozzle will
depend on the following factors:
• Voltage of the line or equipment
• Distance from the nozzle to the line or equipment
• Size of the stream
• Whether the stream is solid or broken
• Purity of the water1
1 The Fire Fighter and Electrical Equipment, The University of Michigan Extension Service, Fourth
Printing 1983. Page 47
CAUTION Fire streams are capable of injury and damage. Do not direct water stream to cause injury or
damage to persons or property.
[Footnote 1: The Fire Fighter and Electrical Equipment, The University of Michigan Extension Service, Fourth Printing 1983, Page 47.]

©Copyright Task Force Tips LLC 2012-2019 LIN-060 April 29, 2019 Rev01
5
3.3 NOZZLE COUPLINGS
NH (National Hose Threads per NFPA #1963) threads are standard on all nozzles. Other threads such as NPSH (National Pipe
Straight Hose threads per ANSI/ASME #B1.20.7) can be specifi ed at time of order.
CAUTION Nozzle must be properly connected. Mismatched or damaged threads may cause nozzle to leak or
uncouple under pressure and could cause injury.
CAUTION Dissimilar metals coupled together can cause galvanic corrosion that can result in the inability
to unscrew the threads or complete loss of thread engagement over time. Per NFPA 1962 (2008
edition), if dissimilar metals are left coupled together an anti-corrosive lubricant should be applied
to the threads. Also, the coupling should be disconnected and inspected at least quarterly.
3.1 VARIOUS MODELS AND TERMS
The TFT Flip Tip nozzle is available in several diff erent confi gurations. The Flip Tip nozzle can be ordered with or without a pistol grip.
Figure 3.1 shows the various models.
Flip Tip Only
No Shutoff
Ball Valve with Smoothbore Rear
and Smoothbore Front
Ball Valve With Smoothbore Rear
and G-Force Fog Nozzle Front
Locking Ring
Coupling
Pistol Grip
G-Force Fog Nozzle
See LIG-010 for
more information
OFFON
Flow Control
Removeable
Stream Straightener*
Available Rear Smoothbores:
7/8”, 15/16”, 1”, 1-1/8”, or 1-3/8”
(22mm, 24mm, 25mm, 28mm, or 30mm)
Available Front Smoothbores:
1/2", 5/8", 7/8", 15/16", 1", 1-1/8", or 1-3/16"
(12mm, 16mm, 22mm, 24mm, 25mm, 28mm, or 30mm)
Serial Number
(on top of valve just ahead of coupling)
Serial Number
(on top of valve just ahead of coupling)
* Standard for 1.5" connections. A special coupling (P198) is needed
to work for 2.5" connections. Contact TFT for details.
Figure 3.1 Common Models and Terms
3.2 SPECIFICATIONS
Maximum nozzle inlet pressure with valve shutoff * 300 psi 20 bar
Operating temperature range of fl uid 33 to 120º F 1 to 50º C
Storage temperature range -40 to 150º F -40 to 65º C
Materials used Aluminum 6000 series hard anodized MIL8625 class 3 type 2,
stainless steel 300 series, nylon 6-6, nitrile rubber
*Consult Factory for higher pressure applications
3.4 USE WITH SALTWATER
Use with salt water is permissible provided the nozzle is thoroughly cleaned with fresh water after each use. The service life of the
nozzle may be shortened due to the eff ects of corrosion and is not covered under warranty.

©Copyright Task Force Tips LLC 2012-2019 LIN-060 April 29, 2019 Rev01
6
4.0 FLOW CHARACTERISTICS AND CHARTS
The Flip Tip nozzle has fi xed orifi ce sizes. Relationship of fl ow and nozzle pressure at each orifi ce size is shown below. If the nozzle
is connected behind a different nozzle, use the flow charts for the outlet nozzle.
1/2"
5/8"
7/8"
15/16"
1"
1 1/8"
1 1/4"
1 3/8"
0
1
2
3
4
5
6
7
0
10
20
30
40
50
60
70
80
90
100
0 100 200 300 400 500 600
PRESSURE (BAR)
PRESSURE (PSI)
FLOW (GPM)
0 500 1000 1500 2000
FLOW (LPM)
Figure 4.0 Flip Tip Flow Chart
Flows at specifi c pressures for each orifi ce size are as follows:
1/2” TIP
PRESSURE FLOW REACTION
PSI GPM LBS
40 47 16
50 53 20
60 58 24
70 62 27
80 66 31
5/8” TIP
PRESSURE FLOW REACTION
PSI GPM LBS
40 73 25
50 82 31
60 90 37
70 97 43
80 104 49
7/8” TIP
PRESSURE FLOW REACTION
PSI GPM LBS
40 144 48
50 161 60
60 176 72
70 190 84
80 203 86
15/16” TIP
PRESSURE FLOW REACTION
PSI GPM LBS
40 165 55
50 185 69
60 202 83
70 218 97
80 234 110
1” TIP
PRESSURE FLOW REACTION
PSI GPM LBS
40 188 63
50 210 79
60 230 90
70 249 110
80 266 126
1-1/8” TIP
PRESSURE FLOW REACTION
PSI GPM LBS
40 238 79
50 266 99
60 291 119
70 315 139
80 336 159
1-1/4” TIP
PRESSURE FLOW REACTION
PSI GPM LBS
40 294 98
50 328 123
60 360 147
70 388 172
80 415 196
1-3/8” TIP
PRESSURE FLOW REACTION
PSI GPM LBS
40 355 119
50 397 148
60 435 178
70 470 208
80 502 237
DANGER An inadequate supply of nozzle pressure and/or fl ow will cause an ineff ective stream and can
result in injury, death or loss of property. See fl ow chart in Figure 4.0 or call 800-348-2686 for
assistance.

©Copyright Task Force Tips LLC 2012-2019 LIN-060 April 29, 2019 Rev01
7
5.0 NOZZLE CONTROLS
5.1 REMOVABLE STREAM STRAIGHTENER
Stream quality is generally improved with use of an integral stream straightener at the Flip Tip Inlet. The Flip Tip may be used without
the straightener if so desired.
The removable stream straightener is a standard option for 1.5” connections.
Our 2.5” connections utilize an optimized waterway in place of the stream straightener. If so desired, the straightener can still be used
with a special 2.5” coupling (P198). Contact TFT for details.
Stream Straightener
Flip Tip with smooth bore fron
t
flipped down
To remove the straightener, flip
the smooth bore front down,
open valve fully, insert a wooden
dowel or similar tool to push
the straightener out the rear of
the coupling.
Figure 5.1 Removable Stream Straightener
5.2 FLIP TIP LOCK
The front nozzle is locked in both positions. To change positions follow the steps in fi gure 2.5.
Unlock
Flip Down
1
2
Unlock Flip Up
1
2
Figure 5.2 Using the Flip Tip Lock
WARNING When the front nozzle is in the down position the sealing surfaces are exposed. Avoid actions
which can damage the sealing surface to prevent possible leakage and repairs.
CAUTION The Flip Tip pivoting joint is not sealed between the fully up and fully down positions. Shut off
water fl ow before changing the front nozzle position to avoid spraying in unintended directions.

©Copyright Task Force Tips LLC 2012-2019 LIN-060 April 29, 2019 Rev01
8
5.5 FRONT G-FORCE FOG NOZZLE
The Flip Tip with G-Force fog nozzle allows selection between a smooth bore and a fog nozzle. The G-Force fog nozzle is available
in fi xed opening, selectable, or automatic versions. See the G-Force owners manual LIG-010 for details.
G-Force Fog Nozzle
Rear
Smooth bore insert
Figure 5.5 Front G-Force Fog Nozzle
CAUTION The lock for the front nozzle is not designed to withstand the full force of the nozzle reaction. Do
not use the front nozzle in the down position as a handle to restrain the nozzle reaction. Injury
from inadvertent unlocking may result.
5.3 REAR SMOOTH BORE INSERTS
The rear smooth bore inserts may be removed by removing the retaining ring and pulling the insert out the front of the nozzle.
1-3/8” diameter if no insert is installed
Smooth bore insert
O-Ring
Retaining ring
(use a pick or similar tool
to remove)
Insert removes in this direction
Figure 5.3 Rear Smooth Bore Inserts
5.4 FRONT SMOOTH BORE NOZZLE
Male Hose Thread for attaching a hose
or other nozzle of the proper thread
Smooth bore nozzle
Figure 5.4 Front Smooth Bore Nozzles

©Copyright Task Force Tips LLC 2012-2019 LIN-060 April 29, 2019 Rev01
9
6.0 USE OF NOZZLES
IT IS THE RESPONSIBILITY OF THE INDIVIDUAL FIRE DEPARTMENT OR AGENCY TO DETERMINE PHYSICAL CAPABILITIES AND SUITABILITY FOR AN
INDIVIDUAL’S USE OF THIS EQUIPMENT.
Many factors contribute to the extinguishment of a fi re. Among the most
important is delivering water at a fl ow rate suffi cient to absorb heat faster
than it is being generated. The fl ow rate depends largely on the pump
discharge pressure and hose friction loss. The pump discharge pressure
can be calculated using a hydraulic equation such as:
PDP = NP + FL + DL + EL
PDP = Pump discharge pressure in PSI
NP = Nozzle pressure in PSI
FL = Hose friction loss in PSI
DL = Device loss in PSI
EL = Elevation loss in PSI
For additional information on calculating specifi c hose layouts, consult an appropriate fi re service training manual such at IFSTA, A
Guide to Automatic Nozzles, or call TFT’s “Hydraulics Hotline” at 800-348-2686.
CAUTION The nozzle may become damaged if allowed to freeze while containing water. Always drain
after use to avoid damage and possible loss of use.
8.0 COLOR CODED VALVE HANDLE AND PISTOL GRIP
The TFT Flip Tip is supplied with black valve handle covers and black pistol grip. Handle covers are available from TFT in various
colors for those departments wishing to color code the nozzle to the discharge controls. A colored handle cover set will be sent upon
receipt of the warranty card and color selection form by TFT. Your department’s name can also be engraved on the covers (see color
selection form for more information).
Handle covers are replaceable by removing the four screws that hold the handle covers in place. Use a 3/32” allen wrench when
replacing screws. Pistol grip is replaceable by following TFT instruction sheet LTT-108.
For standardization NFPA 1901-2009 (A.16.9.1) recommends the following color code scheme:
Preconnect #1 or Front Bumper Jump Line
Preconnect #2
Preconnect #3 or discharge #1
Preconnect #4 or discharge #2
Discharge #3
Discharge #4
Discharge #5
Foam Lines
Booster Reels
Orange
Red
Yellow
White
Blue
Black
Green
Red w/ White border (Red/White)
Gray
Other Colors Available:
• Pink
• Tan
• Purple
7.0 APPROVALS
Flip Tip 1.5” and 2.5” NH threaded nozzles meet the requirements of NFPA 1962 (2013) and NFPA 1964 (2008).

©Copyright Task Force Tips LLC 2012-2019 LIN-060 April 29, 2019 Rev01
10
9.0 EXPLODED VIEWS AND PARTS LISTS
9.1 TIP ONLY FLIP TIP
G-FORCE
FRONT
END
SEE LIG-010
FOR G-FORCE
PARTS LIST & EXPLODED VIEW
56
28
55
49
48
54
46
53
52
1
49
48
47
46
28
45 50
51
45
28
44
43
42
40 41
39
38
36 37
35
28
50
51
34
2
33
3
1
7

©Copyright Task Force Tips LLC 2012-2019 LIN-060 April 29, 2019 Rev01
11
ITEM DESCRIPTION QTY PART #
1 GASKET - 1.5" 2 V3130
2 1/4-28 X 3/16 SOCKET SET SCREW 1 VT25-28SS187
3 3/16" SS BALL 38 V2120
7 STREAM STRAIGHTENER 1 P116
28 10-32 X 1/4 SET SCREW - NYLOK 8 VT10Y32SS250
35 O-RING-132 1 VO-132
36 NAME LABEL 1 FF102L
37 BASE 1 FF102
38 TRUNNION 2 FF110
7/8" SMOOTH BORE INSERT FF111
39 15/16" SMOOTH BORE INSERT 1 FF112
1.0" SMOOTH BORE INSERT FF113
1 1/8" SMOOTH BORE INSERT FF114
40 O-RING-123 1 VO-123
41 SMALLEY RING 1 V4232
42 SEAT 1 FF140
43 O-RING-222 2 VO-222
44 LOCK 1 FF120
45 1/8" ACETAL BALL 2 VB125AC
46 DRAG NUBS 2 B650
47 YOKE 1.5" 1 FF150*
48 SLIDE SPRING 2 XG141
49 LOCK RING 1 FF125
50 NYLON BUSHING 2 AY307
51 CAM SCREW 2 FF126
1/2" SMOOTH BORE FF151
5/8" SMOOTH BORE FF152
15/16" SMOOTH BORE FF153
52 1.0" SMOOTH BORE 1 FF154
1 1/8" SMOOTH BORE FF155
1 3/16" SMOOTH BORE FF156
7/8" SMOOTH BORE FF157
53 COUPLING 1.5" 1 FF145*
54 YOKE G-FORCE 1 FF160
55 O-RING-031 1 VO-031
56 BODY G-FORCE AUX TIP 1 FF161
* - CONSULT FACTORY FOR SPECIAL THREADS

©Copyright Task Force Tips LLC 2012-2019 LIN-060 April 29, 2019 Rev01
12
9.2 FLIP TIP WITH INTEGRATED VALVE
G-FORCE
FRONT
END
SEE LIG-010
FOR G-FORCE
PARTS LIST & EXPLODED VIEW
56
28
55
49
48
54
46
53
52
1
49
48
47
46
32
31
30
29
28
14
13
7
6
5
4
1
2
3
15
16
17
18
19
20 22
23
21
24 25
24 26
27
44
43
42
40 41
39
38
36 37
35
28
45 50
51
45
28
28
50
51
2
3
5
9
8
10
11
12

©Copyright Task Force Tips LLC 2012-2019 LIN-060 April 29, 2019 Rev01
13
ITEM DESCRIPTION QTY PART #
1 GASKET - 1.5" 2 V3130
2 1/4-28 X 3/16 SOCKET SET SCREW 1 VT25-28SS187
3 3/16" SS BALL 38 V2120
4 COUPLING 1.5" 1 H694*
5 O-RING-141 1 VO-141
6 ANTI GG RING VO 1 P147
7 STREAM STRAIGHTENER 1 P116
8 REDUCTION INSERT F 1 P119F
9 GASKET - 2.5" 1 V3190
10 COUPLING 2.5" 1 P205
11 REDUCTION INSERT J 1 P119J
12 DETENT VALVE BODY 1 P110
13 TRUNNION - LEFT 1 P120L
14 3/8-16 X 5/16 SOCKET SET SCREW 1 VT37-16SS312
HANDLE SUBASSEMBLY 1 HX920
15 BLACK HANDLE COVER 2 HM625-BLK
HANDLE 1 HX620
8-14 X 3/8 PUSHTITE BUTTON HEAD 4 VT08-14PT375
16 HDP SPIROL 2 V2005
17 TRUNNION DRIVER 2 HX650
18 3/8-24 X 3/4 BUTTON HEAD 2 VT37E24BH750
19 DETENT SPRING 2 HM770
20 .243" TORLON BALL 2 VB243TO
21 O-RING-118 2 VO-118
22 TEFLON TRUNNION SHIM 2 P170
23 TRUNNION - RIGHT 1 P120R
24 BALL SEAT VALVE 2 P104
25 DELRIN VALVE BALL 1 P103
26 O-RING-227 1 VO-227
27 ADAPTER VALVED BASE 1 FF101
28 10-32 X 1/4 SET SCREW - NYLOK 8 VT10Y32SS250
29 GRIP SPACER HANDLINE 1 HM693-H
30 PISTOL GRIP 1 HM692
31 WASHER 1 VM4109
32 3/8-16 X 1 SOCKET HEAD SCREW 1 VT37-16SH1.0
ITEM DESCRIPTION QTY PART #
35 O-RING-132 1 VO-132
36 NAME LABEL 1 FF102L
37 BASE 1 FF102
38 TRUNNION 2 FF110
7/8" SMOOTH BORE INSERT FF111
39 15/16" SMOOTH BORE INSERT 1 FF112
1.0" SMOOTH BORE INSERT FF113
1 1/8" SMOOTH BORE INSERT FF114
40 O-RING-123 1 VO-123
41 SMALLEY RING 1 V4232
42 SEAT 1 FF140
43 O-RING-222 2 VO-222
44 LOCK 1 FF120
45 1/8" ACETAL BALL 2 VB125AC
46 DRAG NUBS 2 B650
47 YOKE 1.5" 1 FF150*
48 SLIDE SPRING 2 XG141
49 LOCK RING 1 FF125
50 NYLON BUSHING 2 AY307
51 CAM SCREW 2 FF126
1/2" SMOOTH BORE FF151
5/8" SMOOTH BORE FF152
15/16" SMOOTH BORE FF153
52 1.0" SMOOTH BORE 1 FF154
1 1/8" SMOOTH BORE FF155
1 3/16" SMOOTH BORE FF156
7/8" SMOOTH BORE FF157
53 COUPLING 1.5" 1 FF145*
54 YOKE G-FORCE 1 FF160
55 O-RING-031 1 VO-031
56 BODY G-FORCE AUX TIP 1 FF161
* - CONSULT FACTORY FOR SPECIAL THREADS

©Copyright Task Force Tips LLC 2012-2019 LIN-060 April 29, 2019 Rev01
14
11.0 MAINTENANCE
TFT nozzles are designed and manufactured to be damage resistant and require minimal maintenance. However, as the primary
fi refi ghting tool upon which your life depends, it should be treated accordingly. To help prevent mechanical damage, do not drop or
throw equipment.
11.1 FIELD INSPECTION
WARNING Nozzle must be inspected for proper operation and function according to the inspection checklist
in Section 12.0 before each use. Any nozzle that fails inspection is dangerous to use and must
be repaired before using.
CAUTION Any alteration to the nozzle and its markings could diminish safety and constitutes a misuse of
this product.
11.2 REPAIR
Factory service is available with repair time seldom exceeding one day in our facility. Factory-serviced nozzles are repaired by
experienced technicians, wet tested to original specifi cations, and promptly returned. Repair charges for non-warranty items are
minimal. Any returns should include a note as to the nature of the problem and whom to reach in case of questions.
Repair parts and service procedures are available for those wishing to perform their own repairs. Task Force Tips assumes no
liability for damage to equipment or injury to personnel that is a result of user service. Contact the factory or visit the web site at tft.
com for parts lists, exploded views, test procedures and troubleshooting guides. All replacement parts must be obtained from the
manufacturer to assure proper operation of the product, and to maintain approval of the device.
Performance tests shall be conducted on the nozzle after a repair, or anytime a problem is reported to verify operation in accordance
with TFT test procedures. Consult factory for the procedure that corresponds to the model and serial number of the nozzle. Any
equipment which fails the related test criteria should be removed from service immediately. Troubleshooting guides are available with
each test procedure or equipment can be returned to the factory for service and testing.
10.0 WARRANTY
Task Force Tips LLC, 3701 Innovation Way, Valparaiso, Indiana 46383-9327 USA (“TFT”) warrants to the original purchaser of its Flip
Tip series nozzles (“equipment”), and to anyone to whom it is transferred, that the equipment shall be free from defects in material
and workmanship during the fi ve (5) year period from the date of purchase.
TFT’s obligation under this warranty is specifi cally limited to replacing or repairing the equipment (or its parts) which are shown by
TFT’s examination to be in a defective condition attributable to TFT. To qualify for this limited warranty, the claimant must return the
equipment to TFT, at 3701 Innovation Way, Valparaiso, Indiana 46383-9327 USA, within a reasonable time after discovery of the
defect. TFT will examine the equipment. If TFT determines that there is a defect attributable to it, TFT will correct the problem within
a reasonable time. If the equipment is covered by this limited warranty, TFT will assume the expenses of repair.
If any defect attributable to TFT under this limited warranty cannot be reasonably cured by repair or replacement, TFT may elect to
refund the purchase price of the equipment, less reasonable depreciation, in complete discharge of its obligations under this limited
warranty. If TFT makes this election, claimant shall return the equipment to TFT free and clear of any liens and encumbrances.
This is a limited warranty. The original purchaser of the equipment, any person to whom it is transferred, and any person who is
an intended or unintended benefi ciary of the equipment, shall not be entitled to recover from TFT any consequential or incidental
damages for injury to person and/or property resulting from any defective equipment manufactured or assembled by TFT. It is agreed
and understood that the price stated for the equipment is in part consideration for limiting TFT’s liability. Some states do not allow the
exclusion or limitation of incidental or consequential damages, so the above may not apply to you.
TFT shall have no obligation under this limited warranty if the equipment is, or has been, misused or neglected (including failure to
provide reasonable maintenance) or if there have been accidents to the equipment or if it has been repaired or altered by someone
else.
THIS IS A LIMITED EXPRESS WARRANTY ONLY. TFT EXPRESSLY DISCLAIMS WITH RESPECT TO THE EQUIPMENT ALL
IMPLIED WARRANTIES OF MERCHANTABILITY AND ALL IMPLIED WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE.
THERE IS NO WARRANTY OF ANY NATURE MADE BY TFT BEYOND THAT STATED IN THIS DOCUMENT.
This limited warranty gives you specifi c legal rights, and you may also have other rights which vary from state to state.

©Copyright Task Force Tips LLC 2012-2019 LIN-060 April 29, 2019 Rev01
15
11.4.1 HYDROSTATIC TESTING
Each nozzle with a shut offmechanism shall be tested in the following manner.
1. The nozzle shall be placed in a device capable of holding it and the shut offshall be closed.
2. A device capable of exerting a hydrostatic pressure of 300 psi (2070 kPa) or 1.5 times the maximum operating pressure,
whichever is higher, shall be attached to the nozzle.
3. All air shall be bled from the system.
4. The gage pressure shall be increased by 50 psi (3.5 bar or 345 kPa) increments, held for 30 seconds at each pressure up to
the maximum pressure for which the nozzle is being tested, and then held for one minute without leakage.
5. There shall be no sign of leakage through the valve or shut off.
11.4.2 FLOW TESTING
Flow testing must be conducted in the following manner.
1. The nozzle shall be mounted so that the flow rate and pressure through the nozzle and the pressure at the inlet can be
accurately measured.
2. With the shut offfully open, the inlet pressure shall be adjusted to the rated pressure ±2 percent.
3. The valve or shut offand pattern controls shall be operated through their full range of motion at 100 psi (6.9 bar or 690 kPa)
with no signs of leaking, binding or other problems.
4. Evaluate the flow of nozzles as defined by NFPA 1964 in the following manner:
Basic Spray Nozzles shall flow no less than and no more than 10 percent over the rated flow at the rated pressure in the
straight stream and wide-angle fog settings.
11.4.3 RECORDS
A record of testing and repairs must be maintained from the time the nozzle is purchased until it is discarded. Each TFT nozzle is
engraved with a unique serial number which, if so desired, can be used to identify nozzle for documentation purposes.
The following information, if applicable, must be included on the test record for each nozzle:
1. Assigned identification number
2. Manufacturer
3. Product or model designation
4. Vendor
5. Warranty
6. Hose connection size
7. Maximum operating pressure
8. Flow rate or range
9. Date received and date put in service
10. Date of each service test and service test results
11. Damage and repairs, including who made the repairs and the cost of repair parts
12. Reason removed from service
NFPA 1962: Standard for the care, use, inspection, service testing, and replacement of fire hose, couplings, nozzles and fire hose appliances. (2013
ed., Section 5.5.4). Quincy, MA: National Fire Protection Agency.
11.3 FIELD LUBRICATION
All Task Force Tip nozzles are factory lubricated with high quality silicone grease. This lubricant has excellent washout resistance
and long term performance. If your department has unusually hard or sandy water, the moving parts may be aff ected. Foam agents
and water additives contain soaps and chemicals that may break down the factory lubrication.
The moving parts of the nozzle should be checked on a regular basis for smooth and free operation, and signs of damage. IF THE
NOZZLE IS OPERATING CORRECTLY, THEN NO ADDITIONAL LUBRICATION IS NEEDED. Any nozzle that is not operating
correctly should be immediately removed from service.
11.4 SERVICE TESTING
In accordance with NFPA 1962 (2013), nozzles must be tested a minimum of annually. Nozzles failing any part of this test must be
removed from service, repaired and retested upon completion of the repair.

©Copyright Task Force Tips LLC 2012-2019 LIN-060 April 29, 2019 Rev01
TASK FORCE TIPS LLC
MADE IN USA • tft.com
3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 • 219-462-6161 • Fax [phone]
12.0 OPERATION AND INSPECTION CHECKLIST
BEFORE EACH USE the nozzle must be inspected to this checklist:
1) There is no obvious damage such as missing, broken or loose parts, damaged labels etc.
2) Internal vanes are free of debris
3) Coupling is tight and leak free
4) Valve operates freely through full range and regulates fl ow
5) “OFF” position does fully shut off and fl ow is stopped
6) Nozzle fl ow is adequate as indicated by pump pressure and nozzle reaction
7) Shaper turns freely and adjusts pattern through full range
8) Shaper detent (if so equipped) operates smoothly and positively.
BEFORE BEING PLACED BACK IN SERVICE, nozzles must be inspected to this checklist;
1) All controls and adjustments are operational
2) Shut offvalve (if so equipped) closes offthe flow completely
3) There are no broken or missing parts
4) There is no damage to the nozzle that could impair safe operation (e.g. dents, cracks, corrosion or other defects)
5) The thread gasket is in good condition
6) The waterway is clear of obstructions
7) Nozzle is clean and markings are legible
8) Coupling is retightened properly
9) Shaper is set to desired pattern
10) Shutoffhandle is stored in the OFF position
NFPA 1962: Standard for the care, use, inspection, service testing, and replacement of fire hose, couplings, nozzles and fire hose appliances. (2013
ed., Section 5.2.2). Quincy, MA: National Fire Protection Agency.
WARNING Any nozzle failing any part of the checklist is unsafe for use and must have the problem corrected before use or being placed
back into service. Operating a nozzle that has failed the checklist is a misuse of this equipment.
13.0 ANSWERS TO YOUR QUESTIONS
We appreciate the opportunity of serving you and making your job easier. If you have any problems or questions, our toll-free
“Hydraulics Hotline”, 800-348-2686 or 1-219-462-6161 is normally available to you 24 hours a day, 7 days a week.
