©Copyright Task Force Tips LLC 2014-2021 1 LIA-208 May 19, 2021 Rev05
TASK FORCE TIPS LLC
MADE IN USA · tft.com
3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 · 219-462-6161 · Fax [phone]
G-Force
INSTRUCTION FOR INSTALLATION, OPERATION, AND MAINTENANCE
JUMBO LOW PROFILE
BALL INTAKE VALVE (BIV)
DANGER
Understand manual before use. Operation of this device without understanding the manual and
receiving proper training is a misuse of this equipment. Obtain safety information at tft.com/
serial-number.
This equipment is intended for use by trained and qualified emergency services personnel for
firefighting. All personnel using this equipment shall have completed a course of education
approved by the Authority Having Jurisdiction (AHJ).
This instruction manual is intended to familiarize firefighters and maintenance personnel with the
operation, servicing, and safety procedures associated with this product. This manual should be
kept available to all operating and maintenance personnel.
LEFT DRIVE RIGHT DRIVE
AXD1ST-NX-T
Jumbo Low Profile
Ball Intake Valve
Top Crank
with Pressure Relief Valve
AZD1ST-NX-T
without Pressure Relief Valve
(not shown)
AXD1ST-NX-F
Jumbo Low Profile
Ball Intake Valve
Front Crank
with Pressure Relief Valve
AZD1ST-NX-F
without Pressure Relief Valve
(not shown)
AXD1ST-NX-RC
Jumbo Low Profile
Ball Intake Valve
Electrically Actuated
with Pressure Relief Valve
AZD1ST-NX-RC
without Pressure Relief Valve
(not shown)
AXE1ST-NX-RC
Jumbo Low Profile
Ball Intake Valve
Electrically Actuated
with Pressure Relief Valve
AZE1ST-NX-F
without Pressure Relief Valve
(not shown)
AXE1ST-NX-F
Jumbo Low Profile
Ball Intake Valve
Front Crank
with Pressure Relief Valve
AZE1ST-NX-F
without Pressure Relief Valve
(not shown)
AXE1ST-NX-T
Jumbo Low Profile
Ball Intake Valve
Top Crank
with Pressure Relief Valve
AZE1ST-NX-T
without Pressure Relief Valve
(not shown)

©Copyright Task Force Tips LLC 2014-2021 2 LIA-208 May 19, 2021 Rev05
The member companies of FEMSA that provide emergency
response equipment and services want responders to know and
understand the following:
1. Firefighting and Emergency Response are inherently
dangerous activities requiring proper training in their hazards
and the use of extreme caution at all times.
2. IT IS YOUR RESPONSIBILITY to read and understand
any user’s instructions, including purpose and limitations,
provided with any piece of equipment you may be called on
to use.
3. IT IS YOUR RESPONSIBILITY to know that you have been
properly trained in Firefighting and/or Emergency Response
and in the use, precautions, and care of any equipment you
may be called upon to use.
4. IT IS YOUR RESPONSIBILITY to be in proper physical
condition and to maintain the personal skill level required to
operate any equipment you may be called upon to use.
5. IT IS YOUR RESPONSIBILITY to know that your equipment is
in operable condition and has been maintained in accordance
with the manufacturer’s instructions.
6. Failure to follow these guidelines may result in death, burns or
other severe injury.
Fire and Emergency Manufacturers and Service Association, Inc.
PO Box 147, Lynnfield, MA 01940 • www.FEMSA.org
© 2020 FEMSA. All Rights Reserved.
PERSONAL RESPONSIBILITY CODE
DANGER
SUPPORTING MATERIALS
The following document contains supporting safety and operating information pertaining
to the equipment described in this manual.
LIA-202
Pressure Relief Valve Manual
©Copyright TaskForce Tips LLC 2004-2019 LIA-202 November 12, 2019 Rev05
MANUAL: Pressure Relief Valve
INSTRUCTIONS FOR SAFE OPERATION AND MAINTENANCE
WARNING Understand manual before use. Operation of this device without understanding the manual and
receiving proper training is a misuse of this equipment. Obtain safety information at tft.com/
serialnumber.
This instruction manual is intended to familiarize reghters and maintenance personnel with the operation, servicing, and safety
procedures associated with this product.
This manual should be kept available to all operating and maintenance personnel.
Flange Mounted PRV
Flange Mounted PRV
with Galvanic Isolator
Flange mounted PRVs are available with a variety of outlets. Consult the catalog, factory, or tft.com to nd the conguration for your
application.
TASK FORCE TIPS LLC
MADE IN USA • TFT.com
3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 • 219-462-6161 • Fax [phone]

©Copyright Task Force Tips LLC 2014-2021 3 LIA-208 May 19, 2021 Rev05
TABLE OF CONTENTS
1.0 MEANING OF SAFETY SIGNAL WORDS
2.0 SAFETY
3.0 GENERAL INFORMATION
3.1 SPECIFICATIONS
3.1.1 MECHANICAL
3.1.2 ELECTRICAL
3.2 VARIOUS MODELS AND TERMS
3.3 CORROSION
3.4 USE WITH SALT WATER
4.0 OVERALL DIMENSIONS
5.0 INSTALLATION
5.1 MOUNTING THE APPLIANCE
5.2 MOUNTING THE DISPLAY ENCLOSURE
5.3 ELECTRIC INSTALLATION AND WIRING
5.3.1 TESTING THE ELECTRICAL INSTALLATION
5.4 BIV RC MANUAL OVERRIDE
5.5 CHANGING THE OFFSET OF THE CRANK HANDLE
5.6 CHANGING COUPLING LOCK-OUT
5.7 PEG OPTION
5.8 STORZ SUCTION GASKET REQUEST
6.0 USE
6.1 ELBOW
6.2 MANUAL VALVE OPERATION
6.3 RC VALVE OPERATION
6.4 AIR VENT AND WATER DRAIN
6.5 PRESSURE RELIEF VALVE (PRV)
6.5.1 RELIEF VALVE PRESSURE SETTING
6.6 PRESSURE LOSS
6.7 SUCTION SCREEN
7.0 TEN YEAR EXTENDED WARRANTY FOR JBIV-LP SERIES VALVES
8.0 MAINTENANCE
8.1 TROUBLESHOOTING
8.2 SERVICE TESTING
8.3 REPAIR
8.4 CRANKSHAFT OVERRIDE AND REPLACEMENT
8.4.1 EMERGENCY CRANKSHAFT OVERRIDE
8.4.2 DIAGNOSING CRANKSHAFT FAILURE
8.4.3 CRANKSHAFT REPLACEMENT
9.0 EXPLODED VIEW AND PARTS LISTS
10.0 OPERATION AND INSPECTION CHECKLIST
11.0 TEMPLATES
11.1 DISPLAY ENCLOSURE
11.2 QUICK CONNECT PLUG

©Copyright Task Force Tips LLC 2014-2021 4 LIA-208 May 19, 2021 Rev05
1.0 MEANING OF SAFETY SIGNAL WORDS
A safety related message is identified by a safety alert symbol and a signal word to indicate the level of risk involved with a particular
hazard. Per ANSI Z535.6, the definitions of the four signal words are as follows:
2.0 SAFETY
3.0 GENERAL INFORMATION
The Low Profile Jumbo Ball Intake Valve is intended for use on either the intake manifold of a fire engine or on a discharge port of a fire
main. The valve is available in several versions to minimize interference with surrounding components. An adjustable pressure relief
valve mounted on the valve opens to relieve any excess pressure that may damage the hose or the pump. The valve may be used for
pressure or vacuum/drafting service.
An electric remote controlled (RC) model allows the valve to be operated from a remote location. A typical installation consists of the RC
valve and a remote display operator station. Motor controls are designed to auto sense 12 VDC or 24 VDC operation. The motor control
circuit utilizes a position encoder and current limiting to protect the drive train at the ends of travel. Unit is supplied with 2’ of cable with a
plug on RC valve and 15’ of cable with a receptacle to minimize installation effort. Cable has only four conductors (two for power and two
for communications) further easing installation effort. To complete the installation, the installer will need to mount and wire the remote
display operator station. The display has 20’ of cable. The power supply for the RC valve will need to be connected to a protected circuit
from the truck's power distribution center.
DANGER
DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury.
WARNING
WARNING indicates a hazardous situation which, if not avoided, could result in death or serious
injury.
CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, could result in minor
or moderate injury.
NOTICE
NOTICE is used to address practices not related to physical injury.
DANGER
An inadequate supply of pressure and/or flow will cause an ineffective stream and can result
in injury or death. Choose operating conditions to deliver adequate fire suppression.
WARNING
This equipment is intended for use by trained personnel for firefighting. Use of this equipment for
other purposes may involve hazards not addressed by this manual. Seek appropriate guidance and
training to reduce risk of injury.
WARNING
Equipment may be damaged if frozen while containing significant amounts of water. Such damage
may be difficult to detect visually. Subsequent pressurization can lead to injury or death. Any time
the equipment is subject to possible damage due to freezing, it must be tested and approved for
use by qualified personnel before being considered safe for use.
WARNING
Sudden changes in valve position can cause pressure spikes (water hammer) and could lead to
hose or pipe failure or an out of control monitor. Open and close the valve slowly to avoid water
hammer.
WARNING
Interrupting flow to the device could cause injury or death. Avoid situations that may interrupt
flow to the device such as: hose line kinks, traffic running over hose, and automatic doors or
devices that can pinch the hose.
CAUTION The electric drives are current limited but may still produce enough force to cause injury. To avoid
injury from a moving monitor:
• Be aware that the monitor may be remotely operated
• Keep hands and fingers away from pinch points on the monitor
• Never operate the manual override while electric controls are in operation
NOTICE
This equipment has current limiting capability which stops the motor if an obstruction is
encountered. Equipment must be installed as instructed using the correct controls and electrical
boxes. Failure to do so will result in damage to the electric motor and loss of current limiting
controls.
NOTICE
To prevent mechanical damage, do not drop or throw equipment.

©Copyright Task Force Tips LLC 2014-2021 5 LIA-208 May 19, 2021 Rev05
3.1 SPECIFICATIONS
3.1.1 MECHANICAL
Table 3.1.1
3.1.2 ELECTRICAL
Table 3.1.2
3.2 VARIOUS MODELS AND TERMS
Figure 3.2A
STANDARD METRIC
LDH Waterway Size (at valve seat) 5.25” 133 mm
LDH Valve Meets NFPA Slow Close Requirement
Maximum Operating Pressure 250 psi 17 bar
Minimum Pressure Full Vacuum
Hydrostatic Proof Test Pressure 900 psi 62 bar
Operating Temperature Range of Fluid 33° to 120°F 0° to 50°C
Storage Temperature Range* -25° to 135°F -32° to 57°C
Materials Used Aluminum 6000 series hard anodized MIL8625 class 3
type 2, stainless steel 300 series
* For temperatures below 32° (0°C), valves must be drained after use to avoid damage.
Voltage - Auto Sense 12 Volt 24 Volt
Motor Opening/Closing Speed 6 seconds
Motor Current - Nominal 3 amp 1.5 amp
Motor Current - Limit 12 amp 6 amp
Recommended Fuse Size 15 amp 7.5 amp
Environmental Rating All components designed to meet minimum rating of
NEMA 4 (IP65)
Hand Crank
Pressure Relief Valve
Air Vent & Drain
Pull Pin
Intake Elbow
Swivel Side B Coupling
Valve Position
Indicator
Outlet
Side A Coupling
AXD1ST-NX-F
Left Drive Jumbo Low Profile
Ball Intake Valve
Front Crank
with Pressure Relief Valve

©Copyright Task Force Tips LLC 2014-2021 6 LIA-208 May 19, 2021 Rev05
Figure 3.2B
Figure 3.2C
Pressure Relief Valve
Air Vent & Drain
Pull Pin
Intake Elbow
Swivel Side B Coupling
Valve Position
Indicator
Hand Crank
Outlet
Side A Coupling
AZD1ST-NX-T
Left Drive Jumbo Low Profile
Ball Intake Valve
Top Crank
with Pressure Relief Valve
Manual Override
Handwheel
Plug
Electric Motor
AXD1ST-NX-RC
Left Drive Jumbo Low Profile
Ball Intake Valve
Electrically Actuated
with Pressure Relief Valve

©Copyright Task Force Tips LLC 2014-2021 7 LIA-208 May 19, 2021 Rev05
3.3 CORROSION
Aluminum parts are hard anodized. All castings are then powder coated inside and out to help prevent corrosion. Most hose couplings
are attached using polymer bearing rings which provide electrical insulation to help prevent galvanic corrosion. The effects of corrosion
can be minimized by good maintenance practice.
3.4 USE WITH SALT WATER
Use with salt water is permissible provided the equipment is thoroughly cleaned with fresh water after each use. The service life of the
equipment may be shortened due to the effects of corrosion, and is not covered under warranty.
4.0 OVERALL DIMENSIONS
Figure 4.0A
7.2"
8.7"
5.6"
[142mm]
11.3"
[286mm]
6.8"
[172mm]
8.4"
[213mm]
7.0"
[178mm]
R3.4 [R87]
SWING
Side View
Angled Position
Side View
Down Position
12.2"
[309mm]
7.2"
[183mm]
9.4"
[240mm]
5.6"
[142mm]
R3.4 [R87]
SWING
6.8"
[172mm]
8.4"
[213mm]
7.0"
[178mm]
[183mm]
[221mm]
AXD1ST-NX-T
Left Drive Jumbo Low Profile
Ball Intake Valve
Top Crank
with Pressure Relief Valve
Top View
Angled Position
Top View
Down Position

©Copyright Task Force Tips LLC 2014-2021 8 LIA-208 May 19, 2021 Rev05
Figure 4.0B
Side View
Angled Position
Side View
Down Position
6.9"
[174mm]
6.8"
[172mm]
8.4"
[213mm]
6.9"
[174mm]
6.8"
[172mm]
8.4"
[213mm]
R3.4 [R87]
SWING
R3.4 [R87]
SWING
11.3"
[286mm]
8.7"
[221mm]
7.2"
[183mm] 5.6"
[142mm]
5.6"
[142mm]
12.2"
[309mm]
7.2"
[183mm]
9.4"
[240mm]
Top View
Angled Position
Top View
Down Position
AXE1ST-NX-T
Right Drive Jumbo Low Profile
Ball Intake Valve
Top Crank
with Pressure Relief Valve

©Copyright Task Force Tips LLC 2014-2021 9 LIA-208 May 19, 2021 Rev05
Figure 4.0C
Side View
Down Position
Side View
Angled Position
12.3"
[312mm]
5.6"
[142mm] 4.8"
[122mm]
8.7"
[221mm]
8.4"
[213mm]
6.8"
[172mm]
R3.4 [R87]
SWING
7.0"
[178mm]
5.6"
[142mm] 4.8"
[122mm]
9.4"
[240mm]
8.4"
[213mm]
6.8"
[172mm]
7.0"
[178mm]
R3.4 [R87]
SWING
Front View
Down Position
Front View
Angled Position
AXD1ST-NX-F
Left Drive Jumbo Low Profile
Ball Intake Valve
Front Crank
with Pressure Relief Valve

©Copyright Task Force Tips LLC 2014-2021 10 LIA-208 May 19, 2021 Rev05
Figure 4.0D
8.4"
[213mm]
6.8"
[172mm]
12.3"
[312mm]
5.6"
[142mm]
4.8"
[122mm]
8.7"
[221mm]
R3.4 [R87]
SWING
6.9"
[174mm]
Front View
Down Position
8.4"
[213mm]
6.8"
[172mm]
R3.4 [R87]
SWING
Front View
Angled Position
6.9"
[174mm]
4.8"
[122mm]
9.4"
[240mm]
12.3"
[312mm]
5.6"
[142mm]
Side View
Down Position
Side View
Angled Position
AXE1ST-NX-F
Right Drive Jumbo Low Profile
Ball Intake Valve
Front Crank
with Pressure Relief Valve
