INSTRUCTION FOR INSTALLATION, OPERATION, AND MAINTENANCE
Foam Aspirators
WARNING
Understand manual before use. Operation of this device without understanding the manual and
receiving proper training is a misuse of this equipment. Obtain safety information at tft.com/serial-
number.
This equipment is intended for use by trained and qualified emergency services personnel for
firefighting. All personnel using this equipment shall have completed a course of education
approved by the Authority Having Jurisdiction (AHJ).
This instruction manual is intended to familiarize firefighters and maintenance personnel with the
operation, servicing, and safety procedures associated with this product. This manual should be
kept available to all operating and maintenance personnel.
FoamJet
MX-FoamJet
MX-FoamJet
MX Foam Nozzle
FoamJet-LX
FJ-LX-MMX-FoamJet
FJ-LX-M2

©Copyright Task Force Tips LLC 1999-2020 2 LIA-025 September 2, 2020 Rev19
TABLE OF CONTENTS
1.0 MEANING OF SAFETY SIGNAL WORDS
2.0 SAFETY
3.0 GENERAL INFORMATION
4.0 FOAM TYPE, CONCENTRATION, AND PROPORTIONING
5.0 ATTACHMENT TO THE NOZZLE
6.0 USE OF FOAM ATTACHMENTS
6.1 LX FOAMJET
6.2 MX FOAMJET
7.0 USING FOAM
8.0 WARRANTY
9.0 MAINTENANCE
9.1 FIELD LUBRICATION
9.2 SERVICE TESTING
9.3 REPAIR
10.0 OPERATION AND INSPECTION CHECKLIST
DANGER
PERSONAL RESPONSIBILITY CODE
The member companies of FEMSA that provide emergency response
equipment and services want responders to know and understand the
following:
1. Fire¿ghting and Emergency Response are inherently dangerous activities
requiring proper training in their hazards and the use of extreme caution
at all times.
2. It is your responsibility to read and understand any user’s instructions,
including purpose and limitations, provided with any piece of equipment
you may be called upon to use.
3. It is your responsibility to know that you have been properly trained in
Fire¿ghting and /or Emergency Response and in the use, precautions, and
care of any equipment you may be called upon to use.
4. It is your responsibility to be in proper physical condition and to maintain
the personal skill level required to operate any equipment you may be
called upon to use.
5. It is your responsibility to know that your equipment is in operable
condition and has been maintained in accordance with the manufacturer’s
instructions.
6. Failure to follow these guidelines may result in death, burns or other
severe injury.
FEMSA
Fire and Emergency Manufacturers and Service Association
P.O. Box 147, Lynn¿eld, MA 01940 • www.FEMSA.org

©Copyright Task Force Tips LLC 1999-2020 3 LIA-025 September 2, 2020 Rev19
1.0 MEANING OF SAFETY SIGNAL WORDS
A safety related message is identified by a safety alert symbol and a signal word to indicate the level of risk involved with a particular
hazard. Per ANSI Z535.6, the definitions of the four signal words are as follows:
2.0 SAFETY
3.0 GENERAL INFORMATION
In order to produce the best quality low and medium expansion foam for firefighting, the foam solution must be aerated by some means.
The FoamJet, MX-FoamJet, and FoamJet-LX series of nozzle attachments and foam nozzles provide a simple and lightweight means to
aerate the foam as it exits the nozzle. The foam attachments are quickly attached or removed from the nozzle as the situation demands.
The attachments are available for a variety of TFT hand held & master stream nozzles. See the following pages for a listing of available
models and compatible nozzles. The label on each attachment also lists compatible nozzles.
4.0 FOAM TYPE, CONCENTRATION, AND PROPORTIONING
The FoamJet, MX-Foamjet, Foamjet-LX, and Foam Nozzle can be used with most types of concentrate including protein, fluoroprotein,
AFFF, and AR-AFFF (alcohol resistant foam).
The foam concentrate must be proportioned into the water before the nozzle by some means, such as batch mixing, eductors or direct
injection systems.
The nature of the fire hazard will determine the type of foam used, the concentration, and the desired expansion ratio. Finished foam
expansion and longevity (life) are largely dependent on the type and quality of foaming agents used in foam chemical formulations.
Some foams will perform better than others when used with these devices.
5.0 ATTACHMENT TO THE NOZZLE
The FoamJet, MX-FoamJet, and FoamJet-LX Series are attached to the nozzle by three different methods. Each of the three methods is
shown in the following pages. Each method clamps onto the bumper of the nozzle. Assure that bumper of nozzle is in good condition (no
nicks or abrasions) to positively latch and seal to FoamJet attachment.
6.0 USE OF FOAM ATTACHMENTS
Refer to fire service training and foam concentrate manufacturer’s recommendations for the proper use of foam.
6.1 LX FOAMJET
LX aspirators are intended to be used with the nozzle in the straight stream position only. Failure to do so will cause blow-back through
the air intakes of the foam attachment.
6.2 MX FOAMJET
Foam expansion ratios from the MX Foamjet series may be adjusted by changing the bumper position of the nozzle. As the nozzle
bumper is rotated back to the wide fog position, higher expansion ratios will be produced, but with reduced stream reach. Rotating the
nozzle bumper into straight stream will produce lower expansion ratios, but with longer reach.
DANGER
DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury.
WARNING
WARNING indicates a hazardous situation which, if not avoided, could result in death or serious
injury.
CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, could result in minor
or moderate injury.
NOTICE
NOTICE is used to address practices not related to physical injury.
DANGER
Lack of foam can place operator at risk of injury or death. Establish foam flow and adequate supply
of concentrate for the task before advancing into hazardous situations.
WARNING
Improper use of agent could result in death or serious injury, including damage to the eyes. To
reduce the risk of injury, avoid directing agent onto the faces of yourself and other personnel.
Always wear PPE, including eye protection, as directed by the AHJ.
WARNING
Improper use of foam or using the wrong type of foam can result in illness, injury, or damage to the
environment. Follow foam manufacturer’s instructions and fire service training as directed by the
AHJ.

©Copyright Task Force Tips LLC 1999-2020 4 LIA-025 September 2, 2020 Rev19
Series FOAMJET
Description Low Expansion Aspirating Attachment
Model FJ-DQ FJ-GD FJ-U FJ-HM FJ-H
For Nozzle Series
(Flow Range)
1” QuadraFog
5 - 40 GPM
5 - 60 GPM
1” G-Force
10 - 100 GPM
Ultimatic
10 - 125 GPM
Metro 0
20-100 GPM
Mid-Matic
Mid-Force
Metro 1
70 - 200 GPM
Handline
95 - 300 GPM
Dual-Force
95 - 300 GPM
Metro 2
95 - 325 GPM
Attachment Method
Foam Application Use in
Straight Stream
Only
Move latch to
locked position.
LOCKED UNLOCKED
Insert bumper into
attachment engaging ribs.

©Copyright Task Force Tips LLC 1999-2020 5 LIA-025 September 2, 2020 Rev19
Series MX FOAMJET
Description Multi-Expansion Foam Aspirating Attachment
Model FJ-MX-D
For Nozzle Series
(Flow Range)
Twister 1”
10 - 24 GPM
10 - 40 GPM
Attachment Method
Foam Application Use in
Straight Stream through Fog Pattern
Insert bumper into attachment
with ring unlocked.
LOCKED
UNLOCKED
PUSH
Shorter ReachFOG:
More Expansion
STRAIGHT STREAM:
Longer Reach, Less Expansion

©Copyright Task Force Tips LLC 1999-2020 6 LIA-025 September 2, 2020 Rev19
Series MX FOAMJET
Description Multi-Expansion Foam Aspirating Attachment
Model FJ-MX-F FJ-MX-DQ FJ-UMX FJ-MX-FQ FJ-MX-FT FJ-MX-HM FJ-MX-G FJ-HMX
For Nozzle Series
(Flow Range)
1.5” Twister
20-60 GPM
20-95 GPM
1” Quadrafog
5-40 GPM
5-60 GPM
Medium
Expansion
Suitable for
24,40&60
GPM
Settings
ONLY
Ultimatic
10-125 GPM
Metro 0
20-100 GPM
FJ-UMX-G
1” G-Force
10-100 GPM
1.5”
Quadrafog
30-125 GPM
Thunderfog
Series
30-200 GPM
95-250 GPM
QuadraFog
1000
110-1000
l/min
Mid-Matic
Mid-Force
Metro 1
70-200 GPM
1.5” G-Force
30-150 GPM
Handline
95-300 GPM
Dual-Force
95-300 GPM
Metro 2
95-325 GPM
Attachment Method
Foam Application
Use in
Straight Stream through Fog Pattern
LOCKEDUNLOCKED
Insert bumper
with latch unlocked.
Push levers down
to lock in place.
FOG: Shorter Reach
More Expansion
STRAIGHT STREAM:
Longer Reach, Less Expansion

©Copyright Task Force Tips LLC 1999-2020 7 LIA-025 September 2, 2020 Rev19
Series FOAMJET-LX
Description Low Expansion Foam Aspirating Attachment
Model FJ-LX-U FJ-LX-G FJ-LX-FQ FJ-LX-HM FJ-LX-M FJ-LX-M2
For Nozzle Series
(Flow Range)
Ultimatic
10-125 GPM
Metro 0
20-100 GPM
FJ-LX-U-G
1” G-Force
10-100 GPM
1.5” G-Force
30-150 GPM
1.5” Quadrafog
30-125 GPM
Mid-Matic
Mid-Force
Metro 1
70-200 GPM
Master Stream
1000, 1250S
and
Master Foam
250-750 GPM
(946-2839 l/min)
series nozzles
M-F* series
Master Stream
nozzles
Attachment Method
Foam Application Use in
Straight Stream
Only
2
1
Insert bumper into attachment
with latches unlocked
Align latches between
bumper ribs
3Lock all latches
Unlocked Locked

©Copyright Task Force Tips LLC 1999-2020 8 LIA-025 September 2, 2020 Rev19
Series MX FOAMJET
Description Low Expansion Foam Aspirating Attachment
Model FJ-MX-MD
For Nozzle Series
(Flow Range)
MD Series: 100-500 GPM (Max-Force, Max-Matic, Max-Flow)
ZN Series: 350, 500 & 750 GPM Industrial Nozzle
Attachment Method
Foam Application Use in
Straight Stream through Fog Pattern
LOCKEDUNLOCKED
Insert bumper
with latch unlocked.
Push levers down
to lock in place.
FOG: Shorter Reach
More Expansion
STRAIGHT STREAM:
Longer Reach, Less Expansion

©Copyright Task Force Tips LLC 1999-2020 9 LIA-025 September 2, 2020 Rev19
7.0 USING FOAM
It is recommended that the Class A foam used meets USDA Forest Service 5100-307A “Specification for Fire Suppressant Foam for
Wildland Firefighting (Class A Foam)”, or NFPA 1150 “Foam Chemicals for Fires in Class A Fuels”.
Series MX FOAMJET NOZZLE
Description Medium Expansion Foam Nozzle
Model FJ-MX-060 FJ-MX-095 FJ-MX-125
For Nozzle Series
(Flow Range)
60 GPM @ 60 PSI
225 l/min @ 4 bar
95 GPM @ 60 PSI
360 l/min @ 4 bar
125 GPM @ 60 PSI
475 l/min @ 4 bar
Attachment Method
Foam Application Full Open Valve
Straight Hose Line
WARNING
Improper use of foam or using the wrong type of foam can result in illness, injury, or damage to the
environment. Follow foam manufacturer’s instructions and fire service training as directed by the
AHJ.
WARNING
For Class B fires, lack of foam or interruption in the foam stream can cause a break in the foam
blanket and greatly increase the risk of injury or death. Follow procedures established by the AHJ
for the specific fuel and conditions.
Ball Valve
Not Included

©Copyright Task Force Tips LLC 1999-2020 10 LIA-025 September 2, 2020 Rev19
8.0 WARRANTY
Task Force Tips LLC, 3701 Innovation Way, Valparaiso, Indiana 46383-9327 USA (“TFT”) warrants to the original purchaser of its
products (“equipment”), and to anyone to whom it is transferred, that the equipment shall be free from defects in material and
workmanship during the five (5) year period from the date of purchase. TFT’s obligation under this warranty is specifically limited to
replacing or repairing the equipment (or its parts) which are shown by TFT’s examination to be in a defective condition attributable to
TFT. To qualify for this limited warranty, the claimant must return the equipment to TFT, at 3701 Innovation Way, Valparaiso, Indiana
46383-9327 USA, within a reasonable time after discovery of the defect. TFT will examine the equipment. If TFT determines that there is
a defect attributable to it, TFT will correct the problem within a reasonable time. If the equipment is covered by this limited warranty, TFT
will assume the expenses of repair.
If any defect attributable to TFT under this limited warranty cannot be reasonably cured by repair or replacement, TFT may elect to
refund the purchase price of the equipment, less reasonable depreciation, in complete discharge of its obligations under this limited
warranty. If TFT makes this election, claimant shall return the equipment to TFT free and clear of any liens and encumbrances.
This is a limited warranty. The original purchaser of the equipment, any person to whom it is transferred, and any person who is an
intended or unintended beneficiary of the equipment, shall not be entitled to recover from TFT any consequential or incidental damages
for injury to person and/or property resulting from any defective equipment manufactured or assembled by TFT.
It is agreed and understood that the price stated for the equipment is in part consideration for limiting TFT’s liability. Some states do not
allow the exclusion or limitation of incidental or consequential damages, so the above may not apply to you.
TFT shall have no obligation under this limited warranty if the equipment is, or has been, misused or neglected (including failure to
provide reasonable maintenance) or if there have been accidents to the equipment or if it has been repaired or altered by someone else.
THIS IS A LIMITED EXPRESS WARRANTY ONLY. TFT EXPRESSLY DISCLAIMS WITH RESPECT TO THE EQUIPMENT ALL
IMPLIED WARRANTIES OF MERCHANTABILITY AND ALL IMPLIED WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE.
THERE IS NO WARRANTY OF ANY NATURE MADE BY TFT BEYOND THAT STATED IN THIS DOCUMENT.
This limited warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

©Copyright Task Force Tips LLC 1999-2020 11 LIA-025 September 2, 2020 Rev19
9.0 MAINTENANCE
TFT products are designed and manufactured to be damage resistant and require minimal maintenance. However, as the primary
firefighting tool upon which your life depends, it should be treated accordingly. To help prevent mechanical damage, do not drop or throw
equipment.
9.1 FIELD LUBRICATION
All Task Force Tips nozzles are factory lubricated with high quality silicone grease. This lubricant has excellent wash out resistance,
providing long term performance in firefighting nozzles. If your department has unusually hard or sandy water, the moving parts of the
nozzle may be affected. Foam agents and water additives contain soaps and chemicals that may break down the factory lubrication.
The moving parts of the nozzle should be checked on a regular basis for smooth and free operation, and for signs of damage. IF THE
NOZZLE IS OPERATING CORRECTLY, THEN NO ADDITIONAL LUBRICANT IS NEEDED. Any nozzle that is not operating correctly
should be immediately removed from service. The nozzle can be returned to the factory at any time for a complete checkup and re-
lubrication with silicone grease.
The field use of Break Free CLP (spray or liquid) lubricant will help to temporarily restore the smooth and free operation of the nozzle.
These lubricants do not have the washout resistance and long-term performance of the silicone grease. Once Break Free CLP is
applied, re-application will be needed on a regular basis until the nozzle can be returned to the factory for a complete checkup and re-
lubrication with silicone grease.
9.2 SERVICE TESTING
In accordance with NFPA 1962, equipment must be tested a minimum of annually. Units failing any part of this test must be removed
from service, repaired and retested upon completion of the repair.
9.3 REPAIR
Factory service is available with repair time seldom exceeding one day in our facility. Factory serviced equipment is repaired by
experienced technicians, wet tested to original specifications, and promptly returned. Repair charges for non-warranty items are
minimal. Any returns should include a note as to the nature of the problem and whom to reach in case of questions.
Repair parts and service procedures are available for those wishing to perform their own repairs. Task Force Tips assumes no liability for
damage to equipment or injury to personnel that is a result of user service. Contact the factory or visit the web site at tft.com for parts
lists, exploded views, test procedures and troubleshooting guides.
Performance tests shall be conducted on the equipment after a repair, or anytime a problem is reported to verify operation in accordance
with TFT test procedures. Consult factory for the procedure that corresponds to the model and serial number of the equipment. Any
equipment which fails the related test criteria should be removed from service immediately. Troubleshooting guides are available with
each test procedure or equipment can be returned to the factory for service and testing.
CAUTION Aerosol lubricants contain solvents that can swell O-Rings if applied in excess. The swelling can
inhibit smooth operation of the moving parts. When used in moderation, as directed, the solvents
quickly evaporate without adversely swelling the O-Rings.
CAUTION Any alterations to the product or its markings could diminish safety and constitutes a misuse of
this product.
NOTICE
All replacement parts must be obtained from the manufacturer to assure proper operation of the
device.

©Copyright Task Force Tips LLC 1999-2020 12 LIA-025 September 2, 2020 Rev19
TASK FORCE TIPS LLC
MADE IN USA · tft.com
3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 · 219-462-6161 · Fax [phone]
10.0 OPERATION AND INSPECTION CHECKLIST
BEFORE EACH USE, appliances must be inspected to this checklist:
• There is no obvious damage such as missing, broken or loose parts, dents cracks, corrosion, or other defects that could impair safe
operation.
• Clamps and mounted objects are secure.
• Hose and nozzle are securely attached.
• All swiveling elements rotate freely.
• Foamjet is pointed in a safe direction.
BEFORE BEING PLACED BACK IN SERVICE, appliances must be inspected to this list:
• The waterway is clear of obstructions.
• There is no damage to any connections.
• All locks and hold-down devices work properly.
• There is no obvious damage such as missing, broken or loose parts, dents cracks, corrosion, or other defects that could impair safe
operation.
• All swiveling elements rotate freely.
• There are no missing parts or components.
WARNING
Equipment failing any part of the checklist is unsafe for use and must have the problem corrected
before use or being placed back into service. Operating equipment that has failed the checklist is a
misuse of this equipment.
