G-Force
WIRELESS MONITOR OPERATOR STATION
Instruction for Installation of
Radio Board and Antenna for YE-RF-RAD-##
WARNING
Service technicians bear responsibility for ensuring use of appropriate protective clothing and
equipment. The chosen protective clothing and equipment must provide protection from potential
hazards users may encounter while servicing equipment. Requirements for protective clothing and
equipment are determined by the Authority Having Jurisdiction (AHJ).
NOTICE
Circuit boards are Electrostatic Sensitive Devices.
To prevent damage:
• Disconnect power before servicing equipment.
• Use proper grounding techniques.
• Touch unpainted, exposed metal on monitor or fire truck
before removing and handling circuit boards.
ATTENTION
OBSERVE PRECAUTIONS
FOR HANDLING
ELECTROSTATIC
SENSITIVE
DEVICES
YE-RF-## YE-RF-##-D

©Copyright Task Force Tips LLC 2007-2021 2 LIY-410 May 28, 2021 Rev06
1.0 RADIO INSTALLATION
STEP 1
Unscrew the lid screws using 3mm hex
key. Do not remove the screws from the
lid.
Open the lid slowly as it is connected to
the communication board by a flat cable.
Securely support the lid during the
installation process.
STEP 2
Locate the connector with blue & white
wires on the communication board (far
left).
STEP 3
Unplug the connector with blue & white
wires from the communication board.
STEP 4
Remove the communication board by
pulling it straight out.
STEP 5
Remove the nut and hex plug from the
side of the monitor control box.
STEP 6
Ensure the O-ring is in the groove on the
antenna base.
Apply Loctite® #271 (red) Thread Locking
Adhesive to the threads on the antenna
base.
Feed the antenna connector through the
hole in the monitor control box and tighten
the antenna base and nut.

©Copyright Task Force Tips LLC 2007-2021 3 LIY-410 May 28, 2021 Rev06
NOTICE
• Do not pinch any wires between the lid and box.
• Ensure rubber O-ring seal for lid is clean, undamaged, and properly placed in the groove prior to
securing the lid.
STEP 7
Connect the radio board to the
communication board by aligning pin
holes and pushing firmly.
STEP 8
Attach the antenna connector to the radio
board in the orientation shown.
• In some cases, a cable tie may need
to be cut to attach the antenna.
STEP 9
Reinstall the communication/radio board
assembly into the monitor control box.
Press straight in to seat firmly.
1
2
3
4
STEP 10
Plug the connector with the blue & white
wires into the communication/radio board
assembly.
Route antenna wire alongside the board.
STEP 11
Replace the lid. Be sure to guide the flat
cable across the motor boards.
STEP 12
Firmly tighten screws equally in a criss-
cross pattern.

©Copyright Task Force Tips LLC 2007-2021 4 LIY-410 May 28, 2021 Rev06
TASK FORCE TIPS LLC
MADE IN USA · tft.com
3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 · 219-462-6161 · Fax [phone]
2.0 TEACHING ID CODE
Every monitor has a unique ID code that must be “taught or transferred” to the wireless handheld unit. This unique ID code allows
multiple monitors to be used in one location without interference. Perform the following procedure to teach the handheld unit:
On Wireless Handheld Unit without Display:
1. Press POWER button to turn on electronics.
2. Press and hold both LEFT & RIGHT buttons simultaneously for 5 seconds.
3. Continue to hold the LEFT & RIGHT buttons and then press UP button for 2 seconds.
4. Release buttons.
5. After several seconds, the OSC & PARK lights will flash rapidly to indicate that the unit is in teach mode.
On Wireless Handheld Unit with Display:
1. Enter configuration mode by pressing center MENU button for 5 seconds
2. Press & release MENU button until RFID LEARN is displayed above LEFT button
3. Press & release RFID LEARN button. Radio will configure and wait for ID code
On Monitor Control Box:
1. Apply power to monitor.
2. Press and hold both LEFT & RIGHT buttons simultaneously for 5 seconds.
3. Continue to HOLD the LEFT & RIGHT buttons and then press UP button for 2 seconds.
4. Release buttons.
5. After several seconds, the OSC & PARK lights will flash rapidly to indicate that the unit is in teach mode.
ID code is automatically transferred to the wireless handheld unit.
1. OSC & PARK lights on handheld unit will stop flashing after ID code is transferred.
2. Press DOWN button on monitor control box to exit teach mode.
3. Cycle power off and back on to monitor.
In the event the handheld unit does not link up with the monitor, perform the following at the monitor operator station and the
handheld unit:
1. Turn off power.
2. Press and hold DOWN button.
3. Apply power to the monitor, continue to hold DOWN button for 3 seconds.
4. Release DOWN button.
5. After green POWER light stops blinking, test wireless handheld unit.
6. Repeat above procedure for “Teaching ID Code”.
3.0 CHANGING BATTERIES IN WIRELESS HANDHELD UNITS
1. Remove two (2) screws on backside of the handheld unit and slide bottom half of the rubber bumper off the enclosure.
2. Replace four (AA) batteries, Lithium Recommended, verifying that polarity is correct.
3. Replace the rubber bumper and retaining screws.
For questions or assistance with this procedure, contact the TFT Customer Service Team.
NOTICE
• When the operator station and RC Monitor are purchased at the same time, the handheld unit
will be pre-taught at factory.
• If the monitor is mounted to an RC Extend-A-Gun, ensure the Extend-A-Gun is in the raised
position.
• Before teaching, monitor should be powered down.
• If multiple monitors are present, to avoid possible conflicts, apply power only to the monitor
being taught.
NOTICE
• Do not mix battery types.
• Properly dispose of old batteries.
• Do not puncture, incinerate, or disassemble batteries.
