DoorProtect User Manual
DoorProtect is a wireless door and window opening detector designed for use inside premises.
It can operate up to 7 years from a pre-installed battery and is furnished with a sealed contact
reed relay processing more than one million openings. It has a socket for connecting an
external detector.
Sealed contact reed relay is a device which forms a continuous circuit under the effect of
a constant magnet. It consists of ferromagnetic contacts placed in a bulb.
DoorProtect operates within the Ajax security system, by connecting via the protected Jeweller
protocol to the Hub. Communication range - up to 1,200 m, absent any obstacles. In addition,
the detector can be used as part of third-party security central units due to the uartBridge or
ocBridge Plus integration module.
The detector is set up via a mobile application for iOS and Android-based smartphones. The
user is notified of all events through push notifications, SMS messages and calls (if activated).
The Ajax security system is self-sustaining, but the user can connect it to the central monitoring
station of a private security company.
👉Buy opening detector DoorProtect

TH COMMUNICATION SDN BHD www.thcomm.com.my [e-mail]
Functional elements
1. DoorProtect
2. Big magnet
3. Small magnet
4. Light indicator
5. SmartBracket attachment panel (perforated part is required for actuating the tamper in case
of any attempt to tear off the detector from the surface. Don't break it out!)
6. External detector connection socket
7. QR code
8. Device switch
9. Tamper button
DoorProtect Operating Principle
DoorProtect consists of two parts: the detector with a sealed contact reed relay, and a constant
magnet. The detector is attached to a frame and the magnet - to a moving wing or sliding part. If
the sealed contact reed relay is within the coverage area of the magnetic field, it closes the
circuit - the detector is closed. The opening of the wing distances the magnet from the sealed
contact reed relay, resulting in the circuit opening, and the detector records opening.
A small magnet acts at a distance of 1 cm, and the big - up to 2 cm.
After actuation, the DoorProtect detector set in the intrusion detection mode immediately
transmits an alarm signal to the Ajax Hub, activating the sirens connected to the hub and
notifying the user and private security company.
Connecting the Detector to the Ajax Security System
Detector Connection to Hub

TH COMMUNICATION SDN BHD www.thcomm.com.my [e-mail]
Before starting connection:
Following the Hub instruction recommendations, install the Ajax application on your
smartphone. Create an account, add the Hub to the application, and create at least one
room.
Go to the Ajax application.
Switch on the Hub and check the internet connection (via Ethernet cable and/or GSM
network).
Ensure that the Hub is disarmed and does not start updates by checking its status in the
mobile application.
⚠️Only users with administrative privileges can add the device to the hub.
How to connect the detector to the Hub:
1. Select the Add Device option in the Ajax application.
2. Name the device, scan/write manually the QR Code (located on the body and packaging),
and select the location room.
3. Select Add —the countdown will begin.

TH COMMUNICATION SDN BHD www.thcomm.com.my [e-mail]
4. Switch on the device
For the detection and interfacing to occur, the detector should be located within the
coverage area of the wireless network of the Hub (at a single protected object). Request
for connection to the hub is transmitted for a short time at the time of switching on the
device.
If the connection to the Ajax Hub failed, switch off the detector for 5 seconds and repeat the
attempt.
The detector connected to the hub will appear in the list of devices of the hub in the application.
Update of the detector statuses in the list depends on the device inquiry time set in the hub
settings, with the default value - 36 seconds.
Connecting the Detector to Third Party Security Systems
To connect the detector to a third party security central unit using the Ajax uartBridge or Ajax
ocBridge Plus integration module, follow the recommendations in the manual of the respective
device.
States
Devices → DoorProtect

TH COMMUNICATION SDN BHD www.thcomm.com.my [e-mail]
Parameter
Value
Temperature
Temperature of the Detector. This is measured on the processor and
changes gradually
Signal Strength
Signal strength between the hub and the detector
Battery Charge
Battery level of the detector, displayed in increments of 25%
Lid
The tamper mode of the detector, which reacts to the detachment of or
damage to the body
Delay when entering,
sec
Delay time when entering

TH COMMUNICATION SDN BHD www.thcomm.com.my [e-mail]
Delay when leaving,
sec
Delay time when exiting
Connection
Connection status between the hub and the detector
Primary Detector
Primary detector status
Secondary detector
Status of the external detector connected to DoorProtect
Always active
If active, the detector is always in the armed mode
Firmware
Detector firmware version
Device ID
Device identifier
Setting Up the Detector
Devices → DoorProtect → ⚙️

TH COMMUNICATION SDN BHD www.thcomm.com.my [e-mail]
Setting
Value
First field
Detector name, can be edited
Room
Selecting the virtual room to which the device is assigned
Primary Detector
If active, the DoorProtect primary detector reacts to opening/closing
External contact enabled
If active, the detector registers external detector alarms
Always active
If active, the detector always registers opening/closing
Delay when entering, sec
Selecting delay time when entering
Delay when leaving, sec
Selecting delay time on exit
Delays in night mode
Delay turned on when using night mode
Arm in night mode
If active, the detector will switch to armed mode when using night
mode
Alert with a siren if opening
detected
If active, HomeSiren and StreetSiren are activated when the opening
detected
Activate the siren if an additional
contact is open
If active, HomeSiren and StreetSiren are activated during an external
detector alarm
Signal Strength Test
Switches the detector to the signal strength test mode
Detection Zone Test
Switches the detector to the detection area test
Attenuation Test
Switches the detector to the signal fade test mode (available in
detectors with firmware version 3.50 and later)
User Guide
Opens the detector User Guide
Unpair Device
Disconnects the detector from the Hub and deletes its settings
Indication
Event
Indication
Note
Turning on the detector
Lights up green for about one
second
Detector connection to the
Hub, ocBridge, and
uartBridge
Lights up continuously for a
few seconds
Alarm / tamper activation
Lights up green for about one
second
Alarm is sent once in 5 seconds

TH COMMUNICATION SDN BHD www.thcomm.com.my [e-mail]
Battery needs replacing
During the alarm, it slowly
lights up green and slowly goes
out
Replacement of the detector battery is
described in the Battery Replacement
paragraph
Performance testing
The Ajax security system allows conducting tests for checking the functionality of connected
devices.
The tests do not start straight away but within a period of 36 seconds when using the standard
settings. The test time start depends on the settings of the detector scanning period (the
paragraph on “Jeweller” settings in Hub settings).
Signal Strength Test
Detection Area Test
Attenuation Test
Installing the device
Selecting an installation location
Location of the DoorProtect detector determines its remoteness from the Hub and the presence
of any obstacles between the devices hindering the radio signal transmission: walls, inserted
floors, large-size objects located within the room.
Check the signal level at the installation location.
If the signal level is one division, we cannot guarantee stable operation of the security system.
Take possible measures to improve the quality of the signal! As a minimum, move the device -
even 20 cm shift can significantly improve the quality of reception.
If, after moving, the device still has a low or unstable signal strength, use a radio signal range
extender ReX.
The detector is located either inside or outside the door case (window frame).
When installing the detector in the perpendicular planes (inside the case/frame), use the small
magnet from the set. The distance between the magnet and detector should not exceed 1 cm.
When positioning the parts of DoorProtect in the same plane, use the big magnet. Its actuation
threshold - 2 cm.
The magnet is attached to the moving part of the door (window) to the right of the detector. If
necessary, the detector may be overturned or positioned horizontally.

TH COMMUNICATION SDN BHD www.thcomm.com.my [e-mail]
The installing the sensor
Before installing the detector, make sure that you have selected the optimal location and it is in
compliance with the guidelines contained in this manual!
1. Fix the SmartBracket attachment panels of the detector and magnet using bundled screws.
If using any other attachment hardware, make sure that they do not damage or deform the
panel.
The double-sided adhesive tape may be only used for temporary attachment of the detector
and magnet. The tape will run dry in course of time, which may result in falling of
DoorProtect and actuation of the security system. Furthermore, the device may fail from a
hit.
2. Put the detector on the attachment panel. As soon as the detector is fixed in SmartBracket, it
will blink with a LED - this will be a signal that the tamper on the detector is closed. If the
light indicator of the detector is not actuated after installation in SmartBracket, check the

TH COMMUNICATION SDN BHD www.thcomm.com.my [e-mail]
status of the tamper in the Ajax Security System application and then the fixing tightness of
the panel.
If the detector is torn off from the surface or removed from the attachment panel, you will
receive the notification.
3. Put the magnet on the attachment panel.
Do not install the detector:
outside the premises (outdoors)
nearby any metal objects or mirrors causing attenuation and screening of the signal
within any premises with the temperature and humidity beyond the range of permissible
limits
Connecting a Wire Detector
A wire detector with an NC type contact may be connected to the DoorProtect using an outside-
mounted terminal clamp.
We recommend to install the wire detector at a distance not exceeding 1 meter - increasing the
wire length will increase the risk of its damage and reduce the quality of communication
between the detectors.
To lead out the wire from the detector body, break out the plug:

TH COMMUNICATION SDN BHD www.thcomm.com.my [e-mail]
If the external detector is actuated, you will receive the notification.
Detector Maintenance and Battery Replacement
Check the operational capability of the DoorProtect detector on a regular basis.
Clean the detector body from dust, spider web and other contaminations as they appear. Use
soft dry napkin suitable for equipment maintenance.
Do not use for cleaning the detector any substances containing alcohol, acetone, gasoline and
other active solvents.
The service life of the detector from the battery depends on battery quality, the actuation
frequency of the detector and inquiry interval of the detectors by the Hub.
If the door opens 10 times a day and the detector inquiry interval is set at 60 seconds, then
DoorProtect will operate 7 years from the pre-installed battery. You will reduce the service life of
the device to 2 years by setting the inquiry interval at 12 seconds.
If the detector battery is discharged, the user will receive a notice, and the LED will smoothly
light up and go out if the detector or tamper is actuated.
󱃤Battery Replacement
Tech specs
Sensor
Sealed contact reed relay
Detector actuation threshold
1 cm (small magnet)
2 cm (big magnet)

TH COMMUNICATION SDN BHD www.thcomm.com.my [e-mail]
Tamper protection
Yes
Socket for connecting wire
detectors
Yes, NC
Frequency band
868.0 –868.6 MHz or 868.7 –869.2 MHz depending on the region of
sale
Maximum RF output power
Up to 20 mW
Modulation
GFSK
Radio signal range
Up to 1,200 m (any obstacles absent)
Power supply
1 battery CR123A, 3 V
Battery life
Up to 7 years
Operating temperature range
From -10°С to +40°С
Operating humidity
Up to 75%
Dimensions
Ø 20 х 90 mm
Weight
29 g
Complete Set
1. DoorProtect
2. Battery CR123A (pre-installed)
3. Big magnet
4. Small magnet
5. Outside-mounted terminal clamp
6. Installation kit
7. Quick Start Guide
Warranty
Warranty for the “AJAX SYSTEMS MANUFACTURING” LIMITED LIABILITY COMPANY
products is valid for 2 years after the purchase and does not apply to the pre-installed battery.
If the device does not work correctly, you should first contact the support service —in half of the
cases, technical issues can be solved remotely!
