The Handy THSHWCS User manual

02/03/2020 –V5
SAW HORSE WITH
CHAINSAW SUPPORT
MODEL NO: THSHWCS -- PRODUCT NO: 1938101001
EN - ORIGINAL INSTRUCTIONS
ASSEMBLY REQUIRED - MINIMUM TWO PERSONS
SAVE THESE INSTRUCTIONS
SPARES & SUPPORT: 01793 333212
FOR YOUR SAFETY
Please read & understand this manual, paying attention to the safety instructions, before use.
Incorrect use of the product could put the operator or machine in danger.
Whilst every effort has been made to ensure the accuracy of information contained in this manual, our policy
of continuous improvement determines the right to make modifications without prior warning.
Images used are for illustration purposes only
INSTRUCTION MANUAL

Copyright Notice
Copyright © Handy Distribution
Permission is granted to reproduce this publication for personal & educational use only.
Commercial copying, redistribution, hiring or lending is prohibited.
No part of this publication may be stored in a retrieval system or transmitted in any other form or means without written
permission from Handy Distribution.
In all cases this copyright notice must remain intact.

CONTENTS
SPECIFICATIONS
IMPORTANT INFORMATION
GENERAL SAFETY INSTRUCTIONS
SET UP & PREPARATION FOR OPERATION
ASSEMBLY
OPERATION
MAINTENANCE & STORAGE
TRANSPORT
TROUBLESHOOTING
PARTS DIAGRAM & LIST
WARRANTY
ASSEMBLY IS REQUIRED - TWO PERSONS
•This product requires assembly before use.
•See “Assembly”section for instructions.
•Because of the weight and/or size of the machine, it is recommended that another adult be present to
assist with the assembly.
•Inspect all components closely upon receipt to make sure no items are missing or damaged.
IF YOU REQUIRE ASSISTANCE WITH REGARDS TO THE CONTENTS OR OPERATION OF THE MACHINE, PLEASE
CONTACT US:
TEL: [phone]
EMAIL: [e-mail]
OPENING HOURS WEEKDAYS: FEB TO OCT 8:30AM - 5:30PM / NOV TO JAN 8:30AM - 5:00PM
SPECIFICATIONS
The manufacturer reserves the right to change the product specification and livery according to continued
product improvements.
Model Number
THSHWCS
Product Number
1938101001
Assembled Dimensions
H-870 x W-710 x L-1095mm
Max. Bar Length
45cm (18”)
Max. Log Diameter
25cm
Max. Weight Capacity
120kg
Max. Long Length
1.8m
Material
Steel
Weight
G.W 11.55kg - N.W 9.5kg
IMPORTANT INFORMATION
INTENDED USAGE
The Saw Horse with Chainsaw Support is designed for use with domestic Chainsaws in private gardens with a
working chain-bar length of no more than 18 inches (45cm). It is the user’s responsibility to ensure that the
THSHWCS is compatible with your chosen chainsaw. Check with chainsaw manufacturer for compatibility.
For use in private gardens, but not in public facilities, parks or sports grounds and not for agricultural or
forestry use. Generally acknowledged accident prevention regulations and enclosed safety instructions must be
observed. Only perform work described in these instructions for use, any other use is incorrect. The
manufacturer will not assume responsibility for damage resulting from such use.

WARNING!
Read this instruction manual carefully before operation. Make sure that you are familiar with the controls
and properly operate the machine. Following these instructions can reduce the risk of personal injury.
IF NOT USED PROPERLY THIS MACHINE CAN BE DANGEROUS!
This machine can cause serious injury to the operator and others, the warning and safety instructions must be
followed to ensure reasonable safety and efficiency in using this product. The operator is responsible for
following the warning and safety instructions in this manual and on the machine. Never use the product unless
the components are correctly positioned and operational.
TRAINING
Read the instructions carefully: Be familiar with the controls and the proper use of the equipment. Never allow
children or people unfamiliar with these instructions to use the product. Local regulations can restrict the age
of the operator. Keep in mind that the operator or user is responsible for accidents or hazards involving the
machine that occur to other people or their property.
GENERAL SAFETY INSTRUCTIONS
It is important that you read and understand the owner’s manual and labels affixed to the machine. Learn its
application and limitations as well as the specific potential hazards. Retain these instructions for future
reference. The operator is responsible for following the warnings & instructions in this manual and on the
product.
Read & understand the
instruction manuals for the
table and log splitter used
with it before operating.
Failure to follow instructions
could result in death or
serious injury.
DANGER
Risk of Slicing.
Keep hands out of the way of all
moving parts of the log splitter.
Always non-skid safety
shoes, to protect against
falling logs.
Keep bystanders away
Wear protective gloves to
protect your hands
Always wear eye protection and
stout shoes while operating the
machine
Keep guards in place and in
working order. Replace
damaged, missing or failed
parts before using it.
Safety alert symbol. Used to alert
you to potential personal injury
hazards. Obey all safety messages
that follow this symbol to avoid
possible injury.
DANGER
Indicates an imminently
hazardous situation which, if
not avoided, will result in
serious injury.
WARNING
Indicates a potentially hazardous
situation which, if not avoided,
could result in serious injury
CAUTION
Indicates a potentially
hazardous situation which, if
not avoided, may result in
minor or moderate injury.
CAUTION
Used without the safety alert
symbol indicates a potentially
hazardous situation which, if not
avoided, may result in property
damage.

STAY ALERT
Do not use whilst under the influence of drugs, alcohol, or any medication that could affect your ability to use
it properly. Do not use this machine when you are tired or distracted from the job at hand. Always be aware of
what you are doing. Use common sense.
SMALL COMPONENTS
Contains small components that could be a choking hazard if swallowed. Keep these items away from children.
EVENLY DISTRIBUTE YOUR LOAD
Always distribute load evenly over surface of the table, do not exceed maximum weight limit of 120kg.
USERS, BYSTANDERS AND CHILDREN
Do not allow anyone to sit, stand or lay on the saw horse. Do not allow children to play on, stand upon or climb
on the saw horse. Never allow children or people unfamiliar with these instructions to use the saw horse. Local
regulations can restrict the age of the operator. Keep unauthorised persons a safe distance away from the
machine (a minimum of 10 metres) when in use with a chainsaw. If approached, stop the chainsaw
immediately.
AVOID DANGEROUS CONDITIONS
Work in daylight or in good artificial light; always be sure of your footing. Never operate on uneven surfaces
and use extreme caution when reversing or pulling the machine towards you; do not put hands or feet near or
under rotating or moving parts.
INSPECT YOUR MACHINE
Check all screws, bolts, nuts, and washers for tightness before each use, especially those securing. Vibration
during use, may cause these to loosen. Form a habit of checking to see that all other tools/equipment are
removed from the working area before operating. Replace damaged, missing or failed parts before using.
Warning labels carry important information. Replace any missing or damaged warning labels.
DRESS PROPERLY
Be careful of loose clothing and other accessories (watches, necklaces etc.) which can be caught in moving
parts. Long trousers are advisable. Always wear substantial non slip protective footwear when operating.
Never operate barefoot or when wearing sandals. Wear a face or dust mask if the operation is dusty. Wear
protective hair covering to contain long hair, preventing it from getting caught in machinery. Eye & ear
protection is also a requirement, along with protective gloves for your hands.
DO NOT OVERREACH
Serious injury could occur if the machine is tipped or if moving parts are unintentionally contacted. Do not
store anything above or near the machine, where anyone might stand on the machine to reach them.
DO NOT FORCE TOOL
Always work within the rated capacity. Do not use machine for a purpose for which it was not intended.
INSPECT
Before using, always visually inspect to see that the machine is not worn or damaged. Replace worn or
damaged elements and bolts in sets, to preserve balance.
MAINTAIN YOUR MACHINE WITH CARE
Clean immediately after use. Keep clean to ensure it operates to its full and safest performance. When
maintaining, only the manufacturer’s original replacement parts should be used. The use of non-original
manufacturer parts may invalidate your warranty.
PROTECT THE ENVIRONMENT
Take left over materials to an authorised collection point or follow the stipulations in the country where the
machine is used. Do not discharge into drains, soil or water.
STORE IDLE EQUIPMENT
When not in use, the machine should be stored in a dry location. Keep the machine away from children and
others not qualified to use it. Keep away from direct sunlight.

SET UP & PREPARATION FOR OPERATION
This product must be assembled correctly before use. Carefully remove the components and any accessories
from the carton. Inspect carefully to make sure there are no breakages or missing items during shipping. Do
not discard the packing material & carton until you have carefully inspected & satisfactorily operated the
product.
IF YOU REQUIRE ASSISTANCE WITH REGARDS TO THE CONTENTS OR OPERATION OF THE MACHINE, PLEASE
CONTACT US:
TEL: [phone]
EMAIL: [e-mail]
OPENING HOURS WEEKDAYS: FEB TO OCT 8:30AM - 5:30PM / NOV TO JAN 8:30AM - 5:00PM
1. 8x 8x30mm Bolt
2. 8x 8x35mm Bolt
3. 3x 8x45mm Bolt
4. 1x 8x70mm Bolt
5. 1x 10x20mm Bolt
6. 6x 8x12mm Bolt
7. 1x 3mm R-clip
8. Leg Plug
9. 17x M8 Lock Nut
10. 1x 20x30mm Eye Bolt
11. 1x 10x20mm Eye Bolt
12. 2x 16mm End Caps
13. 1x 8mm Washer
1
2
3
4
5
6
7
8
9
11
10
12
13
Allen Key

WARNING
If any parts are damaged or missing do not operate this product until the parts are replaced. Failure to heed
this warning could result in serious personal injury.
Do not attempt to modify this product or create accessories not recommended for use with this product. Any
such alteration or modification is misuse and could result in a hazardous condition leading to possible
serious personal injury.
Read and follow all instructions for assembly and operation. Failure to correctly assemble this equipment
could result in serious injury to the user or bystanders, or cause equipment damage.
ASSEMBLY
DANGER
It is recommended that safety gloves are used during the assembly of this item.
SCHEMATIC DRAWING
The Saw Horse is supplied with Nylock Nuts. They are designed with a blue nylon collar, which has a slightly
smaller diameter to the bolt. The collar deforms elastically over the threads of the screw, but threads are
not cut into the nylon. The nylon collar locks the nut by applying a compressive force against the bolt. This
therefore requires increased pressure when assembling.

All numbers listed in brackets () throughout the below assembly steps are the taken from the parts list, which
is located towards the back of this instruction manual.
Attach the feet to the four (2x short, 2x long) legs,
using 8x35mm Bolts (2) & M8 Lock Nuts (9).
Attach the Leg Brace (22) to the inside of the Long
Legs, ensuring the adjustment slot is located on the
outside of the Long Legs (18 & 23) using 8x30mm
Bolt (1) & M8 Nut (9).
Repeat the same action to the Short Legs (20 & 24).
Attach the two Short Legs to the two Long Legs
bottom fixing hole, ensuring the L-shape at the top
of the Short Leg is positioned on the outside of the
Long Leg. Secure using 8x35mm Bolt (2) & M8 Nut
(9).

Secure Bed 1 (17) to the inside of the two Long Legs,
using six 8x12mm Hex Bolts (6) using an Allen Key,
securing from the underside of the Bed, into the
welded nuts on the Long Legs.
Secure Bed 2 (19) to the Long Leg, using 8x45mm
Bolt (3) and M8 Nut (9), into the upper hole of the
two located in the leg. The L-shape on the Bed,
should sit on the outside of the leg.
Position the Pivot Clamp Holder (16) into the right-
hand Long Leg and secure with the Rod/Handle
Eyelet (26) using 10x20mm Bolt (5) & M8 Washer.
Place the long section of the Measuring Rod (25)
through the Handle Eyelet and secure with the
10x20mm Eyelet Bolt (11).

Place the Pivot Clamp (15) onto the Pivot Clamp
Holder (16), ensuring the eye bolt is located on the
outside of the table. Secure with the 3mm R-Clip (7).
Insert 20x30mm Eyelet Bolt (10) into centre
threaded hole, located on outside of Pivot Clamp
(15).
Carefully lower the chainsaw bar into position
between the two solid blocks on the pivot clamp
and ensure you have a 2cm gap between the body
of the chainsaw and the clamp.
Ensure the bar is approximately 90 degrees to the
clamp and well clear of the chain before tightening
the securing eye bolt. To tighten, use the supplied
metal tube/bar and place within the eye bolt and
rotate to tighten.
Once tightened, test the arc of travel to make sure
that the chain bar does not touch any part of the
saw horse.
Secure the Saw Guard (14) to the Pivot Clamp, using
8x70mm Bolt & M8 Nut (9).
Ensure there is sufficient clearance between the
guard and saw chain.

Insert the Black Plug (8) Into the left Long Leg
Place the two End Caps (12) onto both ends of the
Measuring Rod.
OPERATION
DANGER
The product must only be put into operation if no defects are found. It is crucial that any
defective parts are replaced before the product is used again.
WARNING
Before using the log splitter table, review the instructions below and safety information. Failure to follow
these instructions may result in property damage or injury to the operator or bystanders.
Check the safety equipment and the safe condition of the product:
−Check all parts to make sure that they fit tightly.
−Check whether there are any visible defects: broken parts, cracks, etc.
−Never use the product on slopes. Always work on level ground, ensuring you have a stable footing.
1. Place the wood on the log table, pushing the end to be cut against the measuring rod.
2. Standing behind the saw horse and chainsaw, hold the wood down firmly with your left hand.
3. Keep your hand well clear of the cutting edge of the chainsaw.
4. Arc the chainsaw with your right hand down towards the wood and continue to arc until the wood is cut
through.
5. Repeat steps 1 to 4 for further cutting cycles
PLEASE REMEMBER………….
•The log table of the saw horse is designed for lengths of wood with a maximum length of 1.8 metres and a
maximum diameter of 25cm.
•The maximum permissible weight is 120kg.
•The saw horse chain guard is designed for chainsaws with a cutting bar not longer than 45cm (18”).
A chainsaw with a cutting bar longer than 45cm (18”), which protrudes beyond the guard is not
recommended and potentially dangerous.
•The pivot clamp and guard must be detached from the chainsaw, when used away from the saw horse.
•The saw horse must be used on flat surfaces only.

When using a chainsaw with this saw horse, it is essential that all safety codes of practice supplied by
chainsaw manufacturer and Health & Safety Executive are fully followed.
MAINTENANCE & STORAGE
MAINTENANCE
The pivot clamp and support must be kept well lubricated with multi-purpose grease.
Ensure all nuts and bolts are checked prior to each use.
WARNING
Make sure that unauthorised persons do not have access to the device!
STORAGE
Store the machine is a dry place.
Store away from direct sunlight
Do not store anything above or near the machine, where anyone might stand on the machine to reach them.
Keep the machine away from children and others not qualified to use it.
CLEANING
Careful handling & regular cleaning ensure that the device will remain functional for a long time.
Brush offcoarsedirt.
Wipe down the device with a slightly damp cloth.
TRANSPORT
Secure the device against slipping.
When shipping, use the original packaging if possible.
TROUBLESHOOTING
WARNING
If the product does not perform properly, makes unusual sounds, or any other irregularity or malfunction
occurs, do not attempt to repair the product by yourself. Please contact customer services or your local
authorised service dealer for advice.
IF YOU REQUIRE ASSISTANCE WITH REGARDS TO THE CONTENTS OR OPERATION OF THE MACHINE, PLEASE
CONTACT US:
TEL: [phone]
EMAIL: [e-mail]
OPENING HOURS WEEKDAYS: FEB TO OCT 8:30AM - 5:30PM / NOV TO JAN 8:30AM - 5:00PM

PARTS DIAGRAM –THSHWCS (1938101001)

PARTS LIST –THSHWCS (1938101001)
+
NOTE:
Number 13 are fitted to the Pivot Clamp at the factory
No.
Handy No.
Part
Qty
14
TH191-14
Saw Guard
1
15
TH191-15
Saw Holder
1
16
TH191-16
Holder Eyelet
1
17
TH191-17
Bed 1
1
18
TH191-18
Long Far Leg
1
19
TH191-19
Bed 2
1
20
TH191-20
Short Far Leg
1
21
TH191-21
Foot
4
22
TH191-22
Leg Brace
2
23
TH191-23
Long Leg with Holder Slot
1
24
TH191-24
Short Leg on Holder End
1
25
TH191-25
Handle
1
26
TH191-26
Rod/Handle Eyelet
1

GJ HANDY & CO LTD USER WARRANTY POLICY
VERSION 8 01-2020
Users Statement of Warranty
Each new machine is warranted against defective material or assembly of material under normal usage. The
warranty applies to the original purchaser and covers faulty parts and the labour involved in replacing and
repairing those parts, which are of original manufacture.
Period of Warranty
The Handy (Petrol & Electric only), Webb (excludes Dynamic, Heritage, Legacy), Sanli Engine
a) 2 years from the original date of sale to the first domestic user.
b) 90 days from the original date of sale to the professional/commercial user.
c) 90 days from the original date of sale when used for hire.
d) A reduced warranty period of 90 days applies to those items which are subject to normal wear and tear
(e.g. but not limited to wheels, tyres, cutter bars, cylinders, cutting blades, blade boss, belts, cables, nylon
line & spool, collection bags, spark plugs).
e) Engines are supplied with a separate warranty to the machine. The engine manufacturers warranty
statement which will be supplied within the engine instruction manual. All enquiries and warranty repairs
should be discussed with the engine manufacturer or approved warranty repair dealer.
f) 90 days from the original date of purchase for Replacement Spare Parts (unless normal wear & tear
component, which are covered for 30 days).
g) All machines’ must be serviced within the first 12 months from the original date of purchase to comply
with the warranty (if applicable), failure to do so will invalidate the 2nd year of the warranty.
Webb Dynamic, Heritage & Legacy, Handy (All non-Petrol & Electric), Mowerland,
Q-Garden
a) 1 year from the original date of sale to the first domestic user.
b) 90 days from the original date of sale to the professional/commercial user.
c) 90 days from the original date of sale when used for hire.
d) A reduced warranty period of 90 days applies to those items which are subject to normal wear and tear
(e.g. but not limited to wheels, tyres, cutter bars, cylinders, cutting blades, blade boss, belts, cables, nylon
line & spool, collection bags, spark plugs).
e) Engines are supplied with a separate warranty to the machine. The engine manufacturers warranty
statement which will be supplied within the engine instruction manual. All enquiries and warranty repairs
should be discussed with the engine manufacturer or approved warranty repair dealer.
f) 90 days from the original date of purchase for Replacement Spare Parts (unless normal wear & tear
component, which are covered for 30 days).
All warranty repairs must be undertaken by an authorised service dealer. These dealers have been accredited
by GJ Handy & Co Ltd and agree to only use genuine parts and follow our repair procedures.
Not covered by this warranty
a) The warranty policy does not cover any depreciation or damages caused by ordinary wear, rusting or
corrosion, lack of correct maintenance or operation, misuse, abuse, lack of transportation or accident.
b) The warranty policy does not cover any costs necessary for the standard periodic maintenance services
instructed by the operator’s manual, or service parts replacement which would include oil, filters, tyres,
belts, brake linings, fuses, blades, seals and other service parts unless it can be proven that the item has
evidence of faulty manufacture.
c) The warranty policy will not cover failure or damage caused as a result of parts or accessories being
modified without the written approval of GJ Handy & Co Ltd.
d) The warranty policy will not cover the unit if non-genuine parts have been fitted and as a result damage
has occurred to the unit.
e) The warranty policy is non-transferable and is only applicable to the original purchaser.

Disclaimer
a) This warranty is only a remedy for defect of products. GJ Handy & Co Ltd will never warranty in terms of
the merchantability or the fitness for a particular purpose.
b) No person is authorised to make any warranties, representations or promises, expressed or implied, on
behalf of GJ Handy & Co Ltd, or to modify the terms conditions or limitation of this warranty policy in any
way.
c) Neither GJ Handy & Co Ltd nor any company affiliated with GJ Handy & Co Ltd shall be liable in any event
or manner whatsoever for incidental or consequential damages or injuries, including, but not limited to,
loss of crops, loss of profit, out of pocket expenses or profits, rental of substitute equipment or other
commercial losses.
General
a) Most warrantable failures show up within the first few weeks of use. These failures are usually
straightforward and warranty assessment is relatively easy.
b) Failures relating to cutter decks and belts need careful investigation, as the cause may not always be
straightforward. Look for damage to blades and pulleys especially when the cutter belt or blade boss have
snapped or cracked as this could be due to impact damage.
c) Customers should always refer to the operator/instruction manual when any disputed problem arises, you
will find most areas covered within the manual.

For spares or support of your handy product,
please contact us:
Tel: [phone]
Email: [e-mail]
Opening Hours Weekdays:
Feb To Oct 8:30am - 5:30pm / Nov To Jan 8:30am - 5:00pm
(CLOSED BANK HOLIDAYS)
To see our range of garden machinery & equipment visit:
www.thehandy.co.uk
Making gardening easier & affordable since 1938
Distributed by Handy Distribution, Murdock Road, Dorcan, Swindon, SN3 5HY
