The Handy 1938118001 User manual

23/10/2019 v3
40” (101CM)
TOWED DETHATCHER
MODEL NO: THTD -- PRODUCT NO: 1938118001
EN - ORIGINAL INSTRUCTIONS
ASSEMBLY REQUIRED
SAVE THESE INSTRUCTIONS
SPARES & SUPPORT: 01793 333212
FOR YOUR SAFETY
Please read & understand this manual, paying attention to the safety instructions, before use.
Incorrect use of the product could put the operator or machine in danger.
Whilst every effort has been made to ensure the accuracy of information contained in this manual, our
policy of continuous improvement determines the right to make modifications without prior warning.
Images used are for illustration purposes only
INSTRUCTION MANUAL

Copyright Notice
Copyright © Handy Distribution
Permission is granted to reproduce this publication for personal & educational use only.
Commercial copying, redistribution, hiring or lending is prohibited.
No part of this publication may be stored in a retrieval system or transmitted in any other form or means without
written permission from Handy Distribution.
In all cases this copyright notice must remain intact.

CONTENTS
SPECIFICATIONS
IMPORTANT INFORMATION
GENERAL SAFETY INSTRUCTIONS
COMPONENTS
ASSEMBLY
OPERATION & ADJUSTMENT
MAINTENANCE
PARTS DIAGRAM & LIST
WARRANTY
NOTES
ASSEMBLY IS REQUIRED
This product requires assembly before use. See the “Assembly” section for instructions.
Please check that all parts required for the assembly of this spreader are included. If for any reason you
believe a part for the assembly is missing or damaged, please contact us.
Tools Required:
2x 1/2" Wrenches
1x 9/16" Wrench
1x 3/4" Wrench or Adjustable Wrench
1x Pliers
If you require assistance with regards to the contents or operation of the machine, please contact us:
TEL: [phone]
EMAIL: [e-mail]
(MON –FRI 8.00AM TO 5.30PM EXCL. BANK HOLIDAYS)

SPECIFICATIONS
The manufacturer reserves the right to change the product specification and livery according to continued
product improvements.
Model
THTD
Product Number
1938118001
Weight
14kg
Working Width
40” (101cm)
Spring Loaded Steel Tines
10 x 100mm
IMPORTANT INFORMATION
INTENDED USE
The product is intended for domestic gardens. This product is not intended for commercial use. Generally
acknowledged accident prevention regulations and enclosed safety instructions must be observed. Only
perform work described in these instructions for use, any other use is incorrect. The manufacturer will not
assume responsibility for damage resulting from such use.
GENERAL SAFETY INSTRUCTIONS
Read and understand the owner’s manual and
labels affixed to the product. Learn its application
and limitations as well as the specific potential
hazards. Retain these instructions for future
reference. The operator is responsible for
following the warnings & instructions in this
manual and on the product.
READ THE MACHINE MANUAL
Read the vehicle owner’s manual and vehicle
safety rules to know how to operate the vehicle
before using this equipment.
STAY ALERT
Do not operate the machine while under the
influence of drugs, alcohol, or any medication that
could affect your ability to use it properly. Do not
use this machine when you are tired or distracted
from the job at hand. Be aware of what you are
doing at all times. Use common sense.
USERS
Never allow children to operate the towing vehicle
or dethatcher. Do not allow adults to operate
without having read these instructions.
PASSENGERS
Do not allow anyone to ride or sit on the
dethatcher frame or on the towing vehicle.
BEWARE BYSTANDERS/PETS
Keep the area of operation clear of all persons,
particularly children and pets.
HANDLE WITH CARE
This dethatcher attachment has sharp tine points.
Always handle with care and wear sturdy footwear
and protective gloves when operating this
dethatcher.
AVOID DANGEROUS CONDITIONS
Make sure there is adequate surrounding
workspace. Cluttered areas invite injuries.
Keep your work area clean with sufficient light.
Keep the area around the machine clear of
obstructions, grease, oil, rubbish & other debris
which could cause persons to fall onto moving
parts.
INSPECT YOUR MACHINE
Check all bolts, nuts & screws for tightness before
each use, especially those securing guards & drive
mechanisms. Vibration during use, may cause
these to loosen. Replace damaged, missing or
failed parts before using.
Warning labels carry important information.
Replace any missing or damaged warning labels.
CRUSH AND CUT HAZARDS
Always keep your hands and feet clear from
moving parts while operating the equipment.
Always keep the work area clean and clear when
operating.
CONDITIONS
Always operate up and down a slope, never across
the face of a slope. This equipment should be
operated at reduced speed on rough terrain, along
creeks and ditches and on hillsides, to prevent
tipping and loss of control. Do not drive too close

to a creek or a ditch. Do not tow this equipment
on a highway or any other public thoroughfare.
Always begin with the transmission in first (low)
gear & the engine at low speed. Gradually increase
the speed as conditions permit. The vehicle
braking and stability may be affected with the
dethatcher attached. Be aware of changing
conditions on slopes.
Refer to safety rules in the vehicle owner's
manual, concerning safe operation on slopes.
DRESS CORRECTLY
Do not wear loose clothing, gloves, scarfs, neckties
or jewellery (rings, wrist watches), which can be
caught in moving parts.
DO NOT OVERREACH
Always keep proper footing and balance when
using the machine. Never stand on the machine.
Serious injury could occur if tipped or moving parts
are unintentionally contacted. Do not store
anything above or near the machine, someone
might stand on the machine to reach them.
AVOID INJURY FROM UNEXPECTED ACCIDENT
Keep hands & feet out of the way of all moving
parts. Do not place any part of your body or any
tool in moving parts during operation.
DO NOT FORCE TOOL
Always work within the rated capacity. Do not
operate for a purpose for which it was not
intended.
MAINTAIN YOUR MACHINE WITH CARE
Clean the machine immediately after use. Keep
the machine clean to ensure it operates to its full
& safest performance. When maintaining this
machine, only the manufacturer’s original
replacement parts should be used. The use of non-
original manufacturer parts may invalidate your
warranty.
STORE IDLE EQUIPMENT
When not in use, the machine should be stored in
a dry location, out of direct sunlight. Keep the
machine away from children & others not
qualified.
OPERATION SPEED
Do not exceed 6mph, to avoid personal injury
and/or equipment damage.
SAFETY SYMBOLS
Read & understand the operator’s manual before
using the machine. Failure to follow instructions
could result in death or serious injury.
Risk of slicing. Keep hands out of the way of all
moving parts.
Wear protective gloves to protect your hands
Wear foot protection
Safety alert symbol. Used to alert you to potential
personal injury hazards. Obey all safety messages
that follow this symbol to avoid possible injury.
DANGER
Indicates an imminently hazardous situation
which, if not avoided, will result in serious injury.
WARNING
Indicates a potentially hazardous situation which,
if not avoided, could result in serious injury
CAUTION
Indicates a potentially hazardous situation which,
if not avoided, may result in minor or moderate
injury.
CAUTION
Used without the safety alert symbol indicates a
potentially hazardous situation which, if not
avoided, may result in property damage.

COMPONENTS
Before assembling the dethatcher, lay out all of the components as shown below:
pages.
1.
Tine Shield (40’’)
1
6.
Lift Plate
1
2.
Spring Tines x10
10
7.
Hitch Brackets
2
3.
Lift Handle
1
8.
Hitch Mount Arms
2
4.
Axle Bracket
1
9.
Spring Alignment Wires
2
5.
Wheels
2
A.
Shoulder Bolt
2
H.
Hex Nut M8
14
B.
Hex Bolt M8x50
2
I.
Hex Lock Nut M8
19
C.
Hex Bolt M8x30
2
J.
Hex Lock Nut M10
2
D.
Hex Bolt M8x20
15
K.
Lock Washer φ8
14
E.
Carriage Bolt M8x25
14
L.
Big Flat Washer φ8
10
F.
Hitch Pin φ10
1
M.
Angle Bracket
4
G.
Hair Cotter Pin φ3
1
N.
Hitch Arm Mount Brackets
3

ASSEMBLY
STEP 1
Assemble the lift plate to the top of the tine shield using four M8x20 hex bolts and M8 hex lock nuts as shown
in Figure 1. Tighten.
STEP 2
Turn the tine shield upside down. See Figure 2.
STEP 3
Assemble two (tall) hitch arm mount brackets and two (short) angle brackets to the bottom of the tine shield.
Fasten the brackets to the four round holes at the rear of the tine shield using four M8x20 hex bolts and M8
hex lock nuts. Do not tighten yet. See Figure 2.
STEP 4
Insert two angle brackets into the round holes in the bottom of the tine shield at the front. Use two M8x20 hex
bolts and M8 hex lock nuts. Do not tighten yet. See Figure 2.
LIFT PLATE
M8X20
HEX BOLT
M8 HEX
LOCK NUT
HITCH ARM MOUNT
BRACKET
M8 HEX LOCK
NUT
ANGLE
BRACKET
ANGLE
BRACKET
M8X20 HEX
BOLT
FIGURE 1
FIGURE 2

STEP 5
Fasten the hitch mount arms to the outside of the angle brackets at the front of the tine shield. Use two
M8x20 hex bolts and M8 hex lock nuts. Tighten and then loosen the nuts slightly. See Figure 3.
STEP 6
Fasten the hitch mount arms to the outside of the hitch arm mount brackets at the rear of the tine shield. Use
two M8x25 carriage bolts, Ø8 lock washers and M8 hex nuts. Do not tighten yet. See Figure 3.
STEP 7
Connect the front ends of the hitch mount arms using two M8x30 hex bolts and M8 hex lock nuts. Do not
tighten yet. See Figure 4.
STEP 8
Attach the hitch brackets to the top and bottom of the hitch mount arms using two M8x50 hex bolts and M8
hex lock nuts. Do not tighten yet. See Figure 4.
STEP 9
Assemble the Ф10 hitch pin through the hitch brackets and secure it with a Ф3 hair cotter pin. See Figure 4.
FIGURE 3
FIGURE 4

STEP 10
Tighten the bolts and nuts assembled in step 8.
Tighten the bolts and nuts assembled in step 7.
Tighten the bolts and nuts assembled in step 3.
Tighten the bolts and nuts assembled in step 4.
Tighten and then loosen slightly the bolts and nuts assembled in step 5.
Tighten the bolts and nuts assembled in step 6.
STEP 11
Attach the axle bracket onto the outside of the angle brackets using two M8x20 hex bolts and M8 hex lock
nuts. The ends of the axle bracket must point as shown in Figure 5. Tighten and then loosen the bolts and nuts
slightly.
STEP 12
Assemble the wheels to the axle bracket using two shoulder bolts and two M10 hex lock nuts. Tighten. See
Figure 6.
AXLE BRACKET
M8X20 HEX BOLT
M8 HEX LOCK NUT
M10 HEX
LOCK NUT
SHOULDER BOLT
FIGURE 5
FIGURE 6

STEP 13
Fasten the ten spring tines to the square holes in the bottom of the tine shield. Use a M8x25 carriage bolt, Ф8
big flat washer, Ø8 lock washer and M8 hex nut for each spring tine. Tighten. See Figure 7. NOTE: Spring tines
must sit between dimples.
STEP 14
Thread the spring align wires through the front and rear rows of spring tines, passing the wires in between the
hitch mount arms and the tine shield. Bend the ends of the wires to secure them.
See Figure 8.
STEP 15
Attach a hitch arm mount bracket to the axle bracket using two M8x25 carriage bolts, Ø 8 lock washers and M8
hex nuts. Do not tighten yet. See Figure 9.
STEP 16
Insert the lift handle through the tine shield. Attach it to the just assembled hitch arm mount bracket using
M8x20 hex bolt and a M8 hex lock nut. Tighten. See Figure 9.
SPRING ALIGN WIRE
FIGURE 7
FIGURE 8

STEP 17
Position the hitch arm mount bracket so that some resistance is felt through the lift handle when it is locked in
the up position. Tighten the nuts. See Figure 9.
GRIP
LIFT HANDLE
M8X25
CARRIAGE BOLT
M8X20 HEX
BOLT
M8 HEX
LOCK NUT
Ø 8 LOCK
WASHER
M8
HEX
NUT
FIGURE 9

OPERATION / ADJUSTMENT
DANGER
The product must only be put into operation if no defects are found. It is crucial that defective
parts are replaced before the product is used again. Check the safety equipment and the safe
condition of the product: Check all parts to make sure that they fit tightly. Check whether there
are any visible defects: broken parts, cracks, etc.
Regular removal of thatch is critical to the maintenance of a healthy lawn. Thatch is a layer of stems, clippings,
runners, roots and leaves that have not decayed. Excessive thatch prevents air, water and fertilizer from
reaching the roots. The dethatcher effectively dislodges excessive thatch from your lawn. Read these
instructions to help avoid improper adjustment and operation.
Correct adjustment of the tine shield and spring tines is important for effective performance. Refer to the
following steps for the proper adjustment before operating the dethatcher.
•Move the towing vehicle onto a level surface, such as a driveway or garage floor and attach the tine de-
thatcher to the vehicle hitch. See Figure 10.
•To adjust the spring tine shield, lower the de-thatcher into the operating position using the lift handle.
Loosen the two hex nuts and carriage bolts which fasten the rear of the hitch mount arm to the hitch arm
mount brackets. Adjust the tin shield until it is level and both the front and rear spring tines are in contact
with the ground. Re-tighten the hex nuts. See Figure 10.
•Vary the vehicle's forward speed until the best dethatching action is achieved.
•For best results, use a crisscross pattern on your lawn.
ADDING EXTRA WEIGHT
If the dethatcher appears to be jumping during use, extra weight (max 70lbs/31.75kg) should be added to the
tine shield. Attach and secure weights (Concrete blocks are recommended) to each side of the tine shield using
rubber tie down straps.
DANGER
•Vehicle braking and stability may be affected with the attachment of this machine to your garden
vehicle.
•Always operate up and down a slope, never across the face of a slope.
•Do not work on slopes greater than 10°.
•Drive slowly & carefully, especially when turning and on uneven ground.
•Do not tow this equipment on a highway or any other public thoroughfare.
CARRIAGE BOLT & HEX NUT
HITCH
MOUNT
ARMS
FIGURE 10

MAINTENANCE
LUBRICATE
Maintenance spray or multi-purpose grease can be applied to the wheel axle prior to long-term storage.
CLEANING
After each use thoroughly wash the machine with a stiff brush.
STORING
Before storing, ensure that the machine is clean and dry.
Store in a dry or protected area and coat exposed metal with light oil when not in use.
CHECK ALL NUTS, BOLTS AND FASTENING
Before each use check all fastenings are tight & secure.
APPEARANCE
If rust appears on the shield or spring tines, sand lightly and coat with enamel paint.
NEVER EXCEED LOAD CAPACITY
To avoid damaging the spreader, never exceed the rated load capacity of 45.5kg (100lb)
ONLY USE MANUFACTURER APPROVED PARTS
If a part needs replacing, only use the manufacturer’s original parts. Non-original replacement parts will
invalidate your warranty and may result in a safety hazard or poor operation.

PARTS DIAGRAM & LIST
No.
Part No.
Description
QTY
No.
Part No.
Description
QTY
1
TH153-1
Hitch Arm Mount Bracket
3
13
TH153-13
Hex Lock Nut M10
2
2
TH153-2GM
Hitch Bracket
2
14
TH153-14
Flat Washer
10
3
TH153-3
Spring Tine
10
15
TH153-15
Hex Bolt M8x20
15
4
TH153-4
Spring Alignment Wire
2
16
TH153-16
Lock Washer
14
5
TH153-5
Wheel
2
17
TH153-17
Hex Nut M8
14
6
TH153-6GM
Tine Shield
1
18
TH153-18
Hex Lock Nut M8
19
7
TH153-7GM
Hitch Mount Arm
2
19
TH153-19
Carriage Bolt M8x25
14
8
TH153-8
Gate Plate
1
20
TH153-20
Handle Grip
1
9
TH153-9GM
Axle Bracket
1
21
TH153-21
Hex Bolt M8x50
2
10
TH153-10GM
Lift Handle
1
22
TH153-22
Hex Bolt M8x30
2
11
TH153-11
Shoulder Bolt
2
23
TH153-23
Hitch Pin M8
1
12
TH153-12
Angle Bracket
4
24
TH153-24
R Clip
1
NOTE: Parts Lists are supplied for information purposes only, not all parts are stocked individually & we recommend
you contact our Spares Team on 01793 333212 for expert advice.

GJ HANDY & CO LTD USER WARRANTY POLICY
Users Statement of Warranty
Each new machine is warranted against defective material or assembly of material under normal usage. The
warranty applies to the original purchaser and covers faulty parts and the labour involved in replacing and
repairing those parts, which are of original manufacture.
Period of Warranty
Webb (excludes Electric Handheld, Dynamic, Heritage, Legacy), Webb Pro, Sanli Engine
a) 2 years from the original date of sale to the first domestic user.
b) 90 days from the original date of sale to the professional/commercial user.
c) 90 days from the original date of sale when used for hire.
d) A reduced warranty period of 90 days applies to those items which are subject to normal wear and tear
(e.g. but not limited to wheels, tyres, cutter bars, cylinders, cutting blades, blade boss, belts, cables,
nylon line & spool, collection bags, spark plugs).
e) Engines are supplied with a separate warranty to the machine. The engine manufacturers warranty
statement which will be supplied within the engine instruction manual. All enquiries and warranty
repairs should be discussed with the engine manufacturer or approved warranty repair dealer.
f) 90 days from the original date of purchase for Replacement Spare Parts (unless normal wear & tear
component, which are covered for 30 days).
g) All machines’ must be serviced within the first 12 months from the original date of purchase to comply
with the warranty, failure to do so will invalidate the 2nd year of the warranty.
Webb Electric Handheld, Webb Dynamic, Heritage & Legacy, Handy, Mowerland, Q-Garden
a) 1 year from the original date of sale to the first domestic user.
b) 90 days from the original date of sale to the professional/commercial user.
c) 90 days from the original date of sale when used for hire.
d) A reduced warranty period of 90 days applies to those items which are subject to normal wear and tear
(e.g. but not limited to wheels, tyres, cutter bars, cylinders, cutting blades, blade boss, belts, cables,
nylon line & spool, collection bags, spark plugs).
e) Engines are supplied with a separate warranty to the machine. The engine manufacturers warranty
statement which will be supplied within the engine instruction manual. All enquiries and warranty
repairs should be discussed with the engine manufacturer or approved warranty repair dealer.
f) 90 days from the original date of purchase for Replacement Spare Parts (unless normal wear & tear
component, which are covered for 30 days).
All warranty repairs must be undertaken by an authorised service dealer. These dealers have been accredited by
GJ Handy & Co Ltd and agree to only use genuine parts and follow our repair procedures.
Not covered by this warranty
a) The warranty policy does not cover any depreciation or damages caused by ordinary wear, rusting or
corrosion, lack of correct maintenance or operation, misuse, abuse, lack of transportation or accident.
b) The warranty policy does not cover any costs necessary for the standard periodic maintenance services
instructed by the operator’s manual, or service parts replacement which would include oil, filters, tyres,
belts, brake linings, fuses, blades, seals and other service parts unless it can be proven that the item has
evidence of faulty manufacture.
c) The warranty policy will not cover failure or damage caused as a result of parts or accessories being
modified without the written approval of GJ Handy & Co Ltd.
d) The warranty policy will not cover the unit if non-genuine parts have been fitted and as a result damage
has occurred to the unit.
e) The warranty policy is non-transferable and is only applicable to the original purchaser.

Disclaimer
a) This warranty is only a remedy for defect of products. GJ Handy & Co Ltd will never warranty in terms
of the merchantability or the fitness for a particular purpose.
b) No person is authorised to make any warranties, representations or promises, expressed or implied, on
behalf of GJ Handy & Co Ltd, or to modify the terms conditions or limitation of this warranty policy in
any way.
c) Neither GJ Handy & Co Ltd nor any company affiliated with GJ Handy & Co Ltd shall be liable in any event
or manner whatsoever for incidental or consequential damages or injuries, including, but not limited
to, loss of crops, loss of profit, out of pocket expenses or profits, rental of substitute equipment or other
commercial losses.
General
a) Most warrantable failures show up within the first few weeks of use. These failures are usually
straightforward and warranty assessment is relatively easy.
b) Failures relating to cutter decks and belts need careful investigation, as the cause may not always be
straightforward. Look for damage to blades and pulleys especially when the cutter belt or blade boss
have snapped or cracked as this could be due to impact damage.
c) Customers should always refer to the operator/instruction manual when any disputed problem arises,
you will find most areas covered within the manual.

NOTES
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________

NOTES
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________

For spares or support of your handy product,
please contact us:
Tel: [phone]
Email: customerservic[email protected]
(Mon –Fri 8.00am to 5.30pm excl. Bank Holidays)
To see our range of garden machinery & equipment visit:
www.thehandy.co.uk
Making gardening easier & affordable since 1938
Distributed by Handy Distribution, Murdock Road, Dorcan, Swindon, SN3 5HY
