The Solar Trader F1 User manual

Gears
12
3
Wheel
Axles
To build your own super fast F1 racing car, you will need
these components:
Solar Panel
with Motor Wheels
Body
Step 1 To fit the small gear to the motor; place the flat side of the gear on
to the axle. Allow a gap of approx. 1mm between the motor and the gear.
IMPORTANT: make sure you do not press too hard as this may damage
the components.
Tel: [phone]
www.thesolartrader.co.uk
F1 MINI SOLAR RACING CAR
Part of our world’s smallest range
Step 2 Push the motor gear
through the side of the car body
as shown in the picture. for everything
under the sun
Product Code:
02006SS01

Step 3
Pressing GENTLY
(in order not to
damage it), fit the
solar panel onto
the roof of the
car, making sure
that the wires are
clipped to the side.
Check the panel is
firmly in place.
Step 4 Fit the gear wheel onto
the rear axle as shown in the
picture. Push it along carefully
until 6mm of axle projects
through the gear wheel.
54 6
7
Step 5 Feed the
rear axle through
the holes at the
rear of the car and
fit a set of wheels
on it. Make sure
the gears mesh
together.
Step 6 Feed the front axle through the brackets at the
front of the car and fit the remaining wheels on it.
IMPORTANT: make sure the wheels are not pressed
too tightly into the body of the car.
Congratulations!
Your F1 solar car
is ready to race!
8 9 By adjusting the front
axle within its bracket,
your F1 car can race in
a straight line or curve
to one side or the other.
HAVE FUN RACING!
• The F1 solar racing car is not intended as a toy for small children.
• The F1 solar racing car works best when placed on a flat smooth surface.
• Place in sunlight or under a strong halogen spotlight. NB: Model will not work under normal
overhead lights.
• To ensure your F1 solar racing car remains in good working order, clean the wheels and solar
panel on a regular basis by gently wiping to remove dust/dirt that may slow your car down.
Made in China
• Not suitable for children under 3 due to small parts
• Adult supervision is required when making the car to
avoid damage to the panel and wires.
• Care should be taken if playing with this in direct
sunlight to protect children from UV light.
• Please retain this information for future reference.
WARNING
