THE WORLD MODELS 1/3 PIPER J-3 CUB User manual

* Specifications are subject to change without notice. *
Requires: 80cc gasoline engine,
4-channel radio w/ 6 high torque servos.
1/3 PIPER J-3 CUB
1/3 PIPER J-3 CUB
INSTRUCTION MANUAL
Warning! This model is not a toy.
It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of engine powered precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual at
hand for quick reference.
Wing Span 141 in / 3580 mm
Wing Area 2821 sq in / 182 sq dm
Flying Weight 28.5 lbs / 13000 g
Fuselage Length 91 in / 2310 mm
Specifications
FACTORY PRE-FABRICATED
ALMOST-READY-TO-FLY (ARF) SERIES
MADE IN CHINA
The World Models
Manufacturing Co., LTD.
www.theworldmodels.com
A186RPO27761212

P.1
INDEX
Read through the manual before you begin, so you will have an overall idea of what to do.
BEFORE YOU BEGIN
BEFORE YOU BEGIN
PARTS LIST
ASSEMBLY
SAFETY PRECAUTIONS
P.1
P.2
P.3-P.12
P.12
Check all parts. If you find any defective or missing parts contact your local dealer. Please
DRY FIT and check for defects for all parts that will require CAor Epoxy for final assembly.
Any parts you find to be defective after the gluing process may be difficult to remove for
warranty replacement. The manufacturer will replace any defective parts, but will not extend
to the parts that are good before gluing to defective parts during assembly. Warranty will
not cover any parts modified by customer.
Symbols used throughout this instruction manual comprise of the following :-
1
2
3
Cut off shaded portion.
Ensure smooth non-binding
movement while assembling.
Apply instant glue
(C.A.glue, super glue.)
Assemble left and right
sides the same way.
Peel off shaded portion
covering film.
Pay close attention here!
Apply epoxy glue.
Must be purchased separately !
Drill holes with the specified
diameter (here: 3mm). Pierce the shaded portion
covering film.
3mm
Do not overlook this symbol !
Warning!
Apply thread locker
1/3 PIPER J-3 CUB
1/3 PIPER J-3 CUB
A186RPO27761212

Parts List
COVERING:
TOUGHLON STL 331 CUB YELLOW
LIGHTEX SGX 201 BLACK
P.2
1. MAIN WING -- 1 pair
2. SERVO MOUNTING PANEL(ForAileron) -- 1 pair
HEAVY DUTY CLEVIS PL4112200 -- 4 sets
SOCKET HEAD SCREW M4x60mm -- 2 pcs
SCREW PWA2.3x8mm -- 8 pcs
M4 NYLON INSERT LOCK NUT -- 2 pcs
HEAVY DUTY HORN BRACKET PL4112400 -- 2 sets
HEAVY DUTY SERVO HORN PL4120300 -- 2 sets
PUSHROD Ø2.3x129mm w/ Threads (ForAileron) -- 2 pcs
SWIVELCLEVIS HORN FAIRING PL4610010 -- 2 sets
3. SOCKET HEAD SCREW M4x20mm -- 4 pcs
SOCKET HEAD SCREW M3x20mm -- 8 pcs
WIRE BRACKET PL5330040Y -- 8 pcs
MAIN WING STRUTS -- 1 pair
WING STRUT WIRE D4mm -- 2 pcs
M3 NYLON INSERT LOCK NUT -- 4 pcs
WASHER d3xD7mm -- 12 pcs
WASHER d4xD12mm -- 4 pcs
4. FUSELAGE -- 1 pc.
STABILIZER & ELEVATOR -- 1 set
SCREW PWM2.5x12mm -- 2 pcs
STABILIZER WIRE Ø4x200mm -- 2 pcs
5. VERTICAL FIN & RUDDER -- 1 set
6. TAIL GEAR ASSEMELY (PL3410032) --1 set
COPPER PLATE (For Stays on Tail Fueslage Bottom) 3x12x110mm -- 1 pc.
SCREW PA3x18mm -- 3 pcs
SCREW PWA2.5x12mm -- 2 pcs
ALUMINUM PLATE 1.5x12x60mm -- 1 pc.
SPRING Ø5.2x49mm -- 2 pcs
7. MAIN LANDING GEAR -- 1 set
SCREW HM4x18mm -- 2 pcs
SCREW PA3x14mm -- 12 pcs
SCREW PA4x20mm -- 2 pcs
WASHER d4xD12mm -- 2 pcs
WASHER d4xD9mm -- 2 pcs
MOUNTING PLATE 12x20mm PL4114020 -- 6 pcs
ALUMINUM PLATE 3x15x77mm -- 2 pcs
8. SCREW PA1.7x8mm -- 6 pcs
SCREW PM3x12mm -- 8 pcs
WASHER d3xD7mm -- 16 pcs
M3 NUT -- 8 pcs
COLLAR Ø6.1mm w/ set screw -- 4 sets
LARGE SCALE CAPTIVEAIR WHEELS Ø140mm -- 2 sets
PLYWOOD 2x211.5x193.5mm (Main Langing Gear Cover) --1 pair
WIRE BRACKET PL5330060Y -- 8 pcs
9. BLIND NUT M6 -- 4 pcs
WASHER d6xD15mm -- 4 pcs
SOCKET HEAD SCREW M6x30mm -- 4 pcs
10. COWLING -- 1 pc.
TRANSPARENT 3D TEMPLATE -- 1 pc.
SCREW PA3x12mm -- 4 pcs
WASHER d3xD7mm -- 4 pcs
SILICON GROMMET d2.5xD8.5mm -- 4 pcs
DUMMY ENGINE COVER -- 1 pair
11. FUELTANK 1500cc PL1121500G -- 1 set
CABLE TIE 1.5x8x500mm -- 1 pc.
DOUBLE-SIDED TAPE 40x160mm -- 1 pc.
12. PUSHROD Ø2.3x215mm w/ Threads (For Elevator) -- 2 pcs
SOCKET HEAD SCREW M4x40mm -- 2 pcs
M4 NYLON INSERT LOCK NUT -- 2 pcs
SWIVELCLEVIS HORN FAIRING PL4610010 -- 2 sets
HEAVY DUTY HORN BRACKET PL4112400 -- 2 sets
HEAVY DUTY SERVO HORN PL4120300 -- 2 sets
HEAVY DUTY CLEVIS PL4112200 -- 4 sets
13. PUSHROD Ø2.3x170mm w/ Threads (For Rudder) -- 1 pc.
SOCKET HEAD SCREW M4x60mm -- 1 pc.
M4 NYLON INSERT LOCK NUT -- 1 pc.
SWIVELCLEVIS HORN FAIRING PL4610010 -- 1 set
HEAVY DUTY HORN BRACKET PL4112400 -- 1 set
HEAVY DUTY SERVO HORN PL4120300 -- 1 set
HEAVY DUTY CLEVIS PL4112200 -- 2 set
14. SCREW PM2x18mm -- 12 pcs
WASHER d2xD5mm -- 24 pcs
M2 NYLON INSERT LOCK NUT -- 12 pcs
CLEVIS -- 12 pcs
WIRE Ø1x4200mm -- 1 pc.
FLYING WIRE BRACKET -- 12 pcs
CLIP PIN Ø0.8x23mm -- 6 pcs
EYE SCREW -- 12 pcs
COPPER TUBE d2.5xD3.2x8mm (For Rudder) -- 16 pcs
15. SIDE WINDOWS -- 1 pair
16. LINKAGE CONNECTOR Ø2.1mm w/ set screw -- 1 set
17. PLYWOOD 3x196x304mm (For Fuselage Servos) -- 1 pc.
PLYWOOD 3x10x160mm (For Fuselage Servo Stand) -- 2 pcs
BALSA10x10x288mm (For Fuselage Servo Stand) -- 2 pcs
SPONGE 10x80x200mm -- 2 pcs
THROTTLE PUSHWIRE Ø1.8x480mm -- 1 pc.
PLASTIC TUBE d2xD3xd300mm -- 1 pc.
18. PILOT PC101110A -- 1 set
SCREW PWA2x12mm -- 4 pcs
COCKPIT BASE PANEL3x196x444mm -- 1 pc.
WOOD 10x10x443mm (For Cockpit Base Panel) -- 2 pcs
19. WIND SHIELD -- 1 pc.
M2 NYLON INSERT LOCK NUT -- 2 pcs
SCREW PM2x14mm -- 2 pcs
WASHER d2xD5mm -- 4 pcs
MOUNTING PLATE 5x15mm PL4114015 -- 2 pcs
20. WING TUBE Ø22x976mm -- 2 pcs
SELF-TIGHTENING LATCHING PIN PL9120010 -- 4 pcs
WIRE Ø0.8mm -- 2 pair
M3x8mm SET SCREW -- 4 pcs
21. SCREW HM4x15mm -- 2 pcs
WASHER d4xD12mm -- 2 pcs
M4 NYLON INSERT LOCK NUT -- 2 pcs
22. DECALS：A186RDEC -- 1 set
A186RPO27761212

P.3
Main Wing1
Aileron servo2
Aileron Servo Lead
2
M4 Nylon Insert Lock Nut
2
8
1.5mm
PWA2.3x8mm Screw
PWA2.3x8mm
M2x10mm
HeavyDuty
Clevis
HeavyDutyHornBracket
HeavyDutyClevis
PA1.7x8mm
M2x10mm
M4x60mm
Pushrod
Ø2.3x129mm
M4NylonInsertLockNut
M2NylonInsertLockNut
Bottom View
Bottom View
1.5mm
M2 Nylon Insert
Lock Nut
M2x8mm
SocketHead Screw
M2 Nut
PL4120300
M4x60mmSocketHeadScrew
A186RPO27761212

Vertical Fin & Rudder
5
PWM2.5x12mmScrew
2
Stabilizer & Elevator
4
(Stabilizer)
(Main Wing)
B B'
B=B'
Temporary install the main wing, adjust
leveling of the stabilizer to make it as
parallel to the main wing as possible.
Completed
Completed
PWM2.5x12mm
Ø4x200mm
P.4
Wing Struts
3
M4x20mmSocketHeadScrew
d4xD12mm Washer
d3xD7mm Washer
M3NylonInsertLockNut
4
4
12
4
d4xD12mmWasher
d3xD7mmWasher
d3xD7mmWasher
M4x20mm
M3x20mm
M3x20mm
M3NylonInsertLockNut
M3x20mmSocketHeadScrew
8
Bottom View
465mm 481mm
174mm
280mm
184mm
260mm
Remove coverings for all surfaces in contact before
applying A/B epoxy glue.
A186RPO27761212

Main Landing Gear
Front
PA3x14mm
PA4x20mm
HM4x18mm d4xD9mm
Washer
d4xD12mm
Washer
Aluminum Plate
3x15x77mm
LandingGear
Front
PM3x12mm Screw
PA1.7X8mm Screw
d3xD7mm Washer
M3 Nut
8
6
16
8
4
3mm Set Screw
4
6
D6.1mm Collar
d4 x D12mm Washer
HM4x18mm Screw
2
2
PA 3x14mm Screw
12
d4 x D9mm Washer
2
PA 4x20mm Screw
2
7
8
3.5mm
1.5mm
P.5
Bottom View
Bottom View
Tail Landing Gear
3
2
6
PWA2.5 x 12mm
PA3 x18mm
Copper Plate
1.5x12x60mm
Spring
2.5mm 1.5mm
Bottom View
PA3x18mm Screw
PWA2.5x12mm Screw
M3 x 3mm
Set Screw M3 x 3mm
Set Screw
Wheel Ø140mm
Wheel Cover
6.1 mm Collar 6.1 mm Collar
PA1.7x8 mm
M3 Nut
Washer d3xD7mm
Washer d3xD7mm
PM3x12mm
Main Langing Gear Cover
Wire Bracket Ø6
A186RPO27761212

Engine
9
d6xD15mm Washer
M6 Blind Nut
4
4
4
Cowling
10
PA3x12mm Screw
d2.5x8.5mm Silicon Grommet
4
4
Please refer to the attached sheet for usage of the transparent
3D template.
First insert the grommet to the cowling then apply screw.
M6x30 SOCKET HEAD SCREW
Washer d6xD15mm
M6 Blind Nut
SOCKET HEAD
SCREW M6x30 mm
P.6
190mm
7.48 in.
d3xD7mm Washer
16
Cowling
Fuselage
d2.5x8.5mm Silicon Grommet
PA3x12mm
Washer d3xD7mm
Completed
7.2mm
1.5mm
A186RPO27761212

Fuel Tank
11
UP
P.7
Completed
1 2 3
Double-sided Tape 40x160mm
Cable Tie
1.5x8x500mm
Fuel Tank
1500cc
M4 NYLON INSERT LOCK NUT
2
Bottom View
Elevator Pushrod
12
M2 x 10mm
PA1.7 x 8mm
Heavy Duty Clevis
Pushrod
Heavy Duty Horn Bracket
M4 x 40mm
M2 Nylon Insert
Lock Nut
M4 Nylon
Insert Lock
Nut
M2 x 10mm
Pushrod
Heavy Duty Servo Horn
M2 Nylon Insert Lock Nut
2
M4x40 SOCKET HEAD SCREW
M2x8mm
SocketHeadScrew
M2 Nut
PL4120300
RudderPushrod
13
M4 NYLON INSERT LOCK NUT
1
Bottom View
M2 x 10mm
PA1.7 x 8mm
PA1.7 x 8mm
Heavy Duty Clevis
Pushrod
Heavy Duty Horn Bracket
M4 x 60mm
M2 Nylon Insert
Lock Nut
M4 Nylon
Insert Lock
Nut
1
M4x60 SOCKET HEAD SCREW
M2x8mm
SocketHeadScrew
M2 Nut
PL4120300
M2 x 10mm
Pushrod
Heavy Duty Servo Horn
M2 Nylon Insert Lock Nut
A186RPO27761212

Throttle Pushwire
3mm
Washer
2mm
Washer
2mm
M2 Nut
14 Flying Wire
PM2x18mm Screw12
12
M2 NYLON INSERT LOCK NUT
Windows
Securely glue the windows to the fuselage.
WindowA Window B
15
CopperTube
Press down the center
1/3 portion
Throttle Servo.
COMPLETED
1.5mm
d2xD5mmWasher 24
P.8
Completed
Servo Set
16
3x3mm Set Screw
M2 Nut
LinkageConnector
1
1
1
2
2mm Washer
Please refer to the attached sheet for linkage connector installation.
M2
PM2x18mm
PM2x18mm
d2.5xD3.2x8mm
3mm
3mm
d2xD5mm
Washer
M2 NYLON INSERT LOCK NUT
A186RPO27761212

Throttle Servo
Sponge
Throttle Pushrod
D1.8x480mm
Plastic tube
d2xD3x300mm
18 Pilot
Wind Shield
19
PWA2x12mm Screw
M2NYLONINSERT LOCK NUT
2
PM2x14mm Screw
2
d2 x D5mm Washer
4
17 RadioEquipment
Battery
Receiver
lnstall and arrange the servo as shown in the diagram.
Bottom View
4
PC101110A
PWA2x12mm Screw
P.9
PM2x14mm
Mounting Plate
Washer
d2xD5mm
Washer
d2xD5mm
M2 Nylon
Insert Lock
Nut
A186RPO27761212

P.10
Main Wing
20
Wing Tube
Ø22x976mm
Lead to Aileron Servo
4
Set Screw
M3 x 8mm
Wing Tube PWA2.3x12mm
Self Tightening
Wing Latch Set Screw
M3X8mm
M3x8mm
Set Screw
Wire Ø0.8mm
Completed
Wing Struts
21
HM4x15mm Screw
d4x D12mm Washer
2
2
M4 NYLON INSERT LOCK NUT
2
HM4x15mm
M4 NYLON INSERT LOCK NUT
Washer
d4xD12mm
A186RPO27761212

P.11
Wing Setting
Adjust the wing and fuselage configuration as shown
in the diagrams.
22
A'
A
A = A ' B = B ' C = C '
B B '
CC
'
A186RPO27761212

Important Safety Precautions
23 Control Throws Adjust the control throws as shown in
the diagram.These throws are good for
general flying.You can adjust according
to your personal preference.
Aileron
40mm
Elevator 50mm
Rudder 65mm
24 C
. G .
65mm
50mm
40mm
Warning!
150mm
5.9in
C.G.
1/3 PIPER J-3 CUB
1/3 PIPER J-3 CUB
# First time flyer should never fly by himself / herself. Assistance from experienced flyer is absolutely
necessary.
# Pre-flight adjustment must be done before flying, it is very dangerous to fly a badly pre-adjusted
aircraft.
# is specially designed to be powered by 80c.c. engine, using a more powerful
engine does not mean better performance. In fact, over powered engine may cause structural
damage and injuries.
# Make sure the air field is spacious, never fly the plane too close to people and never get too close
to a running propeller.
# If you find wrinkles on the covering as a result of weather changes, you can use hot iron to remove
the wrinkles. Please begin with lower temperature setting and gradually raise the temperature until
the wrinkles are gone. Too hot an iron may damage the covering.
Don't use hot iron near the seams
or edges, hot iron will melt the glue and shrink the covering at the same time, causing the seams to pull
away.
# Check and re-tighten up all factory assembled screws, use thread locker if necessary.
http://www.theworldmodels.com/para/instruction/instructionManuals.php
P.12
TheidealC.G.positionis150mm(5.9in.)behindtheleadingedgemeasuredatwherethe wingmeetsthe
fuselage.Inordertoobtainthe C.G.specified,addweightto thefuselageor movethe battery position.
Check the C.G.beforeflying.
Ifyouareconvertingthismodeltoelectric,pleasemovetheC.G.forward10%ofcurrentC.G.distancefrom
leadingedgetocompensateforweightoffuel.
A186RPO27761212

Product Registration Form (US Customers)
We would like to share with you any relevant information regarding your model, including
product news and free upgrade parts when applicable. Please fill in the following and send to
AirBorne Models, 4749-K, Bennett Drive, Livermore, CA94551 USA.
1. Name:______________________________________________
2.Address:____________________________________________
3. Phone #:____________________ E-mail:__________________
4. Model:______________________________________________
Wing QC#__________ Fuselage QC# _______________________
(QC numbers are stamped on wing and fuselage)
5. Date of Purchase:_____________________________________
6. Store Name: _________________________________________
Please call AirBorne Models at 925 371 0922 for any assistance in filling this form.
Thank you very much for purchasing our product.
LINKAGE CONNECTOR
HW7111050 & HW7111060
After fastening the round nut, make sure that
the linkage connector can rotate freely.
Drill 2mm hole at servo horn. Insert linkage connector
into servo horn.
Make sure shoulder of
screw is cleared from
servo horn.
Add washer to reduce
play if necessary.
Shoulder
Tighten up the round nut
against the shoulder. Apply
CA or permanent thread
locker.
A186RPO27761212

This transparent 3D template
is used for position guidance
of the actual cutting of the
pre-painted cowling.
Usage of the transparent 3D template
Simply cut the transparent 3D template to fit your engine and
exhaust pipe, then slide onto the actual cowling and use as
template to mark the openings required for final cutting.
1 2
3 4
A186RPO27761212

A186RPO27761212
