Thermador CM302 Guide

Care & Use Manual
for
Thermador Built-In Ovens
Model
CM301, CM302
© 2003 BSH Home Appliances Corp.

A Special Message
to Our Customers
Thank you for buying a Thermador oven. We
recommend that you take the time to read this
entire booklet before using your new appliance.
We hope that the information in this manual will
help you easily operate and care for your oven
for years of satisfaction.
You have selected a remarkable oven capable of
several advanced cooking operations. To help make
your cooking transition smooth,we have dedicated
a specific 800 number for your use. This special
line is staffed with representatives trained to
answer your speed cooking questions or
comments about the oven.
Just phone 1-888-SPD-COOK or reach us
through our website at www.thermador.com.
We can also be reached at 1-800-735-4328 or
write to us at:
Customer Support Call Center
Thermador
5551 McFadden Avenue
Huntington Beach, CA 92649
Always include your model and serial number with
all communication.
Sincerely,
Thermador Test Kitchen Consumer Scientists

Table of Contents
Important Safety Instructions. 2-5
Microwave Precautions, Registration .............. 2
Oven Features .............................. 6-13
Oven Control Features ....................... 6-7
Using The Control Panel ......................... 8
Panel Lock / Child Lockout ...................... 8
Sights & Sounds ......................................... 9
Setting the Clock ....................................10
Setting the Lights.....................................10
Setting the Timer.....................................11
Upper Oven Heating Modes ................ 12
Upper/Lower Oven Heating Modes ...13
Upper Oven Operations..... 14 - 32
CookSmart™ Mode Operation ...14 - 21
CS1 CookSmart Cooking Chart ..16 - 17
CS2 CookSmart Cooking Chart .........18
CS3 CookSmart Cooking Chart ..19 - 20
CS4 CookSmart Cooking Chart .........21
Basics for Microwave Mode..................22
Microwave Mode Operation .........23 - 24
Microwave Cooking Charts...........25 - 27
Micro Broil and Chart.....................28 - 29
Custom Combination Mode ......... 30 -32
Upper / Lower Oven
Operations ...................................... 33 – 49
General Tips ............................................. 33
Bake Mode ................................................ 34
Baking Chart ............................................ 35
Convection Mode ...................................36
Convection Chart ................................... 37
Convection Bake Mode .........................38
Convection Bake Chart .........................39
Convection Broil Chart .........................39
CM Introduction
Roast Mode ..............................................40
Roasting Chart.........................................41
Food Safety Guidelines ..........................41
Broil and Convection Broil Modes ..... 44
Broil Chart ............................................... 45
Convection Roast and Probe Mode..... 42
Convection Roast Chart ....................... 43
Proof Mode .............................................. 46
Dehydrate Mode .....................................47
Timed Oven Mode .................................48
Setting the Sabbath Mode .....................49
Care and Cleaning ........................50-53
Oven Finishes/Cleaning Method.......... 53
Self Cleaning the Ovens ........................54
Self Clean Mode ......................................55
Oven Cleaning Chart ............................. 56
Do-It-Yourself Maintenance ..54-56
Removing the Lower Oven Door ....... 54
Replacing the Oven Light ...................... 55
Changing to 24-Hour Clock.................56
Changing to Centigrade ........................ 56
Calibrating Oven Temperature............. 56
Problem Solving .................... 57-58
Solving Baking Problems ........................57
Solving Operational Problems ............. 58
Consumer Service ....................... 58, 61
How to Obtain Service .........................58
Location of Data Plate .......................6, 61
Microwave Precautions, Registration.... 2
Thermador®Warranty ........................... 61
Page 1

CM Oven Care and Use Manual
a) Do not attempt to operate this oven with the
microwave door open, since open-door
operation can result in harmful exposure to
microwave energy. It is important not to defeat
or tamper with the safety interlocks.
b) Do not place any object between the oven front
face and the door or allow soil or cleaner
residue to accumulate on sealing surfaces.
c) Do not operate the oven if it is damaged. It is
particularlyimportant that the oven doorcloses
properly and that there is no damage to: (1) the
door (bent), (2) the hinges and latches (broken
or loosened), (3) the door seals and sealing
surfaces, inside window/glass area.
d) The oven should not be adjusted or repaired by
anyone except properly qualified personnel.
YOUR MICROWAVE
OVEN MUST BE REGISTERED
MICROWAVE PRECAUTIONS AND REGISTRATIONS
PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
NOTE: Do not operate the oven with any object trapped between the door
and the oven front face.
Data Plate
Copy the model and serial numbers from the data plate located inside the right upper
oven vent on the left hand partition (See Illustration, Item 2, Page 6). Keep your invoice
for warranty validation. Fill in the information below as a handy reference.
ItisaFederalrequirementthat records be maintained
on the location of all microwave ovens.
Therefore, please:
1. Fill in the registration card and mail it to us. (The
registration card is packed with this manual in
the plastic bag.)
2. If you are not the original purchaser of this
applianceorif the cardismissing, please establish
your ownership by writing to us at:
THERMADOR
Microwave Registration
5551 McFadden Avenue
Huntington Beach, CA 92649
3. When writing to us about your oven, please be
sure to include the model and serial number.
Dealer’s Name Service Center Model Number
Dealer’s Telephone Number Service Center’s Telephone Number Serial Number
Date of Purchase
BY LAW THIS APPLIANCE MUST BE REGISTERED. PLEASE BE CERTAIN THAT IT IS.
Safety Precautions
Page 2

CM Oven Care and Use Manual
Safety Precautions
Page 3
• Read and follow the specific PRECAUTIONS
TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY found on
Page 2.
• This appliance must be properly installed and
grounded by a qualified technician. Connect
only to a properly grounded outlet. See
“GroundingInstructions”foundintheInstallation
Instructions.
• This appliance should be serviced only by a
qualifiedservice technician. Contact the nearest
authorized service center for examination,
repair or adjustment.
•Do not repair or replace any part of the oven
unless specifically recommended. Refer service
to an authorized servicer.
•Donotoperate this applianceifit is notworking
properly or if it has been damaged, until an
authorized servicer has examined it.
• Installorlocate this applianceonlyin accordance
with the Installation Instructions.
• Use this oven only as intended by the
manufacturer.If you haveany questions, contact
the manufacturer.
•Do not cover or block any openings on this
appliance.
• Use this appliance only for its intended use as
described in this manual. Do not use corrosive
chemicals, vapors, or nonfood products in this
appliance.Thistypeofovenisspecifically designed
to heat or cook. It is not designed for industrial
orlaboratoryuse.Theuseof corrosive chemicals
in heating or cleaning will damage the appliance.
•Do not allow children to use this appliance,
Please read all instructions before using this appliance.
unless closely supervised by an adult. Children
and pets should not be left alone or unattended
in the area where the appliance is in use. Never
allow children to sit or stand on any part of the
oven.
•Do not store items of interest to children
above the oven. If children should climb onto
the appliance to reach these items, they could
be seriously injured.
To reduce the risk of fire in the oven cavity:
1. Donot store flammable materials in or near the
oven.
2. Do not use water on a grease fire. Smother fire
oruse adry chemicalor foam-typeextinguisher.
3. It is highly recommended that a fire extinguisher
be readily available and highly visible next to any
cooking appliance.
4. Do not overcook food. Carefully attend oven
if paper, plastic or other combustible materials
are placed inside the oven.
5. Remove wire twist-ties from paper or plastic
bags before placing in microwave oven.
6. Do not use the cavity for storage purposes. Do
not leave paper products, cooking utensils or
food in the cavity when not being used.
7. If materials inside the oven should ignite, keep
oven door closed. Turn oven off and disconnect
the circuit at the circuit breaker box.
8. Do not block any vent openings.
9. Be sure the blower fan runs whenever the oven
is in operation. If the fan does not operate, do
not use the oven. Call an authorized service
center.
10. Never use the oven to warm or heat a room.
This can damage the oven parts.
11. Forpersonalsafety,wear proper clothing.Loose
fitting clothes or garments with hanging sleeves
should never be worn while using this appliance.
General Appliance, Oven and Microwave Oven
SAFETY PRECAUTIONS
▲
!
WARNING
When properly cared for, your new Thermador
ovenhasbeendesigned to be a safe, reliable appliance.
Read all instructions carefully before using this
oven. These precautions will reduce the risk of
burns, electric shock, fire, and injury to persons or
exposure to excessive microwave energy. When
using kitchen appliances, basic safety precautions
must be followed, including the following:
Continued on next page

CM Oven Care and Use Manual
General Appliance, Oven and Microwave Oven
SAFETY PRECAUTIONS
The elimination of soil during self-cleaning
generates some by-products which are on
this list of substances.
To minimize exposure to these substances,
always operate this oven according to the
instructions in this manual and provide
good ventilation to the room during and
immediately after self-cleaning the oven.
• Tie long hair so that it doesn’t hang loose.
• In the event that personal clothing or hair
catches fire, drop and roll immediately to
extinguish flames.
• Use only dry potholders. Moist or damp
potholders in contact with hot surfaces may
result in burns from steam.
• Do not use a towel or other types of bulky cloth
in place of potholders. They may ignite if they
touch a hot element.
GENERAL OVEN SAFETY
• Do not touch hot elements or hot interior
surfaces of the oven.
• The heating elements may be hot even though
they are dark in color. Interior surfaces of an
oven become hot enough to cause burns.
• During and after use, do not touch or let
clothing or other flammable materials contact
theheatingelementsuntiltheyhavehadsufficient
time to cool.
• The trim on top and on the sides of the oven
door may become hot enough to cause burns.
• Use care when opening the oven door. Open
slightly at first to let hot air or steam escape
before removing or replacing food.
• Do not heat unopened food containers. Build-
up of pressure may cause the container to burst
and result in injury.
• Always place oven racks at desired level while
oven is cool. If a rack must be moved while oven
is hot, do not let potholder contact the hot
elements.
SELF-CLEANING MODE SAFETY
The California Safe Drinking Water and
Toxic Enforcement Act requires businesses
to warn customers of potential exposure to
substances which are known by the State of
California to cause cancer or reproductive
harm. Continued on next page
▲
!WARNING
• Confirm that the door locks and will not open
before starting self-clean mode. If door does not
lock, do not run self-clean; phone 800
/ 735-4328 for
service (see Page 58, for obtaining service.)
• Clean only oven parts listed in this manual.
• Keep surfaces of door and oven that come
together free of soil. Refer to cleaning
instructions on Page 52.
• Do not clean the door gasket. Care should be
taken not to rub, damage, loosen or remove the
door gasket . It is essential for a good seal.
• Do not use commercial oven cleaners or oven
liner protective coating of any kind in or around
any part of the oven.
• Before setting the self-clean mode, remove the
broiler pan, oven racks, other utensils and
excess, soft spillage.
MICROWAVE MODE SAFETY
• Do not tamper with, adjust or repair the door,
safety interlock switches or any other part of
the oven. Repairs must be done by a qualified
service technician.
•Do not operate the microwave mode
when the oven is empty. If food or water is
not present to absorb the energy, the oven
could be damaged with a risk of fire.
• Do not dry clothes, newspapers or other
materials in the oven. Newspapers and paper
bags are not suitable for cooking; a fire may
result.
• Do not use recycled paper products unless it is
labeled safe for microwave use. These products
may contain impurities that may cause sparks
and result in a fire.
▲
!
WARNING
▲
!
WARNING
Safety Precautions
Page 4

CM Oven Care and Use Manual
Safety Precautions
Page 5
Microwave Oven
SAFETY PRECAUTIONS
IMPORTANT: Do not overcook food;fire could result. Proper cooking depends on selecting the correct power
level and cooking time for the amount of food in the oven. Smaller portions of food that are cooked too long may
catch fire. Always have food in the microwave oven when it is on to absorb the microwave energy. When using the
oven at power levels below 100%, you can hear the magnetron cycling on and off. Condensation is a normal part
of microwave cooking. Covered foods will not cause as much condensation as uncovered ones. Do not block oven
vents. This oven is rated for 650 watts by using the IEC Test Procedure. When preparing foods, check food 1-2
minutes before the minimum time and add time accordingly.
FOOD ITEM OR PROCESS
• Pierce skins of potatoes, apples,
whole squash, hot dogs and
sausages so that steam can escape.
• Puncture whole egg yolks before
cooking to prevent explosion.
DON’T
DO
• Use wire twist-tie to close an oven
cooking bag.
• Deep fat fry.
• Use paper towels or cloths that
contain a synthetic fiber woven
into them (the fiber may cause the
towel to ignite).
• Heat baby food in the original jars.
• Heat bottIes with nipples on.
• Heatbottles withdisposableliners.
• Leave oven unattended when
popping popcorn.
• Use brown paper bags or glass
bowls to popcorn in.
• Cook eggs in the shell.
• Reheat whole eggs.
• Drymeals,herbs,fruits, vegetables,
gourds,wood items orwetpapers.
• Dry nuts or seeds in the shell.
• Heat, cook or can in closed glass
jars or air tight containers.
•
Homecan inthemicrowaveasharmful
bacteria may not be destroyed.
• When using oven cooking bags,
use plastic ties or cotton string to
close bag.
• Stirliquidsbefore and afterheating
to help prevent “eruption.”
• Baked items with fillings shouId be
cut open to allow steam to escape
and avoid burns.
• Pizzasaucecan become extremely
hot. Check temperatures before
eating.
• Place baby food in a small dish and
heat gently, stir often, and check
temperature before serving.
• Place nipples/cap on bottles after
heating and shake thoroughly.
Always“wrist test” beforefeeding.
• Use popcorn packaged for
microwave ovens.
• Refer to popcorn package for
popping time.
Set the time early to
check popping.
Drying
Foods with Non-porous
Skins or Shells
Popcorn
Baby Food/Baby Formula
General
Home Canning

CM Oven Care and Use Manual
Features of Your Oven
TOUCH CONTROL PANEL
1Displays clock / time and oven modes and settings
UPPER OVEN
2Data Plate - behind oven cooling vents, right side
3Probe Receptacle (single oven or upper oven only)
4Microwave Seal (single oven or upper oven only)
UPPER/LOWER OVEN
11 Oven Cooling Vents (both ovens)
12 Broil Element (one in each oven)
13 Convection Fan and Baffle
(one per oven)
14 Bake Element
(under oven floor, one per oven)
LOWER OVEN
15 Removable Oven Door (lower oven only)
16 Oven Exhaust Vent and Trim
(at bottom, under double or single oven)
17 Broil Pan, 2-piece
18 Meat Probe
UPPER OVEN/LOWER OVEN
5Door Lock Latch, automatic (one per oven)
6Halogen Oven Lamps (2 in each oven)
7*Rack Supports (both ovens)
8Removable Racks (3 in each oven)
9Door Gasket (one
per oven)
10 Door Cooling Vents (both ovens)
MODEL CM301
SINGLE OVEN
MODEL CM302
DOUBLE OVEN
1
5
4
3
6
2
7
8
9
1
12
19
11
10
11
➥
16 14
13
15
Oven Features
Page 6
*Rack support positions are numbered from the
bottom rail guide (#1) to the top (#6). Cooking charts
in this manual refer to the recommended rack positions.
17
18

CM Oven Care and Use Manual
CONTROL MENU
1. Upper Oven Mode Pads
• Microwave – selects microwave mode.
• CookSmart – selects a pre-set microwave power
level and convection temperature.
• Probe – selects interior meat temperatures with
Convection Roast mode.
• Pause/Resume – used with any microwave or
CookSmart™ mode to interrupt oven opera-
tion and check food (unlocks and locks door).
2. Upper and Lower Oven Mode Pads
• Convection - selects the Convection function and
may be used in combination with Bake, Roast or
Broil.
• Bake – selects the Bake mode.
• Roast – selects the Roast mode.
• Broil – selects the Broil mode.
• Proof/Dehydrate – touch once to select Proof
mode; touch twice to select Dehydrate mode.
• Self Clean – selects Self-Clean mode.
3. Timed Cooking Pads
• Cook Time – selects the hours to cook.
• Stop Time – selects the time of day the oven is
to automatically turn off.
4. Oven Selector Pads
• Upper/Lower – touch once to select the upper
oven; touch twice to select the lower oven.
• Upper Off – turns the upper oven off .
• Lower Off – turns the lower oven off .
NUMBER PADS
7. Number pads – 1 to 0 – selects a time of day,
temperatures, microwave power level, COOKSMART®
modes, cook and stop time or timer(s).
8. Start pad – touch this pad last to start cooking
modes or timing functions.
LIGHT, PANEL LOCK, CLOCK,TIMER(S),
and COOKSMART MENU
9. Light – turns oven lights on/off.
10. Panel Lock – locks the cooking modes in the off
position as a safety measure when ovens are not
being used.
11. Clock – selects the time of day on the 12-hour
or 24-hour clock.
12. Timers
• Timer 1 – sets a kitchen timer.
• Timer 2 – sets a second kitchen timer.
• Timer Off – turns timer(s) off.
13. Cooksmart Menu – describes food categories
for each CS setting.
SPECIAL FEATURES
• Sabbath Mode Setting – complies with some
religious requirements.
• 12 or 24 hour clock choice – clock setting
options.
• Fahrenheit or Centigrade – temperature
setting options.
Oven Control Features
MICROWAVE PROBE CONVECTION BAKE UPPER
LOWER
COOKSMART SELF CLEAN BROIL ROAST UPPER
1-2-3-4 OFF
PAUSE PROOF STOP COOK LOWER
RESUME DEHYDRATE TIME TIME OFF
LIGHT PANEL LOCK CLOCK
TIMER 1 TIMER OFF TIMER 2
CS+
1 - BREAD, DESSERT CS+3 - SMALL ROAST/POULTR
Y
CS+2 - LARGE ROAST/POULTRY CS+4 - VEGETABLES
12 3
45 6
78 9
START 0
DISPLAY WINDOWS
5. Clock
• Displays the time of day.
• Displays timer(s) countdown.
• Displays “Panel Lock” confirmation.
6. Oven
• Displays selected words, numbers and symbols.
Note: Control Panel shown is on a double oven model.
12
3
4
6
7
13
12
8
910 11
&
Oven Features
Page 7
5

CM Oven Care and Use Manual
UsingThe Control Panel
The control panel contains a series of electronic touch pads that enable you to set the oven. As you
touch these pads, words and numbers appear in the display windows. These word and number displays
are called “prompts” and show what has been selected and what must be done next.
Touch only one
mode or number pad at a time.
MICROWAVE PROBE CONVECTION BAKE UPPER
LOWER
COOKSMART SELF CLEAN BROIL ROAST UPPER
1-2-3-4 OFF
PAUSE PROOF STOP COOK LOWER
RESUME DEHYDRATE TIME TIME OFF
LIGHT PANEL LOCK CLOCK
TIMER 1 TIMER OFF TIMER 2
CS+
1 - BREAD, DESSERT CS+3 - SMALL ROAST/POULTRY
CS+2 - LARGE ROAST/POULTRY CS+4 - VEGETABLES
12 3
45 6
78 9
START 0
o
11
11
1
22
22
2 :
00
00
0
00
00
0
11
11
1
::::: 00
00
0
00
00
0
CONVECTION
ROAST
325325
325325
325
COOK TIME
12
3
457
6
9
1
2
3
5
CONTROL MENU
These pads set the oven modes and select the oven
to be used - in double oven models.
CLOCK /TIMER DISPLAY WINDOW
Clock andTimer settings are displayed in this win-
dow.
TheTimer settings countdown in minutes and
seconds; touch twice to set in hours and minutes.
MODE DISPLAY WINDOW
The settings are shown in this window to verify
what has been selected.
The display shows the oven
selected (in double oven models),cooking or timed
mode,elements on in the oven,oven temperature,
and the preheat function.
NUMBER PADS and START
The number pads select temperatures and time
settings in seconds,minutes and hours.It is neces-
sary to select the START pad to complete any mode
or timed entry.
6
7
8
CM301 model control panel shown in 20º open position.
➥
48
9
LIGHT
This pad is selected to manually turn on or off the
interior oven lights in either oven.
See Page 10.
CLOCK andTIMER MENU
These pads select the Clock and minute Timers
that operate independently of any oven mode.
These pads control the interior oven lights and
Panel Lock.
PANEL LOCK
/ Child Lockout
The Panel Lock is selected to prevent the control
pads from being activated when the oven is not
being used.
Touch and hold for 5 seconds to
activate; repeat to cancel.
TOUCH 'n' TILT PANEL
This panel is on the single oven CM301
model only. It can be used in the tilt or flush-to-
oven position. Push in along the center, bottom of
the panel to release latch and raise panel upward.
Push again to release latch and lower the panel.
Single oven model CM301will have only one
oven displayed on the control panel and
menu. Instructions and illustrations for
double oven models are used throughout
this manual.
COOKSMART™ MENU
Shows the type of food to cook in the
pre-programmed settings: CS+1, CS+2, CS+3,
CS+4
Note: Control Panel shown is on a double oven model.
Oven Features
Page 8

CM Oven Care and Use Manual
Interpreting the Control Panel: Sights & Sounds
The directions in the Care and Use Manual for setting the oven and its various modes are based on the
assumption that the panel displays and sounds will “lead” or help you set the controls easily. To aid in this
path, the following descriptions provide a basis for interpreting what is seen and heard.
Flashing Symbols or Numbers
Signals an incomplete setting; calls for another step or
START to be touched.
I Beep
Signals the receipt of an entry.
2 Beeps
Signal an error in entry.
4 Chimes
Signal the end of a setting.
Probe Symbol
Displays the internal temperature of the meat rather
than the oven roasting temperature.
Oven tempera-
ture can be seen briefly by touching the cook mode
after touching START.
Lock Symbol
Displays during the Microwave, CookSmart, and Self
Clean modes whenever the door is locked. Door can
be opened when symbol no longer appears.
PAU
Displays when a Microwave or Cooksmart program is
paused or interrupted and door unlocks.
Err
Displays if an invalid temperature or time is entered.
Power Failure
After the power returns to the oven,the clock displays
the time when the power was lost or turned off.
UPPER
LOWER
For use in double oven models only.
Selects the active oven to be set by
highlighting the oven in the mode display
window.
Default Settings
The cooking modes automatically select a suitable
temperature. These can be changed when a different
one is needed.
START
Touch to complete an entry and before entering an
additional one.
UPPER OFF and LOWER OFF
Touch to cancel a mode that has already been started
or completed.
COOK TIME
Sets the number of hours and minutes the oven will be
“on.”
Unlike Timer 1 or 2, the oven turns “off” auto-
matically when the time elapses. This pad is used with
the automatic timed oven control.
F Number Codes
These codes are displayed when there is a problem with
the signal sent to the electronic control board.
See Solv-
ing Operational Problems, Page 58.
Convection Fan
Operates during any convection mode.The fan turns
off if the door is opened.
Component Cooling Fan
Activates during any cooking or self-cleaning mode to
cool inner components and outer door surfaces.This
air is exhausted through the vent located below the
lower oven in double oven models. It continues to run
until components have cooled sufficiently.
Oven Features
Page 9

CM Oven Care and Use Manual
Setting the Clock
• Always set the clock immediately after installation
or after a power failure. Once power returns to
the oven, the clock displays the time of day when
power was turned off or lost.
1. Select the CLOCK pad. Touch
CLOCK
2. Set the current time of day. Touch
(Example shows 8 o’clock set for 8
the time of day.) 0
0
3. Select START or CLOCK. Touch
START
Setting the Lights
Touch
UPPER
LOWER
Touch
LIGHT
You Will See
• If 15 seconds elapse between touching the clock
pad or number pads,the mode is automatically can-
celled. Set again.
• The time of day clock can be set when an auto-
matic timed cooking mode is in operation.
You Will See
8:00
1. Select the “active” oven by touching once or
twice to highlight oven display.
2. Touch once to turn light on or off.
• Oven lights turn on automatically when the door is opened and off when closed.
• To set manually, always start by highlighting the oven, whether it is “active” or not.
(Touch the UPPER / LOWER pad to display the “active” oven; flashing outline indicates the active oven.)
• The same LIGHT pad activates the lights in either oven.
• The lights do not operate in the Self-Clean mode.
To manually control the interior oven lights if
either oven is in use:
SET CLOCK
––:––
8:00 SET CLOCK
Oven Features
Page 10
To Set the CLOCK:
OR

CM Oven Care and Use Manual
Setting theTimer
To Change aTimer:
1. TouchTIMER 1 orTIMER 2, whichever one you want to change.
2. Enter the new time.
3. Touch the START pad.
To Set BothTIMER 1 andTIMER 2:
Follow the steps above to set each timer. The timer with the least amount of countdown time has display
priority. The countdown display for the second timer is shown automatically when the first timer has ended.
The words “TIMER 1” and “TIMER 2” are both displayed along with the number countdown.
The word,“TIMER 1” or “TIMER 2,” with the least remaining countdown time is more brightly lit
than the other word.
During the countdown,touch CLOCK orTIMER. Depending on the pad touched,either the time of day
or the remaining time is briefly displayed.
• The oven has two minute timers which are independent of
each other. Neither one controls automatic oven operations.
• Touch once and the timer is set in minutes and seconds.
• Touch twice and the timer is set in hours and minutes.
To Cancel an ActiveTimer:
1. SelectTimer in use. Touch
TIMER 1 or 2
2
. CancelTimer. Touch
TIMER OFF
1. SelectTimer 1 or 2. Touch
TIMER 1
2. Set the amount of time. Touch
(Example shows a 3-minute 3
setting with Timer 1.) 0
0
3. Start Timer. Touch
START
4. When set time is complete, Touch
“End” is displayed and 4 chimes sig- TIMER OFF
nal. When turned off, display reverts
to time of day.
Tip: If timer is not turned off, chimes will continue every 30 seconds. After 5 minutes, chimes stop
and the display reverts to the time of day.
MIN SEC TIMER 1
3:00
SET
MIN SEC TIMER 1
––:––
MIN SEC TIMER 1
3:00
TIMER 1
End
You Will See
To Set TIMER 1 orTIMER 2:
Oven Features
Page 11

CM Oven Care and Use Manual
Heating Modes available only in Single or Upper Ovens
The following illustrations give an overview of the heating activity with each mode setting.The
arrows represent the heat source for specific cooking modes.
MICROWAVE – The microwaves enter
through the plate in the top of the oven. Select
from ten power levels when microwaving. See
Pages 22 – 27 for operation.
COOKSMART™ –
This mode combines pre-
programmed microwave energy and convection
temperatures. CookSmart settings cook in
approximately one-half the standard cooking
time. See Pages 14 – 21 for operation.
➝
➝
➝
➝
➝
➝
➝
➝
➝
➝
➝
➝
MICROBROIL – This mode combines
microwave and broil settings.The intense heat
from the upper element gives excellent top-
browning and microwaves shorten the total
cookingtime. Microbroil isbestfortendermeat,
poultry and fish that is more than 1-1/4inches
thick. See Pages 28 – 29 for operation.
Oven Features
Page 12

CM Oven Care and Use Manual
Heating Modes available in Each Oven
The following illustrations give an overview of what happens in the oven with each mode setting. The arrows repre-
sent the location of the heat source during specific modes.The lower element is concealed under the oven floor.
CONVECTION BROIL
Convection broiling combines the
intense heat from the upper element
with the circulation assisted by the
convection fan.
This air circulation
crisps the exterior surface and
retains inner moisture in meats
more than 1-1/2" thick.
CONVECTION ROAST
Convection roasting combines the
heat from the lower concealed ele-
ment with additional heat from the
convection ring element and the con-
vection fan. The result is a drier,
crispier exterior that seals in the in-
terior juices. It is perfect for roast-
ing tender meats in an uncovered,
low-sided pan.
CONVECTION BAKE
Convection Bake has heat from the
upper and lower element with
circulation assisted by the convection
fan. This mode is designed for breads,
pastries and pies.
CONVECTION or
DEHYDRATE
Convection is cooking with heat
from a third element concealed
behind the back wall of the oven. It
is used with a fan to speed up the
circulation of heated air throughout
the oven. Dehydrating holds an
optimum low temperature while
circulating the heated air to remove
moisture slowly for food
preservation.
BROIL
Broiling uses intense heat radiated
from the upper element to give
excellent top browning or searing.
ROAST
Roasting has more top heat than
baking.
This additional top heat is for
conventional open roasting when
drippings are desired or for covered-
dish roasting.
BAKE or PROOF
Baking is cooking with heated air.
Both upper and lower elements are
used to heat the air and circulate it
to maintain the temperature.
Proof-
ing, while similar to bake,
holds an
optimum low temperature for yeast
dough to rise.
Oven Features
Page 13

CM Oven Care and Use Manual
CookSmart® Mode – Upper or Single Oven ONLY
Continued next page.
Upper Oven Operations
Page 14
COOKSMART combines convection heat and microwave
energy to cook food in about half the conventional cook
time (i.e. 12 minutes conventional time = 6 minutes
COOKSMART time).
COOKSMART modes include:
CS1 - Breads, Desserts
CS2 - Large Roasts and Poultry
CS3 - Small Roasts and Poultry
CS4 - Vegetables
• EachCOOKSMART moderepresentsa pre-programmed
combination of convection temperature with a
microwave power level. Enter the conventional cook
time that is called for in your recipe. COOKSMART will
automatically reduce time entered when preheating
starts.
• Always Preheat before using a COOKSMART mode.
• Do not use COOKSMART mode when oven is empty.
1. Select once for UPPER oven.
Select twice for LOWER oven.
2. Select CookSmart™ Mode.
3. Use number pads to select food group 1,2,
3 or 4, (Example shows food group 1 selected).
4. Select the conventional cooking time.
5. Use number pads to set conventional cook
time.
(Example shows 12 minutes).
• Tip:
Cook time is displayed in conventional time
in hours and minutes.
Touch
UPPER
LOWER
Touch
COOKSMART
Touch
1
Touch
COOK TIME
Touch
1
2
You Will See
SET
HRS min
_ _ : _ _
0 : 12 SET
HRS min
C S 1
COOKSMART
C S -
COOKSMART
To Set a COOKSMART™(CS) Mode
• Select bakeware without a cover that is made of
either metal, oven-safe glass or glass ceramic. Metal
pansbecome hot quicklyandwill yield morebrowning.
• Select rack level before selecting the CS mode.
Remove all racks except one.
• Rack positions are numbered from the bottom
(position #1) to the top (position #6).
• Do not allow metal pans to touch each other or
arcing may occur.
• When using metal containers or foil, allow at least
1-inch (2.5 cm) spacing from oven walls.
• When using microwave, COOKSMART or combination
modes, do not leave an oven thermometer in oven
cavity.
• Do not use paper towels in oven when using
COOKSMART modes.
• Self-clean oven more frequently when using
COOKSMART mode.

CM Oven Care and Use Manual
CookSmart® Mode – Upper or Single Oven ONLY
7. After oven is preheated, add food and select
START.
• Motorized door latch locks door.
•COOKSMART cook time countdown begins.
Touch
START
You Will See
C S 1
Upper Oven Operations
Page 15
11. To add more time to a COOKSMART mode
after the original cooking time has ended.
• Repeat steps 1 through 5; then touch START
two times in succession. (The combination mode
starts immediately as the oven is already preheated.)
Touch
START
START
Touch
UPPER
OFF
10. To cancel a COOKSMART mode after
the mode has started, touch Upper Off .
• The door latch unlocks the door.
• Timer display reverts to the time of day.
Touch
UPPER
OFF
- or -
open the
door
9. At the end of COOKSMART cooking mode:
• Oven chimes 4 times and the word “End” is displayed.
• The door latch unlocks the door.
• Oven will continue to chime as a reminder to check
food.
• When the door is opened, the word “End” disappears
from this display and chimes stop.
EndEnd
EndEnd
End
8. To interrupt the mode or check doneness at minimum
cooking time:
Pause the cooking process by selecting
PAUSE/RESUME
• The door latch unlocks.
• Cooktime stops counting down (example shows
oven paused with 58 seconds remaining to cook).
To resume the cooking process close the door, touch
PAUSE/RESUME pad again.
• The door latch locks the door.
• Cooktime resumes counting down.
Touch
PAUSE
RESUME
Touch
PAUSE
RESUME
min sec
0 : 58
C S 1
PAU
PAUSE
min sec
0 : 58
min sec
6 : 00
6. Select START to preheat oven.
(Example shows cook time converted to CookSmart
time: 6:00 minutes.)
• When the oven reaches the correct temperature
one chime will sound and the word “PREHEAT”
disappears.
Touch
START
C S 1
PREHEAT
min sec
3 : 00

CM Oven Care and Use Manual
CookSmart® Mode – Upper or Single Oven ONLY
CS1- Guidelines for Breads and Desserts
•Preheat oven and bake using one rack at a
time.
• Use the conventional baking time given in a recipe.
• Timings on the chart are a guide.
• Metal pans become hot quickly and brown more than
glass or glass ceramic.
• Place rack in center of oven unless specified
otherwise.
• Biscuits and cookies should be left on pan for 3 to 4
minutes after removal from oven.
Breads, Yeast
White Loaf, Scratch or Frozen 3 9x5 aluminum loaf pan 25 to 30 minutes
White Braid or Baguettes 3 15x12 cookie sheet 25 to 30 minutes
French Loaf 3 15x12 cookie sheet 40 to 45 minutes
Rolls
Cinnamon 3 9x13 pan 20 to 25 minutes
Dinner, scratch 3
8" round pan or12-cup muffin tin 15 to 20 minutes
Breads, Specialty
Bread, Garlic, Fresh (1 lb.) 3 15x12 cookie sheet 18 to 22 minutes
Bread, Garlic, Frozen (1 lb.) 3 15x12 cookie sheet 20 to 24 minutes
Bread, Bruschetta (8 oz.) 3 15x10-1/2 x1 jelly roll pan 10 to 12 minutes
Focaccia 3 15x10-1/2 x1 jelly roll pan 35 to 40 minutes
Cornbread, Scratch 3 8x8 aluminum pan or pyrex 20 to 55 minutes
3 12-cup muffin tin 15 to 18 minutes
Cornbread, Mix (1 lb.) 3 8x8 aluminum pan or pyrex 30 to 35 minutes*
3 12-cup muffin tin 18 to 20 minutes
Quick Bread, Mix (14 oz.) 3 8x4 loaf pan 55 to 65 minutes
Scratch 3 8x4 loaf pan 50 to 55 minutes
Muffins
Scratch Muffins, Nut Variety 3 12-cup muffin tin 15 to 20 minutes*
Scratch, Mini-Muffins, Nut Variety 3 12-cup mini-muffin tin 12 to 16 minutes*
Biscuits
Refrigerator, Large (1 lb. 0.3 oz.) 3 15x12 cookie sheet 15 to 18 minutes*
Refrigerator, (12 oz.) 3 15x12 cookie sheet 8 to 11 minutes*
Crescent Rolls, refrigerated (8 oz.) 2 15x12 cookie sheet 11 to 13 minutes
Scones, 8 to 10 2 15x12 cookie sheet 12 to 15 minutes
CS1 FOOD ITEMS RACK PAN SIZE AND TYPE CONVENTIONAL
LEVEL COOK TIME
*May need longer cooking time. Chart continued next page
Upper Oven Operations
Page 16

CM Oven Care and Use Manual
CS1 FOOD ITEMS RACK PAN SIZE AND TYPE CONVENTIONAL
LEVEL COOK TIME
Brownies
Fudge, Scratch 3 8x8 aluminum or Pyrex®20 to 25 minutes
3 9x13 aluminum or Pyrex®20 to 25 minutes
Fudge, Mix (1 lb. 3 oz.) 3 9x13 aluminum or Pyrex®28 to 30 minutes
Cakes, Specialty
Angel Food, Mix (16 oz.) 1 10-inch aluminum tube 37 to 47 minutes
Bundt, Scratch 3 12-cup bundt 40 to 45 minutes
Carrot, Scratch 3 9x13 aluminum 35 to 40 minutes
Cheesecake 3 9" springform pan 35 to 40 minutes
Pineapple Upside-Down 3 8" round glass dish 30 to 35 minutes
Streusel Coffeecake,
Mix (1lb. 10.5 oz.) 3 12-cup bundt 40 to 45 minutes
3 9x13 aluminum or Pyrex®35 to 40 minutes
Mix
(18.3 oz.) 3 8x8 aluminum or Pyrex®25 to 30 minutes
Mix
(10 oz.) 3 Pan included in package 21 to 26 minutes
Streusel Coffeecake, Scratch 3 9x13 aluminum or Pyrex®45 to 60 minutes
Gingerbread, Mix 3 8x8 glass 20 to 25 minutes
Cookies
Scratch, Bar 3 15x10-1/2x1 jelly roll pan 20 to 25 minutes
Scratch, Drop 3 15x12 cookie sheet 8 to 10 minutes
Scratch, Rolled and Cut 3 15x12 cookie sheet 7 to 8 minutes
Refrigerated Dough 3 15x12 cookie sheet 9 to 11 minutes
Pastry Crust
Frozen 1 9" aluminum in package 7 to 9 minutes
Graham Cracker 3 9" Pyrex®pie pan 8 minutes
Pies, Cobblers, Fruit Crisps
Pie, two-crust scratch,
Apple or Cherry 1 8" or 9" aluminum or 50 to 60 minutes*
9" Pyrex®pie pan
Pecan 1 9" metal or Pyrex® pie pan 45 to 50 minutes
Pumpkin 1 9" metal or Pyrex® pie pan 55 to 65 minutes
Cream Cheese 3 9" Pyrex® pie pan 20 to 25 minutes
Cobbler, fruit, with biscuit topping 3 9x13 metal or glass or 20 to 25 minutes
2 quart deep dish
Crisp, fruit (peach or apple) 3 8x8 or 9 x 13 aluminum 30 to 35 minutes
or Pyrex®
Quiche
Pre-baked crust 1 9" Pyrex®pie pan 35 to 40 minutes
CookSmart® Mode – Upper or Single Oven ONLY
(continued from previous page)
*May need longer cooking time.
Upper Oven Operations
Page 17

CM Oven Care and Use Manual
CookSmart® Mode – Upper or Single Oven ONLY
CS2 – Guidelines for Large Roasts and Poultry
• Allow approximately 1/2 the calculated cooking time.
• Use this mode for meats over 4.5 lbs.
• Allow refrigerated meats and poultry to be at room
temp for 15-20 minutes before roasting. Prepare
meats at this time.
• Cook all large meat items on Rack 1, 2 or 3, depending
on height.
• Use bottom broiler pan of 2-piece broiler set.
• For lamb, whole chicken or turkey, use V-rack in
bottom broiler pan.
• Preheat before placing food in oven.
• Do not leave a meat thermometer in meat during
roasting.
• Check food at minimum roasting time for doneness.
• After cooking, allow meat to stand covered with foil
for 15-20 minutes before carving/serving.
• Food will continue to cook during recommended
standing time, and temperatures will even out and
will rise approximately 10-15 degrees during this time.
• Oven probe cannot be used in this mode.
• Refer to Page 41 for Food Safety Guidelines.
Tips for roasting a turkey:
• Remove wire leg clamp from turkey before roasting.
• To prepare turkey for roasting, tuck wings behind
back and loosely tie legs with kitchen string.
• Cover top of breast and ends of legs with wide strips
of foil. After half of the cooking time has expired,
remove foil on breast area.
• Cook only unstuffed turkeys in this mode.
Upper Oven Operations
Page 18
CS2 LARGE ROASTS and WEIGHT COOK TIME
POULTRY Minutes Per Pound
Lamb:
Leg of Lamb 5 to 6 Ibs. 22 to 23 minutes / lb.
(cover small end of leg with foil)
Pork:
Loin roast 4.5 to 6 Ibs. 24 to 26 minutes / lb. 150º F (66º C) 160º F to 165º F
(tied double) (71º C to 74º C)
Turkey:
Whole 12 to 16 lbs. 13 to 15 minutes / lb.
17 to 21 lbs. 11 to 13 minutes
/ lb.
22 to 26 lbs. 9 to 12 minutes
/ lb.
Breast, with bones, skin 4.5 to 7 lbs. 19 to 21 minutes
/ lb.
Whole turkey
(netted), boneless 5 to 7 lbs. 13 to 15 minutes / lb.
Beef:
Rib Roast with bones 4.5 to 6 Ibs. 23 to 25 minutes / lb.
6.5 to 8.5 Ibs. 17 to 20 minutes / lb.
Rib Eye Roast, boneless 4.5 to 6 Ibs. 19 to 21 minutes / lb.
6.5 to 8.5 Ibs. 16 to 19 minutes / lb.
Salmon:
Whole filet 4.5 to 5.5 lbs. 35 to 42 minutes total
CONVENTIONAL
END
TEMP
DONENESS
CARVING
TEMP
Lamb should be removed from oven when
internal temperatures reach 120-125ºF (55
-57ºC). Aftercoveringwith foilandstanding,
serving temps should be 140ºF (60º C) for
rare, 145ºF (63º C) for medium rare and
150º (66ºC) for medium.
Turkey should be removed from oven when
internal temperatures reach 160º F (68º C)
in the breast and 170ºF (77ºC) in the thigh.
After covering with foil and standing, serving
temps should be 170º – 175ºF (77 – 79º C).
Roast may be turned over halfway during
cooking time. Beef should be removed from
ovenwhen internaltemperatures reach120-
125º F (55 - 57º C). After covering with foil
and standing, serving temps should be
140º F (60º C) for rare, 145º F (63º C) for
medium rare and 150º F (66º C) for medium.
Fish should be removed from oven when
fish flakes with a fork.
