Thermaltake swingrs 100 VF8000 series User manual

VF8000 Series
SwingRS 100
2007 Thermaltake Technology Co., Ltd. All Rights Reserved. 2007.04
C
Tested To Comply
With FCC Standards
FOR HOME OR OFFICE USE
All other registered trademarks belong to their respectivecompanies. www.thermaltake.com
VF8000 Series
SwingRS 100
User Manual

VF8000 Series
SwingRS 100
2
1
Chapter 1. Product Introduction
Chapter 2. Case Mechanical Operation
Specification
Chapter3 Motherboard & Lends Installation
Motherboard installation
Case LED connection
USB2.0 connection
eSATA connection
Audio connection
2-1
2-2
2-3
2-4
2-5
2-6
2-7
2-8
How to open the side panel
Transparent side panel
Honeycomb see-through side panel
How to install PSU
5.25" device installation
HDD installation
3.5" device installation
Motherboard installation
PCI slot usage
Front fan installation (optional)
1-1
3-1
3-2
3-3
3-4
3-5
Chapter4 RSI Cooler and Power Supply
RSI Cooler (Optional)
RSI Power Supply (Optional)
4-1
4-2
02
03
03
04
05
06
08
09
10
11
12
14
15
16
16
17
18
Specification
Chapter 1. Product Introduction
ContentS
19
Model
Case Type
Side Panel
Dimension
(H*W*D)
Cooling System
Drive Bays
- Front accessible
- Internal
Material
Color
Expansion Slots
Motherboards
VF8000BNS
Full Tower
Honeycomb
see-through window
540.0 x 205.0 x 500.0 mm
(21.3 x 8.1 x 19.7 inch)
Front (Intake) :
120 x 120 x 25 mm (optional)
Rear (Exhaust) :
120 x 120 x 38 mm, 1200rpm, 17dBA
12
5 x 5.25", 2 x 3.5"
5 x 3.5"
SECC
Black
7
Micro ATX , Standard ATX
I/O Ports USB 2.0 x 2, e-SATA connector x 1, HD Audio
VF8000BWS
Transparent window
PSU Standard ATX PSII (Option)

VF8000 Series
SwingRS 100
4
3
2-1 How to open the side panel
Chapter 2. Case Mechanical Operation
To remove the side panel,
please remove upper and
bottom thumb screws on
the back of the case.
Push the handle then swing
out the side panel.
Transparent side panel
To remove the side panel,
please remove upper and
bottom thumb screws on
the back of the case.
Push the handle then swing
out the side panel.
Honeycomb see-through side panel
Insert the provided key
and turn it clockwise.
1
2
1
2
3

VF8000 Series
SwingRS 100
6
5
2-3 5.25" device installation
2-2 How to install PSU
Place power supply unit
in the right position.
Secure it by screws as shown.
1
2
Open the front panel first.
Remove the 5.25" drive bay
metal cover.
Remove the 5.25" drive bay
plastic cover by pressing it
at the bottom corner.
1
2
3
1
2
Find the drive bay rails right
behind the plastic drive bay
cover.
4

VF8000 Series
SwingRS 100
8
7
Slide the 5.25" device into
drive bay till the fix-position.
Mount drive rails to 5.25"
device and fasten the
device using screws.
5
6
5.25" device installation
complete.
7
2-4 HDD installation
Press the clip on each side of
the HDD tray and pull backward
to take off the HDD tray.
Slide HDD tray into the
cage till the fix-position.
Place HDD on the drive tray,
then secure HDD by screws.
1
2
3
HDD installation complete.
4
1
2

VF8000 Series
SwingRS 100
10
9
2-5 3.5" device installation
Press the clip on each
side of the 3.5" tray
and pull backward to
take off the 3.5" tray.
Place and fasten 3.5" device by screws.
Unscrew the 3.5"
metal cover.
12
3
1
2
Slide the 3.5" tray
into drive bay till the
fix-position.
3.5" device installation
complete.
45
Remove thumb screws on the motherboard tray.
Slide the motherboard
tray toward the drives
and remove it.
1
2
Place the motherboard
tray back to the case
and slide it back to the
position.
Screw up the thumb screws.
45
2-6 Motherboard installation
Place the motherboard
tray on a flat surface and
mount the motherboard.
3
Note:
While doing motherboard
installation, please also
refer to Page 14.

VF8000 Series
SwingRS 100
12
11
2-7 PCI slot usage
Take off the tool-free
kit as shown.
Locate Graphic Card to
the motherboard
through fixing it on the
space of PCI bracket.
Remove the PCI bracket.
12
3
Installation complete.
5
2-8 Front fan installation (optional)
Put back the tool-free
kit to lock the Graphic
Card as shown.
4
Note:
1.If your add-on card is a 2-slot
add-on card or have trouble
securing your PCI card, please
remove the tool-free kit from the
chassis and secure PCI card by
screws.
2. If you are system integrator, we
strongly recommend to secure
add-on cards using screws.
Remove both side panels.
Remove the front panel using a flat-head screwdriver.
1
2
Take off the whole front panel.
3
1
2

VF8000 Series
SwingRS 100
1413
Place the 120mm fan and
fasten the fan by screws.
Find the fan filter from the
enclosed package and place
it on the fan. Front fan
installation complete.
4
5
3-1 Motherboard Installation
Chapter.3 Motherboard & Leads Installation
Each motherboard has different standoff layout. It is highly suggested
that you refer to your motherboard's manual when installing
motherboard into the Case. The cases are applicable with Standard ATX,
Micro ATX motherboards. Your motherboard may require a special I/O
Panel, which should be included with your motherboard.
Placement Direction:
When installing the motherboard, make sure you follow the direction
provided by your motherboard manufacturer. On most standard
motherboards, the edge with external ports goes to the rear part of the
chassis. It is highly recommended that you install CPU, heat sink and
modular components before fixing the motherboard inside the chassis.
Note
Due to the variety of motherboards on the market, the majority of the
motherboards come with their own I/O plates. It s necessary for you
to remove the fan holder before install the I/O plates.
478
The locations of the
screw holes. Note
these locations and
place included
standoffs on the
chassis first.
Above illustration is a sample of what the motherboard's
layout. For more detail screw hole placement, please refer
to your motherboard manual.
This side towards
the rear of the
chassis

VF8000 Series
SwingRS 100
1615
3-2 Case LED connection
On the front of the case, you can find some LEDs
and switch leads (POWER SW*1, POWER LED*1,
H.D.D. LED*1, RESET SW*1). Please consult user
manual of your motherboard manufacturer, then
connect these leads to the panel header on the
motherboard. These leads are usually labeled;
if not, please trace them back to the case front to
find out their source.
POWER LED
connects to your M/B at the PLED
POWER SW
connects to the PWR connector on the motherboard.
H.D.D LED
connects to the 2-pin labeled HDD LED connector.
RESET SW
connects to the RSW connector on the motherboard,
SPEAKER
connects to the SPK connector on the motherboard
VCC
-D
+D
GROUND
RED
WHITE
GREEN
BLACK
KEY
RED
WHITE
GREEN
BLACK
NC
VCC
-D
+D
GROUND
USB Function
3-3 USB 2.0 connection
Please consult your motherboard
manual to find out the section of
"USB connection".
3-4 eSATA connection
Connect this to your
motherboard at SATA.

VF8000 Series
SwingRS 100
18
17
RED
BROWN
YELLOW
PURPLE
BULE
BLACK
BLACK
ORANGE
KEY
GREEN
PORT1 L
PORT1 R
PORT2 R
SENSE_SEND
PORT2 L
AUD GND
PRESENCE#
SENSE1_RETURN
SENSE1_RETURN
AUDIO AZALIA Function
MICIN
MIC POWER
R-OUT
L-OUT
RED
BROWN
YELLOW
NC
BULE
BLACK
NC
YELLOW
KEY
BLUE
GROUND
R-RET
L-RET
AUDIO AC'97 Function
- Please refer to the following
illustration of Audio connector
and your motherboard user
manual.
- Please select the motherboard
which used AC'97 or HD Audio
(Azalia), (be aware of that
your audio supports AC'97 or
HD Audio (Azalia)) or it will damage your device(s).
- On some motherboards, the connectors for Audio
are not the same as the drawing below. Please check
with your motherboard manual before installing.
3-5 Audio Connection 4.1 RSI Cooler (Optional)
Chapter4 RSI Cooler and Power Supply
FEATURES :
- Perfect ratio aluminum extrusion heatsink
for better heat dissipation.
- Tool-less clip, easy installation.
- Silent Solution
FEATURES:
- Aluminum Crotch Fin provides more heat
dissipation area.
- Silent operation.
Optimized solution for low power processors.
- Back plate & Spring Screw mounting method
ensure safe installation when shipping.
P/N : CL-P0441
Designed for Intel Core 2 Duo Processor
Application for Intel Core 2 Duo / Pentium D /
Celeron series (Socket LGA775)
P/N : CL-P0444
Application for
AMD Athlon 64 X2/Athlon 64 FX/
Athlon 64(Socket AM2/ 939/754) and
Sempron (Socket AM2/754)

VF8000 Series
SwingRS 100
20
19
There are recommended products of Thermaltake PSU,
please refer to http://www.thermaltake.com
FEATURES:
- Intel ATX 12V 2.0 Compatible.
- Supports 6-pin PCI-Express, 2 SATA, and 20+4 pin connector.
- Dual +12V output circuit provides steady output for system.
- Super quiet and stable 12cm ball bearing fan.
- Build-in Over Current Protection, Over Voltage protection, and
Short-Circuit protection.
- Safety : UL, CUL, CE, NEMKO, TUV+CB, BSMI, FCC certification.
Litepower
400W
P/N: W0161 W/PFC P/N: W0162 No PFC
ATX
12V 2.0
X1
PCI
Express
X2
S-ATA
AMD/
Intel
Dual Core
Support
PFC
Universal
24(20)
Pin
4-2 RSI Power Supply (Optional) MEMO
