Thermaltake VL20001W2Z User manual

©2009 Thermaltake Technology Co., Ltd. All Rights Reserved. 2009.08
All other registered trademarks belong to their respective companies. www.thermaltake.com
Tested To Comply
With FCC Standards
FOR HOME OR OFFICE USE
Create for eSports
User's Manual 安裝說明書
Benutzerhandbuch 用戶手冊
Mode d’emploi ユーザーズマニュアル
Manual del usuario Руководство пользователя
Manuale dell’utente kullanıcı elkitabı
VL20001W2Z
產品料 號
V L 2 0 0 0 1 W 2 Z E l e m e n t V說明書 09/ 07/ 30 A
產品名 稱 印刷項 目 子件料 號 發稿日 期 版本
騎馬釘2 8 8 0X X X X X X XX 書寫紙 單色 無無
其他特殊處理效果表面處理
2
厚度(g/m )
折數 裝訂方 式 材質雙面印 刷 頁數 印刷 色 彩單面印 刷
規格樣 式
單張 整本 MARKETING CHECK DESIGN
PRODUCT GM
其他特 殊 處 理效果表面處 理
2
厚度(g/m )
材質印刷色彩
封面樣式（當封面與內頁樣式不同時尚須填寫)
Peipei
藍色線條為尺寸標示，請勿印刷上去！ 刀模線
125 mm
176 mm

1 2
Chapter 1. Product Introduction
Specification
CPU Cooler Height & VGA
(Add-on card) Length Limitation
1.0
1.1
02
03
Chapter 2. Installation Guide
2.0
2.1
2.2
2.3
2.4
2.5
2.6
2.7
2.8
2.9
Side Panels Disassembly
Motherboard Installation
5.25” Drives Installation
3.5” HDD Installation
2.5” HDD Installation
Power Supply Unit (PSU) Installation
PCI Card Installation
Keyboard & Mouse Security Lock Usage
Fan Speed & Light Control Operation
Water Bottle Cage Installation
05
07
08
10
12
13
14
15
16
18
Contents
Chapter 3. Leads Installation Guide
Leads Installation Guide
eSATA Connection
3.0
3.1
19
24
Chapter 4. Other
Toughpower/ Purepower/
TR2 power supply series (optional)
4.0
25
1.0 Specification
Model
Case Type
Net Weight
Dimension
(H*W*D)
Cooling System
Drive Bays
- Accessible
- Hidden
Material
Color
Expansion Slots
Motherboards
I/O Ports
LCS Upgradable
PSU
Removable PSU Bridge
Adjustable PSU Bridge
12
5 x 5.25”
6 x 3.5” , 1 x 2.5”
SECC
Black
7
9.6” 12” x 13” (Extend ATX)x 9.6” (Micro ATX), 12” x 9.6” (ATX),
USB 2.0 x 4, eSATA x 1, HD Audio x 1
Support 1/2” , 3/8” , 1/4” water tube
Standard PS2 PSU (Optional)
v
v
VL20001W2Z
Full Tower
14.13 kg / 31.15 lb
532 x 220 x 537 mm
(20.9 x 8.7 x 21.1 inch)
Open Window
Side Panel
Front (intake) :
120 x 120 x 25 mm Touchcolor fan x 1 (1000~1400rpm,17dBA)
120 x 120 x 25 mm Turbo fan x 1(1400rpm,17dBA)
Rear (exhaust) :
120 x 120 x 25 mm Turbo fan (1400rpm,17dBA)
Top (exhaust) :
200 x 200 x 20 mm Touchcolor fan (600~800rpm, 12~14dBA)
200 x 200 x 20 mm x 1(optional)
VGA (exhaust) :
50 x 50 mm fan x 2 (optional)
Side (intake) :
Plug&Play 230 x 230 x 20 mm Touchcolor fan (600~800rpm, 13~15dBA)
- Case LED connection
- USB 2.0 connection
- Audio connection
